GS Instech SMR700 D User Manual

Installation Guide Manual

Package

Version 0.3

SMR Unit ◊ 梱包箱構成図

* DAU (Donor Antenna Unit)

* SAU (Service Antenna Unit)

•SAU & Bracket Set •Adaptor

Accessories

◊ AC/DC Adaptor * 197 ft Link Cable

* DAU Bracket & Jumper Cable * SAU Stand Bracket * SAU Bracket

•Link Cable

•AC Cord

•Stand Bracket

•DAU

•DAU Bracket

• Jumper Cable

SMR Installation

Donor Antenna Unit

◊ Donor Antenna Unit (DAU)

◊ Se

rvice Antenna Unit (SAU)

External Port

◊ Standard Operation

- Plug & Play

- Auto Level Control, Auto Gain Control, Auto Isolation Check

- Input Level -67dBm ~ -37dBm

- Output Power of SAU +13dBm

rvice Antenna Unit (SAU)

◊ Se

Link Cable

AC/DC adaptor

STAND

SAU

[Back]

SAU
[Front]

LED Iindicators

NO Items LED Indications Explanations

1Checking

2Normal

3Alarm

4Alarm

5Alarm

6Alarm

7Alarm

8Alarm

Picture Frame

Alarm Æ GREEN LED Blinking
Power Æ GREEN LED Blinking

Alarm Æ Green LED ON
Power Æ Green LED ON

Alarm Æ GREEN LED Blinking
Power Æ OFF

Alarm Æ GREEN LED Blinking Repeatedly
Power Æ GREEN LED Blinking Repeatedly

Alarm Æ OFF
Power Æ RED LED ON

Alarm Æ RED LED ON
Power Æ RED LED ON

Alarm Æ Red LED Blinking Repeatedly
Power Æ Red LED Blinking Repeatedly

Alarm Æ RED LED Blinking
Power Æ RED LED Blinking

Auto Setup

Standard operation

Low Input Signal from DAU

Isolation Re-Check

Low Input Voltage (Feeding to DAU)

Link Fail between DAU and SAU

Shutdown Condition

Lack of Isolation between DAU and SAU

◆ Picture Size: 4 X 6 [inch]Pull Out

Specifications

Frequency Range

Band Width 10MHz

Gain

Composite Output Power

Shutdown Level +15dBm±2dB Over 5sec standing

Group Delay < 6usec

EVM (Error Vector Magnitude) DL: < 8% @CPL15dB, UL:12.5% @CPL15dB

Size

Link Cable

Power Consumption ≤ 18W

Operating Temperature +14°F ~ +122°F

ITEM SPECIFICATIONS REMARKS

Down Link 746 – 756 MHz

Up Link 777 – 787 MHz

Down Link 50 ~80dB ±1dB

Up Link 50~ 80dB ±1dB

Down Link +13dBm/Total

Up Link +13dBm/Total

ITEM SPECIFICATIONS REMARKS

DAU 6.22 × 5 × 1.96 H*W*D [inch]

SAU 5.7 × 7.67 × 1.65 H*W*D [inch]

Weight 1.63 lbs each DAU, SAU

Length 196.85 ft RG174/1.5D(2.6mm)

Connector SMA(M) DAU to SAU direction

Humidity 0% ~ 95%

AGC dynamic Range: 30dB

external adaptor

12V/3.5A
