GW Security 51 User guide

IP Camera User Manual

(WEB interface)

Welcome

 Official Website: www.gwsecurityusa.com

 Support Team: [e-mail]

 Phone: [phone]

 Business Hours: Monday ~ Friday from 9:00AM to 5:30PM PT.

Title

Content

Internet connection

Introduction to IP camera connecting guide and web login guide

Preview

Introduction to IP camera Preview’s main functions and usage

Playback

Introduction to record playback’s main functions and usage

Settings

Introduction to the web setting’s main functions and usage

Title

Content

Warning

There is a potential danger; alert users there may be potential harm

Caution

There is a potential risk that could lead to camera damage or loss of data

Description

Additional information, as an additional remark for main content.

P r e f a c e

Thank you for purchasing our GW POE IP Cameras!

This user manual is designed to be a reference tool for the connection and operation of your camera.

Here you can find information about the camera’s features and functions, as well as troubleshooting information.

GW Security Inc.

Overview

Main content of this manual include:

Symbol Definition

There are some Symbols in this manual; their meanings are explained by the following:

Important Safeguards and Warnings

1．Electrical Safety

All installation and operation should conform to your local electrical safety codes.

The product must be grounded to reduce the risk of electric shock.

We assume no liability or responsibility for any fires or electrical shock caused by improper handling or

installation.

2．Transportation Security

Heavy stress, violent vibrations, and excess moisture should not occur during transportation, storage, and

installation of the device.

3．Installation

Handle the device with care. Keep the device right side up.

Do not apply power to the camera before completing installation.

Do not place objects on top of the camera.

4．Repair Professionals

All the examination and repair work should be done by qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or user-attempted repair.
5．Environment

The camera should be kept in a cool, dry place away from direct sunlight, flammable materials, explosive

substances, etc.

This product should be transported, stored, and used only in the specified environments as stated above.

Do not aim the camera at a strong light source, as it may cause overexposure of the picture, and may affect the

longevity of the camera’s sensors.

Ensure that the camera is in a well ventilated area to prevent overheating.

6. Operation and Maintenance

Do not touch the camera sensor or lens directly.
To clean dust or dirt off of the lens, use an air blower or a microfiber cloth.

D i r e c t o r y

1 Connection Guide................................................................................................................................................8

1.1 Conn ect ion Guide...................................................................................................................................8

1.2 Log ging into the Web Interface ........................................................................................................ 9

2 Preview............................................................................................................................................................... 12

2.1 Main Menu ...............................................................................................................................................12

2.2 Function Bar...........................................................................................................................................13

2.3 Sid e bar.................................................................................................................................................... 14

3 Playback..............................................................................................................................................................15

4 Settings................................................................................................................................................................16

4.1 Local Co nfi gurat ion .............................................................................................................................16

4.2 Conf ig Med ia.......................................................................................................................................... 16

4.2. 1 Audio Vid eo.................................................................................................................................16

4.2. 2 Privacy .......................................................................................................................................... 17

4.2. 3 Image.............................................................................................................................................18

4.2. 4 ROI-Reg ion of Interest ............................................................................................................20

4.2. 5 OSD .................................................................................................................................................20

4.3 Netwo rk....................................................................................................................................................21

4.3. 1 TCP/IP...........................................................................................................................................21

4.3. 2 PPPOE ............................................................................................................................................22

4.3. 3 DDNS Client .................................................................................................................................23

4.3. 4 Email..............................................................................................................................................24

4.3. 5 FTP ..................................................................................................................................................24

4.3. 6 Bonjour.........................................................................................................................................25

4.3. 7 SNMP..............................................................................................................................................26

4.3. 8 HTTPS............................................................................................................................................27

4.3. 9 P2P ................................................................................................................................................. 27

4.4 Alarm Co nfi g...........................................................................................................................................28

4.4. 1 Motion Detectio n ......................................................................................................................28

4.4. 2 Video Bi nd & Ala rm.................................................................................................................30

4.5 Storage......................................................................................................................................................31

4.5. 1 Schedule.......................................................................................................................................31

4.5. 2 SD Storage ....................................................................................................................................32

4.5. 3 Snapshot.......................................................................................................................................32

4.5. 4 Destination ................................................................................................................................. 33

4.5. 5 NAS..................................................................................................................................................34

4.6 System.......................................................................................................................................................34

4.6. 1 Maintenance ............................................................................................................................... 34

4.6. 2 Device Inf o.................................................................................................................................. 35

4.6. 3 Set Time ........................................................................................................................................35

4.6. 4 User Admin..................................................................................................................................36

Glossary of Terms....................................................................................................................................................37

1 Connection Guide

1.1 Connection Guide

There are two main methods to co nne ct the camera:

Pic 1-1 Net work cab le connection diagram

Pic 1-2 POE switch or route r connection dia gram

Before accessing the IP camera, us er needs to acq uire the IP camera’s IP address. Use r can

find the IP address by using th e “GW Device Manager” soft ware inc lud ed in the CD.

