82L Upright Freezer
/ DD1-10
DANGER means that failure to read this safety statement may result in severe personal
injury.
WARNING means that failure to read this safety statement may result in extensive product
damage or serious personal injury.
CAUTION means that failure to read this safety statement may result in minor or moderate
personal injury, property or equipment damage.
General Safety Instructions
This symbol alerts you to take care as the appliance contains a
ammable refrigerant. Do not expose it to high heat, sparks and open
ames.
Pay particular attention to safety messages that follow this safety alert
symbol or the words DANGER, WARNING or CAUTION. These words are
used to alert you to a potential hazard that can seriously injure you and
others.
The instructions will tell you how to reduce the chance of injury and let you
know what can happen if the instructions
are not followed.
Read this manual thoroughly before rst use, even if you are familiar with this type of
product. We have provided many important safety statements in this manual concerning the
use of this appliance. Always read and observe all safety statements. They reduce the risk of
re, electric shock and injury when correctly adhered to.
Keep the manual in a safe place for future reference, along with the completed warranty
card, purchase receipt and carton.
If applicable, pass these instructions on to the next owner of the appliance.
We assume no liability for any eventual damages caused by misuse of the appliance or
noncompliance with the instructions in this manual.
CAUTION:
Flammable Gas
General Safety Instructions (Cont.)
Installation
• Heavy: This appliance is heavy, take care when moving it. To avoid back or other injury,
consider a two person lift or mechanical aid when installing it.
• Location: The room for installing appliance must be at least 1M³per 8g of refrigerant. The
amount and type of refrigerant in the appliance can be found on the rating plate inside
the appliance.
• Moisture: Install the freezer in an indoor area protected from wind, rain, water spray or
drips.
• Heat: Do not install it next to an oven, grill or other source of high heat.
• Ventilation: To ensure proper ventilation, the front of the unit must be completely
unobstructed. Keep any ventilation openings clear of obstructions. Choose a well
ventilated area with temperatures above 16˚C and below 32˚C.
• Refrigerant circuit: Do not damage the refrigerant circuit.
• Level: Install the appliance level in order to ensure proper operation.
• Pipes: Make certain that the pipes are not pinched, kinked or damaged during
installations. Check for leaks after connection.
Electrical safety
• Voltage: Make sure your outlet voltage and circuit frequency correspond to the voltage
stated on the appliance rating label. Plug the bar fridge into a 220-240V, 50Hz, 3-prong,
power outlet with a 15A fuse at the mains. The outlet must be properly earthed to the
ground.
• Separate circuit: Do not use an adaptor; do not use an extension cord. We recommend
you connect the bar freezer to a separate circuit serving only this appliance. This provides
the best performance and prevents overloading the house wiring circuits that could
cause a re hazard from overheating. Use a power point that cannot easily be turned o
accidentally.
• Power cord: Do not kink or damage the power cord. Do not leave it exposed or dangling.
Secure it behind the unit so no one steps on or places anything on the cord or against it.
Never unplug the unit by pulling the cord. Always grip the plug rmly and pull straight out
from the power point.
• Damaged cord: Do not use a cord that shows cracks or abrasion damage along its length
or at either end. If the power cord is damaged, it must be replaced by the manufacturer or
its service agent. Contact the after sales support line to have it replaced.
• Electrical work: If the installation of this appliance requires any electrical work, make sure
it is carried out by a qualied electrician.
General Safety Instructions (Cont.)
Usage conditions and restrictions
• Indoor domestic use only: This appliance is intended for indoor household use only. It is
not suitable for commercial, industrial or outdoor use.
• Intended purpose: Do not use this appliance for anything other than its intended
purpose, and only use it as described in this manual. Do not attempt to alter or modify this
appliance in any way.
• Electrical type appliances: Do not use any such appliances inside the food storage compartments of the appliance, unless they are specically recommended in this manual.
• Usage restrictions: The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
• Children: Supervise children to ensure they do not play with the fridge. Never allow children to operate, play with or crawl inside the bar freezer.
Cleaning and maintenance
• Disconnect: Unplug the bar freezer or disconnect power before cleaning or servicing.
Failure to do so can result in electrical shock, injury or death. Do not connect or disconnect
the electric plug when your hands are wet.
• Flames: Do not let open ames or ignition sources enter the appliance.
• Flammable/explosive substances: Never clean this appliance with ammable uids. Do
not store or use volatile, ammable or explosive propellants or liquids close to this or any
other appliance. The fumes can create a re hazard or explosion caused by electric sparks.
