GVS CHTC-86/01.1.21, CHTC-86/01.1.24, CHTC-86/01.1.22 User Manual

Guangzhou Video-star Electronics Industrial Co., Ltd

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

K-BUS

○

R

Thermostat

User manual-Ver. 1

CHTC-86/01.1.21

CHTC-86/01.1.22

CHTC-86/01.1.24

KNX/EIB Intelligent Installation Systems

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

2

Contents

1. Summary------------------------------------------------------------------------------------------------------------------------------------ 4

1.1 Product and function instruction---------------------------------------------------------------------------------------------------- 4

2. Technical Parameter, Size Structure chart and Wire Map--------------------------------------------------------------------- 5

2.1 Technical Parameter------------------------------------------------------------------------------------------------------------------- 5

2.2 Size Structure Picture----------------------------------------------------------------------------------------------------------------- 6

2.3 Button operation instruction--------------------------------------------------------------------------------------------------------- 8

3. Project design and application------------------------------------------------------------------------------------------------------- 10

3.1 Summary-------------------------------------------------------------------------------------------------------------------------------10

3.2 The external and internal temperature sensor----------------------------------------------------------------------------------- 10

3.3 Basic heating cooling and additional heating cooling control functions--------------------------------------------------- 10

3.4 the temperature control--------------------------------------------------------------------------------------------------------------10

3.5 threshold function-------------------------------------------------------------------------------------------------------------------- 12

3.6 logical function----------------------------------------------------------------------------------------------------------------------- 12

3.7 disable/enable temperature and humidity control function, the threshold value and the logical function----------- 12

3.8 timing function----------------------------------------------------------------------------------------------------------------------- 13

3.9 binary input and temperature sensor input---------------------------------------------------------------------------------------13

4. Parameter setting description in the ETS----------------------------------------------------------------------------------------- 13

4.1 overview------------------------------------------------------------------------------------------------------------------------------- 13

4.2 parameter Settings window "General"------------------------------------------------------------------------------------------- 13

4.3 parameter setting interface "Measurement Settings"-------------------------------------------------------------------------- 18

4.4 Parameter setting interface“Heating/Cooling setpoint”----------------------------------------------------------------------- 23

4.5 Parameter setting interface "Heating / Cooling Control"--------------------------------------------------------------------- 34

4.6 Parameter setting interface“Additional heating/cooling”--------------------------------------------------------------------- 42

4.7 Parameter setting interface "Fan Coil General"-------------------------------------------------------------------------------- 42

4.8 Parameter window "Fan Coil Heating/Cooling"--------------------------------------------------------------------------------44

4.9 Parameter window "Threshold value"--------------------------------------------------------------------------------------------45

4.9.1 Temperature threshold value---------------------------------------------------------------------------------- 47

4.9.2 Humidity threshold value--------------------------------------------------------------------------------------50

4.10 Parameter window "Logic"------------------------------------------------------------------------------------------------------- 53

4.11 parameter window "Timer Page 1" and "Timer Page 2"---------------------------------------------------------------------57

4.12 Parameter window "Pushbutton Interface"------------------------------------------------------------------------------------ 60

4.12.1 Switch------------------------------------------------------------------------------------------------------- 61

4.12.2 Switch/Dimming-------------------------------------------------------------------------------------------63

4.12.3 Shutter control--------------------------------------------------------------------------------------------- 65

4.12.4 Scene-------------------------------------------------------------------------------------------------------- 67

4.12.5 External temperature sensor for RTC-------------------------------------------------------------------69

4.13 Parameter window "Air Condition"---------------------------------------------------------------------------------------------71

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

3

5. Communication Object Description------------------------------------------------------------------------------------------------ 74

5.1 "General Setting” Communication Object---------------------------------------------------------------------------------------74

5.2 "Heating/cooling control “Communication Object---------------------------------------------------------------------------- 75

5.3 "Threshold value" communication object--------------------------------------------------------------------------------------- 82

5.4 "Logic" Communication Object--------------------------------------------------------------------------------------------------- 83

5.5 "Timer Page 1/2" communication object---------------------------------------------------------------------------------------- 84

5.6 "Pushbutton Interface" Communication Object-------------------------------------------------------------------------------- 85

5.6.1 "Switch" Communication Object-----------------------------------------------------------------------------85

5.6.2 "Dimming" Communication Object--------------------------------------------------------------------------86

