Page 1
TV Service Manual
3. Ergänzung / Supplement 3
Basic ++
CUC 1830
M 72 – 01
GCL7875 / VNM/VNA
CUC 1836
ST 63 – 270/8 IDTV 2
GCG1600 / VNA
M 70 – 282
GCI8975 / VNX
GCI8992 / VNX
ST 70 – 282/8
GCI8675 / VNX
GCI8692 / VNX
Zusätzlich erforderliche Unterlagen für den Komplettservice
Additionally required Service Documents for the Complete Service
Service
Manual
Basic ++
CUC 1836
Materialnr./Part No.
72010 026 9000
Materialnummer/Part Number 72010 026 9300
Änderungen vorbehalten/Subject to alteration • Printed in Germany HD
E-BS 32 0101
http://www.grundig.com
Ergänzung
Supplement
1
Materialnr./Part No.
72010 026 9100
Service
Manual
Sicherheit
Safety
Materialnr./Part No.
72010 800 0000
Service
Training
CUC 1828
Materialnr./Part No.
Ķ 72010 350 1700
ķ 72010 350 1800
CUC 1929
MW 82 – 45/8
GCM4500 / VNM
GCM4510 / VNM
Grundig Service
Technik:
TV
TV
SAT
VCR/LiveCam
HiFi/Audio
Car Audio
Telekommunikation
Planatron
Ersatzteil-Verkauf: ...Mo.-Fr. 8.00-19.00 Uhr
Fax:
(8.00-22.00 Uhr)
Telefon:
Fax:
Hotline Deutschland...
...Mo.-Fr. 8.00-18.00 Uhr
0180/52318-41
0180/52318-49
0180/52318-48
0180/52318-42
0180/52318-43
0180/52318-44
0180/52318-45
0180/52318-51
0180/52318-99
0180/52318-40
0180/52318-50
Page 2
Allgemeiner Teil / General Section CUC 1830 / 1836 / 1929
PFC (Power Factor Correction)
Für die in den Tabellen aufgeführten Geräte erfolgt die Umstellung auf
"PFC" während der laufenden Produktion und ist durch die Versionsnummer auf dem Aufkleber der Geräterückwand gekennzeichnet.
Versionsnummer für Geräte
Version number for Units
ohne / without PFC mit / with PFC
CUC 1806
DAVIO 55 M 55-290/8 IDTV
GCH4752 –– VNA
GCH4772 –– VNA
GCH4792 –– VNA
CUC 1828
MW 70-100/8
GCF2681 –– VNA
GCF2692 –– VNA
CUC 1829
M 84-211/8 IDTV
GCI1290 VNM VNA
CUC 1830
M 72-109
GCL2375 VNM VNA
TORONTO SE 7215
GCK6224 VNM VNA
GCK6275 VNM VNA
TORONTO SE 7215/8
GCK6175 VNM VNA
M 72-100 A VNA VNX
GCG5475
M 72-100/8 A
GCG5375 –– VNA
M 72-798 IDTV
GCI7172 VNM VNA
CUC 1836
M 70-282
GCI8975 VNM VNA
GCI8992 VNM VNA
ST 70-282/8
GCI8675 VNM VNA
GCI8692 VNM VNA
PFC (Power Factor Correction)
The sets shown in the tables will be changed to "PFC" during production.
This will be indicated by the version number on the label on the rear
panel.
Versionsnummer für Geräte
Version number for Units
ohne / without PFC mit / with PFC
CUC 1836
XENTIA 63 M 63-400/8
GCI0977 VNM VNA
ST 70-250 IDTV
GCK0375 VNM VNA
ST 70-260/8 IDTV
GCK1875 VNM VNA
ST 70-869 a IDTV
GCK2686 VNM VNA
DAVIO 70 M 70-290 IDTV
GCH3072 VNM VNA
DAVIO 70 M 70-290/8 IDTV
GCH3752 VNM VNA
GCH3772 VNM VNA
WIEN 100 SE 6320 IDTV/LOG
GCF0423 –– VNA
GCF0485 –– VNA
ST 63-270/8 IDTV
GCG1685 VNM VNA
ST 70-280 IDTV
GCI0368 VNM VNA
GCI0375 VNM VNA
BOSTON SE 7010 IDTV
GCI0475 VNM VNA
ST 70-898 NIC / DOLBY
GCL1975 VNA VNG
CUC 1929
MW 82-50/8
GCH0452 –– VNA
GCH0475 –– VNA
GCH0492 –– VNA
ST 70-298 IDTV
GCL2175 VNM VNA
2 GRUNDIG Service
Page 3
CUC 1830 / 1836 / 1929 Allgemeiner Teil / General Section
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Materialnummer 72010 800 0000, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
Für die auf der Titelseite aufgeführten Chassis gilt das Service Manual
CUC 1836 (Basic ++).
Diese Ergänzung dokumentiert die Unterschiede bzw. zusätzlichen
Bestückungen der Geräte.
Grundlage für den Service sind:
–Service Manual CUC 1836 (Materialnummer 72010 026 9000)
– 1. Ergänzung CUC 1836 (Materialnummer 72010 026 9100)
–Service Manual "Sicherheit" (Materialnummer 72010 800 0000)
Inhaltsverzeichnis
Seite
Hinweise ......................................................................................... 3
Modulauflistung – Service Manual mit Ergänzungen ...................... 4
Modulübersicht ................................................................................ 5
Technische Daten ........................................................................... 6
Chassisplatte .................................................................................. 8
Messpunkte Chassis ..................................................................... 15
Netz-Chassis ................................................................................. 17
Color-Chassis ............................................................................... 21
Feature Box 29504 209 0500 / 1500 ............................................ 25
Buchsenplatte 29305 008 4600 .................................................... 32
Bedieneinheit 29501 085 1300 ..................................................... 33
Netzschalterplatte 29305 165 7700 .............................................. 35
Ersatzteillisten ............................................................................... 37
The regulations and safety instructions shall be
valid as provided by the "Safety" Service Manual,
part number 72010 800 0000, as well as the
respective national deviations.
The Service Manual CUC 1836 (Basic ++) applies to the chassis
specified on the front page.
This Manual describes the differences and the additionally fitted
components of the TV receivers.
Basic instructions for servicing are given in the:
–Service Manual CUC 1836 (Part number 72010 026 9000)
–1st Supplement CUC 1836 (Part number 72010 024 9100)
–Service Manual “Safety” (Part number 72010 800 0000)
Table of Contents
Page
Notes ............................................................................................... 3
List of Modules – Service Manual with Supplements ...................... 4
Module List ...................................................................................... 5
Technical Data ................................................................................ 6
Chassis Board ................................................................................. 8
Testpoints Chassis ........................................................................ 15
Mains Chassis ............................................................................... 17
Colour Chassis .............................................................................. 21
Feature Box 29504 209 0500 / 1500 ............................................ 25
Socket Board 29305 008 4600 ..................................................... 32
Control Unit 29501 085 1300 ........................................................ 33
Mains Switch Board 29305 165 7700 ........................................... 35
Spare Parts Lists ........................................................................... 37
Hinweise
Vor dem Öffnen des Gehäuses zuerst den Netzstecker ziehen!
Leitungsverlegung
Bevor Sie die Leitungen und insbesondere die Masseleitungen lösen,
muss die Leitungsverlegung zu den einzelnen Baugruppen wie z.B.
Chassis, Netzschalterplatte, Bedieneinheit, Bildrohrplatte, Ablenkeinheit, Lautsprecher usw. beachtet werden.
Nach erfolgter Reparatur ist es notwendig, die Leitungsführung wieder
in den werkseitigen Zustand zu versetzen um evtl. spätere Ausfälle
oder Störungen zu vermeiden.
Netzkabel
Diese Geräte dürfen nur mit dem Original-Netzanschlusskabel mit
integrierter Entstördrossel betrieben werden. Dieses Netzkabel verhindert Störungen aus dem Netz und ist Bestandteil der Geräte-
zulassung. Im Ersatzfall bestellen Sie bitte ausschließlich das Netzkabel laut Ersatzteilliste.
GRUNDIG Service 3
Notes
Before opening the cabinet disconnect the mains plug!
Wiring
Before disconnecting any leads and especially the earth connecting
leads observe the way they are routed to the individual assemblies like
the chassis, mains switch panel, keyboard control panel, picture tube
panel, deflection unit, loudspeaker and so on.
On completion of the repairs the leads must be laid out as originally
fitted at the factory to avoid later failures or disturbances.
Mains cable
The TV receiver must only be operated with an original mains connecting
cable with an interference suppressor choke integrated in the mains
plug.This mains cable prevents interference from the mains supply and
is part of the product approval. For replacement please order exclusively
the mains connecting cable specified in the spare parts list.
Page 4
Allgemeiner Teil / General Section CUC 1830 / 1836 / 1929
Modulauflistung – Service Manual mit Ergänzungen
List of Modules – Service Manual with Supplements
Modul
Module
Signal-Baustein
Signal Module
Buchsenplatte
Socket Board
Feature Box
Bedieneinheit
Control Unit
Bildrohrplatte
CRT Panel
Standby-Netzteil
Standby Power Supply
Netzschalterplatte
Mains Switch Board
Keyboard
Geschw.-Moduator-Platte
Velocity Moduation Board
Fokussierungsplatte
VGA-Baustein
VGA Module
PIP-Baustein
PIP Module
SAT-Baustein
SAT Module
Materialnummer
Part Number
29504 102 3400 – Seite / Page 33
29504 162 3400
29504 102 3600
29504 162 3600
29305 008 4000
29305 008 4600
29504 103 4201 Seite / Page 3-23 ––
29504 209 0500
29504 209 1500
29501 082 7500
29501 085 0700
29504 085 1300
29305 122 1700
29305 122 2000
29304 050 2900
29304 050 8500
29305 165 7700
29501 083 2400
29305 108 0700
29305 025 3600
29305 160 3600
29504 106 5500
29504 106 2400
Service Manual
Basic ++
CUC 1836 / 1929
72010 026 9000 72010 026 9100 72010 026 9300
Seite / Page 3-35 ––
Seite / Page 3-39 ––
– Seite / Page 16 –
––Seite / Page 32
––Seite / Page 25
– Seite / Page 13 –
– Seite / Page 13 –
––Seite / Page 37
Seite / Page 3-55 ––
Seite / Page 3-57 ––
Seite / Page 3-13 ––
– Seite / Page 11 –
––Seite / Page 39
– Seite / Page 8 –
Seite / Page 3-29 ––
Seite / Page 3-30 ––
Seite / Page 3-53 ––
Seite / Page 3-47 ––
Seite / Page 3-43 ––
1. Ergänzung
Supplement 1
Basic ++
CUC 1836 / 1830
3. Ergänzung
Supplement 3
Basic ++
CUC 1830 / 1836 / 1929
4 GRUNDIG Service
Page 5
CUC 1830 / 1836 / 1929 Allgemeiner Teil / General Section
Modulübersicht / Module List
Bestell-Nr.
Order No.
Chassis-Nr.
Chassis No.
Tuner
abhängig von Signal-Baustein
dependent on Signal Module
Signal-Baustein
Signal Module
Feature Box
Bedieneinheit
Control Unit
Materialnummer
Part Number
29504 201 2100
29504 201 3100
29504 301 0100
29504 102 3400
29504 102 3600
29504 162 3600
29504 162 3400
29504 103 4201
29504 209 0500
29504 209 1500
29501 082 7500
M 72 - 01
CUC 1830
VNM/VNA
GCL7875 GCG1600
29704 096 7100
29704 015 2700
L
29504 102 3400L 29504 162 3400
ww / or
29504 102 3400
L
29504 102 3600
ww / or
ST 63 - 270/8
IDTV 2
CUC 1836
VNA
29704 015 3300 29704 015 2000
M 70 - 282
CUC 1836
VNX
GCI8975
GCI8992
ST 70 - 282/8
CUC 1836
VNX
GCI8675
GCI8692
29704 015 2100
29704 015 2200
––
MW 82 - 45/8
CUC 1929
VNM
GCM4500
GCM4510
29701 096 8100
L
29504 162 3400
––––
ww / or
29504 162 3600L 29504 102 3600L 29504 162 3600L 29504 162 3600
––––
•••••
–
ww / or
•
–––
––
••••
–
•
–––
ww / or
•
–
Keyboard
Bildrohrplatte
CRT Panel
Standby-Netzteil
Standby Power Supply
Netzschalterplatte
Mains Switch Panel
Buchsenplatte
Socket Board
Fokussierungsplatte
Focusing Bosrd
Geschw.-Modulator-Platte
Velocity Modulation Board
29501 085 0700
29501 085 1300
29501 083 2400
29305 122 1700
29305 122 2000
29304 050 2900 ww / or
29304 050 8200 ww / or
29304 050 8500
29305 165 7700
29305 008 4000
29305 008 4600
29305 025 3600
29305 108 0700
––
•
––––
••••
––––
••••
––––
––––
•
––––
––––
••
–
––––
•
–
•
–––
–––
ww / or
ww / or
–
•
•
––––
•
•
TP 800 29642 061 0104
TP 810 C 29642 061 1001
VGA2 (nachrüstbar)
VGA2 (retrofittable)
PIP 3a (nachrüstbar)
PIP 3a (retrofittable)
SER 150 ET (nachrüstbar)
SER 150 ET (retrofittable)
GRUNDIG Service 5
G.AD 4200
G.AF 6500
G.AD 2500
–
•
•
–
–––
•••
•••••
•••••
•••••
Page 6
Allgemeiner Teil / General Section CUC 1830 / 1836 / 1929
Technische Daten / Technical Data
Bildröhre / Picture Tube
Sichtbares Bild
Visible picture
Bildschirmdiagonale
Screen diagonale
Ablenkwinkel
Deflection angle
Zeilenfrequenz
Line frequency
Bildwechselfrequenz
Vertical frequency
Formatumschaltung
Format switching
Elektronik / Electronic
Programmspeicherplätze
Programme positions
Perfect clear, Blue stretch,
Gamma adjustment
AV-Auswertung
AV evaluation
Tuner
TV-Normen
TV-Standards
Stereo-Systeme
Stereo systems
Videotext
Teletext
SAT nachrüstbar
SAT retrofittable
PIP-Baustein nachrüstbar
PIP Module retrofittable
Musikleistung
Music power
Anschlüsse Front / Connections Front
72cm (29"), Megatron, Super Flat
Black Line S, CCS, Invar
Bildformat 4:3, 16:9, 4:3/16:9 auto
(über Euro-AV-Buchse),
(für Letterbox- und PAL-plus-Programm).
Standard 4:3, 16:9, 4:3/16:9 auto
(for letterbox- and PAL plus-program)
179 TV/SAT + 39 Radio + 3 AV
(bei Nachrüstung SAT/
when retrofitted with SAT)
8 Seiten TOP/FLOF-text mit VPS,
8 pages TOP/FLOF-text with VPS,
M 72 - 01
CUC 1830
VNM/VNA
68cm 59cm 66cm
110° 110° 110°
32kHz 32kHz 32kHz
100Hz 100Hz 100Hz
Panorama-Zoom
(via Euro-AV-socket),
Panorama Zoom
99 + 3 AV
ja / yes ja / yes ja / yes
PAL / SECAM /
NTSC 4,43MHz,
B/G
Deutsch A2
German A2
SER 150 ET SER 150 ET SER 150 ET
PIP 3 a PIP 3 a PIP 3 a
2 x 20W 2 x 20W 2 x 20W
ST 63 - 270/8 IDTV 2
CUC 1836
VNA
63cm (25"), FTS,
Blackline FX
Bildformat 4:3, 16:9, 4:3/16:9 auto
(über Euro-AV-Buchse),
(für Letterbox- und PAL-plus-Programm).
auf jeden Programmplatz programmierbar
programmable for every programme position
PLL-Frequenz synthesizer tuning UHF / VHF
PLL-frequency synthesizer tuning UHF / VHF
Panorama-Zoom
Standard 4:3, 16:9, 4:3/16:9 auto
(via Euro-AV-socket),
Panorama Zoom
(for letterbox- and PAL plus-program)
99 + 3 AV
179 TV/SAT + 39 Radio + 3 AV
(bei Nachrüstung SAT/
when retrofitted with SAT)
PAL / SECAM /
NTSC 4,43MHz, via AV 3,58MHz
B/G, I, D/K/K', L/L'
Deutsch A2 / German A2
NICAM 5,85 (BG, L) + 6,52MHz (I)
8 Seiten TOP/FLOF-text mit VPS,
8 pages TOP/FLOF-text with VPS,
B/G/D/K
M 70 - 282
70cm (28"), FTS, Megatron
Black Line S, CCS, Invar
Bildformat 4:3, 16:9, 4:3/16:9 auto
(über Euro-AV-Buchse),
(für Letterbox- und PAL-plus-Programm).
Panorama-Zoom
Standard 4:3, 16:9, 4:3/16:9 auto
(via Euro-AV-socket),
Panorama Zoom
(for letterbox- and PAL plus-program)
179 TV/SAT + 39 Radio + 3 AV
(bei Nachrüstung SAT/
when retrofitted with SAT)
PAL / SECAM /
NTSC 4,43MHz, via AV 3,58MHz
B/G, I, D/K/K', L/L'
Deutsch A2 / German A2
NICAM 5,85 (BG, L) + 6,52MHz (I)
8 Seiten TOP/FLOF-text mit VPS,
8 pages TOP/FLOF-text with VPS,
CUC 1836
VNX
99 + 3 AV
B/G/D/K
Kopfhörer
Headphones
Video IN 1 x Cinch in AV 3-Position 1 x Cinch in AV 3-Position 1 x Cinch in AV 3-Position
Audio IN 2 x Cinch 2 x Cinch 2 x Cinch
Anschlüsse Rückwand / Connections Rear Panel
Euro AV 1(schwarz/black)
Euro AV 2 (orange)
Standard VGA
2 x Cinch NF/in
Netzteil / Mains Stage
Netzspannung (Regelber.)
Mains voltage (variable)
Netzfrequenz
Mains frequency
Öko-Schalter
Eco switch
Leistungsaufnahme
Power consumption
Standby ca. 6W ca. 7W ca. 6W
FBAS-Ein-/Ausgang, RGB-Eingang
FBAS-Ein-/Ausgang, RGB-Eingang
Stereo 3,5mm Klinkenbuchse, Lautstärke regelbar, individuelle Tonkanalwahl bei 2-Ton-Empfang
Stereo 3.5mm jacksocket, adjustable volume, individual channel selection with dual-sound broadcasts
S-Video Eingang, Megalogic
CCVS in-/output, RGB input,
S-Video input, Megalogic
S-Video Eingang,
CCVS in-/output, RGB input,
S-Video input
VGA 2 nachrüstbar
VGA 2 retrofitting possible
165…265V 165…265V 165…265V
50 / 60Hz 50 / 60Hz 50 / 60Hz
ja / yes ja / yes ja / yes
ca. 125W ca. 110W ca. 125W
FBAS-Ein-/Ausgang, RGB-Eingang
S-Video Eingang, Megalogic
CCVS in-/output, RGB input,
S-Video input, Megalogic
FBAS-Ein-/Ausgang, RGB-Eingang
S-Video Eingang,
CCVS in-/output, RGB input,
S-Video input
VGA 2 nachrüstbar
VGA 2 retrofitting possible
FBAS-Ein-/Ausgang, RGB-Eingang
S-Video Eingang, Megalogic
CCVS in-/output, RGB input,
S-Video input, Megalogic
FBAS-Ein-/Ausgang, RGB-Eingang
CCVS in-/output, RGB input,
VGA 2 retrofitting possible
S-Video Eingang,
S-Video input
VGA 2 nachrüstbar
6 GRUNDIG Service
Page 7
CUC 1830 / 1836 / 1929 Allgemeiner Teil / General Section
Technische Daten / Technical Data
ST 70 - 282/8
CUC 1836
VNX
Bildröhre / Picture Tube
Sichtbares Bild
Visible picture
Bildschirmdiagonale
Screen diagonale
Ablenkwinkel
Deflection angle
Zeilenfrequenz
Line frequency
Bildwechselfrequenz
Vertical frequency
Bildformat 4:3, 16:9, 4:3/16:9 auto
Formatumschaltung
Format switching
Elektronik / Electronic
Programmspeicherplätze
Programme positions
Perfect clear, Blue stretch,
Gamma adjustment
AV-Auswertung
AV evaluation
Tuner
TV-Normen
TV-Standards
Stereo-Systeme
Stereo systems
Videotext
Teletext
SAT nachrüstbar
SAT retrofittable
PIP-Baustein nachrüstbar
PIP Module retrofittable
Musikleistung
Music power
Anschlüsse Front / Connections Front
Kopfhörer
Headphones
Video IN 1 x Cinch in AV 3-Position 1 x Cinch in AV 3-Position
Audio IN 2 x Cinch 2 x Cinch
Anschlüsse Rückwand / Connections Rear Panel
Euro AV 1(schwarz/black)
Euro AV 2 (orange)
Standard VGA
2 x Cinch NF/in
Netzteil / Mains Stage
Netzspannung (Regelber.)
Mains voltage (variable)
Netzfrequenz
Mains frequency
Öko-Schalter
Eco switch
Leistungsaufnahme
Power consumption
Standby ca. 6W ca. 7W
(für Letterbox- und PAL-plus-Programm).
Standard 4:3, 16:9, 4:3/16:9 auto
(for letterbox- and PAL plus-program)
179 TV/SAT + 39 Radio + 3 AV
NTSC 4,43MHz, via AV 3,58MHz
NICAM 5,85 (BG, L) + 6,52MHz (I)
8 Seiten TOP/FLOF-text mit VPS,
8 pages TOP/FLOF-text with VPS,
FBAS-Ein-/Ausgang, RGB-Eingang
S-Video Eingang, Megalogic
CCVS in-/output, RGB input,
FBAS-Ein-/Ausgang, RGB-Eingang
CCVS in-/output, RGB input,
66cm 76cm
70cm (28")
FST, Black Line D
110° 106°
32kHz 32kHz
100Hz 100Hz
(über Euro-AV-Buchse),
Panorama-Zoom
(via Euro-AV-socket),
Panorama Zoom
99 + 3 AV
(bei Nachrüstung SAT/
when retrofitted with SAT)
ja / yes ja / yes
auf jeden Programmplatz programmierbar
programmable for every programme position
PLL-Frequenz synthesizer tuning UHF / VHF
PLL-frequency synthesizer tuning UHF / VHF
PAL / SECAM /
B/G, I, D/K/K', L/L'
Deutsch A2 / German A2
B/G/D/K
SER 150 ET SER 150 ET
PIP 3 a PIP 3 a
2 x 20W 2 x 20W
Stereo 3,5mm Klinkenbuchse, Lautstärke regelbar,
individuelle Tonkanalwahl bei 2-Ton-Empfang
Stereo 3.5mm jacksocket, adjustable volume,
individual channel selection with dual-sound broadcasts
S-Video input, Megalogic
S-Video Eingang,
S-Video input
VGA 2 nachrüstbar
VGA 2 retrofitting possible
165…265V 165…265V
50 / 60Hz 50 / 60Hz
ja / yes ja / yes
ca. 125W ca. 135W
(für Letterbox- und PAL-plus-Programm).
(for letterbox- and PAL plus-program)
M 82 - 45/8
CUC 1929
VNM
82cm (32"), Megatron, Super Flat
Black Matrix, CCS, Invar
Bildformat 4:3, 16:9, 4:3/16:9 auto
(über Euro-AV-Buchse),
Panorama-Zoom
Standard 4:3, 16:9, 4:3/16:9 auto
(via Euro-AV-socket),
Panorama Zoom
99 + 3 AV
179 TV/SAT + 39 Radio + 3 AV
(bei Nachrüstung SAT/
when retrofitted with SAT)
PAL / SECAM /
NTSC 4,43MHz, via AV 3,58MHz
B/G, I, D/K/K', L/L'
Deutsch A2 / German A2
NICAM 5,85 (BG, L) + 6,52MHz (I)
8 Seiten TOP/FLOF-text mit VPS,
8 pages TOP/FLOF-text with VPS,
FBAS-Ein-/Ausgang, RGB-Eingang
FBAS-Ein-/Ausgang, RGB-Eingang
B/G/D/K
S-Video Eingang, Megalogic
CCVS in-/output, RGB input,
S-Video input, Megalogic
S-Video Eingang,
CCVS in-/output, RGB input,
S-Video input
VGA 2 nachrüstbar
VGA 2 retrofitting possible
GRUNDIG Service 7
Page 8
Allgemeiner Teil / General Section CUC 1830 / 1836 / 1929
Bestückungskoordinaten der Bauteile auf dem
Chassis
- Die Koordinaten X und Y sind sowohl als metrische Koordinaten für die Originalplatine in Millimeter, als auch als absolute
Koordinaten für die Abbildungen der Platinen verwendbar.
Chassis Platte
Koordinaten für die Bauteile der Bestückungsseite (Oberseite)
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
AV01 99 245
AV02 40 245
B 224 159
BR01 210 127
BR02 269 127
BR03 146 233
BR04 58 219
BR05 132 133
BR06 80 218
BR07 197 156
BR08 130 202
BR09 192 123
BR10 99 118
BR11 34 184
BR12 54 191
BR13 129 66
BR14 102 132
BR15 128 41
BR16 78 213
BR17 125 225
BR18 60 68
BR19 207 150
BR20 101 121
BR21 68 22
BR22 63 26
BR23 65 22
BR24 69 215
BR25 86 209
BR26 154 244
BR27 231 158
BR28 100 197
BR29 45 201
BR30 110 203
BR31 64 250
BR32 11 210
BR33 197 114
BR34 57 172
BR35 194 121
BR36 45 162
BR37 45 154
BR38 19 159
BR39 19 157
BR40 65 122
BR41 231 146
BR42 250 169
BR43 353 158
BR44 90 113
BR45 77 148
BR46 269 16
BR47 136 43
BR113 189 157
BR114 196 24
BR115 166 71
BR116 167 22
BR117 177 173
BR118 175 170
BR119 169 180
BR120 169 133
BR122 154 150
BR124 76 124
BR125 140 72
BR126 158 173
BR127 192 216
BR129 232 60
BR130 167 19
BR132 160 52
BR133 61 183
BR135 41 39
BR136 65 80
BR137 164 69
BR138 165 175
BR139 217 228
BR140 144 15
BR141 175 151
BR145 134 124
BR146 64 109
BR147 109 119
BR151 58 58
BR154 111 174
BR155 134 23
BR158 131 174
BR159 55 226
BR160 58 226
BR161 61 226
BR163 142 83
BR165 81 122
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
BR167 137 137
BR169 64 106
BR173 55 133
BR174 58 131
BR176 112 105
BR177 73 124
BR178 43 63
BR179 121 130
BR180 123 131
BR181 150 98
BR182 155 66
BR186 50 132
BR187 53 132
BR188 124 38
BR189 33 60
BR192 66 111
BR193 78 123
BR195 165 172
BR196 266 161
BR197 278 11
BR198 177 46
BR199 219 242
BR200 302 154
BR201 52 26
BR202 71 123
BR204 113 161
BR205 107 119
BR207 109 25
BR208 125 21
BR209 68 123
BR210 104 117
BR211 80 21
BR212 123 21
BR213 127 23
BR214 149 96
BR215 86 120
BR216 111 102
BR217 188 111
BR218 299 189
BR219 177 192
BR220 285 126
BR221 200 149
BR222 203 152
BR223 237 58
BR224 137 101
BR225 159 191
BR250 45 132
BR251 46 157
BR252 90 125
BR254 121 88
BR255 303 179
BR256 303 177
BR257 294 152
BR258 229 190
BR259 159 9
BR260 93 75
BR261 50 175
BR262 113 27
BR264 78 21
BR266 256 159
BR267 206 163
BR268 150 75
BR269 92 124
BR270 157 101
BR271 133 169
BR272 130 177
BR273 154 171
BR274 84 157
BR275 174 191
BR277 301 41
BR278 284 44
BR279 159 206
BR280 152 224
BR281 134 143
BR282 156 40
BR283 186 233
BR284 177 219
BR285 283 90
BR286 22 98
BR287 147 86
BR288 173 28
BR289 252 36
BR291 173 150
BR294 123 146
BR21102 355 158
BRU255 111 113
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
C21202 310 159
C21212 337 160
C21232 244 165
C32327 19 211
C32332 11 193
C32343 38 210
C32346 31 211
C32355 48 168
C32360 25 211
C32364 12 175
C34501 98 188
C34506 101 163
C34509 91 188
C34510 94 195
C34511 88 195
C34521 113 188
C34522 107 188
C34523 103 188
C40001 13 95
C40003 10 107
C40006 14 15
C40011 12 81
C40013 31 49
C40021 12 75
C40029 41 30
C40031 30 89
C40032 45 89
C40033 36 71
C41006 28 141
C41007 33 141
C41012 36 116
C41014 30 103
C41031 23 111
C43002 45 226
C43007 50 224
C43012 35 226
C43017 40 221
C43022 29 223
C43027 23 223
C43032 10 222
C43037 17 223
C43066 102 228
C43068 85 222
C43079 103 222
C43082 128 221
C43084 78 209
C43093 114 230
C43098 69 240
C46007 127 96
C50012 198 189
C50014 196 202
C50026 200 173
C50027 171 204
C52001 205 211
C52002 166 231
C52003 192 238
C52004 176 240
C53006 283 210
C53007 265 210
C53009 291 210
C53011 308 242
C53012 251 230
C53013 235 220
C53016 326 249
C53017 353 240
C53018 338 236
C53019 344 236
C53071 271 228
C53072 244 228
C53073 255 204
C54001 350 200
C54002 351 173
C55003 228 196
C55004 218 204
C55011 234 184
C55012 238 189
C55013 235 197
C58001 215 197
C58004 219 167
C58011 231 174
C58012 229 182
C58013 224 174
C58014 222 183
C58021 216 189
C58023 211 169
C60001 270 59
Assembly Coordinates of the Components at
the Chassis
- The X and Y coordinates can be used as both metric coordinates in mm for the original circuit board and absolute
coordinates for the diagrams of the circuit boards.
