Grundig GCE0992E User Manual

COLOR TELEVISION

SE 6376 TOP/LOG

Contents

If a specialized dealer has already set up and adjusted the
television, start with page 6 of this manual.

Notes on Safety and Setting Up

Notes on safety and setting up, connecting

switching the unit on/off .................................................... 3

Assigning Programme Positions

The automatic tuning system ATS euro plus...................... 4

ATS euro plus - update ....................................................... 5

Assigning programme positions manually......................... 6

Fine tuni n g ........................................................................... 6

Changing the Programme Position Assignment

The TV station table.......................................................... 7- 9

The Remote Control Handset

The remote control handset.............................................. 1 0

Changing the Sound Setting...

... via the Audio menu ....................................................... 1 1

Calling up the Audio-Menu .............................................. 1 1

Stereo expansion .............................................................. 1 1

Sound (stereo, two-channel sound, mono)....................... 1 1

Treble, bass, balance ....................................................... 11

Headphones: Connection, volume .................................... 1 1

Adjusting the Picture

Contrast and picture definition ........................................ 1 2

Switching the picture format ............................................ 1 2

Brightness and colour contrast ........................................ 1 2

Teletext

Teletext mode.............................................................. 13-16

Convenient Functions

Security/Timer functions ............................................ 17-19

Blocking broadcasts unfit for children.............................. 18

Blocking all programmes ............................................ 18-19

Entering a switch-off time (Sleep Timer) ......................... 1 9

Entering a switch-on time (Wake-up Time)...................... 1 9

Special functions ......................................................... 20/21

Connection Capabilities and Operation

For video recorder............................................................. 2 2

For camcorder................................................................... 2 3

For satellite receiver, descrambler .................................. 2 4

For several external units at a time ................................. 2 5

Copying video recordings via the television .................... 2 6

Specification

Specification ..................................................................... 2 7

ķ

2

GB

ķ

3

GB

Savety and Installation/Connection and Putting into Operation

Switching the unit on and off (continuet).
Switching on from standby: Press 0…9buttons once
again.
Switching off with remote control handset: Press Ǽ button
twice (switching on again only possible on the unit).
Switching off on the unit: Press

¢

IO

button.

If you do not use the televison for extended periods of time
(e.g., at night), it is recommended to activate the ecologi­cal mains switch
This will ensure that the unit is completely switched off
from standby.
This helps you to save energy.
For further information see the "Settings" function in the
"Special Functions" menu on page 20.

Please avoid:

Damage to the set due to electrical storms by disconnecting
the mains and aerial cables.

Opening of the set and interventions by incompetent persons.

Heat build-up, moisture, and penetration of dust and foreing
objects into the set.

Obstruction of the ventilation slots.

Too little distances inside cabinets.

Damage to the mains lead.

Scratching and rubbing the picture screen.

Clean the picture screen only with a moistened and soft
cloth. Use clear and clean water only.

Magnetic fields (loudspeaker boxes) near the set.

Connecting the set to the aerial

Connect the aerial cable with the aerial socket É of the TV set.
For TV/video recorder operation, connect as shown in the
figure.

Connecting the TV set with the mains

Switching the set on/off

Switching on: Press

¢

IO

button on unit.
Switching to standby: Press Ǽ button on remote control
handset once.

L

H

L

H

ń

ń

+

+

–

–

EURO-AV A1

AUDIO

R

L

R

L

DECODER A2

EURO-AV

Krieg am Golf

10

cm

20

cm

20 cm

10

cm

°C

°C

2 Std

5 x

! SERVICE !

ķ

4

ĻĻĻ

Press the following buttons on the
remote control You will see this on the TV screen Explanations

The Automatic Tuning System "ATS euro plus"

After switching on the television set, the "ATS euro plus" page
appears.
If this page does not appear, press and hold down the mbut­ton until the "ATS euro plus" page appears on the screen.
The dialogue lines at the bottom of the screen are used as
user guide.

The signs ɦ, ɼ,

ʺʺ, ɶɶ

are symbols for the following buttons

on the remote control handset:

ʺʺ, ɶɶ

= programme selection buttons | and ]

ɦ, ɼ = volume x and c

OK = O button

In the following text, the remote control buttons instead of
the symbols will be shown.

Assigning Channel Positions

You can choose between several lan­guages for the on-screen dialogue with
your television. After you select a lan­guage, all menu guide messages and
information will appear in the language
you selected.

After pressing the O button, the "ATS

euro plus channel search" is started.
The television searches for all available
channels, sorts, and stores them.
This procedure can take one minute or
more, depending on the number of
channels that can be received.
If a video recorder equipped with the
MEGALOGIC functions is connected to
this TV set (the connection must be
made via the EURO-AV sockets –
socket AV2 on the TV set – with a fully
wired EURO-AV cable), the display
shown opposite will appear.
It is then possible to select between the
functions ”MEGALOGIC Upload” and
”ATS”.

