G-Technology 0G02529 User Manual
G DRIVE
®
Portable USB and FireWire®
PRODUCT MANUAL
g-technology.com
G DRIVE
®
G DRIVE
®
Welcome to G-DRIVE mobile
Table of Contents
Safety & General Use
Safety Precautions ................................................... 4
Backup Your Data .................................................... 5
About Your G-DRIVE mobile
Introduction .............................................................. 7
What’s in the Box .................................................... 8
System Requirements ............................................ 8
Overview of the Drive ........................................... 9
Easy Installation for Mac ....................................... 9
Disconnect the Drive ...........................................10
Table of Contents
Using Your Drive on Mac
Use with Time Machine ....................................... 12
Initialize Drive for Mac ........................................14
Restore the Drive Icon .........................................17
Reformat with Partitions .....................................19
Using Your Drive on Windows
Windows Use ...........................................................24
Cross Platform Use ................................................25
Support & Warranty
Technical Support .................................................29
Limited Warranty ...................................................30
Copyright ..................................................................32
p.2
G DRIVE
®
Safety & General Use
•
Safety Precautions ......................................... p.4
•
Backup Your Data ........................................... p.5
G DRIVE
®
Safety & General Use
Safety Precautions
The G-DRIVE® mobile’s warranty may be void as a result of the failure to respect the
pre-cautions listed here. If you detect a problem with your drive, please contact our
Technical Support department.
If the product is returned with damage caused by improper handling, the warranty will
be void and liability will rest with the user. Please read our Limited Warranty.
• Servicing: Your drive contains no user-serviceable parts. If it appears to be
malfunctioning, have it inspected by a qualied Technical Support representative.
• Moisture: Place the device away from moisture or liquids. To reduce the risk of
damage, do not expose this drive to rain or moisture. Do not use it in damp or wet
conditions. Never place objects containing liquids on the drive as they may spill into its
openings.
• Ventilation: Place the device in a vented area. The drive should never be placed near
or over a radiator or heat source.
• Temperature: Do not expose this drive to temperatures outside the range of 5°C to
35°C (41°F to 95°F); or to operational humidity beyond 5-80%, non-condensing, or
non-operating humidity beyond 10-90%, non-condensing. Avoid placing your drive
near a source of heat, or exposing it to sunlight (even through a window), or in an
environment that is too cold or humid.
• Physical Damage: Do not place heavy objects on the drive. Never use excessive force
on your drive.
p.4
G DRIVE
®
Safety & General Use
Backup Your Data
The disk drive contained in your G-DRIVE mobile device is a delicate electronic
instrument and is susceptible to damage due to excessive physical shock. Under no
circumstances will G-Technology® be held liable for the recovery or restoration of lost
data. Any loss, corruption or destruction of data while using a G-Technology drive is
the sole responsibility of the user.
Make two backups
To help prevent the loss of your data, we highly recommend that you keep TWO copies
of your data in separate storage locations. Keep one copy on your G-Technology drive.
Keep a second copy on your internal hard drive, another G-Technology drive, or a form
of removable storage media.
p.5
G DRIVE
®
About Your G-DRIVE mobile
•
Introduction .................................................... p.7
•
What’s in the Box .......................................... p.8
•
System Requirements ................................. p.8
•
Overview of the Drive ............................... p.9
•
Easy Installation for Mac .......................... p.9
•
Disconnect the Drive ................................. p.10
G DRIVE
®
About Your G-DRIVE mobile
Introduction
Thank you for purchasing the G-DRIVE mobile from G-Technology. G-DRIVE mobile hard
drives are the ideal storage solutions for people on the go.
G-DRIVE mobile is the perfect compliment to your Mac® laptop and other portable
computers. Weighing in at less than 9 oz., the drive oers a stylish look with a heavy duty
feel and is perfect to store or backup your important documents, music, digital videos
and digital photo les.
Back up all the les on your MacBook Pro® automatically! G-DRIVE mobile works with
Time Machine® right out of the box. You can also use the drive on a Windows® computer
or work cross-platform. See how here.
The drive features a silent, ‘fan-less’ design and an integrated cooling system to ensure
reliable operation and long life. G-DRIVE mobile is bus powered, eliminating the need to
carry around an external AC power supply to use the drive. Portability was never so easy!
p.7
G DRIVE
®
About Your G-DRIVE mobile
What’s in the Box
The following items are included in the box:
• G-DRIVE mobile
• (1) USB 3.0 cable (2.0 compatible)
• (1) FireWire® 800 cable
• Quick Install Guide
If any items are missing, please contact G-Technology at g-technology.com/support.
System Requirements
G-DRIVE mobile supports the folllowing Operating Systems. The drive is set up at the
factory for use with Mac OS® systems, and formatted as ‘HFS+ with Journaling’.
Mac: Mac OS 10.6 + and an available USB 3.0 or USB 2.0 port.
Windows: Windows® 8, 7 Vista and XP® and an available USB 3.0 or USB 2.0 port.
See how here.
p.8
G DRIVE
®
About Your G-DRIVE mobile
Overview of the Drive
This diagram shows the helpful features of your G-DRIVE mobile. A Power &
Activity LED is on the front of the unit. Two FireWire ports and a USB port are
on the rear.
The Activity light will glow when power is applied via a USB or FireWire port.
It will ash brighter as data is transferred to or from the hard drive.
Easy Installation for Mac
G-DRIVE mobile easily attaches to your computer via the USB or FireWire port. Simply
use one of the included cables to connect the drive to the appropriate connection
on your computer. For best performance, it is recommended to use the USB 3.0
connection when available. G-DRIVE mobile will automatically mount on the desktop if
you are running Mac OS.
No AC power supply is necessary. The drive is bus powered to eliminate the need to
carry around an external AC power supply to use the drive.
p.9
G DRIVE
®
About Your G-DRIVE mobile
Disconnect the Drive
A great feature of G-DRIVE mobile is its ability to be connected and disconnected while
your computer is running. To prevent failures and/or data loss, it is important to follow
the steps below when disconnecting or ‘unmounting’ the drive from your computer.
1. Before disconnecting the drive, unmount the system by simply dragging the
G-DRIVE mobile icon to the trash located in the dock. Keyboard shortcut:
Select the drive icon and hit Command+E.
2. It is safe to remove the drive from your system when the drive icon is no longer
present on your desktop.
Helpful links
• To use G-DRIVE mobile on Windows, go to Windows Use.
• To use G-DRIVE mobile on Mac and Windows, go to Cross Platform Use.
p.10