Chassis Board
Coordinates of the Components on the Components Side (Top Side)
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
C60002 317 24
C60006 333 51
C60007 338 24
C60009 334 76
C60011 307 25
C60012 299 33
C60013 300 13
C60014 282 11
C60016 294 10
C60018 285 38
C60019 201 94
C60021 224 96
C60023 218 48
C60024 229 48
C60026 252 53
C60027 241 53
C60028 249 78
C60029 217 56
C61002 196 32
C61004 202 16
C61008 170 56
C61011 321 131
C61012 317 141
C61013 316 151
C61016 314 90
C61017 333 142
C61018 333 129
C61021 305 145
C61022 284 138
C61026 281 111
C61027 267 137
C61032 167 91
C61036 241 114
C61037 211 136
C61042 166 117
C61052 169 64
C61056 303 110
C61057 300 137
C61061 255 134
C61062 228 135
C61063 242 137
C61064 222 149
C61066 255 139
C61301 242 12
C61317 163 32
C62021 247 26
C62022 209 41
C62048 349 109
C65542 172 35
C70509 164 221
C70511 160 164
C70516 164 142
C70527 154 34
C80059 123 51
C80081 161 15
D21212 350 157
D32356 55 99
D32357 61 84
D40006 42 19
D50013 189 199
D52006 196 245
D53008 286 191
D53019 341 236
D53071 238 247
D53072 210 247
D54001 355 194
D55012 229 217
D60006 342 45
D60012 291 28
D60014 289 15
D60019 212 92
D60021 212 98
D60023 250 42
D61011 316 131
D61012 313 136
D61016 337 117
D61021 298 150
D61026 282 117
D61033 296 171
D61036 254 117
D61056 309 117
D61061 254 129
D61062 238 152
D61066 255 145
D61067 245 153
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
D70508 159 152
D81000 81 109
DX60006 340 45
DX60023 247 45
IC32300 30 185
IC32310 47 102
IC34510 106 174
IC40020 23 72
IC41010 33 125
IC43080 117 213
IC50010 187 177
IC55010 231 206
IC58010 213 180
IC60010 308 13
IC61001 184 30
IC61006 184 65
IC61030 199 118
IC61040 227 118
IC61050 184 102
IC61310 231 13
IC80040 119 44
IC80050 99 75
IC80060 85 40
IC80065 136 49
IC80070 136 60
IC80090 82 141
J 243 191
J07 216 159
L32342 42 167
L34517 126 133
L46021 76 85
L53001 264 246
L53002 269 240
L53003 286 240
L53011 297 230
L53012 256 159
L53021 275 191
L53074 279 160
L55014 229 233
L60006 311 40
L60028 209 75
L61011 311 103
L61016 317 103
L61021 303 100
L61026 279 89
L61036 274 89
L61056 297 89
L61061 288 89
L61066 292 89
L70508 174 133
L70555 48 127
LX60028 209 75
M 211 159
NETZ 231 33
OK60031 262 18
OK60046 262 9
Q32305 20 169
Q80055 120 59
R21101 354 215
R21102 354 158
R21211 323 158
R21212 344 167
R21213 346 159
R21214 326 159
R21216 238 174
R21221 192 151
R21227 177 149
R21231 194 152
R32315 129 26
R32357 61 68
R32359 49 145
R40013 48 55
R40017 13 33
R40027 13 45
R40031 38 80
R41016 41 123
R43004 124 229
R43098 129 247
R50007 165 199
R50008 161 199
R50027 170 189
R50028 170 156
R50029 166 159
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
R52001 206 198
R52003 168 240
R52006 205 240
R52007 294 246
R53002 269 235
R53003 286 235
R53008 290 195
R53011 300 235
R53012 252 181
R53016 260 179
R53021 281 179
R54001 347 188
R55001 325 165
R55002 325 167
R55004 224 201
R55012 223 201
R55014 225 218
R58001 215 215
R58002 220 224
R60001 330 15
R60002 330 9
R60006 322 39
R60007 336 58
R60008 331 41
R60012 285 31
R60016 286 24
R60028 228 74
R60029 261 32
R60032 316 13
R61001 190 13
R61018 335 126
R61022 54 47
R61031 171 105
R61033 296 169
R61041 196 130
R61051 171 78
R61062 234 151
R61063 241 152
R61312 224 12
R61313 216 12
R61314 203 8
R61316 244 7
R62049 250 104
R65541 152 27
R65542 167 25
R80085 112 99
SI60001 263 59
SI60201 228 88
SI61022 54 20
SI61026 274 102
SI61036 264 108
SI61056 295 101
SI61061 284 101
SI61066 292 111
SIGNALBST 66 173
STBR 348 138
STCT01 53 204
STGM03 109 144
STGM04 170 45
STH 48 11
STIR/KB 93 11
STKB 115 11
STLL 18 134
STLR 18 146
STMP 68 11
STOS 133 11
STPI01 92 211
STPI02 92 148
STRGB 120 196
STTEST 122 119
STUB02 192 47
STVGA03 112 43
STVGA02 128 154
T21211 329 158
T40010 22 35
T50028 185 148
T50029 185 208
T52003 184 237
T53001 280 246
T60006 336 65
TR52001 205 226
TR53010 321 206
TR60001 299 64
8 GRUNDIG Service
Page 9
CUC 1830 / 1836 / 1929 Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams
Chassisplatte / Chassis Board BestŸckungsseite, Ansicht von oben / Component Side, Top View
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300
X
0
Y
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
10
20
30
40
50
60
70
80
90
LOETRICHTUNG
T40010
EB
10
2
BR286
14
1
C41006
1
BR036
10
C32360
C43022
C43027
MI-
11
1
IC40020
C41012
C41031
IC41010
L32342
44
C32346
C43012
D40006
C40031
C41014
58
C41007
BR011
C32343
C43017
T 1,6A
SI61022
BR037
19
C43002
R41016
BR250
13
ST-H
BR201
C40029
BR135
C40013
R40013
BR189
BR178
BR018
C40033
R40031
D32356
13
BR169
BR146
BR192
L70555
BR186
R32359
BR251
BR261
IC32300
61
60
BR029
BR004
C43007
BR159
15
BR023
BR022
29304-730.13/4B(14)
R61022
17 32
BR151
R32357
D32357
C40032
IC32310
BR187
C32355
BR136
BR209
BR174
BR173
BR040
15
BR034
BR133
BR012
1
15
ST-CT1
BR024
BR161
BR160
BR031
17
BR021
ST-MP
BR264
IC80060
32
33
L46021
BR202
BR124
BR177
58
BR045
BR193
IC80090
ST-IR/KB
12
53
BR176
BR010
11
54
BR014
116
BR020
BR210
BR207
Q80055
BR205
1
BR211
BR260
IC80050
D81000
BR269
BR044
BR215
BR252
BR165
14
19
ST-PI2
ST-GM3
C34506
BR274
IC34510
BR204
SIGNAL-BST
C34501
C34509
C34511
C34510
C43068
BR025
1
C43079
C43066
ST-PI1
C43084
BR016
BR006
AV1
C43098
220
121
C34523
BR028
6
110
IC43080
BR017
C43093
C40006
R40017
R40027
C40021
C40011
A
C40001
E
C40003
+B2
2
ST-LL
2
ST-LR
BR039
BR038
Q32305
C32364
26
27 43
C32332
BR032
C32327
C43032
C43037
220
AV2
121
13
ST-KB
BR262
2
1
ST-VGA3
1
R80085
BRU255
ST-TEST
BR147
BR294
6
BR154
C34522
C34521
BR030
BR212
BR188
IC80040
31
75
74
BR254
BR216
4
BR179
BR158
ST-RGB
C43082
R43004
BR208
BR015
C80059
BR013
C46007
1
BR180
ST-VGA2
BR271
17
BR008
1120
2
1
BR213
R32315
58
IC80065
58
IC80070
BR125
BR163
BR214
BR181
BR224
BR005
L34517
13
BR272
R43098
ST-OS
BR140
BR155
C70527
BR047
14
14
BR268
1
BR145
BR167
BR281
43
R65541
2
42
BR003
BR182
BR270
BR122
BR273
BR280
BR259
C80081
C61317
BR282
ST-GM4
BR132
C61008
C61032
BR287
C70511
BR126
R50008
BR279
C70509
BR026
R65542
R61051
R61031
C61042
C70516
D70508
BR195
BR138
BR225
C52002
BR130
BR116
BR288
2
BR137
L70508
BR120
BR291
R50029
BR119
R50027
R50007
C50027
1
BR198
C61052
BR115
BR141
R50028
BR118
BR275
BR284
R52003
CUC 1830 / 1836 / 1929 Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams
310 320 330 340 350 360
R61001
IC61001
C65542
1 3
C61002
ST-UB2
12
1 3
IC61006
IC61050
1 3
BR217
BR035
R61041
BR113
BE
T50028
R21227
BR117
BR219
C52004
R21221
IC50010
26
1 7
D50013
T50029
BE
BR127
BR283
CEB
C52003
T52003
D52006
R61314
R61313
BR114
BR033
BR007
R21231
C50014
46
C61004
C62022
46
63
C60019
D60021
BR009
BR221
C52001
D60019
IC61030
13
BR001
C61037
BR019
BR222
C61064
M
1
C58023
C50026
BR267
IC58010
14
C50012
C58021
R52001
TR52001
58
C61301
14
R61312
14
C60023
C60024
C60029
R60028
L60028
SI60201
12
13
T0,1A
IC61040
C61062
1J71
B
C58004
C58013
58
C58014
C58012
BR258
C58001
R55004
C55004
R55012
R58001
R55014
13
87
R58002
BR139
R52006
BR199
L55014
D53072
IC61310
C62021
NETZ
1
BR129
BR223
UB1
13
BR041
R61062
BR027
C55011
C55003
58
IC55010
C53013
D53071
C61036
C61063
D61062
R61063
C21232
R21216
C55013
C60028
C53072
C60021
C58011
C55012
14
D55012
BR197
C60016
C60014
D60014
R61316
13
OK60046
13
OK60031
BR046
46
R60016
46
R60029
C60018
C60001
L61036
T2,5A
SI61026
D61026
R60012
11
121314
BR285
L61026
T2A
SI61061
C61026
BR278
9
15
L61066
L61061
SI61066
PF1
C60027
R62049
PF2
C60026
D61036
BR289
D60023
T2A
SI60001
SI61036
T2,5A
T2A
L53012
L53002
BR002
BR266
L53021
C53073
C53007
C61027
BR196
R53016
L53074
H-SHIFT/2H-SHIFT/1
H-SHIFT/3
C53071
T53001
BR220
C61022
BR257
R61033
R53021
D53008
R53008
C53006
L53011
R53003R53002
R52007
BE
D61061
C61061
C61066
D61066
D61067
BR042
R53012
18
J
C53012
L53001
C60013
D60012
BR277
7
16
C61057
BR218
C53009
R53011
L53003
C60012
17
L61056
T2,5A
SI61056
C61056
C61021
BR200
D61033
BR255
IC60010
58
C60011
L60006
536
4
181920
L61021
L61011
D61056
D61021
C21202
R55001
BR256
C53011
R60032
14
C60002
21
C61016
L61016
D61011
C61011
D61012
C61012
R21211
C61013
R55002
R60006
1
22
C61018
R60008
TR60001
M/A
R21214
T21211
C60006
R60007
D61016
CE
C53016
R60002
R60001
C60007
D60006
M/B
C60009
D
SG
T60006
C62048
R61018
1
1
C61017
ST-BR
6
R21102
BR043
D21212
C54002
R54001
D54001
C54001
BR21102
R21213
C21212
R21212
R21101
TR53010
C53019
C53018
D53019
C53017
260
GRUNDIG Service
9
GRUNDIG Service
10
Page 10
Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams CUC 1830 / 1836 / 1929
Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams CUC 1830 / 1836 / 1929
Chassisplatte / Chassis Board
Koordinaten fŸr die Bauteile der Lštseite
(Unterseite)
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CBR02 130 77
CBR04 153 184
CBR09 158 181
CBR23 83 107
CBR24 49 122
CBR25 83 152
CBR26 85 117
CBR27 161 227
CBR29 128 141
CBR30 139 163
CBR31 72 153
CBR32 120 51
CBR33 58 148
CBR34 104 202
CBR35 86 173
CBR38 91 171
CBR41 155 250
CBR42 122 149
CBR43 62 246
CBR44 101 63
CBR46 104 215
CBR47 120 153
CBR48 138 124
CBR49 82 218
CBR50 125 226
CBR51 117 142
CBR52 127 213
CBR53 135 240
CBR54 158 250
CBR55 116 188
CBR56 9 167
CBR57 73 185
CBR58 81 167
CBR60 313 159
CBR61 96 119
CBR62 71 142
CBR63 80 139
CBR67 120 179
CBR68 123 142
CBR69 9 95
CBR70 120 81
CBR71 100 150
CC21206 317 161
CC21221 192 164
CC21231 200 165
CC21233 354 133
CC32301 11 181
CC32302 15 177
CC32303 22 183
CC32306 25 182
CC32307 38 153
CC32308 35 161
CC32309 41 185
CC32310 38 186
CC32311 26 155
CC32312 21 161
CC32313 19 157
CC32314 35 186
CC32315 32 186
CC32316 11 162
CC32317 20 166
CC32318 15 173
CC32326 44 198
CC32328 25 203
CC32331 48 198
CC32333 9 194
CC32336 22 204
CC32337 19 204
CC32338 28 192
CC32339 30 193
CC32341 36 181
CC32345 48 179
CC32347 29 205
CC32348 24 188
CC32350 46 169
CC32355 47 105
CC32365 11 185
CC32370 45 108
CC34502 119 164
CC34503 115 163
CC34504 112 163
CC34507 101 163
CC34517 105 194
CC34518 102 172
CC34519 105 172
CC34520 108 172
CC34524 131 135
CC34525 118 129
CC34526 126 129
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CC34541 96 159
CC34542 87 158
CC34543 88 162
CC34550 117 156
CC40002 20 86
CC40004 11 86
CC40012 24 81
CC40013 32 60
CC40014 32 65
CC40017 13 33
CC40022 30 73
CC40027 10 32
CC40028 12 22
CC41008 25 136
CC41009 40 130
CC41013 34 126
CC41017 25 131
CC41018 29 125
CC41021 25 123
CC41022 25 126
CC41029 42 18
CC43001 20 199
CC43003 87 230
CC43006 16 199
CC43008 84 230
CC43011 44 203
CC43013 71 231
CC43016 42 203
CC43018 76 232
CC43021 16 194
CC43023 27 231
CC43024 160 239
CC43025 150 252
CC43026 10 200
CC43028 24 231
CC43031 37 204
CC43033 16 232
CC43036 37 201
CC43038 22 246
CC43059 134 213
CC43061 105 232
CC43073 78 221
CC43081 98 209
CC43083 124 214
CC43086 80 204
CC43087 79 172
CC43089 79 179
CC43094 118 245
CC43099 70 246
CC46002 117 92
CC46003 92 77
CC46004 102 76
CC46005 122 109
CC46021 93 81
CC46022 96 81
CC46023 111 96
CC46024 114 92
CC46026 99 77
CC46031 77 123
CC46032 80 123
CC46033 66 121
CC46036 70 91
CC50002 195 177
CC50004 160 186
CC50011 194 193
CC50013 181 175
CC50023 178 188
CC50024 196 170
CC60031 266 26
CC61002 195 27
CC61003 198 23
CC61006 187 57
CC61007 185 54
CC61022 156 79
CC61028 196 114
CC61031 200 114
CC61038 222 124
CC61041 227 114
CC61051 185 89
CC61058 186 94
CC61311 231 10
CC70501 154 130
CC70502 140 182
CC70503 146 188
CC70506 152 136
CC70507 155 136
CC70508 152 196
CC70512 146 143
CC70513 146 148
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CC70518 120 173
CC70528 156 45
CC80002 143 44
CC80010 101 42
CC80016 136 63
CC80051 108 39
CC80053 70 93
CC80055 119 58
CC80056 124 58
CC80058 95 67
CC80059 115 57
CC80065 136 53
CC80069 102 86
CC80070 138 67
CC80074 105 81
CC80079 126 69
CC80089 109 72
CC80091 85 139
CC80093 81 142
CC81001 99 81
CC81002 88 102
CC81004 96 110
CC87002 129 35
CC87003 70 99
CC87004 70 102
CC87005 102 81
CC87006 80 107
CC87007 122 38
CC87008 129 42
CC87009 129 39
CC87011 113 100
CC87016 95 72
CC87023 70 96
CC87024 130 92
CC87026 97 86
CD21201 303 160
CD21202 297 144
CD21203 306 160
CD21206 324 171
CD21221 184 159
CD21222 184 166
CD21231 206 180
CD21232 206 172
CD32315 71 217
CD32324 54 151
CD34513 99 175
CD34517 115 177
CD40008 28 19
CD40015 23 26
CD41011 41 111
CD43025 162 250
CD43084 74 190
CD50004 195 181
CD52003 189 238
CD53019 338 228
CD55003 228 189
CD55004 222 201
CD58001 210 207
CD58004 211 202
CD58007 221 175
CD58011 228 174
CD58012 222 168
CD58021 210 191
CD58022 206 185
CD70501 157 222
CD70506 157 161
CD70507 163 153
CD70517 158 134
CD70519 142 99
CD70521 143 87
CD70522 149 86
CD70523 155 54
CD70551 156 147
CD70553 166 138
CD80060 100 68
CD80081 139 17
CD80085 157 12
CD80091 87 133
CD81004 93 109
CIC43010 151 239
CR21201 299 152
CR21202 313 164
CR21203 320 161
CR21206 338 182
CR21222 188 165
CR21223 194 164
CR21224 197 164
CR21226 181 159
Coordinates of the Components on the Solder Side
(Bottom Side)
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CR21232 202 154
CR21233 354 130
CR21234 342 130
CR32301 57 145
CR32302 9 173
CR32307 35 157
CR32309 37 165
CR32310 28 164
CR32311 21 157
CR32313 11 157
CR32314 19 161
CR32315 22 171
CR32317 13 167
CR32319 74 198
CR32320 71 198
CR32325 69 175
CR32334 40 148
CR32335 42 148
CR32339 13 204
CR32340 15 204
CR32341 57 201
CR32360 28 211
CR32364 28 188
CR34085 107 205
CR34345 51 161
CR34509 125 180
CR34510 118 185
CR34511 92 177
CR34512 88 188
CR34513 90 177
CR34514 139 135
CR34516 135 140
CR34517 95 177
CR34518 116 130
CR34519 123 130
CR34520 110 191
CR34521 101 188
CR34522 122 189
CR34523 125 189
CR34524 131 131
CR34525 120 130
CR34526 128 134
CR34541 98 159
CR34542 83 160
CR34543 83 158
CR34544 83 155
CR34546 165 164
CR40001 14 105
CR40002 14 101
CR40003 9 114
CR40004 14 109
CR40005 14 115
CR40007 28 13
CR40009 33 24
CR40010 14 113
CR40011 13 72
CR40012 13 53
CR40013 10 58
CR40014 23 18
CR40021 13 69
CR40022 13 61
CR40023 10 65
CR40031 36 90
CR40032 39 90
CR40033 18 125
CR40034 23 147
CR41001 33 148
CR41002 37 142
CR41003 23 152
CR41004 26 141
CR41005 30 148
CR41006 30 135
CR41007 37 136
CR41010 27 148
CR41011 43 112
CR41031 13 119
CR43001 25 221
CR43002 49 245
CR43003 90 230
CR43004 38 245
CR43005 32 245
CR43006 9 205
CR43008 81 230
CR43009 132 252
CR43010 134 252
CR43011 45 216
CR43013 71 234
CR43014 141 252
CR43016 42 216
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CR43018 78 232
CR43019 138 252
CR43021 10 215
CR43023 30 231
CR43024 152 217
CR43025 150 247
CR43026 8 215
CR43028 22 231
CR43031 14 216
CR43033 16 242
CR43034 116 213
CR43035 114 213
CR43036 19 219
CR43038 22 243
CR43041 48 224
CR43042 40 229
CR43043 141 243
CR43045 112 213
CR43046 141 240
CR43047 141 238
CR43048 147 233
CR43049 121 213
CR43050 119 213
CR43051 92 230
CR43052 95 230
CR43053 91 244
CR43054 121 206
CR43055 119 206
CR43056 98 244
CR43057 105 244
CR43058 111 244
CR43059 134 218
CR43060 131 213
CR43061 128 224
CR43062 131 226
CR43063 130 219
CR43065 77 169
CR43066 122 222
CR43067 119 236
CR43071 103 219
CR43072 43 245
CR43073 103 224
CR43075 75 223
CR43076 114 221
CR43077 116 221
CR43078 59 235
CR43079 110 221
CR43080 133 230
CR43081 101 211
CR43082 119 222
CR43083 98 218
CR43084 97 214
CR43085 75 158
CR43086 83 204
CR43087 81 172
CR43088 78 175
CR43089 77 191
CR43091 82 179
CR43092 123 233
CR43093 123 241
CR43095 66 242
CR43096 63 241
CR43098 101 206
CR43099 104 206
CR46003 120 88
CR46004 67 86
CR46005 123 104
CR46006 119 109
CR46007 117 109
CR46008 121 93
CR46011 70 76
CR46012 70 79
CR46013 70 73
CR46014 71 81
CR46022 111 92
CR46024 114 88
CR46026 107 81
CR46031 108 164
CR46032 104 159
CR46033 102 134
CR46034 62 88
CR46035 80 90
CR46036 75 90
CR50001 188 171
CR50002 195 174
CR50003 160 178
CR50004 163 186
CR55003 231 183
CR55006 235 214
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
CR55007 232 192
CR55011 234 194
CR55016 214 206
CR58004 217 197
CR58007 215 171
CR58011 236 177
CR58012 236 173
CR58013 219 183
CR58014 225 184
CR58015 220 194
CR58021 210 180
CR58022 206 175
CR60013 301 20
CR60031 314 22
CR60033 272 14
CR60046 318 11
CR61003 182 35
CR61004 198 20
CR61007 179 58
CR61008 176 58
CR61009 181 63
CR61029 166 110
CR61032 170 99
CR61039 207 132
CR61042 228 123
CR61052 182 81
CR61059 171 86
CR61301 248 13
CR61302 242 15
CR61303 231 15
CR61304 206 23
CR61306 210 18
CR61307 240 18
CR61311 221 8
CR61317 161 36
CR65543 114 135
CR70501 146 168
CR70502 183 170
CR70504 158 216
CR70506 157 153
CR70507 159 153
CR70508 154 153
CR70509 138 195
CR70510 138 198
CR70512 158 141
CR70513 161 143
CR70516 156 141
CR70518 117 173
CR70519 139 112
CR70521 144 99
CR70522 146 86
CR70523 156 39
CR70524 152 56
CR70526 151 91
CR70527 152 39
CR70528 152 45
CR70551 169 143
CR70552 153 147
CR70553 166 143
CR80001 128 28
CR80003 130 87
CR80004 125 81
CR80006 125 32
CR80007 107 97
CR80009 104 42
CR80010 103 68
CR80011 98 43
CR80012 101 36
CR80013 110 56
CR80015 103 52
CR80016 119 68
CR80017 99 36
CR80018 96 52
CR80019 94 52
CR80021 97 36
CR80022 86 52
CR80023 81 52
CR80024 89 52
CR80026 91 52
CR80027 94 36
CR80028 91 36
CR80029 89 36
CR80031 86 36
CR80032 84 36
CR80033 81 36
CR80034 79 36
CR80036 76 36
CR80037 76 52
CR80039 73 52
XY
Koordinaten fŸr die Bauteile der Lštseite
(Unterseite)
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CR80040 71 52
CR80041 69 52
CR80042 68 58
CR80043 69 36
CR80044 71 36
CR80046 73 36
CR80049 135 59
CR80050 135 56
CR80051 112 49
CR80052 109 52
CR80053 75 92
CR80055 114 61
CR80059 80 93
CR80060 122 44
CR80066 80 99
CR80067 80 102
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CR80069 105 97
CR80070 99 86
CR80071 109 104
CR80075 106 76
CR80076 108 92
CR80079 108 76
CR80081 152 18
CR80082 161 15
CR80083 150 18
CR80086 147 18
CR80087 142 18
CR80088 80 96
CR80092 69 86
CR80093 87 142
CR80096 116 125
CR81001 92 98
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CR81002 96 101
CR81003 100 107
CR81004 96 105
CR81005 126 92
CR81006 86 102
CR83006 113 104
CR87002 126 84
CR87003 75 98
CR87004 75 101
CR87005 74 107
CR87006 75 104
CR87007 125 44
CR87008 125 49
CR87009 127 77
CR87016 95 69
CR87023 75 95
Coordinates of the Components on the Solder Side
(Bottom Side)
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CR87024 132 84
CR87082 115 65
CRX61001 195 14
CRX61031 167 101
CRX61041 203 130
CRX61051 178 86
CT21221 188 159
CT21233 349 122
CT32308 38 158
CT32310 25 160
CT32312 15 159
CT32315 16 167
CT40010 29 28
CT43060 133 207
CT43088 81 198
CT43089 81 191
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CT43091 81 185
CT43092 110 205
CT43093 115 205
CT43094 123 245
CT43095 65 231
CT46005 126 109
CT58012 211 197
CT61301 252 18
CT61316 253 8
CT70505 163 159
CT70520 147 93
CT70525 153 61
CT80002 141 40
CT80085 151 12
CT81001 92 102
CT81004 100 102
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
11
GRUNDIG Service
12
GRUNDIG Service
Page 11
CUC 1830 / 1836 / 1929 Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams
CUC 1830 / 1836 / 1929 Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams
Chassisplatte / Chassis Board
310320330340350360
CR60046
CR60031
CT21233
CR21233
CR21234
CC21233
CBR060
CC21206
CR21203
CR21202
CD21206
CR21206
CD53019
CD21203
CR60013
Lštseite, Ansicht von unten / Solder Side, Bottom View
CT61316
CR61302
CT61301
CR61301
CR61307
CR55007
CR55006
CR60033
CC60031
CD21202
CR21201
CD21201
CR55011
CC61311
CR61303
CR58012
CR58011
CR61042
CR55003
CC61041
CD58011
CR58014
CD55003
CR61311
CD58012
CD55004
CC61038
CR58013
CR58015
CD58007
CR58004
CR55016
CR58007
CR58021
CD58021
CT58012
CD58004
CR61306
CR61039
CR61304
CD58001
CR21232
CR50002
CR58022
CD58022
CC61031
CRX61041
CC21231
CD21232
CC50002
CD21231
CRX61001
CC50024
CD50004
CR61004
CC61003
CC61028
CR21224
CC61002
CC21221
CR21223
CC50011
CC61007
CC61006
CC61051
CC61058
CT21221
CR50001
CR21222
CD52003
CR61003
CR61009
CR61052
CD21221
CD21222
CR61007
CRX61051
CR21226
CR70502
CC50013
CR61008
CR61059
CC50023
CR61032
CR80082
CRX61031
CR61029
CD70553
CR70551
CR70553
CT70505
CD70507
CR34546
CR50004
CD43025
CD70517
CR70513
CR50003
CR70504
CC43024
CR61317
CR70523
CC70528
CD70523
CR70512
CD70551
CR70506
CR70507
CC50004
CBR027
CBR054
CD80085
CC70507
CD70506
CBR004
CBR009
CD70501
CR80081
CC61022
CD70522
CR70526
CC70501
CR70516
CR70508
CC70508
CBR041
CR80083
CR70527
CR70528
CR70524
CT70525
CT70520
CC70506
CR70552
CC70503
CR43024
CR43048
CIC43010
CT80085
CR80086
CR70522
CC70512
CC70513
CR43025
CC43025
CT80002
CC80002
CC80016
CR70521
CR70501
CR43047
CR43046
CR43043
29304-730.13/4LS(12)
CR80087
CD80081
CR80001
CC87002
CR80006
CR87008
CC80079
CR87002
CT46005
CC34526
CBR052
CR43060
CR43061
CR87007
CR87009
CR81005
CR46005
CR34526
CBR068
CBR029
CBR042
CC34502
CR34509
CR34523
CBR050
CR43092
CT43094
CC80056
CR80004
CR46003
CR46008
CC46005
CR34519
CBR047
CC70518
CBR067
CR34522
CR43054
CR43049
CC43083
CR43066
CC87007
CR80060
CC80055
CR80016
CC87011
CR46006
CR34525
CBR051
CR70518
CR43055
CR43034
CR43050
CR43082
CR80052
CBR032
CC80059
CR80055
CBR070
CC46002
CR46007
CC34525
CR65543
CR34510
CR43035
CR43077
CR43067
CR43093
CC43094
CR87082
CR46024
CC46024
CR83006
CR80096
CR34518
CC34550
CC34503
CBR055
CT43093
CR43058
CR80013
CC80089
CR46022
CR46031
CC34504
CD34517
CT43092
CR43076
CC80051
CR80051
CR80079
CR80076
CC46023
CR80071
CC34520
CR34520
CR43099
CR43045
CR43079
CC43061
CC87009
CC87008
CC80065
CR80050
CR80049
CC80070
CBR002
CR87024 CR46014
CR80003
CD70521
CC87024
CD70519
CR70519
CBR048
CR34524
CR34514
CC34524
CR34516
CBR030
CC70502
CR70509
CR70510
CT43060
CC43059
CR43063
CR43059
CR43080
CR43062
CBR053
CR43009
CR43019
CR43010
CR43014
CR80009
CR80010
CR46026
CR80007
CR81003
CR46032
CC34519
CR34085
CBR046
CR43071
CR43057
CC80010
CR80075
CC87005
CC80074
CR80069
CT81004
CC34518
CR34521
CC34517
CR80012
CR80015
CC46004
CC80069
CR46033
CBR071
CC34507
CBR034
CR43098
CR43081
CR43083
CR43073
CR43056
CR80017
CR80011
CBR044
CD80060
CC46026
CC81001
CR80070
CBR061
CR34541
CD34513
CR80021
CR80018
CC46022
CC87026
CR81002
CR81004
CC81004
CR80093
CR34517
CC43081
CR43084
CR43052
CR80027
CR80019
CC80091
CC34541
CR80028
CR80026
CC80058
CR87016
CC87016
CC46021
CR81001
CT81001
CBR038
CR34511
CR43051
CR43053
CR80029
CR80024
CC46003
CC81002
CD81004
CR34513
CR34512
CR43003
CR80031
CR80022
CR46035
CR80059
CR80088
CR80066
CR81006
CBR023
CBR026
CBR025
CC34542
CC34543
CBR035
CC43003
CR80032
CR80067
CC46032
CD80091
CBR058
CR43087
CR43091
CR43086
CC43008
CR80033
CR80023
CC87006
CR34544
CR34543
CR34542
CR43065
CR43088
CT43091
CT43089
CT43088
CBR049
CR43008
CR80034
CR46011
CR46012
CR46036
CR80053
CR87023
CR87003
CR87004
CR87006
CR87005
CC46031
CBR063
CC80093
CC43087
CC43089
CR43089
CC43086
CC43073
CR43018
CR80036
CR80037
CR80092
CBR062
CBR031
CR32319
CC43013
CR43013
CC43018
CR80046
CR80039
CR46013
CC87004
CR43085
CR32325
CBR057
CD43084
CR43075
CC43099
CR80044
CR80040
CC46033
CR32320
CD32315
CR80043
CR80041
CR46004
CC46036
CC80053
CC87023
CC87003
CR43095
CR80042
CR46034
CBR033
CT43095
CR43096
CBR043
CC32355
CD32324
CR32341
CR43078
CC32370
CBR024
CR32301
CR41011
CR34345
CC32345
CC32350
CC32331
CR43011
CR43041
CR43002
CC41029
CC32326
CC43011
CC41009
CR32335
CT32308
CC32309
CC43036
CC43016
CR43072
CR40032
CD41011
CR41002
CR32334
CR32309
CC32310
CC43031
CR43016
CR43042
CR40009
CC40013
CC40014
CR40031
CC41013
CR41007
CR41001
CC32307
CC32308
CC32341
CC32314
CR43004
CD40008
CT40010
CC40022
CC41018
CR41006
CR41005
CR32307
CC32315
CR32364
CC32339
CC32347
CR40007
CC41021
CR32310
CR43023
CR43005
CD40015
CC40012
CC41017
CR41004
CR41010
CC32338
CR32360
CR43001
CC43023
CR43038
CR40014
CC40002
CC41022
CC41008
CR41003
CC32311
CT32310
CC32306
CC32348
CC32336
CC32328
CC43028
CC43038
CR40012
CR40021
CR40011
CR40034
CR32311
CC32312
CR32315
CC32303
CC43001
CR43036
CR43028
CR40013
CR40022
CR40010
CR40005
CC32313
CR32314
CC32317
CC32337
CC43033
CR43033
CC40028
CC40017
CC40004
CR40002
CR40001
CR41031
CR40033
CT32312
CT32315
CC32302
CC43021
CC43006
CR32340
CR43031
CR40023
CR40004
CR32313
CC32318
CC32301
CC32365
CC43026
CR32339
CBR069
CC32316
CR32317
CR43021
CC40027
CR40003
CBR056
CR32302
CC32333
CR43006
CR43026
0102030405060708090100110120130140150160170180190200210220230240250260270280290300
X
0
Y
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
GRUNDIG Service
13
GRUNDIG Service
14
Page 12
Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams CUC 1830 / 1836 / 1929
Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams CUC 1830 / 1836 / 1929
Messpunkte (Chassis) / Testpoints (Chassis)
8
11
9
10
12
Lštseite, Ansicht von unten / Solder Side, Bottom View
64
66
65
69
67
68
70
71
22
20
38
47
48
49
37
31
63
62
53
55
57
32
F
G
E
D
C
B
H
I
K
L
36
30
29
A
21
15
19
M
28
17
16
26
24
18
25
23
27
13.413.213.3
GRUNDIG Service
13.1
15
5452
51
16
50
GRUNDIG Service
34
61
60
35
33
59
58
Page 13
CUC 1830 / 1836 / 1929 Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams
220u/50V
S
0
M
R
R
1
Netz-Chassis / Mains Chassis
2
M
1
ST-UB2
SM SEITE / PAGE 3-14
/14V+U
B
8
OK60031
CN17F1
OK60046
CN17F1
4
P
1
24
CR61301
CT61316
BC848B
1
24
6,2
6,2
5,1
6,2
6,8
6,2
6,2
6,2
6,2
6,2
2,7/2W145V
C60014
P
CT61301
BC848B
470
M
M
62k
47k
47k
47k
56k
47k
56k
5
6
+
CR61307
CR61302
+H
R61316
R60006
4,7
CR60013
10k
2,2u/63V
0
1k
270
D60014
BAV21
C61317
220k
100k
100k
100k
100k
22k
22k
22k
22k
100k
22k
9
R60007
P
+
C60011
P
1
IC61310
LM358N
C61301
+
1u/100V
M
P
33n/FKP1
T60006
G
2,2k
220u/40V
C60016
P
+Q
K
15n
CR61317
22k
R21212CR21206
4,7M
1,5M
1,5M
1,5M
1,5M
1,5M
1,5M
1,5M
1,5M
1,5M
1,5M
1,5M
15k/7W
Min.
P
56
4
3
2
C60006
R60012
47
R61313
R61312
CR61311
R60008
100p
D60006
F
C60009
47k
2,2k
M
CR61303
10k
R21214R21101
10
MUR880
220p/FKP1
P
n.V.
C60018
22k
CC61311
M
CR61304
L60006
3,6u
F
10n/FKP1/1250V
R61314
*
3,3n
CR61306
1k
1k
M
C21232
C60007
PC50
C60012
270p/2kV
D60012
BYT53B
3,3n/FKC3
M
4
8
+Q
D
S
K
R60016
+A
+
-
10k
10k
10k
10k
10k
10k22k 2,4
100k
100k
100k
100k
10k
10k
ALLA PIASTRA INTERR. DI RETE
VERS C.I. INTERR. SECTEUR
TO MAINS SWITCH BOARD
ZUR NETZSCHALTERPLATTE
SEITE/PAGE 35
RED 230V
RETE 230V
SECTEUR 230V
MAINS 230V
NETZ 230V
SEITE/PAGE 33
SM SEITE / PAGE 3-13 / 3-14
2
P
SI60201
C60028
PFC
29201-703.97
PF1
NETZ1
4
3
2
1
A LA PLACA INTERRUPTOR RED
SM SEITE / PAGE 3-59 / 3-62 / 3-63 / 3-66
M
PRIMAERMASSE / NICHT NETZGETRENNTES SCHALTUNGSTEIL
PRIMARY CHASSIS, NOTE / CIRCUT NOT MAINS ISOLATED
MASSE PRIMAIRE / CIRCUIT NON ISOLE DU SECTEUR
P
MASSA PRIMARIO / CIRCUITO NON SEPAR.,DALARETE
MASA PRIMARIA / SECTOUR DE COM. NO SEP. DE LA RED
AENDERUNGEN VORBEHALTEN
SUBJECT TO ALTERNATE
SOURS RESERVE DE MODIFIC
CON RISERVA DI MODIFICA
RESERV. EL DEREC. DE MODIFIC.
NETZ-CHASSIS
MAINS CHASSIS
CHASSIS DI SECTEUR
CHASSIS DI RETE
CHASIS INTERR. RED
+
1
*
P
PF2
n.V.
n.V.
UB1
T100mA
/385V
BR289
C62021
C62022
1
180k
R60028
P
F
2,2n/400V_AC
F
2,2n/400V_AC
STAND-BY NETZTEIL
29304-050.82
(29304-050.29)
XX
0,1u
C60021
D60021
BR223
XX
0,1u
C60019
D60019
n.V.
XX
L60028
C60029
P
0,1u/MP3/400V_AC
D60023
B380/C2200
1n
C60023
P
1n
C60024
P
K
C62048
M
CUC 1806
CUC 1828
CUC 1829
CUC 1830
CUC 1836
CUC 1929
SI60001
T2A
1n
C60026
+-
1n
C60027
1n/400V_AC
C60001
R60001
270k
C60002
R60002
680k
2,2n/FKC3
P
F
C60013
3
7
1
0,1u
P
CR60031
P
P
2,7M
R62049
M
PHI 55cm/BL A51EHE175X50
PHI 63cm/BL-D A59EAK071X44
PHI 63cm/BL-S A59EAK652X44
PHI 70cm/BL-D A66EAK071X44
PHI 70cm/BL-S A66EAK652X44
PHI 70cm 16:9 W66ESF202X44
PHI 72cm/BL-S A68ESF202X043
PHI 72cm/CAS A68ESF202X143
PHI 84cm A80EFF002X43
PHI 82cm 16:9 W76ESF231X44
VC 84cm A80EJA33X122
TOSH 72cm A68LBT696X99
1n
P
R60032
220
*
R60029
47k
5,6k
STAND
BY
2
CR60033
CC60031
CR60046
8
2
START LOGIK
IC60010
TDA4605/3
11
5
2,4k
2,2n
P
5
4,7k
P
P
135V
143V
135V
146V
142V 1,6 1,6 0,5u 0,47u 859.55
148V
143V
148V
1u
1u
1u
2,2u
1u
CUC 1830 / 1836 / 1929 Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams
+OEKO
P
+Q
29201-
TR60001
5
3
6
4
7
9
+A
CR21234
390
390
390
390
390
*
19
20
21
12
22
C61016
13
12
17
14
M
15
M
16
18
CR50001
CR50003
82k
75k
68k
75k
68k
68k
82k
82k
82k
82k
82k
75k
68k3,3/2W
L61021
8104-982-014
M
L61011
8104-982-014
K
100p/FKP1/1kV6
L61026
M
8104-982-014
L61036
8104-982-014
L61056
8104-982-014
L61061
8104-982-014
L61066
8104-982-014
2,7
1,5
1,5
1,5
1,5
2,4
1,5138V
1,6 1,6
2,4
n.V.
L61016
8104-982-014
SI61026
T2,5A
SI61036
T2,5A
SI61056
T2,5A
SI61061
T2A
SI61066
T2A
3
1,5
1,51,5
1,5
1,5
1,5
2,4
1,61,6
1,51,5
+
C61002
M
C61021
100p
D61021
MUR420
C61026
D61026
MUR840
C61036
D61036
MUR840
C61056
100p
D61056
MUR840
C61061
100p
D61061
MUR420
D61066
MUR420
C61066
100p
CC50023
LM317T
ADJUST
1
220
R61001
LM317T
ADJUST
1
4,7u/350V
C61018
M
R61031
R61041
R61051
23
OUTIN
CR61003
220/1%
23
OUTIN
CR61007
0,1u
CC61022
M
1
4,7n
R61018
M
IC61030
LM317T
ADJUST
470
IC61040
LM350
ADJUST
220
IC61050
LM317T
ADJUST
220
470
R61062
470
R61063
CR61009
220/1%
270/1%
CR61008
1k/1%
SI61022
T1,6A
100k
OUTIN
CR61032
1
220/1%
OUTIN
CR61042
1
220/1%
OUTIN
CR61052
1
220/1%
M
1,8
1,58,2/1W
1,2
1,2
1,2
1,2
1,2
1,5
1
1
R61033
4
100
23
23
23
0,1u
C61004
CC61003
M
0,1u
C61008
CC61007
M
M
R61022
2,7/6,5W
D61033
1N4004
0,1u
C61032
CC61031
M
0,1u
C61042
CC61041
M
M
n.V.
0,1u
C61052
CC61051
M
C61064
0,25u3,3146V
0,3u 0,3u
0,3u 0,3u
0,41u 0,41u
0,41u
0,41u
0,41u
0,41u1,5
0,41u
0,41u
+H
/5V
+
+H
FEATURE-B.
CONT.8
1000u/25V
M
+Q
/8,2-8,8V
+
220u/25V
M
+LNC
+G
+C
+A
TABELLE
+D
+M
+B
+
1000u/25V
M
+E
+F
+F
+
FEATURE-B.
CONT.9/10
2200U/16V
OPTION A
+N
+N
+
FEATURE-B.
CONT.32/33
100u/25V
M
+K
+
/14V
*
M
/14V
-K
TR53010R50008R50007
0,25u
-033.01
-680.02
-033.01
0,41u
-680.01
0,41u
-680.01
0,3u
-680.01
0,5u
-680.01
-680.01
0,41u
0,3u
-680.02 11,5n
0,3u
-680.01
-680.01
0,41u0,41u
0,25u0,25u
-680.01
IC61001
0,1u
470u/40V
C61011
100p
D61011
BYV38
CC61002
M
CR61004
M
560
CC61006
100p
BYV38
M
0,1u
+
C61022
M
+
C61013
IC61006
600u/63V
+M
n.V.
C61012
D61012
M
D61016
MUR880
+
+
M
+
M
+
M
+
+
M
470u/40V
M
1000u/63V
M
470u/40V
M
w.w.
470u/40V
w.w.
470u/40V
C61017
CC61028
0,1u
CR61029
M
1,8k
CC61038
0,1u
CR61039
M
560
CC61058
0,1u
CR61059
560
L61062
D61062
L61067
D61067
100u/250V
M
*
100p
C61027
100p
C61037
C61057
C61062
C61063
*
1n
8,2/1W
8,2/1W
8,2/1W
8,2/1W
4,7/1W -122
4,7/1W
4,7/1W
1n
8,2/1W 1,5
4,7/1W
1n
4,7/1W
4,7/1W
TR52001
09245-812.31
09245-812.31
09246-867.04
09245-812.31
09246-867.04
09246-867.04
09246-867.04
09246-867.04
09246-867.04
09246-867.04
09246-867.04
09246-867.04
09246-867.04
/15V
/27V
/27V
/200V
/26V
/16,5V
/12V
/9V
/5V
/5V
CR55016
C
R53012
560k/1%
560k/1%
560k/1%
560k/1%
560k/1%
560k/1%
560k/1%
560k/1%
560k/1%
560k/1%
560k/1%
OWA
VERT.
CR50001
2,7k
n.V.
R55001
3,9k
R55002
1,8k/2%
L53021R52001
-11933/2W 859.656,8n390-680.02
-122
-122
-122
-122
-122
-122
-122
-122
-122
-122
-122
50
51
53
*
CR50003
CR50002
51k
CC50002
2,2n
13.3
VERT.
52
*
M
M
M
-K
220/1%
CR55003
M
R53021
VG
CD21222
LS4148
CD21221
LS4148
-K
13.2
n.V.
CD50004
xx
15k
R55004
M
CD55004
*
CD55003
M
220
220
220
390
390
390
390
390
220
390
390
390
CC50023
CC50024
LS4148
*
M
C53071C53007C53006R52006
11n
10n
13n
13n
13,5n143V
13n
14n
14n
13n
+F
R21227
2,2k
CR21226
CR21222
4.7k
CC50004
2,2n
CR50004
51k
M
M
1
7
0,1u
F
C55004
M
F
C55003
M
9n1M/1%1,8
+A
2,2u/350V
5.6k
CR70527
CC70528
CR21224
CC50011
0,1u
C50012
1000U/25V
22n
28
2,2n
CR55006
C53072
27n
20n
27n
20n
27n
27n
20n
27n
27n
27n
27n
20n
27n
+
C70527
12k
CR70523
33n
CR70528
M
CT21221
BC848C
680
M
+
C50026
7
8
1
3
12k
M
+A
330k
CR70524
33k
M
CC21221
+K
CC50013
0,1u
D50013
BYV28-200
2
IC50010
TDA4173AF
4
+
1000u/25V
M
IC55010
TDA8145
C53073
0,47u
0,47u
0,47u
0,47u
0,47u
0,47u
0,68u
0,68u
0,68u
0,68u
0,68u
1k
10n
R50027
CR21223
1,5
+Q
LS4148
CD70523
CT70525
BC858C
R21221
47k
10k
OPTION B
6
3
5
L53074+A R21213R21211
859.55
859.63
859.55
859.64
859.61PAN 70cm A66ECF50X56 820k10k1,5M100k56k6,2146V
859.65
859.550,56u12,5n
859.63
859.63
859.65
859.64
R50007
+
C50014
0,1u/MK
C50
CR55
IB
UA
C
*
*
GRUNDIG Service
17
GRUNDIG Service
18
Page 14
Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams CUC 1830 / 1836 / 1929
10k
T
SEITE / PAGE 24
ZUM COLOR CHASSIS
+
MMMM
18k
18k18k
+B
22u/25V
CT58012
BC848B
R53003
1,5
L53003
L53002
24
26
TO COLOUR CHASSIS
VERS COLOUR CHASSIS
AL CHASSIS COLORE
A CHASIS COLOR
CR58007
+B
1,8k
CD58007
M
ZPD2,7/2%
LS4148
CD58004
CR58004
M
M
C58004
+
22u/25V
+B
CR58013
*
CR58014
CR58015
M
BEI BEDARF
ON REQUEST
SI NECESSAIRE
SE OCCORRE
EN CASO NECESARIO
1,5
R53002
F
BY359
D53071
C53071
C53072
D53072
BY229/600
TR60001CR58011
-569.97
-566.97
-573.97
-566.97
-569.97
-569.97
-573.97
-568.97
-568.97
-569.97
-573.97
-569.97
-569.97
C60028
220u
300u
300u
300u
300u
300u
300u
300u
300u
300u
300u
300u
300u
*
*
1u/100V
*
M
H-SHIFT
/FKP1/2kV
*
C53073
/MKP10
*
*
MM
2
3
5
6
C58014
+
BA157
XX
L61062
D61062
L61067
D61067
1N4004
-
+
IC58010
LM393
+
-
M
C53006
L53021
47u
47u
47u
47u
47u
47u
47u
47u
47u
47u
47u
47u
n.V.
8
4
M
M
F
/MKP4/10/160V
*
*
29203-
J1/J2
JH
J3/J4
C61064
2200u/25V
2200u/25V
2200u/25V
2200u/25V
2200u/25V
+A
F
C53007
R53021
2
R21216
22k
1
7
/MKP4/10/160V
*
*
23
25
+B+B
1,2k
CR58021
CD58021
LS4148
+
C58021
47u/50V
M
CR58022
1,2k
CD58022
LS4148
+
C58023
47u/50V
M
J6 J5
L53012
1,5m
F
C53009
R53008
10k
D53008
BA157
H-SH1H-SH2
UG2/SHIFT-PLATTE
29305-119.32
n.V.
H-SH3
M
R61314
15k
10k
10k
10k
15k
15k
15k
10k
10k
15k
15k
15k
15k
0,68u/160V/MKS4
18
PHI 84cm/320u
PHI 55cm/380u
TOSH 72cm/360u
CT70520
BC848C
ZPD3,3V
CC21231
CR70522
CD70522
M
CR21232
10k
0,15u
M
+Q
1k
CD21232
LS4148
CD21231
LS4148
SSC
100
CR70521
CD70521
M
C21232
F
*
470
CT21233
BC848C
ZPD5,1V
CC21233
CR21233
1n
10k
*
CR21234
M
M
M
HOR.2FT
LÔ
CR58012
*
R58001
20k/2%
CR58011
*
CD58001
LS4148
*
R58002
M M
C58011
F
*
F
0,22u
C58012
M
+
C58001
22u/25V
CD58012
LS4148
LS4148
CD58011
M M
C58013
Q
LS4148
CR70526
70525
C858C
R21221
TION B
47k
1k
R21231
33k
+M
54
+
C52002
C52003
T52003
BDX43
LS4148
CD52003
4,7u/63V
K
470p
1
R52001
+
C52001
M
15
4
R52003
F
C52004
MMM
*
TR52001
470u/25V
39
68n/100V
FEATUREBOX PIN 21
DF
*
2
R52006
16 17
*
R52007
1N4004
D52006
T53001
2SC5331
100
L53001
R50007*R50008
C50014
6
3
5
0,1u/MKS4-16
7
*
M M
+
220u/50V
13.4
F
C50027
T50029
BD537
T50028
BD538
R50028
4,7
-K
270
R50029
J8
JV
J7
13.1
B
M
DYNAM.FOKUSSIERUNG
CR55007
*
2
IB
IC
UB
UA
4
M
L53074 R58002
859.65
859.55
859.63
859.55
859.64
CD55003
ZPD4,3V/2%
ZPD3,9V/2%
ZPD3,9V/2%
ZPD4,3V/2%
ZPD3,9V/2%
CR55007
ZPD3,9V/2%
859.65
ZPD4,3V/2%
859.55
ZPD3,9V/2%
859.55
ZPD3,9V/2%
859.63
859.63
859.65
859.64
ZPD3,9V/2%
ZPD4,3V/2%
ZPD3,9V/2%
ZPD4,3V/2%
220k
220k
C55011
F
10n
4,7k
CR55011
5
1n
F
C55012
6
+
C55013
47u/50V
M
3k/2% 13k/2%
82k
3,9k/2%
82k
3,3k/2%
82k
3,9k/2%
82k
3,6k/1%
82k
3,6k/1%
82k
3,6k/1%
82k
3,9k/2%
82k
3,9k/2%
82k
3,3k/2%
3,6k/1%
82k
3,6k/1%
3k/2% 3,3k/2%
82k
M
2
470
R55012
CR58004
13k/2%
13k/2%
12k/2%
12k/2%
12k/2%
12k/2%
12k/2%
12k/2%
12k/2%
12k/2%
12k/2%
13k/2%
27
ZPD33
D55012
M
+D
C58011
1,2k/2%
0,56u
1,2k/2%
0,56u
1,5k/2%
0,56u
1,2k/2%
0,56u
1,5k/2%
0,56u
3,3k/2%859.61
0,56u
1,2k/2%
0,56u
1,5k/2%
0,56u
1,5k/2%
0,56u
0,56u
1,2k/2%
0,56u
1,2k/2%
0,56u
2,2k/2%
0,47u
DYNAMIC FOCUSSING
FOCALIS.DYNAMIQUE
FOCALIZZ.DINAMICA
ENFOQUE DINAMICO
L55014
R55014
4,7/NKS3
CR58012
1,5k/2%
1,5k/2%
1,5k/2%
1,5k/2%
1,5k/2%
1,5k/2%
1,5k/2%
1,5k/2%
1,5k/2%
1,5k/2%
1,5k/2%
2,2k/2%
1,5k/2%
5m
10k/1%
10k/1%
10k/1%
10k/1%
10k/1%
10k/1%
10k/1%
10k/1%
10k/1%
10k/1%
8,2k
8,2k
8,2k
SM SEITE / PAGE 3-30
CR58015CR58014CR58013
8,2k/1%
8,2k/1%
8,2k/1%
8,2k/1%
8,2k/1%
8,2k/1%
8,2k/1%
18k
18k 18k
8,2k/1%
8,2k/1%
8,2k/1%
Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams CUC 1830 / 1836 / 1929
BY
CD21203
LS4148
CD21206
BAV103
R53012
STAND
U
22k
CR21201
LS4148
CD21201
10k
CR21203
CC21206
M
T21211
S298
4,7n
OPTION C
n.V.