From the GW Device Manager software, lef t click on “sea rch” to find all the available IP
cameras in yo ur curre nt LAN networ k. The softwa re will display the IP camera’s IP address, port
numb er, MAC addre ss, Ser ial Numb er, UID, versi on info, and model number. Ple ase use the
pict ure bel ow as re fe rence .

If the IP address found does not match you r compu ter ’s IP subn et, please use GW Devic e

Mana ger to mod ify the IP camera’s net work info.

From the GW Device Manager, select the IP camera to be mod ified and rig ht click , the n

choo se Netwo rk Configuration . Ple ase use th e bel ow picture as refe rence .

Note

The IP camera wil l have DHC P turned on by defau lt. Please connect the IP camera to a

network wit h DHC P availab le. If there is no DHCP server available, the IP camera ’s IP ad dress
will defaul t to 192.168.0.66 .

Defaul t Username and Password: admin/adm in.

1.2 Logging into the Web Interface

When user accesses the web interface fo r the fi rst time, “VLC med ia player” is neede d in

order for the vi deo to show correctly.
To access the web interfac e, please follow the ste ps below.

Step 1: Open Inter net Explorer and input the IP camera’s IP add ress into the UR L add re ss bar.
Step 2: Whe n the user interface is shown , enter the default usern ame: admin and pas sword: adm in

to log into the web interfac e. An example of the login screen is shown bel ow.

Step 3. Insta ll the plug-in whe n prompted :

① ②

③ ④

Step 4. Refre sh the web page after th e plu g-i n installe d suc ces sfull y. Repeat step 2 to log into the
web inter fa ce again . The web interfac e is shown below :

Available from the Web Inter fa ce:

• Live Preview

• Record Playback

• Save a recordin g onto the local com puter.

• Modi fy IP ca mera param ete rs , cha nge setti ngs, change vid eo quality and syste m time.

Mini mum Req uirement

：

• 2.0 Ghz and up CPU

• 2GB and up RAM

• 10/1 00M bps net work

• 1024 x 768 or up Monitor Res olution

Supp orted OS ：

• Micros oft Wind ows XP, Mic ro soft Win dows Vis ta, Mic rosoft Win dows 7,M icrosoft Wi ndows

8,Mi croso ft Win dows 10

• Mac OS

Note:

The Inter net brows er men tioned in the manu al is In ternet Explorer. Please use IE ve rs ion 9 an d up to
acce ss the web inte rface .

2 Preview

Parameter

Desc ription

1

Menu Bar

2

Status Bar

3

Side bar





②

Web client preview has included the 3 function bar:

Web client preview picture reference below

2.1 Main Menu

For de tail informatio n of each sections, please see (secti on 2 Previ ew, sec tion 3 Backu p, se cti on 4

Settin gs)

Click here for help

Click here to lo g out

④⑤③

⑩

2.2 Function Bar

Paramete r

icon

Desc ription

① Main Stream

Switch to mai n strea m; Mai n stream is the rec orded bit rate
with high resolution

② Sub Strea m

Switch to sub stre am; Sub st ream is the lower resoluti on and
bit rate used when bandwi dth is a restr iction .

Sens or alarm

Disp lay the Sen sor Alar m Statu s:

 White: Senso r ala rm has not be en set up

 Blue: Sensor Ala rm has been set up an d activated

 Sensor Ala rm is been tri gge red

Note: Onl y the status is shown here. For detail settin g, ple ase
refer to sec tio n 4.3.2

④Motio n Alarm

Disp lay the Mot ion Alar m Statu s:

 White: Motion Ala rm has not been set up

 Blue: Mot ion Alarm has be en set up and ac tivated

 Red: Motion Alar m is be en tri gge red.

Note: Onl y the status is shown here. For detail settin g, ple ase

refer to sec tio n 4.4.1

⑤ Vide o Cover
Alar m

Disp lay the Vid eo Cov er Alarm st at us:

 White: Video Co ver Ala rm has not been set up

 Blue: Video Cover Alarm has been set up and act ivated

 Red: Vid eo Cover Al arm is been tri gge red.

Note: On ly the statu s is shown here. For detail setting, pl ease

refer to sec tio n 4.4.2

⑥ Full screen

Sing le left click this icon will bri ng the video to fu ll scree n.
Doub le click on the video or hit “ES C” to exit ful l screen

⑦ Manu al Re cord

Sing le left click will turn on man ual record mod e

⑧ Sche dul e
Record

Show the stat us of Schedule Re cord:

 White: Sched ule Record has no t been set up.

 Blue: Schedule Record has been set up and is cur rentl y

recording

⑨ Audi o

Turn on/off the Au dio

⑩ Screen
Capture

Sing le left click will cap ture a scree nsh ot. For the scree nsh ot
save path, plea se re fe r to se ction 4.1

⑪ Di spl ay /Hi de
Side bar

Disp lay/h ide sideba r

①

②

⑥⑦⑧

⑨

⑪

Note

Sens or ala rm，Audio ， Vid eo cover alarm is not avai lab le for some mod els.

