29FA1029FA10
COLOUR TELEVISION
OPERATING
INSTRUCTIONS
◆Stage curtain for open and close effect
◆218 programs stored
◆Multi-picture modes and sound modes selection
◆On/Off timer
◆Child lock
◆Soft exchange
◆Appointment
◆DVD component input
◆Surround sound
01
0090500881
CONTENTS
WARNING AND CAUTIONS
Warning and cautions................................................................................................1
Basic feature..............................................................................................................2
Technical specification..............................................................................................2
Preparing for operations............................................................................................3
Function buttons and external sockets......................................................................4
AV connections........................................................................................................5
Remote controller guide...........................................................................................6
Power supply............................................................................................................7
Tuning procedure.....................................................................................................7
Picture and audio adjustment function ..................................................................11
Time function.........................................................................................................14
Setting function .....................................................................................................17
Game......................................................................................................................22
Trouble shooting guide..........................................................................................23
1. When you clean the TV set, please pull
out the power plug from AC outlet.
Or may result in electric shock, fire or
damage to the TV set. Don't clean the
cabinet and the screen with benzene,
petrol and other chemicals.
2. In order to prolong the using life of the
TV set, please place it at a well ventilated
location.
3. Don't place the TV
set in direct sunlight
or near heat source.
4. Do not place the TV set near rain
or moisture as it may cause an electric
shock, or the TV set to catch fire. The TV
set must only be used
in dry indoor location.
5. The back cover must only be removed
by a registered electrical service person.
Removing the back cover may result in
electric shock, fire or damage to
the TV set.
6. If the TV set is not going to be used for
a long time, or there is a severe thunder &
lightening storm, it is recommended that
the TV set be disconnected from the AC
power outlet and the aerial plug
Explanation on the display tube
When the picture tube requires cleaning, please disconnect the power and use a
dry soft cotton cloth. Do not use any cleaner or abrasive cloth.
1
BASIC FEATURE
◆Stage curtain for open and close effect
◆218 programs stored
◆Multi-picture modes and sound modes selection
◆On/Off timer
◆Child lock
◆Soft exchange
◆Appointment
◆DVD component input
◆Surround sound
PREPARING FOR OPERATIONS
Antenna connection
Antenna
Connect an antenna to the antenna socket on
the TV set, we recommend using a Cable TV
system for better picture and audio quality.
1.If you use a coaxial cable(75Ω),insert the
antenna plug (see figure C) into 75Ωsocket
(see figure A).
2.If you use a twin-lead cable(300Ω),please
Figure A Figure B
75-300Ω
Antenna adapter
shape the cable as figure D, and connect the
leads to antenna adapter and then insert the
antenna adapter into the 75Ωsocket(see
figure B).
TECHNICAL SPECIFICATION
1.CRT: 29"
2.COLOUR SYSTEM: PAL N TSC4.43/3.58(AV)
3.AUDIO SYSTEM: BG DK I M N
4.POWER SUPPLY: See rating plate
5.POWER CONSUMPTION: See rating plate
6.ANTENNA INPUT IMPEDANCE : 75Ω
7.SOUND OUTPUT POWER: 5W+5W
8.NET WEIGHT(Kg): 4 6
9.NET DIMENSION (mm): 800 × 525 ×598
Supplied accessories:
Infrared remote control handset 1
Battery(AA) 2
Operating instruction 1
Design and specifications are subject to change without notice.
Antenna cable
with a plug
Figure C Figure D
Coaxial cable(75Ω) twin-lead cable(300Ω)
Antenna feeder
Power source wire connection
Insert the power plug into AC outlet.
Install and replace batteries of the
remote control unit:
1.Place the remote control unit with the face
down, then open the battery cover of the
unit.
2.Place the two"AA"size batteries, matching
the + and - signs on each battery to the +
and -signs of the battery compartment.
3.Close the cover of the battery compartment.
NOTE:
(1)Don't drop or wet or dismantle the unit.
(2)If you don't intend to use the unit for a
long period or the electricity of the
batteries is used up, remove the batteries
to prevent batteries acid from leaking
into the battery compartment.
(3)Replace the two old batteries at the
same time.
(4)Don't use charge battery (Ni-cd )and
don't mix battery type.
(5)Don't throw your batteries into a fire.
Dispose of your batteries in a required
place.
