LOW PROFILE FAN HEATER
GLFH2K17
Instruction Manual
GLFH2K17_IB_161128_grace.indd 1 28/11/16 4:28 pm
GLFH2K17_IB_161128_grace.indd 2 28/11/16 4:28 pm
1
Contents
Guide to the Appliance 2
Caring for the Environment 3
Safety Information and Warnings 4
Items in the Box 11
Operation Instructions 12
Troubleshooting 13
Care and Maintenance 14
Technical Specifications 15
GLFH2K17_IB_161128_grace.indd 1 28/11/16 4:28 pm
2
Guide to the Appliance
Due to production improvements, the appliance may differ
slightly from the diagram shown. Diagrams in this instruction
manual are for reference only.
1. Thermostat Control
2. Indicator
3. Power Control
4. Heating Outlet
1
3
2
4
GLFH2K17_IB_161128_grace.indd 2 28/11/16 4:28 pm
3
Caring for the Environment
Responsible disposal of the packaging
The packaging of your appliance has been selected from environmentally
friendly materials and can usually be recycled. Please ensure these are
disposed of correctly.
Plastic wrapping can be a suffocation hazard for babies and young
children, please ensure all packaging materials are out of reach and
are safely disposed of. Please ensure they are offered for recycling rather
than throwing these materials away.
Responsible disposal of the appliance
At the end of its working life, do not throw this appliance out with your
household rubbish. An environmentally friendly method of disposal will
ensure that valuable raw materials can be recovered and used again.
Electrical and electronic appliances contain materials and substances
which, if handled or disposed of incorrectly, could be potentially
hazardous on the environment and human health.
Observe any local regulations regarding the disposal of electrical
consumer goods and dispose of it appropriately. Contact your local
authorities for advice on recycling facilities in your area.
The plug must be rendered useless and the cable cut off directly behind
the appliance or the machine to prevent misuse.
GLFH2K17_IB_161128_grace.indd 3 28/11/16 4:28 pm
4
Safety Information and Warnings
Please follow all the safety precautions
listed below for safety and to reduce the
risk of injury or electrical shock.
• Read all the instructions before operating
the appliance and keep them for future
reference. If you pass the product on to a
third party, include these instructions.
• This appliance is intended for indoor
household use and similar applications
such as:
– farm houses and by clients in hotels,
motels and other residential type
environments;
– bed and breakfast type environments;
– catering and similar non-retail
applications.
• Make sure your home voltage matches
the voltage displayed on the appliance.
If you are not sure, contact an electrician.
• Do not kink or wrap the mains cable and
plug around the appliance, as this may
cause the insulation to weaken and split,
particularly where it enters the appliance.
GLFH2K17_IB_161128_grace.indd 4 28/11/16 4:28 pm
5
Safety Information and Warnings
• Ensure the mains cable is fully extended
before use and arrange it so that it is not
in contact with any part of the appliance.
• Do not pull on the mains cable. Never
move, carry or hang the appliance by the
mains cable.
• Always position the appliance with the
mains plug in an accessible position and
avoid the use of an extension cable as it
may overheat and create a potential fire
risk.
• The appliance must have a minimum
20 cm clearance around all sides of the
appliance.
• Ensure that the unit is used on a stable
and level surface. If the floor surface is
uneven there is a risk that the appliance
could tip over. Also, excessive vibration
and noise may occur. If the appliance
should be accidentally tipped over, please
immediately disconnect from the power
supply.
• Do not use the appliance in wardrobes or
near fabrics or clothing. Do not stand the
GLFH2K17_IB_161128_grace.indd 5 28/11/16 4:28 pm
6
Safety Information and Warnings
appliance on deep pile carpets.
• Do not use the appliance in areas
where petrol, paints or other flammable
substances are used or stored.
• Do not use in very dusty areas as dust
may accumulate on the heating elements
and cause overheating.
• Do not use if there are any visible signs of
damage to the appliance.
• Do not operate the appliance in direct
sunlight, near heat sources, humid
environments or in places near water or
other liquids such as bathrooms, showers
or swimming pools.
• Do not operate with wet hands or spill
water or other liquids on to the appliance,
the mains cable or plug.
• Always unplug the appliance when not in
use.
• Never leave the appliance unattended
when in use.
• The heater must not be located
immediately below a mains socket.
GLFH2K17_IB_161128_grace.indd 6 28/11/16 4:28 pm
7
Safety Information and Warnings
• Do not allow children to play with the
appliance or sit, stand, or climb on it.
• Do not leave children alone or unattended
in the area where the appliance is in use.
• For safety reasons a broken or damaged
mains cable may only be replaced by
the manufacturer or a similarly qualified
person.
• This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use
of the appliance by a person responsible
for their safety. Children shall not play
with the appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
• Children should be supervised to ensure
that they do not play with the appliance.
• Never allow children to point their fingers
into any power sockets or moving parts.
GLFH2K17_IB_161128_grace.indd 7 28/11/16 4:28 pm
8
Safety Information and Warnings
• Do not block or restrict the airflow around
the appliance. Position the unit so that
the air inlet and exhaust grilles are not
blocked or restricted in anyway.
• Do not push any objects in the air inlet
and exhaust grilles.
• WARNING: In order to avoid overheating,
do not cover the appliance.
• Do not use this heater with a programmer,
timer, separate remote-control system or
any other device that switches the heater
on automatically, since a fire risk exists
if the heater is covered or positioned
incorrectly.
