Gyros S 033G Using Instruction

OUTDOOR USE ONLY

Please read these instructions carefully before using the helicopter.

Safety Instructions

Ready to fly

1. Please keep the helicopter and the box away from small children.

2. Please keep a safe distance from high speed rotating propellers to avoid injury.

3. First time users should be gentle with the throttle to avoid crashing the helicopter or

any potential injuries.

4. When finished flying, please turn off first the remote controller then the helicopter.

5. Please keep the charging battery away from fire and humidity.

6. Do not fly the helicopter near pets, young children, elderly and disabled people.

7. Non rechargeable batteries are not to be charged; Different types of batteries or new and

used batteries are not to be mixed; Batteries are to be inserted with correct polarity;

Exhausted batteries are to be removed from the product. The supply terminals are not to

be short circuited

8. When not in use, please turn off the power of controller and helicopter. When the

helicopter is not in use for a long period of time, remove the batteries from remote

controller.

1. Fly in a clear open space, outdoor, away from any people, pets and obstacles.

2. Turn helicopter power switch “ON”. The helicopter lights will flash. It will search the
signal from controller.

3. Turn the remote controller “ON”. The indicator light will flash. Push the left control
throttle up and down. The indicator light will be constant.

4. Push the left control throttle up slowly and start to fly.

Low power protection

Instructions for care and maintenance

When the helicopter’s battery is low, the system will cut-off the power to avoid excessive
discharge. This will reduce any damage to the battery.

1. Please clean the helicopter and controller with a clean soft cloth.

2. Store the helicopter in a dry, clean place. Keep the box for storage.

3. Inspect the helicopter before use. Do not use if any parts are damaged or broken.

Antenna, Battery & Charging

Charge time: about 240-250 minutes—Fly time 7-8 minutes!

Different types of batteries or new and used batteries are not to be mixed;
Batteries are to be inserted with correct polarity;
Exhausted batteries are to be removed from the product;
The supply terminals are not to be short circuited.

Install the antenna in the transmitter by turning clockwise until tight and secured.

Battery Installation in the remote controller

1. Use a crosshead screw driver to remove the controller battery cover. Insert 4 batteries
(size AA, 1.5V) observing the correct polarity indicated in the compartment. Replace the
battery cover and secure the screw.

Charging the helicopter battery
Be sure to switch off the helicopter power.
a. Plug the transformer into the mains. Plug the DC10V transformer to the mains transformer.
The red light will switch on.
b. On the helicopter, the cable with a white plug needs to be plug into the DC10V transformer.
The green light will switch on when the battery is charging. It will switch of when the
battery is fully charged

The helicopter contains a built-in Li-Po battery, please pay attention to the following matters:

- Keep the battery away from fire and heating sources. It could damage the battery or cause it
to explode.

- Keep the helicopter and the battery away from water.

- Only charge the helicopter with the provided adapter.

- Do not remove or dismantle the built-in battery.

- Do not leave unattended when charging.

Flying your helicopter

When the right control lever (steering rudder) is
pushed up, the helicopter will move forward.

When the right control lever (steering rudder) is
pushed down, the helicopter will move backward.

If the helicopter is turning
excessively clockwise, rotate this
calibration button anticlockwise
until the helicopter is balanced.

If the helicopter is turning
excessively anticlockwise, rotate
this calibration button clockwise
until the helicopter is balanced.

The helicopter has
two flight modes:
slow (default mode)
and fast. Press the
switch to change
between modes.

A-B Frequency switch:
Two helicopter can be
used in the same area,
by using two different
frequencies.

Push the rudder stick toward right to
turn clockwise

Push the rudder stick toward left to
turn counter clockwise.

When you pull down the left
stick(throttle) the speed of the
main rotor blade will decrease
and the helicopter will go down.

When you push up the left
stick(throttle) the speed of the
main rotor blade will increase
and the helicopter will go up.

S033G-01A S033G-01B S033G-02A S033G-02B S033G-03A

S033G-03B S033G-04 S033G-05A S033G-05B S033G-06

S033G-07 S033G-08A S033G-08B S033G-10A S033G-10B

S033G-11 S033G-12B S033G-12C S033G-12D S033G-12E

S033G-13A S033G-13B

S033G-17

S033G-14 S033G-15 S033G-16

Head cover A Head cover B Tail decoration A Tail decoration B Main blades

Tail blade Main frame Balance bar Connect buckle Ascend and descend

Gear Top blades grip set Under blades grip set Battery case Lights decoration

Tail assembly Tail competent Metal frame Motor heat sink Main shaft

Motor A Motor B

Transmitter

Li-Poly Circuit board Charging

Troubleshooting

Spare parts

All the spare parts below can be bought from local distributor.

No reaction from
the helicopter

No reaction from
the helicopter
when in flight

1. Not enough power for the helicopter.

2. Not enough power for the controller.

3. The channel is different from helicopter and the
controller.

4. The gyro of the helicopter can’t find out the right
point.

1. Charge the helicopter battery

2. Install new batteries in controller

3. Make sure the same channel is used for the
helicopter and the controller.

4. Move the helicopter onto a flat surface, and then
turn it on. Then turn on the controller

Change frequency or use the helicopter out of the
range of other RC helicopters.

Have the same frequency remote control
transmitter.
