GUCCI Collection bambou, Bambou édition L.O.V.E, Collection g chrono, Collection g-frame, Collection g-timeless User Manual
...
INSTRUCTIONS FOR USE
I-GUCCI WATCHES
Instructions for use
General information
Main functions:
Double time zone, see "List of cities" table
- world time with selected city indicator
- local time
Display options:
- digital, by numerals with date
- digital, by hands on ref. 114-2 only
- digital, by numerals with seconds
DST (Daylight Saving Time)
Date and day of week programmed until 31 December 2049, also takes into
account the different month lengths and leap years.
12 or 24 hour display format
Alarm for local time
Backlighting
2
World time display area:
Hour, minutes, city code
Push-button
Set the various time
Push-button
Set alarm
Validate settings made
Local time display area:
Hour, minutes, day of week, date or seconds
A: Select display options
and date functions
B: Backlighting
3
Daylight saving time (DST)
When daylight saving time is activated (DST ON), winter time automatically
advances one hour to summer time. You need to bear in mind that summer
time is not used in certain states or regions.
Backlighting
A short press on push-button B will turn the backlight on for 3 seconds.
If setting start with backlighting on, the backlight will keep on during the
whole setting process.
4
1. a) Time display options (ref. 114-2)
Press push-button A to change the display option.
Regardless of the display option selected, press push-button B to activate
backlighting.
5
b) Time display options (ref. 114-4)
Press push-button A to change the display option.
AABBA
B
Regardless of the display option selected, press push-button B to activate
backlighting.
6
Description of display options in "Time display" mode
1.1 Double time zone display, with date indicator
1 World time: hour
2 World time: minutes
3 Date
4 Day of week
5 Local time: minutes
6 Local time: hour
7 DST indicator for local time
8 Local time alarm activated
indicator
9 12/24 hour indicator
for local time
10 Indicator for local time
11 City code for world time
12 DST indicator for world time
13 12/24 hour indicator
for world time
7
1.2 Local time display by hands (ref. 114-2 only)
1 Hour hand
2
1
1.3
Double time zone display, with second indicator
2
2 Minutes hand
Local time: seconds
8
2. Time and date setting
- The setting sequences for time and date setting and for alarm setting can
be accessed regardless of the display option selected.
- If no push-button is pressed for over thirty seconds, the original display
option will be restored automatically.
- If setting start with backlighting on, the backlight will keep on during the
whole setting process.
9
2.1 World time
A > 2sec.
Press push-button A,
and hold for at least
two seconds.
The city code for world
time will flash.
(*) If you do not need to modify local time, it is possible to exit the setting sequence
at this point by holding down push-button B for at least two seconds.
Scroll through the city
codes by pressing
push-button A.
For further information
on city codes, see
the "List of cities" table.
Press push-button B to
go to the next step.
The DST indicator
will flash.
Activate (ON) or
deactivate (OFF) daylight
saving time for the selected
city by pressing pushbutton A. The DST icon
appears if the function
is activated. (*)
Press push-button B to go to
the next step. The display
will switch to local time
and date setting mode, and
the city code for local time
will flash.
10
2.2 Local time
1 Month
2 Day
3 Local time: seconds
4 Year
5 Local time: minutes
6 Local time: hour
7 City code for local time
11
Scroll through the city
codes by pressing
push-button A.
For further information on
city codes, see
the "List of cities" table.
When selecting the
city, local time will be
corrected automatically
based on world time.
The date will also be
adapted according
to the time zone where
the city is located.
Press push-button B
to go to the next step.
The DST indicator
will flash.
Activate (ON) or
deactivate (OFF) daylight
saving time for the local
city selected by pressing
push-button A.
The DST icon appears
if the function is activated.
Press push-button B
to go to the next step.
The hour will flash.
12
Set the hour by pressing
push-button A.
Press push-button B
to go to the next step.
The minutes will flash.
Set the minutes by
pressing push-button A.
Press push-button B
to go to the next step.
The seconds will flash.
Reset the seconds by
pressing push-button A.
Press push-button B
to go to the next step.
The year will flash.
If a correction is made to local time in this setting phase, the world time will
be recalculated and ajusted automatically.
13
2.3 Date
Set the year by pressing
push-button A.
Press push-button B
to go to the next step.
The month will flash.
Set the month by pressing
push-button A.
Press push-button B
to go to the next step.
The day will flash.
Set the day by pressing
push-button A.
Press push-button B
to go to the next step.
The display will switch
to 12 / 24 hour format
setting mode, and
the 12 / 24 hour
indicator will flash.
14
2.4 12 / 24 hour format
Select the 12 / 24 hour format
by pressing push-button A.
Press push-button B to return
to the original display option.
The icon
if the 12 hour format is selected.
will appear
15
2
1
3. Alarm setting
3.1 Alarm for local time
7
6
5
1 Alarm time: hour
2 Alarm time: minutes
3 Alarm ON (Active) / OFF (Inactive)
indicator
4 Local time: minutes
5 Local time: hour
3
6 Local time alarm activated indicator
7 Alarm setting mode indicator
4
16
B > 2sec.
Press push-button B, and hold
for at least two seconds.
The alarm ON (Active) / OFF
(Inactive) indicator will flash.
Activate (ON) or deactivate
(OFF) the alarm for local time
by pressing push-button A.
The icon
if the alarm is activated.
Press push-button B
to go to the next step.
The hour will flash.
will appear
17
Set the hour by pressing
push-button A.
Press push-button B
to go to the next step.
The minutes will flash.
Set the minutes by pressing
push-button A.
Press push-button B to return
to the original display option.
The alarm sounds for 30 secs. It can be stopped by pressing one of
the push-buttons.
18
List of cities
City
code
SOA Samoa Midway Islands
HNL Honolulu, HI Papeete
ANC Anchorage Nome
LAX Beverly Hills, CA Vancouver, Las Vegas, Tijuana
ASE Aspen, CO Edmonton, Denver, Phoenix
CHI + MEX Chicago, IL + Mexico City Houston, El Salvador
NYC New York, NY Montreal, Detroit, Boston, Miami,
Bogota, Lima
CCS Caracas
SCL Santiago La Paz, Santo Domingo
SAO Sao Paulo Rio de Janeiro, Buenos Aires,
Montevideo
SAW Grytviken
AZR Azores Praia
City
Other major cities
in same time zone
19
City
code
City Other major cities
in same time zone
LON London Lisbon, Casablanca, Bamako, Dakar
ROM Rome Zürich, Brussels, Vienna, Berlin, Paris,
Stockholm, Milan, Madrid
ATH Athens Helsinki, Cairo, Tel Aviv, Johannesburg,
Beirut
MOW Moscow St. Petersburg, Riyadh, Nairobi, Addis
Ababa, Kuweit
DXB Dubai Abu Dhabi, Muscat
KHI Karachi Male, Tashkent
DEL New Delhi Mumbai, Colombo
DAC Dhaka
BKK Bangkok Phnom Penh, Jakarta, Hanoi
HKG Hong Kong Beijing, Shanghai, Singapore, Manila,
Taipei, Kuala Lumpur, Perth
20
City
code
City Other major cities
in same time zone
TYO + SEL Tokyo + Seoul Pyongyang
SYD Sydney Vladivostok, Melbourne
NOU Noumea Port Vila
AKL Auckland Wellington, Nauru Island
- Ref. 114.4 and earlier versions of ref. 114.2 may slightly differ
- Please note that the time zones are correct at the time of production but that
some countries may change their time zone afterwards
21