5.6.3 "Shutter" Communication Object---------------------------------------------------------------------------- 86

5.6.4 "Scene" Communication object-------------------------------------------------------------------------------87

5.6.5 "Temperature limiter (underfloor heating)" Communication Object------------------------------------88

5.7 "Air Condition" Communication Object-----------------------------------------------------------------------------------------88

GVS K-BUS

○

R

KNX/EIB Thermostat

4

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

1. Summary

Thermostat is a device to control indoor temperature. It adjusts the room temperature and relative

humidity according to the measured temperature and relative humidity, generally implemented by

controlling indoor temperature controller and fan coil actuator on the bus. Thermostat closely bound up

with our living environment. For example, in an air-conditioned room, people would feel comfortable only

the room temperature and relative humidity is under in a certain range. Then we can monitor the current

actual indoor temperature, relative humidity through the panel, if it is beyond control, the Thermostat will

send a signal to adjust the indoor temperature and humidity by air condition. It is also widely applied in

other industries, such as food industry, temperature and humidity are essential, greenhouse and other

humidity-related industries.

User can adjust the indoor temperature according to their needs by capacitive touch buttons. LCD

screen displays the status of the current temperature control.

This user manual provides specific technical information including installation and programming

details, and explains how to use the binary input by the application examples.

1.1 Product and function instruction

Temperature control panel mainly used in building control systems and installed with EIB / KNX bus

and other devices together as a system. It’s connected directly to the terminal via the EIB bus, needed of

additional power supply. Standard 86 wall-mounted installation. You can use the engineering design

software ETS (version above ETS3 ) with VD4 ETS files to allocate physical address and set up

Parameter.

Main function summarized as below:

 Capacitive touch buttons, LCD display

 Selected internal and external temperature sensor



Basic and additional heating and cooling temperature control function

 Relative and absolute room temperature adjustment function

 Variety of temperature control mode, continuous PI control, switching PI control and

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

5

on-off control

 With PI parameters self-tuning and manual tuning two kinds of control modes



Timing room temperature control switch mode and transmit data function

 Manual and automatic three-speed fan control

 Temperature and humidity threshold function



Logical function

 Three way binary input for controlling the switching, dimming, curtains and scenes;

one for external NTC thermistor temperature sensor input

2. Technical Parameter, Size Structure chart and Wire Map

Temperature control panel use standard 86 wall-mounted installation, through the bus terminal

connected to EIB/KNX system.

2.1 Technical Parameter

Power supply

EIB/KNX voltage

21-30V DC

EIB/KNX current consumption

Max. 12mA

EIB/KNX power consumption

Max. 360mW

Auxiliary power supply

voltage

20-30V DC

power consumption

<2W

Input：

three input channels

Can be Individually configured

One NTC temperature input

Configurable NTC characteristics

Input scan voltage

3.3V DC

Input scan current

Max.0.5mA

Operating and instruction

Red LED and buttons

Distribution of physical address

Green LED flashing

Indicates device working properly

Connection

input

Connecting five lines, up to 10m

EIB/KNX

Bus connection terminal (diameter

0.8mm2)

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

6

Temperature range

operating

– 5 °C ... 45 °C

storage

– 25 °C ... 55 °C

transportation

– 25 °C ... 70 °C

Environmental conditions

humidity

<80%，No dewing

Installation

standard 86 wall-mounted installation

Size

86*86*42.6mm

Weight

0.3KG

Temperature

Measuring range

-5℃…70℃

Resolution

0.1℃

Accuracy

±0.5℃

Humidity

Measuring range

0…100%RH

Resolution

0.01%

Accuracy

3%RH

2.2 Size Structure Picture

Figure2.2.1 Thermostat Size picture

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

7

Figure2.2.2Thermostat coupler size picture

Figure2.2.2Thermostat connect picture

①、②：KNX/EIB Auxiliary power supply

③、④：KNX/EIB BUS

⑤： NTC temperature
⑥、⑦、⑧：Three binary inputs

To ensure the accuracy and stability of the measurement Thermostat, please note the following

items:

1．Keep away from air conditioners, refrigerators, stoves and other areas sensitive to changes in

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

8

air temperature.

2 ． Should not be installed in direct sunlight and away from a strong vibration, electromagnetic

interference are, Its location should avoid breaking the appearance and integrity of the building, installed

with a outdoor weatherproof shield.

