Guoguang Electric VIFANORDIC1 Users manual

OSLO
Owner’s Manual
IMPORTANT SAFETY INSTRUCTIONS
Regulatory Safety Information
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
7 Do not block any ventilation openings.
Install in accordance with the manufac­turer’s instructions.
8 Do not install near any heat sources
such as radiators, heat registers, stoves, or other apparatus (including ampliers) that produce heat.
9 Do not defeat the safety purpose of
the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third ground­ing prong. The wide blade or the third prong are provided for your safety. If the provided plug does not t into your outlet consult an electrician for replace­ment of the obsolete outlet.
10 Make sure the power cord is not stepped
on or otherwise interferred with, particu­larly at the mains socket and where it exits the apparatus.
11 Only use attachments/accessories
specied by the manufacturer.
12 Use only with the cart, stand,
tripod, bracket or table speci-
ed by the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/ap­paratus combination to avoid injury from tip-over.
13 Unplug this apparatus during lightning
storms or when unused for long periods of time.
14 Refer all servicing to qualied service
personnel. Servicing is required when the apparatus has been damaged in any way, such as damage to the power cord or plug, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally or has been dropped.
15 To completely disconnect unit power
from the AC mains, disconnect the unit’s power cord from the mains socket.
WARNING:
• To reduce the risk of re and electric shock do not expose this apparatus to rain or moisture.
• Do not place objects lled with liquids such as vases on the apparatus.
Do not open the appartus. There are no user-serviceable parts inside. Risk of electric shock inside.
The lightning ash and arrow head within the triangle is a warning sign alerting you of dangerous voltage inside the product.
The exclamation point within the triangle is a warning sign alert­ing you to important instructions
accompanying the product.
IMPORTANT STATEMENTS
This device complies with Part 15 of the FCC Rules. Its operation is subject to the following two conditions:
1. This device may not cause harmful interfer­ence, and
2. This device must accept any interference received, including interference that may cause undesired operation.
Cet appareil est conforme à la section 15 des ré­glementations de la FCC. Le fonctionnement de l’appareil est sujetaux deux conditions suivantes:
1. Cet appareil ne doit pas provoquer d’interférences néfastes, et 2. Cet appar­eil doit tolérer les interférences reçues, y compris celles qui risquent de provoquer un fonctionnement indésirable.
Note: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason­able protection against harmful interference in a residential installation. This product gen­erates, uses, and can radiate radio frequency energy and, if not installed and used in accord­ance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interfer­ence will not occur in a particular installation. If this product does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
· Consult the dealer or an experienced radio/ TV technician for help.
Changes or modications not expressly ap­proved by the party responsible for compliance could void the user’s authority to operate the equipment.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two con­ditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that may cause un­desired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radioexempts de licence. L’exploitation est au­torisée aux deux conditions suivantes :
1. l’appareil ne doit pas produire de brouil­lage, et
2. l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en comprom­ettre le fonctionnement.
Vifa Denmark A/S
Mariendalsvej 2A
DK-8800 - Denmark
www.vifa.dk
Product Care .................................................................................. 6
Oslo Functions
Buttons and indicators on Oslo ...................................................... 8
Mode button & Status indicator ..................................................... 9
Battery charge ..............................................................................10
Connecting to Oslo
Connecting with Bluetooth ...........................................................12
Connecting with Bluetooth - NFC ................................................13
Wired connection ........................................................................14
Troubleshooting
Factory Default .............................................................................16
Oslo Reset ....................................................................................17
Specications ...............................................................................19
Support ....................................................................................... 20
Trademarks .................................................................................. 21
For manuals in other languages please visit www.vifa.dk/support
You’ve chosen well
Vifa Oslo. A loudspeaker for anyone who values exclusive
Designed to be intuitive for you to use, this manual just
Nordic design and authentic sound.
spells out the details - for instance, how to connect
wirelessly in a ash.
Enjoy!
PRODUCT CARE
Oslo is built for a long-lasting relationship. In order to ensure the quality music performance please ensure no exposure to rain, moisture, high humidity or sources of heat that may damage the product. The intended use is within a temperature range of 5 - 40 °C (40 - 105 °F).
Cleaning
Your Vifa product is covered by beautiful highly durable textile from Kvadrat. Remove non-greasy stains by carefully dabbing with a lint-free cloth or use a lint roller to remove lint from the textile.
Never use a vacuum cleaner, this can cause damage to the loudspeaker units behind the textile.
6
OSLO
FUNCTIONS
BUTTONS AND INDICATORS ON OSLO
TM
NFC area
Status indicator
Volume up
Volume down
Power socket, battery charge
USB service
Aux analog input
Battery indicator, Reset
MODE button
8
MODE BUTTON & STATUS INDICATOR
Turn Oslo ON
Press and hold the MODE button until the status indicator turns solid YELLOW.
