Page 1
SPIRAL CURLS HAIR STYLER
HS 6031
DE
SV
EN
NL
FR
PL
IT
CS
PT
TR
ES
EL
Page 2
Page 3
3
_________________________________________________________
A B C F G HD
E
Page 4
4
_________________________________________________________
DEUTSCH 05-13
PORTUGUÊS 39-46
POLSKI 72-80
FRANÇAIS 22-29
SVENSKA 55-62
TÜRKÇE 89-96
ENGLISH 14-21
ESPAÑOL 47-54
ČESKY 81-88
DEUTSCH 05-14
DEUTSCH 05-14
DEUTSCH 05-14
ITALIANO 30-38
NEDERLANDS 63-71
ΕΛΛΗΝΙΚΑ 97-105
Page 5
14ENGLISH
SAFETY ________________________________
Please note the following instructions
when using the appliance.
7
Keep the instruction manual for
future use. Should a third party be
given the unit, please ensure the
instruction manual is included.
7
The appliance is designed for
domestic use only.
7
Never use the appliance in the
bath, shower or over a wash basin
filled with water; nor should it be
operated with wet hands.
7
Do not immerse the appliance in
water or let it come into contact
with water, even during cleaning.
7
If the appliance is used in the
bathroom, it is essential that
you unplug it after use, as any
water close to the appliance can
still pose a hazard, even if the
appliance is switched off.
7
If not already in use, installing
a residual current-operated
protective device (RCD) is
recommended for additional
protection with a rated residual
operating current not exceeding
30 mA in the electrical circuit of
your bathroom. Ask your plumber
for advice.
7
Never cover the appliance, for
example with a towel.
7
Never place the appliance on
soft cushions or blankets during
operation.
7
The appliance can become very
hot. Do not keep your hair around
the heating element for more than
a few seconds.
7
Do not allow the barrel to come
into contact with your face, neck
or head. Do not touch it with your
bare hands.
7
Unplug the appliance after use.
Do not disconnect the plug by
pulling on the cord. Place the
appliance on a heat resistant
surface and allow it to cool down.
7
Never use the appliance if it
or the power cord is visibly
damaged.
Page 6
15 ENGLISH
SAFETY _______________________________
7
If the power cord is damaged,
it must be replaced by the
manufacturer, a service centre
or a similarly qualified person to
avoid any danger of electrical
shock.
7
Make sure that there is no danger
that the power cord could be
accidentally pulled or that
someone could trip over it when
the appliance is in use.
7
Keep the appliance out of the
reach of children.
7
The appliance should not be
used by the following people,
including children: those with
limited physical, sensory or
mental capabilities and also those
with a lack of experience and
knowledge. This does not apply
to the latter if they were instructed
in the use of the appliance or if
they use it under the supervision
of a person responsible for their
safety. Children should always be
supervised to ensure that they do
not play with the appliance.
7
Do not leave the appliance
unattended when switched on.
7
Never open the appliance under
any circumstance. No warranty
claims are accepted for damage
caused by improper handling.
7
Check if the mains voltage on the
type plate (on the handle of the
appliance) corresponds to your
local mains supply. The only way
to disconnect the appliance from
the mains is to unplug it.
7
Never wrap the power cord
around the appliance.
7
Never use the appliance in or
near to combustible, inflammable
places and materials and
furniture. Do not let the appliance
come into contact with or become
covered by inflammable materials
e.g. curtains, textiles, etc. Please
make sure that the appliance is
always kept a safe distance away
from flammable materials and
furniture.
7
Do not use paper, cardboard,
plastic, inflammable, unprotected
polished surfaces under the
appliance.
Page 7
16ENGLISH
OVERVIEW ____________________________
Dear customer,
Congratulations on the purchase of
your GRUNDIG HS 6031 Spiral Curls
Hair Styler.
Read the following information carefully to ensure that you can use your
high-quality GRUNDIG product for
many years.
A responsible approach!
GRUNDIG focusses on
contractually agreed
social working conditions with fair wages
for both internal employees and suppliers, as well as on
the efficient use of raw materials with
continual waste reduction of several
tonnes of plastic each year – and
availability of at least 5 years for all
accessories.
For a future worth living.
For a good reason. Grundig.
Features
7
Care and protection with its gentle
ceramic coating with tourmaline
and nano silver – for hydrated hair
with more shine, bounce and care.
– Ceramic ensures constantly
high temperature and even heat
distribution. The heat is distributed
evenly to ensure hair is fully protected.
– Tourmaline generates negative
ions in a natural way, prevents
frizz, static charging and preserves
the natural moisture of the hair.
– Nano silver inhibits bacteria
build-up, constantly protecting
and maintaining the surface of the
plates – for healthy hair and hygienic styling plates.