2.3 Side bar

Parameter

icon

Desc ription

Zoom

Adju st th e camera’s Zoo m level; single le ft click or left click

and hold on the + and – si gn fo r adjustme nt.

Focus

Adju st th e focus ; single lef t click or left click and hold on the +
and – si gn fo r adj ustment.

Zoom and Fo cus

Note

Only mode l with motorize d zoom sup por t this feature .

3 Playback

Parameter

icon

Desc rip tion

① Slow forwa rd

Clic k thi s butto n for slo w play back

② Last

Clic k thi s butto n to play last vid eo or picture

③ Sto p

Clic k thi s butto n to stop playback

④ N ex t

Clic k thi s butto n to play next vid eo or picture

⑤ Fast Forward

Clic k thi s butto n to speed up playback

⑥ Capture

Clic k thi s butto n to ca pture pict ure

⑦ Audio

Clic k thi s butto n to turn on/off audio

Web client playback picture reference below

Step1 Select“ File Type ”，“ Vid eo”and“Image ” option.

Step2 Select“ Date Source ” ， “SDC ard” and “ Local option ” .
Step3 Select date and tim e.
Step4 Click

to play video and pic ture.

4 Settings

Web Cli ent ’s Sett ing has 6 opt ion s: Local Conf igu ration Config Medi a, Network, Alar m, Reco rd,

and System.

4.1 Local Configuration

Step 1: Cho ose “Settin gs -> Local Co nfi guration -> Fil e Path”. Reference Pi ctu re below :

Step 2: Sel ect the st orage path for video and cap ture and click “Save ” to finish setting.

4.2 Config Media

Conf ig Media ha s the sections: Audi o Video, Privacy, Ima ge, ROI , OSD.

4.2.1 Audio Video

Step 1: Cho ose “Settin gs -> Config Med ia -> Aud io Video”. Reference Pictu re below :

Step 2: Aud io Vid eo Pa ra meters:

Parameter

Desc rip tion

Standa rd

Set the vid eo stand ard

 Pal: 25FPS

 NTSC : 30FPS

Stream type

Set the vid eo param eter for each strea m typ e:

 Main Stream is the recorded bi t rate

 Sub Stream is the secondary st ream use d for mobile access

Fra me Rate

Set the Frame Rate Per second (FPS ). Re duc ing the frame rate will
increa se the ave ra ge bit rate for each frame, but does not necessar y
saves dis k space. The maximum FPS wi ll dep end on the resolution set

Code c

Set the camera to use H.264 or H.2 65 codec

Bitrate Mode

Bitrate mod e

 CBR: The bit rate wi ll stay constant

 VBR: When video contains high amo unt of activ ity, the bi trate wil l

Increa ses; the bit rate decreases in the ca se of inanimate
environment, savin g storage space

Resoluti on

Sele ct IP camera’s resolution

Video Quality

provid es “Be st/Exce lle nt/good/no rmal/w orst five option

Video Rate

The actual amo unt of data the cam era is using for recordi ng. The
high er the bitrate, the la rger the video footprint, re sul ts in better
image.

I Frame Inter val

Indi cates the number of P frames before two I fra mes . The larger the
numb er, the fewe r key frames and the more critic al frames. Increa sin g
crit ical frame Nu mbe rs im prove s quality, but adds net work load.
The maxim um is 100, and the recommended setting is tw ice the frame
rate. The defau lt va lue is 50.

Audio Enable

Clic k to tu rn on/off aud io inp ut/output

Codec

Sele ct audio en coding format G.7 11U /G.77A , sugge st to select G. 711A

Step 3: cli ck “Save ” to co mpl ete vid eo co nfi guration .

4.2.2 Privacy

Step .1 Select “ Setti ngs > Config Med ia > Privacy”. See picture below fo r reference:

Step2 Check“En abl e” .

Parameter

Desc ription

Hue

Changes the color mix of the image (this can have very dramatic results)

Step3 Click“Fu ll Scree n” to sel ect the entire area， cl ick “ Clear Screen ” to clear the prev iou s.

settin gs， clic k “Save ” to complete privac y area co nfi guration.

Note

Privac y blo ck supports up to fou r areas .

4.2.3 Image

Step1 Select“ Settings > Con fig Media > Ima ge” . See picture below for reference:

Step2 Image setti ng detai l des cript ion .

Brig htnes s

Changes how bright the image appears to be. The bigger number the brighter.

Contra st

The separation between the darkest and brightest areas of the image.

Saturati on

Alters how much color is displayed in the image. The higher the saturation, the brighter

and vivid colors will appear to be.

Shar pness

Sharpen image to increase the Signal Noise ratio.

Mirror

Change the orientation of the image to be horizontally reversed.

Turn

Change the orientation of the image to be vertically reversed.