3．As far as possible away from door, window, and air vents. If impossible, the distance should not

less than 2m;

4．Try to avoid using environment in the dusty environment and installing in poorly ventilated place.

5 ． Avoid working in extreme conditions and chemical vapors, otherwise it will cause inaccurate

readings of Thermostat.

2.3 Button operation instruction

LCD display: the current temperature, setting temperature, the heating and cooling, working mode,

wind speed, weeks time, timing marks, relative humidity

Button on the circuit board from left to right: mode key, increasing key, reducing key, wind speed

key, timing button and power button underneath.

Power button: the power button is used for the switch display.Just on electricity, Thermostat

LCD screen does not display anything until you press the power button on screen.At this point the

pattern, temperature, refrigeration and heating and time on the screen can be set by buttons.

Mode button: mainly used to switch four kinds of room temperature control modes. the icons

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

9

from left to right are the comfortable mode, standby mode, night mode and

the protection mode, different modes correspond to different setting temperature .In addition, the mode

key can switch heating and cooling functions. When the database is set to the heating and cooling both

needed, you can long press the button to switch the heating and cooling on the "Heating/cooling

setpoint"parameter window’s parameters "Switchover between Heating and cooling" with option "manual

Switchover by object”.

Increasing key: the key is mainly used to upward adjust current set temperature or time

regularly.When adjust the set temperature,the increment is 0.5 ℃, when adjust the set time, the

increment is 1.

Reducing key: the key is mainly used to downward adjust the current set temperature or time

regularly.When adjust the set temperature, the reduction is 0.5 ℃, when adjust the time, the reduction is

1.

Wind speed key: the key is used to adjust the fan speed.The icon

indicates the wind speed, which is divided into four gears, automatic transmission, 1, 2 and 3

transmission, which can also switch the wind speed.

Timed key: the key is mainly used for timing and modifying the regular time.Before entering

the timing Settings, short press it can implement the timing function, the icon displays enable

timing function, at this time the short press of mode key is locked and the operation is invalid, the mode

switchover according to the periodic time ;If the icon don't show anything, the timing function don't

enable .Before entering the long press of timing time setting ,the humidity display area will not display

the humidity temporarily, but use the serial number to modify time, the "0" shows modifying the current

time value , the other "1-16" show 16 regular time values;At this point the modifying place will twinkle

and you can short press switch to modify it ,then adjust the current value through the increase or

decrease button .When completed, long press timing Settings exits , the humidity and time return to

normal display.

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

10

3. Project design and application

3.1 Summary

Application program

Max. number of

communication objects

Max. number of group

addresses

Max. number of

association addresses

Thermostat

108

180

180

Thermostat mainly send output control value to fan coil actuator through collecting temperature

and setting temperature , so as to realize the effect of indoor constant temperature. Thermostat can also

carry out fan speed adjustment, room mode switching and timing Settings by KNX manual operation ,

and so on. Thermostat also provide 3 binary inputs which can be used to switch, dimming, curtains and

scene control.

3.2 The external and internal temperature sensor

Thermostat can provide three temperature collecting ways,

○

1

from temperature sensor in

Thermostat,

○

2

from bus to receive external temperature,

○

3

from external NTC thermistors.

3.3 Basic heating cooling and additional heating cooling control functions

Thermostat has the basic heating refrigeration output control function according to the temperature

set by the user , in addition to basic heating refrigeration control function, there is additional heating

refrigeration control function as a supplement to the temperature control. When the actual temperature

and set temperature have a large deviation , additional heating refrigeration control function can let a

room faster heating or cooling.

3.4 the temperature control

Thermostat use relative adjustment in all kinds of temperature setting values of work mode .At the

same time ,it also provide a variety of types of controls, such as continuous PI control, switch mode PI

control, 2 - point control and fan coil control, different types of control is suitable for different types of

temperature controller.

Continuous control

Continuous control’s control values is calculated by the actual temperature and set temperature,

and then control the opening of continuous valve, attain the comfortable room temperature state. For

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

11

example, when the current control values is 50% of the largest , the valve position will open to 50%

according to the control values ;If the output control values is the maximum , the valve is fully open.

Continuous control can realize the "on", "off" and "stop" three-step operations, specific action is shown in

the figure below:

Continuous control can realize the most precise temperature adjustment without quite big overshoot.