• Solvents: Do not use solvent based cleaning agents or abrasives on the interior. These
cleaners may damage or discolour the interior.
• Defrosting aids: Do not use mechanical devices, steam cleaners or other means to
accelerate the defrosting process. Never use a sharp or metal instrument to remove frost
as it may damage the cooling system and will void the warranty. We recommend using a
plastic scraper.
• Service: Do not attempt to repair or replace any part of the bar freezer unless it is
specically recommended in this manual. Refer all other servicing to a qualied
technician, or contact the after sales support line for advice on repair or replacement. It is
hazardous for anyone other than an Authorised Service Person to service this appliance.
In Queensland - the authorized Service Person MUST hold a Gas Work Authorisation for
hydrocarbon refrigerants, to carry out Servicing or repairs which involve the removal of
covers.
Contents
General Safety Instructions
Parts List
1
Getting Started
2
Instructions
4
Rever
sing the Door Swing
5
Care and Maintenance
6
Responsible Disposal
8
Troubleshooting
9
1
Parts List
NOTE: Due to the production’s improvement, the unit you purchased may vary slightly from
below sketch.
2
Getting Started
Before rst use
• Unpack the appliance but keep all packaging materials until you have made sure your new
bar freezer is undamaged and in good working order.
• Plastic wrapping can be a suocation hazard for babies and young children, so ensure all
packaging materials are out of their reach.
• Check to ensure you have all the parts listed on the opposite page, plus aninstruction
manual and a warranty certicate.
• Read this manual to familiarise yourself with all the parts. Pay particular attention to the
safety instructions on the previous pages.
• Unwind the cord to its full length and inspect it for damage. Do not use the appliance if
the appliance or its cord have been damaged. In case of damage, contact our after sales
support line for advice on examination, repair or return of the damaged product.
• Make sure the bar freezer is disconnected from the power supply before cleaning the
interior surfaces with lukewarm water using a soft cloth to remove any dust from transit
and storage. Dry the appliance thoroughly.
•
Your bar freezer
has the capability of the door opening from the right or left side. If
your setup requires reversal of the door swing, follow the instructions on page 5
.
•
Your new bar freezer is now ready for use – see page 4 for instructions.
Installing the bar freezer
• Before installing your new upright bar freezer, read all safety instructions in this manual,
especially the sections on electrical safety and installation
. Then follow the
instructions below.
• This appliance is designed to be freestanding only and should not be recessed or built in.
• Place the bar freezer on a sturdy, level oor that is strong enough to support the unit when
it is fully loaded.
• DO NOT install the appliance directly on carpeting or soft material. Carpeting must be
removed or protected by a metal or wood panel beneath the appliance, which extends at
least the full width and depth of the appliance. NOTE: Ensure that the appliance does not
stand on the electrical supply cable. Parts which heat up should not be exposed. Whenever
possible, the back of the appliance should be close to a wall but leaving the required
distance for ventilation.
Overloading the freezer will aect cold air circulation and cooling performance. We
therefore recommend you only load the freezer up to about 70% of its storage volume,
always leave some space around food stored, and do not use containers that are too
large and block ventilation openings.
3
• Locate the bar freezer:
• Away from direct sunlight, which may aect the acrylic coating.
• Away from sources of heat (stove, heater, radiator, dishwasher, etc.),which may increase
power consumption.
• In an area without extreme cold ambient temperatures, which may aect cooling
performance.
• In a cool, well ventilated area, without excessive moisture and high humidity.
• Installing the unit in the coolest area of the room will save energy consumption and
running costs.
• To ensure correct operation, this appliance must not be located where the temperature
will be below 10°C or above 43°C.
• Ensure there are no obstructions that could prevent the freezer door from closing.
• To level the bar freezer, adjust the levelling legs at the bottom of the unit.
• The refrigerator must have at least 50mm clearance between the rear of the appliance and
the wall, 100mm between the sides and wall, and the space above the top should be at
least 100mm. Ensure that there is enough spacing to open the door to 160°.
• Before plugging in your new bar freezer, let it stand upright for approximately 2
hours. This will allow the refrigerant gases to settle into the compressor and reduce the
possibility of a malfunction in the cooling system from handling during transportation.
• The Bar Freezer is suitable for connection to 220-240VAC 50Hz supply. The Bar Freezer must
be plugged into a dedicated individual 220-240VAC main socket outlet.
• Plug the unit into an exclusive, properly installed and earthed wall outlet. Do not under
any circumstances cut or remove the third (ground) prong from the power cord. If in doubt
about your setup, direct any questions concerning power and/or grounding to a certied
electrician.