R21101
1
5,1
R21213
*
R21102
2
*
BR21102
1
M
2
3
M
4
5
6
+C
ST-BR
A LA PLACA-ZOCALO TRC
ALLA PIASTRA CINESC.
VERS C.I. TUBE CATHOD
TO CART BASE
ZUR BILDROHRPLATTE
SM SEITE / PAGE 3-55 / 3-57
+C
R21212
*
R21211
C21212
+
4,7u/350V
*
R21214
M
M
F
*
1N4004
D21212
M
SB
SS
+M
LS4148
CD21202
CR21202
56k
+
B
C21202
M
47u/25V
CR21206
*
+B
*
1
R53011
F
C53012
F
C53013
M
M
UG2
L53074
*
275u
BR256BR255
6,8
L53011
142p/2kV
1,8n/2,5%
0,33u/MKP10
F
C53011
18n/FKP2
10u
LÔ
R53016
19
C53017
C53016
20
OPTION B OPTION C
6,8/7W
0,33uMKP10
M
M
TR53010
29201-
L
I
E
F
G
*
U
H
82cm PHI
K
L
FOKUS-BLOCK
M
U
FOK1
U
FOK2
U
SG
SM SEITE / PAGE 3-57
U
/
SG/FOC.
A
LS4148
18n
18n
F
C53018
K
M
F
C53019
M
CD53019
ZY51
D53019
M
GF
E
D
H
I
C
C54001
560p
D54001
1N4936
BR256
*
B
AA
ANSCHL. V. UNTEN GESEHEN
CONN. BOTTOM VIEW
CONN. VUES DE DESSOUS
COLLEGAM. VISTI DI SOTTO
CONEXIONES VISTAS POR DEBAJO
BR255
M
*
R54001
0,33
+
C54002
100u/50V
TR 53010
+D
(26V)
MM
D
21
C
C
H
22
B
B
M
X
X
X
X
X
X
X
X
X
X
X
X
X
071100
21658-907.01
19
GRUNDIG Service
20
GRUNDIG Service
Page 15
CUC 1830 / 1836 / 1929 Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams
2
3
5
3
4
3
3
3
Color-Chassis / Colour-Chassis
CUC 1830 / 1836 / 1929 Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams
+B
D32315
ZPD33V
15
100
CR34345
MSP
RESET
SEITE/PAGE 35/ 37
VERS C.I. INTERR. SECTEUR
TO MAINS SWITCH BOARD
ZUR NETZSCHALTERPLATTE
LED-PLATTE
R32357
12
+A
+33V
4
12k
R32315
1
SIGNAL-BAUSTEIN
SIGNAL MODULE
MODULE SIGNAL
MOD.SIGNALE
MOD.SENAL
29504-102.34
29504-162.34
SEITE / PAGE SM 3-31 / 3-35 / 3-39
234567
12
CR32319
TERR
SCL
U
A LA PLACA INTERRUPTOR RED
ALLA PIASTRA INTERR. DI RETE
SEITE / PAGE SM 3-59 / 3-62 / 3-63 / 3-66 / 3-67
PIASTRA LED
C.I. LED
LED-BOARD
D32356
1N4004
+F
11
47
CR32320
SDA
IR
+H
KB
U
POWER
U
+OEKO
U
KB
+H
+OEKO
POWER
U
DATA
CLK
ACK
D32357
1N4004
47
AFC
ENA
U
ST-TEST
1
2
3
4
ST-IR\KB
1
2
3
4
5
LED
6
OFF
7
ST-KB
3
LED
2
1
ST-OS
1
2
OFF
ST-MP
1
2
3
4
+F
M
5
+LNC
+B
(MULTI)
M
+H
M
M
CC87002
+H
M
CR87007
+F
CC32355
+B
CR32301
1314
+B
2930
FBAS
SDA
1n
CR80001
820
4,7k
IC32310
78M05
2
0,22u
ZUR BED.EINHEIT
TO CONTROL UNIT
VERS UNITE DE COMMANDE
ALLÕUNITA DI COMANDO
A LA UNIDAD DE MANDO
680
1n
9
8
36
10
A
3,3k
n.V.
CR32325
SCL
POWER
U
CR87002
390
CR80006
M
330
+F
+OEKO
+H
+OEKO
+H
4,7k
4,7k
CR87009
CR87008
OUTIN
CC32301
FBAS
OFF
CT81004
BC848B
+H
CC87007
31
CINCH
+H1
CR81005
CR83006
M
100p
M
CC32370
AAA
CR32302
470
A
CC32302
CR81004
4,7k
M
CR80007
1k
4,7k
CC87008
0,1u
C32355
A
25
23
52
24
10n
A
CC32309
3,3n
27k
n.V.
CT80002
BC858C
CC87005
100p
M
+
470/10V
28
CR32309
CR32307
CC32308
PSEN
CR81009
1n
M
+F
CC87009
M
L32342
10u
CINCH
AUDIO-R
5
CINCH
AUDIO-L
4
FBAS
A
CINCH
3
2
V
1
ST-CT1
1516
12
Q32305
18,432MHz
32
1,5p
1,5p
CC32306
CC32303
AA
CC32310
3,3n
CC32307
3,3k
10n
3,3k
CT32308
BC858B
560p
KH
AUDIO-R
CD81004
LS4148
47k
CR81003
270p
CC81004
M
330
M
CR80059
M
100p
22k
+H1
CR81002
CC80002
M
100p
58
1
VSS
P2.3
PSEN
80
P1.4
79
P1.5
78
P1.6
P0.1
49 50 51 52 53 54
4,7k
100
CR80053
CC80053
0,1u
TERR
U
470
470
CR32340
CR32339
CC32336
470p
75
CR32341
V
66
27
A
CC32314
3,3k
CC32311
CR32310
10n
3,3k
CR32311
CT32310
BC858B
560p
CC32312
AA
MEGA
LOGIC
CT81001
BC848B
220p
CC81002
100k
CR81006
CR81001
M
CBR070
*
82 8384 2345
P3.4
P3.3
P3.2
P1.2
P0.3
P0.2
+F
4,7k
CR80088
100
CC87023
M
CR87003
100p
SDA
150
CR87023
ENA
3,3n
KH
AUDIO-L
+H
220
M
CC81001
100p
55
P0.7
+F
CR80066
CC87003
M
CR32314
CC32316
CC80010
CR80003
2,7k
CR87004
100p
CC32337
470p
CC32338
3637 3839 40 41
49
AAAA
3,3k
CC32313
10n
3,3k
CR32313
CT32312
BC858B
560p
A
CR80015
4,7k
ST-VGA3
1
2
M
4,7k
CR80009
M
100p
M
M
100
CR80010
10k
P1.0
P0.4
+F
2,7k
CR80067
100
CR87006
100p
CC87004
M
IDENT
SCL
U
CR32364
1,8
47n
A
CC32341
A
0,1u
CC32350
A
1n
AA
470p
470p
CC32339
11 12
IC32300
MSP3410
MSP3400C
32
35
A
CC32326
+
C32327
CC32315
3,3n
3,3k
CC32317
CR32315
3,3k
CR32317
CT32315
BC858B
560p
CC32318
A
AUDIO-R
+H
CR80013
330
+H
4,7k
CR80011
CR80012
2
A16
330
+H
CR80017
10k
CR80004
7172 7374
8 91011 12 13 1415 1617 1819 2021 22232425 26 27 2829 30 31
A16
ALE
P3.5
A18/P4.1
P0.5
10n
CC80069
CC87006
M
M
100k
47k
CR87005
M
CC32345
+Q1
82
R32359
C32360
A
220u/10V
A
6162636465
6768 44 4546
4243 10
390p
CC32328
4,7u/63V
10n
CR80014
0
A15
34 56789101112
330
CR80018
A15
10n
R80069
AV2
EURO-
U
17
bei SIGNAL-BAUST. -162.34
bei SIGNAL-BAUST. -102.34
535455 5657585960
A
390p
CC32331
+
AA
C32332
10u/50V
0,1u
AA
+F
AUDIO-L
WR
PP
V
A14
A13
A12
A11
330
330
CR80019
CR80022
330
330
CR80021
CR80023
A14
A13
A12
A11
P2.1
P2.2
59 60 61
10n
CC87011
M
10k
10k
CR80071
AV1
EURO-
U
CR32360
+
29
CC32333
+
C32343
10u/50V
0,1u
+
C32346
13 14
0
10u/50V
CC32347
AA
CD32334
XX
CR32335
220
CR32334
RGB
U
SCL
SDA
IC80060
27C020-15NS
A10A9A8A7A6A5A4A3A2A1A0
232425 26 272829
330
330
CR80027
330
100k
CR80070
M
M
CR80028
R80085
100p
OFF
POWER
U
CR80029
330
CR80031
P0.6
100
330
CR80032
330
CC80074
M
CR80024
330
CR80026
A9A8A7A6A5A4A3A2A1A0D7D6D5D4D3D2D1
A10
CC80070
+Q2
0,1u
220
I2S
330
CR80033
10n
CR80076
A
CL
CR80034
330
P2.0
10k
AFC
U
220u/10V
CC32365
26
WS
I2S
330
330
CR80036
C32364
+
CC32348
0,1u
I2S
A
A
1n
A
456789
TER
I2S
D_IN
D7D6D5D4D3D2D1
330
CR80039
330
CR80037
CR80040
P3.7
CR80075
+H1
CR43001
C43002
+
470
4,7u/63V
470p
CC43001
A
CR43006
C43007
+
470
4,7u/63V
470p
CC43006
A
CR43011
C43012
+
CC
V
D0
131415161718192021
330
D0
8
VCC
X24C08
CC43011
CC43016
CC43021
CC43026
CC43031
CC43036
+H
CE
VCC
OE
CE
GND
1234
1n
A
CR43016
1n
A
CR43021
470p
A
CR43026
470p
A
CR43031
1n
A
CR43036
1n
A
PSEN
30
22
CR80065
0
M
OPTION UP1
M
CC46021
CR80050
4,7k
SDA
SCL
220
22u/16V
C43017
+
220
22u/16V
C43022
+
470
4,7u/63V
C43027
+
470
4,7u/63V
C43032
+
220
22u/16V
C43037
+
220
22u/16V
+H
BR80051
CR80052
330
CR80068
0
M
M
56p/2%
L46021
L
1,5u/2%
44 45
LCIN
IC80050
*
P3.0
P3.1
7576 77
6465
DATA
5
5
6
6
3334
51
50
31
30
48
47
3
18192021 22
MP
CC80051
M
0,1u
31 321
WE
330
330
CR80041
CR80043
CR80046
330
330
330
CR80042
CR80044
32 3334 3536 37 38 39 40
P3.6
+H
10k
10k
CC80065
CR80079
M
0,1u
7
IC80065
TEST
VSS A2 A1 A0
M
n.V.
CR80051
M
56p/2%
CC46022
71
LCOUT
CR80049
+H
4,7k
+H+H
CLK
SDA
IC80070
ST24W02
SCL
1234
M
CC43003
A
CC43008
A
CC43013
A
CC43018
A
CC43023
A
CC43028
A
CC43033
A
CC43038
A
4,7k
M
CC80055
66
A17/P4.0
CR80025
8
0
VCC
CR43003
470
470p
CR43008
470
470p
CR43013
220
1n
CR43018
220
1n
CR43023
470
470p
CR43028
470
470p
CR43033
220
1n
CR43038
220
1n
+F
F
C80081
CR80082
XTAL1
TEST
VSSA2A1A0
0,33u
820k
M
*
Q80055
*
CC80016
n.V.
CR80030
6
2
1
3
+H
CR80081
CR80083
+H
M
CC46027
CC80056
CR80055
100p
M
7
XX
8
10
20
16
15
11
7
19
21
DEC
18
EURO-AV
17
14
13
9
5
M
4
A
6
2
1
3
*
P1.7
CR80016
8
10
20
16
15
11
7
21
19
21
VCR
18
EURO-AV
17
14
100k
AV2
MEGA
LOGIC
IC80040
MC33164
3
M
+H
220u/10V
33n
+H1
6,8k
FIL1SLC
HS/SC
46 47
100p
CC46015
M
*
+F
100
CR43051
AV1
EURO-
U
22k
CR80060
C80059
+
M
CC80059
RST
VS/P4.7
CC46014
100k
*
M
M
+H1
M
CR46003
*
CR80093
CC80091
CD80091
SSC
100
270k
47
*
*
XTAL2
+H
4,7k
CC80089
CC87024
M
CR43042
13
9
5
4
M
CR43041
M
A
CD80085
LS4148
68k
EURO-
U
CR80087
1,8k
8,2k
CR80086
CD80081
21
LS4148
CT80085
BC858B
M
OPTION UP2
M
M
M
33n
0,22u
CC46023
CR46022
M
CC46024
*
6,8k
CR46024
63 64 65
FIL3SLC
P1.3
81
n.V.
38
1k
100p
CR87024
10n
RESET
MSP
RESET
U
CC46026
CR46026
FIL2SLC
CC87026
M
LS4148
CD80060
CR80096
VERT.2FV
M
CR43002
CR43052
68k
RESET
U
IREF
*
220
+B
0,1u
2
3,3V2%
3
57
75
M
CR43014
CR43004
M
M
CC80058
0,1u
VDD
100
CR46004
47
75
M
M
M
STAND
U
CC80079
CR87016
4,7k
CC87016
47n
VDDA
6667 6869 70
CC46003
M
8
4
CR43009
47
47
CR43019
75
CR43005
M
C43098
47u/10V
CR43096
75
BY
0,1u
100
M
CL46004
0,1u
-
1
LM393
+
M
CR43053
M
CR43078
M
+Q1
R43098
+
CR87082
P1.1
VDD
43
0
CC80093
0,1u
IC80090
75
CR43056
C43079
M
1u/100V
75
3,3
CC43099
CR43095
M
CR46011
CT43095
+H1
75
+
CR43079
10n
BC848B
1k
R
OSD
*
CC46002
M
75
CR43058
M
M
47
G
OSD
69 706867
*
CR46012
R
0,1u
M
CR80092
+F
560
CR43048
CR43057
V
B
OSD
*
CR46013
G
COR
41
CC46004
47
75
CR43072
DATA
U
CR46034
CR46014
B
NC
+
0,1u
C46005
M
CR43010
75
M
OSD
680
1,5k
BLAN
56 57
100u/10V
M
CR43046
47
CR43043
47
CR43047
47
-K
CR43024
68k
47
CC43073
0,1u
+F
CR46035
P0.0
VSSA
NC
+H1
M
48
VSS
M
11
12
10
15
CR43073
4,7k
WR
RD
CVBS
VIDEO
CIC43010
8
MC14551
2
3
6
1
MC14551
47
KLEMM
U
CR46036
n.V.
6
7
62
42
M
+H1
9
CR43075
RGB
U
WR
CC46036
100p
100
R46039
CT46005
BC848B
16
13
14
+Q1
CR43076
CR43077
CR43080
47k
18k
M
n.V.
CR46040
330
CR46006
150
CC46005
xx
n.v.
+Q1
4
5
7
100k
100k
M
CE
330
CR46005
CC43024
0,1u
CC43025
47n
+Q1
CC43087
M
CR46008
xx
M
PIP
+Q1
47n
*
C46007
M
CR46007
CD43025
LS4148
CR43025
M
10k
M
CR43088
CR43087
+
2,2u/100V
150
M
M
+Q1
M
10k
CR43089
CT43088
BC848B
10k
M
CR43086
M
OPTION UP1/UP2
CR43093
1k
18k
560k
*
CR46003
CC46014
CC46015
CR46022
CC46027
CC80055
CC80056
Q80001
75
R43004
3,3
+
C43093
CR43034
CR43091
CC43089
CT43089
CC43061
0,1u
+Q1
CR43092
CT43094
BC848B
47u/10V
M
0
PIP
CR43035
18k
0,1u
BC858B
IDENT
U
SDA 5250-100
82k
560k/2%CR46008
1,8kCR46011/12/13
8,2k
68pCC46031/32/33
180CR46031/32/33
15p
33CR80055
56p
18MHz
10nCC80059
CR43061
M
CC43094
PIP
0
CT43091
BC858B
CC43086
IC800
13
18
0,1u
47
3
5
CR4306
PIP
CR4306
10n
M
100k
100k
0
CR43045
M
CR43071
FBAS
+
C43068
CINCH
GRUNDIG Service
21
GRUNDIG Service
22
Page 16
Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams CUC 1830 / 1836 / 1929
CC
Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams CUC 1830 / 1836 / 1929
C70511
+
1u/100V
CT70505
BC848B
M
VGA-BUCHSENPLATTE 29305-160.3600
VGA SOCKET BOARD
C.I.PRISES VGA
PIASTRA PRESE VGA
PLACA DE TOMAS VGA
SEITE / PAGE SM 3-53
ST-VGA2
ST-VGA2
1
1
M
2
3
3
ZPD15
D70508
4,7u/63V
5,6k
+
CR70512
C70516
270k
M
CR70513
27k
CR70516
LS4148
CD70517
SB
SB
9,1k
CR34514
CR34516
*
CR34517
1,8k
25
C34521
M
F
0,22u
C34522
23
21
20
22
24
M
F
0,22u
C34523
M
F
0,22u
+B
CR34521
100
60
CR34522
100
59
CR34523
100
58
AENDERUNGEN VORBEHALTEN
SUBJECT TO ALTERNATE
SOURS RESERVE DE MODIFIC
CON RISERVA DI MODIFICA
RESERV. EL DEREC. DE MODIFIC.
M
ST-CI1X
PIP-BAUSTEIN 29504-......
PIP MODULE
MODULE PIP
MODULO PIP
MODULO PIP
SEITE / PAGE SM 3-47
ST-PI1
12345
+B
+33V
M
PIP
FBAS
+Q3
+B
CD34517
61
7
6
5
M
4
3
M
2
1
6
M
SCL
SDA
LS4148
CC34517
M
270p
CR34520
M
100k
ST-RGB
SW
B
G
R
SEITE / PAGE SM 3-55 / 3-57
HOR.2FH
M
+
C34509
4,5V
10 11 121314
22n
M
M
11
30
CR70518
100
SSC
C34511
1u/100V
M
CC34542
G
PIP
+
22n
CR70506
1,2k
CR70507
180k
CR70508
3,3k
DF
14
4,7k
SCL
2,2u/100V
CC34543
B
SDA
M
+
C34510
4,7V
22n
CR34541
CR34543
PIP
62635557545352515035494847
1k
1k
LS4148
CD70506
2728
13
15
19
29
31
161718
CC70512
M
100p
CC70513
M
100p
1,5M
CR34512
4,7u/63V
M
COMP.
IC34510
TDA4780V3
CR34544
1k
CR34542
1k
CD70507
6
M
CR34513
22k
M
LS4148
M
SS
CD34513
LS4148
7,1V
3,3V
3,2V
3,3V
2,9V
2,7V
2,8V
+N
n.V.
CC70502
CC70501
M
0,1u
8910
34 35
4,7n
n.V.
CC70503
0,1u
32 33
FEATURE-BOX
29504 103 4201
29504 209 0500
29504 209 1500
M
M
61
1
43094
848B
43094
34
PIP
M
75
M
CR43061
CR43062
CR43063
CR43067
47
+
C43066
100k
100k
13
1u/100V
47
CR43066
CC43083
M
47n
8910 1112
3V 3V
3,1V
+Q1
M
M
C43082
+
220u/10V
CR43050
2,2k
CR43049
2,2k
M
IC43080
10n
M
3
3V
5
4V
18
BUS CONTROLLED VIDEO MATRIX
3V
TEA6415B
TEA6425
14 15
CR43055
2,2k
CR43054
2,2k
PIP
PIP
M
CR43059
CR43060
M
0,1V2V2V8,1V4V
CT43060
BC848B
1k
0
+Q1
CC43059
0,22u
PIP
+H
LÔ
3,9k
CR70504
CD70501
M
ZPD5,1V
REF
31
37
38
M
39
40
M
41
42
M
43
12345
PIP
CR34085
100k
M
+
C65542
M
CBR71
CR34525
Y
100
1920
CR43082
M
33
330
CR43099
M
CHROMA
10u/250V
0
CR34519
M
56
CC34526
M
2V0V0V3,3V2,8V3V 3V 3V
16 17
CT43093
BC848B
0
34
35
1
2
M
CC34519
62
CR34526
100p
-(R-Y)
VIDEO
ST-GM4
SEITE / PAGE SM 3-29
22n
15
100
M
M
CT43092
BC848B
CR43098
M
+A1
ST-GM3
CR34524
75
CC34524
100p
330
+Q1
-(B-Y)
PIP
FBAS
CR65543
1
2
3
M
4
5
6
CC34518
-(B-Y)
M
CC34520
100
820
+B
0,1u
100
-(R-Y)
100
C34501
1u/100V
22n
27k
33
CR70502
CR70510
27k
33
CR70501
CR70509
Y
100
100
100
VIDEO
-(R-Y)
U
CHROMA
GM
-(B-Y)
OSD
PIP
Y
DATA
DATA
100
U
U
VERT.
VERT.
VG
SCL
+Q3
220u/10V
+
M
C34506
47n
8,3V
M
CC34507
M
5
9
Y
8
100
3,8V
7
4V
6
4V
+
1,7V
CR46032
M
*
CR46033
*
M
CC46033
M
*
SSC
SSC
Y
MATRIX
22n
CC34503
CC34502
R
G
OSD
100
OSD
26 2728
A
D
22n
CR34509
3V
CC34504
B
OSD
220
0V5V5V5V0,7V
22n
DATA
U
3,5V
35
T43091
C858B
CC43086
A 5250-100
560k/2%
12
67
0
CR43045
47
0,1u
M
CR43071
+
C43068
FBAS
CINCH
+
C43084
1u/100V
FBAS
CD43084
4,7u/25V
CR43085
KLEMM
U
LS4148
CR43065
100k
+A
GESCHW.MODULATOR-PLATTE 29305-108.0700
VELOCITY MODULATION BOARD
PLAQUE REGULATEUR DE VITESSE
PIASTRA MODULATORE VELOCITA
PLACA MODULADOR DE VELOCIDAD
IC80050
SDA 5450
27k82k
1M
01,8k
470p
0,1u
2,7k8,2k
68p
33
33n
100180
33p15p
0
33p56p
6MHz18MHz
1u10n
220
CR43083
CR43084
1M
M
SDA
SCL
R65541
8311-212-070
4
220
CC43081
M
PIP
R65542
2
1k
CR34518
M
CC34525
M
+Q1
PIP
0
47n
CR43081
18
100p
+B
+F
L70508
035.97
09241-
CC70508
CC70506
M
4,7n
4,7n
CC70507
C70509
M
+
0,1u
1000u/25V
36
20212223 24 25 26
12
7
37
10n
CC70518
XX
CR70519
n.V.
XX
CD70519
BY
I
STAND
OWA
SDA
CR34510
2,8V
2
CI
CR46031
OSD
1234
CC46031
CC46032
BEAM
U
VERT.2FV
+Q3
1M
CR34511
220
3,3V
15 16 171819
LIMITING ZAEHLER
CC34541
*
M
M
*
M
*
PIP
R
DATA
PIP
U
CR41031
ST-CI1 ST-VGA3
11
55
SEITE / PAGE SM 3-53
1
1
SEITE / PAGE SM 3-50
SEITE / PAGE SM 3-50
12345
M
+F
VERT.2FT
TO CRT PANEL
A LA PLACA-ZOCALO TRC
ALLA PIASTRA CINESC.
VERS C.I. TUBE CATHOD
470
C41031
1
2
SEITE / PAGE SM 3-19
ST-PI2A
ST-PI2A
ST-PI2
6
0
CR34546
-K
100
SSC
+B
+A
+B2
SEITE / PAGE 32 SM 3-59 / 3-63
ZUR BILDROHRPLATTE
+B2/
+
100u/25V
9
9
789
PIP
B
G
DATA
PIP
PIP
U
CR70551
+G
+F
+LNC
PHI 55cm/BL
PHI 63cm/BL-D
PHI 63cm/BL-S
PHI 70cm/BL-D
PHI 70cm/BL-S
PHI 70cm 16:9
PHI 72cm
PHI 72cm/CAS
PHI 84cm
PHI 82cm 16:9
VC 84cm
TOSH 72cm
PAN 70cm
R
+B
+H1
L46006
*
PIP
1M/1%
+H
BRUECKE
I
CR70552
+N
NF-INVERTIERPLATTE
CR40010
CR70553
*
270k/2%
+Q
L70555
CBR070
+Q1
10u
CD70553
LS4148
+Q3
L34517
1,5k
SB
+OEKO
10u
CR34516
7,5k/2%
7,5k/2%
6,2k/2%
7,5k/2%
6,2k/2%
6,2k/2%
5,6k/2%
5,6k/2%
6,2k/2%
6,2k/2%
6,2k/2%
6,2k/2%
7,5k/2%
+B2/
BEAM
M
NETZ-CHASSIS
MAINS CHASSIS
CHASSIS DI SECTEUR
CHASSIS DI RETE
CHASIS INTERR. RED
SEITE / PAGE 19
29305-119.7800
+B2/
1,5k
CR40005
AUDIO-L
AUDIO-R
VG
VERT.
VERT.
CR40023
180
180
180
180
180
180
180
180
180
180
180
120
120
4,7k
CR40003
4,7k
CR40001
HOR.2FT
CR70553
3,9M
3,9M
6,8M
3,9M
6,8M
6,8M
6,8M
6,8M
6,8M
6,8M
6,8M
6,8M
6,8M
A
OWA
CR40004
CR40002
SS
+B
BY
STAND
U
C40003
3,3k
C40001
3,3k
CR40013
R
CR40011
A
A
CC40004
CC40002
w.w.
4,7n
4,7n
1u
F
1u
F
AA
+H
470
ZPD10
CT40010
BC848B
6,8k
A
CR41005
2,2k
10k
CR41002
CC41009
3,3n
D40006
CR40014
M
KH
AUDIO-R
CR41001
F
0,22u
2,2k
CR40007
CD40008
CR40009
M
+B2 +B2
+H
CR40012
150
1N4004
470u/16V
2,2k
CD40015
C41007
CR41007
2,2k
+G
CC40014
1k
1
A
56
C40006
+
LS4148
1k
R40013
C40013
CC40013
+
AA
2200u/35V
+
C40011
0,6V
CC40012
1,2V
1,2V
CC40022
0,6V
+
C40021
CR40023
R
22u/35V
2
3,3n
1
5
3,3n
4
22u/35V
R
*
2
1
5
4
4,7n
CC40028
CR40021
A
0,1u
24,5V
911
911
IC40020
TDA7262
67
76
A
CR40022
2,2k
56
M
KH
AUDIO-L
CR41010
2,2k
1k
CR41003
MM
CR41004
CC41008
A
CD41011
LS4148
CR41011
2,2k
10k
3,3n
470u/16V
A
+
C41014
F
0,1u
0,22u
C41006
A
CC41013
2,2k
CR41006
4
5
+
C41012
220u/10V
A
COLOR-CHASSIS
COLOUR CHASSIS
COLOUR CHASSIS
CHASSIS COLORE
CHASIS COLOR
CUC 1806
CUC 1828
CUC 1829
CUC 1830
CUC 1836
CUC 1929
A
0,1u
10
+B
R41016
IC41010
TDA3006
678
11,5V
3
9
13V
11,5V
12
CC41017
3
10
3
8
R40027
CC40027
A
0,1u
A
R40017
CC40017
A
1,8
0,1u
ST-LL
A
10k
CR40033
A
10k
CR40034
A
1
2
ST-LR
2
1
LL
LR
0,1u
C40031
+
1000u/25V
1000u/25V
+
C40033
C40032
1000u/25V
18
1,8
R40031
T40010
BC368
10k
CR40031
A
10k
CR40032
+
A
+
C40029
22u/25V
A
+B2
2
1
CC41018
4,7n
CC41022
0,1u
4,7n
CC41021
A
KH
L
0,1u
CC41029
A
KH
R
21658-907.02
181000
ST-H
1
2
3
ZUR KH-BUCHSE
A LA TOMA DE AURICUL.
ALLA PRESA CUFFIA
VERS PRISE CASQUE
TO HEADPHONE SOCKET
SEITE / PAGE 32 SM 3-59 / 3-62 / 3-63 / 3-67
23
GRUNDIG Service
24
GRUNDIG Service
Page 17
CUC 1830 / 1836 / 1929 Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams
3
3
2
2
2
2
L
Feature Box 29504 209 0500/1500
9
+F/5V
+B/12V
+N/3,3V
+H/5V
VIDEO
CHROMA
R
50
G50
B50
U
DATA
SDA
SCL
VG
I
BEAM
SS
REF
10
36
32
33
8
34
38
40
42
35
43
39
41
37
16
14
13
15
17
19
29
31
22
25
27
28
BU
BU
BU
BU
BU
n.V.
BU
BU
BU
BU
BU
BU
BU
BU
BU
BU
BU
BU
BU
BU
BU
BU
BU
BU
BU
BU
BU
BU
09241-035.97
10nF
CC1339
M
09241-035.97
09241-035.97
10nF
CC1338
M
A
M
L1401
L1402
L1403
L1407
L1353
L1351
L1357
n.V.
L1358
10u
10u
10u
10u
10u
CR2051
56
L1310
L1313
L1315
L1317
CR1401
3,3k/5%
CR1402
CD1403
LS4148
CD1407
LS4148
C1353
C1354
A A
C1357
M
C1359
CR2050
1k
+1
CR1415
CD1419
CR1414
M
330
+
CC1356
220uF/16V
MM
+
CC1352
220uF/25V
+
CC1358
220uF/16V
M
+
CC1359
100uF/35V
MM
13
8140-532-085
27p/5%
CC1306
A
CR1304
180
CR1305
180
CR1306
180
CR1307
330
1,5k
+
C1415
ZPD3,9V/2%
M
+4
43/2%
10k/5%
CR1412
CC1401
M
CC1402
M
1k/2%
CR1403
MMM M
4,7k
CR1407
0,1u
0,1u
0,1u
0,1u
CC1307
56p/5%
L1306
8
1,8u
BAR42
CD1418
10uF/50V
47n
68n
+4A
CC1403
+2
/5V
10nF
CC1340
CC1341
M M
L1361
L1362
n.V.
24156 89
7
22p/5%
CC1311
A
22p/5%
CC1313
A
22p/5%
CC1315
A
22p/5%
CC1317
A
0,1u
CC1415
M
CR1404
0
470p
CD1406
IC1310
LD1117V33C
10nF
CC1342
M
+1
+3A
+3B
+4
10nF
CC1343
M
/12V
/3,3V
/3,3V
/5V
10nF
CC1344
M
10nF
CC2049
M
CC1345
M
0,1u
10nF
CC1346
M
M
10nF
M
AA
1314151617181920212223
GND
F202004
F2000
CC1309
68p/5%
L1308
13
8
3,3u
8140-532-086
270p/5%
CC1308
A A A
L1412
4,7u
220uF/16V
M
C1423
0,1u
M
CC1422
0,1u
M
CC1419
0,1u
M
CC1417
CR1408
M
CR1405
M
CR1433
CR1434
0
M
ZPD5,1V/2%
CC1407
M
27p
CC1408
M
27p
OUTIN
11
7
L1411
4,7u
+
1,2V
25
2,5V
18
4,0V
14
SW2
11
32
0
15
34
xx
33
12
xx
27 28
SW1
26
2
Q1408
12MHz
3
12
CC1310
+4A
M
24
394041
CR2052
CR2056
A
CR2053
1,1k/2%
330p/5%
L1309
18u
xx
CC1312
L1311
18u
xx
CC1314
L1312
18u
xx
CC1316
L1314
18u
xx
CC1318
+4
L1421
17
9
CIC1410
*
S-DDC
10
M
100
1k
18p/5%
18p/5%
18p/5%
18p/5%
38
16
1
CC1347
CR1423
31
23
10nF
CC1348
M
0
43
13
19
42
44
37
36
35
30
1
4
5
6
7
8
29
20
22
21
23
CC2056
M
10nF
+1
CR2057
A
CR1303
M
M
0,1u
CC1349
M
1k
CT2057
BC858B
1,1k/2%
+4
L1423
CC1421
CR1421
M
+
C2058
M
10nF
**
CC1304
A
CC1305
A
CC1319
A
CC1320
A
CC1325
A
C1427
+
220uF/16V
CC1426
0,1u
CC1428
100p/5%
CC1410
1,5n/5%
M
1,8k/2%
10uF/50V
+3
+2
xx
Chroma(Rot)
39p/5%
CR1320
A
CR1321
39p/5%
A
CR1322
39p/5%
A
39p/5%
CR1323
A
UTVVGA
M
M
M
1n
+3
HS2/HVGA
VS2/VVGA
SCC/100
V-OUT/POS
V-OUT/NEG
+3
+4
+2
C1367
F
0,68u
1k
1k
1k
xx
LL1,5X
SDA
SCL
VBLK
HOR
OWA
/3,3V
CC2057
A
CR1311
100k
L1350
0,1u
+3
CC1330
M
+
C1350
L1352
L1360
100uH
CC1362
A
A
10uF/50V
CC1365
A
CC1366
A
Net-
0
CR1367
C1369
F
0,22u
C1312
F
0,22u
C1316
F
0,22u
CR1330
680
CIC1320
100n
TLC7733ID
1234
+
C1323
M
CC1354
100uF/35V
M
C1352
M
C1360
A
47n
C1364
+
3,3p
3,3p
M
LOE2
connection
A
5678
MM
2,2uF/50V
0,1u
+
100uF/35V
+
220uF/16V
Q1365
C1368
F
0.22u
C1314
F
0,22u
RESN
M
CC1351
MM
CC1353
M
CC1361
A
LOE1
20,25MHz
CR2063
150
0,1u
0,1u
0,1u
A
A
A
A
M
A
F
C1361
CR2062
4
31
36
57
M
66
3
1
2
67
58
68
5
6
7
8
9
59
65
64
61
63
62
60
0,22u
*
10 111213
VIN4
HC
16
M
10k
CR2060
CT2058
BC848B
OPTION A
CIC1350
*
SCL
SDA
CC1367
1n
+4
1,1k
CR2061
RES
CR2069
5455 56
2,2k
CT2059
BC848B
M
CUC 1830 / 1836 / 1929 Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams
FEATURE-BOX
15
VVGA
VS
CL1377
CR2070
20
21
22
23
24
25
28
29
38
39
40
41
42
43
46
47
17
14
26
27
30
32
35
37
33
44
51
52
50
49
48
34
45
53
19
18
BLM21A121S
8104-982.333
2,2k
LL1,5=27MHz
LL3=13.5MHz
33 34
xx
CR1371
CC1371
100uF/35V
CC1373
100uF/35V
MM
CC1375
220uF/16V
AA
xx
0,1u
0.1u
0,1u
51
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
29
CIC1360
CIP3250
30
53
19
PADS
57
35
67
65
63
54
3132
55
CC1368
Y7
Y6
Y5
Y4
Y3
Y2
Y1
Y0
C7
C6
C5
C4
C3
C2
C1
C0
BLN0
HS‘
M
CR1370
0
+2
M
M
+2
*
BR1350
CL1376
BLM21A121S
8104-982.333
+3
CC2059
A
L1370
L1372
L1374
100u
0,1u
+
C1370
M M
+
C1372
+
C1374
R50
G50
B50
FS
LL3
CC1376
M
LL1,5
CC1377
M
xx
STELLUNG
TV-BETRIEB
9
10
11
14
15
678
M
345
CR2065
CIC2020
74HC4053
1
2
13
M
12
CR2025
+4
16
CR2020
0,1u
CC2020
M
M
0
59
+
C1377
2
3
4
5
6
7
8
9
10
D-Y7
11
D-Y6
12
D-Y5
13
D-Y4
14
D-Y3
15
D-Y2
16
D-Y1
17
D-Y0
20
D-U1
C7
21
D-U0
C6
22
D-V1
C5
23
D-V0
C4
24
C3
25
C2
26
C1
27
C0
28
BLN
58
62
64
66
A
1
18
52
56
6061
68
M
A
M
1n
**
*
*
-209.03
-209.05
-209.13
0.1u
CC1378
10uF/50V
AA
+3B
+3A
LL3
LL1,5
VS
RESN
NUR VORGESEHEN
ONLY IF REQUIRED
PREVU
SOLO PREVISTO
SOLAM. PREVISTO PARA
CIC1350OPTION A
VPC3215A
VPC3211A
VPC3215A
VPC3211A
CC1692
M
CC2012
CR2016
M
SDA9362-2
SDA9362-2-209.15
0,1u
M
0
CIC1410
SDA9362
SDA9362
**
M
100uF/10V
M
M
M
M
0,1u
M
M
CC2010
0,1u
C2000
CC2001
0,1u
CC2002
0,1u
41
42
50
49
48
47
46
45
44
43
40
39
38
37
34
33
32
31
35
36
23
19
LL3
LL1,5
CC2021
+3A
+
1n
CIC2010
SDA9400
SDA9401
SDA9400
SDA9401
+3B
M M
M
51 5253
CIC2010
M
2
55 5657 5859
*
C2004
+
100uF/10V
CC2014
0,1u
CC2003
0,1u
M
M
M
63
64
1
3
4
5
6
7
10
11
12
13
14
15
16
17
18
24
25
M
9
8
M
62
CL2022
8104-982.333
BLM21A121S
26
60
54
61
CR2020
20 2122
CR2062
27 2829 30
CC2018
Q2015
27MHz
27p
BR1350
CC2019
L2018
27p
VS2
xx
CC2017
2,2k
0
2,2k
0
CC1690
M
CC1688
M
xx
MMM
29504
29504
29504
29504
0,1u
0,1u
xx
CC2022
M
+
+
B
LL1
H
GRUNDIG Service
25
GRUNDIG Service
26
Page 18
Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams CUC 1830 / 1836 / 1929
9
8
Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams CUC 1830 / 1836 / 1929
29504 209 0300
29504 209 0500
29504 209 1300
29504 209 1500
M
+3B
M
+3B
M
BLN2
LL1,5X
HS2
xx
M
M
64
65
66
67
68
25
24
23
22
21
20
19
18
16
15
14
13
12
7
6
5
2
3
4
63
60
43
28
29
41
Y7
Y6
Y5
Y4
Y3
Y2
Y1
Y0
U1
/C7
U0
/C6
V1
/C5
V0
/C4
C3
C2
C1
C0
CC1649
M
10 11
CIC1640
SDA9280
DISPLAY
PROCESSOR
>
= B22
383940
3031 32
M
1n
CR1691
2,2k
26
!!