At the same time, the frequency of the positioning valve actuator can maintain at a low level. Continuous

control can also control the rise and fall valve of the fan coil or KNX valve actuator.

PWM control

PWM (pulse width modulation) control’s values is calculated according to the actual temperature

and set temperature, and then calculate the on and off time of the switch valve to control it, to achieve a

comfortable room temperature state. Switch valve only has "open" and "full close" two control

operations.PWM control needs to set a fixed cycle time at first, such as setting the PWM cycle for 15

minutes, when the control values is 20% of the maximum , the valve will open 15 * 20% = 3 minutes;

Close 15 * 80% = 12 minutes; When the control values is 50% of the maximum , the valve will open 15 *

50% = 7.5 minutes; Close 15 * 50% = 7.5 minutes. Schematic diagram is shown below:

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

12

PWM control is a relatively accurate adjustment, if you choose the appropriate cycle, the

temperature overshoot will not be very big, a simple low cost common switch valve actuator can be

used .It can be used to control ordinary switch valve of the fan coil , electric valve or KNX valve driver.

3.5 threshold function

Temperature and humidity each provides two threshold functions, the Thermostat ,based on

threshold range of the current temperature and humidity , triggers two different types (1bit / 1 byte) of

data to sent to the bus, which can control other equipment switches or adjust related output of valves.

3.6 logical function

Thermostat provides two logic functions, each has three inputs, each input can be arbitrarily set, it

can be the message (1bit) sent by the temperature threshold , or the message (1bit) sent by the humidity

threshold , or the message received from the bus, also it can be obtained by getting the opposite

message to participate in the logic operation, the message (1 bit / 1 byte) will be output according to the

result , triggering the switch of other equipment, or to adjust output of valves.

3.7 disable/enable temperature and humidity control function, the threshold value

and the logical function

The temperature and humidity control functions can be prohibited or enabled by bus, when the

temperature/humidity function is banned, the Thermostat will not be able to send the control values. The

threshold value and the logical function can also be banned or enabled by bus, when the threshold

function is banned, the Thermostat will not determine the current threshold values range of temperature

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

13

and humidity and will not control it; When logic functions are banned, the logic operation from

Thermostat will be disrupted as well as the control of this function.

3.8 timing function

Thermostat offers 16 timing time, so users can set the timing time regularly according to their using

habits, which automatically adjust the working mode and send the appropriate value. When arrived at

timing time, it can automatically switch to the corresponding working mode and the corresponding

numerical values.

3.9 binary input and temperature sensor input

Thermostat offers binary input and three roads, which is used to switch, dimming, curtains and

scene controls. One way is externally connected to temperature sensor input, which can be a NTC

thermistor as an external temperature sensor, or as a floor heating temperature limiter, stops heating

when floor heating is higher than the limited temperature heating.

4. Parameter setting description in the ETS

4.1 overview

Thermostat can be set at different control modes according to users’ needs; here we introduce the

database settings of Thermostat below.

4.2 parameter Settings window "General"

"General" parameter Setting interface as shown in figure 4.2, the interface are mainly some of the

general Thermostat parameter Settings, such as the choice of heating and refrigeration control functions

by temperature control , LCD backlight brightness parameter setting, and so on.

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

14

Figure 4.2“General settings “Parameter Settings interface

Parameter “Send ‘In operation’ object”

Options ：No

Send value “0” cyclically

Send value “1” cyclically

These parameter set the Thermostat cycle and send a message "1" or "0" to the bus,which shows

that the panel is working well. If fail, it will stop sending the message "1" or "0".Options for "No", do not

send; Options for the value '0' cyclically "send" or "send the value '1' cyclically", Thermostat will send a

message "0" or "1"according to the set period of time, so the object "in operation" and "Transmission

period of" in operation "object" parameter will be visible.

Parameter “Transmission period of "In operation" object”

Options： 5s

10s

…

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

15

2h

This parameter is the communication object sending period for testing whether Thermostat is

normal or not, and mainly being sent to the bus circularly to tell whether Thermostat is normal or not

through object "in operation”.

Parameter “Temperature display”

Options： Celsius (C)

Fahrenheit (F)

Here setting the LCD panel temperature display unit. Choose “Celsius (C)”the temperature will be

displayed in Celsius; Choose "Fahrenheit (F)" the temperature will be displayed in Fahrenheit.

