GVI Security NIB-2150 Specifications
NIB-2150
2 Megapixel, H.264 IP Box Camera
Summary
autoIP™ NIB-2150 box camera is designed to provide cost effective, 2MP FULL HD video surveillance.
A 1/2.7” CMOS progressive scan image sensor delivers 1080p FULL HD video that is compressed
with H.264 to retain high video quality at a low data rate. Motion Detection, privacy masks, and
tampering alarm increases the effectiveness of security surveillance. Power over Ethernet (PoE)
reduces installation time and costs. NIB-2150 camera is compatible with the user-friendly autoIP™
open platform video management software, as well as ONVIF conformant VMS, for quick plug and play
installation.
Features
• 1/2.7” Progressive Scan CMOS
• Full HD, 1920x1080 Resolution
• True Day/Night (ICR)
• Multiple Codec (H.264, MJPEG)
• Simultaneous Dual Codec Support
• Motion Detection
2MP, Full HD Resolution
autoIP™ NIB-2150 provides high quality crisp
image with up to 1920x1080p resolution. This
feature produces same resolution levels used by
1080p Full HD monitors.
True Day/Night
autoIP™ NIB-2150 is equipped with ICR Cut
Filter that is automatically activated to enable
video recording in low light conditions.
• Tampering Alarm
• Flip, Mirror, Rotate Functions
• Micro SD Card Support
• Power over Ethernet (PoE) Support
• Operating Temperature Range: 32°F ~ 122°F
• ONVIF Conformant
Standard 2MP, Full HD Resolution
GVI Security | Toll Free: 888-595-2288 | Fax: 972-245-7333
This product specifications and manual are also available in pdf format at www.gviss.com
The information is subject to change without notice - v7.14.11
Day Night
NIB-2150
NIB-2150
2 Megapixel, H.264 IP Box Camera
Specications
Camera
Image Sensor 1/2.7” Progressive CMOS
Picture Elements 1920(H) x 1080(V)
Minimum Illumination Color 0.2 Lux @ F 1.2
Shutter Speed 1~ 1/10000 sec.
White Balance Manual / AWB / ATW
Lens C/CS Mount
Video
Compression H.264/MJPEG
Streaming Simultaneous H.264 + MJPEG
Resolution H.264/MJPEG Full HD (1080p)/HD (720p)/D1/CIF
Frame Rate 30 fps at HD and lower resolutions
Image Settings Auto Iris Yes
Day/Night True Day/Night (ICR)
Audio
Bi-directional Yes
Connector Stereo phone jack, ∅ 3.5mm
I/O Line out
Compression G.711/G.726
Alarm
Connector 4 pins terminal block, pitch 3.5mm
Input 5V 10kΩ
Output Relay Output 300VDC/AC
Tampering Alarm Yes
Network
Connector RJ-45
Interface 10/100Mbps Ethernet (RJ-45)
Supported Protocols TCP/IP, UDP, RTP, RTSP, HTTP, ICMP,FTP, SMTP, DHCP, PPPoE,
User Account Allowance 20
Other Connectors
Analog Video BNC, 1.0 Vp-p / 75 Ω
Micro SD SDHC
Environmental
Operating Temperature 32°F~122°F (0°C ~ 50°C)
Operating Humidity 10% to 90%, No Condensation
Power
Power Source DC12V/AC24V/PoE
Power Consumption 4W
Certifications and Dimensions
Certifications CE, FCC, RoHS
Dimension (L x W x H) 4.92 x 3.23 x 2.05 in. (125 x 82 x 52 mm)
Weight 0.80 lbs (360 g)
B/W 0.02 Lux @ F1.2
H.264 + H.264
15fps at Full HD
Exposure Auto/Manual
Brightness Manual
Sharpness Manual
Contrast Manual
Saturation Manual
Hue Manual
Motion detection On/Off
Privacy Mask 2 Masks
Transparent, Color
Line in/Mic in
UPnP and IGMP
Dimensions (unit : in)
4.92 3.23
Certications
Lens Options (Not Included)
GV-2.8-12ADCIRMP
12mm F1.4 1R Corrected, Megapixel
1/3” Vari-focal DC Auto Iris 2.8-
Side/Rear Panel
2.05
GVI Security | Toll Free: 888-595-2288 | Fax: 972-245-7333
This product specifications and manual are also available in pdf format at www.gviss.com
The information is subject to change without notice - v7.14.11