CC1673
33
39p
42
CR1673
SDA
L1641
61 62
3637
+2
220
INPUT
GND
CR1674
SCL
V
U
Y
CC1674
39p
220
CR1681
C1641
M
51
45
48
52
58
49
54
57
56
59
55
53
50
46
47
44
35
34
27
17
9
8
1
CT1680
BC848B
CC1681
M
2,2k
CT1690
BC848B
CC1691
+
CR1661
M
xx
xx
M
220uF/16V
CC1652
CC1653
CR1659
300/2%
11k/2%
A
A
M
CR1682
M
CR1692
CC1623
M
0,1u
A
0,1u
A
A
CC1661
CR1671
CC1671
10k
10k
M
0,1u
+
C1651
+
C1656
CR1662
15k/1%
0,1u
A
6,8k/2%
1,5n/5%
CT1681
BC848B
CR1683
M
CT1691
BC848B
CR1693
M
CC1642
M
220uF/16V
A
220uF/16V
A
CC1672
+2
47k
+2
47k
xx
0,1u
L1651
L1656
L1662
10u
CR1684
CR1694
CC1644
M
CC1658
CC1657
CC1662
2,2k
M
2,2k
M
0,1u
A
A
A
0,1u
CC1646
M
CR1649
0,1u
0,1u
CR1658
C1663
CR1668
+2
+2
+
A
A
A
A
+2
150/2%
150/2%
150/2%
0,1u
CC1648
M
10uF/50V
CD1663
100uF/35V
A
10uF/50V
CD1533
LS4148
CD1534
M
LS4148
HVGA
VVGA
SSC
0,1u
C1501
10uF/50V
C1511
+
CR1663
1k
ZPD5,1V/2%
C1521
+
HOR
L1509
CR1508
68/2%
+
C1509
A
2,2u
220uF/25V
L1508
CT1506
BCX51-16
240/2%
CR1503
51k/2%
CR1501
CT1501
BC849B
+
10k/2%
CR1502
CR1504
CR1506
100/2%
CR1507
300/2%
180/2%
A
CT1516
51K/2%
CR1511
CR1512
+1
CR1521
CR1522
CT1511
BC849B
10k/2%
A
51k/2%
CT1521
BC849B
10k/2%
CR1513
CR1514
CR1523
CR1524
240/2%
CR1516
100/2%
CR1517
300/2%
180/2%
240/2%
CR1526
100/2%
CR1527
200/2%
180/2%
BCX51-16
CT1526
BCX51-16
CR1518
68/2%
CR1528
68/2%
CC1526
A
L1518
0,1u
A
L1532
10u
L1531
CT1561
CR1562
+2
VBLK
M
CD1532
LS4148
CD1530
LS4148
CR1561
2,2k
CR1532
100
CR1531
100
CR1541
4,7k
BC848B
CR1544
620
M
CT1541
BC848B
CR1543
M
56
CR1563
560
CR1542
L1543
330
BC848B
CT1545
L1538
L1563
220
10u
CR1549
M
10u
+2
10u
L1533
L1536
L1537
CR1546
220
CR1545
56
L1546
10u
470
L1544
10u
+7
+1
BU
5
-(R-Y)
100
BU
6
BU-
Y/100
01
MASSE
02
-(B-Y)/100
03
MASSE
+7
BU
3
-(B-Y)
100
BU
4
+7
BU
1
Y
100
BU
2
BU
7
VERT.2FV
VVGA
BU
18
CSY
BU
21
DF
BU
12
VVGA
BU
11
HVGA
BU
26
SSC
100
04
-(R-Y)/100
05
06
VERT.2FV
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
SSC 100
27
28
29
30
HOR.2FH
31
32
33
34
35
36
U
37
MASSE ANALOG
38
39
MASSE ANALOG
40
41
MASSE ANALOG
42
43
MASSE
+H (+4/5V)
+F (+2/5V)
+F (+2/5V)
HVGA
VVGA
MASSE
SCL
MASSE
SDA
MASSE
CSY
MASSE
OWA
DF
VG
V/AP
V/AN
IBEAM
SS
MASSE
MASSE
+N (+3/5V)
+N (+3/5V)
FBAS
CHROMA
+B(+1/12V)
DATA
G50
B50
R50
REF
50
C
BCX
51-16
E
C
B
IC VON OBEN
IC TOP VIEW
IC VUES DE DESSOUS
IC VEDUTO DA SOPRA
IC VISTO DESDE ARRIBA
44
1
CIC1410
SDA9362
11
12
64
1
CIC2010
SDA9400
16
17
168
10
CIC1350
CIC1360
CIC1640
26
27 43
VPC3215A
CIP3250
SDA9280
C
BC84
84
E
B
34
33
23
22
49
48
33
32
61
60
44
+1
BU
30
HOR.2FH
+1
BU
20
OWA
BU
23
V/AP
BU
24
V/AN
060300
27
GRUNDIG Service
28
GRUNDIG Service
Page 19
CUC 1830 / 1836 / 1929 Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams
CT1526
CR2065
CR1673
CR1674
CR2063
CR2016
CR1367
CR2025
CC1644
CC1646
CC1674
CC1673
CC1422
CC1339
CC1346
CC2020
CC1378
CC1362
CC1415
CD1418
CC1672
CC1345
LOE2
CL1376
CC1330
34
23
12
1
CIC1410
CIC1360
CIC1350
CIC1640
CR1691
CT1506 CT1516
64
49
48 33
32
17
16
1
CIC2010
1
CIC1320
1
CIC2020
29304-686.42/4BS(03)
0
10
20
30
40
50
60
70
80
90
100
110
120
Y
0102030405060708090100110120130140150160170
X
BestŸckungsseite, Ansicht von oben / Component Side, Top View
120
CUC 1830 / 1836 / 1929 Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams
29304-686.42/4B(03)
3
C2058
L1352
1
LOE1
L1360
C1360
1
C1323
L1308
L1306
C1357
IC1310
C1352
C1368
F2000
C1367
C1364
1
C1369
L1309
42
43
L1312
L1350
C1350
C1316 C1312
C1314
L1311
L1313
L1315
L1310
C1370 C1372
L1370
Q1365
C1377
C1354
L1314
L1351
L1543
L1317
1
C1361
L1374
C1374
L1407
L1372
L1537
L1403
L1402
C2000
Q2015
BR1350
L1538
L1544
1
C1415
L1401
L1563
L1362
L1361
L1546
Q1408
23
L1531
C1641
C2004
L2018
1
L1411
1
L1533
L1412
L1641
1
L1536
C1427
L1358
L1532
L1421
C1423
L1423
L1508
L1518
C1359
2
1
C1656
C1521
BU
L1662
C1663
L1509
L1353L1357
L1656
L1651
C1501
C1353
C1651
C1509
110
100
90
80
70
60
50
C1511
40
30
20
10
0
Y
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
BR1350 88 59
BU 85 2
C1312 121 47
C1314 125 47
C1316 130 47
C1323 160 36
C1350 129 101
C1352 141 101
C1353 11 16
C1354 109 34
C1357 161 16
C1359 38 29
C1360 161 60
C1361 97 57
C1364 140 46
C1367 151 47
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
C1368 154 38
C1369 134 47
C1370 113 101
C1372 94 101
C1374 103 43
C1377 113 46
C1415 77 47
C1423 49 37
C1427 51 47
C1501 23 46
C1509 10 60
C1511 13 46
C1521 32 46
C1641 56 101
C1651 20 76
C1656 25 87
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
C1663 20 63
C2000 85 102
C2004 65 102
C2058 160 107
F2000 144 29
IC1310 151 106
L1306 152 21
L1308 155 29
L1309 138 28
L1310 133 21
L1311 126 34
L1312 133 36
L1313 125 21
L1314 119 34
L1315 129 21
L1317 121 21
0102030405060708090100110120130140150160170
X
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
L1350 123 105
L1351 115 22
L1352 159 93
L1353 19 9
L1357 150 9
L1358 51 23
L1360 159 74
L1361 79 105
L1362 71 105
L1370 119 105
L1372 101 105
L1374 101 49
L1401 81 22
L1402 94 22
L1403 102 22
L1407 106 22
L1411 66 22
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
L1412 62 22
L1421 42 42
L1423 38 43
L1508 31 21
L1509 21 54
L1518 31 18
L1531 70 22
L1532 47 23
L1533 58 22
L1536 55 22
L1537 98 22
L1538 91 22
L1543 109 22
L1544 85 22
L1546 73 22
L1563 77 22
L1641 48 105
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
L1651 13 70
L1656 13 83
L1662 28 69
L2018 69 93
LOE01 158 84
Q1365 132 56
Q1408 62 56
Q2015 79 93
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CC1330 163 53
CC1339 44 15
CC1345 106 111
CC1346 83 111
CC1362 141 58
CC1378 121 65
CC1415 77 38
CC1422 55 42
CC1644 38 60
CC1646 42 92
CC1672 34 60
CC1673 45 59
CC1674 49 59
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CC2020 88 36
CD1418 78 56
CIC1320 161 46
CIC1350 138 74
CIC1360 105 75
CIC1410 65 42
CIC1640 48 76
CIC2010 77 76
CIC2020 89 43
CL1376 122 73
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CR1367 149 56
CR1673 48 55
CR1674 49 57
CR1691 77 33
CR2016 71 88
CR2025 94 36
CR2063 97 44
CR2065 84 49
CT1506 22 30
CT1516 14 30
CT1526 30 30
LOE02 154 67
GRUNDIG Service
29
GRUNDIG Service
30
Page 20
Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams CUC 1830 / 1836 / 1929
AUDIO-L
CAV
AUDIO-R
CAV
R44503
470
FBAS
L
R
1
2
3
BU10
KH
AUDIO-R
KH
AUDIO-L
K
470p
C44501
R44501
470
K
8,2n
C41502
K
5,6n
C41501
K
5,6n
C41503
K
470p
C44503
R44504
*
CINCH
R41501
*
R
L
FBAS
S-VHS
F
0,22u
CC44508
+
*
C44504A
R41503
*
K
0,1u
C41504
U
IDEN1
+H
n.V.
K
1n
C44511
K
8,2n
C44506
BRU100
47k
R44511
n.V.
82k
R44508
+
*
C44502A
BC558C
T44510
BC548B
T44505
3,3k
R44506
1,8k
R44507
1
2
ST-ID
FBAS
S-VHS
AUDIO-L
CAV
AUDIO-R
CAV
1
2
3
4
5
ST-CI2
KH
AUDIO-L
KH
AUDIO-R
1
2
3
ST-H1
CINCH
1
2
3
ST-H
+
*
C44504
CINCH
+
*
C44502
1
2
3
4
5
ST-CI1
+H
+H
V
V
VV
V
V
V
V
V
V
A
A
A
A
A
A
A
KH
KH
KH
KH
KH
BUCHSENPLATTE 29305 008 3400
190500
-008.4600
29305 008 4600
NUR BEI .3800/3900
29305 008 4100
29305 008 3900
29305 008 3800
-008.4100
-008.3900
-008.3800
-008.3400
75
75
75
R44504
SOLAM. CON
SEUL. POUR
33
X
X
X
X
X
2,2U/100V
2,2U/100V
2,2U/100V
2,2U/100V
2,2U/100V
100
100
100
33
BRU100
ST-H
ST-CT2ST-CT1
ST-ID
ST-H1
C44502A
C44504AC44504
C44502
R41503
R41501
*
*
*
*
SOLO NELLA
ONLY WITH
A LA PLACA INTERRUPTOR RED
ALLA PIASTRA INTERR. DI RETE
VERS C.I. INTERR. SECTEUR
TO MAINS SWITCH BOARD
ZUR NETZSCHALTERPLATTE
*
*
*
AL CHASIS SENAL
AL CHASIS SENAL
AL CHASSIS SEGNALE
AL CHASSIS SEGNALE
VERS CHASSIS SIGNAL
VERS CHASSIS SIGNAL
TO SIGNAL CHASSIS
TO SIGNAL CHASSIS
ZUM SIGNAL-CHASSIS
ZUM SIGNAL-CHASSIS
PLACA DE TOMAS
C.I.PRISES
PIASTRA PRESE
SOCKET BOARD
SEITE/PAGE 24
SEITE/PAGE 24
R44506
R44507
C44502A
51
C44504A
R41503
CINCH
2
1
ST-H
C44504
C44502
R4450131R44503
51
ST-CI1
C44503
C41503
C41501
C41502
C44501
21
CE
T44505
CE
T44510
BU10
R44508
R44511
R44504
C44506
C44511
C41504
BRU100
R41501
BRU001
R44505
C44508
C44505
MI-
1
6
3
2
5
48
7
0
51
42
3
9
/4B(04)
29304-678.34
Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams CUC 1830 / 1836 / 1929
Lštseite, Ansicht von unten / Solder Side, Bottom View
120
110
100
CC1653
CR1659
CC1662
CR1662
CR1661
CC1661
CC1652
90
80
CC1657
CC1658
CD1663
70
CC1341
60
50
40
30
CR1512
CR1514
CC1526
CT1511
CR1663
CR1671
CC1671
CR1649
CR1501
CR1658
CR1502
CR1511
CR1517
CR1518
CR1503
CR1513
CT1501
CR1504
CR1506
CR1516
CR1507
CR1508
CR1522
CT1521
CR1524
CR1528
CR1668
CR1527
CR1521
CR1523
CR1526
CC1359
CT1681
20
10
0
Y
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
CC1304 150 37
CC1305 136 38
CC1306 148 15
CC1307 151 16
CC1308 158 24
CC1309 150 26
CC1310 159 29
CC1311 139 28
CC1312 136 30
CC1313 123 23
CC1314 124 31
CC1315 130 23
CC1316 133 33
CC1317 118 28
CC1318 117 37
CC1319 123 39
CC1320 130 38
CC1325 117 39
CC1338 147 9
CC1340 16 7
CC1341 8 67
CC1342 48 106
CC1343 89 106
CC1344 121 107
CC1347 163 105
CC1348 163 87
CC1349 162 21
CC1351 134 86
CC1352 112 35
CC1353 139 86
CC1354 135 68
CC1356 10 12
CC1358 162 19
CC1359 41 32
31
X
CC1356
0
XY
CC1340
10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
CC1361 144 62
CC1365 136 59
CC1366 128 59
CC1367 144 73
CC1368 109 76
CC1371 112 78
CC1373 94 77
CC1375 109 67
CC1376 117 75
CC1377 118 70
CC1401 84 33
CC1402 90 33
CC1403 107 43
CC1407 59 53
CC1408 65 53
CC1410 52 47
CC1417 67 38
CC1419 69 38
CC1421 60 47
CC1426 65 43
CC1428 59 44
CC1526 10 53
CC1623 60 67
CC1642 49 67
CC1648 56 83
CC1649 63 69
CC1652 36 71
CC1653 33 87
CC1657 8 81
CC1658 8 73
CC1661 28 83
CC1662 17 66
CC1671 33 62
XY
CC1342
CC1648
CC1623
CC1642
CC1407
CC1421
CC1410
CR1421
CC1428
CR1433
CR1404
CR1405
CR1681
CT1680
CC1681
CR1531
CR1684
CR1683
CR1682
CD1534
CD1533
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
CC1681 54 25
CC1688 68 78
CC1690 77 78
CC1691 96 35
CC1692 81 74
CC2001 76 67
CC2002 81 68
CC2003 77 72
CC2010 82 100
CC2012 86 82
CC2014 68 100
CC2017 69 90
CC2018 82 89
CC2019 77 89
CC2021 90 85
CC2022 70 75
CC2049 148 107
CC2056 155 107
CC2057 159 76
CC2059 98 49
CD1403 101 35
CD1406 104 35
CD1407 102 23
CD1419 69 49
CD1530 65 21
CD1532 69 21
CD1533 55 20
CD1534 58 21
CD1663 14 65
CL1377 122 71
CL2022 73 82
CR1303 157 37
CC2014
CC2017
CL2022
CC1688
CC2022
CC1649
CC2003
CC2001
CR1415
CC1408
CD1419
CR1414
CR1434
CC1426
CR1561
CC1419
CC1417
CR1423
CR1408
CR1532
CR1549
CD1532
CD1530
CR1544
CT1545
CR1545
XY
CC1343
CC2010
CC2018
CC2019
CC2012
CC1690
CC1692
CC2002
CR2070
CT2059
CC1401
CR1401
CR1412
CT1561 CT1541
CR1562
CR1563
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
CR1304 134 24
CR1305 126 24
CR1306 130 30
CR1307 120 32
CR1311 161 49
CR1320 136 41
CR1321 123 41
CR1322 130 41
CR1323 117 42
CR1330 157 51
CR1370 129 78
CR1371 99 86
CR1401 78 35
CR1402 92 33
CR1403 107 40
CR1404 54 37
CR1405 58 37
CR1407 98 32
CR1408 62 37
CR1412 81 35
CR1414 65 48
CR1415 69 54
CR1421 57 44
CR1423 65 37
CR1433 58 39
CR1434 62 41
CR1501 25 46
CR1502 19 46
CR1503 25 39
CR1504 20 34
CR1506 24 34
CR1507 23 32
CR1508 20 21
CR1511 15 46
CC2021
CR2069
CR2062
CR2020
CC1402
CT1691
CR1694
CT2058
CR1402
CR1692
CR1371
CC1373
CR2061
CC2059
CR1407
CC1691
CT1690
CR1693
29304-686.42/4LS(03)
XY
CC1371
CC1376
CC1368
CL1377
CC1377
CC1375
CR2060
CC1403
CR1323
CC1325
CC1352
CR1403
CR1543
CC1318
CD1403
CD1407
CD1406
CR1541
CR1307
CC1317
CR1546
CR1542
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
CR1512 10 46
CR1513 15 39
CR1514 10 34
CR1516 15 34
CR1517 13 32
CR1518 15 21
CR1521 35 46
CR1522 29 46
CR1523 35 39
CR1524 29 34
CR1526 33 34
CR1527 32 32
CR1528 30 21
CR1531 62 24
CR1532 62 22
CR1541 106 20
CR1542 111 22
CR1543 107 32
CR1544 75 32
CR1545 72 19
CR1546 114 26
CR1549 69 25
CR1561 75 35
CR1562 85 24
CR1563 79 20
CR1649 21 53
CR1658 16 49
CR1659 30 84
CR1661 23 79
CR1662 25 79
CR1663 17 61
CR1668 29 50
CR1671 33 64
CR1681 53 34
CC1344
CR1321
CC1319
CC1313
CR1370
CC1366
CC1314
CR1305
CC1351
CC1353
CC1367
CC1354
CC1365
CR2057
CR1322
CR1320
CC1320
CC1305
CC1316
CC1312
CR1306
CC1311
CR1304
CC1315
CR2050
CR2051
XY
CC2049
CC2056
CC2057
CC1361
CT2057
CR2056
CR1330
CR2052
CC1304
CR1303
CR2053
CC1310
CC1309
CC1308
CC1306
CC1349
CC1307
CC1358
CC1338
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
CR1682 47 20
CR1683 51 22
CR1684 44 22
CR1692 90 20
CR1693 97 20
CR1694 87 22
CR2020 90 45
CR2050 138 20
CR2051 144 16
CR2052 144 44
CR2053 150 32
CR2056 145 42
CR2057 139 46
CR2060 99 43
CR2061 94 47
CR2062 86 46
CR2069 90 47
CR2070 82 49
CT1501 21 39
CT1511 11 39
CT1521 30 39
CT1541 107 23
CT1545 74 24
CT1561 81 24
CT1680 49 25
CT1681 43 26
CT1690 97 24
CT1691 91 24
CT2057 145 47
CT2058 95 43
CT2059 82 46
GRUNDIG Service
CC1347
CC1348
CR1311
XY
Buchsenplatte / Socket Board 29305 008 4600
BestŸckungsseite, Ansicht von oben
Component Side, Top View
32
GRUNDIG Service
Page 21
CUC 1830 / 1836 / 1929 Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams
NETZ1
NETZ_
NETZ2
NETZ
R62202
SI62001
C62001
C62002
S6000
C84001
13
IC84001
D85001
R83002
R83001
R84001
R83003
R83004
R84002
R81000
R81001
R81003
R81005
R81004
R81002
EC
T81002
E
B
T81001
D81501
R22011
ST-E
C22001
BR100
L62001
BR81501
BR101
BR102
BR103
17
ST-IR\KBA
+P
-L
+L
-P
T3,15AH
29306-202.32/4B(00)
Netztrennung
keine
Bedieneinheit / Control Unit 29501 085 1300
R84002
+OEKO
R81003
T81002
BC548B
IRIR
BR81501
29501 085 1300BED.-EINHEIT
15k
100
R81004
10k
n.V.
+OEKO
R81002
R81005
-L
-L
R83004
8,2k
+L
+L
R83003
4,7k
-P
-P
R83002
22k
10k
2,2k
R83001
1,2k
+H
+P
+P
D85001
TLHR4601
+OEKO
+H
ST-IR\KBA
7
6
IR
5
4
3
2
1
AMP
IR
+H
KB
U
POWER
OFF
U
+OEKO
IR
+OEKO
1N4148
D81501
IC84001
TFMS5300
1
CONTROL UNIT
UNITE DE COMMANDE
UNITA DI COMANDO
UNIDAD DE MANDO
IR
3
+
C84001
IR
R84001
47u/10V
270
+H +H
T81001
2SD1866TV2
+5V
2
IR
R81001
4,7k
S6000
S2KO004
IR
n.V.
10k
R81000
LED1
CUC 1830 / 1836 / 1929 Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams
BestŸckungsseite, Ansicht von oben
Component Side, Top View
ZUM CHASSIS
TO CHASSIS
VERS CHASSIS
AL TELAIO
AL CHASIS
SEITE/PAGE 21
ZUM CHASSIS
TO CHASSIS
VERS CHASSIS
AL TELAIO
AL CHASIS
SEITE/PAGE 17
NETZ
NETZ1
ST-E
1
1
1
2
C22001
F
0,1u/MKS4-R/250V_AC
T3,15AH
SI62001
!
L62001
F
C62001
29500-835.97
0,47u/MP3/250V_AC
R22011
8311-200-...
F
C62002
0,33u/MP-KT/250V_AC
R62202
NTC4,7
NICHT NETZGETRENNTES SCHALTUNGSTEIL
CIRCUIT NOT MAINS ISOLATED
CIRCUIT NON ISOLE DU SECTEUR
CIRCUITO NON SEPAR., DALA RETE
SECTOUR DE COM. NO SEP. DE LA RED
NETZ2
1
1
NETZ_
300500
ZUM CHASSIS
TO CHASSIS
VERS CHASSIS
AL TELAIO
AL CHASIS
SEITE/PAGE 17
GRUNDIG Service
33
GRUNDIG Service
34
Page 22
Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams CUC 1830 / 1836 / 1929
R81505
D81501
31
ST-IR1
R62501
R62505
21
ST-KB
12
34
C62505
C62501
SI62501
BE
T81501
CE
T81502
R81503 R81501
R81500
R81504
R81502
34
5
12
HAN
SPULE
43
21
ST-E
C62502
71
ST-IR-KB
29304-540.98/4b(02)
Netz 3
keine netztrennung
Netz 2
Netz 1
T 3.15 AH
Netzschalterplatte / Mains Switch Board 29305 165 7700
NETZSCHALTERPLATTE 29305 165 6800
MAINS SWITCH PANEL
C.I. INTERR. SECTEUR
PIASTRA INTERR. DI RETE
PLACA INTERRUPTOR RED
29305 165 7000
29305 165 7700
Platinenabbildungen und SchaltplŠne / Layout of the PCBs and Circuit Diagrams CUC 1830 / 1836 / 1929
BestŸckungsseite, Ansicht von oben / Component Side, Top View
SEITE/PAGE 21
LA PLACA DE TOMAS CINCH
ALLA PIASTRA PRESE CINCH
VERS C.I.PRISES CINCH
TO PHONE SOCKET BOARD
ZUR CINCH-BUCHSENPLATTE
AL TECLADO
ALLA TASTIERA
VERS CLAVIER
TO KEYBOARD
ZUM KEYBOARD
IR
+H
KB
+H
ST-IR1
ST-KB
+OEKO
1
2
3
1
2
1N4148
D81501
+H
IR
+H
28500-708.97
T81501
2SD1866TV2
IR
S60000
R81501
10k
R81500
IR
+OEKO
15k
R81503
T81502
4,7k
BC548B
R81504
n.V.
IR
NICHT NETZGETR.SCHALTUNGSTEIL
CIRCUIT NOT MAINS ISOLATED
CIRCUIT NON ISOLE DU SECTEUR
CIRCUITO NON SEPAR., DALA RETE
SECDOR DE COM. NO SEP. DE LA RED
10k
+OEKO
R81502
R81505
IR
22k
10k
+H
D85001
TLHR4601
+H
IR
+OEKO
ST-IR-KB
7
6
5
4
3
2
1
IR
+H
KB
U
LED1
POWER
OFF
U
+OEKO
ZUM CHASSIS
TO CHASSIS
VERS CHASSIS
AL TELAIO
AL CHASIS
SEITE/PAGE 21
!
SI62501
T3,15AH
29500-834.97
F
C62501
DEMAGNETISACION
SMAGNETIZZAZIONE
DEMAGNETISATION
DEGAUSSING
ENTMAGNETISIERUNG
ST-E
1
2
F
C62505
3
0,1u/MKS4-R/250V~
1
2
R62505
8311-200-012
12
3
L62501
0,47u/MP3/250V~
F
4
C62502
0,33u/MP3/250V~
R62501
NTC4,7
NETZ2
1
2
NETZ1
2
1
250500
4
3
2
1
ZUM CHASSIS
TO CHASSIS
VERS CHASSIS
AL TELAIO
AL CHASIS
SEITE/PAGE 17
35
GRUNDIG Service
36
GRUNDIG Service
Page 23
GRUNDIG Service 37
Ķ
Ersatzteilliste
Spare Parts List
4 / 2000
MATERIAL-NR. / PART NO.: 92195 201 7500 BESTELL-NR. / ORDER NO.: G.CL 78-75 SCHWARZ/BLACK
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
92195 201 7500 VNM M 72-01 SCHWARZ M 72-01 BLACK
0200.000 29625 742 0100 GEH-VORDERTEIL OFB GEH-VORDERTEIL OFB
0201.000 19115 007 9700 2 HOCHTON-LAUTSPRECHER TWEETER LOUDSPEAKER
0207.000 29633 810 0100 GITTER M.STOFF KPL GRILLE WITH CLOTH CPL.
0207.000 29633 811 0100 GITTER M.STOFF KPL GRILLE WITH CLOTH CPL.
0229.000 29602 603 5100 EMBLEM GRUNDIG EMBLEM GRUNDIG
0230.000 29636 615 0101 IR-FENSTER DRUCK KPL IR WINDOW PRINT CPL
0250.000 29501 599 0102 ABDECKUNG S-BUCHSEN COVER S-SOCKETS
0300.000 29636 121 0300 GEH-RUECKTEIL LACKIERT KPL REAR PART VARNISHED CPL
0310.000 19154 043 6100 2 LAUTSPRECHER RUND LOUDSPEAKER ROUND
0320.000 29110 223 0501 TYPENAUFKLEBER VNM TYPE LABEL VNM
0700.000
S 09246 134 7800 SPULE ENTMAGNETISIERUNG M.HALTER COIL DEGAUSSING W.HOLDER
0770.000 29628 760 0104 ZWISCHENSTUECK OBEN RECHT INTERMEDIATE PIECE TOP RH
0770.000 29628 761 0104 ZWISCHENSTUECK OBEN LINKS INTERMEDIATE PIECE TOP LH
0770.000 29628 762 0104 ZWISCHENSTUECK UNTEN RECHTS INTERMEDIATE PIECE BOTTOM RH
0770.000 29628 763 0104 ZWISCHENSTUECK UNTEN LINKS INTERMEDIATE PIECE BOTTOM LH
0960.000 29305 008 4600 BUCHSENPLATTE SOCKET BOARD
0972.000 29633 780 0100 ABDECKUNG BUCHSEN COVER SOCKET
0983.000 29303 390 4200 KOPFHOERERBUCHSE 3,5 O.SCHALTER HEADPHONE SOCKET 3,5 W/O SWITCH
0984.000 29303 168 0503 CINCH-BUCHSE 3-FACH FBAS/NF L,R CINCH SOCKET 3 FOLD FBAS/AF L,R
1100.000
S 83000 682 0400 BILDR.A 68 ESF 202X143 PHILIPS PICT.TUBE A 68 ESF 202X143 PHILIPS
1200.000 S 29201 360 1106 ANODENKAPPE M.HOCHSPANNUNGSKABEL ANODE CAP W.HIGH VOLTAGE CABLE
1300.000 29501 085 1300 BEDIENEINHEIT CONTROL UNIT
1306.000 29501 666 0100 FIXIERUNG BEDIENTEIL FIXATION CONTROL
1311.000 29703 357 0100 TASTSCHALTER PROGRAMM + KEY SWITCH PROGRAMME +
1312.000 29703 357 0100 TASTSCHALTER PROGRAMM - KEY SWITCH PROGRAMME -
1313.000 29703 357 0100 TASTSCHALTER LAUTSTAERKE + KEY SWITCH VOLUME +
1314.000 29703 357 0100 TASTSCHALTER LAUTSTAERKE + KEY SWITCH VOLUME +
1315.000 29501 668 0104 TASTENSATZ PROGRAMM/LAUTSTAERKE KEY SET PROGRAMME/VOLUME
1350.000 29501 643 0104 NETZTASTENKNOPF POWER KEY BUTTON
1360.000
S 29703 291 7105 NETZSCHALTER ECO O.WISCHER POWER SWITCH ECO W/O WIPER
1390.000
S 09621 113 0206 2 SICHERUNGSHALTER FUSE HOLDER
2100.000
S 82909 913 1600 NETZKABEL KPL POWER CABLE CPL
2300.000 S 29305 122 1700 X BILDROHRPLATTE PICTURE TUBE BOARD
2400.000 29642 061 1001 TP 810 C FERNBEDIENUNG TP 810 C REMOTE CONTROL
21952 941 0100 BEDIENUNGSANLEITUNG D OPERATING INSTRUCTIONS D
72010 026 9000 SERVICE MANUAL D/GB SERVICE MANUAL D/GB
72010 026 9100 SERVICE MANUAL D/GB 1.ERGAENZUNG SERVICE MANUAL D/GB 1ST SUPPLEMENT
72010 026 9300 SERVICE MANUAL D/GB 3.ERGAENZUNG SERVICE MANUAL D/GB 3RD SUPPLEMENT
29656 004 2500 MONTAGEZUBEHOER F.BILDROHR MOUNTING ACCESSORIES F.PICTURE
29701 096 7100 X CHASSIS-FS-STEREO DIGI BASIC ++ CHASSIS TV STEREO DIGI BASIC ++
d©
KEIN E-TEIL NO SPARE PART
KEIN E-TEIL NO SPARE PART
CUC 1830 INL/4:3 CUC 1830 INL/4:3
KEIN E-TEIL NO SPARE PART
X = SIEHE GESONDERTE E-LISTE X = SEE SEPARATE PARTS LIST
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
VERSION NR./VERSION NO.: VNM
M 72-01
TV
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
29305 008 4600 BUCHSENPLATTE
C 41504 86682 030 2300 ABBLOCK-C 0,1 UF
29501 085 1300 BEDIENEINHEIT
C 62001
S 85117 930 4700 FOKO MP3 0,47UF 20% 250VW
D 81501 83092 150 4500 DIODE 1N4148
IC 84001 83053 675 3000 IC TFMS5300 STEHEND
L 62001
S 29500 835 9700 ENTSTOER-DR 2X22MH
R 22011
S 83112 000 1600 PTC DUO
R 62202 83110 050 1700 NTC 4,7 OHM 30%
SI 62001
S 83156 225 0300 SI 5X20 T3,15A H 250V
T 81001 83032 028 7500 TRANS 2SD1866TV2
T 81002 83032 055 4800 TRANS BC548B/ BC547B
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 72010 800 0000, sowie zusätzlich die eventuell
abweichenden, landesspezifischen Vorschriften!
