GVA CO12B Instruction Manual

Instruction Manual
GVACO12B
12L CONVECTION OVEN
1
Guide to the Appliance 2
Caring for the Environment 3
Safety Information and Warnings 4
Getting Started 6
Operating Instructions 7
Advanced Features 11
Care and Maintenance 13
Technical Specications 14
2
Guide to the Appliance
1. Control panel
2. Top/lid
3. Air ow
4. Handle (attached to the base)
5. Glass bowl
6. Base
7. Display window
8. Timer
9. Temperature
10. Down
11. Up
12. Appoint
13. Clear / Pause
14. Conrm
15. Wire racks
16. Tong
13
11
9
8
10
12
14
7
1
2
4
5
3
6
15
16
3
Caring for the Environment
Responsible disposal of the packaging
The packaging of your appliance has been selected from environmentally friendly materials and can usually be recycled. Please ensure these are disposed of correctly. Plastic wrapping can be a suffocation hazard for babies and young children, please ensure all packaging materials are out of reach and are safely disposed of. Please ensure they are offered for recycling rather than throwing these materials away.
Responsible disposal of the appliance
At the end of its working life, do not throw this appliance out with your household rubbish An environmentally friendly method of disposal will ensure that valuable raw materials can be recovered and used again. Electrical and electronic appliances contain materials and substances which, if handled or disposed of incorrectly, could be potentially hazardous on the environment and human health.
4
Read this manual thoroughly before rst use, even if you are familiar with this type of product. The safety precautions enclosed herein reduce the risk of re, electric shock and injury when correctly adhered to. Keep the manual in a safe place for future reference, along with the warranty card, purchase receipt and carton. If applicable, pass these instructions on to the next owner of the appliance.
Always follow basic safety precautions and accident prevention measures when using an electrical appliance, including the following:
Electrical safety and cord handling
• Make sure that your outlet voltage and circuit frequency correspond to the voltage stated on the appliance rating plate.
• The power socket must be readily accessible so that you can easily switch off the power supply and unplug the oven.
• Do not let the cord hang over the edge of a table or benchtop, or touch hot or sharp surfaces. Do not wrap it around the appliance.
• Run the power cord so that there will be no risk of anyone pulling it inadvertently or tripping over it.
• WARNING: To avoid electrical hazards, do not expose the cord, plug or top/lid to water.
Do not immerse the top/lid in water or spill liquids into it.
• Do not operate this appliance if it has a damaged cord or plug, if it is not working properly or if it has been damaged or dropped.
• If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualied person in order to avoid a hazard.
• Do not leave the oven unattended while it is plugged into the power supply.
• Always switch off, unplug and let the oven cool down after use and before moving the oven, assembling or disassembling parts and cleaning it. (Allow up to half an hour for the oven to cool down before cleaning or storage.)
• When unplugging the appliance, grip the plug, do not pull on the cord.
Usage conditions and restrictions
• This appliance is intended for domestic use only, it is not designed for industrial or commercial use. Do not use it for anything other than its intended purpose and only use it as described in this manual.
Safety Information and Warnings
5
Safety Information and Warnings
• The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Young children should be supervised to ensure they do not play with the oven. Close supervision is necessary when the oven is used by or near children.
• The appliance is not intended to be operated by means of an external timer or separate remote control system.
• The use of accessories or attachments not recommended by the product distributor may result in re, electric shock and/or cause personal injury.
• Improper installation or use may result in the risk of re, electric shock or injury. We accept no liability for any damage due to improper use or incorrect handling.
• Before switching the appliance on, make sure it is placed:
• In the centre of a at and secure benchtop or table, close to a power point.
• Away from any open ame, hot surface or radiant cooking element.
• Lower the top/lid gently, do not let it drop down.
• Always take the top/lid off before removing the bowl from the base.
• Always use two hands when moving the oven.
• Always carry the oven by the handles on the base; the handle on the top/lid only moves the lid.
