BARRES DE DÉBOSSELAGE PREMIUM
PREMIUM DUAL-FOOT LEVELLING BAR
73502_V9_05/12/2022
www.gys.fr
Notice originale
1
2
3
No.
Référence
Qté
Désignation
1
M03501Ecrou M14 anti rotation
2 42162 1
Rondelle Schnorr M5
3 42169 1
Vis M5x16 Torx 25
BARRES DE DÉBOSSELAGE PREMIUM
PREMIUM DUAL-FOOT LEVELLING BAR
No. Ref.
1 M0350ST x1 Ecrou M14 anti rotation / M14 anti-rotation nut
2 42162 x1 Rondelle Schnorr M5 / Schnorr washer M5
3 42169 x1 Vis mx M5x16 TCB / M5x16 TCB screw
2
Notice originale
BARRES DE DÉBOSSELAGE PREMIUM
PREMIUM DUAL-FOOT LEVELLING BAR
MONTAGE BARRE DE TIRAGE PREMIUM / ASSEMBLING THE PREMIUM DUAL-FOOT LEVELLING BAR
11
22
4
No. Ref.
1 51586 x2 Axe / Locking pin
2 42116 x2 Vis M5x6 Torx 25 / M5x6 Torx 25 screw
3 M0350ST x1 Ecrou M14 anti rotation / M14 anti-rotation nut
4 42162 x1 Rondelle Schnorr M5 / Schnorr washer M5
5 42169 x1 Vis M5x16 Torx 25 / M5x16 Torx 25 screw
3
5
3
Notice originale
BARRES DE DÉBOSSELAGE PREMIUM
PREMIUM DUAL-FOOT LEVELLING BAR
MONTAGE BARRE DE TIRAGE 1200 PREMIUM / ASSEMBLING THE PREMIUM DUAL-FOOT LEVELLING
BAR 1200
1221
4
No. Ref.
1 51586 x2 Axe / Locking pin
2 42116 x2 Vis M5x6 Torx25 / M5x6 Torx 25 screw
3 M0350ST x1 Ecrou M14 anti rotation / M14 anti-rotation nut
4 42162 x1 Rondelle Schnorr M5 / Schnorr washer M5
5 42169 x1 Vis M5x16 Torx 25 / M5x16 Torx 25 screw
3
5
JBDC
1, rue de la Croix des Landes
CS 54159
53941 SAINT-BERTHEVIN Cedex
4
FRANCE