SOCKET BOARD
CONTROL UNIT
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
29625 742 0100
29501 643 0104
29501 668 0104
29602 603 5100
29303 168 0503
29303 390 4200
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 72010 800 0000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
CUC 1830 / 1836 / 1929 Ersatzteillisten / Spare Parts Lists
Page 24
38 GRUNDIG Service
Ķ
Ersatzteillisten / Spare Parts Lists CUC 1830 / 1836 / 1929
Ķ
Ersatzteilliste
Spare Parts List
11 / 2000
MATERIAL-NR. / PART NO.: 921952017500 BESTELL-NR. / ORDER NO.: GCL7875 SCHWARZ/BLACK
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
921952017500 M 72-01 SCHWARZ M 72-01 BLACK
0208.000 297006280307 ABDECKUNG BASIC ++ COVER BASIC ++
0231.000
S 296288210100 FOLIE ISOLIERUNG BRANDSCHUTZ FOIL INSULATION FIRE PROTECTION
0320.000 291102230602 TYPENAUFKLEBER TYPE LABEL SELF ADHESIVE
0350.000 296284830103 2 DISTANZSTUECK BILDROHR SPACER PICTURE TUBE
0700.000
S 092461347500 SPULE ENTMAGNETISIERUNG DEGAUSSING COIL W.HOLDER
0963.000 295016650100 HALTER BUCHSENPLATTE HOLDER SOCKET BOARD
2410.000 267280070001 DECKEL BATTERIE BATTERY LID
296560041600 MONTAGEZUBEHOER F.BILDROHR MOUNTING ACCESSORIES F.PICT.TUBE
297040152700 X CHASSIS-FS-STEREO BASIC++/INL CHASSIS TV STEREO BASIC++/INL
d©
KEIN E-TEIL NO SPARE PART
KEIN E-TEIL NO SPARE PART
CUC 1830 CUC 1830
KEIN E-TEIL NO SPARE PART
X = SIEHE GESONDERTE E-LISTE X = SEE SEPARATE PARTS LIST
ALLE WEITEREN TEILE SIEHE E-LISTE FOR ALL OTHER PARTS SEE
M 72-01 M 72-01
MAT.-NR.: 921952017500 PART NO.: 921952017500
BESTELL-NR.: GCL7875 ORDER NO.: GCL7875
AUSGABE 4/2000 EDITION 4/2000
VERSION NR.: VNM VERSION NO.: VNM
VERSION NR./VERSION NO.: VNA
M 72-01
TV
Ersatzteilliste
Spare Parts List
10 / 2000
MATERIAL-NR. / PART NO.: 921696888100 BESTELL-NR. / ORDER NO.: GCG1600 SCHWARZ/BLACK
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
921696888100 ST 63-270/8 IDTV 2 SCHWARZ ST 63-270/8 IDTV 2 BLACK
0200.000 296354280201 GEH-VORDERTEIL DRUCK KPL CABINET FRONT PART PRINT CPL
0201.000 191260349700 2 LAUTSPRECHER 70X165MM LOUDSPEAKER 70X165MM
0208.000 297006280307 ABDECKUNG BASIC ++ COVER BASIC ++
0211.000 296360320100 ABDECKUNG BUCHSEN CINCH COVER SOCKET CINCH
0218.000 295016880106 NETZTASTENKNOPF KEY POWER
0219.000 296284170101 DRUCKFEDER NETZTASTE PRESSURE SPRING KEY POWER
0229.000 296321140102 EMBLEM GRUNDIG EMBLEM GRUNDIG
0230.000 296334310100 INFRA-FENSTER INFRA WINDOW
0300.000 296362940100 GEH-RUECKTEIL OFB CABINET REAR PART SURFACE TREATED
0320.000 291103646301 TYPENAUFKLEBER VNM TYPE LABEL VNM
0700.000
S 092461307504 ENTMAGNETISIERUNGSSPULE M.HALTER DEGAUSSING COIL W.HOLDER
1100.000
S 830002041200 BILDR.A59EAK071X44 PHILIPS PICT.TUBE A59EAK071X44 PHILIPS
1110.000 S 292013600211 ANODENKAPPE M.HOCHSPANNUNGSKABEL ANODE CAP W.HIGH VOLTAGE CABLE
1300.000 295010827500 BEDIENEINHEIT BASIC ++ CONTROL UNIT BASIC ++
1311.000 297033571100 TASTSCHALTER PROGRAMM+ KEY SWITCH PROGRAMME+
1312.000 297033571100 TASTSCHALTER PROGRAMM- KEY SWITCH PROGRAMME-
1313.000 297033571100 TASTSCHALTER LAUTSTAERKE+ KEY SWITCH VOLUME+
1314.000 297033571100 TASTSCHALTER LAUTSTAERKE- KEY SWITCH VOLUME-
1350.000 295016710602 TASTEN-SATZ PROGRAMM/LAUTSTAERKE KEYS SET PROGRAMME/VOLUME
1360.000
S 297032917105 NETZSCHALTER ECO O.WISCHER POWER SWITCH ECO W/O WIPE
1383.000 293033904200 KOPFHOERERBUCHSE 3,5 O.SCHALTER HEADPHONE SOCKET 3,5 W/O SWITCH
1384.000 293031688100 CINCH-BUCHSE 3-FACH FBAS/NF L,R CINCH SOCKET 3 FOLD FBAS/AF L,R
1390.000
S 096211130206 2 SICHERUNGSHALTER SI62501 FUSE HOLDER SI62501
2100.000
S 829099131600 NETZKABEL KPL POWER CABLE CPL
2300.000 S 293051221700 X BILDROHRPLATTE PICTURE TUBE BOARD
2400.000 296420610104 TP 800 TELEPILOT TP 800 TELEPILOT
2410.000 759540590100 DECKEL BATTERIE TP 800 BATTERY LID TP 800
216969410400 BEDIENUNGSANLEITUNG PL/CZ/H OPERATING INSTRUCTION PL/CZ/H
720100269000 SERVICE MANUAL D/GB SERVICE MANUAL D/GB
72010 026 9100 SERVICE MANUAL D/GB 1.ERGAENZUNG SERVICE MANUAL D/GB 1ST SUPPLEMENT
720100269300 SERVICE MANUAL D/GB 3.ERGAENZUNG SERVICE MANUAL D/GB 3RD SUPPLEMENT
296560040100 MONTAGEZUBEHOER F.BILDROHR MOUNTING ACCESSORIES F.PT
297040150300 X CHASSIS-FS-STEREO CHASSIS TV STEREO
d©
KEIN E-TEIL NO SPARE PART
KEIN E-TEIL NO SPARE PART
CUC 1836 BASIC++/INL 4:3 CUC 1836 BASIC++/INL 4:3
KEIN E-TEIL NO SPARE PART
ST 63-270/8 IDTV 2
VERSION NR./VERSION NO.: VNM
TV
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 720108000000, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
X =SIEHE GESONDERTE E-LISTE X =SEE SEPARATE PARTS LIST
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Page 25
GRUNDIG Service 39
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
295010827500 BEDIENEINHEIT BASIC++
C 62501
S 851179303300 FOKO MP3 0,22UF 20% 250VW
D 00805 830994460100 LE DIODE TLHR 4601
D 81501 830921504500 DIODE 1N4148
IC 84001 830536753000 IC TFMS5300 STEHEND
L 62501
S 295008259700 ENTSTOER-DR
R 62501 831100501700 NTC 4,7 OHM 30%
R 62505
S 831120001600 PTC DUO T251-A80-A10
SI 62501
S 831562250300 SI 5X20 T3,15A H 250V
T 81501 830320287500 TRANS 2SD1866TV2
T 81502 830320554800 TRANS BC548B/ BC547B
CONTROL UNIT BASIC++
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
296354280201
295016880106
296321140102
295016710602
293031688100
293033904200
Ersatzteilliste
Spare Parts List
11 / 2000
MATERIAL-NR. / PART NO.: 921696888100 BESTELL-NR. / ORDER NO.: GCG1600 SCHWARZ/BLACK
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
921696888100 ST 63-270/8 IDTV 2 SCHWARZ ST 63-270/8 IDTV 2 BLACK
0320.000 291103646402 TYPENAUFKLEBER VNA TYPE LABEL VNA
216969410400 BEDIENUNGSANLEITUNG PL/CZ/H OPERATING INSTRUCTION PL/CZ/H
720100269000 SERVICE MANUAL D/GB SERVICE MANUAL D/GB
720100269100 SERVICE MANUAL D/GB 1.ERGAENZUNG SERVICE MANUAL D/GB 1ST SUPPLEMENT
720100269300 SERVICE MANUAL D/GB 3.ERGAENZUNG SERVICE MANUAL D/GB 3RD SUPPLEMENT
297040153300 X CHASSIS-FS-STEREO CHASSIS TV STEREO
d©
KEIN E-TEIL NO SPARE PART
CUC 1836 BASIC++/INL 4:3 CUC 1836 BASIC++/INL 4:3
KEIN E-TEIL NO SPARE PART
X=SIEHE GESONDERTE E-LISTE X=SEE SEPARATE PARTS LIST
ALLE WEITEREN TEILE SIEHE E-LISTE FOR ALL OTHER PARTS SEE
ST 63-270/8 IDTV 2 SCHWARZ ST 63-270/8 IDTV 2 BLACK
MAT.-NR.: 921696888100 PART NO: 921696888100
BESTELL-NR.: GCG1600 ORDER NR: GCG1600
AUSGABE 10/2000 EDITION 10/2000
VERSION NR.: VNM VERSION NO.: VNM
Ķ
TV
ST 63-270/8 IDTV 2
VERSION NR./VERSION NO.: VNA
CUC 1830 / 1836 / 1929 Ersatzteillisten / Spare Parts Lists
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 720108000000, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 720108000000, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Page 26
40 GRUNDIG Service
Ersatzteilliste
Spare Parts List
6 / 2000
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
0200.000 29635 350 0101 GEH-VORDERTEIL DRUCK KPL CABINET FRONT PART PRINT CPL
0201.000 19126 034 9700 2 LAUTSPRECHER LOUDSPEAKER
0211.000 29700 628 0306 ABDECKUNG CINCH BUCHSEN COVER CINCH SOCKETS
0225.000 29636 563 0102 KLAPPE DRUCK KPL PROGRAMM/LAUTST. FLAP PRINT CPL PROGRAMME/VOLUME
0227.000 27041 217 0100 DRUCKSCHNAEPPER BEDIENTEILKLAPPE PRESSURE SNAPPER CONTROL UNIT FLAP
0230.000 29636 532 0102 IR-FENSTER IR WINDOW
0300.000 29631 981 0101 GEH-RUECKTEIL OFB CABINET REAR PART SURFACE TREATED
0320.000 29110 118 6302 TYPENAUFKLEBER TYPE LABEL SELF ADHESIVE
0700.000
0750.000 81261 252 8700 4 EINSATZBUCHSE BILDROHR INSERT SOCKET PICTURE TUBE
1100.000 S 83000 304 7500 BILDROHR A66 EAK 652X44 PHILIPS PICTURE TUBE A66 EAK 652X44 PHILIPS
1200.000 S 29201 360 1106 ANODENKAPPE M.HOCHSPANNUNGSKABEL ANODE CAP W.HIGH VOLTAGE CABLE
1300.000 29501 085 0700 BEDIENEINHEIT BASIC++ CONTROL UNIT BASIC++
1311.000 29703 357 1100 TASTSCHALTER PROGRAMM + KEY SWITCH PROGRAMME +
1312.000 29703 357 1100 TASTSCHALTER PROGRAMME - KEY SWITCH PROGRAMME -
1313.000 29703 357 1100 TASTSCHALTER LAUTSTAERKE + KEY SWITCH VOLUME +
1314.000 29703 357 1100 TASTSCHALTER LAUTSTAERKE - KEY SWITCH VOULME -
1350.000 29636 534 0102 TASTENKNOPF NETZSCHALTER KEY MAINES SWITCH
1360.000
1370.000 29636 533 0102 TASTENSATZ PROGRAMM/LAUTSTAERKE KEYS SET PROGRAMME/VOLUME
1383.000 29303 390 4200 KOPFHOERERBUCHSE 3,5 O.SCHALTER HEADPHONE SOCKET 3,5 W/O SWITCH
1384.000 29303 168 8100 CINCH-BUCHSE 3-FACH FBAS/NF L,R CINCH SOCKET 3 FOLD FBAS/AF L,R
1390.000
1398.000 29501 760 0101 ABDECKUNG BEDIENEINHEIT COVER CONTROL UNIT
2100.000 S 82909 913 1600 NETZKABEL KPL MIT ENTSTOERDRSSEL POWER CABLE CPL W.INTERFERENCE COIL
2300.000
2400.000 29642 061 1001 TP 810 C FERNBEDIENUNG TP 810 C REMOTE CONTROL
2410.000 75954 059 0100 DECKEL BATTERIE LID BATTERY
Ķ
M 70-282
MATERIAL-NR. / PART NO.: 92184 901 7500 BESTELL-NR. / ORDER NO.: G.CI 89-75 SCHWARZ/BLACK
d©
92184 901 7500 M 70-282 M 70-282
S 09246 131 7505 ENTMAGNETISIERUNGSSPULE DEGAUSSING COIL
S 29703 291 7105 NETZSCHALTER ECO O.WISCHER POWER SWITCH ECO W/O WIPER
S 09621 113 0206 2 SICHERUNGSHALTER SI62501 FUSE HOLDER SI62501
S 29305 122 1700 X BILDROHRPLATTE PICTURE TUBE BOARD
21849 941 0100 BEDIENUNGSANLEITUNG OPERATING INSTRUCTIONS
72010 026 9000 SERVICE MANUAL SERVICE MANUAL
72010 026 9100 SERVICE MANUAL 1. ERGAENZUNG SERVICE MANUAL 1ST SUPPLEMENT
72010 026 9300 SERVICE MANUAL 3.ERGAENZUNG SERVICE MANUAL 3RD SUPPLEMENT
29656 004 0200 MONTAGEZUBEHOER F.BILDROHR MOUNTING ACCESSORIES F.PICTURE TUBE
29701 096 6200 X CHASSIS-FS-STEREO CHASSIS TV STEREO
KEIN E-TEIL NO SPARE PART
KEIN E-TEIL NO SPARE PART
CUC 1836 CUC 1836
KEIN E-TEIL KEIN E-TEIL
VERSION NR./VERSION NO.: VNM
TV
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 62501 S 85117 930 3300 FOKO MP3 0,22UF 20% 250VW
C 84002 86682 030 2300 ABBLOCK-C 0,1 UF -GR 25V
D 00805 83099 446 0100 LE DIODE TLHR 4601
D 81501 83092 150 4500 DIODE 1N4148
IC 84001 83053 675 3000 IC TFMS5300 STEHEND/ TSOP
L 62501
S 29500 835 9700 ENTSTOER-DR 2X22MH
R 62501 83110 050 1700 NTC 4,7 OHM 30%
R 62505
S 83112 000 1600 PTC DUO T251-A80-A10
SI 62501 S 83156 225 0300 SI 5X20 T3,15A H 250V
T 81501 83032 028 7500 TRANS 2SD1866TV2
T 81502 83032 055 4800 TRANS BC548B
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
29635 350 0101
29636 534 0102
29636 532 0102
29636 563 0102
Ersatzteillisten / Spare Parts Lists CUC 1830 / 1836 / 1929
X = SIEHE GESONDERTE E-LISTE X = SEE SEPARATE PARTS LIST
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 72010 800 0000, sowie zusätzlich die eventuell
abweichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 72010 800 0000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Page 27
GRUNDIG Service 41
Ķ
Ķ
CUC 1830 / 1836 / 1929 Ersatzteillisten / Spare Parts Lists
Ersatzteilliste
Spare Parts List
11 / 2000
MATERIAL-NR. / PART NO.: 921849017500 BESTELL-NR. / ORDER NO.: GCI8975 SCHWARZ/BLACK
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
921849017500 M 70-282 SCHWARZ M 70-282 BLACK
0208.000 297006280307 ABDECKUNG BASIC ++ COVER BASIC ++
0300.000 296319810102 GEH-RUECKTEIL OFB CABINET REAR PART SURFACE TREATED
0320.000 291101186502 TYPENAUFKLEBER VNX TYPE LABEL VNX
218499410100 BEDIENUNGSANLEITUNG D/I/F/NL OPERATING INSTRUCTIONS D/I/F/NL
720100269000 SERVICE MANUAL D/GB SERVICE MANUAL D/GB
720100269100 SERVICE MANUAL D/GB 1.ERGAENZUNG SERVICE MANUAL D/GB 1ST SUPPLEMENT
720100269300 SERVICE MANUAL D/GB 3.ERGAENZUNG SERVICE MANUAL D/GB 3RD SUPPLEMENT
297040152000 X CHASSIS-FS-STEREO CHASSIS TV STEREO
d©
KEIN E-TEIL NO SPARE PART
CUC 1836 BASIC++/INL 4:3 CUC 1836 BASIC++/INL 4:3
KEIN E-TEIL NO SPARE PART
X=SIEHE GESONDERTE E-LISTE X=SEE SEPARATE PARTS LIST
ALLE WEITEREN TEILE SIEHE E-LISTE FOR ALL OTHER PARTS SEE
M 70-282 SCHWARZ M 70-282 BLACK
MAT.-NR.: 921849017500 PART NO: 921849017500
BESTELL-NR.: GCI8975 ORDER NR: GCI8975
AUSGABE 06/2000 EDITION 06/2000
VERSION NR.: VNM VERSION NO.: VNM
M 70-282
VERSION NR./VERSION NO.: VNX
TV
Ersatzteilliste
Spare Parts List
3 / 2000
MATERIAL-NR. / PART NO.: 92184 901 9200 BESTELL-NR. / ORDER NO.: G.CI 89-92 TITANE
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
92184 901 9200 M 70-282 TITANE M 70-282 TITANE
0200.000 29635 350 0201 GEH-VORDERTEIL DRUCK KPL CABINET FRONT PART PRINT
0201.000 19126 034 9700 2 LAUTSPRECHER LOUDSPEAKER
0225.000 29636 563 0102 KLAPPE DRUCK KPL FLAP PRINT CPL
0227.000 27041 217 0100 DRUCKSCHNAEPPER PRESSURE SNAPPER
0230.000 29636 532 0102 IR-FENSTER IR WINDOW
0300.000 29631 981 0301 GEH-RUECKTEIL OFB CABINET REAR PART SURFACE
0312.000 29700 628 0306 ABDECKUNG EURO-AV COVER EURO AV
0320.000 29110 118 6302 TYPENAUFKLEBER VNM TYPE LABEL VNM
0700.000
S 09246 131 7505 ENTMAGNETISIERUNGSSPULE M.HALTER DEGAUSSING COIL W.HOLDER
0740.000 81261 252 8700 4 EINSATZBUCHSE BILDROHR INSERT SOCKET PICTURE TUBE
1100.000
S 83000 304 7500 BILDR.A 66 EAK 652X44 PHILIPS PICT.TUBE A 66 EAK 652X44 PHILIPS
1200.000 S 29201 360 1106 ANODENKAPPE M.HOCHSPANNUNGSKABEL ANODE CAP W.HIGH VOLTAGE CABLE
1300.000 29501 085 0700 BEDIENEINHEIT BASIC++ CONTROL UNIT BASIC++
1310.000 29703 357 1100 TASTSCHALTER PROGRAMM + KEY SWITCH PROGRAMME +
1320.000 29703 357 1100 TASTSCHALTER PROGRAMM - KEY SWITCH PROGRAMME -
1330.000 29703 357 1100 TASTSCHALTER LAUTSTAERKE + KEY SWITCH VOLUME +
1340.000 29703 357 1100 TASTSCHALTER LAUTSTAERKE - KEY SWITCH VOLUME -
1350.000 29636 533 0101 TASTEN-SATZ PROGRAMM/LAUTSTAERKE KEY SET PROGRAMME/VOLUME
1360.000
S 29703 291 7105 NETZSCHALTER ECO O.WISCHER POWER SWITCH ECO W/O WIPER
1370.000 29636 534 0101 NETZTASTENKNOPF KEY POWER
1383.000 29303 390 4200 KOPFHOERERBUCHSE 3,5 O.SCHALTER HEADPHONE SOCKET 3,5 W/O SWITCH
1384.000 29303 168 8100 CINCH-BUCHSE 3-FACH FBAS/NF L,R CINCH SOCKET 3 FOLD FBAS/AF L,R
1390.000
S 09621 113 0206 2 SICHERUNGSHALTER FUSE HOLDER
2100.000 S 82909 913 1600 NETZKABEL KPL MIT ENTSTOERDROSSEL POWER CABLE WITH INTERFERENCE COIL
2300.000
S 29305 122 1700 X BILDROHRPLATTE PICTURE TUBE BOARD
2400.000 29642 061 1001 TP 810 C FERNBEDIENUNG TP 810 C REMOTE CONTROL
21849 941 0100 BEDIENUNGSANLEITUNG D/F/I/NL OPERATING INSTRUCTIONS D/F/I/NL
72010 026 9000 SERVICE MANUAL D/GB SERVICE MANUAL D/GB
72010 026 9100 SERVICE MANUAL D/GB 1.ERGAENZUNG SERVICE MANUAL D/GB 1ST SUPPLEMENT
720100269300 SERVICE MANUAL D/GB 3.ERGAENZUNG SERVICE MANUAL D/GB 3RD SUPPLEMENT
29656 004 0200 MONTAGEZUBEHOER F.BILDROHR MOUNTING ACCESSORIES F.PT
29701 096 6200 X CHASSIS-FS-STEREO CHASSIS TV STEREO
d©
KEIN E-TEIL NO SPARE PART
KEIN E-TEIL NO SPARE PART
CUC 1836 DIGI BASIC ++/INL 4:3 CUC 1836 DIGI BASIC ++/INL 4:3
KEIN E-TEIL NO SPARE PART
M 70-282
VERSION NR./VERSION NO.: VNM
TV
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 720108000000, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
X = SIEHE GESONDERTE E-LISTE X = SEE SEPARATE PARTS LIST
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Page 28
42 GRUNDIG Service
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 62501 S 85117 930 3300 FOKO MP3 0,22UF 20% 250VW
C 84002 86682 030 2300 ABBLOCK-C 0,1 UF
D 00805 83099 446 0100 LE DIODE TLHR 4601
D 81501 83092 150 4500 DIODE 1N4148
IC 84001 83053 675 3000 IC TFMS5300 STEHEND
L 62501
R 62501 83110 050 1700 NTC 4,7 OHM 30%
R 62505
SI 62501 S 83156 225 0300 SI 5X20 T3,15A H 250V
T 81501 83032 028 7500 TRANS 2SD1866TV2
T 81502 83032 055 4800 TRANS BC548B/ BC547B
29501 085 0700 BEDIENEINHEIT BASIC++
CONTROL UNIT BASIC++
S 29500 835 9700 ENTSTOER-DR 2X22MH
S 83112 000 1600 PTC DUO
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
29635 350 0201
29636 534 0101
29636 532 0102
29636 563 0102
Ķ
Ersatzteilliste
Spare Parts List
11 / 2000
MATERIAL-NR. / PART NO.: 921849019200 BESTELL-NR. / ORDER NO.: GCI8992 TITAN/TITANE
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
921849019200 M 70-282 TITAN M 70-282 TITANE
0208.000 297006280307 ABDECKUNG BASIC ++ COVER BASIC ++
0320.000 291101186502 TYPENAUFKLEBER VNX TYPE LABEL VNX
1350.000 296365330102 TASTEN-SATZ PROGRAMM/LAUTSTAERKE KEYS SET PROGRAMME/VOLUME
1370.000 296365340102 TASTENKNOPF NETZ KEY KNOB POWER
2410.000 759540590100 DECKEL BATTERIE TP 810 C BATTERY LID TP 810 C
218499410100 BEDIENUNGSANLEITUNG D/I/F/NL OPERATING INSTRUCTIONS D/I/F/NL
720100269000 SERVICE MANUAL D/GB SERVICE MANUAL D/GB
720100269100 SERVICE MANUAL D/GB 1.ERGAENZUNG SERVICE MANUAL D/GB 1ST SUPPLEMENT
720100269300 SERVICE MANUAL D/GB 3.ERGAENZUNG SERVICE MANUAL D/GB 3RD SUPPLEMENT
297040152000 X CHASSIS-FS-STEREO CHASSIS TV STEREO
d©
KEIN E-TEIL NO SPARE PART
CUC 1836 BASIC++/INL 4:3 CUC 1836 BASIC++/INL 4:3
KEIN E-TEIL NO SPARE PART
X=SIEHE GESONDERTE E-LISTE X=SEE SEPARATE PARTS LIST
ALLE WEITEREN TEILE SIEHE E-LISTE FOR ALL OTHER PARTS SEE
M 70-282 TITAN M 70-282 TITANE
MAT.-NR.: 921849019200 PART NO: 921849019200
BESTELL-NR.: GCI8992 ORDER NR: GCI8992
AUSGABE 03/2000 EDITION 03/2000
VERSION NR.: VNM VERSION NO.: VNM
M 70-282
VERSION NR./VERSION NO.: VNX
Ersatzteillisten / Spare Parts Lists CUC 1830 / 1836 / 1929
TV
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 72010 800 0000, sowie zusätzlich die eventuell
abweichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 72010 800 0000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 720108000000, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
296353500201
296365340101 (VNM)
296365340102 (VNA/VNX)
296365320102
2966365630102
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Page 29
GRUNDIG Service 43
Ķ
Ersatzteilliste
Spare Parts List
6 / 2000
MATERIAL-NR. / PART NO.: 92187 202 7500 BESTELL-NR. / ORDER NO.: G.CI 86-75 SCHWARZ/BLACK
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
92187 202 7500 ST 70-282/8 ST 70-282/8
0200.000 29635 350 0101 GEH-VORDERTEIL DRUCK KPL CABINET FRONT PART PRINT CPL
0201.000 19126 034 9700 2 LAUTSPRECHER LOUDSPEAKER
0211.000 29700 628 0307 ABDECKUNG BASIC ++ COVER BASIC ++
0225.000 29636 563 0102 KLAPPE DRUCK KPL PROGRAMM/LAUTST. FLAP PRINT CPL PROGRAMME/VOLUME
0227.000 27041 217 0100 DRUCKSCHNAEPPER BEDIENTEILKLAPPE PRESSURE SNAPPER CONTROL UNIT FLAP
0230.000 29636 532 0102 IR-FENSTER IR WINDOW
0300.000 29631 981 0101 GEH-RUECKTEIL OFB CABINET REAR PART SURFACE TREATED
0320.000 29110 119 6302 TYPENAUFKLEBER TYPE LABEL SELF ADHESIVE
WW. 29110 201 6301 TYPENAUFKLEBER TYPE LABEL SELF ADHESIVE
0750.000 81261 252 8700 4 EINSATZBUCHSE BILDROHR INSERT SOCKET PICTURE TUBE
1100.000
S 83000 304 3600 BILDROHR A66 EAK 71X44 PHILIPS PICTURE TUBE A66 EAK 71X44 PHILIPS
1100.000 S 83000 304 8500 BILDROHR A66 ECF 50X56 PANASONIC PICT.TUBE A66 ECF 50X56 PANASONIC
1200.000 S 29201 360 1106 ANODENKAPPE M.HOCHSPANNUNGSKABEL ANODE CAP W.HIGH VOLTAGE CABLE
1200.000
S 09246 131 7505 ENTMAGNETISIERUNGSSPULE DEGAUSSING COIL
1300.000 29501 085 0700 BEDIENEINHEIT BASIC++ CONTROL UNIT BASIC++
1311.000 29703 357 1100 TASTSCHALTER PROGRAMM + KEY SWITCH PROGRAMME +
1312.000 29703 357 1100 TASTSCHALTER PROGRAMM - KEY SWITCH PROGRAMME -
1313.000 29703 357 1100 TASTSCHALTER LAUTSTAERKE + KEY SWITCH VOLUME +
1314.000 29703 357 1100 TASTSCHALTER LAUTSTAERKE - KEY SWITCH VOLUME -
1350.000 29636 534 0102 TASTENKNOPF NETZSCHALTER KEY MAINS SWITCH
1360.000
S 29703 291 7105 NETZSCHALTER ECO O.WISCHER POWER SWITCH ECO W/O WIPER
1370.000 29636 533 0102 TASTENSATZ PROGRAMM/LAUTSTAERKE KEYS SET PROGRAMME/VOLUME
1383.000 29303 390 4200 KOPFHOERERBUCHSE 3,5 O.SCHALTER HEADPHONE SOCKET 3,5 W/O SWITCH
1384.000 29303 168 8100 CINCH-BUCHSE 3-FACH FBAS/NF L,R CINCH SOCKET 3 FOLD FBAS/AF L,R
1390.000
S 09621 113 0206 2 SICHERUNGSHALTER SI62501 FUSE HOLDER SI62501
1398.000 29501 760 0101 ABDECKUNG BEDIENEINHEIT COVER CONTROL UNIT
2100.000 S 82909 913 1600 NETZKABEL KPL MIT ENTSTOERDROSSEL POWER CABLE CPL W. INTERFERENCE COIL
2300.000
S 29305 122 1700 X BILDROHRPLATTE PICTURE TUBE BOARD
2400.000 29642 061 1001 TP 810 C FERNBEDIENUNG TP 810 C REMOTE CONTROL
2410.000 75954 059 0100 DECKEL BATTERIE BATTERY LID
21872 941 0100 BEDIENUNGSANLEITUNG OPERATING INSTRUCTIONS
21872 941 0200 BEDIENUNGSANLEITUNG 31KV OPERATING INSTRUCTIONS 31KV
72010 026 9000 SERVICE MANUAL SERVICE MANUAL
72010 026 9100 SERVICE MANUAL 1.ERGAENZUNG SERVICE MANUAL 1ST SUPPLEMENT
72010 026 9300 SERVICE MANUAL D/GB 3.ERGAENZUNG SERVICE MANUAL D/GB 3RD SUPPLEMENT
29656 004 0200 MONTAGEZUBEHOER F.BILDROHR MOUNTING ACCESSORIES F.PICTURE TUBE
29701 096 6800 X CHASSIS-FS-STEREO CHASSIS-TV-STEREO
29701 096 8300 X CHASSIS-FS-STEREO CHASSIS TV STEREO
d©
KEIN E-TEIL NO SPARE PART
KEIN E-TEIL NO SPARE PART
CUC 1836 PHLIPS-BR CUC 1836 PHILIPS-PT
KEIN E-TEIL NO SPARE PART
CUC 1836 PANASONIC-BR CUC 1836 PANASONIC-BR
KEIN E-TEIL NO SPARE PART
ST 70-282/8
VERSION NR./VERSION NO.: VNM
TV
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 62501 S 85117 930 3300 FOKO MP3 0,22UF 20% 250VW
C 84002 86682 030 2300 ABBLOCK-C 0,1 UF -GR 25V
D 00805 83099 446 0100 LE DIODE TLHR 4601
D 81501 83092 150 4500 DIODE 1N4148
IC 84001 83053 675 3000 IC TFMS5300 STEHEND/ TSOP
L 62501
S 29500 835 9700 ENTSTOER-DR 2X22MH
R 62501 83110 050 1700 NTC 4,7 OHM 30%
R 62505
S 83112 000 1600 PTC DUO T251-A80-A10
SI 62501
S 83156 225 0300 SI 5X20 T3,15A H 250V
T 81501 83032 028 7500 TRANS 2SD1866TV2
T 81502 83032 055 4800 TRANS BC548B
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
29635 350 0101
29636 534 0102
29636 532 0102
29636 563 0102
CUC 1830 / 1836 / 1929 Ersatzteillisten / Spare Parts Lists
X = SIEHE GESONDERTE E-LISTE X = SEE SEPARATE PARTS LIST
WW. = WAHLWEISE WW. = OPTIONAL
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 72010 800 0000, sowie zusätzlich die eventuell
abweichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 72010 800 0000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Page 30
44 GRUNDIG Service
Ķ
Ersatzteillisten / Spare Parts Lists CUC 1830 / 1836 / 1929
Ķ
Ersatzteilliste
Spare Parts List
11 / 2000
MATERIAL-NR. / PART NO.: 921872027500 BESTELL-NR. / ORDER NO.: GCI8675 SCHWARZ/BLACK
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
921872027500 ST 70-282/8 SCHWARZ ST 70-282/8 BLACK
0300.000 296319810102 GEH-RUECKTEIL OFB CABINET REAR PART SURFACE TREATED
0320.000 291101196503 TYPENAUFKLEBER VNX PHILIPS-BR TYPE LABEL VNX PHILIPS PT
0320.000 291102016502 TYPENAUFKLEBER VNX PANASONIC-BR TYPE LABEL VNX PANASONIC PT
218729410100 BEDIENUNGSANLEITUNG PHILIPS-BR OPERATING INSTRUCTION PHILIPS PT
218729410200 BEDIENUNGSANLEITUNG OPERATING INSTRUCTION
720100269000 SERVICE MANUAL D/GB SERVICE MANUAL D/GB
720100269100 SERVICE MANUAL D/GB 1.ERGAENZUNG SERVICE MANUAL D/GB 1ST SUPPLEMENT
720100269300 SERVICE MANUAL D/GB 3.ERGAENZUNG SERVICE MANUAL D/GB 3RD SUPPLEMENT
297040152100 X CHASSIS-FS-STEREO PHILIPS-BR CHASSIS TV STEREO PHILIPS PT
297040152200 X CHASSIS-FS-STEREO PANASONIC-BR CHASSIS TV STEREO PANASONIC PT
d©
KEIN E-TEIL NO SPARE PART
D/F/I/NL/DK/N/S/FIN/E/P/PL/CZ/H D/F/I/NL/DK/N/S/FIN/E/P/PL/CZ/H
31KV PANASONIC-BR 31KV PANASONIC PT
D/F/I/NL/DK/N/S/FIN/E/P/PL/CZ/H D/F/I/NL/DK/N/S/FIN/E/P/PL/CZ/H
CUC 1836 BASIC++/INL 4:3 CUC 1836 BASIC++/INL 4:3
KEIN E-TEIL NO SPARE PART
CUC 1836 BASIC++/INL 4:3 CUC 1836 BASIC++/INL 4:3
KEIN E-TEIL NO SPARE PART
X=SIEHE GESONDERTE E-LISTE X=SEE SEPARATE PARTS LIST
ALLE WEITEREN TEILE SIEHE E-LISTE FOR ALL OTHER PARTS SEE
ST 70-282/8 SCHWARZ ST 70-282/8 BLACK
MAT.-NR.: 921872027500 PART NO: 921872027500
BESTELL-NR.: GCI8675 ORDER NR: GCI8675
AUSGABE 06/2000 EDITION 06/2000
VERSION NR.: VNM VERSION NO.: VNM
ST 70-282/8
VERSION NR./VERSION NO.: VNX
TV
Ersatzteilliste
Spare Parts List
3 / 2000
MATERIAL-NR. / PART NO.: 92187 202 9200 BESTELL-NR. / ORDER NO.: G.CI 86-92 TITANE
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
92187 202 9200 ST 70-282/8 TITANE ST 70-282/8 TITANE
0200.000 29635 350 0201 GEH-VORDERTEIL DRUCK KPL CABINET FRONT PART PRINT
0201.000 19126 034 9700 2 LAUTSPRECHER LOUDSPEAKER
0225.000 29636 563 0102 KLAPPE DRUCK KPL FLAP PRINT CPL
0227.000 27041 217 0100 DRUCKSCHNAEPPER PRESSURE SNAPPER
0230.000 29636 532 0102 IR-FENSTER IR WINDOW
0300.000 29631 981 0301 GEH-RUECKTEIL OFB CABINET REAR PART SURFACE
0312.000 29700 628 0306 ABDECKUNG EURO-AV COVER EURO AV
0320.000 29110 119 6302 TYPENAUFKL.VNM F.PHILIPS-BR TYPE LABEL VNM F.PHILIPS PT
0320.000 29110 201 6301 TYPENAUFKL.VNM F.PANASONIC-BR TYPE LABEL VNM F.PANASONIC PT
0700.000
S 09246 131 7505 ENTMAGNETISIERUNGSSPULE M.HALTER DEGAUSSING COIL W.HOLDER
0740.000 81261 252 8700 4 EINSATZBUCHSE BILDROHR INSERT SOCKET PICTURE TUBE
1100.000 S 83000 304 3600 BILDR.A 66 EAK 71X44 PHILIPS PICT.TUBE A 66 EAK 71X44 PHILIPS
1101.000
S 83000 304 8500 BILDR.A 66 ECF 50X56 PANASONIC PICT.TUBE A 66 ECF 50X56 PANASONIC
1200.000 S 29201 360 1106 ANODENKAPPE M.HOCHSPANNUNGSKABEL ANODE CAP W.HIGH VOLTAGE CABLE
1300.000 29501 085 0700 BEDIENEINHEIT BASIC++ CONTROL UNIT BASIC++
1310.000 29703 357 1100 TASTSCHALTER PROGRAMM + KEY SWITCH PROGRAMME +
1320.000 29703 357 1100 TASTSCHALTER PROGRAMM - KEY SWITCH PROGRAMME -
1330.000 29703 357 1100 TASTSCHALTER LAUTSTAERKE + KEY SWITCH VOLUME +
1340.000 29703 357 1100 TASTSCHALTER LAUTSTAERKE - KEY SWITCH VOLUME -
1350.000 29636 533 0101 TASTEN-SATZ PROGRAMM/LAUTSTAERKE KEY SET PROGRAMME/VOLUME
1360.000
S 29703 291 7105 NETZSCHALTER ECO O.WISCHER POWER SWITCH ECO W/O WIPER
1370.000 29636 534 0101 NETZTASTENKNOPF KEY POWER
1383.000 29303 390 4200 KOPFHOERERBUCHSE 3,5 O.SCHALTER HEADPHONE SOCKET 3,5 W/O SWITCH
1384.000 29303 168 8100 CINCH-BUCHSE 3-FACH FBAS/NF L,R CINCH SOCKET 3 FOLD FBAS/AF L,R
1390.000
S 09621 113 0206 2 SICHERUNGSHALTER FUSE HOLDER
2100.000
S 82909 913 1600 NETZKABEL KPL MIT ENTSTOERDROSSEL POWER CABLE WITH INTERFERENCE COIL
2300.000 S 29305 122 1700 X BILDROHRPLATTE PICTURE TUBE BOARD
2400.000 29642 061 1001 TP 810 C FERNBEDIENUNG TP 810 C REMOTE CONTROL
21872 941 0100 BEDIENUNGSANLEITUNG D/F/I/NL/ OPERATING INSTRUCTION D/F/I/NL/
21872 941 0200 BEDIENUNGSANLEITUNG D/F/I/NL/ OPERATING INSTRUCTION D/F/I/NL/
72010 026 9000 SERVICE MANUAL D/GB SERVICE MANUAL D/GB
72010 026 9100 SERVICE MANUAL D/GB 1.ERGAENZUNG SERVICE MANUAL D/GB 1ST SUPPLEMENT
72010 026 9300 SERVICE MANUAL D/GB 3.ERGAENZUNG SERVICE MANUAL D/GB 3RD SUPPLEMENT
29656 004 0200 MONTAGEZUBEHOER F.BILDROHR MOUNTING ACCESSORIES F.PT
29701 096 6800 X CHASSIS-FS-STEREO PHILIPS-BR CHASSIS-TV-STEREO PHILIPS PT
29701 096 8300 X CHASSIS-FS-STEREO PANASONIC-BR CHASSIS TV STEREO PANASONIC PT
d©
KEIN E-TEIL NO SPARE PART
DK/N/S/FIN/E/P/PL/CZ/H DK/N/S/FIN/E/P/PL/CZ/H
DK/N/S/FIN/E/P/PL/CZ/H DK/N/S/FIN/E/P/PL/CZ/H
KEIN E-TEIL NO SPARE PART
CUC 1836 DIGI BASIC ++/INL 4:3 CUC 1836 DIGI BASIC ++/INL 4:3
KEIN E-TEIL NO SPARE PART
CUC 1836 DIGI BASIC ++/INL 4:3 CUC 1836 DIGI BASIC ++/INL 4:3
KEIN E-TEIL NO SPARE PART
ST 70-282/8
VERSION NR./VERSION NO.: VNM
TV
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 720108000000, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
X = SIEHE GESONDERTE E-LISTE X = SEE SEPARATE PARTS LIST
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Page 31
GRUNDIG Service 45
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
29501 085 0700 BEDIENEINHEIT BASIC++
C 62501
S 85117 930 3300 FOKO MP3 0,22UF 20% 250VW
C 84002 86682 030 2300 ABBLOCK-C 0,1 UF
D 00805 83099 446 0100 LE DIODE TLHR 4601
D 81501 83092 150 4500 DIODE 1N4148
IC 84001 83053 675 3000 IC TFMS5300 STEHEND
L 62501
S 29500 835 9700 ENTSTOER-DR 2X22MH
R 62501 83110 050 1700 NTC 4,7 OHM 30%
R 62505
S 83112 000 1600 PTC DUO T2S1-A80-A10
SI 62501
S 83156 225 0300 SI 5X20 T3,15A H 250V
T 81501 83032 028 7500 TRANS 2SD1866TV2
T 81502 83032 055 4800 TRANS BC548B/ BC547B
CONTROL UNIT BASIC++
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
29635 350 0201
29636 534 0101
29636 532 0102
29636 563 0102
Ersatzteilliste
Spare Parts List
12 / 2000
MATERIAL-NR. / PART NO.: 921872029200 BESTELL-NR. / ORDER NO.: GCI8692 TITAN/TITANE
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
921872029200 ST 70-282/8 TITAN ST 70-282/8 TITANE
0208.000 297006280307 ABDECKUNG BASIC ++ COVER BASIC ++
0320.000 291101196503 TYPENAUFKLEBER VNX PHILIPS-BR TYPE LABEL VNX PHILIPS PT
0320.000 291102016502 TYPENAUFKLEBER VNX PANASONIC-BR TYPE LABEL VNX PANASONIC PT
1350.000 296365330102 TASTEN-SATZ PROGRAMM/LAUTSTAERKE KEYS SET PROGRAMME/VOLUME
1370.000 296365340102 TASTENKNOPF NETZ KEY KNOB POWER
2410.000 759540590100 DECKEL BATTERIE TP 810 C BATTERY LID TP 810 C
218729410100 BEDIENUNGSANLEITUNG PHILIPS-BR OPERATING INSTRUCTION PHILIPS PT
218729410200 BEDIENUNGSANLEITUNG OPERATING INSTRUCTION
720100269000 SERVICE MANUAL D/GB SERVICE MANUAL D/GB
720100269100 SERVICE MANUAL D/GB 1.ERGAENZUNG SERVICE MANUAL D/GB 1ST SUPPLEMENT
720100269300 SERVICE MANUAL D/GB 3.ERGAENZUNG SERVICE MANUAL D/GB 3RD SUPPLEMENT
297040152100 X CHASSIS-FS-STEREO PHILIPS-BR CHASSIS TV STEREO PHILIPS PT
297040152200 X CHASSIS-FS-STEREO PANASONIC-BR CHASSIS TV STEREO PANASONIC PT
d©
KEIN E-TEIL NO SPARE PART
D/F/I/NL/DK/N/S/FIN/E/P/PL/CZ/H D/F/I/NL/DK/N/S/FIN/E/P/PL/CZ/H
31KV PANASONIC-BR 31KV PANASONIC PT
D/F/I/NL/DK/N/S/FIN/E/P/PL/CZ/H D/F/I/NL/DK/N/S/FIN/E/P/PL/CZ/H
CUC 1836 BASIC++/INL 4:3 CUC 1836 BASIC++/INL 4:3
KEIN E-TEIL NO SPARE PART
CUC 1836 BASIC++/INL 4:3 CUC 1836 BASIC++/INL 4:3
KEIN E-TEIL NO SPARE PART
Ķ
TV
ST 70-282/8
VERSION NR./VERSION NO.: VNX
CUC 1830 / 1836 / 1929 Ersatzteillisten / Spare Parts Lists
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 72010 800 0000, sowie zusätzlich die eventuell
abweichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 72010 800 0000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
X=SIEHE GESONDERTE E-LISTE X=SEE SEPARATE PARTS LIST
ALLE WEITEREN TEILE SIEHE E-LISTE FOR ALL OTHER PARTS SEE
ST 70-282/8 TITAN ST 70-282/8 TITANE
MAT.-NR.: 921872029200 PART NO: 921872029200
BESTELL-NR.: GCI8692 ORDER NR: GCI8692
AUSGABE 03/2000 EDITION 03/2000
VERSION NR.: VNM VERSION NO.: VNM
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Page 32
46 GRUNDIG Service
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
Ersatzteilliste
Spare Parts List
Ersatzteillisten / Spare Parts Lists CUC 1830 / 1836 / 1929
Ķ
TV
ST 70-282/8
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 720108000000, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
296353500201
296365340101 (VNM)
296365340102 (VNA/VNX)
296365320102
296365630102
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
10 / 2000
MATERIAL-NR. / PART NO.: 922201027500 BESTELL-NR. / ORDER NO.: GCM4500 SCHWARZ/BLACK
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
922201027500 MW 82-45/8 SCHWARZ MW 82-45/8 BLACK
0200.000 296352110101 GEH-VORDERTEIL DRUCK KPL CABINET FRONT PART PRINT CPL
0201.000 191160117200 2 LAUTSPRECHER LOUDSPEAKER
0202.000 191150079700 2 HOCHTON-LAUTSPRECHER TWEETER
0208.000 297006280307 ABDECKUNG BASIC ++ COVER BASIC ++
0225.000 296363430101 KLAPPE DRUCK KPL FLAP PRINT CPL
0226.000 296341120100 2 KLAPPENLAGER KPL. FLAP BEARING CPL.