2
3
FUNCTION BUTTONS AND EXTERNAL SOCKETS
操
1.Front Panel
作
之
前
①
③
MENU
TV/AV
VOL-
VOL+
CH-
CH+
④
⑥⑦
⑤
②
AV CONNECTIONS
Direction of signal
W
white（left audio）
R
red（C /right audio ）
blue（C ）
B
green
G
yellow
Y
r
b
（Y）
（video）
①Remote sensor:Let the remote controller aim here the set can receive remote
control signal.
②Power switch:Press the button to turn on the TV set ,press the button again to turn
off the TV set.
③Power indicator: The indicator lights when power on.
④Menu button
⑤Program up/down button
⑥Volume up/down button
⑦TV/AV
2.The sockets on the rear panel
①Antenna socket
②Audio/Video socket
③S-Video socket
④DVD component socket
Cb
L AUDIO R
Cr
①
②
④
③
S-VIDEO
Y
IN
VIDEO
OUT
VIDEO
AUDIO
Cb
L AUDIO R
W R
Cr
DVD(with DVD component)
T
t
tpu
u
o
o
v
ide
To
o
a di
u
W
G R
o
o
u
t
R
o
m
o o
B
p e t
n
n
o t
uT c
Y
IN
S-VIDEO
VCR (without S-VIDEO terminal)
R
L
W R
Y
VIDEO
OUT
VCR (with S-VIDEO terminal)
t
o
utpu
id o
v
s e
o
T
Note:
1.When receives s-video signal, you must remove video signal; when receive
video signal, you must remove s-video signal.
2.When receive front video signal, you must remove back video signal; when
receive back video signal, you must remove front video signal.
4
5
REMOTE CONTROLLER GUIDE
Remote controller functions
1
2
3
4
5
6
7
8
9
TV/AV
1 2 3
4 5 6
7 8 9
-/--
0
P.STD
VOL- VOL+
PRE
STEREO
MODE
CALENDAR
CH+
MENU
CH-
EXIT
LOCK
SCAN
SYSTEM
DISPLAY
S.STD
BACK
GAME
Intell igent butt on:
The numeric bu tt on“1”has intell igent fu ncti on,
pre ss it fo r 6s, then th e TV set wil l se arc h and sto re
the program auto mati call y. Press 0 butt on conti nually
for 6s, th e brig htness, color, sh arp n ess and ti nt will be
adju ste d to the fa cto ry pre se t sta tus auto mati call y.
20
19
18
17
16
15
14
13
12
11
10
1
TV/AV exchanging button
2
Mute button
3
Numeric button
One/two/three digital buttons
4
5
Picture mode selection
6
Volume up/dwon button
7
Program play-forward button
8
Surround sound selection button
9
Game background selection button
10
Game exit button
10
11
Game start or restart button
12
Program play-backward button
13
Volume mode selection
14
Display button
15
Calendar display button
16
System preset button
17
Scan button
Lock preset button
18
19
DC standby button
20
Sleep timer
POWER SUPPLY
Power supply (switch on/off to set main power supply).
1.Press power switch button to switch on AC power supply. The red power indicator
will light.
2. Press the power switch button on the remote controller to enter normal receiving
condition when the TV set is in standby condition.
TUNING PROCEDURE
There are Auto-search, Semi-Auto search and
Fine tuning method.
Auto-search
1.Press [MENU] button, let main menu display
on the screen, then press [-VOL+] buttons to select
TUNING item.
2.Press [CH-] button to enter TUNING menu, then
press [-CH+] buttons to select AUTO MEMORY.
3. Press [VOL+] button to make the AUTO MEMORY
mode work, the TV set will begin to search
programs from program number 0.
After the search is finished, program number
0 will display on the screen.
Note: During auto-search, if you want to stop searching,
press [VOL-] button.
AUTO MEMORY
ASM VL 0
STOP
TIMER
TUNING
SOUNDPICTURE
SELECT
POSITION 01
BAND VL
SKIP OFF
SEARCH DOWN
MFT UP
49.87 MHZ
SELECT
FUNCTION
CONFIRM
ADJUST
6 7
TUNING PROCEDURE
Semi-Auto search
1.Press [-CH+] buttons or numeric button (0~9) to
select the channel number you need. (For example:
channel 1).
2.
Press [MENU] button, let main menu display on the
screen, then press
item.
