COLOR TELEVISION
MW 70-269 PAL PLUS
Kurzanleitung
ķ
6
Safety, Setting up and Connection
r
Connection example
(TV set and Video recorder)
This highly digitalised TV set offers you optimum
picture and sound quality.
Ń
!
The essential prerequisites for this are:
An aerial system and aerial connection cable in perfect working order with a high degree of shielding
(85dB) as a connection between the TV set and
aerial socket or between the TV set and video
recorder.
Ń
!
Avoid wear to the cable near the set.
Ń
!
You will find further information on connecting
various external units (e.g. SAT receiver, decoder)
in the dialog center menu section » Audio-/video
connections «.
r
The GRUNDIG MEGALOGIC System
The TV set is equipped MEGALOGIC System.
If you connect a GRUNDIG video recorder to the
MEGALOGIC System using the supplied MegalogicEURO/AV (Scart) cable, terrestrial TV channels (and
all channel position related information) are automatically transferred to the video recorder (VCR)
with each “Reprogramming of the TV channel”.
“Setting the TV channel on the video recorder” is no
longer necessary.
Ǻ
ń
R
L
AUDIO
R
L
I
N
O
U
T
EURO - AV 2
AV 1
EURO -
AV 1
AV1
AV2
AV3
AUDIO-OUT
L
R
AV1
r
Dear Customer!
In order for this high-quality convenient TV set to
bring you viewing pleasure for many years, it is
necessary that you observe the following points
when setting it up.
Ń
!
Ideal viewing distance is 5x the length of the TV
screen diagonal
Light from external sources falling on the TV the
screen will impair the picture quality.
Ń
!
There must be sufficient clearance from the cabinet
walls at the appropriate location.
Ń
!
Do not cover the ventilation openings.
Ń
!
Heat build-ups may occur in the set.
– Heat build-ups are a source of danger and may
shorten the life span of the set.
For safety reasons, have an expert remove
deposits from the set occasionally.
Ń
!
Do not damage the mains cable.
Ń
!
Do not place any magnetic field sources in the vicinity of the set (speaker boxes for example).
Ń
!
Do not place flower vases or flower pots on top of
the set.
Ń
!
Ensure that liquids or other objects are not allowed
to enter the set (danger of short circuits).
Ń
!
Clean the TV screen with a moist, soft towel using
pure water only.
Ń
!
Avoid damage from lightning strikes by disconnecting the mains and aerial cables.
– Even if the set is switched off, damage may result
from a power surge due to lightning in the mains
or in the aerial cable.
Ń
!
The set may be opened and maintained by authorised experts only.
Ń
!
This TV set is to be used for the reception and
reproduction of picture and audio signals. Any
other use is excluded.
Ǻ
5 x
10
cm
20
cm
20 cm
10
cm
rieg am
K
olf
G