0229.000 296026015100 EMBLEM GRUNDIG EMBLEM GRUNDIG
0230.000 296366910101 IR-FENSTER DRUCK KPL IR WINDOW PRINT CPL
0300.000 296361780100 GEH-RUECKTEIL OFB CABINET REAR PART SURFACE TREATED
0320.000 291103620502 TYPENAUFKLEBER VNM TYPE LABEL VNM
0700.000
S 092461527506 ENTMAGNETISIERUNGSSPULE M.HALTER DEGAUSSING COIL W.HOLDER
0900.000 S 292014770100 FOKUS U.UG2-REGLER FOCUS AND UG2-ADJUSTMENT
0910.000
S 292014760102 2 FOKUSLEITUNG M.TUELLE ROT FOCUSING CABLE WITH GROMMET RED
0910.000 S 292014760202 FOKUSLEITUNG M.TUELLE BLAU FOCUSING CABLE WITH GROMMET BLUE
0921.000 297033570100 TASTSCHALTER PROGRAMM+ KEY SWITCH PROGRAMME+
0922.000 297033570100 TASTSCHALTER PROGRAMM- KEY SWITCH PROGRAMME-
0923.000 297033570100 TASTSCHALTER LAUTSTAERKE+ KEY SWITCH VOLUME+
0924.000 297033570100 TASTSCHALTER LAUTSTAERKE- KEY SWITCH VOLUME-
0925.000 295016980100 TASTEN-SATZ PROGRAMM/LAUTSTAERKE KEYS SET PROGRAMME/VOLUME
0950.000 293050084000 BUCHSENPLATTE DIGI BASIC ++ SOCKET BOARD DIGI BASIC ++
0953.000 293033904200 KOPFHOERERBUCHSE 3,5 O.SCHALTER HEADPHONE SOCKET 3,5 W/O SWITCH
0954.000 293031680500 CINCH-BUCHSE 3-FACH FBAS/NF L,R CINCH SOCKET 3 FOLD FBAS/AF L,R
0955.000 295016990100 AUFNAHME-BUCHSENPLATTE HOLDER PCB SOCKETBOARD
1100.000
1110.000 S 292013601106 ANODENKAPPE M.HOCHSPANNUNGSKABEL ANODE CAP W.HIGH VOLTAGE CABLE
1900.000
1960.000 S 297032917100 NETZSCHALTER ECO O.WISCHER POWER SWITCH ECO W/O WIPE
1970.000 295016960100 TASTE M.LICHTLEITER KPL KEY LIGHT GUIDE CPL
1990.000
2100.000 S 829099131600 NETZKABEL KPL POWER CABLE CPL
2300.000
2400.000 296420611001 TP 810 C FERNBEDIENUNG TP 810 C REMOTE CONTROL
2410.000 759540590100 DECKEL BATTERIE TP 810 C BATTERY LID TP 810 C
295010832400 KEYBOARD KEYBOARD
S 830007623100 BILDR.W76ESF231X44 PHILIPS PICT.TUBE W76ESF231X44 PHILIPS
S 293051657700 NETZSCHALTERPLATTE POWER SWITCH BOARD
S 096211130200 2 SICHERUNGSHALTER SI62501 FUSE HOLDER SI62501
S 293051222000 X BILDROHRPLATTE DIGI-BASIC ++ PICTURE TUBE BOARD DIGI BASIC ++
222019410100 BEDIENUNGSANLEITUNG OPERATING INSTRUCTION
720100269000 SERVICE MANUAL D/GB SERVICE MANUAL D/GB
72010 026 9100 SERVICE MANUAL D/GB 1.ERGAENZUNG SERVICE MANUAL D/GB 1ST SUPPLEMENT
720100269300 SERVICE MANUAL D/GB 3.ERGAENZUNG SERVICE MANUAL D/GB 3RD SUPPLEMENT
296560041200 MONTAGEZUBEHOER F.BILDROHR MOUNTING ACCESSORIES F.PT
297010968100 X CHASSIS-FS-STEREO CHASSIS TV STEREO
d©
KEIN E-TEIL NO SPARE PART
KEIN E-TEIL NO SPARE PART
D/I/F/NL/DK/N/S/E/P/FIN D/I/F/NL/DK/N/S/E/P/FIN
KEIN E-TEIL NO SPARE PART
CUC 1929 DIGI-BASIC ++ CUC 1929 DIGI BASIC ++
KEIN E-TEIL NO SPARE PART
X =SIEHE GESONDERTE E-LISTE X =SEE SEPARATE PARTS LIST
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
MW 82-45/8
VERSION NR./VERSION NO.: VNM
Page 33
GRUNDIG Service 47
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
293050084000 BUCHSENPLATTE DIGI BASIC ++
IC 84001 830536753000 IC TFMS5300 STEHEND
293051657700 NETZSCHALTERPLATTE
C 62501
S 851179304700 FOKO MP3 0,47UF20%250VW
C 62502
S 851179304500 FOKO MP3 0,33UF 20% 250VW
D 81501 830921504500 DIODE 1N4148
D 85001 830996610000 LE-DIODE TLDR4100
L 62501
S 295008349700 FUNKENTSTOERDROSSEL 2X49MH
R 62501 831100501700 NTC 4,7 OHM 30%
R 62505
S 831120001200 PTC #3 DUO
SI 62501
S 831562250300 SI 5X20 T3,15A H 250V
T 81501 830320287500 TRANS 2SD1866TV2
T 81502 830320554800 TRANS BC548B/ BC547B
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 720108000000, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
SOCKET BOARD DIGI BASIC ++
POWER SWITCH BOARD
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
296352110101
295016960100
296026015100
295016980100
296363430101
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Ersatzteilliste
Spare Parts List
10 / 2000
MATERIAL-NR. / PART NO.: 922201029200 BESTELL-NR. / ORDER NO.: GCM4510 TITAN/TITANE
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
922201029200 MW 82-45/8 TITAN MW 82-45/8 TITANE
0200.000 296352110701 GEH-VORDERTEIL DRUCK KPL CABINET FRONT PART PRINT CPL
0201.000 191160117200 2 LAUTSPRECHER LOUDSPEAKER
0202.000 191150079700 2 HOCHTON-LAUTSPRECHER TWEETER
0208.000 297006280307 ABDECKUNG BASIC ++ COVER BASIC ++
0225.000 296363430302 KLAPPE DRUCK KPL FLAP PRINT CPL
0226.000 296341120100 2 KLAPPENLAGER KPL. FLAP BEARING CPL.
0229.000 296026015100 EMBLEM GRUNDIG EMBLEM GRUNDIG
0230.000 296366910101 IR-FENSTER DRUCK KPL IR WINDOW PRINT CPL
0300.000 296361780302 GEH-RUECKTEIL OFB CABINET REAR PART SURFACE TREATED
0320.000 291103620502 TYPENAUFKLEBER VNM TYPE LABEL VNM
0700.000
S 092461527506 ENTMAGNETISIERUNGSSPULE M.HALTER DEGAUSSING COIL W.HOLDER
0900.000 S 292014770100 FOKUS U.UG2-REGLER FOCUS AND UG2-ADJUSTMENT
0910.000 S 292014760102 2 FOKUSLEITUNG M.TUELLE ROT FOCUSING CABLE WITH GROMMET RED
0910.000
S 292014760202 FOKUSLEITUNG M.TUELLE BLAU FOCUSING CABLE WITH GROMMET BLUE
295010832400 KEYBOARD KEYBOARD
0921.000 297033570100 TASTSCHALTER PROGRAMM+ KEY SWITCH PROGRAMME+
0922.000 297033570100 TASTSCHALTER PROGRAMM- KEY SWITCH PROGRAMME-
0923.000 297033570100 TASTSCHALTER LAUTSTAERKE+ KEY SWITCH VOLUME+
0924.000 297033570100 TASTSCHALTER LAUTSTAERKE- KEY SWITCH VOLUME-
0925.000 295016980100 TASTEN-SATZ PROGRAMM/LAUTSTAERKE KEYS SET PROGRAMME/VOLUME
0950.000 293050084000 BUCHSENPLATTE DIGI BASIC ++ SOCKET BOARD DIGI BASIC ++
0953.000 293033904200 KOPFHOERERBUCHSE 3,5 O.SCHALTER HEADPHONE SOCKET 3,5 W/O SWITCH
0954.000 293031680500 CINCH-BUCHSE 3-FACH FBAS/NF L,R CINCH SOCKET 3 FOLD FBAS/AF L,R
0955.000 295016990100 AUFNAHME-BUCHSENPLATTE HOLDER PCB SOCKETBOARD
1100.000
S 830007623100 BILDR.W76ESF231X44 PHILIPS PICT.TUBE W76ESF231X44 PHILIPS
1110.000
S 292013601106 ANODENKAPPE M.HOCHSPANNUNGSKABEL ANODE CAP W.HIGH VOLTAGE CABLE
1900.000 S 293051657700 NETZSCHALTERPLATTE POWER SWITCH BOARD
1960.000
S 297032917100 NETZSCHALTER ECO O.WISCHER POWER SWITCH ECO W/O WIPE
1970.000 295016960100 TASTE M.LICHTLEITER KPL KEY LIGHT GUIDE CPL
1990.000
S 096211130200 2 SICHERUNGSHALTER SI62501 FUSE HOLDER SI62501
2100.000 S 829099131600 NETZKABEL KPL POWER CABLE CPL
2300.000
S 293051222000 X BILDROHRPLATTE DIGI-BASIC ++ PICTURE TUBE BOARD DIGI BASIC ++
2400.000 296420611001 TP 810 C FERNBEDIENUNG TP 810 C REMOTE CONTROL
2410.000 759540590100 DECKEL BATTERIE TP 810 C BATTERY LID TP 810 C
222019410100 BEDIENUNGSANLEITUNG OPERATING INSTRUCTION
720100269000 SERVICE MANUAL D/GB SERVICE MANUAL D/GB
720100269300 SERVICE MANUAL D/GB 3.ERGAENZUNG SERVICE MANUAL D/GB 3RD SUPPLEMENT
296560041200 MONTAGEZUBEHOER F.BILDROHR MOUNTING ACCESSORIES F.PT
297010968100 X CHASSIS-FS-STEREO CHASSIS TV STEREO
d©
KEIN E-TEIL NO SPARE PART
KEIN E-TEIL NO SPARE PART
D/I/F/NL/DK/N/S/E/P/FIN D/I/F/NL/DK/N/S/E/P/FIN
KEIN E-TEIL NO SPARE PART
CUC 1929 DIGI-BASIC ++ CUC 1929 DIGI BASIC ++
KEIN E-TEIL NO SPARE PART
X =SIEHE GESONDERTE E-LISTE X =SEE SEPARATE PARTS LIST
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Ķ
TV
MW 82-45/8
VERSION NR./VERSION NO.: VNM
CUC 1830 / 1836 / 1929 Ersatzteillisten / Spare Parts Lists
Page 34
48 GRUNDIG Service
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
IC 84001 830536753000 IC TFMS5300 STEHEND
C 62501
C 62502
D 81501 830921504500 DIODE 1N4148
D 85001 830996610000 LE-DIODE TLDR4100
L 62501
R 62501 831100501700 NTC 4,7 OHM 30%
R 62505
SI 62501 S 831562250300 SI 5X20 T3,15A H 250V
T 81501 830320287500 TRANS 2SD1866TV2
T 81502 830320554800 TRANS BC548B/ BC547B
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 720108000000, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
293050084000 BUCHSENPLATTE DIGI BASIC ++
293051657700 NETZSCHALTERPLATTE
S 851179304700 FOKO MP3 0,47UF20%250VW
S 851179304500 FOKO MP3 0,33UF 20% 250VW
SOCKET BOARD DIGI BASIC ++
POWER SWITCH BOARD
S 295008349700 FUNKENTSTOERDROSSEL 2X49MH
S 831120001200 PTC #3 DUO
( ! )
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
296352110701
295016960100
296026015100
295016980100
296363430302
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Ķ
Ersatzteilliste
Spare Parts List
5 / 99
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
0100.000 29504 102 3400 X BAUSTEIN SIGNAL/ZF+TUNER MODULE SIGNAL/IF+TUNER
WW. 29504 102 3600 X BAUSTEIN SIGNAL/ZF+TUNER MODULE SIGNAL/IF+TUNER
0300.000 29504 103 4200 X FEATURE-BOX FEATURE-BOX
0400.000
S 29304 050 2900 NETZTEIL STAND BY POWER SUPPLY STAND BY
0400.000 S 29304 050 8200 NETZTEIL STAND BY POWER SUPPLY STAND BY
1040.000 29700 632 0109 HALTER BAUSTEIN HOLDER MODULE
1080.000 29303 119 6600 EURO-AV BUCHSENLEISTE 21-P. SCHWARZ EURO-AV SOCKET STRIP 21 P BLACK
1082.000 29303 119 6800 EURO-AV BUCHSENLEISTE 21-P. ORANGE EURO-AV SOCKET STRIP 21 P ORANGE
2300.000
S 29303 399 5100 NETZ EINBAUGERAETESTECKER APPLIANCE COUPLER W.CABLE
2410.000 29303 153 0100 2 MONTAGECLIP T53001/6006 MOUNTING CLIP T53001/6006
2420.000 29303 153 0200 MONTAGECLIP IC40020 MOUNTING CLIP IC40020
2430.000 29303 153 1200 3 MONTAGECLIP D60006/53071/53072 MOUNTING CLIP D60006/53071/53072
2435.000 29303 153 1208 10 MONTAGECLIP IC50010/50029/61001/ MOUNTING CLIP IC50010/50029/61001/
2445.000 29303 153 1605 MONTAGECLIP T52003 MOUNTING CLIP T52003
2460.000 29303 156 1800 2 FOLIE WAERMELEITEND D60006/T60006 FOIL HEAT CONDUCTING D60006/T60006
2470.000 29303 156 2000 12 FOLIE WAERMELEITEND IC50010/61006/ FOIL HEAT CONDUCTING IC50010/61006/
2480.000 29303 156 2100 2 FOLIE WAERMELEITEND D53071/53072 FOIL HEAT CONDUCTING D53071/53072
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 40013 84529 961 9000 ELKO 2200UF 20% 35V CB
C 40031 84529 961 4700 ELKO 1000UF 20% 25V CB
C 40032 84529 961 4700 ELKO 1000UF 20% 25V CB
C 40033 84529 961 4700 ELKO 1000UF 20% 25V CB
C 50012 84529 961 4700 ELKO 1000UF 20% 25V CB
C 50026 84529 961 4700 ELKO 1000UF 20% 25V CB
C 53071 85159 117 0200 FOKO FKP1 0,0125UF 3,5%2000V
C 60001 86500 811 2500 HV-KERKO 1000PF 20% 1KV
C 60006 86500 670 4600 HV-KERKO 100PF 20% 1KV
C 60012 86500 811 1100 HV-KERKO 270PF 20% 2KV
C 60023 86500 811 2500 HV-KERKO 1000PF 20% 1KV
C 60024 86500 811 2500 HV-KERKO 1000PF 20% 1KV
C 60026 86500 811 2500 HV-KERKO 1000PF 20% 1KV
C 60027 86500 811 2500 HV-KERKO 1000PF 20% 1KV
C 61004 84529 961 4700 ELKO 1000UF 20% 25V
C 61016 85159 110 3800 FOKO FKP1 100PF 10% 1600V
C 61021 86500 670 4600 HV-KERKO 100PF 20% 1KV
C 61026 86500 670 4600 HV-KERKO 100PF 20% 1KV
C 61032 84529 961 4700 ELKO 1000UF 20% 25V
C 61036 86500 670 4600 HV-KERKO 100PF 20% 1KV
C 61037 84520 970 5700 ELKO 28 1000UF 63V
C 61042 84529 961 0700 ELKO 2200UF 20% 16V
C 61061 86500 670 4600 HV-KERKO 100PF 20% 1KV
CHASSIS-FS-STEREO DIGI BASIC ++ / INL 4:3 CUC 1830
CHASSIS-TV-STEREO DIGI BASIC ++ / INL 4:3 CUC 1830
MATERIAL-NR. / PART NO.: 29701 096 7100
d©
29701 096 7100 CHASSIS-FS-STEREO DIGI BASIC ++/INL4:3 CHASSIS TV STEREO DIGI BASIC ++/INL4:3
CUC 1830 CUC 1830
KEIN E-TEIL NO SPARE PART
61030/61040/61050/D61016/61026/ 61030/61040/61050/D61016/61026/
61036/T50028 61036/T50028
61001/61030/61040/61050/D61016/61026/ 61001/61030/61040/61050/D61016/61026/
61036/T50028/50029/52003 61036/T50028/50029/52003
X = SIEHE GESONDERTE E-LISTE X = SEE SEPARATE PARTS LIST
WW. = WAHLWEISE WW. = OPTIONAL
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 61064 84529 961 5000 ELKO 2200UF 20% 25V CB
C 61066 86500 670 4600 HV-KERKO 100PF 20% 1KV
C62021
S 86600 982 3800 SI-KERKO B-SS 2200PF 20%400V
C62022 S 86600 982 3800 SI-KERKO B-SS 2200PF 20%400V
C62048
S 86600 982 3400 SI-KERKO B-SS 1000PF 20%400V
C 70509 84529 961 4700 ELKO 1000UF 20% 25V
CD 21221 83250 041 4800 SMD DIODE LS 4148
CD 21222 83250 041 4800 SMD DIODE LS 4148
CD 21231 83250 041 4800 SMD DIODE LS 4148
CD 21232 83250 041 4800 SMD DIODE LS 4148
CD 32315 83094 553 3100 MELF Z-DIODE 33B 0,5W
CD 34513 83250 041 4800 SMD DIODE LS 4148
CD 34517 83250 041 4800 SMD DIODE LS 4148
CD 40008 83094 551 0100 MELF-Z DIODE 10 B 0,5W
CD 40015 83250 041 4800 SMD DIODE LS 4148
CD 41011 83250 041 4800 SMD DIODE LS 4148
CD 43025 83250 041 4800 SMD DIODE LS 4148
CD 52003 83250 041 4800 SMD DIODE LS 4148
CD 53019 83250 041 4800 SMD DIODE LS 4148
CD 55003 83094 550 4000 MELF-Z DIODE 3,9 B 0,5W
CD 55004 83250 041 4800 SMD DIODE LS 4148
CD 58001 83250 041 4800 SMD DIODE LS 4148
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
TV
Ersatzteillisten / Spare Parts Lists CUC 1830 / 1836 / 1929
Page 35
GRUNDIG Service 49
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
CUC 1830 / 1836 / 1929 Ersatzteillisten / Spare Parts Lists
CD 58004 83250 041 4800 SMD DIODE LS 4148
CD 58007 83094 550 2800 MELF Z-DIODE 2,7 B 0,5W
CD 58011 83250 041 4800 SMD DIODE LS 4148
CD 58012 83250 041 4800 SMD DIODE LS 4148
CD 58021 83250 041 4800 SMD DIODE LS 4148
CD 58022 83250 041 4800 SMD DIODE LS 4148
CD 60201 83250 041 4800 SMD DIODE LS 4148
CD 60202 83250 041 4800 SMD DIODE LS 4148
CD 60223 83250 041 4800 SMD DIODE LS 4148
CD 70501 83094 550 5200 MELF-Z DIODE 5,1 B 0,5W
CD 70506 83250 041 4800 SMD DIODE LS 4148
CD 70507 83250 041 4800 SMD DIODE LS 4148
CD 70517 83250 041 4800 SMD DIODE LS 4148
CD 70521 83094 550 5200 MELF-Z DIODE 5,1 B 0,5W
CD 70522 83094 550 3300 MELF-Z DIODE 3,3 C 0,5W
CD 70523 83250 041 4800 SMD DIODE LS 4148
CD 70553 83250 041 4800 SMD DIODE LS 4148
CD 80060 83250 041 4800 SMD DIODE LS 4148
CD 80081 83250 041 4800 SMD DIODE LS 4148
CD 80085 83250 041 4800 SMD DIODE LS 4148
CD 80091 83094 550 3400 MELF Z-DIODE 3,3 B 0,5W A
CD 81004 83250 041 4800 SMD DIODE LS 4148
CIC43010 83058 145 5100 SMD IC MC14551BD/R2 MOT A
CT 21221 83010 068 4800 SMD-TRANS.BC 848 C
CT 21233 83010 068 4800 SMD-TRANS.BC 848 C
CT 32308 83010 038 5800 SMD-TRANS.BC 858 B
CT 32310 83010 038 5800 SMD-TRANS.BC 858 B
CT 32312 83010 038 5800 SMD-TRANS.BC 858 B
CT 32315 83010 038 5800 SMD-TRANS.BC 858 B
CT 40010 83010 048 4800 SMD-TRANS.BC 848 B
CT 43060 83010 048 4800 SMD-TRANS.BC 848 B
CT 43088 83010 048 4800 SMD-TRANS.BC 848 B
CT 43089 83010 038 5800 SMD-TRANS.BC 858 B
CT 43091 83010 038 5800 SMD-TRANS.BC 858 B
CT 43092 83010 048 4800 SMD-TRANS.BC 848 B
CT 43093 83010 048 4800 SMD-TRANS.BC 848 B
CT 43094 83010 048 4800 SMD-TRANS.BC 848 B
CT 43095 83010 048 4800 SMD-TRANS.BC 848 B
CT 46005 83010 048 4800 SMD-TRANS.BC 848 B
CT 58012 83010 048 4800 SMD-TRANS.BC 848 B
CT 60203 83010 048 4800 SMD-TRANS.BC 848 B
CT 60206 83010 068 5800 SMD-TRANS.BC 858 C
CT 60213 83010 038 5800 SMD-TRANS.BC 858 B
CT 61301 83010 048 4800 SMD-TRANS.BC 848 B
CT 61316 83010 048 4800 SMD-TRANS.BC 848 B
CT 70505 83010 048 4800 SMD-TRANS.BC 848 B
CT 70520 83010 068 4800 SMD-TRANS.BC 848 C
CT 70525 83010 068 5800 SMD-TRANS.BC 858 C
CT 80002 83010 068 5800 SMD-TRANS.BC 858 C
CT 80085 83010 038 5800 SMD-TRANS.BC 858 B
CT 81001 83010 048 4800 SMD-TRANS.BC 848 B
CT 81004 83010 048 4800 SMD-TRANS.BC 848 B
D 21212 83092 150 2000 DIODE 1 N 4004 -GA
D 32356 83092 150 2000 DIODE 1 N 4004 -GA
D 32357 83092 150 2000 DIODE 1 N 4004 -GA
D40006
S 83092 150 2000 DIODE 1 N 4004 -GA
D 50013 83095 162 8300 DIODE BYV 28-200 RA 12,5/
D 52006 83092 150 2000 DIODE 1 N 4004 -GA
D 53008 83092 010 0500 DIODE BA157
D 53019 83097 090 0300 Z DIODE ZY 51 ITT
D 53071 83092 043 5900 DIODE BY359 1500 PHI/ 5TU
D 53072 83092 042 3000 DIODE BY 229-600
D 54001 83092 010 0500 DIODE BA157
D 55012 83097 203 3300 Z DIODE 33 C 0,5W
D 60006 83098 208 8000 DIODE MUR 880 WW.BYT 08 P
D 60012 83095 167 5400 DIODE BYT53B TFK/ EGP10B
D 60014 83092 000 2100 DIODE BAV21 ITT/ TFK AV61
D 60023 83085 605 2000 GLR.B 380 C 3700/2200 >>
D 60202 83097 201 3100 Z DIODE 13 B 0,5W
D 60203 83097 200 8300 Z DIODE 8,2 B 0,5W
D 60207 83092 150 2000 DIODE 1 N 4004 -GA
D 60208 83092 150 2000 DIODE 1 N 4004 -GA
D 60216 83092 000 2100 DIODE BAV21 ITT/ TFK
D 60217 83092 011 5900 DIODE BA159
S 83096 631 8000 Z-DIODE BZT03D180
D60218
D 60221 83092 011 5900 DIODE BA159
D60222
S 83096 631 8000 Z-DIODE BZT03D180
D60223 S 83096 631 8000 Z-DIODE BZT03D180
D 61001 83095 167 5400 DIODE BYT53B TFK/ EGP10B
D 61011 83095 160 3800 DIODE BYV38 TFK
D 61012 83095 160 3800 DIODE BYV38 TFK
D 61016 83098 208 8000 DIODE MUR 880 WW.BYT 08 P
D61021
S 83095 171 7200 DIODE BYW172D TEMIC/ FUF5
D 61026 83098 208 4000 DIODE MUR 840/BYV 29-400/
D 61033 83092 150 2000 DIODE 1 N 4004 -GA
D 61036 83098 208 4000 DIODE MUR 840/BYV 29-400/
D61061
S 83095 171 7200 DIODE BYW172D TEMIC/ FUF5
D61066 S 83095 171 7200 DIODE BYW172D TEMIC/ FUF5
D 70508 83097 201 1600 Z-DIODE 15 C 0,5W
IC 32300 83057 954 0000 SMD IC MSP3400C-PS-C8 PLC
IC 32310 83052 057 0000 IC 78M05 2%
IC 34510 83053 347 8000 IC TDA4780V3/ V4
IC 40020 83053 372 6100 IC TDA7262 SGS
IC 41010 83053 330 0600 IC TDA3006 SMI
IC 43080 83053 664 2500 IC TEA6425 SGS
IC 50010 83053 441 7300 IC TDA4173AF
IC 55010 83053 381 4500 IC TDA8145
IC 58010 83052 043 9300 IC LM393P TID/ 393N RAY/M
IC 60010 83053 546 0500 IC TDA4605/3
IC 60220 83053 615 0100 IC TEA1501 N1 TIP8 PHI
IC 61001 83052 043 1700 IC LM317T NSC/MOT/SGS
IC 61006 83052 043 1700 IC LM317T NSC/MOT/SGS
IC 61030 83052 043 1700 IC LM317T NSC/MOT/SGS
IC 61040 83052 043 5000 IC LM350T
IC 61310 83052 043 5700 IC LM358N NSC/TID/MOT/RAY
IC 80040 83052 100 6500 IC MC33164P-5RP AV330 ERIC 80050 83059 452 5100 SMD IC SDA5250D49
IC 80060 19798 323 0900 IC 27C040-150NS PROG.KPL
IC 80065 83051 240 0800 IC M24C08B1/ M24C08-BN6
IC 80070 83056 024 1000 IC ST24W02CB1/ M24C02-BN6
IC 80090 83052 043 9300 IC LM393P TID/ 393N RAY/M
L 32342 81405 232 4900 DR ST 0411-GRP 10UH 10%
L 34517 81405 263 6100 DR 0411 10UH 5% AV619 -AM
L 46021 81405 229 0300 DR ST 0411 1,5UH 2% SIE A
L 53001 81049 820 5600 FERRITPERLE HF70 BTL 3,5X
L 53002 81049 820 5600 FERRITPERLE HF70 BTL 3,5X
L 53003 81049 820 5600 FERRITPERLE HF70 BTL 3,5X
L 53011 81405 052 4900 DR A AX-GA 10UH 10%
L 53012 09240 114 0400 DROSSEL 1,5 MH/CHOKE COIL
L 53021 29203 122 9700 LINEARITAETSREGLER (70CM)
L 53074 09246 859 5500 BRUECKENSPULE M.KERN
L 55014 09245 816 0100 O/W AUSKOPPELSPULE
L 60006 29701 739 0800 DAEMPFUNGSPERLE UV 930 30
L 61011 81049 820 1400 DAEMPF-PERLE 433003038102
L 61016 81049 820 1400 DAEMPF-PERLE 433003038102
L 61021 81049 820 1400 DAEMPF-PERLE 433003038102
L 61026 81049 820 1400 DAEMPF-PERLE 433003038102
L 61036 81049 820 1400 DAEMPF-PERLE 433003038102
L 61061 81049 820 1400 DAEMPF-PERLE 433003038102
L 61062 81405 050 6500 DR A AX-GA 47UH 5%
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
FERRITE BEAD
LINEARITY CONTROL
BRIDGE COIL
E/W DECOUPLING COIL
DAMPING BEAD
L 61066 81049 820 1400 DAEMPF-PERLE 433003038102
L 61067 81405 050 6500 DR A AX-GA 47UH 5%
L 70508 09241 035 9700 STABKERNDROSSEL
L 70555 81405 263 6100 DR 0411 10UH 5%
OK60031
S83060 000 1200 OPTOKOPPLER CNY17F1/ CNY1
OK60046 S 83060 000 1200 OPTOKOPPLER CNY17F1/ CNY1
Q 32305 83824 391 8600 QUARZ #439-9 18,432MHZ 12
Q 80055 86023 311 5500 KERRES #155 18MHZ RAD
R21101
S 87053 210 2000 MOW 0411 6,2 OHM 5%
R32357 S 87011 210 2700 KSW SI B 12 OHM 5%
R40017
S 87003 290 0700 KSW NB 0207 1,8 OHM 5%
R40027 S 87003 290 0700 KSW NB 0207 1,8 OHM 5%
R41016 S 87003 290 2700 KSW NB 0207 12 OHM 5%
R43004
S 87011 210 1300 KSW SI B 3,3 OHM 5%
R43098 S 87011 210 1300 KSW SI B 3,3 OHM 5%
R52001 S 87053 290 1700 MOW 0411 4,7 OHM 5%
R52006
S 87053 690 0300 MOW 0617 1,2 OHM 5%
R53011 87052 270 2100 MOW 0411 6,8 OHM 5%
R53016
S 87302 800 2100 DRW SI S11 7W 6,8 OHM 5%
R53021 S 87053 690 6300 MOW 0617 390 OHM 5%
R54001 S 87350 030 3300 DRW 0,75W 0,33 OHM 10%
R55012 S 87053 690 6500 MOW 0617 470 OHM 5%
R55014
S 87012 308 1700 NKS 3 4,7 OHM 5% ROE
R60012 87000 490 4100 KSW 0411 47 OHM 5%
R60028 87650 441 2700 MSW 0414 180 KOHM 5% TK10
R60029
S 87053 691 1300 MOW 0617 47 KOHM 5%
R60207 S 87003 290 1700 KSW NB 0207 4,7 OHM 5%
R61001 87900 500 1700 ESTR.SK10-A 220 OHM LIN
R61018 87052 213 2100 MOW 0411 100 KOHM 10%
R61031 87900 500 2500 ESTR.SK10-A 470 OHM LIN
R61041 87900 500 1700 ESTR.SK10-A 220 OHM LIN
R61313 87900 500 5400 ESTR.SK10-A 22 KOHM LIN
R62049
S 87663 491 5500 MSW SI 0414 2,7 MOHM 5%
SI60001
S 83156 200 6800 SI LOET T2A 250V MST250/2
SI60201 S 83156 070 2600 SI LOET T100MA 250V
SI61022
S 83156 190 2800 SI LOET T1,6A 250V
SI61026 S 83156 210 2700 SI LOET T2,5A 250V AV330
SI61036 S 83156 210 2700 SI LOET T2,5A 250V AV330
SI61061
S 83156 202 2500 SI LOET T2A 250V
SI61066 S 83156 202 2500 SI LOET T2A 250V
T 40010 83032 873 6800 TRANS.BC 368 GEG.AMMO-PAC
T 50028 83022 105 4400 TRANS BD544B TID/ BD538
T 50029 83022 105 4300 TRANS BD543B TID/ BD537
T 52003 83022 180 4300 TRANS.BDX 43
T 53001 83026 253 3100 TRANS 2SC5331
T 60006 83028 050 5000 TRANS IRFPC50 IRF/ 2SK26
T 60223 83022 690 9100 TRANS.BUZ 90 A TYP 2/3 TY
TR 52001 09246 867 9700 UEBERTRAGER VOGT
TR53010
S 29201 680 0100 TRAFO DIODEN-SPLIT DIGI
TR60001
S 29201 568 9700 TRAFO SPERRWANDLER
TR60220
S 29201 701 9700 TRAFO STAND-BY
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 72010 800 0000, sowie zusätzlich die eventuell
abweichenden, landesspezifischen Vorschriften!
