G-Tek BTG-100 User Manual

1

Table of Contents

Introduction……………………………………………………………………..3

Installation……………………………………………………………………....6

Pairing Bluetooth headset with the Gateway……………………………..8
Making a call…………………………………………………………………….8
Answering a call………………………………………………………………10
Pairing with Multiple Headsets……………………………………………..10
Specifications………………………………………………………………….11
Troubleshooting………………………………………………………………12

First edition (April 2004)
Corrections, changes and improvements to this manual might be made at any time and without notice. Such update
will, however, might be incorporated into new edition of this manual. The manufacturer assumes no responsibility or
reliability for any error or inaccuracy that may appear in this user guide.

All rights reserved.
Bluetooth is trademark of the Bluetooth SIG, Inc. The trademark are owned by Bluetooth SIG, Inc. USA

2

FCC Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two condition:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and use in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:

z Reorient or relocate the receiving antenna.
z Increase the separation between the equipment and receiver.
z Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
z Consult the dealer or an experienced radio/TV technician for help.
z You are cautioned that changes or modifications not expressly approved by the part responsible for compliance

could void the user’s authority to operate the equipment.

3

A. Introduction

Thank you for your purchase of BTG-100, Bluetooth Phone Audio Gateway. Your BTG-100
enables convenient cordless communication with analogue landline phone and Bluetooth
headset that are compliant with Bluetooth version 1.1 (or higher) and support the headset
profile.

Bluetooth technology make wireless link between any compatible mobile and stationary
communication devices. The technology adopts a global available RF frequency range to
establish RF link that offer secure, fast and reliable transmission of voice and data.

This user guide is intended to help you set up the gateway and to quickly familiarize
yourself with its operations. This document will guide you through the installation and
provide you with instructions on how to use the gateway’s features.

What is inside the box

The following items should be in your giftbox that comes with the Bluetooth Phone Audio
Gateway. If an item is missing, please contact your dealer.

Quantity Description

BTG-100 Bluetooth Phone Audio Gateway for house phone * 1
Linear AC Power Adapter with cord * 1
Phone cord * 1
User Manual * 1
Quick Start Guide * 1

It is recommended to use the power supply provided, otherwise there is risk of damaging the
Bluetooth phone audio gateway.

PICTURES of ITEMS in the BOX

BTG-100 Audio Gateway Linear AC Power Adapter RJ-11 Phone cord
