gtt systems GTTS-2000Bi Installation And User Manual
Installation and User’s Manual
Global Tracking and Tracing System
GTTS-2000Bi
Version 1.1 June 2009
GTTSystems B.V. Herfordstraat 16 7418 EX Deventer, The Netherlands T 0570 605075 F 0570 677755 E info@gtts.eu W www.gtts.eu
PREFACE
The information in this Installation and User’s Guide is subject to change in order to improve reliability,
design or function without prior notice.
In no event GTTSystems B.V. will be liable for technical or editorial errors or omissions herein.
Nor for incidental, special or consequential damages from the furnishing, performance or use of this
Installation and User’s Guide.
WARNINGS AND NOTICES
Read this installation and User’s Manual before unpacking and installing the GTTS-2000Bi.
Do not store the GTTS2000Bi on a metal shelf. This will drain the battery.
There are no user serviceable parts inside. Do not open the GTTS-2000Bi under any circumstances.
If the internal battery has to be replaced, contact your dealer.
If GTTS-2000Bi systems were ordered with (optional) mounting magnets, the magnets are in factory
mounted to reduce risk of injury.
If magnets are mounted, a warning label will be present inside the box or crate and/or on the lid of the
GTTS-2000Bi
Warning Label:
Caution: The magnets are very strong. The 4 magnets have a total holding force of
1080 N (~108 Kg)
Approvals: CE / EMC EN 60945 (2002), chapter 9
EN 60945 (2002), chapter 10
Page 3 of 10
Table of Content
1 INTRODUCTION ................................................................................................................................................. 4
1.1 GENERAL INFORMATION ................................................................................................................................ 4
1.2 SYSTEM DESCRIPTION .................................................................................................................................... 4
2 INSTALLATION .................................................................................................................................................. 6
2.1 UNPACKING ................................................................................................................................................... 6
2.2 ACTIVATION IN THE IRIDIUM NETWORK ........................................................................................................ 6
2.3 INSTALLATION GENERAL READ THIS FIRST ......................................................................................... 6
2.3.1 INSTALLATION WITH MAGNET MOUNTING ................................................................................................... 7
2.3.2 INSTALLATION WITH SCREW MOUNTING ..................................................................................................... 8
3 CONFIGURATION ............................................................................................................................................... 9
3.2 BATTERY LIFE ................................................................................................................................................ 9
4 REPLACEMENT OF THE BATTERY ....................................................................................................................... 9
5 SPECIFICATIONS .............................................................................................................................................. 10
