GS Instech SC 8930AMP User Manual

SpeedCell Repeater

INSTALLATION GUIDE

Ver. 1.0

ntzT_`ZWhtwVkm|Tzwy

SpeedCell Repeater

Installation Guide Ver. 1.0

ntzT_`ZWhtwVkm|Tzwy

Contents of Box

Contents Picture Quantity Contents Picture Quantity

SpeedCellRepeater System

PSU Unit

4.3”(W) x 16.9”(H) x 10.7”(D) , 15 lbs

DFM Unit

2.8”(W) x 16.9”(H) x 10.7”(D), 9.9 lbs

800/900 AMP Unit

3.9”(W) x 16.9”(H) x 10.7”(D) , 19 lbs

Mounting Bracket

23.2”(W) x 18.5”(H) x 2.75”(D), 23.5 lbs

CD which contains

- User Manual

- Installation Guide

1EA

Ground Cable

6.6ft (2m)

Power Cord

5.9ft (1.8m)

Ethernet Cable

6.6ft (2m)

Lag Screw

1/2” x 2”

Ground Sems Screw

M4 x 8mm

1EA

4EA

RF Cable Set

Front RF Cable 2EA, Top RF Cable 4EA,

Reference Cable 3EA

1EA

Mounting Sems Screw

M6 x 10mm

8EA

This publication provides instruction for installing the SpeedCell repeaters.

Date

Version

Changes

03/2011

version 1.0

The images for the User Interface in this publication may vary from the repeater’s depending on its S/W

Version.

Revision History

Certification

UL/FCC: This equipment complies with UL and FCC

Warnings and Hazards

WARNING! ELECTRIC SHOCK

Opening the BDA (bi-directional amplifier) could result in electric shock and may cause severe injury.

WARNING! EXPOSURE TO RF

Working with the repeater while in operation, may expose the technician to RF electromagnetic fields that exceed FCC rules for human exposure. Visit the FCC website at http://www.fcc.gov/oet/rfsafety to learn more about the effects of exposure to RF electromagnetic fields.

WARNING! DAMAGE TO EQUIPMENT

Operating the BDA with antennas in very close proximity facing each other could lead to severe damage to the repeater.

RF EXPOSURE & ANTENNA PLACEMENT

Actual separation distance is determined upon gain of antenna used. Please maintain a minimum safe distance of at least 8inch while operating near the donor and the server antennas. Also, the donor antenna needs to be mounted outdoors on a permanent structure.

WARRANTY

Opening or tampering the BDA will void all warranties.

CAUTION: REPEATER SHOULD BE INSTALLED AS CLOSE AS POSSIBLE TO POWER SOURCE.

CAUTION: THIS REPEATER IS FOR INDOOR USE ONLY AND SHOULD BE LOCATED INSIDE OF BUILDING.

CAUTION: RISK OF EXPLOSION IF BATTERY ON CONTROLLER BOARD IS REPLACED WITH AN INCORRECT TYPE.

CAUTION: DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS

Mounting Repeater

Wood-Framed Wall

• It is recommended to first attach a sheet of plywood to the wall. The sheet of plywood should be anchored to the studs in the wall.

• Using a pencil, mark the location for each of the mounting bracket's four mounting holes on the plywood.

• Place the mounting bracket over the four lag screws heads.

• Thread a lag screw at the positions marked in step 2.

Wood-Framed Wall

Lag Screw

1/2” x 2”

<Picture 1> Mounting the Bracket

on a Wood-Framed Wall.

Mounting Bracket

Hang and Grounding

• Hang the PSU unit to the mounting bracket.

• Locate the two Mounting Sems Screws (M6 x10mm) underneath the PSU unit. Tighten bolts until secure.

Mounting Sems Screw

M6 x 10mm

<Picture 2> Hanging the PSU Unit.

Hang and Grounding

• Hang the rest of the units in the following order: 800/900 AMP.

• Locate the two Mounting Sems Screws (M6 x10mm) underneath each unit. Tighten bolts until secure.

CAUTION

Units must be hung in the following order only: DFM -> 800/900 AMP.

<Picture 3> Hanging the Rest of Units.

Hang and Grounding

• Connect ground cables of each unit to the bracket using Ground Sems Screws (M4 x 8mm) as displayed at the picture below.