3.Press [CH-] button to enter TUNING sub-menu. Then
press
[CH-] button to select SEARCH item.
4.Press [-VOL+] buttons to start searching.
is to search the program from low FC. [CH+] button is
to search the program from high FC. Repeat above
procedure until you find the channel you need.
5.When you intend to memory another channel in
another position, press [-CH+] buttons to select
POSITION item, and use [-VOL+] button to select
a number you need, then press [CH-] button to
select SEARCH, and repeat fourth
procedure.
[-VOL+] buttons to select TUNING
[CH-] button
TIMER
TUNING
SOUNDPICTURE
SELECT
POSITION 01
BAND VL
SKIP OFF
SEARCH DOWN
MFT UP
AUTO MEMORY
49.87 MHZ
SELECT
POSITION 01
BAND VL
SKIP OFF
SEARCH DOWN
MFT UP
AUTO MEMORY
49.87 MHZ
SELECT
POSITION 01
BAND VL
SKIP OFF
SEARCH DOWN
MFT UP
AUTO MEMORY
49.87 MHZ
SELECT
FUNCTION
CONFIRM
ADJUST
ADJUST
ADJUST
TUNING PROCEDURE
Skip
After pre-tuning the channel, you can skip the
channel you do not need in order to only select
the channel you want to watch.
1.Press [-CH+] buttons or numeric button(0~9) to
select the channel number skipped(for example:
channel 1).
2.Press [MENU] button, let main menu display on
the screen, then press [-VOL+] buttons to select
TUNING item, then press [CH-] button to enter
TUNING menu.
3.Press [-CH+] buttons to select SKIP item.
4.Press [-VOL+] buttons to set SKIP ON mode.
5.Press [DISPLAY] button to shut off the menu. The
channel number will be skipped when you use
[-CH+] buttons to select channels. But you can
still use numeric button to select the channel
number skipped.
Note:
1.You can use the numeric button to select the
channel number that need recover.
2.Press [MENU] button to let the main menu
appear on the screen, then press [-VOL+]
buttons to select TUNING, and press [CH-]
button to enter TUNING menu, then select SKIP.
3.Press [-VOL+] buttons to set SKIP OFF mode.
POSITION 01
BAND VL
SKIP OFF
SEARCH DOWN
MFT UP
AUTO MEMORY
49.87 MHZ
SELECT
POSITION 01
BAND VL
SKIP OFF
SEARCH DOWN
MFT UP
AUTO MEMORY
SELECT
POSITION 01
BAND VL
SKIP OFF
SEARCH DOWN
MFT UP
AUTO MEMORY
SELECT
ADJUST
49.87 MHZ
ADJUST
49.87 MHZ
ADJUST
1
8
9
TUNING PROCEDURE
PICTURE AND AUDIO ADJUSTMENT FUNCTION
Fine tuning
Because of some reasons, if auto searching effect of program
isn't good, please fine tune your TV set.
1.Press [-CH+] buttons or numeric button(0~9)
to select the channel number that need to fine
tune.( For example: channel1)
2.Press [MENU] button, let main menu display on
the screen, then press [-VOL+] buttons to select
TUNING item, then press [CH-] button to enter
TUNING menu.
3.Press [-CH+] buttons to select MFT item.
4.Press and hold [-VOL +] buttons until the effects
of the picture and audio are good.
[VOL -] button is to search program from low FC.
[VOL+] button is to search program from low FC.
POSITION 01
BAND VL
SKIP OFF
SEARCH DOWN
MFT UP
AUTO MEMORY
49.87 MHZ
SELECT
POSITION 01
BAND VL
SKIP OFF
SEARCH DOWN
MFT UP
AUTO MEMORY
SELECT
ADJUST
49.87 MHZ
ADJUST
Picture mode selection
You can select the picture mode you need
quickly in five preset modes and a user's
personal set.
1
Press [ P.STD] button to select the picture
quality you need. There are six picture modes
you can select in turn.
DYNAMIC, STANDARD, MILD, MEMORY,
PICTURE MUTE and COLOR MUTE.
Mode Picture quality
DYNAMIC Rich , Bright Movie
STANDARD Proper color
MILD Soft, Light
MEMORY The picture quality you set
PICTURE MUTE function ( no signal)
Picture mute
DY NAMIC
STANDARD
MILD
ME M O RY
PICTURE MUTE
COLOR MUTE
COLOR MUTE Black &White picture
Note: If the picture in PICTURE MUTE or COLOR MUTE
status, the TV set will recover to DYNAMIC
status when restart.