Parameter “Backlight in no operation in day (%)”

Parameter “Backlight in operation in day (%)”

Parameter “Backlight in no operation in night (%)”

Parameter “Backlight in operation in night (%)”

Options：0…100%

This parameter is mainly used to set up the LCD panel backlight brightness.in the daytime or at

night under the condition of operation and non-operation .The user can set the day or night through the

bus, also can identify the day or night by time points .

Parameter “Time of backlight delay(s)”

Options：5…50 s

This parameter is mainly used for setting the backlight value from operating status to non-operation

status. Namely when nobody operates screen, delaying the parameter time, entering the screen

backlight without operation.

Parameter “Switch day/night mode automatically"

Options: no

yes

Set the mode automatically switches about whether to activate the day / night backlight brightness.

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

16

If you choose "no", conduct day or night light switch through the communication objects-"Day / night

mode"; If you choose "yes”, setting up automatic switching by setting the time moment.

Parameter "Time for switching to night at: hour (0 ... 23) / minute (0 ... 59)"

Set the time that LCD backlight brightness switches to night backlight. For example, once setting to

18:00 that means the backlight brightness of the LCD screen automatically switches to night mode when

the time is 18:00 pm.

Parameter "Time for switching to day at: hour (0 ... 23) / minute (0 ... 59)"

Set the time that LCD backlight brightness of the backlight switch to daylight. For example, once

setting to 6:00, that means LCD backlight brightness automatically switched to day mode when the time

is 6:00.

Parameter "Time mode"

Options: 24H

AM / PM

This parameter set show the mode of time display. "24H" indicates the time on the Thermostat

display system for 24 hours; "AM / PM", means the time display system in Thermostat for 12-hour.

Parameters "Send current time"

Options: Do not send

1s

30s

1min

30min

1h

This parameter set sends the current time on the bus, "Do not send" means don't send time to the

bus; "1s" means sending the time to the bus per second; "30s" means sending time to the bus on 30s,

such as 9:10:30, 9:11:30, 9:12:30; "1min" means sending the time to the bus per on minute point, such

as 9:11:00, 9:12:00, 9:13:00; "30min" means sending the time to the bus on 30 minutes, such as 9:30:00,

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

17

10:30:00, 11:30:00; "1h" means sending the time to the bus per on hour point, such as 9:00:00, 10:00:00,

11:00:00.

Parameters "Warning tone"

Options: disable

enable

The parameters mainly are set in the Thermostat keys about whether to open the tone. "Disable" is

not enabled tone, "enable" to enable beep.

Parameter "Control device"

Options: HVAC

air condition

This parameter is used to select the type of heating and cooling systems. "HVAC" means the fan

coil system, controlling the temperature by controlling fan coil actuator; "air condition" means home air

conditioning system, adjusting household air temperature by controlling the infrared device.

Parameter "Temperature control system"

Options: Cooling

Heating

Heating and Cooling

Basic and additional cooling

Basic and additional heating

Basic and additional Heating and Cooling

This parameter is used to set the temperature control feature, you can select the basic heating and

cooling can also choose the basic heating and cooling plus auxiliary heating and cooling. Select "cooling

/ heating", enabling cooling / heating function, or both enabled, when selecting its options, the

corresponding settings interface "heating / cooling setpoint" and "heating / cooling control" visible in the

interface can be set with the corresponding parameters.

Parameter "Control action when display off"

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

18

Options: All off

Protect mode

This parameter is a command need to be send when the display off. "All off" means the command of

sending off the fan and coil instructions when the screen being turned off; "Protect mode" means the

command of the room mode transfer to protected mode when the screen being turned off.

Parameters "Heating and cooling share object"

Options: yes

no

This parameter is visible when choosing "Heating and Cooling" or "Basic and additional Heating and

Cooling" in temperature control function ,this parameter is used to select whether the heating and

cooling control value share a communication object to accommodate two or four control system controls.

4.3 parameter setting interface "Measurement Settings"

"Measurement Settings" parameter setting interface as shown in Figure 4.3, where the main set

some general parameters to measure temperature and humidity.

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

19

Figure 4.3 "Measurement Settings" parameter setting interface

Parameter "Temperature sensor"

Options: internal sensor

external sensor

internal sensor and external sensor

This parameter defines the type of temperature sensor.