ŁŁ

Your television is equipped with "ATS euro plus" (Auto Tuning
System). This new system offers you the advantage of auto­matic channel position assignment.
This search and memory system scans the entire reception
range, stores the channels found, and enters them with their
respective station name (abbreviation) into a TV station table.

You can change the automatic

channel position assignment
as you wish. For example, for channels without identification,
you can choose a name (station name) in a list of abbrevia­tions displayed on the screen and assign it the channel.

GRUNDIG ATS euro plus

Country

A B CH D DK E F GB I N

NL P S SF Others

Select < >

ɶ

ʺ

Confirm OK
Terminate

Ǻ

1. Menu guide language

a) Select a language

xor c

b) Confirm

O

2. Country (location)

a) Select a country

xor c

b) Confirm

O

GRUNDIG ATS euro plus

Language

D DK/N E F GB I NL P S SF

Select < >
Confirm OK
Terminate

Ǻ

3. Selection between:
a) ATS station search

Start ATS

a)

O

or

GRUNDIG ATS euro plus

ATS

MEGALOGIC Upload
Accept stations table

Select < >

ɶ

ʺ

Confirm OK
Terminate

Ǻ

ķ

5

Assigning Channel Positions

Press the following buttons on the
remote control You will see this on your TV screen Explanations

Transfer of the TV stations table
from the video recorder to the tele­vion set.

The TV set is provided with the MEGA­LOGIC system.
In connection with a video recorder
which is provided with the same
system, operation of the two sets be­comes very convenient.
It is possible to transfer the data of the
programme positions (stored channels)
from the video recorder to the TV set.
The ATS search function then is no
longer necessary.
After transferring the data, you can
immediately watch TV and simul­taneously record the programme on the
video recorder.
For this, the TV set (socket AV2) and
the video recorder (Euro-AV socket)
must be connected by means of a
Euro-AV cable (all pins used).
During data transfer, the message
”Transfer of VCR stations table” as well
as the programme position number and
the station name are displayed.
When data transfer is completed, the
picture received on channel position 1
is visible on the picture screen.

ĻĻĻ

3. or
b) Transfer the stations table (pro-

gramme position data) from the
video recorder to the TV set

b)

|

VCR1 x or cVCR2

start transfer

O

GRUNDIG ATS euro plus

ATS

MEGALOGIC Upload
Accept stations table

Select < >

ɶ

ʺ

Confirm OK
Terminate

Ǻ

ķ

6

ATS euro plus – Update

If you have already found and stored programmes (channels)
with the "ATS euro plus" tuning system and wish to start ano­ther ATS euro plus search to update programme allocation in
the TV station table – for example, when the reception condi­tions have changed because of newly offered programmes ­Nselect the menu point "Actualize TV-Stations" in the Infocen­ter.

How to proceed:

Press the .button then the Obutton.
The "GRUNDIG Infocenter" appears on the screen.

Use the

|

button to select the menu line "Actualize TV Stati-

ons".

Press the

O

button.
The automatic tuning system is started with the last settings
(language and country).

The newly found channels ("programmes") are added to the
existing channels in the TV station table and highlighted in
blue.

It is possible to shift the programmes to other programme
positions.

If a completely new run of the automatic tuning system is
required (e.g., when changing location or in the case of
connection to a cable TV system at a later date), start ATS as
described on page 4. In this case, the previous programme
position data is cleared.

Pressing the

.

button calls up the storage function and

pressing the

O

button stores the new programme alloca-

tion into memory.

Assigning Programme Positions Manually

Exam

ple:

You wish to assign a programme which is transmitted on
special channel S 08 to the programme position 10.

GRUNDIG Infocenter

D DK E F GB

I N NL P S SF

Special functions

Picture-menu

Timer/Security

TV-Station Table

Actualize TV-Stations

Select

ɶ

ʺ

Activate OK
Terminate

Ǻ

Assigning Channel Positions

How to proceed:

Select programme position P 10.

Press the

m

button then the xbutton.
In the data entry line, the letter C (for channel) is marked by a
colour.

Press the

]

button; C changes to S (for special channel).
Press the cbutton;
the cursor jumps to the channel entry position.

Press the

0

and 8button;
S 08 is visible in the data entry line.
Channel entry can also be effected by means of the manual
channel search.
For this, press the

|

or ]button to start the channel

search.

The search stops at each channel which can be received in
your area.

The unit automatically adjusts the best possible picture
sharpness.

You can assign the programme position a station name
(abbreviation of max. 4 characters). To do this, press the

c

button.