7
19 mm instant heat curling tong.
7
Adjustable temperature regulation
from 140° C to 180° C.
7
Fast electronic heating up time
within 60 sec. to 100° C.
7
Worldwide automatic voltage adjustment.
Page 8
17 ENGLISH
OVERVIEW ____________________________
Controls
See the figure on page 3.
A
Cool tip
B
Curling wand with clip (ceramic-
tourmaline-nano silver coating)
C
Integrated product stand
D
Lever (to open clip)
E
Mode indicator
F
Temperature setting wheel (mark-
ers between one and three dots).
G
On/Off buttons
H
Power cord with swivel joint
Page 9
18ENGLISH
OPERATION
__________________________
Styling curls
Your appliance conjures up glamorous
curls and ringlets that are spectacularly
springy and stay in a perfect shape.
Caution
7
The heating element with clip becomes very hot. Do not touch with
your hands.
7
Do not allow the heating element
to come into contact with your skin,
face, neck or head.
7
Set the appliance to the lowest
temperature level the first time you
use it. You can find the level which is
suitable for your hair by incrementing the temperature level.
1 Place the appliance on a solid, flat,
heat resistant surface.
Use the product stand.
2 Plug the power cord
H
into the wall
socket.
3 Adjust the temperature level with the
temperature setting wheel
F
.
Note
7
There are 3 temperature levels
which are shown with the markers
on the temperature setting wheel.
One dot shows the minimum and
three dots show the maximum temperature level. The temperature can
also be set between the dots.
4 Press and hold down On button
G
for 2 seconds to switch on the appliance.
– The mode indicator light
E
lights
up blue and starts flashing until it
reaches the set temperature.
– When the appliance has reach-
ed the desired temperature, the
mode indicator light
E
stops
flashing, meaning that it is ready
to use.
– The mode indicator LED is also
flashing when set temperature
will be changed during operation
until new set temperature (higher
or lower) is reached.
5 Comb or brush out a section of your
hair about 3 cm wide.
6 Press and hold down lever
D
. Place
the end of the section of hair under
the clip and release the lever
D
.
7 Wrap the section of hair around the
curling wand with clip
B
towards
your head.
8 After 5 to 10 seconds, press down
lever
D
to open the clip and re-
move the curling wand from the hair.
Page 10
19 ENGLISH
OPERATION
__________________________
Note
7
Repeat the procedure section by
section.
9 After use, switch the appliance off
by pressing the Off button
G
for 2
seconds.
– The mode indicator light
E
disap-
pears.
10 Unplug the power cord
H
from
the wall socket.
Now, your defined curls are ready
– spectacularly springy and in a
perfect, long lasting shape.
Notes
7
The appliance can reach a
temperature of 140° C up to a
maximum temperature of 180 °C.
It reaches 100° C approximately in
60 seconds.
7
If the appliance is not used for a
while after it is heated up, it automatically switches off after 60
minutes.
7
Never leave the appliance unattended while it is plugged in.
7
Allow the appliance to cool down
in a safe place.
Page 11
20ENGLISH
INFORMATION _________________________
Cleaning and care
1 Turn the appliance off and unplug
the power cord
H
from the wall
socket.
2 Before cleaning, allow the
appliance to cool down. The
appliance can become very hot
and may take up to 45 minutes to
cool down.
3 Clean the appliance only with a soft
damp cloth.
Caution
7
Never put the appliance or power
cord in water or any other liquid.
Do not use any cleaning agents.
Note
7
Before using the appliance after
cleaning, dry all parts carefully
using a dry soft towel.
Storage
7
If you do not plan to use the
appliance for a long period of time,
please store it carefully.
7
Make sure that it is unplugged,
has completely cooled and is
completely dry.
7
Do not wrap the power cord
around the appliance.
7
Keep it in a cool, dry place.
7
Make sure that the appliance is kept
out of the reach of children.
Page 12
21 ENGLISH
INFORMATION _________________________
Environmental note
This product has been manufactured
with high quality parts and materials
which can be reused and are
suitable for recycling.
Therefore, do not
dispose of the product
with normal domestic
waste at the end of its
service life. Take it to a
collection point for the
recycling of electrical and electronic
equipment. This is indicated by this
symbol on the product, in the
operating manual and on the
packaging.
Please consult your local authorities
to find out the location of the nearest
collection point.
Help protect the environment by
recycling used products.
Technical data
This product conforms to the
European directives
2004/108/EC, 2006/95/EC and
2009/125/EC.
Power supply:
120 – 240 V~, 50/60 Hz
Power:
27 W
Page 13
www.grundig.com
72011 908 2000 11/47