Adjust the picture status you need to Memory.
Press [MENU] button, let main menu display on
1.
the screen, then press [-VOL+] buttons to select
PICTURE item, then press [CH-] button to enter
CONTRAST 100
BRIGHT 50
COLOR 50
SHARP 50
B.B ON
PICTURE menu.
SELECT
ADJUST
2.Press [-CH+] buttons to select the item you want
to adjust, then press [-VOL+] buttons to adjust to
your expect effect. The picture status will be stored
to the COLOR MUTE item.
Item Press [VOL-]button
Press [VOL+]button
CONTRAST Weak Strong
BRIGHT Dark Bright
COLOR Light Dark
SHARP Soft Sharp
B.B Light green Light purple
10
Note: Tint is only appear in N signal, the method of adjustment is the same
as above.
11
PICTURE AND AUDIO ADJUSTMENT FUNCTION
PICTURE AND AUDIO ADJUSTMENT FUNCTION
Sound mode selection
You can select the sound mode you need from
three modes quickly.
Press [S.STD] button to select the sound quality
you need. There are THEATER, NEWS, MUSIC,
PERSONAL to select in turn.
Volume set function
You can adjust the volume to your preset value
quickly(for example: BASS, TREBLE, BALANCE
or S.WOOFER)
1.Press [MENU] button to let main menu display on
the screen, then press [-VOL+] buttons to select
SOUND item, then press [CH-] button to enter
SOUND menu.
2.Press [-CH+] buttons to select BASS item, then
press [-VOL+] buttons to adjust to your expect
effect. You can adjust the parameters of TREBLE,
BALANCE and S.WOOFER by using the same way.
Note: If you want to adjust the S.WOOFER volume,
you should set the S.WOOFER ON.
THEATERTHEATER
NEWSNEWS
MUSICMUSIC
PERSONALPERSONAL
BASS 66
TREBLE 68
BALANCE ±00
S.WOOFER ON
S.WOOFER 100
SELECT
BASS 66
TREBLE 68
BALANCE ±00
S.WOOFER ON
S.WOOFER 100
SELECT
ADJUST
ADJUST
S.C.C
There is soft exchange function in this TV set, when you set this function is ON
and exchange channels, the picture will fade in/fade out to protect your eyes.
1.Press [MENU] button, let main menu display on
the screen, then press [-VOL+] buttons to select
FUNCTION item, then press [CH-] button to enter
FUNCTION menu.
2.Press [-CH+] buttons to select S.C.C item, then press
LANG. ENGLISH
CURTAIN III
POS. EX.
S.C.C OFF
AUTO OFF OFF
[-VOL+] buttons to set the S.C.C ON/OFF.
SELECT
ADJUST
MUTE function
When you need pay attention to the surround sound or answer the telephone or the
guest to visit, using mute function will be convenient.
1.Press [MUTE] button on the remote controller, the( )
will appear at the bottom of the screen, at this time
the sound will be shut off.
2.If you want to recover the sound, you can press the
MUTE button again or press the [-VOL+] buttons
directly.
12
BASS 66
TREBLE 68
BALANCE ±00
S.WOOFER ON
S.WOOFER 100
SELECT
ADJUST
13
TIME FUNCTION
TIME FUNCTION
Off timer function
When you use OFF TIMER function, you can make the TV set switch to the
standby status in that the appointing timer is coming.
1.Press
on the screen, then press [-VOL+] buttons to select
TIMER item.
[MENU] button to let the main menu display
OFF TIMER ONCE
19:00
ON TIMER OFF
22:00
POS 0
CLOCK 1:40
APPOINTMENT
SELECT
0
0
ADJUST
2.Press [CH-] button to enter TIMER menu, then
press [-CH+] buttons to select OFF TIMER item,
then press [-VOL+] buttons repeatedly to set
ON-TIMER to ONCE, EVERY or OFF.
3.Press [CH-] button to select the next item, at this
time, you can set the off time by pressing [-VOL+]
buttons.