Allocating programme position 10 to special channel S 08
now is concluded and you can switch to TV mode by pressing
the

.

button or repeat the above steps to allocate further

programme positions.

In difficult reception conditions it may be necessary to im­prove the the picture quality by manual fine tuning.

Fine Tuning

Press the mbutton.

Press the

c

button until the highlighted cursor has reached

the 00 position (for fine tuning).

Use the

]

(63 steps) or

|

button (64 steps)

to adjust the optimum picture and sound quality.

C Channel
S S-Channel

P 10 nS 08 -00 – – – –

Select

ɶɶ

ʺʺ

Select position < >
Terminate

Ǻ

Changing the Programme Position Assignment

ķ

7

Press the following buttons on the
remote control You will see this on the TV screen Explanations

ĻĻĻ

ŁŁ

The TV Station Table

The TV station table shows you the programme position
assignment with the associated station names.
You can change this programme position assignment accor­ding to your personal preferences and assign a station name
to stations without identification.

1. Call up the "GRUNDIG Infocenter"

.

O

2. Select the "TV-Station Table"
line

|
|

a) confirm

O

The following chapters

3.1 – 3.3 describe the different func­tions.
Select the desired function(s).

You can leave the TV station table by
pressing the .button. Your set­tings are automatically stored in
memory.

GRUNDIG Infocenter

D DK E F GB I N NL P S SF

Special functions

Picture-Menu

Security/Timer

TV-Station Table

Actualize TV-Stations

Select

ɶ

ʺ

Activate OK
Terminate

Ǻ

GRUNDIG TV-Station Table

Prog Channel Station

1 C 06 ARD
2 C 24 ZDF
3 C 47 BR 3
4 C 40 SAT1
5 C 21 PRO7
6 C 59 BR 3
7 C 41 – – – –
8 C 53 RTL2
9 C 31 ZDF

10 C 32 ZDF

Select programme

ɶ

ʺ < >

Change channel OK
Move/Copy

n

Delete

n

Terminate

Ǻ

Changing the Channel Position Assignment

Press the following buttons on the
remote control

ķ

8

You will see this on the TV screen Explanations

3.2. Clear programme position data *

a) Select programme position

|,or ]

b) Clear programme position data

¢

(red button)

3.1 Changing the order of the

channels (shift or copy) *

a) Select programme position

|,or ]

b) Mark programme position

(shift:

¢ yellow button 1x;

copy:**

yellow button 2x)

c) Select new programme position

(shift; copy)

|,or ]

O

If you should not like the order of the
channels ("programmes), it is possible
to change the order at any time.

When shifting a channel, only the order
of the data on the channel positions will
be changed.
When copying a channel, the already
existing data of the marked channel
position will appear a second time on
the selected channel position (where
the cursor bar is located).

If desired, repeat this procedure for fur­ther channels ("programmes").

GRUNDIG TV-Station Table

Prog Channel Station

1 C 06 ARD
2 C 24 ZDF
3 C 47 BR 3
4 C 40 SAT1
5 C 21 PRO7
6 C 59 BR 3
7 C 41 – – – –
8 C 53 RTL2
9 C 31 ZDF

10 C 32 ZDF

Move

ɶ

ʺ < >

Confirm OK
Copy

n

* The steps 1 and 2 explained on page 7 must already be executed.

**Copying is only possible after having fitted a SAT module into your set.

If deired,repeat this procedur for further channels ("programmes")

d) Select existing station

name

c

e) Select new station name

|,or ]

f) Terminate

.

Changing the Programme Position Assignment

Press the following buttons on the
remote control You will see this on your TV screen Explanations

If you store the channel number 00 on a
programme position, it is no longer
possible to select higher programme
positions with the |or

]

button
("return point"). If this return point is
placed on a programme position bet­ween 1 and 10, only the programme
positions 1 to 9 can be selected wit the
numeric buttons.

ķ

9

3.3. Enter a station name and channel
number or modify the existing one *

a) Select programme position

|,or ]

b) Visualize the data of the

programme position

O

c) Enter channel number

1 … 0

If you cannot find the desired name in
the list, you can enter your own. In
order to do so, press the cbutton
once, and using the |or ]button,
select the desired letter/number.

Press the

c

button to select the next

position.

Press the

.

button to complete this

procedure.

ARD
– – – –
BRT 1
BRT 2
CAN +
CAN 1
FILM
F 2
F 3
INFO
ITB
LIVE

P 25 C 32 32

n

ARD

Sel. station name

ɶ

ʺ

Select position < >
Terminate

Ǻ

C Channel
S

S-channel

P 25 nC 32 -32 – – – –

Select

ɶ

ʺ

Select position < >
Terminate

Ǻ

* The steps 1 and 2 explained on page 7 must already be executed.