• Do not use an extension cord or an adapter plug.
• Secure the bar freezer’s supply cord behind the unit. Do not leave it exposed or dangling to
prevent injury and accidental disconnection from the power supply.
NOTE: After plugging the appliance into a wall outlet, allow the unit to cool down for two
to 3 hours before placing food in the refrigerator compartment.
Getting Started (Cont.)
4
Normal Operating Sounds
The following noises are characteristic of refrigeration appliances:
Clicks: Whenever the compressor is switched on or o, a click sound may be heard.
Humming: As soon as the compressor is in operation, you may hear it humming.
Bubbling/Splashing: When refrigerant ows into thin tubes, you may hear bubbling or
splashing noises. Even after the compressor has been switched o, this noise may still occur
for a short time.
Instructions
5
Reversing the Door Swing
This bar freezer can be opened from either the left side (as supplied) or right side to suit your
individual installation requirements. If you want to open the door from the right side, follow
the instructions below and opposite to reverse the door swing (the numbers in brackets
refer to the parts in the illustrations).
WARNING!
Ensure the bar freezer is disconnected from the power supply when reversing
door swing.
NOTE: Keep all parts you remove for re-installation of the door on the other side.
1. Remove the upper hinge cover (6)
2. Remove the two screws (1) that hold the upper hinge (5) (right side) from the frame.
Take o the upper hinge (5).
3. Lift the door and place it on a padded surface to prevent scratching.
4. Remove the two screws (8) that hold the lower hinge (2). Remove the lower hinge (2).
If there is originally a washer on the hinge pin, it must remain there while reversing the
door.
5. If necessary, remove the front levelling legs (4) when reversing the lower hinge and
remember to install them after reversing.
6. Remove the plug buttons (7) from the holes and place to the right side.
7. Set the door in place, make sure it sits on the door seat at the lower hinge (2).
8. While holding the door in the closed position secure the upper hinge (5) on the top
left hand side with the two screws (1). Do not tighten the two screws (1) until the door
is well aligned with the cabinet. Adjust the lower hinge (2) as well if necessary when
aligning the door.
9. Install the upper hinge cover (7) back onto the upper hinge.
6
Care and Maintenance
Defrosting the bar freezer
When? For the most ecient operation and minimum energy consumption, defrost the bar
freezer when the frost accumulated on the evaporator is about 5mm thick.
How? Turn the thermostat dial to the min position and unplug the bar freezer. Remove
perishable food items from the freezer and keep them in another freezer or cooler bag to
protect the food.
Defrosting usually takes a few hours. After defrosting, dry the food compartments and
return the thermostat dial to the desired position.
To defrost quickly, remove all foods from the freezer and leave the door open.
CAUTION:
Do not use boiling water because it may damage the plastic parts. Never use
a sharp or metallic instrument to remove frost as it may damage the cooling
system. Use a plastic scraper, if required.
Cleaning the bar freezer
• CAUTION: Before cleaning the freezer, make sure to turn the temperature control to the
[0] position, unplug the bar freezer and remove the food and shelves.
• Wash the inside surfaces with a warm water and baking soda solution. The solution
should be about 2 tablespoons of baking soda to 1.2L of water. Wring excess water out
of the sponge or cloth before cleaning around the temperature control or any electrical
parts.
• Clean the shelves and inside freezer, as well as the outside of the freezer, with a mild
detergent solution and warm water. Rinse and dry thoroughly.
• Never use acids, chemical thinners, petrol, benzene or the like for cleaning any part of
the bar freezer.
• It is advisable to periodically clean the refrigeration system at the back of the appliance
with a duster or vacuum cleaner.
Power failure
Most power failures are corrected within a few hours and should not affect the temperature
of your freezer if you minimise the number of times the door is opened. If the power is going
to be off for a longer period of time, take appropriate steps to protect your food.
7
Care and Maintenance (Cont.)
Energy saving tips
• Place the freezer in the coolest area of the room, away from heat-producing appliances
and out of direct sunlight.
• Let hot foods cool down a little before placing them into the freezer. Overloading the
freezer forces the compressor to run longer.
• Wrap foods properly and wipe containers dry before placing them in the freezer. This
cuts down on frost build-up inside the freezer.
• Do not line any freezer storage bin with aluminum foil, wax paper or paper towels.
Liners interfere with cold air circulation, reducing cooling eciency.
• Do not leave the freezer door open for longer than required.
When away on holidays
• Short holidays: leave the freezer operating during vacations of less than three weeks.
• Long holidays: if the appliance will not be used for several months, remove all food,
unplug the unit and thoroughly clean and dry the interior. To prevent odour and mould
growth, block the door open slightly.