OFF TIMER ONCE
19:00
ON TIMER OFF
22:00
POS 0
CLOCK 1:40
APPOINTMENT
SELECT
OFF TIMER ONCE
ON TIMER OFF
22:00
POS 0
CLOCK 1:40
APPOINTMENT
SELECT
0
0
ADJUST
19:00
0
0
ADJUST
4.Press [-CH+] buttons to select CLOCK item, then
you can set the current time by pressing [-VOL+]
buttons. ( on timer/off timer take this clock as
standard )
OFF TIMER ONCE
ON TIMER OFF
22:00
POS 0
CLOCK 01:40
APPOINTMENT
SELECT
19:00
0
ADJUST
Sleep timer function
Using the sleep timer function, the TV set can switch to the standby status
automatically when the TV set restarts after an appointing certain time.
1.The sleep timer can be set 120 minutes longest, and it can
change every 10 minutes unit, there are 12 off timer in all.
2.Press[ ] button, the bottom of the
screen will display the right figure cycle.
SLEEP: OFFSLEEP: OFF
SLEEP: 120MINSLEEP: 120MIN
SLEEP: 110MINSLEEP: 110MIN
SLEEP: 20MINSLEEP: 20MIN
SLEEP: 10MINSLEEP: 10MIN
On timer function
Using ON TIMER function in the standby status, the TV set can connect power
supply and broadcast the appointing channel number automatically when the
appointing time is coming.
1.Press [MENU] button to let the main menu appear
on the screen, then press [-VOL+] buttons to select
TIMER item, then press [CH-] button to enter
TIMER menu.
2.Press[-CH+] buttons to select ON TIMER item,
then press [-VOL+] buttons repeatedly to set the
ON TIMER to OFF, ONCE or EVERY .
3.Press[-CH+] buttons to select next item. At this
OFF TIMER ONCE
19:00
ON TIMER OFF
22:00
POS 0
CLOCK 1:40
APPOINTMENT
SELECT
0
0
ADJUST
time, press [-VOL+] buttons to set ON TIMER(the
method is the same as OFF TIMER).
4.Press[-CH+] buttons to select POS 00 item, then press
[-VOL+] buttons to set ON/OFF TIMER channel
number(for example 05).
5.Press[-CH+] buttons to select CLOCK item, then
press [-VOL+] buttons to set the current time(the
method is the same as OFF TIMER, ON/OFF
TIMER takes this clock as standard).
OFF TIMER ONCE
19:00
ON TIMER OFF
22:00
POS 00
CLOCK 1:40
APPOINTMENT
SELECT
0
ADJUST
14
15
TIME FUNCTION
SETTING FUNCTION
Appointing program
1.Press [MENU] button to let the main menu display
on the screen, then press [-VOL+] buttons to select
TIMER item, then press [CH-] button to enter
TIMER menu.
2. Press [-CH+] buttons to select CLOCK item, then
press [-VOL+] buttons to set the current time( the
method is the same as OFF TIMER,
APPOINTMENT takes this clock as standard).
3.Press [CH-] button to select APPOINTMENT item.
Then press [-VOL+] buttons to enter APPOINTMENT
sub-menu.
4.Press [-VOL+] buttons to set the POS. you need
( for example:100).
5.Press [CH-] button to enter TIMER item. Then
press [-VOL+] buttons to set the time. Pressing
[-VOL+] buttons, the time will change with 1
minute unit. Pressing and holding [-VOL+] buttons,
the time will change with 10 minutes unit.
6.Press [CH-] button and repeatedly the fourth and
fifth to set the next POS.l.
7.Press [DISPLAY] button to exit the [TIMER] menu.
When the timer is coming, the TV set will
switch to the channel number you appointed
automatically.
The APPOINTMENT is only valid in ON
TIMER status, it is invalid in AC or DC standby status.
OFF TIMER ONCE
19:00
ON TIMER OFF
22:00
POS 0
CLOCK 01:40
APPOINTMENT
SELECT
APPOINTMENT
POS. TIME
000 OFF
000 OFF
000 OFF
000 OFF
000 OFF
000 OFF
APPOINTMENT
POS. TIME
00 OFF
1
000 OFF
000 OFF
000 OFF
000 OFF
000 OFF
APPOINTMENT
POS. TIME
00 12:58
1
000 OFF
000 OFF
000 OFF
000 OFF
000 OFF
0
ADJUST
Language selection
1.Press [MENU] button to let the main menu display
on the screen, then press [-VOL+] buttons to select
FUNCTION item, then press [CH-] button to enter
FUNCTION menu.