Came ra Angle

Change the orientation of the image to 90°、180°、270° or normal.

3D DNR

3D-Noise Ratio: if Enabled, may decrease the noise of the image.

LUX

Adjust Illuminance value, the bigger the number the easier to trigger the infrared. Set to

“0”

to turn off the IR lights and set to“9”to keep the IR lights always on.

De-war pin g

Refers to the process of perspective correction of an image, to reverse the effects of
geometric distortions caused by the camera lens. Most commonly known as a“Fisheye

”

and/or “360º” device.

Led inten sity

Adjust the intensity of LED lights. Set to “0” to turn off the LED lights. The bigger the
number the stronger the intensity.

Expo sure Mod e

 Auto: Select the exposure level of the camera based on pre-defined conditions.

 Manual: Adjust shutter speed and gain value of the camera manually.

shutte r

Known as“exposure time”, stands for the length of time a camera shutter is open to
expose light into the camera sensor. If the shutter speed is fast, it can help to freeze
action completely. If the shutter speed is slow, it can create an effect called “motion
blur”, where moving objects appear blurred along the direction of the motion. This effect
is used quite a bit in advertisements of cars and motorbikes, where a sense of speed and
motion is communicated to the viewer by intentionally blurring the moving wheels.

BLC Mode

 Turning on the Wide Dynamic Range (WDR) feature for photos improves the overall

exposure throughout your entire image. It enables the camera to pick up greater
detail in dark shadows, while making sure that the highlights don't get blown-out.

 Digital wide dynamic range (D-WDR) is a software-based technique that optimizes

image quality by adjusting the gamma (γ) value to enhance dark areas.

 Back-light Compensation (BLC) optimizes exposure in the foreground and

background of security video. It splits the video scene into different regions and
uses a different exposure for each of these regions. It corrects regions with
extremely high or low levels of light to maintain a normal and usable level of light
for the object in focus.

 Highlight Compensation (HLC) senses strong sources of light in video and

compensates for exposure on these spots to enhance the overall quality.

FLC

 50Hz ：In the case of 50Hz, according to the brightness of the scene, the exposure is

automatically adjusted to ensure that the image does not appear horizontal stripes

 60Hz: In the case of 50Hz, according to the brightness of the scene, the exposure

is automatically adjusted to ensure that the image does not appear horizontal
stripes

 Outd oor ：In this mode, the mode of exposure mode can be changed to achieve the

effect of the corresponding exposure mode

FLC： Outdoor /50 Hz/ 60Hz opt ional， defau lt mode is Outdoor

Day/Ni ght

 Colo r：Only display co lor image

 B/W：On ly display black/white image

 Auto ： Display col or or B/W image accordin g to CDS(l ux va lue )

 Time： Disp lay col or or B/W image according to setti ng time

Day /Ni ght ：Color/B& W/auto/time optional. For non -IR ip cam era, default mode
is color, for ip camera wit h IR, default mod e is auto.

4.2.4 ROI-Region of Interest

Paramete r

Desc ription

Show clock

Disp lay or Hide current tim e

Show Fps

Disp lay or Hide FPS info

Step1 Select“ Settings > Con ig Media > ROI” . See picture below for reference:

Step2 Check“En abl e” .

Step3 Click“Fu ll Scree n” to selec t the whole are a， cl ick “ Cle ar Scree n” to clear the pre vious

settin gs，Cl ick “ Save”to complete ROI area configurat ion .

Note

ROI function su ppo rts up to four areas.

4.2.5 OSD

Step1 Select“ Settings > Con fig Media > OSD ” . Se e picture bel ow fo r refe rence :

Step2 OSD Para meters.

Show Channel
Name

Disp lay or Hide Channel nam e. (up to 16 cha ra cters)
Show User Info

Disp lay or Hide User info. (up to 16 cha ra cters)

Parameter

Desc rip tion

Max co nnection

Allows up to 10 concurrent device logins.

Step3 Click “Save” to co mplete OSD configuratio n.

Note

You can use mouse to cha nge the OSD conte nt posit ion .

4.3 Network

Local Netwo rk Configurat ion : “TCP/IP 、 PPPOE、DD NS Cli ent 、 Ema il、FT P、Bonjo ur、SN MP、

HTTPS 、 P2P “

4.3.1 TCP/IP

Step1 Select“ Settings > Netwo rk > TCP/IP” . See pic ture bel ow fo r refe rence :

Step2 TCP/ IP Pa ra meters.
Step 3. Click“Save”to complete TCP/IP configuration.

DHCP

Enab le or Disable DHC P

 Enable DHCP: DHCP is a system where one device on your network (usually a

router) will automatically assign IP address to device connected to the network.

 Disable DHCP(Static): Static networks require all devices to have their IP addresses

manually defined, as there is no device dedicated to automatically assign IP
address.