If selecting "internal sensor", the temperature measured by the temperature sensor panel, will be

read or send to the bus by the “Actual temperature”, so that controller will control according to the

temperature;

If selecting "external sensor", the temperature will be measured by an external temperature sensor,

Thermostat receives the temperature send from the bus temperature sensor by "Input external

temperature", Thermostat will control according to this temperature. When you select this option, after

power-up, the panel began to control the temperature. only when the Thermostat received the

temperature from an external sensor.

Once selecting "internal sensor and external sensor", the local sensor and external temperature

sensor will be used simultaneously, this sets suit for a large area to temperature control, such as a lobby,

where using many sensors at the same time, temperature sensors B get the temperature from sensor A,

then get the proportion of the sum itself, and then it will control the temperature based on the results of

summation, or transmits the result to the summing sensor C, or give the sum to sensor C which will

control temperature after receives the temperature and got the proportion of the sum itself too. The

proportion of the sum results of multiple temperature sensors is set through the "Actual temperature", the

temperature send from the external temperature sensor is received by “Input external temperature".

Parameters "Internal / External temperature correction

Options: -128 ... 127 (value * 0.1)

It sets the temperature correction, which can correct the temperature detected by internal / external

sensors to prevent too much error between the actual temperature and the measured one. For example,

if the amendment data is 50, the temperature detected by sensor is 20 ℃, so the temperature corrected

is 20 +50 * 0.1 = 25 ℃.

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

20

Parameters "Weighting interior / exterior"

Options: 0% / 100%

10% / 90%

...

100% / 0%

This parameter is visible when selecting "Internal and External sensor" in the sensor type, it can set

the proportion between the measured temperature of Thermostat sensor and an external sensor. For

example, the option is "40% / 60%", so, the panel temperature sensor (A) occupies 40%, an external

sensor (B) occupies 60%, temperature control = (the temperature × 40% A) + (the temperature of B ×

60%), Thermostat will control temperature according to the calculated temperature control which send

by the "Actual temperature". This is the proportion summing process.

Parameters "Send temperature at variation of (℃)"

Options: Do not send

0.1

0.2

…

3

This parameter define "Actual temperature" can send the current temperature to the bus when a

certain amount of temperature change.

If the option is "Do not send", the temperature only be sent to the bus through the "Actual

temperature", because the temperature measurement value is not automatically transmitted to the bus

If an option is "3", the "Actual temperature" can send the current temperature to the bus when the

temperature reached changes at least 3 ℃,

Parameter "Monitoring time of external sensor in min (0 = inactive)"

Options : 0 ... 255 min

This parameter will be visible when choosing "external sensor" or "internal and external sensor"

about sensor type, to set monitoring time of the thermostat panel to external temperature sensor. If

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

21

setting the monitoring time to 0, will not be monitoring the external temperature sensor .

Once setting the "external sensor", if the thermostat panel does not receive the temperature send

from external temperature sensor within the set monitoring time, Thermostat will consider the external

sensor is faulty, will stop controlling and control sending packets of controlling stop.

Once setting the "internal and external sensor", if the thermostat panel does not receive the

temperature send by external temperature sensor within the set monitoring time, Thermostat will

consider the external sensor is faulty , so that only use the measurement by Thermostat to control .

The monitoring time will be re-timed, when the thermostat panel receives each packet send from the

external temperature sensor,

Note: The monitoring time from Thermostat for external temperature sensor should be at

least 2 times for the time that the external temperature sensor sending messages for preventing

packets missing.

Parameters "Period of sending temperature"

Options: Do not send

5s

10s

..

2h

This parameter sets the time interval of sensor for sending temperature to the bus loop through

"Actual temperature".

Parameters "Indoor and outdoor temperature"

Options: disable

enable

The parameter is visible when the "Temperature sensor" selecting "internal sensor and external

sensor", which can be used to set whether to alternately display the indoor temperature and outdoor

temperature on the display. Outdoor temperature taken from the object 84.

Parameters "Indoor and outdoor temperature switch time (second)"

Options: 0 ... 255 s

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

22

The parameter will be visible when the parameter "Indoor and outdoor temperature" selecting

"enable" ,which is used to set the time interval for the internal temperature and external temperature

alternately.

Parameters "Humidity correction in%"

Optional: -15 ..15

This parameter defines the correction settings of humidity that sensor measured to prevent much

error between the moisture measurement with the actual humidity. For example, setting correction

value to 1%, if the humidity measured by the sensor is 40%, then the corrected humidity is 40% + 1% =

41%.