• Do not leave water or food in the oven overnight.
• Store the appliance in a dry place, out of reach of young children.
• If the appliance stops working unexpectedly, switch off the power supply, unplug it from the wall socket and contact the after sales support line for advice on repair or return.
• WARNING: The appliance has no user-serviceable parts contained inside.
Do not attempt to repair the oven or adjust it yourself. Any repair or service must only be carried out by qualied service personnel. Call the after sale support line for advice.
CAUTION: HOT!
• Oven surfaces will become hot during use — handle with care.
• Always supervise children when the oven is in use.
• Do not touch any part of the oven, other than the handles, until the oven has cooled down sufciently and it is safe to touch.
6
Getting Started
Before rst use
• Unpack the appliance but keep all packaging materials until you have made sure your new convection oven is undamaged and in good working order. Plastic wrapping can be a suffocation hazard for babies and young children, so ensure all packaging materials are out of their reach.
• Inspect the cord and plug for damage. Do not use the appliance if the appliance or its cord have been damaged or are not working properly.
• Read this manual to familiarise yourself with all the parts and operating principles of the convection oven. Pay particular attention to the safety instructions on the previous pages.
• Make sure the appliance is disconnected from the power supply.
• Wipe the inside of the bowl with a clean, damp sponge to remove any dust or other remnants from the manufacturing process. Dry thoroughly.
• Place the oven racks inside the bowl – do not leave the tongs in the bowl.
• Lift the top/lid by the handle and carefully lower it onto the bowl.
• Heat your new convection oven once before cooking with it. During the process, the oven may give off a slight burning smell or smoke. The oven is actually burning off excess lubricants found in the oven’s heating elements. Any odour or smoke will not harm you, your food or the oven. Ensure good ventilation.
• Plug the oven into an appropriate power point and switch on power at the outlet.
• Set the timer to approximately 10 minutes, timer will indicate on the display.
• Set the temperature control to 200°C.
• After the set 10 minutes, when the timer has shut off the oven, allow it to cool for about 10 minutes before opening the top/lid.
• Your convection oven is now ready for cooking food.
7
Operating Instructions
Starting operation
1. Plug oven into power outlet. It may make a short “beep” sound and the digital light will show “01:00”. The temperature will be at 60°C.
2. Choose the desired cooking time by pressing “UP” or “DOWN”. To increase the time rapidly, simply hold the button down. Then press “CONFIRM”.
Getting started
1. Put the steel racks into the glass bowl, and then put the food in. Note always leave some space between the food and the oven lid.
2. Insert the oven plug according to the power specication. It is not allowed to share the same plug-set with other electrical appliances.
3. Set the timer to your required time by using the “UP” and “DOWN” button.
4. Set the temperature to your required temperature by using the “UP” and “DOWN” button. Then press “CONFIRM” button to set.
Important
1. When the convection oven is in operation, the handles will expand due to the heat and may become loose. This is normal and they will restore once the convection oven has cooled down after use.
2. Don’t put the oven bowl directly on the bench after cooking, otherwise the bench will get burned. Place it on a heat-resistant base.
3. The oven lid is not allowed to be washed in the water. Clean the lid with a clean soft cloth to prevent staining.
4. The oven bowl can be washed only after it has completely cooled off.
8
Operating Instructions
Suggested cooking times and temperatures
All cooking times, methods and temperatures included in this manual are suggestions only. Try these suggestions and amend them according to your taste and preferred cooking style.
Temperature guide
100°C Defrost frozen food
Quick wash after use (see page 13 for details) 150°C Reheat 170°C Steam 170°C Bake 200°C Toast 200°C Roast 220°C Grill 220°C Preheat 250°C Dry fry
Cooking times
Food Time Temperature Chicken 30-40 minutes 170-200°C Fish 10-15 minutes 120-150°C Pork 15-20 minutes 170-200°C Cake 10-12 minutes 150-170°C Lobster 12-15 minutes 150-170°C Prawns 10-12 minutes 150-170°C Sausages 10-13 minutes 120-150°C Potatoes 12-15 minutes 170-200°C
9
How to use the Appoint function
Set the cooking time and temperature.
