X-Pro
Speedcontroller
Dear Customer,
Thank you for your purchase of the X- Series Controller, a new generation of sensorless speed
controllers especially for ’Hacker Brushless A-Series- Motors’ and other Brushless Motor
Designs. Special programming options are provided to ensure the best possible power and
performance from your motor system. ‘Brushless’ systems offer high power efficiency combined
with low weight and compact dimensions. For best performance and reliability from your
Controller, use only High quality connectors, motors and batteries.
Please, pay careful attention to the following instructions before you start to work with
your new motor and speed controller.
Connections:
The speed controller can be connected to the motor by direct soldering or with high quality
connectors. Always use new connectors, which should be soldered carefully to the cables and
insulated with Heat-shrink tubing. It is possible to extend the cables to the motor battery pack up
to a maximum of 8 inches. Deans Ultra or other high quality connectors are recommended for
connecting the motor battery pack to the controller.
• Solder Controller to the Motor wires
• Solder appropriate connectors to the Battery wires
• Insulate all Solder connections with Heat Shrink Tubing.
• Plug the JR connector into the receiver throttle channel.
When connecting controller to battery pack, care should be taken to ensure that multiple touches
of the connectors are not made.
Reversing the motor directions is achieved by the exchanging the position of any two wires
connected to the motor or by programming “rotation reverse”.
Installing the Controller:
Install the speed controller in the model so that it is isolated from vibration and shock, using Velcro
or double sided foam tape. Allow space around it for cooling. Make sure that there is sufficient
cooling of the motor and speed controller by ducting air through adequate cooling holes from the
outside airflow. Main power packs should be connected at one attempt.
Copyright 01/06 – Hacker Motor GmbH 1
The X-speed controllers have an optimal default setup for A-Motors.
Factory default settings:
Brake: Off
Battery type (ESC with BEC): 3S Li-Poly (ca. 8,7V)
Battery type (ESC-Opto without BEC): 5S Li-Poly (ca. 14,5V)
Under voltage: Reduce power
Acceleration : Fast
Timing: Auto
Frequency: 8KHz
Active RPM-Control (Helimode / Governormode): Off
Normal start up:
When throttle stick is off, connect battery pack,switch on the controller (if switch is installed), you
will hear one beep for Brake on or two tones for Brake off.
For changing the default setup, please read the following manual
ESC program procedure
It is possible to program the ESC in two different ways:
-by using a Computer with “Hacker X-Pro USB-Interface” and a special software, which can be
acquired, (see then enclosed operating instructions).
The USB software offers still additional adjusting parameters:
-variable cutoff voltage for LiPo cells
-Brake "off", "soft", "hard"
-finer gradations in the Motortiming
-acceleration in three stages selectable
-updates for the X-Pro ESC
-programming by throttlestick:
With throttle stick at full power, connect the battery and wait for 5 sec. Program mode is entered
when you hear two low tones and two high tones. _ _ - Each time you enter the programming mode you are allowed to make one change and then you
will automatically exit the programming mode. To change more than one parameter you will have
to re-enter the programming mode each time.
1. Brake
To change the brake function, as soon as you hear the programming tones mentioned
above, move the throttle stick to low position. Brake function will be inverted. (IE: If brake
was on, it now will be off.)
To change any of the remaining functions, enter the programming mode as detailed above.
Leave the throttle at high position until you are within the five sets of beeps as detailed in
each of the choices below. When you arrive at the choice you want to make, move the
throttle to low position while that series of 5 tones are still being heard.
WARNING: the motor will run now by moving the throttlestick!
Copyright 01/06 – Hacker Motor GmbH 2
2. Battery type
(Voltage Cut-off)
NiCd: . . . . .
2 Lipos: (5.8V) .. .. .. .. ..
3 Lipos: (8.7V) ... ... ... ... ...
Following options only on OPTO-controllers:
4 Lipos: (11.6V) .… .… .… .… .…
5 Lipos: (14.5V) .…. .…. .…. .…. .….
3. Under voltage
reduces power when the battery gets low. -_ -_ -_ -_ -_
cuts off power when the battery getslow. _- _- _- _- _-
4. Acceleration
Low: V V V V V
Medium: VV VV VV VV VV
High: VVV VVV VVV VVV VVV
5. Timing
Automatic: (7 ~ 30 degree) (recommended) - - - - -
Soft: (7 degree) (2-pole motors) -- -- -- -- --
Hard (22 ~ 30 degree) (multipole motors) --- --- --- --- ---
6. Frequency
8 kHz: (recommended) \ \ \ \ \
16 kHz / / / / /
7. Rotation reverse
Reverse motor rotation W W W W W
8. Active RPM-Control, Heli-/ Governormode
rpm control: Off _._ _._ _._ _._ _._
up to 20 000 electrical RPM: _.._ _.._ _.._ _.._ _.._
up to 50 000 electrical RPM: _…_ _…_ _…_ _…_ _…_
above 50 000 electrical RPM: _…._ _…._ _…._ _…._ _…._
(electrical RPM on two-pol motors, for a 4-pol motor for example:
Copyright 01/06 – Hacker Motor GmbH 3
50 000 electrical RPM:2 = 25 000RPM, 10-pol motors electrical 50 000RPM:5
= 10 000RPM and so on…)
Trouble shooting:
• Switch “ON” the transmitter and check the throttle channel settings are +/-100% (for
computer radios). For
channel. Set the throttle to “closed” or brake position
• Locate the controller to Avoid multiple touches of the connectors when installing a fresh
motor battery pack
• You must hear a ‘beep’. Between switching on the switch and the ‘beep’ the throttle
stick must not be moved. If you do not hear a ‘beep’, switch off the switch, disconnect
the power connectors, wait for 5 seconds and repeat the procedure of connecting and
switching on.
• If you do not hear ‘beep’ again, check the following:
o ⎯ Is JR connector plugged in throttle chanel?
o ⎯ Is the throttle stick in “closed” position (OFF)?
o ⎯ Is the throttle channel in ‘normal’ position? (for Futaba, in the Reverse
position?)
• The position of ‘full throttle’ will be adjusted automatically
• All programming will be stored.
• The speed controller will turn-off the motor when the main power pack voltage falls
under 5,5 V or at the voltage wich is programed in step “under voltage”. It depends on which
occurs first.
• Temperature overload protection is built into the speed controller; it turns off the motor when the
temperature reaches 230º F /110º C.
• These speed controllers are equipped with protection functions that take care of correct start
and operation of the motor across the whole range of RPM, Current and Voltage.
• Do Not connect the speed controller to just ‘any’ kind of power source. Take care to
ensure the right polarity of NiCd/ NiMH or LiPoly power packs only.
• Do not connect the motor battery to the wrong polarity; the speed controller will be
severely damaged.
• Controllers connected to the wrong battery polarity, WILL NOT be covered under the
warranty
Futaba Radios program the “Servo Reverse” function on the throttle
Copyright 01/06 – Hacker Motor GmbH 4
Warranty Terms and Conditions
Hacker Brushless Motors warrants products to be free from defects at the date of purchase. This
warranty does not cover any component parts damaged by use or modification. Hacker Brushless
Motors reserves the right to change or modify this warranty without notice.
In that Hacker Brushless Motors has no control over the final assembly, no liability shall be
assumed nor accepted for any damage resulting from the use by user of the final assembled
product, the user accepts all resulting liability.
All returns require a “Merchandise Return Authorization (MRA)”, which can be obtained by
contacting Hacker Brushless Motors. No returns of any type will be accepted without a MRA
number and will be returned to the sender. The following information is required for obtaining a
MRA number: Customer name (or Store name), Invoice number, part or model number and
explanation of defect or problem.
• Hacker Brushless Motors must authorize all returns within 7 days from receipt of order
• All returns must have a copy of the original invoice with MRA number
• All returning packages must have the MRA number clearly marked on the outside of the
packaging
• All packages shall be inspected upon delivery. All claims for damaged products must be made
with carrier within 3 days of the receipt of the package.
• All defective items must be processed through the Manufacturer or the Distributor of the product
• Sender must prepay all transportation and insurance charges
• All returning items must be in new, saleable condition. They must have original packing
material, manuals and accessories
• Warning: Once the Motor Battery Pack is connected, handle the model with extreme
care! Ensure that you are well clear of the propeller at all times. Rotating propellers are
extremely dangerous!
• Always Connect the motor battery pack just before flight and disconnect it immediately after
landing the model.
• Warning: Even when the switch is ‘off’ remember the Motor Battery pack may be
connected, handle the model with extreme care and stay well clear of the Propeller!
Copyright 01/06 – Hacker Motor GmbH 5
Declaration of conformity
The described products are in compliance with the relevant and applicable EC guidelines
for electromagnetic compatibility:
89/336/EWG
92/31/EWG
93/68/EWG
Many happy landings!
Hacker Motor GmbH
Hummler Str. 5
Tel.: 0049 (0) 8761-752 129
Fax.:0049 (0) 8761-754 314
EMAIL : info@hacker-motor.com
D-85416 Niederhummel
Copyright 01/06 – Hacker Motor GmbH 6