Moving the bar freezer
• Remove all food from inside the freezer, tape the door shut and securely tape down all
loose items inside. Turn the levelling feet up to the base.
• We recommend moving the freezer in its original packaging. Otherwise, make sure to
protect the outside of the freezer with a blanket or similar item during transportation.
• Do not apply force on any external part such as pipes, condenser or door when moving.
• Ensure the freezer stays secure in an upright position; do not tilt it for more than 45°
from upright.
Switching o the appliance
To switch o the appliance, turn the temperature regulator to position “min”. If the appliance is
not going to be used for an extended period:
• Remove all refrigerated items.
• Switch off the appliance by turning the temperature regulator to position “min”
• Remove the mains plug or switch o or disconnect the electricity supply.
• Clean thoroughly.
• Leave the door open to avoid the build up of odours.
• Once the unit has been turned o, allow the unit to settle down for about 10 minutes
before turning the unit on. This will prevent the compressor from being damaged.
8
Responsible disposal
• At the end of its working life, do not throw this appliance out with your household
rubbish. Electrical and electronic products contain substances that can have a detrimental
eect on the environment and human health if disposed of inappropriately. Observe any
local regulations regarding the disposal of electrical consumer goods and dispose of it
appropriately for recycling and recovery of the refrigerant.
This appliance contains the ammable refrigerant isobutane (R600a) and cyclopentane
(R141b) in the cabinet insulation, and must be disposed of in a separate waste collection.
Contact your local authorities for advice on recycling facilities in your area.
• Before discarding your bar freezer, ensure the refrigerant circuit is not damaged so that the
refrigerant gas cannot escape into the environment. Then disconnect the appliance from
the power supply and cut o and render any plug useless.
DANGER! Risk of child entrapment: When discarding a fridge or freezer, make sure to take
o the door and the spring action or bolt catch. Leave the shelves in place so that children
cannot easily climb in and get trapped inside and suocate.
Responsible Disposal
9
Troubleshooting
Problem Possible cause
The freezer does not operate. • It is not plugged in. Ensure it is properly plugged in and
there is power at the socket (plug another appliance into
the outlet to check).
• The circuit breaker tripped or has blown a fuse.
• The freezer temperature control is set to OFF.
• A general power outage has cut power to your home
(check the household lights).
The freezer temperature is not
cool enough.
• The room temperature is hotter than normal.
• A large amount of food has been added at once.
• The door is opened too often.
• The door is not closed completely.
• The temperature control is not set correctly.
• The door gasket does not seal properly.
There are vibrations.
• The freezer is not level.
The freezer seems to make too
much noise.
• A rattling noise may come from the ow of the
refrigerant, which is normal. A popping and crackling
noise may be caused by the contraction and expansion
of the inside walls.
• The freezer is not level, or is touching other furniture.
• Bottles or packages inside the freezer are touching each
other.
The door will not close
properly.
• The freezer is not level.
• The door was reversed and is not properly installed.
• The gasket is dirty or bent.
• The shelves, racks or crisper are out of position.
The freezer door will not open.
• If the door has just been opened, leave it for a few
minutes to allow the air pressure to equalise before
trying again.
Moisture forms on the inside
or outside walls of the bar
freezer.
• Hot and humid weather increases the internal rate of
frost build-up. This is normal.
• Open the door less often and make sure it is always
properly closed.
If you experience a problem with your bar freezer, check in the following table for solutions
to help you solve the problem. If after these checks you still have a problem with your bar
freezer, call the after sales support line for advice.
10
Troubleshooting (Cont.)
The external freezer surface is
warm.
• The exterior walls can be warmer than room
temperature. This is normal while the compressor works
to transfer heat from inside the freezer cabinet.
Excessive frost and ice has
built up.
• The freezer door has been left open.
• Something is preventing the door from closing.
• The door gasket is dirty or damaged.
• Make sure to defrost the fridge regularly.
The compressor runs
continuously.
• The temperature is set too cold: select a lower (warmer)
setting.
• The door is open, or something is obstructing proper
door closure.
• The door gaskets are worn, dirty or damaged.
• Large quantities of food have been added to the freezer.
• The room temperature is hotter than usual.
M.E.W (Australia) Pty Ltd
15 Vaughan St
Essendon Fields VIC 3041
ACN 152 719 036
www.gvaproducts.com.au
While every effort has been made in the preparation of this instruction manual, the publishers cannot be held
responsible for the accuracy of the information contained herein or any consequences arising from it.
Loading...