Then push the “Appoint” button, the default time setting is 6 hours. You can choose the time for when you want to start the cooking process. For example, if you want to start cooking after 2 hours, press the “Down” button until the hour displays 2 hours.
Press the “Conrm” button to conrm time setting. Then the convection oven will only start to work after the time you set.
How to broil/roast
Place food directly on the wire rack (low or high rack)
For very thick cuts of meat, turn the food at the halfway point.
Roasting and broiling time may vary depending on cut, size, amount and type of food, etc.
How to steam
You can steam vegetables at the same time you cook your main dish by placing the vegetables in an aluminum foil pouch: add a few drops of water and seal the pouch.
You can also add a cup of water in the bottom pot, with savory herbs and spices to steam sh or vegetables, but just a little water.
How to fry
You can get the effect of deep fried french fries without all the oil by dipping potato strips in polyunsaturated cooking oil, allow excess oil to drain away and cook according to cooking guide.
To make delicious fried chicken, dip chicken pieces in butter and then in cooking oil, drain excess oil and cook according to chart provided on page 8.
How to grill
Place food directly on the wire rack.
Grilling time may vary depending on cut, size, amount and type of food, etc.
Operating Instructions
10
How to toast
You can get perfectly toasted bread and snacks with the convection oven without preheating. Simply put the food directly on wire rack and watch it toast. It will be crisp on the outside and stay soft on the inside.
You can also improve stale snack food like crackers, chips and even cookies by placing them in the convection oven for a few minutes at maximum temperature to bring back their crunchiness.
How to bake a cake
Place your cake tin on the low wire rack inside the glass bowl. For very moist cakes with almost no crust, cover the tin with foil and remove the foil shortly before the end of the baking time so the top can dry out slightly. Cakes will bake a little faster in this convection oven than they will in a conventional oven.
CAUTION: Avoid stacking too much food in the oven. Hot air must be able to circulate freely
so that food on all levels is cooked evenly.
How to defrost
You can use the convection oven to defrost frozen food more evenly than a microwave oven, simply set the temperature at 100°C and check the food every 5-10 minutes.
Remember to distribute food evenly in the convection oven to ensure an even ow of air all around the food.
The rst time you try a recipe, check the cooking process through tempered glass bowl as the cooking time of the convection oven is short.
Since it is practical to place food directly on the wire rack, you may want to spray it with a non-stick spray to avoid sticking.
Operating Instructions
11
Benets of cooking in the convection oven
• Low-fat/fat-free cooking
No need to add any fat (oil, butter or margarine) for cooking, or only very little. Hot air circulating around the food cooks it to perfection and fat can easily drip out of the food suspended on a wire rack.
• Crisp, brown and juicy meat
Meat and poultry sear quickly, leaving it brown and crisp on all sides with juices sealed inside.
• Low-fat chips
Sliced potatoes can be “air-fried” crisp and golden brown in a very small amount of oil. (Cooking total oil-free chips is possible too, but a little olive oil will give them a beautiful nish and delicate avour.)
• Ideal pastries
Pastries, scones and cake rise higher and turn out ufer, yet remain moister than if cooked in a conventional oven.
• Quick and easy
Just put in your food and set the timer and temperature control and the circulating hot air will cook your food evenly and quickly.
• Time and energy efcient
Your convection oven can save you time and energy, cooking an entire meal at once on multilevel racks.
• No installation
No installation required and easily portable, so you can take it with you when you move.
• Easy to clean
Soot or fatty residues cannot drip onto the heating element during cooking. A built-in pre-wash cycle makes cleaning the oven very easy. Simply let the convection oven wash itself and then rinse and dry.