CAUTION

Ground cables must be properly grounded to provide both EMI and voltage surge protection for the repeater.

Ground Cable

<Picture 3> Grounding of the PSU, 1900 AMP, DFM, 800/900 AMP Units.

Hang and Grounding

• Locate the ground lug on the underside (or side) of the bracket.

• Crimp the ground cable to the ground lug.

• Route the free end of the ground cable to an approved (per local code or practice) ground source.

CAUTION

Ground cable must be properly grounded to provide both EMI and voltage surge protection for the repeater.

<Picture 4> Grounding the Bracket.

Position Antenna

• After installing 800/900MHz antennas the installer should make line of site.

• Customer specifications should be followed for positioning the antennas properly.

Warning: In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna should not be less than 50cm during normal operation. The gain of the antenna is 12 dBi.

<Picture 5> An installer is directing Donor Antenna to

nearby BTS to receive strong input signal.

RF Cable Connections: Top of The Repeater

• Connect the 800/900 Antennas to their corresponding ports.

• Plug in four N(M) to N(M) type RF cables as demonstrated in the picture below.

CAUTION

Do not connect or disconnect cable from ANT port when power is ON.

A B

C D

A B

<Picture 6> Top View of the Repeater.

RF Cable Connections: Front Side

• Take out two SMA (M) to SMA (M) type RF cables.

• Please, pay attention to cable‟s corresponding number and its color while connecting.

• 800/900 AMP and DFM via Band 2.

A B

<Picture 7> Front View of the Repeater.

10M REF.

1. RS485_P

2. RS485_N

3. GND

4. INSERT

5. RESET

6. NC

7. ID_RESERVE

8. GND

9. ID1

10. ID2

11~14. COM_GND

15~18. NC

19~22. COM_GND

23. 27.5V

24. 27.5V

25. 6.5V

2. RS485_N

3. GND

4. INSERT

5. RESET

6. NC

7. ID_RESERVE

8. GND

9. ID1

11~14. COM_GND

15~18. NC

19~22. COM_GND

23. 27.5V

24. 27.5V

25. 6.5V

10M REF.

1. RS485_P

2. RS485_N

3. GND

4. INSERT

5. RESET

6. NC

7. ID_RESERVE

8. GND

9. ID1

10. ID2

11~16. COM_GND

17~20. NC

A1. 5.5V

C A

1: VCC 2: VCC 3: GND 4: GND

A: AC B: AC C: F.G

DFM

AMP

RF Cable Connections: Bottom of The Repeater

• Take out three SMA (M) to SMA (M) type RF cables.

• While connecting the PSU and the DFM units underneath, use referenced cable and pay attention to the labels. Plug them into their corresponding outlets.

• User may choose either of the two SMA ports on the bottom of the PSU to connect to the DFM.

• User may choose any two of the four SMA ports on the bottom of the PSU to connect to amplifiers.

CAUTION

Please, pay attention while connecting PSU and DFM, PSU and 800/900 AMP. The repeater will not work if connection is inappropriate.

A B C

<Picture 8> Bottom View of the Repeater.

10M REF.

1312 11 10 9 7 6 5 4 3 2 1

1516

181920

2122

1. RS485_P

2. RS485_N

3. GND

4. INSERT

5. RESET

6. NC

7. ID_RESERVE

8. GND

9. ID1

10. ID2

11~14. COM_GND

15~18. NC

19~22. COM_GND

23. 27.5V

24. 27.5V

25. 6.5V

INTERFACE

10M REF.

1312 11 10 9 7 6 5 4 3 2 1

1516

181920

2122

1. RS485_P

2. RS485_N

3. GND

4. INSERT

5. RESET

6. NC

7. ID_RESERVE

8. GND

9. ID1

10. ID2

11~14. COM_GND

15~18. NC

19~22. COM_GND

23. 27.5V

24. 27.5V

25. 6.5V

AMP INTERFACE

10M REF.

