GVI Security NID-2161 Specifications
NID-2161
2 Megapixel, H.264, IRLED Dome IP Camera
Summary
autoIP™ NID-2161 varifocal indoor dome camera is designed to provide cost effective, FULL HD video
surveillance in low light conditions. A 1/2.5” CMOS progressive scan image sensor delivers FULL HD
video that is compressed with H.264 to retain high video quality at a low data rate. IR LED lets getting
clear image under low light conditions for up to 35 feet distance. Moreover, Power over Ethernet (PoE)
reduces installation time and costs. NID-2161 camera is compatible with the user-friendly autoIP™
open platform video management software, as well as ONVIF conformant VMS, for quick plug and play
installation.
Features
• 1/2.5” Progressive Scan CMOS
• Full HD, 1920x1080 Resolution
• Auto-Iris Varifocal Lens: F 1.4 / f = 3.3 ~ 12 mm
• IR LED: 23 units
• Effective Distance: 35ft
• Min. Illumination: 0 Lux at 50 IRE
• Tampering Alarm
2MP, Full HD Resolution
autoIP™ NID-2161 provides high quality crisp
image with up to 1920x1080p resolution. This
feature produces same resolution levels used by
1080p Full HD monitors.
Standard 2MP, Full HD Resolution
True Day/Night
autoIP™ NID-2161 is equipped with ICR Cut
Filter that is automatically activated to enable
video recording in low light conditions.
• Multiple Codec (H.264, MJPEG)
• Simultaneous Dual Codec
• Micro SD Card Support
• Power over Ethernet (PoE)
• Operating Temperature Range: 12°F ~ 122°F
• 3-axis Installation
Effective IR Distance: 35ft
With an “effective IR Distance” of 35ft, autoIP™
NID-2161 records every single detail of an
object in the complete darkness. Moreover,
camera provides enough illumination to see an
object located up to 100 feet away.
GVI Security | Toll Free: 888-595-2288 | Fax: 972-245-7333
This product specifications and manual are also available in pdf format at www.gviss.com
The information is subject to change without notice - v7.14.11
Day Night
35ft.
NID-2161
NID-2161
2 Megapixel, H.264, IRLED Dome IP Camera
Specications
Camera
Image Sensor 1/2.5” Progressive CMOS
Picture Elements 1920(H) x 1080(V)
Minimum Illumination LED off 0.1 lux @ F 1.6
IR LED Unit Count 20
Shutter Speed 1~ 1/10000 sec.
White Balance Manual / AWB / ATW
Lens F 1.4 / f = 3.3 ~ 12 mm
Video
Compression H.264/MJPEG
Streaming Simultaneous H.264 + MJPEG
Resolution H.264/MJPEG Full HD 1080p/HD 720p/SXGA/D1/VGA/QVGA/CIF
Frame Rate 30 fps at HD and lower resolutions
Image Settings Auto-Iris Yes
Day/Night True Day/Night
Audio
Bi-directional Audio Line-out/Line-in (Mic-in)
Compression G.711/G.726
Alarm
I/O Input 5V 10kΩ
Network
Connector RJ-45
Interface 10/100Mbps Ethernet (RJ-45)
Supported Protocols TCP/IP, UDP, RTP, RTSP, HTTP, ICMP,FTP, SMTP, DHCP, PPPoE,
User Account Allowance 20
Other Connectors
Micro SD SDHC
Analog Video BNC, 1.0 Vp-p / 75Ω
Environmental
Operating Temperature 12°F~122°F (-10°C ~ 50°C)
Operating Humidity 10% to 90%, No Condensation
Power
Power Source DC12V/AC24V/PoE
Power Consumption LED off 5W
Certifications and Dimensions
Certifications CE, FCC, RoHS
IP66 No
Dimension (W x H) 5.9 x 5.1 in (151 x 130 mm)
Weight 1.50 lbs (0.7 kg )
LED on 0 lux
Effective Distance 35 ft
71° ~ 21°
H.264 + H.264
15fps at Full HD
Exposure Auto/Manual
Brightness Manual
Sharpness Manual
Contrast Manual
Saturation Manual
Hue Manual
Motion detection On/Off
Tampering Alarm Yes
Privacy Mask 2 Masks
Output Relay 300VDC/AC
LED on 8.4W
Transparent, Color
UPnP and IGMP
Dimensions (unit : in)
5.9
5.1
Certications
Side/Rear Panel
GVI Security | Toll Free: 888-595-2288 | Fax: 972-245-7333
This product specifications and manual are also available in pdf format at www.gviss.com
The information is subject to change without notice - v7.14.11