• Multipurpose
Your new convection oven can replace numerous appliances (a standard oven, deep­fryer, microwave oven, toaster oven, rotisserie, electric fry pan, electric steamer) and can cook your food many different ways (roast, bake, reheat, fry, steam).
Advanced Features
12
With your new convection oven you can prepare delicious, healthy meals much faster than cooking the traditional way. What makes these superior results possible is our revolutionary approach to certain time-honoured cooking methods. It has long been known that the performance of a traditional oven can greatly be improved if a fan is installed to accelerate the hot air circulation inside the oven.
Convection ovens usually have a round fan mounted on one side of a square metal box.
This convection oven improves upon traditional convection ovens in the following ways: The convection oven combines a round bowl with a large fan mounted in the top/ lid so that hot air currents move down over the food, around the bowl’s sides, and then back up to the fan. This creates a tornado-like ow of constantly moving, super-heated air that cooks and browns food quickly and thoroughly.
The convection oven bowl is made of glass, so you can clearly see what you are cooking.
The convection oven uses cooking racks that allow you to cook two levels of food at once. In addition, when meat, poultry or sh are cooked, fats and oils are blown away and drip through the racks into the bottom of the bowl. You will cook lighter (lower in fat), more nutritious meals with enhanced natural avours.
Advanced Features
13
Care and Maintenance
Self-cleaning
A built-in prewash cycle makes cleaning the oven very easy, just follow the simple steps below:
• Add about 2L of water and a little dishwashing detergent into the glass bowl.
• Close the top/lid.
• Press the ‘Timer’ Button and set timer to 15 mins. Press the ‘Temp’ Button, and set temperature to 100C.
• Press the ‘Conrm’ Button and the convection Oven will start self-cleaning.
• The Convection oven will make beeping sound and stop automatically when it nishes cleaning. You can press and hold the ‘Clear/Pause’ button to reset the convection oven.
• Unplug the power cord from the wall socket and empty water from the glass bowl.
• Wipe the glass bowl with a dry cloth.
• The hot air circulation creates an automatic turbo wash action that removes baked on residue. The wire rack(s) and any other dirty elements may be left in the oven for prewashing.
Manual cleaning
• Unplug the oven and let it cool down completely.
• When it is safe to touch, wipe any excess fat out of the bowl with a paper towel.
• Use a clean sponge or dishcloth with a little mild dishwashing detergent and warm water to wipe the bowl clean. Rinse well to remove all detergent. Wipe dry.
• Wipe the top/lid and fan housing using a damp, clean dishcloth or sponge with a little mild dishwashing detergent.
• Do not clean with steel wool pads or abrasive materials.
• Wash the wire racks in water and mild dishwashing detergent.
• Clean the metal parts using a sponge or dishcloth with mild dishwashing detergent, then wipe clean. If scrubbing is necessary, use a nylon or polyester mesh pad or a pod brush. For very “burnt on” stains, use stainless steel or other metal scourers. A thick “tub” style paste cleaner is recommended with a damp sponge for stubborn stains.
WARNING:
• Never immerse the top/lid in water or any other liquid.
• Never let the fan assembly get wet.
• Never leave the top/lid on the oven after it switches off, either with food or with water in it. Doing so will eventually cause rusting of the metal parts in the lid, which is NOT covered by warranty. You are expected to keep the oven clean and dry after cooking and/or washing.
14
Technical Specications
Specications:
Model: GVACO12B Functions: Roasts, bakes, grills, dry fries and steams. Features: Variable temperature control, touch control panel, LED display, self-clean function. Rated parameter: AC220-240V 50Hz 1200-1400W Made in China
M.E.W. (Australia) Pty Ltd 15 Vaughan St Essendon Fields VIC 3041 ACN 152 719 036
1300 725 885 customercare@gvaproducts.com.au gvaproducts.com.au
While every effort has been made in the preparation of this instruction manual, the publishers cannot be held
responsible for the accuracy of the information contained herein or any consequences arising from it.