10 9 7 6

5 4 3 2 1

11121617181920

1. RS485_P

2. RS485_N

3. GND

4. INSERT

5. RESET

6. NC

7. ID_RESERVE

8. GND

9. ID1

10. ID2

11~16. COM_GND

17~20. NC

A1. 5.5V

INTERFACE

1415 13

C A

1: VCC 2: VCC 3: GND 4: GND

INTERFACE

EXTRA

SNMP

A: AC B: AC C: F.G

DC OUT

DFM

AMP

AMP INTERFACE

DFM INTERFACE

AMP INTERFACE

EXPAND FOR QUAD

AMP INTERFACE DFM INTERFACE AMP INTERFACE

10M REF.

13 12 11 10 9 7 6 5 4 3 2 1

14151617181920

2122232425

1. RS485_P

2. RS485_N

3. GND

4. INSERT

5. RESET

6. NC

7. ID_RESERVE

8. GND

9. ID1

10. ID2

11~14. COM_GND

15~18. NC

19~22. COM_GND

23. 27.5V

24. 27.5V

25. 6.5V

INTERFACE

10M REF.

13 12 11

10 9 7 6 5

4 3 2 1

14151617181920

2122232425

1. RS485_P

2. RS485_N

3. GND

4. INSERT

5. RESET

6. NC

7. ID_RESERVE

8. GND

9. ID1

10. ID2

11~14. COM_GND

15~18. NC

19~22. COM_GND

23. 27.5V

24. 27.5V

25. 6.5V

AMP INTERFACE

10M REF.

10 9 7 6 5

4 3 2 1

11121617181920

1. RS485_P

2. RS485_N

3. GND

4. INSERT

5. RESET

6. NC

7. ID_RESERVE

8. GND

9. ID1

10. ID2

11~16. COM_GND

17~20. NC

A1. 5.5V

INTERFACE

1415 13

C A

1: VCC 2: VCC 3: GND 4: GND

INTERFACE

EXTRA

SNMP

A: AC B: AC C: F.G

DC OUT

DFM

AMP

AMP INTERFACE

DFM INTERFACE

AMP INTERFACE

EXPAND FOR QUAD

AMP INTERFACE DFM INTERFACE AMP INTERFACE

Power Cord Connections

• Plug in the cables to PSU, DFM and 800/900 AMP as displayed at the picture below.

<Picture 9> Bottom View of the Repeater.

These ports are used for an added 2600 MHz amplifier while extension of the repeater.

Connecting Power Cable and LED Light Verification

• Connect Power Cable

<Picture 10> AC Power Port Connection.

• Turn the switch “ON” on the left side of PSU.

System On

System Off

<Picture 11> ON/OFF Switch of SpeedCell Repeater.

• Turn the switch “ON” on the front side of PSU as displayed at the picture 12.

<Picture 12> Verification of LED Lights.

LED Indicators

• The LED‟s on the repeater will light up and should change to green as displayed at the picture below. Tx and Rx LEDs will be blinking.

RUN LED : Green light ON. ALARM LED : Green light is normal status, Red light is alarm status. SHUT DOWN LED : Green light is normal status, Red light is shutdown status.

PSU

1900 AMP

800/900 AMP

DFM

Input Power Signal

Less than ~ -86dBm

LED 1bar

-85dBm~-79dBm

LED 2 bars

-78dBm~-72dBm

LED 3 bars

-71dBm~-65dBm

LED 4 bars

More than -64dBm

LED 5 bars

• Please note the number of LED bars for input indicates signal strength level.

The tables below indicate the levels.

Number of LED bars on the front side of Repeater will show input signal level:

<Table 1> LED Bars Indication.

Output Power Signal

Less than ~ +5dBm

LED 1bar

+6dBm~+10dBm

LED 2 bars

+11dBm~+15dBm

LED 3 bars

+16dBm~+20dBm

LED 4 bars

More than +21dBm

LED 5 bars

• Please note the number of LED bars for output indicates signal strength level.

Number of LED bars on the front side of Repeater will show output signal level:

<Table 2> LED Bars Indication.

Web UI

• LAN port is used for connection of laptop and repeater.

• WAN 1 port is used for connection of repeater and wireless modem for remote access.

• WAN 2 port is a redundancy port for remote access.

1 2 3

<Picture 12> Ethernet Port.

Configuring Laptop to Connect to Repeater

• Connect Ethernet crossover cable from the LAN port of the repeater to laptop.

1. Go to Local area connection.

2. Click ‘TCP/IP Properties’.

3. Choose ‘Obtain DNS server address

automatically’.