2. Press [-CH+] buttons to select LANG. item, then
press [-VOL+] buttons to select language, the
character will display with the change of language.
Screen projection function
When the background function is activated and the
TV set receive no signal, the screen will change into
the right figure.(game screen projection picture).
1.Press [MENU] button to let the main menu display
on the screen, then press [-VOL+] buttons to select
PICTURE item, then press [CH-] button to enter
PICTURE menu.
2.Press [CH-] button to select B.B item, then press
[-VOL+] buttons to set the B.B ON.
LANG. ENGLISH
CURTAIN III
POS. EX.
S.C.C OFF
AUTO OFF OFF
SELECT
CONTRAST 100
BRIGHT 50
COLOR 50
SHARP 50
B.B ON
SELECT
ADJUST
I
I
I
I
I
I
I
I
I
I
SCORE 000
ADJUST
I
I
I
I
I
I
I
I
I
I
16
17
SETTING FUNCTION
SETTING FUNCTION
Stage curtain for open and close effect
There are three different method of stage curtain for open and close effect, you
can select according to your need.
1.Press [MENU] button to let the main menu display
on the screen, then press [-VOL+] buttons to select
FUNCTON item, then press [CH-] button to enter
FUNCTION menu.
2. Press [-CH+] buttons to select CURTAIN item, then
press [-VOL+] buttons to select one of I, II or III.
I: stage curtain for open and close effect
II: fade in/fade out
LANG. ENGLISH
CURTAIN III
POS. EX.
S.C.C OFF
AUTO OFF OFF
III: mix stage curtain for open and close effect
SELECT
ADJUST
Calendar function
The calendar of this TV set stores the years from 1901year to
2050 year.
1.Press [CALENDAR] button on the remote controller
the calendar will be displayed on the screen(pressing
it again, you can cancel the on-screen display).
2.Press [-CH+] buttons to adjust year, press [-VOL+]
buttons to adjust month.
JAN 2004
SU MO TU WE TH FR SA
1 2 3
4 5 6 7 8 9 10
11 12 13 14 15 16 17
18 19 20 21 22 23 24
25 26 27 28 29 30 31
Exchange
For example: exchange the position of the position number 1 with position
number 9
1.Press [MENU] button to let the main menu display
on the screen, then press [-VOL+] buttons to select
FUNCTION item, then press [CH-] button to enter
FUNCTION menu.
2. Press [-CH+] buttons to select POS.EX item, then
LANG. ENGLISH
CURTAIN III
POS. EX.
S.C.C OFF
AUTO OFF OFF
SELECT
ADJUST
press [-VOL+] buttons to enter POS.EX sub-menu.
The digit of EX.POS1 and EX.POS2 item are the current
position number.
POS.EX
EX.POS1 1
EX.POS2 1
EXCHANGE ？
RETURN
3.Press [-CH+] buttons to select EX.POS2 item, then
press [-VOL+] buttons to input position number 9.
POS.EX
EX.POS1 1
EX.POS2 9
EXCHANGE ？
4.Press [-CH+] buttons to select EXCHANGE item,
RETURN
then press [-VOL+] buttons to enter. At this time,
the program of original position number 1 is
exchanged to position number 9, the program of
original position number 9 is exchanged to position
number 1.
9
18
19
SETTING FUNCTION
SETTING FUNCTION
There is lock function in this TV set, you can select it to protect your TV set
according to your need.
定时关机功能
Changing password
The password of the TV set is preset "0000" in
manufacture, if you want to change the password,
LOCK
you can fill in four digits.
1.Press [LOCK] button, OSD is
LOCK SET UP
PASSWORD: - - - -
as the right figure.
CH+
MENU
VOL+VOL-
CH-
1 2 3
4 5 6
7 8 9
2.Press "0" button directly for
four times, and enter LOCK
SET UP menu. Press
[-CH+]
buttons to select CHANGE PW.
item, then press [VOL+] button
to enter CHANGE PW.
sub-menu.
3.Press numeric buttons and
input four digits.
LOCK SET UP
CHANGE PW.
TUNING LOCK OFF
PRESET PROG. OFF
AV LOCK OFF
GAME LOCK OFF
CHILD LOCK OFF
MAX.VOLUME OFF
UNLOCK
CHANGE PW.