Turn Oslo OFF
Press and hold the MODE button until the status indicator ashes YELLOW. Then release.
Oslo SLEEP mode
If no signal input or no button is being pressed for 3 minutes, Oslo goes into SLEEP mode, meaning the status indicator will pulsate.
Status Indicator
BLUE - Bluetooth connection
GREEN - AUX connection
RED - Fault indications
YELLOW - No connections active
9
BATTERY CHARGE
A full charge will take 3-4 hours. Please charge Oslo for more than 4 hours the rst time you charge it. Keep Oslo plugged in when near power outlet. The intelligent power management will keep battery in perfect condition.
When charging you can see the progress,
Low Battery level below 5% RED
Medium Battery level between 5 and 80% YELLOW
Full Battery level above 80% GREEN
10
CONNECTING TO
OSLO
CONNECTING WITH BLUETOOTH
1
Bluetooth
VIFA_BTxxxx
Bluetooth
14:52
Paired
3
1. To turn Oslo on, press and hold the MODE button until status indicator turns on.
2. Press and hold the MODE button until status indicator ashes BLUE.
3. Enable Bluetooth pairing on your device and select Vifa BTxxxxxx as your Bluetooth device.
4. The status indicator turns solid BLUE when a connection is established. Let the music play.
2
4
12
CONNECTING WITH BLUETOOTH - NFC
TM
Only for NFC enabled devices
1
2
NFC AREA
NFC
3 4
NFC
1. To turn Oslo on, press and hold the MODE button until status indicator turns on.
2. The NFC area of Oslo is placed by the volume buttons.
3. Activate NFC function on your device. Place NFC enabled device on NFC area and accept pairing on your device.
4. The status indicator turns solid BLUE when a connection is established. Let the music play.
13
WIRED CONNECTION
1
2
3
1. To turn Oslo ON press and hold the MODE button until status indicator turns on.
2. Connect the wire on the back side and start music playback from your device.
3. The status indicator turns solid GREEN when wired playback is enabled.
Oslo prefers Bluetooth over AUX. But briey pressing the MODE button the connection will switch from Bluetooth to AUX. Pressing it again turns it back to normal priority.
14
TROUBLESHOOTING
FACTORY DEFAULT
Factory default
Resets Oslo’s software to factory settings
To factory default Oslo, press and hold the MODE button and the volume up and volume down buttons simultaneously until the status indicator turns red.
Release the buttons and Oslo will go to factory default. Please note that after factory default ALL USER SETTINGS WILL BE LOST.
To update Oslo’s rmware, please go to www.vifa.dk/support for
further information.
16
OSLO RESET
Reset
Reset
May be used if Oslo freezes.
To reset Oslo, briey press the reset button - no user settings will be lost.
If you experience issues that are not described in this manual, please refer to www.vifa.dk/support
17
SPECIFICATIONS
Description Portable wireless loudspeaker
Technical features Bluetooth 4.0 aptX AUX 3.5 mm mini- ‐jack NFC Lithium Ion battery Force Balanced Woofers DSP crossover, optimized for low distortion and high precision 4 channel digital PurePath amplier
Drive Units
Full-range 2 X 50 mm Vifa driver unit with aluminum cone and neodymium magnet
Woofer 2 x 65 mm Vifa drive units with at sandwich cone and neodymium magnet. Mounted mechanically back to back in a force balanced conguration supported by 2 passive radiators.
Frequency response 55 Hz – 18 kHz @ +/- ‐ 3 dB
Input voltage, wall adaptor 100 Volt - 240 Volt 50/60 Hz 1500mA Max
Input voltage, loudspeaker 18VDC,2500mA Standby power consumption Less than 0.5 watt when battery is fully charged.
Inputs Bluetooth aptX AUX 3.5 mm mini- ‐jack.
Dimensions Height/Width/Depth 268 mm / 181 mm / 90 mm Net weight 2,4 kg Frame One piece diecast aluminium Enclosure Reinforced ABS Grilles Custom made Kvadrat textile
19
SUPPORT
Vifa App
An app will be available for your Vifa Oslo. More info will be announced on www.vifa.dk/support
Register your Oslo
We encourage you to register your product at www.vifa.dk/support
20
TRADEMARKS
A Vifa product is in compliance with directives of relevance, including RoHS directive – Vifa declaration of conformity can be found and downloaded from: www.vifa.dk/support - see product label for more regional regulatory approvals.
The NFC Forum has developed the “N-mark” trademark as a universal
symbol for Near eld communication.
The Bluetooth logo, the Bluetooth name and the combination are
trademarks owned by Bluetooth SIG Inc.
© 2013 CSR pic and its group companies. The aptX® mark and the aptX logo are trade marks of CSR pic or one of its group companies and may be registered in one or more jurisdictions.
21
2015 11 REV.1
For more information please visit our website at
www.vifa.dk