IPv4 /IPv6
Address

 Just as Home and Office needs to have an address which identifies their location on

the road network. The camera uses IPv4 addressing, which consists of four groups
of numbers between 0 and 255, separated by periods. For example, a typical IP
address might be “192.168.1.37”or similar.

 The length of the IPv6 address is 128 bits, which is four times the length of the IPv4

address, expressed in hexadecimal and separated by colons. For example, a typical
IP address can be "2001: 250: 3000: 1 :: 1: 7 "or similar.

IPv4 Subnet

 If the IP address is like a street address, then a sub-network is like your

neighborhood.

 This will be formatted in a similar way to the IP address (ie. four numbers up to 255

separated by periods) but contain very different numbers.

 In the above example, the Subnet might be something like:“255.255.255.0”.

Gateway

 This is the address of the “way to the Internet.” To continue the road analogy, this is

like your local access point to the highway. This is an IP address in the same format
as the others, and is typically very similar to the IP address of the Camera.

 To continue the above example, it might be something such as:“192.168.1.1”.

DNS

Set DNS server address

MAC Addre ss

The Media Access Control address. This is a unique code which nothing else should
share. You can’t change this one - it’s pre-set when the Camera is manufactured.

Http Port

 This is the port through which you will be able to log in to the Camera. It will need

to be forwarded properly in order to ensure smooth, latency-free communication.

 The default value is“80”, if another device on your network is using this port,

please change to other value.

 This is the port number you’ll need to remember when logging in remotely from a

remote PC via the HTTP interface.
ie. http://ip:port

(http://56.236.333.237:80)

Onvif Port

 ONVIF protocol communication port.

 The default value is “85”

RTSPPort

“Real Time Streaming Protocol”, you may use this port to send the streaming file

 The default RTSP port is 554

Main Stream path example
rtsp://192.168.0.83:554/H264?channel=0&subtype=0&unicast=true&proto=Onvif

Sub Stream path example

rtsp://192.168.0.83:554/H264?channel=0&subtype=1&unicast=true&proto=Onvif

4.3.2 PPPOE

Step.1 Select”Settings > Network > PPPOE”. picture for reference only:

Step2 Check“PPPOE”Enable”.

Parameter

Desc rip tion

Provider

Choose a server that you’re using from 3322.org, DynDDNS, Noip.

Server

Enter the server address from your DDNS service provider.

Hostname

Enter the Hostname that you set up in your DDNS service. This is the address you use to
access your network.

Username

Enter the username you setup with your DDNS server.

Password

Enter the password you setup with your DDNS server. These do not have to match your
username/password combination in either your Camera or router. (For the sake of
security, we suggest making them different).

Step3 Input username & password from ISP（Internet Service Provider）.
Step4 Click“Save” Camera will reboot to complete PPPOE configuration.

Note

PPPOE: An advanced protocol that allows the Camera to be more directly connected via a DSL modem. This is an
option for advanced users only.

4.3.3 DDNS Client

Step1 Select“Settings > Network > DDNS Client”, picture for reference only:

Step2 DDNS Client Parameters.

Step3 Click”Save”Camera will reboot to complete DDNS Client configuration.

Note

DDNS – This stands for Dynamic Domain Name System. DDNS is a method of automatically updating a name
server in the Domain Name System (DNS), often in real time, with the active DNS configuration of its configured
hostnames, addresses or other information.

4.3.4 Email

Parameter

Desc ription

Enab le Email

Enable or Disable Email Function

Moti on Subject

This field allows the user to define the Motion Subject line of the email that is sent to
the receivers.

Alar m Subject

This field allows the user to define the Alarm Subject line of the email that is sent to
the receivers.

SMTP Server

SMTP stands for Simple Mail Transfer Protocol.
This field allows the user to enter the SMTP server used by the email service.
For example: “smtp.gmail.com”

SMTP Port

The SMTP Port used by the email provider of your choice.
The default value is “25”

Send er Addre ss

The address you’re sending the emails from.
For example:“[e-mail]”or similar.

Send er Password

The password for the outgoing email account.

Recipient Addres s

The email address you want the Camera to send emails to. Note that the Camera might
send a large number of automatic emails under certain conditions.
Maximum 4 recipients.

Step1 Select“Settings > Network >Email”. See picture below for reference :

Step2 Email Setting Parameters .

Step3 Click”Save”to complete Email configuration.

4.3.5 FTP

Step1 Select“Settings > Network >FTP”. See pic ture bel ow fo r refe rence.

Step2 FTP Parameters.

Parameter

Desc rip tion

Server

Enter your FTP server address, can be IP address or the FTP link address.

Port

Enter the FTP port number.
The default value is“21

”

Mode

Setting up FTP mode: active or passive (active presentation of the data transfer by the
server, passively representing the client's data transfer)

Username

Enter the username used to login to the FTP server.

Password

Enter the password used to login to the FTP server.

Upload Path

Enter the upload folder name here to receive the recorded files.

Test

After finished setting, you may click Testing to verify your FTP settings, it will show FTP
Test

Step 3 Click “Save” to complete FTP configuration.