NEW PW. - - - -
4. The screen returns to the
0
original status after inputting
new password(see the right
LOCK SET UP
PASSWORD: - - - -
figure), at this time you can
input new password to enter
password set menu.
LOCK
CH+
MENU
CH-
1 2 3
4 5 6
7 8 9
0
Lock set up
The TV set can lock tuning, preset program,
AV, game and child lock items, if you need to lock
them, you can set as following procedure.
1.Press [LOCK] button, and
OSD is as the right figure.
LOCK SET UP
PASSWORD: - - - -
2.Press "0" button directly
for four times (or press the
four-digit password you have
VOL+VOL-
changed) to enter LOCK SET
UP menu.
3.Press buttons to
[-CH+]
select TUNING LOCK
LOCK SET UP
CHANGE PW.
TUNING LOCK OFF
PRESET PROG. OFF
AV LOCK OFF
GAME LOCK OFF
CHILD LOCK OFF
MAX.VOLUME OFF
UNLOCK
item, and press [VOL+]
button to select ON or
OFF.
CHANGE PW.
NEW PW. - - - -
Note:
1.When the tuning lock is on, you should enter password
to enter the tuning menu, meanwhile you cannot exchange
the program and press 1 button to enter auto search.
2. You can set the default program of on timer by using the
function of preset program.
3.When the AV lock is on, the AV terminal is invalid, at this
time, the screen become black screen and remind that it
is locked, the TV set in mute status.
4.When the child lock is on, the screen will remind that
it is in CHILD LOCK status if you press the buttons of
the TV set, and the buttons of this TV set are invalid.
5.When the game lock is on, the [GAME] button on the
remote controller is invalid.
6. The max volume lock can restrict the max volume of the
TV set, if you set the volume lock 50, the max volume of
the TV set is 50, when you press [VOL+] button to adjust
the volume value that is over 50, the volume will not
change with it any more.
20
21
GAME
TROUBLE SHOOTING GUIDE
When you select“SUBMARINE”game item, enter game mode and the other
buttons (except [GAME], , ， ) are invalid, unless you exit the
[-VOL+] [-CH+]
game.
Instructions of game controlling buttons
Fire button
VOL- VOL+
CH+
MENU
CH-
Up/Down
button
MODE
GAME
Selection buttons of
game background
Game button
Left/Right
EXIT
Game exit button
button
Play game:
1.Press [Game] button to enter game.
2.Use the remote controller to operate yellow
battle ship. Yellow battle ship bump one of
green ship or blue ship or purple ship or red
ship or blue shot. and game is over. Yellow ship
use [MENU] button shoot shots. The shot bumps
green ship or blue ship or purple ship or blue
shot and win 100scores,the shot bumps red ship,
and win 1000 scores.
3.During game or game is over, press [Game] button
and game can restart. Ship obtaining highest
scores wins.
I
I
I
I
I
I
I
I
I
I
SCORE 000
I
I
I
I
I
I
I
I
I
I
SCORE 5800
GAME OVER
The following problems are not always caused by hardware failure, please use the
follow trouble shooting guide before you call for service:
BREAKDOWN PHENOMENON
CHECKING
SOUND
The direction and connection of the
antenna
Picture with s now
Noise
Direction, station and connection
Double or Triple Image
Normal
of the antenna
Interference from electric
appliance. Automobile、Motor,
Disturb
Noise
Vehicle Fluorescence lamp etc.
Volume, Sound mute
I
I
I
I
I
I
I
I
I
I
Normal
?
??
No Picture
No Color
No Sound
No Sound
Normal Volume
The power plug isn't plugged in AC
outlet. The main power isn't turned
on. The setting up of contrast, brightness and volume.
Adjust color control
Adjust channel again
I
I
I
I
I
I
I
I
I
I
Note:1.If the problem can not be fixed after you check above items. DO NOT attempt
to remove the back cover by yourself.
Scramble
Color Spot
Normal or Weak Volume
Normal Volume
Moving the TV set or using magnetic electric appliance near TV, Which will lead to color spot on screen. Please remove the electric appliance and cut
off power. After 120 minutes turn the TV on, the picture will be recovered.
2.If the snapping sound from the cabinet of the TV set can be heard occasionally
because of temperature changing of environment, it is normal, you can use it
reassuringly.
22
23
Loading...