DAMPING BEAD
BAR CORE CHOKE COIL
TRANSFORMER
DIODE SPLIT TRANSFORMER
B.O.-TYPE CONVERTER
TRANSFORMER
TRANSFORMER STAND-BY
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 72010 800 0000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Page 36
50 GRUNDIG Service
Ersatzteilliste
Spare Parts List
11 / 2000
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
0100.000 295041023600 X BAUSTEIN SIGNAL / ZF+TUNER MODULE SIGNAL / IF+TUNER
0247.000 293031196600 EURO-AV BUCHSENLEISTE 21-POL SW EURO-AV SOCKET STRIP 21 P BLACK
0247.000 293031196800 EURO-AV BUCHSENLEISTE 21-POL OR EURO-AV SOCKET STRIP 21 P ORANGE
0400.000 295042091500 X FEATURE-BOX BASIC 3 FEATURE-BOX BASIC 3
WW. 295042090500 X FEATURE-BOX BASIC ++/BASIC 3 FEATURE-BOX BASIC ++/BASIC 3
0401.000 297006320201 HALTER BAUSTEIN HOLDER MODULE
0405.000
0406.000 297006131104 NETZTEILAUFNAHME HOLDER POWER SUPPLY
2200.000
2310.000 S 293033892101 VORSCHALTDROSSEL KPL LOETBAR SERIES REACTOR CPL SOLDERING
2310.000
2400.000 293031530100 MONTAGECLIP T60006 MOUNTING CLIP T60006
2405.000 293031530107 MONTAGECLIP T53001 MOUNTING CLIP T53001
2410.000 293031530200 MONTAGECLIP IC40020 MOUNTING CLIP IC40020
2415.000 293031531200 MONTAGECLIP D60006 MOUNTING CLIP D60006
2420.000 293031531208 12 MONTAGECLIP D53071/53072/61016/ MOUNTING CLIP D53071/53072/61016/
2425.000 293031531605 MONTAGECLIP T52003 MOUNTING CLIP T52003
2450.000 293031561800 2 FOLIE WAERMELEITEND D60006/T60006 FOIL HEAT CONDUCTING D60006/T60006
2460.000 293031562000 10 FOLIE WAERMELEITEND D61026/61036/ FOIL HEAT CONDUCTING D61026/61036/
2470.000 293031562100 2 FOLIE WAERMELEITEND D53071/53072 FOIL HEAT CONDUCTING D53071/53072
2480.000 293031562301 FOLIE WAERMELEITEND T53001 FOIL HEAT CONDUCTING T53001
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 40013 845299619000 ELKO 2200UF 20% 35V
C 40031 845299614700 ELKO 1000UF 20% 25V
C 40032 845299614700 ELKO 1000UF 20% 25V
C 40033 845299614700 ELKO 1000UF 20% 25V
C 50012 845299614700 ELKO 1000UF 20% 25V
C 50026 845299614700 ELKO 1000UF 20% 25V
C 53012 851591160200 FOKO FKP1 142PF 2,5% 2000V
C 53071 851591170200 FOKO FKP1 0,0125UF 3,5% 2000V
C 60001 865008112500 KERKO HV C 1000PF 20% 1KV
C 60006 865006704600 KERKO HV C 100PF 20% 1KV
C 60009 851591104000 FOKO FKP1 220PF 10% 1600V
C 60012 865008111100 KERKO HV C 270PF 20% 2KV
C 60023 865008112500 KERKO HV C 1000PF 20% 1KV
C 60024 865008112500 KERKO HV C 1000PF 20% 1KV
C 60026 865008112500 KERKO HV C 1000PF 20% 1KV
C 60027 865008112500 KERKO HV C 1000PF 20% 1KV
C 60028 844330605900 ELKO 15 300/330UF 385V
Ķ
CHASSIS-FS-STEREO CUC 1830 BASIC++/INL 4:3
CHASSIS TV STEREO CUC 1830 BASIC++/INL 4:3
d©
297040152700 CHASSIS-FS-STEREO CHASSIS TV STEREO
S 293040508500 NETZTEIL STAND BY POWER SUPPLY STAND BY
S 293033995100 NETZ EINBAUGERAETESTECKER APPLIANCE COUPLER W.CABLE
S 293033892102 VORSCHALTDROSSEL KPL STECKBAR SERIES REACTOR CPL INSERT
CUC 1830 BASIC++/INL 4:3 CUC 1830 BASIC++/INL 4:3
KEIN E-TEIL NO SPARE PART
61026/D61036/IC50010/61001/61006/ 61026/D61036/IC50010/61001/61006/
61030/61040/T50028/50029 61030/61040/T50028/50029
IC50010/61001/61003/61006/61040/ IC50010/61001/61003/61006/61040/
T50028/50029/52003 T50028/50029/52003
X =SIEHE GESONDERTE E-LISTE X =SEE SEPARATE PARTS LIST
WW. = WAHLWEISE WW. = OPTIONAL
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
WW. 845199712400 ELKO #6 300UF +50-20% 385V
C 61004 845299614700 ELKO 1000UF 20% 25V
C 61016 851591103800 FOKO FKP1 100PF 10% 1600V
C 61021 865006704600 KERKO HV C 100PF 20% 1KV
C 61026 865006704600 KERKO HV C 100PF 20% 1KV
C 61032 845299614700 ELKO 1000UF 20% 25V
C 61036 865006704600 KERKO HV C 100PF 20% 1KV
C 61037 845209705700 ELKO 28 1000UF 63V
C 61042 845299610700 ELKO 2200UF 20% 16V
C 61061 865006704600 KERKO HV C 100PF 20% 1KV
C 61064 845299615000 ELKO 2200UF 20% 25V
C 61066 865006704600 KERKO HV C 100PF 20% 1KV
C 62048
S 866009823400 KERKO SI 1000PF 20% 400V
C 70509 845299614700 ELKO 1000UF 20% 25V
CD 21221 830953414900 MELF-DIODE LL 4148
CD 21222 830953414900 MELF-DIODE LL 4148
MATERIAL-NR. / PART NO.: 297040152700
TV
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
CD 21231 830953414900 MELF-DIODE LL 4148
CD 21232 830953414900 MELF-DIODE LL 4148
CD 32315 830945533100 MELF Z-DIODE 33B 0,5W
CD 34513 830953414900 MELF-DIODE LL 4148
CD 34517 830953414900 MELF-DIODE LL 4148
CD 40008 830945510100 MELF-Z DIODE 10 B 0,5W
CD 40015 830953414900 MELF-DIODE LL 4148
CD 41011 830953414900 MELF-DIODE LL 4148
CD 43025 830953414900 MELF-DIODE LL 4148
CD 52003 830953414900 MELF-DIODE LL 4148
CD 53019 830953414900 MELF-DIODE LL 4148
CD 55003 830945504000 MELF-Z DIODE 3,9 B 0,5W
CD 55004 830953414900 MELF-DIODE LL 4148
CD 58001 830953414900 MELF-DIODE LL 4148
CD 58004 830953414900 MELF-DIODE LL 4148
CD 58007 830945502800 MELF Z-DIODE 2,7 B 0,5W
CD 58011 830953414900 MELF-DIODE LL 4148
CD 58012 830953414900 MELF-DIODE LL 4148
CD 58021 830953414900 MELF-DIODE LL 4148
CD 58022 830953414900 MELF-DIODE LL 4148
CD 70501 830945505200 MELF-Z DIODE 5,1 B 0,5W
CD 70506 830953414900 MELF-DIODE LL 4148
CD 70507 830953414900 MELF-DIODE LL 4148
CD 70517 830953414900 MELF-DIODE LL 4148
CD 70521 830945505200 MELF-Z DIODE 5,1 B 0,5W
CD 70522 830945503300 MELF-Z DIODE 3,3 C 0,5W
CD 70523 830953414900 MELF-DIODE LL 4148
CD 70553 830953414900 MELF-DIODE LL 4148
CD 80060 830953414900 MELF-DIODE LL 4148
CD 80081 830953414900 MELF-DIODE LL 4148
CD 80085 830953414900 MELF-DIODE LL 4148
CD 80091 830945503400 MELF Z-DIODE 3,3 B 0,5W
CD 81004 830953414900 MELF-DIODE LL 4148
CIC43010 830581455100 SMD IC MC14551BD/R2
CT 21221 830100684800 SMD TRANS BC848C/ BC847C
CT 21233 830100684800 SMD TRANS BC848C/ BC847C
CT 32308 830100385800 SMD TRANS BC858B/ BC857B
CT 32310 830100385800 SMD TRANS BC858B/ BC857B
CT 32312 830100385800 SMD TRANS BC858B/ BC857B
CT 32315 830100385800 SMD TRANS BC858B/ BC857B
CT 40010 830100484800 SMD TRANS BC848B/ BC847B
CT 43060 830100484800 SMD TRANS BC848B/ BC847B
CT 43088 830100484800 SMD TRANS BC848B/ BC847B
CT 43089 830100385800 SMD TRANS BC858B/ BC857B
CT 43091 830100385800 SMD TRANS BC858B/ BC857B
CT 43092 830100484800 SMD TRANS BC848B/ BC847B
CT 43093 830100484800 SMD TRANS BC848B/ BC847B
CT 43094 830100484800 SMD TRANS BC848B/ BC847B
CT 43095 830100484800 SMD TRANS BC848B/ BC847B
CT 46005 830100484800 SMD TRANS BC848B/ BC847B
CT 58012 830100484800 SMD TRANS BC848B/ BC847B
CT 61301 830100484800 SMD TRANS BC848B/ BC847B
CT 61316 830100484800 SMD TRANS BC848B/ BC847B
CT 70505 830100484800 SMD TRANS BC848B/ BC847B
CT 70520 830100684800 SMD TRANS BC848C/ BC847C
CT 70525 830100685800 SMD TRANS BC858C/ BC857C
CT 80002 830100685800 SMD TRANS BC858C/ BC857C
CT 80085 830100385800 SMD TRANS BC858B/ BC857B
CT 81001 830100484800 SMD TRANS BC848B/ BC847B
CT 81004 830100484800 SMD TRANS BC848B/ BC847B
D 21212 830921502000 DIODE 1 N 4004
D 32356 830921502000 DIODE 1 N 4004
D 32357 830921502000 DIODE 1 N 4004
D 40006
S 830921502000 DIODE 1 N 4004
D 50013 830951628300 DIODE BYV 28-200
D 52006 830921502000 DIODE 1 N 4004
D 53008 830920100500 DIODE BA157
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
D 53019 830970900300 Z DIODE ZY 51
D 53071 830920435900 DIODE BY359 1500
D 53072 830920423000 DIODE BY 229-600
D 54001 830920100500 DIODE BA157
D 55012 830972033300 Z DIODE 33 C 0,5W
D 60006 830982088000 DIODE MUR 880 WW.BYT 08 P
D 60012 830951675400 DIODE BYT53B
D 60014 830920002100 DIODE BAV21
D 60023 830856052000 GLR.B 380 C 3700/2200
D 60216 830920002100 DIODE BAV21
D 60217 830920115900 DIODE BA159
S 830966318000 Z-DIODE BZT03D180
D 60218
D 61001 830951675400 DIODE BYT53B
D 61011 830951603800 DIODE BYV38
D 61012 830951603800 DIODE BYV38
D 61016 830982088000 DIODE MUR 880 WW.BYT 08 P
D 61021
S 830951717200 DIODE BYW172D
D 61026 830982084000 DIODE MUR 840/BYV 29-400
D 61033 830921502000 DIODE 1 N 4004
D 61036 830982084000 DIODE MUR 840/BYV 29-400
D 61061
S 830951717200 DIODE BYW172D
D 61066 S 830951717200 DIODE BYW172D
D 70508 830972011600 Z-DIODE 15 C 0,5W
IC 32300 830579540000 SMD IC MSP3400C-PS-C8 PLC
IC 32310 830520570000 IC 78M05 2%
IC 34510 830533478000 IC TDA4780V3/ V4
IC 40020 830533726100 IC TDA7262
IC 41010 830533300600 IC TDA3006
IC 43080 830536642500 IC TEA6425
IC 50010 830534417300 IC TDA4173AF
IC 55010 830533814500 IC TDA8145
IC 58010 830520439300 IC LM393P
IC 60010 830535460500 IC TDA4605/3
IC 60220 830536150100 IC TEA1501 N1
IC 61001 830520431700 IC LM317T
IC 61006 830520431700 IC LM317T
IC 61040 830520435000 IC LM350T
IC 61310 830520435700 IC LM358N
IC 80040 830521006500 IC MC33164P-5RP
IC 80050 830594525100 SMD IC SDA5250D49
IC 80060 197983270100 IC 27C040-150NS PROG.KPL
IC 80065 830512400800 IC M24C08B1/ M24C08-BN6
IC 80070 830560241000 IC ST24W02CB1/ M24C02-BN6
IC 80090 830520439300 IC LM393P
L 32342 814052324900 DR ST 0411-GRP 10UH 10%
L 34517 814052636100 DR 0411 10UH 5%
L 46021 814052290300 DR ST 0411 1,5UH 2%
L 53001 810498205600 FERRITPERLE HF70 BTL 3,5X6
L 53002 810498205600 FERRITPERLE HF70 BTL 3,5X6
L 53003 810498205600 FERRITPERLE HF70 BTL 3,5X6
L 53011 814050524900 DR A AX-GA 10UH 10%
L 53012 092401140400 DROSSEL 1,5 MH/COIL 1.5 MH
L 53021 292031229700 LINEARITAETSREGLER (70CM)
L 53074 092468595500 BRUECKENSPULE M.KERN
L 55014 092458160100 O/W AUSKOPPELSPULE
L 60006 297017390800 DAEMPFUNGSPERLE
L 61011 810498201400 DAEMPF-PERLE 433003038102
L 61016 810498201400 DAEMPF-PERLE 433003038102
L 61021 810498201400 DAEMPF-PERLE 433003038102
L 61026 810498201400 DAEMPF-PERLE 433003038102
L 61036 810498201400 DAEMPF-PERLE 433003038102
L 61061 810498201400 DAEMPF-PERLE 433003038102
L 61062 814050506500 DR A AX-GA 47UH 5%
FERRITE BEAD
LINEARITY CONTROL
BRIDGE COIL W.CORE
E/W DECOUPLING COIL
DAMPING BEAD
Ersatzteillisten / Spare Parts Lists CUC 1830 / 1836 / 1929
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Page 37
GRUNDIG Service 51
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
L 61066 810498201400 DAEMPF-PERLE 433003038102
L 61067 814050506500 DR A AX-GA 47UH 5%
L 70508 092410359700 STABKERNDROSSEL
L 70555 814052636100 DR 0411 10UH 5%
OK 60031
S830600001200 OPTOKOPPLER CNY17F1
OK 60046 S830600001200 OPTOKOPPLER CNY17F1
Q 32305 838243918600 QUARZ #439-9 18,432MHZ 12PF
Q 80055 860233115500 KERRES #155 18MHZ
R 21101
S 870532102000 MOW 0411 6,2 OHM 5%
R 32315 S 870537009900 MOW 0922 12 KOHM 5% LI
R 32357
S 870112102700 KSW SI B 12 OHM 5% LI
R 32359 S 870032904700 KSW NB 0207 82 OHM 5% LI
R 40013 S 870532907300 MOW 0411 1 KOHM 5% LI
R 40017
S 870032900700 KSW NB 0207 1,8 OHM 5% LI
R 40027 S 870032900700 KSW NB 0207 1,8 OHM 5% LI
R 40031 S 870032903100 KSW NB 0207 18 OHM 5% LI
R 41016
S 870032902700 KSW NB 0207 12 OHM 5% LI
R 43004 S 870112101300 KSW SI B 3,3 OHM 5% LI
R 43098
S 870112101300 KSW SI B 3,3 OHM 5% LI
R 50007 S 876632740500 MSW 0207 1,5 OHM 1%
R 50008 S 876632740500 MSW 0207 1,5 OHM 1%
R 50027 S 870012120500 KSW 0207 1,5 OHM 5% LI
R 50029
S 876635705900 MSW 0414 270 OHM 5%
R 52001 S 870532901700 MOW 0411 4,7 OHM 5%
R 52003
S 873506403900 DRW 4 39 OHM 5%
R 52006 S 870536900300 MOW 0617 1,2 OHM 5% LI
R 53002 S 870012120500 KSW 0207 1,5 OHM 5% LI
R 53003
S 870012120500 KSW 0207 1,5 OHM 5% LI
R 53008 S 870032909700 KSW NB 0207 10 KOHM 5% LI
R 53011 870522702100 MOW 0411 6,8 OHM 5%
R 53016
S 873028002100 DRW SI S11 7W 6,8 OHM 5%
R 53021 S 870536906300 MOW 0617 390 OHM 5% LI
R 54001 S 873500303300 DRW 0,75W 0,33 OHM 10%
R 55012
S 870536906500 MOW 0617 470 OHM 5% LI
R 55014 S 870123081700 NKS 3 4,7 OHM 5%
R 58001 876509830400 MSW 0207 20 KOHM 2%
R 60001 870006913100 KSW 0617 270 KOHM
R 60002 870006914100 KSW 0617 680 KOHM
R 60008 873017930100 DRW 7 15 KOHM 10% ST
R 60012 870004904100 KSW 0411 47 OHM 5%
R 60016
S 870537004300 MOW 0922 56 OHM 5% LI
R 60028 876504412700 MSW 0414 180 KOHM 5%
R 60029
S 870536911300 MOW 0617 47 KOHM 5% LI
R 60212 S 876504915300 MSW SI 0414 2,2 MOHM VDE
R 61001 879005001700 ESTR.SK10-A 220 OHM LIN
R 61018 870522132100 MOW 0411 100 KOHM 5%
R 61022
S 873229601100 DRW 6,5 2,7 OHM 10%
R 61031 879005002500 ESTR.SK10-A 470 OHM LIN
R 61033
S 870537005800 MOW 0922 100 OHM 10% LI
R 61041 879005001700 ESTR.SK10-A 220 OHM LIN
R 61313 879005005400 ESTR.SK10-A 22 KOHM LIN
R 62049
S 876634915500 MSW SI 0414 2,7 MOHM 5% LI
SI 60001
S 831562006800 SI LOET T2A 250V
SI 60201 S 831560702600 SI LOET T100MA 250V
SI 61022 S 831561902800 SI LOET T1,6A 250V
SI 61026
S 831562102700 SI LOET T2,5A 250V
SI 61036 S 831562102700 SI LOET T2,5A 250V
SI 61061 S 831562022500 SI LOET T2A 250V
SI 61066
S 831562022500 SI LOET T2A 250V
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 720108000000, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
DAMPING BEAD
BAR CORE CHOKE COIL
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
T 40010 830328736800 TRANS.BC 368
T 50028 830221054400 TRANS BD544B/ BD538
T 50029 830221054300 TRANS BD543B/ BD537
T 52003 830221804300 TRANS.BDX 43
T 53001 830262533100 TRANS 2SC5331
T 60006 830280505000 TRANS IRFPC50
TR 52001 092468679700 UEBERTRAGER VOGT
S 292016800100 TRAFO DIODEN-SPLIT
TR 53010
TR 60001S 292015689700 TRAFO SPERRWANDLER
TR 60220
S 292016199700 SPERRWANDLERTRAFO KPL
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
TRANSFORMER
DIODE SPLIT TRANSFORMER
REVERSE CONVERTER
TRANSFORMER
REVERSE CONVERTER
TRANSFORMER
Ersatzteilliste
Spare Parts List
10 / 2000
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
297040150300 CHASSIS-FS-STEREO CHASSIS TV STEREO
0100.000 295041623400 X BAUSTEIN SIGNAL / ZF+TUNER MODULE SIGNAL / IF+TUNER
WW. 295041623600 X BAUSTEIN SIGNAL / ZF+TUNER MODULE SIGNAL / IF+TUNER
0247.000 293031196600 EURO-AV BUCHSENLEISTE 21-POL SW EURO-AV SOCKET STRIP 21 P BLACK
0247.000 293031196800 EURO-AV BUCHSENLEISTE 21-POL OR EURO-AV SOCKET STRIP 21 P ORANGE
0400.000 295041034201 X FEATURE-BOX DIGI BASIC ++ FEATURE-BOX DIGI BASIC ++
0401.000 297006320109 HALTER BAUSTEIN 295041034201 HOLDER MODULE 295041034201
0405.000 293040508500 NETZTEIL STAND BY POWER SUPPLY STAND BY
0406.000 297006131104 NETZTEILAUFNAHME HOLDER POWER SUPPLY
2200.000
S 293033995100 NETZ EINBAUGERAETESTECKER APPLIANCE COUPLER W.CABLE
2310.000
S 293033892101 VORSCHALTDROSSEL KPL LOETBAR SERIES REACTOR CPL SOLDERING
2310.000 S 293033892102 VORSCHALTDROSSEL KPL STECKBAR SERIES REACTOR CPL INSERT
2400.000 293031530100 MONTAGECLIP T60006 MOUNTING CLIP T60006
2410.000 293031530107 MONTAGECLIP T53001 MOUNTING CLIP T53001
2420.000 293031530200 MONTAGECLIP IC40020 MOUNTING CLIP IC40020
2430.000 293031531200 MONTAGECLIP D60006 MOUNTING CLIP D60006
2440.000 293031531208 12 MONTAGECLIP D53071/53072/61016/ MOUNTING CLIP D53071/53072/61016/
2445.000 293031531605 MONTAGECLIP T52003 MOUNTING CLIP T52003
2450.000 293031561800 2 FOLIE WAERMELEITEND D60006/T60006 FOIL HEAT CONDUCTING D60006/T60006
2460.000 293031562000 10 FOLIE WAERMELEITEND D61026/61036 FOIL HEAT CONDUCTING D61026/61036
2470.000 293031562100 2 FOLIE WAERMELEITEND D53071/53072 FOIL HEAT CONDUCTING D53071/53072
2480.000 293031562301 FOLIE WAERMELEITEND T53001 FOIL HEAT CONDUCTING T53001
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 40013 845299619000 ELKO 2200UF 20% 35V
C 40031 845299614700 ELKO 1000UF 20% 25V
C 40032 845299614700 ELKO 1000UF 20% 25V
C 40033 845299614700 ELKO 1000UF 20% 25V
C 50012 845299614700 ELKO 1000UF 20% 25V
C 50026 845299614700 ELKO 1000UF 20% 25V
C 53012 851591160200 FOKO FKP1 142PF 2,5% 2000V
C 53071 851591169000 FOKO FKP1 9000PF 3,5% 2000V
C 60001 865008112500 KERKO HV C 1000PF 20% 1KV
C 60006 865006704600 KERKO HV C 100PF 20% 1KV
C 60009 851591104000 FOKO FKP1 220PF 10% 1600V
C 60012 865008111100 KERKO HV C 270PF 20% 2KV
C 60023 865008112500 KERKO HV C 1000PF 20% 1KV
C 60024 865008112500 KERKO HV C 1000PF 20% 1KV
C 60026 865008112500 KERKO HV C 1000PF 20% 1KV
C 60027 865008112500 KERKO HV C 1000PF 20% 1KV
C 60028 845199712400 ELKO #6 300UF +50-20% 385V
C 60028 844330605900 ELKO 15 300/330UF 385V
CHASSIS-FS-STEREO CUC 1836 BASIC++/INL 4:3
CHASSIS TV STEREO CUC 1836 BASIC++/INL 4:3
d©
CUC 1836 BASIC ++/INL 4:3 CUC 1836 BASIC ++/INL 4:3
KEIN E-TEIL NO SPARE PART
61026/61036/IC50010/61001/6106/ 61026/61036/IC50010/61001/6106/
61030/61040/T50028/50029 61030/61040/T50028/50029
IC50010/61001/61006/61030/61040 IC50010/61001/61006/61030/61040
T50028/50029/52003 T50028/50029/52003
X = SIEHE GESONDERTE E-LISTE X = SEE SEPARATE PARTS LIST
WW. = WAHLWEISE WW. = OPTIONAL
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 61004 845299614700 ELKO 1000UF 20% 25V
C 61016 851591103800 FOKO FKP1 100PF 10% 1600V
C 61021 865006704600 KERKO HV C 100PF 20% 1KV
C 61026 865006704600 KERKO HV C 100PF 20% 1KV
C 61032 845299614700 ELKO 1000UF 20% 25V
C 61036 865006704600 KERKO HV C 100PF 20% 1KV
C 61037 845209705700 ELKO 28 1000UF 63V
C 61042 845299610700 ELKO 2200UF 20% 16V
C 61061 865006704600 KERKO HV C 100PF 20% 1KV
C 61066 865006704600 KERKO HV C 100PF 20% 1KV
C 62021
S 866009823800 KERKO SI 2200PF 20% 400V
C 62022 S 866009823800 KERKO SI 2200PF 20% 400V
C 62048
S 866009823400 KERKO SI 1000PF 20% 400V
C 70509 845299614700 ELKO 1000UF 20% 25V
CD 21201 830953414900 MELF-DIODE LL 4148
CD 21202 830953414900 MELF-DIODE LL 4148
CD 21203 830953414900 MELF-DIODE LL 4148
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Ķ
TV
MATERIAL-NR. / PART NO.: 297040150300
CUC 1830 / 1836 / 1929 Ersatzteillisten / Spare Parts Lists
Page 38
52 GRUNDIG Service
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
Ersatzteillisten / Spare Parts Lists CUC 1830 / 1836 / 1929
CD 21206 832531310300 MELF DIODE BAV103
CD 32315 830945533100 MELF Z-DIODE 33B 0,5W
CD 34513 830953414900 MELF-DIODE LL 4148
CD 34517 830953414900 MELF-DIODE LL 4148
CD 40008 830945510100 MELF-Z DIODE 10 B 0,5W
CD 40015 830953414900 MELF-DIODE LL 4148
CD 41011 830953414900 MELF-DIODE LL 4148
CD 43025 830953414900 MELF-DIODE LL 4148
CD 52003 830953414900 MELF-DIODE LL 4148
CD 53019 830953414900 MELF-DIODE LL 4148
CD 55003 830945504000 MELF-Z DIODE 3,9 B 0,5W
CD 55004 830953414900 MELF-DIODE LL 4148
CD 58001 830953414900 MELF-DIODE LL 4148
CD 58004 830953414900 MELF-DIODE LL 4148
CD 58007 830945502800 MELF Z-DIODE 2,7 B 0,5W
CD 58011 830953414900 MELF-DIODE LL 4148
CD 58012 830953414900 MELF-DIODE LL 4148
CD 58021 830953414900 MELF-DIODE LL 4148
CD 58022 830953414900 MELF-DIODE LL 4148
CD 70501 830945505200 MELF-Z DIODE 5,1 B 0,5W
CD 70506 830953414900 MELF-DIODE LL 4148
CD 70507 830953414900 MELF-DIODE LL 4148
CD 70517 830953414900 MELF-DIODE LL 4148
CD 70553 830953414900 MELF-DIODE LL 4148
CD 80060 830953414900 MELF-DIODE LL 4148
CD 80081 830953414900 MELF-DIODE LL 4148
CD 80085 830953414900 MELF-DIODE LL 4148
CD 80091 830945503400 MELF Z-DIODE 3,3 B 0,5W
CD 81004 830953414900 MELF-DIODE LL 4148
CIC43010 830581455100 SMD IC MC14551BD/R2
CT 32308 830100385800 SMD TRANS BC858B/ BC857B
CT 32310 830100385800 SMD TRANS BC858B/ BC857B
CT 32312 830100385800 SMD TRANS BC858B/ BC857B
CT 32315 830100385800 SMD TRANS BC858B/ BC857B
CT 40010 830100484800 SMD TRANS BC848B/ BC847B
CT 43060 830100484800 SMD TRANS BC848B/ BC847B
CT 43088 830100484800 SMD TRANS BC848B/ BC847B
CT 43089 830100385800 SMD TRANS BC858B/ BC857B
CT 43091 830100385800 SMD TRANS BC858B/ BC857B
CT 43092 830100484800 SMD TRANS BC848B/ BC847B
CT 43093 830100484800 SMD TRANS BC848B/ BC847B
CT 43094 830100484800 SMD TRANS BC848B/ BC847B
CT 43095 830100484800 SMD TRANS BC848B/ BC847B
CT 46005 830100484800 SMD TRANS BC848B/ BC847B
CT 58012 830100484800 SMD TRANS BC848B/ BC847B
CT 61301 830100484800 SMD TRANS BC848B/ BC847B
CT 61316 830100484800 SMD TRANS BC848B/ BC847B
CT 70505 830100484800 SMD TRANS BC848B/ BC847B
CT 80002 830100685800 SMD TRANS BC858C/ BC857C
CT 80085 830100385800 SMD TRANS BC858B/ BC857B
CT 81001 830100484800 SMD TRANS BC848B/ BC847B
CT 81004 830100484800 SMD TRANS BC848B/ BC847B
D 21212 830921502000 DIODE 1 N 4004
D 32356 830921502000 DIODE 1 N 4004
D 32357 830921502000 DIODE 1 N 4004
D 40006
S 830921502000 DIODE 1 N 4004
D 50013 830951628300 DIODE BYV 28-200 RA
D 52006 830921502000 DIODE 1 N 4004
D 53008 830920100500 DIODE BA157
D 53019 830970900300 Z DIODE ZY 51
D 53071 830920435900 DIODE BY359 1500
D 53072 830920423000 DIODE BY 229-600
D 54001 830920100500 DIODE BA157
D 55012 830972033300 Z DIODE 33 C 0,5W
D 60006 830982088000 DIODE MUR 880 WW.BYT 08 P
D 60012 830951675400 DIODE BYT53B
D 60014 830920002100 DIODE BAV21
D 60023 830856052000 GLR.B 380 C 3700/2200
D 60216 830920002100 DIODE BAV21
D 60217 830920115900 DIODE BA159
S 830966318000 Z-DIODE BZT03D180
D 60218
D 61001 830951675400 DIODE BYT53B
D 61011 830951603800 DIODE BYV38
D 61012 830951603800 DIODE BYV38
D 61016 830982088000 DIODE MUR 880 WW.BYT 08 P
D 61021
S 830951717200 DIODE BYW172D
D 61026 830982084000 DIODE MUR 840/BYV 29-400
D 61033 830921502000 DIODE 1 N 4004
D 61036 830982084000 DIODE MUR 840/BYV 29-400
D 61061
S 830951717200 DIODE BYW172D
D 61066 S 830951717200 DIODE BYW172D
D 70508 830972011600 Z-DIODE 15 C 0,5W
IC 32300 830579541000 SMD IC MSP3410B-PS
IC 32310 830520570000 IC 78M05 2%
IC 34510 830533478000 IC TDA4780V3/V4
IC 40020 830533726100 IC TDA7262
IC 41010 830533300600 IC TDA3006
IC 43080 830536642500 IC TEA6425
IC 50010 830534417300 IC TDA4173AF
IC 55010 830533814500 IC TDA8145
IC 58010 830520439300 IC LM393P
IC 60010 830535460500 IC TDA4605/3
IC 60220 830536150100 IC TEA1501 N1
IC 61001 830520431700 IC LM317T
IC 61006 830520431700 IC LM317T
IC 61030 830520431700 IC LM317T
IC 61040 830520435000 IC LM350T
IC 61310 830520435700 IC LM358N
IC 80040 830521006500 IC MC33164P-5RP/
IC 80050 830515855000 SMD IC SDA5250D12
IC 80060 197983183500 IC 27C040-150NS PROG.KPL
IC 80065 830512400800 IC M24C08B1/ M24C08-BN6
IC 80070 830560241000 IC ST24W02CB1/ M24C02-BN6
IC 80090 830520439300 IC LM393P
L 32342 814052324900 DR ST 0411-GRP 10UH 10%
L 34517 814052636100 DR 0411 10UH 5%
L 46021 814052290300 DR ST 0411 1,5UH 2%
L 53001 810498205600 FERRITPERLE HF70 BTL 3,5X6
L 53002 810498205600 FERRITPERLE HF70 BTL 3,5X6
L 53003 810498205600 FERRITPERLE HF70 BTL 3,5X6
L 53011 814050524900 DR A AX-GA 10UH 10%
L 53012 092401140400 DROSSEL 1,5 MH/COIL 1.5 MH
L 53021 292031229700 LINEARITAETSREGLER (70CM)
L 53074 092468595500 BRUECKENSPULE M.KERN
L 55014 092458160100 O/W AUSKOPPELSPULE
L 60006 297017390800 DAEMPFUNGSPERLE
L 61011 810498201400 DAEMPF-PERLE 433003038102
L 61016 810498201400 DAEMPF-PERLE 433003038102
L 61021 810498201400 DAEMPF-PERLE 433003038102
L 61026 810498201400 DAEMPF-PERLE 433003038102
L 61036 810498201400 DAEMPF-PERLE 433003038102
L 61061 810498201400 DAEMPF-PERLE 433003038102
L 61062 814050506500 DR A AX-GA 47UH 5%
L 61066 810498201400 DAEMPF-PERLE 433003038102
L 61067 814050506500 DR A AX-GA 47UH 5%
L 70508 092410359700 STABKERNDROSSEL
L 70555 814052636100 DR 0411 10UH 5%
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
FERRITE BEAD
LINEARITY CONTROL
BRIDGE COIL W.CORE
E/W DECOUPLING COIL
DAMPING BEAD
DAMPING BEAD
BAR CORE CHOKE COIL
OK 60031S 830600001200 OPTOKOPPLER CNY17F1
OK 60046S 830600001200 OPTOKOPPLER CNY17F1
Q 32305 838243918500 QUARZ 18,432 MHZ
Q 80055 860233115500 KERRES #155 18MHZ
R 21101
S 870532102000 MOW 0411 6,2 OHM 5%
R 32315 S 870537009900 MOW 0922 12 KOHM 5% LI
R 32357 S 870112102700 KSW SI B 12 OHM 5% LI
R 32359
S 870032904700 KSW NB 0207 82 OHM 5% LI
R 40013 S 870532907300 MOW 0411 1 KOHM 5% LI
R 40017
S 870032900700 KSW NB 0207 1,8 OHM 5% LI
R 40027 S 870032900700 KSW NB 0207 1,8 OHM 5% LI
R 40031 S 870032903100 KSW NB 0207 18 OHM 5% LI
R 41016
S 870032902700 KSW NB 0207 12 OHM 5% LI
R 43004 S 870112101300 KSW SI B 3,3 OHM 5% LI
R 43098 S 870112101300 KSW SI B 3,3 OHM 5% LI
R 50007
S 876632740500 MSW 0207 1,5 OHM 1%
R 50008 S 876632740500 MSW 0207 1,5 OHM 1%
R 50027 S 870012120500 KSW 0207 1,5 OHM 5% LI
R 50029
S 876635705900 MSW 0414 270 OHM 5%
R 52001 S 870532122300 MOW 0411 8,2 OHM 5%
R 52003
S 873506403900 DRW 4 39 OHM 5%
R 52006 S 870536100700 MOW 0617 1,8 OHM 5% LI
R 53002 S 870012120500 KSW 0207 1,5 OHM 5% LI
R 53003
S 870012120500 KSW 0207 1,5 OHM 5% LI
R 53008 S 870032909700 KSW NB 0207 10 KOHM 5% LI
R 53011 870522702100 MOW 0411 6,8 OHM 5%
R 53016
S 873028002100 DRW SI S11 7W 6,8 OHM 5%
R 53021 S 870536925700 MOW 0617 220 OHM 10% LI
R 54001
S 873500303300 DRW 0,75W 0,33 OHM 10%
R 55012 S 870536906500 MOW 0617 470 OHM 5% LI
R 55014 S 870123081700 NKS 3 4,7 OHM 5%
R 58001 876509830400 MSW 0207 20 KOHM 2%
R 60001 870006913100 KSW 0617 270 KOHM
R 60002 870006914100 KSW 0617 680 KOHM
R 60008 873017930100 DRW 7 15 KOHM 10% ST
R 60012 870004904100 KSW 0411 47 OHM 5%
R 60016
S 870537004300 MOW 0922 56 OHM 5% LI
R 60028 876504412700 MSW 0414 180 KOHM 5%
R 60029
S 870536911300 MOW 0617 47 KOHM 5% LI
R 60212 S 876504915300 MSW SI 0414 2,2 MOHM
R 61001 879005001700 ESTR.SK10-A 220 OHM LIN
R 61018 870522132100 MOW 0411 100 KOHM 5%
R 61022
S 873229601100 DRW 6,5 2,7 OHM 10%
R 61031 879005002500 ESTR.SK10-A 470 OHM LIN
R 61033
S 870537005800 MOW 0922 100 OHM 10% LI
R 61041 879005001700 ESTR.SK10-A 220 OHM LIN
R 61313 879005005400 ESTR.SK10-A 22 KOHM LIN
R 62049
S 876634915500 MSW SI 0414 2,7 MOHM 5% LI
SI 60001
S 831562006800 SI LOET T2A 250V
SI 60201 S 831560702600 SI LOET T100MA 250V
SI 61022 S 831561902800 SI LOET T1,6A 250V
SI 61026
S 831562102700 SI LOET T2,5A 250V
SI 61036 S 831562102700 SI LOET T2,5A 250V
SI 61061 S 831562022500 SI LOET T2A 250V
SI 61066
S 831562022500 SI LOET T2A 250V
T 21211 830340129900 TRANS.BF299 G
T 40010 830328736800 TRANS.BC 368
T 50028 830221054400 TRANS BD544B
T 50029 830221054300 TRANS BD543B
T 52003 830221804300 TRANS.BDX 43
T 53001 830262533100 TRANS 2SC5331
T 60006 830280505000 TRANS IRFPC50
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 720108000000, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
TR 52001 092458129600 TREIBERUEBERTRAGER
S 292210330100 TRAFO DIODEN-SPLIT
TR 53010
TR 60001
S 292015669700 TRAFO SPERRWANDLER
TR 60220S 292016199700 SPERRWANDLERTRAFO KPL
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
DRIVER TRANSFORMER
DIODE SPLIT TRANSFORMER
REVERSE CONVERTER
TRANSFORMER
REVERSE CONVERTER
TRANSFORMER
Page 39
GRUNDIG Service 53
Ķ
Ersatzteilliste
Spare Parts List
11 / 2000
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
297040152000 CHASSIS-FS-STEREO CHASSIS TV STEREO
0100.000 295041023600 X BAUSTEIN SIGNAL / ZF+TUNER MODULE SIGNAL / IF+TUNER
0247.000 293031196600 EURO-AV BUCHSENLEISTE 21-POL SW EURO-AV SOCKET STRIP 21 P BLACK
0247.000 293031196800 EURO-AV BUCHSENLEISTE 21-POL OR EURO-AV SOCKET STRIP 21 P ORANGE
0400.000 295042090500 X FEATURE-BOX BASIC ++/BASIC 3 FEATURE-BOX BASIC ++/BASIC 3
WW. 295042091500 X FEATURE-BOX BASIC 3 FEATURE-BOX BASIC 3
0401.000 297006320201 HALTER BAUSTEIN HOLDER MODULE
0405.000 293040508500 NETZTEIL STAND BY POWER SUPPLY STAND BY
0406.000 297006131104 NETZTEILAUFNAHME HOLDER POWER SUPPLY
2200.000
S 293033995100 NETZ EINBAUGERAETESTECKER APPLIANCE COUPLER W.CABLE
2310.000
S 293033892101 VORSCHALTDROSSEL KPL LOETBAR SERIES REACTOR CPL SOLDERING
2310.000 S 293033892102 VORSCHALTDROSSEL KPL STECKBAR SERIES REACTOR CPL INSERT
2400.000 293031530100 MONTAGECLIP T60006 MOUNTING CLIP T60006
2410.000 293031530107 MONTAGECLIP T53001 MOUNTING CLIP T53001
2420.000 293031530200 MONTAGECLIP IC40020 MOUNTING CLIP IC40020
2430.000 293031531200 MONTAGECLIP D60006 MOUNTING CLIP D60006
2440.000 293031531208 12 MONTAGECLIP MOUNTING CLIP
2445.000 293031531605 MONTAGECLIP T52003 MOUNTING CLIP T52003
2450.000 293031561800 2 FOLIE WAERMELEITEND D60006/T60006 FOIL HEAT CONDUCTING D60006/T60006
2460.000 293031562000 10 FOLIE WAERMELEITEND D61026/61036/ FOIL HEAT CONDUCTING D61026/61036/
2470.000 293031562100 2 FOLIE WAERMELEITEND D53071/53072 FOIL HEAT CONDUCTING D53071/53072
2480.000 293031562301 FOLIE WAERMELEITEND T53001 FOIL HEAT CONDUCTING T53001
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 40013 845299619000 ELKO 2200UF 20% 35V
C 40031 845299614700 ELKO 1000UF 20% 25V
C 40032 845299614700 ELKO 1000UF 20% 25V
C 40033 845299614700 ELKO 1000UF 20% 25V
C 50012 845299614700 ELKO 1000UF 20% 25V
C 50026 845299614700 ELKO 1000UF 20% 25V
C 53012 851591160200 FOKO FKP1 142PF 2,5% 2000V
C 53071 851591170300 FOKO FKP1 0,013UF 3,5% 2000V
C 60001 865008112500 KERKO HV C 1000PF 20% 1KV
C 60006 865006704600 KERKO HV C 100PF 20% 1KV
C 60009 851591104000 FOKO FKP1 220PF 10% 1600V
C 60012 865008111100 KERKO HV C 270PF 20% 2KV
C 60023 865008112500 KERKO HV C 1000PF 20% 1KV
C 60024 865008112500 KERKO HV C 1000PF 20% 1KV
C 60026 865008112500 KERKO HV C 1000PF 20% 1KV
C 60027 865008112500 KERKO HV C 1000PF 20% 1KV
C 60028 844330605900 ELKO 15 300/330UF 385V
CHASSIS-FS-STEREO CUC 1836 BASIC ++/INL 4:3
CHASSIS TV STEREO CUC 1836 BASIC ++/INL 4:3
MATERIAL-NR. / PART NO.: 297040152000
d©
CUC 1836 BASIC ++/INL 4:3 CUC 1836 BASIC ++/INL 4:3
KEIN E-TEIL NO SPARE PART
D53071/53072/61016/61026/61036/ D53071/53072/61016/61026/61036/
IC50010/61001/6106/61030/61040/ IC50010/61001/6106/61030/61040/
T50028/50029 T50028/50029
IC50010/61001/61006/61030/61040/ IC50010/61001/61006/61030/61040/
T50028/50029/52003 T50028/50029/52003
WW.=WAHLWEISE WW.=OPTIONAL
X=SIEHE GESONDERTE E-LISTE X=SEE SEPARATE PARTS LIST
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
WW. 845199712400 ELKO #6 300UF +50-20% 385V
C 61004 845299614700 ELKO 1000UF 20% 25V
C 61016 851591103800 FOKO FKP1 100PF 10% 1600V
C 61021 865006704600 KERKO HV C 100PF 20% 1KV
C 61026 865006704600 KERKO HV C 100PF 20% 1KV
C 61032 845299614700 ELKO 1000UF 20% 25V
C 61036 865006704600 KERKO HV C 100PF 20% 1KV
C 61037 845209705700 ELKO 28 1000UF 63V
C 61042 845299610700 ELKO 2200UF 20% 16V
C 61061 865006704600 KERKO HV C 100PF 20% 1KV
C 61066 865006704600 KERKO HV C 100PF 20% 1KV
C 62048
S 866009823400 KERKO SI 1000PF 20% 400V
C 70509 845299614700 ELKO 1000UF 20% 25V
CD 21201 830953414900 MELF-DIODE LL 4148
CD 21202 830953414900 MELF-DIODE LL 4148
CD 21203 830953414900 MELF-DIODE LL 4148
TV
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
CD 21206 832531310300 MELF DIODE BAV103
CD 32315 830945533100 MELF Z-DIODE 33B 0,5W
CD 34513 830953414900 MELF-DIODE LL 4148
CD 34517 830953414900 MELF-DIODE LL 4148
CD 40008 830945510100 MELF-Z DIODE 10 B 0,5W
CD 40015 830953414900 MELF-DIODE LL 4148
CD 41011 830953414900 MELF-DIODE LL 4148
CD 43025 830953414900 MELF-DIODE LL 4148
CD 52003 830953414900 MELF-DIODE LL 4148
CD 53019 830953414900 MELF-DIODE LL 4148
CD 55003 830945504000 MELF-Z DIODE 3,9 B 0,5W
CD 55004 830953414900 MELF-DIODE LL 4148
CD 58001 830953414900 MELF-DIODE LL 4148
CD 58004 830953414900 MELF-DIODE LL 4148
CD 58007 830945502800 MELF Z-DIODE 2,7 B 0,5W
CD 58011 830953414900 MELF-DIODE LL 4148
CD 58012 830953414900 MELF-DIODE LL 4148
CD 58021 830953414900 MELF-DIODE LL 4148
CD 58022 830953414900 MELF-DIODE LL 4148
CD 70501 830945505200 MELF-Z DIODE 5,1 B 0,5W
CD 70506 830953414900 MELF-DIODE LL 4148
CD 70507 830953414900 MELF-DIODE LL 4148
CD 70517 830953414900 MELF-DIODE LL 4148
CD 70553 830953414900 MELF-DIODE LL 4148
CD 80060 830953414900 MELF-DIODE LL 4148
CD 80081 830953414900 MELF-DIODE LL 4148
CD 80085 830953414900 MELF-DIODE LL 4148
CD 80091 830945503400 MELF Z-DIODE 3,3 B 0,5W
CD 81004 830953414900 MELF-DIODE LL 4148
CIC43010 830581455100 SMD IC MC14551BD/R2
CT 32308 830100385800 SMD TRANS BC858B/ BC857B
CT 32310 830100385800 SMD TRANS BC858B/ BC857B
CT 32312 830100385800 SMD TRANS BC858B/ BC857B
CT 32315 830100385800 SMD TRANS BC858B/ BC857B
CT 40010 830100484800 SMD TRANS BC848B/ BC847B