Note

FTP: A file transfer protocol. The two-way transmission of control files on the network. In the use of FTP, there
are two concepts: "download" and "upload". The "download" file is a copy of the file from the remote host to its
own computer. "Uploading" files is copying files from their computers to remote hosts. This feature is the camera
"uploading" or video to FTP Server

4.3.6 Bonjour

Step1 Select“Settings > Network > Bonjour”, See picture below for referen ce:

Step2 Check“Enable”, Click ”Save” to complete Bonjour configuration.

Parameter

Desc ription

SNMP Version

These check-boxes allow the user to select the SNMP version to use.

SNMP Port

This field allows the user to write in a port for SNMP to use.
The default value is “161”

Read Community

This field shows which SNMP community has read access.
The default setting is： public

Write Community

This field shows which SNMP community has write access.
The default setting is: Private

Note

Bonjour is Apple's implementation of Zero-configuration networking (Zeroconf), a group of technologies that

includes service discovery, address assignment, and hostname resolution.

Click the check-box next to Enable to the Bonjour functionality. The Server Name field allows the user specify

what name to use in order to connect devices via the Bonjour protocol.

To reset to default settings, click the Default button. To update the Bonjour Server Name, click the Update

button. Click the “Save” button to save the settings,

4.3.7 SNMP

Step1 Select“Settings > Network > SNMP” . See pic ture bel ow fo r refere nce :

Step 2 SNMP Parameters.

Step3 Click“Save”to complete Bonjour configuration.

Trap Address

This field allows the user to write in a trap address.

Trap Port

This field allows the user to write in a trap port number. The trap port number should
not be the same as the SNMP port.
The default value is “162”

Note

SNMP stands for Simple Network Management Protocol. This protocol is used to provide a basic framework in
order to allow connection between various network devices.

4.3.8 HTTPS

Step1 Select“Settings > Network > HTTPS”, See picture below for reference :

Step2 Check“Enable”,Click ”Save” to complete HTTPs configuration.

Note

This check-box enables the use of the HTTPS protocol for accessing the camera. This field designates the
Hypertext Transfer Protocol Secure (HTTPS) port number. The default value is “443”.

4.3.9 P2P

Step 1 Select“Settings > Network >P2P” . See pic ture bel ow fo r refe rence:

Step 2 Check“P2P”to enable the P2P feature for the camera. This feature must be enabled for the camera to
connect to a smartphone or tablet via the GW App. It is enabled by default.
Step 3 Scan QR Code to download the GW Mobile App.
Step4 Use the GW APP to scan the UUID QR Code to add the camera. The S/N can be used to manually enter the
camera’s information on a mobile or tablet device in case the QR code scanning feature cannot be used.
Click“Save”，to complete P2P configuration.

Note

By using mobile APP, user is able to remote check camera real time video. Remote recording and snapshot,

change IP camera parameter setting, alarm setting etc.

4.4 Alarm Config

Alar m is divid ed into “Motio n Detec tion、 Vid eo Blind、 Alarm “

4.4.1 Motion Detection

How Motion Detection Works?

The way that the Camera detects motion is quite straight forward - it’s a process where it compares one frame
with the next. A certain amount of“difference”between these two“frames”is interpreted as motion.
As a result, the Camera is able to detect when there is a change in the picture. However, this does not necessarily
need to be something moving in the frame.
For example, a light being turned on or off, a lightning flash or even the sun coming out momentarily on a cloudy
day might be enough to trigger the motion detection on the Camera. However, as these events last only a
moment (and are relatively rare) they will only create a few redundant clips, which will not take up too much
space or pose a problem with scanning through footage.

Step 1 Select“Settings > Alarm Config > Motion Detection”, picture for reference only:

Step 2 Check“Enable ” to turn on the Motio n Detectio n fun cti on，then ch eck “Alarm Output ” an d

 Alarm Output: check this function to generate an alarm output signal to trigger the related alarm output

 Record Video: check this function to record video when a motion detection alarm is triggered.

 Sensitivity: the higher the sensitivity, the less movement is required to trigger a motion event.

 Threshold: the level that the motion detection needs to reach in order to trigger detection.

 Full Screen: one-click to select all areas for motion detection.

 Clear Screen: one-click to remove all areas for motion detection.

 Alarm Duration: when alarm triggered, the alarm duration will last for a certain period. (range from 5 to 300

 Pre-record Time: this field specifies in seconds how long the surveillance footage is recorded before motion

“Record Vid eo”, dep end ing on diffe rent circu mstan ces .

devices.

Step 3 Cli ck“Regional Edit”op ens a pop up screen that can be used to set detectio n areas.

Use the mouse to select detection areas. Areas with blue squares are selected.

The lower the sensitivity, the more movement is required to trigger a motion event.

The lower the threshold, the more likely that motion will trigger detection.