• Children should be kept away unless
continuously supervised.
• Children shall not plug in, regulate and
clean the appliance or perform user
maintenance.
• CAUTION: Some parts of this product
can become very hot and cause burns.
Particular attention has to be given where
children and vulnerable people are
present.
GLFH2K17_IB_161128_grace.indd 8 28/11/16 4:28 pm
9
Safety Information and Warnings
• Do not let the power cord hang over
the edge of a bench or table, touch hot
surfaces or become knotted.
• Switch the appliance and disconnect from
supply before changing accessories or
approaching parts that move in use.
• It is recommended to inspect the appliance
regularly. Do not use the appliance if the
power supply cord, plug, connector or
appliance becomes damaged in anyway.
Return the entire appliance to the nearest
authorised Service Centre for examination
and/or repair.
• This appliance is for household use only.
Do not use this appliance for other than
its intended use. Do not use in moving
vehicles or boats. Do not use outdoors.
Misuse may cause injury.
GLFH2K17_IB_161128_grace.indd 9 28/11/16 4:28 pm
10
Safety Information and Warnings
• The installation of a residual current
device (safety switch) is recommended to
provide additional safety protection when
using electrical appliances. It is advisable
that a safety switch with a rated residual
operating current not exceeding 30mA be
installed in the electrical circuit supplying
the appliance. See your electrician for
professional advice.
• Always turn the appliance to the OFF
position, switch off at the power outlet
and unplug at the power outlet when the
appliance is not in use.
• Do not place this appliance on or near a hot
source, such as hot plate, oven or heaters.
• Position the appliance at a minimum
distance of 20cm away from walls,
curtains and other heat or steam sensitive
materials and provide adequate space
above and on all sides for air circulation.
GLFH2K17_IB_161128_grace.indd 10 28/11/16 4:28 pm
11
Items in the Box
Remove all items from the packaging. Retain the packaging. If you
dispose of it please do so according to local regulations.
The following items are included:
Instruction Manual
Instruction
Manual
Main Unit
GLFH2K17_IB_161128_grace.indd 11 28/11/16 4:28 pm
12
Operation Instructions
• To switch on the heater, plug in to the power outlet and turn the power
control to I (lower power), II (higher power) or just fan.
• Turn the thermostat control to maximum position.
• Wait for the heater to fully heat up. When the room reaches the desired
temperature, turn the thermostat control slowly anti-clockwise.
• If you want to raise the room temperature, turn the thermostat control
slowly clockwise.
• To switch off the heater, turn the power control to 0 and turn the
thermostat control to minimum position, then unplug from the power
outlet.
Built-in Safety Tipover Switch
When you use the heater in an upright position on a firm and level
surface, the built-in safety tipover switch will be on. In the event the heater
is knocked over, the heater will stop functioning automatically.
Make sure the heater is standing upright on the floor away
from curtains, furniture or wall coverings. Ensure the heater is
standing on a flat stable surface.
In order to avoid overheating, do not cover the heater during
operation.
Before plugging in the unit, make sure the thermostat control
is at minimum position and the power control is at 0 position.
GLFH2K17_IB_161128_grace.indd 12 28/11/16 4:28 pm
13
Troubleshooting
Problem Solution
The heater does not work
when turned on.
• Check that the heater is plugged in
and the power is turned on at the
mains socket.
• Check that the heater is in an
upright position.
• If the heater still doesn’t work, do
not try to repair the heater yourself.
Consult a repair specialist.
The heater’s power is
automatically cut off.
• Unplug the heater and allow it to
cool down.
• Inspect the heater. Clean it if
necessary. If there is any sign of
physical damage (e.g. melting, or
burning of the case), do not attempt
to repair yourself. Consult a repair
specialist.
• Plug in the heater and switch on
again. If it cuts off again, move the
heater to a better ventilated location.
GLFH2K17_IB_161128_grace.indd 13 28/11/16 4:28 pm
14
Care and Maintenance
• Always unplug the mains cable from the mains socket and allow the
heater to cool down before cleaning.
• Your heater should be cleaned regularly to prevent dirt and dust from
building up which will affect its performance.
• Wipe the unit with a soft damp (not wet) cloth.
• Never completely cover the unit with water or use chemicals or
detergents as they could damage the unit in some way.
GLFH2K17_IB_161128_grace.indd 14 28/11/16 4:28 pm
15
Technical Specifications
Rated Voltage 220-240V~
Rated Frequency 50 Hz
Input Power 1800-2000 W
Features and specifications are subject to change without prior notice.
GLFH2K17_IB_161128_grace.indd 15 28/11/16 4:28 pm
GLFH2K17_IB_161128_grace.indd 16 28/11/16 4:28 pm
GLFH2K17_IB_161128_grace.indd 17 28/11/16 4:28 pm
IB-GLFH2K17-161128V1
While every effort has been made in the preparation of this instruction
manual, the publishers cannot be held responsible for the accuracy of the
information contained herein or any consequences arising from it.
M.E.W. (Australia) Pty Ltd
15 Vaughan Street
Essendon Fields VIC 3041
ACN 152 719 036
1300 725 885
customercare@gvaproducts.com.au
gvaproducts.com.au
GLFH2K17_IB_161128_grace.indd 18 28/11/16 4:28 pm
Loading...