Parameters "Send rel. Humidity at variation of (%)"

Options: Do not send

1

2

...

20

This parameter defines to change when humidity change a certain amount, the communication

object "rel. Humidity" can send current humidity to the bus.

If choosing "do not send", humidity measurements are not automatically sent to the bus, can sent

automatically after be read through communication objects "rel. Humidity".

If choosing "3", the communication object "rel humidity" will send to the current temperature on the

bus when the humidity changed to 3%.

Parameters "Period of sending humidity"

Options: Do not send

5s

10s

..

2h

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

23

This parameter setting defines the transmission time interval of the thermostat panel cycle send to

other devices in the bus through its communication objects “rel. humidity.

4.4 Parameter setting interface“Heating/Cooling setpoint”

In the setting of “Temperature control system”, parameter’s setting content will be different in this

page according to your choice from “Cooling”, ”Heating” or “Heating and Cooling”. Temperature can be

set here under any work patterns, including relative mode and absolute mode.

Figure 4.4.1 Parameter setting interface of “Heating setpoint”

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

24

Figure 4.4.2 Parameter setting interface of “Cooling setpoint”

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

25

Figure 4.4.3 Parameter setting interface of “Heating/cooling setpoint”

Parameter “operation mode after reset”

Options： comfort

standby

night

Frost/heat protection

Here we can set the work patterns which is after BUS DEVICE RESET or after programming.

There are 4 work patterns in temperature controller including comfort mode, standby mode, night

mode and Frost/Heating protecting mode. Every mode has its corresponding temperature setting.

Comfort mode is applied to the daytime when someone at home. Standby mode is applied to the

daytime when no one at home for saving the energy. Night mode is applied for the night time when

someone at home. Frost/Heating protecting mode is applied for the long time going out in order to

prevent the devices from damaging by the highest or lowest temperature.

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

26

Parameter “Object type for operating mode switchover”

Options： 1bit

1byte

This Parameter is use for giving a definition of object type when switching mode room’s temperature

work patterns.

When choosing “1bit”，you can find the type of “Active frost/heating protection mode”, “Active night

mode” and“Active comfort mode”. These types can switch the room temperature controller into different

work patterns. The work pattern will switch to standby mode when the value of all these three type is “0”.

Choosing “1bit”, the priority of every work patterns are as follows. (Frost/heating protection→ Comfort

→night→standby):

forcing

switchover

Window

status

Presence

object

1bit switching

Work pattern to be

activated

Comfort

Standby

Night

Frost/heating

protection

01xxxxxx

Comfort

02xxxxxx

Standby

03xxxxxx

Night

04xxxxxx

Frost/heating

protection

001xxxxx

Frost/heating

protection

0001xxxx

Comfort

00001000

Comfort

00000100

Standby

00000010

Night

00000001

Frost/heating

protection

When choosing“1byte”, you can find the type of“Temperature operating mode switchover”. Under

this circumstances, different Room temperature controller can be switched into different work patterns by

setting every value of type. Values to the work pattern is as follows. 0 - Automation (comfort mode). 1 -

Comfort mode. 2 - Standby mode. 3 - Night mode. 4 - Frost/Heating protecting mode. 5 - Reserved.

GVS K-BUS

○

R

KNX/EIB Thermostat

www.video-star.com.cn [e-mail] Tel.：[phone]

Fax.：[phone]

27

forcing switchover

Window status

Presence object

Operating mode

switchover

Work pattern

to be activated

01xxxComfort

02xxxStandby

03xxxNight

04xxxFrost/heating

protection

001xxFrost/heating

protection

0001xComfort

000001Comfort

000002Standby

000003Night

000004Frost/heating

protection

Parameter “Send setpoint”

Options ： do not send

on change

cyclically

on change and cyclically

In the Parameter of “Send setpoint”, the ways of sending the temperature setpoint can be set.

When choosing “do not send”，the temperature setpoint won’t be sent. It only can be sent to the bus

after reading by “setpoint temperature”.

When choosing “on change”, the temperature setpoint will be sent to the bus after the changing of

temperature setpoint.

When choosing “cyclically”, the temperature setpoint will be sent to the bus recurrently. Once the

temperature setpoint are changed, it will be sent one week later.

When choosing “on change and cyclically”, the temperature setpoint will be sent to the bus

recurrently. Once the temperature setpoint are changed, it will be sent immediately. Cycling time starts

over.