Step 4 Cli ck“Save ” ，th en click to complete the configurat ion .
Step 5 Set up "Al arm Duration ", "Pre- record Tim e", "Record Tim e" fo r different ci rcumstance s .

seconds) The alarm will not be triggered again till this period is ended.

detection is triggered.

 Record Time: this field specifies in seconds how long the surveillance footage will be recorded after motion

detection is triggered. The record time will not be triggered again till this period ended.

Note

Set up the “Alarm Duration” time shorter than “Record Time” is recommended. Otherwise might not record all
the events.
Step 6 Set up“Time Periods”for motion alarm, only scheduled periods will trigger alarm event.
You can set up 4 periods per day maximum.
Step 7 You can duplicate the same settings to different days as you select, or all days by checking “Select All”.

Step 8 Cli ck “Save ”to com plete mo tio n detec tio n confi guration.

Note

Only certain models support Alarm Output function.

4.4.2 Video Bind & Alarm

Step1 “Settings > Alarm Config > Video Bind & Alarm”
Video Blind Picture reference

Alarm pict ure referen ce

Step 2 Check“Enable” to turn on the Video & Alarm，”then check “Alarm Output” and “Record Video”depending

 Alarm Output: check this function to generate an alarm output signal to trigger the related alarm output

 Record Video: check this function to record video when a motion detection alarm is triggered.

 Alarm Duration: when alarm triggered, the alarm duration will last for a certain period. (range from 5 to 300

 You can set up 4 periods per day maximum.

on different circumstances .

devices.

Step 3 Set up the alarm interval according to requirements, 5-300 seconds option, and Detection sensitivity
provides: High/middle/low optional .

seconds) The alarm will not be triggered again till this period ends.

Step 4 Set up “Time Periods”for alarm, only scheduled periods will trigger alarm event.

Step 5 You can duplicate the same settings to different days as you select, or all days by checking “Select All”.
Step6 Click“Save” to complete Video & Alarm.

Note

Only certain models support Alarm Output function.

4.5 Storage

Storage divided into “Schedule、SD Storage、Snapshot、Destination、NAS“

4.5.1 Schedule

Step 1 Select“Settings > Storage > Schedule” . See picture below for reference:

Step 2 Check“Enable”to set up scheduled recording.

Step 3 Set up “Time Periods” for scheduled recording, only scheduled periods will start recording. You can set up

4 periods per day maximum.

Step 4 You can duplicate the same settings to different days as you select, or all days by checking “Select All”.

Step 5 Click “Save” to complete scheduled recording configuration.

4.5.2 SD Storage

Step 1 Select“Settings > Storage > SD Storage”，picture for reference only:

Step 2 After put in the SD card, click“Refresh”，to check the“Total Space”,”Used Space”and“Available Space

Step 3 Click “Format” to format the SD card before use. All existing data from the SD card will be erased.

Step 4 Enable or Disable auto overwrite for different circumstance.

“On”: The recording will overwrite the data to the first day of records that's saved on the SD card automatically

when there’s no available space.

“Off”: The recording will stop when the SD card has no available space.

Click “Save” to complete SD Storage configuration.

4.5.3 Snapshot

Step 1 Select“Settings > Storage > Snapshot”，picture for reference only:

”

Step 2 Check“Enable”to turn on the snapshot function.

Parameter

Desc ription

SD Card

When sele ct this option, Video, alarm and snapshot will save in SD card

FTP

when Sele ct this option , Video, alarm and snapshot will save in FTP ser ver

NAS

when Sele ct this option , Video, alarm and snapshot will save in NAS

Step 3 Set up the capture time interval from 1 to 600 seconds for different circumstances.

Step 4 Set up “Time Periods” for snapshot, only scheduled periods will capture snapshots.

You can set up 4 periods per day maximum.

Step 5 You can duplicate the same settings to different days as you select, or all days by checking “Select All”.

Step 6 Click “Save” to complete Snapshot configuration.

4.5.4 Destination

Step1 Select “Settings > Storage > Destination”，See picture below for reference:

Step 2 Destination Parameters.

Step3 Click“Save”to complete Destination configuration.

4.5.5 NAS

Parameter

Desc ription

Server Addre ss

Input NAS IP address

Remote Directory

Input NAS director y

Paramete r

Desc rip tion

Fac tory Default

Reset the system to factory default settings .

Step1 Select“Settings > Storage > NAS” . picture for reference only:

Step2 NAS Parameters.

Step 3 Click“Save”to complete NAS configuration.

4.6 System

System divided into ”Maintenance、Device info、Set Time、User Admin“

4.6.1 Maintenance

Step 1 Select“Settings > System > Maintenance” . See pic ture below fo r refe rence:

Step 2 Maintenance Parameters.

Step 3 Click“Save” to complete Maintenance configuration.

Reboot

Simp ly re boot the IP Camera.

Auto Reb oot

Sche dule an auto reboot for the IP Camera.

Parameter

Desc rip tion

Device Model

mode l num ber for the IP Came ra

UPnP

The re quire d port is au tomatically enabled throu gh th e UPNP protocol
to the route r that has th is capabili ty

IPC Version

IP Camera firmw are versi on

4.6.2 Device Info

Step 1 Select“Setting > System > Device Info”. See pic ture bel ow fo r refere nce :

Step 2 Device info Parameters.

Step 3 Click“Save”to complete Device Info configuration.

4.6.3 Set Time

Step 1 Select“Settings > System > Set Time”. See picture below fo r refere nce :

Step 2 Set Time Parameters.

Step 3 Click“Save”to complete Set Time configuration.

Parameter

Desc rip tion

Time zone

Set IPC time zone

Time

Manu ally set tim e whe n necessary

PC Tim e Sync

Set SYNC time with PC

NTP

Set if enable SYN C netwo rk time fun cti on, default is “enabl e ”.

NTP Ser ver

Set NTP ser ver ad dress, defau lt is “time.w indows .com”.

 User ： Create an user for IPC .

 Group：Provide Manager, mai ntain er, user 3 level

opti on.

 Passwo rd： Change use r password .

 Confirm ： Conf irm pas swo rd.

4.6.4 User Admin

Step 1 Select “Settings > System > User Admin” See picture below for reference :

Step 2 Click “Add User”to add a user for IPC.

Note

User 1, User2 cannot be deleted, only allow modifying password. New added user is allow to be deleted.

Glossary of Terms

1 WDR

WDR (Wide Dynamic Range) is the technique aim to reproduce a similar range of luminance through
adapting to the different exposure level presented in the environment, by collecting two different level of
exposure of the same picture twice and combining them. The WDR feature will allow the dark area to be
brighter and darken over-expose area, allowing detail other-wise dampened by over-exposure (glare) and
under-exposure.

2 DWDR

With the same aim as WDR, DWDR (Digital Wide Dynamic Range) adjust the exposure by digitally adjusting
the contrast and gamma value of the picture, reducing the effect of glare. Unlike WDR is done by the hardware,
DWDR may cause the picture to appear washed-out.

3 BLC

BLC (Backlight Compensation) increase the overall exposure of the entire picture to reduce the contrast
between the background and the main interest area. The overall viewable area will improve but area with
brightly-lit area will be overexposed.

4 HLC

HLC (Highlight Compensation) reduce the overall exposure in the main interest area to reduce the effect of
strong light. It is the reverse of BLC because HLC target the lighting generated in the main interest area.

5 3DNR

3DNR (3D Noise Reduction) is the technique used to reduce video noise by analyzing and compare the
difference between each successive frames in order to adjust video pixel. With 3DNR, there will be a trade-off
between video crisp and motion blur.

6 IPv6

IPv6 is the next version of IP (Internet Protocol), the communication protocol that provides an identification
and location system for traffic-routing across the networks. It is designed by IETF (Internet Engineering Task
Force) to replace IPv4 in the anticipation of IPv4 address exhaustion.

7 FTP

FTP (File transfer Protocol) is a protocol used to transfer files between two end-points (computers) on a
network. FTP is an application that exists in different operation system which follows the same set of standard
for file transportation, allowing file transfer across different platforms.

8 DHCP

DHCP (Dynamic Host Configuration Protocol) is a network protocol that allows a server (in most cases, a
router/modem) to automatically assign an IP address to a connected device from a defined range of IP numbers.
DHCP allows a uniformly assigned network environment across different devices.

9 DDNS

DDNS (Dynamic Domain Name System) is a system to automatically update the client’s dynamic IP address

to a static domain name, thus allow a consistent connection without the need to check dynamic IP address. The
update client will send the IP address in real time, based on a predefined interval, to a server hosting the static
domain name, which in term allows other domain name server to acknowledge the new IP address, without the
need to manually changing the record.

10 PPPOE

PPPoE (Point-to-Point Protocol over Ethernet) is a network protocol for encapsulating Point-to-Point
Protocol (PPP) frames inside Ethernet frames. It is used mainly with DSL services where individual users connect
to a DSL modem over Ethernet.

11 RTSP

RTSP (Real Time Streaming Protocol) is a network protocol designed to allow system to control streaming
media servers and is used to establish and control media session between two end-points over TCP/IP.

12 ONV IF

ONVIF is the global and open industry standard for interfacing between video surveillance product and
other physical security areas. The standard defines device discoveries, live video and audio standard, bit rate,
and controls, ensuring compatibility between different manufacturer.

13 H26 5

H.265 is the successor to the H.264 video encoding standard. The aim for H.265 is to improve bit rate, video
quality, and overall video performance. Compare to H.264, H.265 only needs half of the require data to achieve
the same video quality as H.264.

14 HTTPS

HTTPS (Hyper Text Transfer Protocol Secure) is the secure version of HTTP, the protocol which data is sent
between browser and the website connected to. The 'S' at the end of HTTPS stands for 'Secure'. It means all
communications between your browser and the website are encrypted using SSL.