CT 43060 830100484800 SMD TRANS BC848B/ BC847B
CT 43088 830100484800 SMD TRANS BC848B/ BC847B
CT 43089 830100385800 SMD TRANS BC858B/ BC857B
CT 43091 830100385800 SMD TRANS BC858B/ BC857B
CT 43092 830100484800 SMD TRANS BC848B/ BC847B
CT 43093 830100484800 SMD TRANS BC848B/ BC847B
CT 43094 830100484800 SMD TRANS BC848B/ BC847B
CT 43095 830100484800 SMD TRANS BC848B/ BC847B
CT 46005 830100484800 SMD TRANS BC848B/ BC847B
CT 58012 830100484800 SMD TRANS BC848B/ BC847B
CT 61301 830100484800 SMD TRANS BC848B/ BC847B
CT 61316 830100484800 SMD TRANS BC848B/ BC847B
CT 70505 830100484800 SMD TRANS BC848B/ BC847B
CT 80002 830100685800 SMD TRANS BC858C/ BC857C
CT 80085 830100385800 SMD TRANS BC858B/ BC857B
CT 81001 830100484800 SMD TRANS BC848B/ BC847B
CT 81004 830100484800 SMD TRANS BC848B/ BC847B
D 21212 830921502000 DIODE 1 N 4004
D 32356 830921502000 DIODE 1 N 4004
D 32357 830921502000 DIODE 1 N 4004
D 40006
S 830921502000 DIODE 1 N 4004
D 50013 830951628300 DIODE BYV 28-200
D 52006 830921502000 DIODE 1 N 4004
D 53008 830920100500 DIODE BA157
D 53019 830970900300 Z DIODE ZY 51
D 53071 830920435900 DIODE BY359 1500
D 53072 830920423000 DIODE BY 229-600
D 54001 830920100500 DIODE BA157
D 55012 830972033300 Z DIODE 33 C 0,5W
D 60006 830982088000 DIODE MUR 880 WW.BYT 08 P
D 60012 830951675400 DIODE BYT53B
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
D 60014 830920002100 DIODE BAV21
D 60023 830856052100 GLR B380C3700/2200
D 60216 830920002100 DIODE BAV21
D 60217 830920115900 DIODE BA159
S 830966318000 Z-DIODE BZT03D180
D 60218
D 61001 830951675400 DIODE BYT53B
D 61011 830951603800 DIODE BYV38
D 61012 830951603800 DIODE BYV38
D 61016 830982088000 DIODE MUR 880 WW.BYT 08 P
D 61021
S 830951717200 DIODE BYW172D
D 61026 830982084000 DIODE MUR 840/BYV 29-400
D 61033 830921502000 DIODE 1 N 4004
D 61036 830982084000 DIODE MUR 840/BYV 29-400
D 61061
S 830951717200 DIODE BYW172D
D 61066 S 830951717200 DIODE BYW172D
D 70508 830972011600 Z-DIODE 15 C 0,5W
IC 32300 830579540000 SMD IC MSP3400C-PS-C8
IC 32310 830520570000 IC 78M05 2%
IC 34510 830533478000 IC TDA4780V3/ V4
IC 40020 830533726100 IC TDA7262
IC 41010 830533300600 IC TDA3006
IC 43080 830536642500 IC TEA6425
IC 50010 830534417300 IC TDA4173AF
IC 55010 830533814500 IC TDA8145
IC 58010 830520439300 IC LM393P
IC 60010 830535460500 IC TDA4605/3
IC 60220 830536150100 IC TEA1501 N1
IC 61001 830520431700 IC LM317T
IC 61006 830520431700 IC LM317T
IC 61030 830520431700 IC LM317T
IC 61040 830520435000 IC LM350T
IC 61310 830520435700 IC LM358N
IC 80040 830521006500 IC MC33164P-5RP
IC 80050 830594525100 SMD IC SDA5250D49
IC 80060 197983270200 IC 27C040-150NS PROG.KPL
IC 80065 830512400800 IC M24C08B1/ M24C08-BN6
IC 80070 830560241000 IC ST24W02CB1/ M24C02-BN6
IC 80090 830520439300 IC LM393P
L 32342 814052324900 DR ST 0411-GRP 10UH 10%
L 34517 814052636100 DR 0411 10UH 5%
L 46021 814052290300 DR ST 0411 1,5UH 2%
L 53001 810498205600 FERRITPERLE HF70 BTL 3,5X6
L 53002 810498205600 FERRITPERLE HF70 BTL 3,5X6
L 53003 810498205600 FERRITPERLE HF70 BTL 3,5X6
L 53011 814050524900 DR A AX-GA 10UH 10%
L 53012 092401140400 DROSSEL 1,5 MH/COIL 1.5 MH
L 53021 292031229700 LINEARITAETSREGLER (70CM)
L 53074 092468596400 SPULE BRUECKE M.KERN
L 55014 092458160100 O/W AUSKOPPELSPULE
L 60006 297017390800 DAEMPFUNGSPERLE
L 61011 810498201400 DAEMPF-PERLE 433003038102
L 61016 810498201400 DAEMPF-PERLE 433003038102
L 61021 810498201400 DAEMPF-PERLE 433003038102
L 61026 810498201400 DAEMPF-PERLE 433003038102
L 61036 810498201400 DAEMPF-PERLE 433003038102
L 61061 810498201400 DAEMPF-PERLE 433003038102
L 61062 814050506500 DR A AX-GA 47UH 5%
L 61066 810498201400 DAEMPF-PERLE 433003038102
L 61067 814050506500 DR A AX-GA 47UH 5%
L 70508 092410359700 STABKERNDROSSEL
L 70555 814052636100 DR 0411 10UH 5%
FERRITE BEAD
LINEARITY CONTROL
BRIDGE COIL W.CORE
E/W DECOUPLING COIL
DAMPING BEAD
DAMPING BEAD
BAR CORE CHOKE COIL
CUC 1830 / 1836 / 1929 Ersatzteillisten / Spare Parts Lists
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Page 40
54 GRUNDIG Service
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
OK 60031 S830600001200 OPTOKOPPLER CNY17F1
OK 60046 S830600001200 OPTOKOPPLER CNY17F1
Q 32305 838243918600 QUARZ #439-9 18,432MHZ 12PF
Q 80055 860233115500 KERRES #155 18MHZ
R 21101
R 32315 S 870537009900 MOW 0922 12 KOHM 5% LI
R 32357 S 870112102700 KSW SI B 12 OHM 5% LI
R 32359
R 40013 S 870532907300 MOW 0411 1 KOHM 5% LI
R 40017
R 40027 S 870032900700 KSW NB 0207 1,8 OHM 5% LI
R 40031 S 870032903100 KSW NB 0207 18 OHM 5% LI
R 41016
R 43004 S 870112101300 KSW SI B 3,3 OHM 5% LI
R 43098 S 870112101300 KSW SI B 3,3 OHM 5% LI
R 50007
R 50008 S 876632740500 MSW 0207 1,5 OHM 1%
R 50027 S 870012120500 KSW 0207 1,5 OHM 5% LI
R 50029
R 52001 S 870532122300 MOW 0411 8,2 OHM 5%
R 52003
R 52006 S 870536900300 MOW 0617 1,2 OHM 5% LI
R 53002 S 870012120500 KSW 0207 1,5 OHM 5% LI
R 53003
R 53008 S 870032909700 KSW NB 0207 10 KOHM 5% LI
R 53011 870522702100 MOW 0411 6,8 OHM 5%
R 53016
R 53021 S 870536906300 MOW 0617 390 OHM 5% LI
R 54001
R 55012 S 870536906500 MOW 0617 470 OHM 5% LI
R 55014 S 870123081700 NKS 3 4,7 OHM 5%
R 58001 876509830400 MSW 0207 20 KOHM 2%
R 58002 876519808600 MSW 0207 3,6 KOHM 1%
R 60001 870006913100 KSW 0617 270 KOHM
R 60002 870006914100 KSW 0617 680 KOHM
R 60008 873017930100 DRW 7 15 KOHM 10% ST
R 60012 870004904100 KSW 0411 47 OHM 5%
R 60016
R 60028 876504412700 MSW 0414 180 KOHM 5%
R 60029
R 60212
R 61001 879005001700 ESTR.SK10-A 220 OHM LIN
R 61018 870522132100 MOW 0411 100 KOHM 5%
R 61022
R 61031 879005002500 ESTR.SK10-A 470 OHM LIN
R 61033 S 870537005800 MOW 0922 100 OHM 10% LI
R 61041 879005001700 ESTR.SK10-A 220 OHM LIN
R 61313 879005005400 ESTR.SK10-A 22 KOHM LIN
R 62049
SI 60001
SI 60201 S 831560702600 SI LOET T100MA 250V
SI 61022
SI 61026 S 831562102700 SI LOET T2,5A 250V
SI 61036 S 831562102700 SI LOET T2,5A 250V
SI 61061
SI 61066 S 831562022500 SI LOET T2A 250V
T 21211 830340129900 TRANS.BF299 G
T 40010 830328736800 TRANS.BC 368
T 50028 830221054400 TRANS BD544B/ BD538
T 50029 830221054300 TRANS BD543B/ BD537
T 52003 830221804300 TRANS.BDX 43
T 53001 830262533100 TRANS 2SC5331
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 720108000000, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
S 870532122100 MOW 0411 6,8 OHM 5%
S 870032904700 KSW NB 0207 82 OHM 5% LI
S 870032900700 KSW NB 0207 1,8 OHM 5% LI
S 870032902700 KSW NB 0207 12 OHM 5% LI
S 876632740500 MSW 0207 1,5 OHM 1%
S 876635705900 MSW 0414 270 OHM 5%
S 873506403900 DRW 4 39 OHM 5%
S 870012120500 KSW 0207 1,5 OHM 5% LI
S 873028002100 DRW SI S11 7W 6,8 OHM 5%
S 873500303300 DRW 0,75W 0,33 OHM 10%
S 870537004300 MOW 0922 56 OHM 5% LI
S 870536911300 MOW 0617 47 KOHM 5% LI
S 876504915300 MSW SI 0414 2,2 MOHM VDE
S 873229601100 DRW 6,5 2,7 OHM 10%
S 876634915500 MSW SI 0414 2,7 MOHM 5% LI
S 831562006800 SI LOET T2A 250V
S 831561902800 SI LOET T1,6A 250V
S 831562022500 SI LOET T2A 250V
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
T 60006 830280505000 TRANS IRFPC50
TR 52001 092468679700 UEBERTRAGER
S 292016800100 TRAFO DIODEN-SPLIT DIGI
TR 53010
TR 60001
S 292015699700 SPERRWANDLERTRAFO
TR 60220
S 292016199700 SPERRWANDLERTRAFO KPL
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
DRIVER TRANSFORMER
DIODE SPLIT TRANSFORMER
REVERSE CONVERTER
TRANSFORMER
REVERSE CONVERTER
TRANSFORMER
Ķ
Ersatzteilliste
Spare Parts List
10 / 2000
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
297040152100 CHASSIS-FS-STEREO CHASSIS TV STEREO
0100.000 295041623600 X BAUSTEIN SIGNAL/ZF+TUNER MODULE SIGNAL/IF+TUNER
0247.000 293031196600 EURO-AV BUCHSENLEISTE 21-POL SW EURO-AV SOCKET STRIP 21 PIN BLACK
0247.000 293031196800 EURO-AV BUCHSENLEISTE 21-POL OR EURO-AV SOCKET STRIP 21 PIN ORANGE
0400.000 295042091500 X FEATURE-BOX BASIC 3 FEATURE-BOX BASIC 3
WW. 295042090500 X FEATURE-BOX BASIC++/BASIC 3 FEATURE-BOX BASIC++/BASIC 3
0400.000
S 293040508500 NETZTEIL STAND BY POWER SUPPLY STAND BY
0450.000 297006320201 HALTER BAUSTEIN HOLDER MODULE
0450.000 297006131104 NETZTEILAUFNAHME HOLDER POWER SUPPLY
2200.000
S 293033995100 NETZ EINBAUGERAETESTECKER APPLIANCE COUPLER
2310.000 S 293033892101 VORSCHALTDROSSEL MONTIERT KPL SERIES REACTOR MOUNTED CPL
2310.000
S 759880730000 VORSCHALTDROSSEL MONTIERT KPL SERIES REACTOR MOUNTED CPL
2400.000 293031530100 MONTAGECLIP T60006 MOUNTING CLIP T60006
2405.000 293031530107 MONTAGECLIP T53001 MOUNTING CLIP T53001
2410.000 293031530200 MONTAGECLIP IC40020 MOUNTING CLIP IC40020
2430.000 293031531200 2 MONTAGECLIP D60006/61016 MOUNTING CLIP D60006/61016
2435.000 293031531208 11 MONTAGECLIP D53071/53072/61026/61036/ MOUNTING CLIP D53071/53072/61026/
61036/
2440.000 293031531605 MONTAGECLIP T52003 MOUNTING CLIP T52003
2460.000 293031561800 3 FOLIE WAERMELEITEND T60006/D60006/ FOIL HEAT CONDUCTING T60006/D60006/
2470.000 293031562000 9 FOLIE WAERMELEITEND D61026/61036/ FOIL HEAT CONDUCTING D61026/61036/
2480.000 293031562100 2 FOLIE WAERMELEITEND D53071/53072 FOIL HEAT CONDUCTING D53071/53072
2490.000 293031562301 FOLIE WAERMELEITEND T53001 FOIL HEAT CONDUCTING T53001
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 40013 845299619000 ELKO 2200UF 20% 35V
C 40031 845299614700 ELKO 1000UF 20% 25V
C 40032 845299614700 ELKO 1000UF 20% 25V
C 40033 845299614700 ELKO 1000UF 20% 25V
C 50012 845299614700 ELKO 1000UF 20% 25V
C 50026 845299614700 ELKO 1000UF 20% 25V
C 53012 851591160200 FOKO FKP1 142PF 2,5% 2000V
C 53071 851591140900 FOKO FKP1 0,01UF 3,5% 2000V
C 60001 865008112500 KERKO HV C 1000PF 20% 1KV
C 60006 865006704600 KERKO HV C 100PF 20% 1KV
C 60009 851591104000 FOKO FKP1 220PF 10% 1600V
C 60012 865008111100 KERKO HV C 270PF 20% 2KV
C 60023 865008112500 KERKO HV C 1000PF 20% 1KV
C 60024 865008112500 KERKO HV C 1000PF 20% 1KV
CHASSIS-FS-STEREO CUC 1836 BASIC ++/INL 4:3
CHASSIS TV STEREO CUC 1836 BASIC ++/INL 4:3
MATERIAL-NR. / PART NO.: 297040152100
d©
CUC 1836 BASIC ++/INL 4:3 CUC 1836 BASIC ++/INL 4:3
KEIN E-TEIL NO SPARE PART
GELOETET SOLDERED
GESTECKT PLUGGED
IC50010/61001/61006/61030/61040/ IC50010/61001/61006/61030/61040/
T50028/50029 T50028/50029
61016 61016
IC61001/61006/61030/61040/ IC61001/61006/61030/61040/
T50028/50029/T52003 T50028/50029/T52003
X = SIEHE GESONDERTE E-LISTE X = SEE SEPARATE PARTS LIST
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 60026 865008112500 KERKO HV C 1000PF 20% 1KV
C 60027 865008112500 KERKO HV C 1000PF 20% 1KV
C 60028 844330605900 ELKO 15 300/330UF 385V
C 61004 845299614700 ELKO 1000UF 20% 25V
C 61016 851591103800 FOKO FKP1 100PF 10% 1600V
C 61021 865006704600 KERKO HV C 100PF 20% 1KV
C 61022 845202706000 ELKO #16/V 600/680UF 63V
C 61026 865006704600 KERKO HV C 100PF 20% 1KV
C 61032 845299614700 ELKO 1000UF 20% 25V
C 61036 865006704600 KERKO HV C 100PF 20% 1KV
C 61037 845209705700 ELKO 28 1000UF 63V
C 61042 845299610700 ELKO 2200UF 20% 16V
C 61061 865006704600 KERKO HV C 100PF 20% 1KV
C 61066 865006704600 KERKO HV C 100PF 20% 1KV
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
TV
Ersatzteillisten / Spare Parts Lists CUC 1830 / 1836 / 1929
Page 41
GRUNDIG Service 55
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 62021
S 866009823800 KERKO SI 2200PF 20% 400V
C 62022
S 866009823800 KERKO SI 2200PF 20% 400V
S 866009823400 KERKO SI 1000PF 20% 400V
C 62048
C 70509 845299614700 ELKO 1000UF 20% 25V
CD 21201 830953414900 MELF-DIODE LL 4148
CD 21202 830953414900 MELF-DIODE LL 4148
CD 21203 830953414900 MELF-DIODE LL 4148
CD 21206 832531310300 MELF DIODE BAV103
CD 32315 830945533100 MELF Z-DIODE 33B 0,5W
CD 34513 830953414900 MELF-DIODE LL 4148
CD 34517 830953414900 MELF-DIODE LL 4148
CD 40008 830945510100 MELF-Z DIODE 10 B 0,5W
CD 40015 830953414900 MELF-DIODE LL 4148
CD 41011 830953414900 MELF-DIODE LL 4148
CD 43025 830953414900 MELF-DIODE LL 4148
CD 52003 830953414900 MELF-DIODE LL 4148
CD 53019 830953414900 MELF-DIODE LL 4148
CD 55003 830945504400 MELF Z-DIODE 4,3 B 0,5W
CD 55004 830953414900 MELF-DIODE LL 4148
CD 58001 830953414900 MELF-DIODE LL 4148
CD 58004 830953414900 MELF-DIODE LL 4148
CD 58007 830945502800 MELF Z-DIODE 2,7 B 0,5W
CD 58011 830953414900 MELF-DIODE LL 4148
CD 58012 830953414900 MELF-DIODE LL 4148
CD 58021 830953414900 MELF-DIODE LL 4148
CD 58022 830953414900 MELF-DIODE LL 4148
CD 70501 830945505200 MELF-Z DIODE 5,1 B 0,5W
CD 70506 830953414900 MELF-DIODE LL 4148
CD 70507 830953414900 MELF-DIODE LL 4148
CD 70517 830953414900 MELF-DIODE LL 4148
CD 70553 830953414900 MELF-DIODE LL 4148
CD 80060 830953414900 MELF-DIODE LL 4148
CD 80081 830953414900 MELF-DIODE LL 4148
CD 80085 830953414900 MELF-DIODE LL 4148
CD 80091 830945503400 MELF Z-DIODE 3,3 B 0,5W
CD 81004 830953414900 MELF-DIODE LL 4148
CIC43010 830581455100 SMD IC MC14551BD/R2
CT 32308 830100385800 SMD TRANS BC858B/BC857B
CT 32310 830100385800 SMD TRANS BC858B/BC857B
CT 32312 830100385800 SMD TRANS BC858B/BC857B
CT 32315 830100385800 SMD TRANS BC858B/BC857B
CT 40010 830100484800 SMD TRANS BC848B/BC847B
CT 43060 830100484800 SMD TRANS BC848B/BC847B
CT 43088 830100484800 SMD TRANS BC848B/BC847B
CT 43089 830100385800 SMD TRANS BC858B/BC857B
CT 43091 830100385800 SMD TRANS BC858B/BC857B
CT 43092 830100484800 SMD TRANS BC848B/BC847B
CT 43093 830100484800 SMD TRANS BC848B/BC847B
CT 43094 830100484800 SMD TRANS BC848B/BC847B
CT 43095 830100484800 SMD TRANS BC848B/BC847B
CT 46005 830100484800 SMD TRANS BC848B/BC847B
CT 58012 830100484800 SMD TRANS BC848B/BC847B
CT 61301 830100484800 SMD TRANS BC848B/BC847B
CT 61316 830100484800 SMD TRANS BC848B/BC847B
CT 70505 830100484800 SMD TRANS BC848B/BC847B
CT 80002 830100685800 SMD TRANS BC858C/BC857C
CT 80085 830100385800 SMD TRANS BC858B/BC857B
CT 81001 830100484800 SMD TRANS BC848B/BC847B
CT 81004 830100484800 SMD TRANS BC848B/BC847B
D 21212 830921502000 DIODE 1N4004
D 32356 830921502000 DIODE 1N4004
D 32357 830921502000 DIODE 1N4004
D 40006
S 830921502000 DIODE 1N4004
D 50013 830951628300 DIODE BYV 28-200
D 52006 830921502000 DIODE 1N4004
D 53008 830920100500 DIODE BA157
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
D 53019 830970900300 Z DIODE ZY 51
D 53071 830920435900 DIODE BY359 1500
D 53072 830920423000 DIODE BY 229-600
D 54001 830920100500 DIODE BA157
D 55012 830972033300 Z DIODE 33 C 0,5W
D 60006 830982088000 DIODE MUR 880
D 60012 830951675400 DIODE BYT53B
D 60014 830920002100 DIODE BAV21
D 60023 830856052100 GLR B380C3700/2200
D 60216 830920002100 DIODE BAV21
D 60217 830920115900 DIODE BA159
S 830966318000 Z-DIODE BZT03D180
D 60218
D 61001 830951675400 DIODE BYT53B
D 61011 830951603800 DIODE BYV38
D 61012 830951603800 DIODE BYV38
D 61016 830982088000 DIODE MUR 880
D 61021
S 830951717200 DIODE BYW172D
D 61026 830982084000 DIODE MUR 840
D 61033 830921502000 DIODE 1N4004
D 61036 830982084000 DIODE MUR 840
D 61061
S 830951717200 DIODE BYW172D
D 61066
S 830951717200 DIODE BYW172D
D 70508 830972011600 Z-DIODE 15 C 0,5W
IC 32300 830579541000 SMD IC MSP3410B-PS PLCC
IC 32310 830520570000 IC 78M05 2%
IC 34510 830533478000 IC TDA4780V3/V4
IC 40020 830533726100 IC TDA7262
IC 41010 830533300600 IC TDA3006
IC 43080 830536642500 IC TEA6425
IC 50010 830534417300 IC TDA4173AF
IC 55010 830533814500 IC TDA8145
IC 58010 830520439300 IC LM393P
IC 60010 830535460500 IC TDA4605/3
IC 60220 830536150100 IC TEA1501N1
IC 61001 830520431700 IC LM317T
IC 61006 830520431700 IC LM317T
IC 61030 830520431700 IC LM317T
IC 61040 830520435000 IC LM350T
IC 61310 830520435700 IC LM358N
IC 80040 830521006500 IC MC33164P-5RP
IC 80050 830515855000 SMD IC SDA5250D12
IC 80060 197983260200 IC 27C040-150NS PROG.KPL
IC 80065 830512400800 IC M24C08B1
IC 80070 830560241000 IC ST24W02CB1
IC 80090 830520439300 IC LM393P
L 32342 814052324900 DR ST 0411-GRP 10UH 10%
L 34517 814052636100 DR 0411 10UH 5%
L 46021 814052290300 DR ST 0411 1,5UH 2%
L 53001 810498205600 FERRITPERLE HF70 BTL 3,5X
L 53002 810498205600 FERRITPERLE HF70 BTL 3,5X
L 53003 810498205600 FERRITPERLE HF70 BTL 3,5X
L 53011 814050524900 DR A AX-GA 10UH 10%
L 53012 092401140400 DROSSEL 1,5 MH
L 53021 292031229700 LINEARITAETSREGLER
L 53074 092468595500 BRUECKENSPULE M.KERN
L 55014 092458160100 O/W AUSKOPPELSPULE
L 60006 297017390800 DAEMPF-PERLE UV 930 30
L 61011 810498201400 DAEMPF-PERLE 433003038102
L 61016 810498201400 DAEMPF-PERLE 433003038102
L 61021 810498201400 DAEMPF-PERLE 433003038102
L 61026 810498201400 DAEMPF-PERLE 433003038102
L 61036 810498201400 DAEMPF-PERLE 433003038102
L 61061 810498201400 DAEMPF-PERLE 433003038102
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
FERRITE BEAD
LINEARITY CONTROL
BRIDGE COIL W.CORE
E/W COUPLING COIL
DAMPING BEAD
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
L 61062 814050506500 DR A AX-GA 47UH 5%
L 61066 810498201400 DAEMPF-PERLE 433003038102
L 61067 814050506500 DR A AX-GA 47UH 5%
L 70508 092410359700 STABKERNDROSSEL
L 70555 814052636100 DR 0411 10UH 5%
OK 60031
S 830600001200 OPTOKOPPLER CNY17F1
OK 60046
S 830600001200 OPTOKOPPLER CNY17F1
Q 32305 838243918500 QUARZ 18,432 MHZ
Q 80055 860233115500 KERRES #155 18MHZ
R 21101
S 870532102000 MOW 0411 6,2 OHM 5%
R 21212 870000754900 KSW 0207 1,5 MOHM 5%
R 32315 S 870537009900 MOW 0922 12 KOHM 5%
R 32357
S 870112102700 KSW SI B 12 OHM 5%
R 32359 S 870032904700 KSW NB 0207 82 OHM 5%
R 40013 S 870532907300 MOW 0411 1 KOHM 5%
R 40017
S 870032900700 KSW NB 0207 1,8 OHM 5%
R 40027 S 870032900700 KSW NB 0207 1,8 OHM 5%
R 40031
S 870032903100 KSW NB 0207 18 OHM 5%
R 41016 S 870032902700 KSW NB 0207 12 OHM 5%
R 43004 S 870112101300 KSW SI B 3,3 OHM 5%
R 43098 S 870112101300 KSW SI B 3,3 OHM 5%
R 50007
S 876632740500 MSW 0207 1,5 OHM 1%
R 50008 S 876632740500 MSW 0207 1,5 OHM 1%
R 50027
S 870012120500 KSW 0207 1,5 OHM 5%
R 50029 S 876635705900 MSW 0414 270 OHM 5%
R 52001 S 870532122300 MOW 0411 8,2 OHM 5%
R 52003
S 873506403900 DRW 4 39 OHM 5%
R 52006 S 870536900500 MOW 0617 1,5 OHM 5%
R 53002 S 870012120500 KSW 0207 1,5 OHM 5%
R 53003
S 870012120500 KSW 0207 1,5 OHM 5%
R 53008 S 870032909700 KSW NB 0207 10 KOHM 5%
R 53016 S 873028002100 DRW SI S11 7W 6,8 OHM 5%
R 53021
S 870536925700 MOW 0617 220 OHM 10%
R 54001 S 873500303300 DRW 0,75W 0,33 OHM 10%
R 55012 S 870536906500 MOW 0617 470 OHM 5%
R 55014
S 870123081700 NKS 3 4,7 OHM 5%
R 58001 876509830400 MSW 0207 20 KOHM 2%
R 60008 873017930100 DRW 7 15 KOHM 10%
R 60016
S 870537004300 MOW 0922 56 OHM 5%
R 60029 S 870536911300 MOW 0617 47 KOHM 5%
R 60212 S 876504915300 MSW SI 0414 2,2 MOHM VDE
R 61001 879005001700 ESTR.SK10-A 220 OHM LIN
R 61022
S 873229601100 DRW 6,5 2,7 OHM 10%
R 61031 879005002500 ESTR.SK10-A 470 OHM LIN
R 61033
S 870537005800 MOW 0922 100 OHM 10%
R 61041 879005001700 ESTR.SK10-A 220 OHM LIN
R 61313 879005005400 ESTR.SK10-A 22 KOHM LIN
R 62049
S 876634915500 MSW SI 0414 2,7 MOHM 5%
SI 60001
S 831562006800 SI LOET T2A 250V
SI 60201 S 831560702600 SI LOET T100MA 250V
SI 61022 S 831561902800 SI LOET T1,6A 250V
SI 61026
S 831562102700 SI LOET T2,5A 250V
SI 61036 S 831562102700 SI LOET T2,5A 250V
SI 61061 S 831562022500 SI LOET T2A 250V
SI 61066
S 831562022500 SI LOET T2A 250V
T 21211 830340129900 TRANS BF299G
T 40010 830328736800 TRANS BC368
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 72010 800 0000, sowie zusätzlich die eventuell
abweichenden, landesspezifischen Vorschriften!
DAMPING BEAD
BAR CORE COIL
OPTO COUPLER
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
T 50028 830221054400 TRANS BD544B
T 50029 830221054300 TRANS BD543B
T 52003 830221804300 TRANS BDX43
T 53001 830262533100 TRANS 2SC5331
T 60006 830280505000 TRANS IRFPC50
TR 52001 092458129600 TREIBERUEBERTRAGER
S 292210330100 TRAFO DIODEN-SPLIT
TR 53010
TR 60001
S 292015669700 TRAFO SPERRWANDLER
TR 60220
S 292016199700 SPERRWANDLERTRAFO
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 72010 800 0000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
TRANSFORMER DRIVER
TRANSFORMER DIODE SPLIT
B.O.TYPE CONVERTER
TRANSFORMER
293040508500
B.O.TYPE CONVERTER
TRANSFORMER
CUC 1830 / 1836 / 1929 Ersatzteillisten / Spare Parts Lists
Page 42
56 GRUNDIG Service
Ersatzteilliste
Spare Parts List
11 / 2000
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
0100.000 295041623600 X BAUSTEIN SIGNAL / ZF+TUNER MODULE SIGNAL / IF+TUNER
0247.000 293031196600 EURO-AV BUCHSENLEISTE 21-POL SW EURO-AV SOCKET STRIP 21 P BLACK
0247.000 293031196800 EURO-AV BUCHSENLEISTE 21-POL OR EURO-AV SOCKET STRIP 21 P ORANGE
0400.000 295042090500 X FEATURE-BOX BASIC ++/BASIC 3 FEATURE-BOX BASIC ++/BASIC 3
WW. 295042091500 X FEATURE-BOX BASIC 3 FEATURE-BOX BASIC 3
0401.000 297006320201 HALTER BAUSTEIN HOLDER MODULE
0405.000 293040508500 NETZTEIL STAND BY POWER SUPPLY STAND BY
0406.000 297006131104 NETZTEILAUFNAHME HOLDER POWER SUPPLY
2200.000
2310.000 S 293033892101 VORSCHALTDROSSEL KPL LOETBAR SERIES REACTOR CPL SOLDERING
2310.000
2400.000 293031530100 MONTAGECLIP T60006 MOUNTING CLIP T60006
2410.000 293031530107 MONTAGECLIP T53001 MOUNTING CLIP T53001
2420.000 293031530200 MONTAGECLIP IC40020 MOUNTING CLIP IC40020
2430.000 293031531200 MONTAGECLIP D60006 MOUNTING CLIP D60006
2440.000 293031531208 12 MONTAGECLIP MOUNTING CLIP
2445.000 293031531605 MONTAGECLIP T52003 MOUNTING CLIP T52003
2450.000 293031561800 2 FOLIE WAERMELEITEND D60006/T60006 FOIL HEAT CONDUCTING D60006/T60006
2460.000 293031562000 10 FOLIE WAERMELEITEND D61026/61036/ FOIL HEAT CONDUCTING D61026/61036/
2470.000 293031562100 2 FOLIE WAERMELEITEND D53071/53072 FOIL HEAT CONDUCTING D53071/53072
2480.000 293031562301 FOLIE WAERMELEITEND T53001 FOIL HEAT CONDUCTING T53001
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 40013 845299619000 ELKO 2200UF 20% 35V
C 40031 845299614700 ELKO 1000UF 20% 25V
C 40032 845299614700 ELKO 1000UF 20% 25V
C 40033 845299614700 ELKO 1000UF 20% 25V
C 50012 845299614700 ELKO 1000UF 20% 25V
C 50026 845299614700 ELKO 1000UF 20% 25V
C 53012 851591160200 FOKO FKP1 142PF 2,5% 2000V
C 53071 851591170300 FOKO FKP1 0,013UF 3,5% 2000V
C 60001 865008112500 KERKO HV C 1000PF 20% 1KV
C 60006 865006704600 KERKO HV C 100PF 20% 1KV
C 60009 851591104000 FOKO FKP1 220PF 10% 1600V
C 60012 865008111100 KERKO HV C 270PF 20% 2KV
C 60023 865008112500 KERKO HV C 1000PF 20% 1KV
C 60024 865008112500 KERKO HV C 1000PF 20% 1KV
C 60026 865008112500 KERKO HV C 1000PF 20% 1KV
C 60027 865008112500 KERKO HV C 1000PF 20% 1KV
C 60028 844330605900 ELKO 15 300/330UF 385V
Ķ
CHASSIS-FS-STEREO CUC 1836 BASIC ++/INL 4:3
CHASSIS-FS-STEREO CUC 1836 BASIC ++/INL 4:3
d©
297040152200 CHASSIS-FS-STEREO CHASSIS TV STEREO
S 293033995100 NETZ EINBAUGERAETESTECKER APPLIANCE COUPLER W.CABLE
S 293033892102 VORSCHALTDROSSEL KPL STECKBAR SERIES REACTOR CPL INSERT
CUC 1836 BASIC ++/INL 4:3 CUC 1836 BASIC ++/INL 4:3
KEIN E-TEIL NO SPARE PART
D53071/53072/61016/61026/61036/ D53071/53072/61016/61026/61036/
IC50010/61001/6106/61030/61040/ IC50010/61001/6106/61030/61040/
T50028/50029 T50028/50029
IC50010/61001/61006/61030/61040/ IC50010/61001/61006/61030/61040/
T50028/50029/52003 T50028/50029/52003
WW.=WAHLWEISE WW.=OPTIONAL
X=SIEHE GESONDERTE E-LISTE X=SEE SEPARATE PARTS LIST
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
WW. 845199712400 ELKO #6 300UF +50-20% 385V
C 61004 845299614700 ELKO 1000UF 20% 25V
C 61016 851591103800 FOKO FKP1 100PF 10% 1600V
C 61021 865006704600 KERKO HV C 100PF 20% 1KV
C 61026 865006704600 KERKO HV C 100PF 20% 1KV
C 61032 845299614700 ELKO 1000UF 20% 25V
C 61036 865006704600 KERKO HV C 100PF 20% 1KV
C 61037 845209705700 ELKO 28 1000UF 63V
C 61042 845299610700 ELKO 2200UF 20% 16V
C 61061 865006704600 KERKO HV C 100PF 20% 1KV
C 61066 865006704600 KERKO HV C 100PF 20% 1KV
C 62048
C 70509 845299614700 ELKO 1000UF 20% 25V
CD 21201 830953414900 MELF-DIODE LL 4148
CD 21202 830953414900 MELF-DIODE LL 4148
CD 21203 830953414900 MELF-DIODE LL 4148
MATERIAL-NR. / PART NO.: 297040152200
S 866009823400 KERKO SI 1000PF 20% 400V
TV
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
CD 21206 832531310300 MELF DIODE BAV103
CD 32315 830945533100 MELF Z-DIODE 33B 0,5W
CD 34513 830953414900 MELF-DIODE LL 4148
CD 34517 830953414900 MELF-DIODE LL 4148
CD 40008 830945510100 MELF-Z DIODE 10 B 0,5W
CD 40015 830953414900 MELF-DIODE LL 4148
CD 41011 830953414900 MELF-DIODE LL 4148
CD 43025 830953414900 MELF-DIODE LL 4148
CD 52003 830953414900 MELF-DIODE LL 4148
CD 53019 830953414900 MELF-DIODE LL 4148
CD 55003 830945504000 MELF-Z DIODE 3,9 B 0,5W
CD 55004 830953414900 MELF-DIODE LL 4148
CD 58001 830953414900 MELF-DIODE LL 4148
CD 58004 830953414900 MELF-DIODE LL 4148
CD 58007 830945502800 MELF Z-DIODE 2,7 B 0,5W
CD 58011 830953414900 MELF-DIODE LL 4148
CD 58012 830953414900 MELF-DIODE LL 4148
CD 58021 830953414900 MELF-DIODE LL 4148
CD 58022 830953414900 MELF-DIODE LL 4148
CD 70501 830945505200 MELF-Z DIODE 5,1 B 0,5W
CD 70506 830953414900 MELF-DIODE LL 4148
CD 70507 830953414900 MELF-DIODE LL 4148
CD 70517 830953414900 MELF-DIODE LL 4148
CD 70553 830953414900 MELF-DIODE LL 4148
CD 80060 830953414900 MELF-DIODE LL 4148
CD 80081 830953414900 MELF-DIODE LL 4148
CD 80085 830953414900 MELF-DIODE LL 4148
CD 80091 830945503400 MELF Z-DIODE 3,3 B 0,5W
CD 81004 830953414900 MELF-DIODE LL 4148
CIC43010 830581455100 SMD IC MC14551BD/R2
CT 32308 830100385800 SMD TRANS BC858B/ BC857B
CT 32310 830100385800 SMD TRANS BC858B/ BC857B
CT 32312 830100385800 SMD TRANS BC858B/ BC857B
CT 32315 830100385800 SMD TRANS BC858B/ BC857B
CT 40010 830100484800 SMD TRANS BC848B/ BC847B
CT 43060 830100484800 SMD TRANS BC848B/ BC847B
CT 43088 830100484800 SMD TRANS BC848B/ BC847B
CT 43089 830100385800 SMD TRANS BC858B/ BC857B
CT 43091 830100385800 SMD TRANS BC858B/ BC857B
CT 43092 830100484800 SMD TRANS BC848B/ BC847B
CT 43093 830100484800 SMD TRANS BC848B/ BC847B
CT 43094 830100484800 SMD TRANS BC848B/ BC847B
CT 43095 830100484800 SMD TRANS BC848B/ BC847B
CT 46005 830100484800 SMD TRANS BC848B/ BC847B
CT 58012 830100484800 SMD TRANS BC848B/ BC847B
CT 61301 830100484800 SMD TRANS BC848B/ BC847B
CT 61316 830100484800 SMD TRANS BC848B/ BC847B
CT 70505 830100484800 SMD TRANS BC848B/ BC847B
CT 80002 830100685800 SMD TRANS BC858C/ BC857C
CT 80085 830100385800 SMD TRANS BC858B/ BC857B
CT 81001 830100484800 SMD TRANS BC848B/ BC847B
CT 81004 830100484800 SMD TRANS BC848B/ BC847B
D 21212 830921502000 DIODE 1 N 4004
D 32356 830921502000 DIODE 1 N 4004
D 32357 830921502000 DIODE 1 N 4004
D 40006
S 830921502000 DIODE 1 N 4004
D 50013 830951628300 DIODE BYV 28-200 RA
D 52006 830921502000 DIODE 1 N 4004
D 53008 830920100500 DIODE BA157
D 53019 830970900300 Z DIODE ZY 51
D 53071 830920435900 DIODE BY359 1500
D 53072 830920423000 DIODE BY 229-600
D 54001 830920100500 DIODE BA157
D 55012 830972033300 Z DIODE 33 C 0,5W
D 60006 830982088000 DIODE MUR 880 WW.BYT 08 P
D 60012 830951675400 DIODE BYT53B
D 60014 830920002100 DIODE BAV21
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
D 60023 830856052100 GLR B380C3700/2200
D 60216 830920002100 DIODE BAV21
D 60217 830920115900 DIODE BA159
S 830966318000 Z-DIODE BZT03D180
D 60218
D 61001 830951675400 DIODE BYT53B
D 61011 830951603800 DIODE BYV38
D 61012 830951603800 DIODE BYV38
D 61016 830982088000 DIODE MUR 880 WW.BYT 08 P
D 61021
S 830951717200 DIODE BYW172D
D 61026 830982084000 DIODE MUR 840/BYV 29-400
D 61033 830921502000 DIODE 1 N 4004
D 61036 830982084000 DIODE MUR 840/BYV 29-400
D 61061
S 830951717200 DIODE BYW172D
D 61066 S 830951717200 DIODE BYW172D
D 70508 830972011600 Z-DIODE 15 C 0,5W
IC 32300 830579541000 SMD IC MSP3410B-PS
IC 32310 830520570000 IC 78M05 2%
IC 34510 830533478000 IC TDA4780V3/ V4
IC 40020 830533726100 IC TDA7262
IC 41010 830533300600 IC TDA3006
IC 43080 830536642500 IC TEA6425
IC 50010 830534417300 IC TDA4173AF
IC 55010 830533814500 IC TDA8145
IC 58010 830520439300 IC LM393P
IC 60010 830535460500 IC TDA4605/3
IC 60220 830536150100 IC TEA1501 N1
IC 61001 830520431700 IC LM317T
IC 61006 830520431700 IC LM317T
IC 61030 830520431700 IC LM317T
IC 61040 830520435000 IC LM350T
IC 61310 830520435700 IC LM358N
IC 80040 830521006500 IC MC33164P-5RP
IC 80050 830515855000 SMD IC SDA5250D12
IC 80060 197983260200 IC 27C040-150NS PROG.KPL
IC 80065 830512400800 IC M24C08B1/ M24C08-BN6
IC 80070 830560241000 IC ST24W02CB1/ M24C02-BN6
IC 80090 830520439300 IC LM393P
L 32342 814052324900 DR ST 0411-GRP 10UH 10%
L 34517 814052636100 DR 0411 10UH 5%
L 46021 814052290300 DR ST 0411 1,5UH 2%
L 53001 810498205600 FERRITPERLE HF70 BTL 3,5X6
L 53002 810498205600 FERRITPERLE HF70 BTL 3,5X6
L 53003 810498205600 FERRITPERLE HF70 BTL 3,5X6
L 53011 814050524900 DR A AX-GA 10UH 10%
L 53012 092401140400 DROSSEL 1,5 MH/COIL 1.5 MH
L 53021 292031229700 LINEARITAETSREGLER (70CM)
L 53074 092468596100 BRUECKENSPULE M.KERN
L 55014 092458160100 O/W AUSKOPPELSPULE
L 60006 297017390800 DAEMPFUNGSPERLE
L 61011 810498201400 DAEMPF-PERLE 433003038102
L 61016 810498201400 DAEMPF-PERLE 433003038102
L 61021 810498201400 DAEMPF-PERLE 433003038102
L 61026 810498201400 DAEMPF-PERLE 433003038102
L 61036 810498201400 DAEMPF-PERLE 433003038102
L 61061 810498201400 DAEMPF-PERLE 433003038102
L 61062 814050506500 DR A AX-GA 47UH 5%
L 61066 810498201400 DAEMPF-PERLE 433003038102
L 61067 814050506500 DR A AX-GA 47UH 5%
L 70508 092410359700 STABKERNDROSSEL
L 70555 814052636100 DR 0411 10UH 5%
FERRITE BEAD
LINEARITY CONTROL
BRIDGE COIL W.CORE
E/W DECOUPLING COIL
DAMPING BEAD
DAMPING BEAD
BAR CORE CHOKE COIL
Ersatzteillisten / Spare Parts Lists CUC 1830 / 1836 / 1929
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Page 43
GRUNDIG Service 57
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
OK 60031S 830600001200 OPTOKOPPLER CNY17F1
OK 60046
S 830600001200 OPTOKOPPLER CNY17F1
Q 32305 838243918500 QUARZ 18,432 MHZ
Q 80055 860233115500 KERRES #155 18MHZ
R 21101
S 870532102000 MOW 0411 6,2 OHM 5%
R 32315
S 870537009900 MOW 0922 12 KOHM 5% LI
R 32357 S 870112102700 KSW SI B 12 OHM 5% LI
R 32359
S 870032904700 KSW NB 0207 82 OHM 5% LI
R 40013 S 870532907300 MOW 0411 1 KOHM 5% LI
R 40017 S 870032900700 KSW NB 0207 1,8 OHM 5% LI
R 40027 S 870032900700 KSW NB 0207 1,8 OHM 5% LI
R 40031
S 870032903100 KSW NB 0207 18 OHM 5% LI
R 41016 S 870032902700 KSW NB 0207 12 OHM 5% LI
R 43004
S 870112101300 KSW SI B 3,3 OHM 5% LI
R 43098 S 870112101300 KSW SI B 3,3 OHM 5% LI
R 50007 S 876632740500 MSW 0207 1,5 OHM 1%
R 50008
S 876632740500 MSW 0207 1,5 OHM 1%
R 50027 S 870012120500 KSW 0207 1,5 OHM 5% LI
R 50029 S 876635705900 MSW 0414 270 OHM 5%
R 52001
S 870532122300 MOW 0411 8,2 OHM 5%
R 52003 S 873506403900 DRW 4 39 OHM 5%
R 52006
S 870536900300 MOW 0617 1,2 OHM 5% LI
R 53002 S 870012120500 KSW 0207 1,5 OHM 5% LI
R 53003 S 870012120500 KSW 0207 1,5 OHM 5% LI
R 53008 S 870032909700 KSW NB 0207 10 KOHM 5% LI
R 53011 870522702100 MOW 0411 6,8 OHM 5%
R 53016
S 873028002100 DRW SI S11 7W 6,8 OHM 5%
R 53021
S 870536906300 MOW 0617 390 OHM 5% LI
R 54001 S 873500303300 DRW 0,75W 0,33 OHM 10%
R 55012 S 870536906500 MOW 0617 470 OHM 5% LI
R 55014
S 870123081700 NKS 3 4,7 OHM 5%
R 58001 876509830400 MSW 0207 20 KOHM 2%
R 58002 876519808600 MSW 0207 3,6 KOHM 1%
R 60001 870006913100 KSW 0617 270 KOHM
R 60002 870006914100 KSW 0617 680 KOHM
R 60008 873017930100 DRW 7 15 KOHM 10% ST
R 60012 870004904100 KSW 0411 47 OHM 5%
R 60016
S 870537004300 MOW 0922 56 OHM 5% LI
R 60028 876504412700 MSW 0414 180 KOHM 5%
R 60029
S 870536911300 MOW 0617 47 KOHM 5% LI
R 60212 S 876504915300 MSW SI 0414 2,2 MOHM VDE
R 61001 879005001700 ESTR.SK10-A 220 OHM LIN
R 61018 870522132100 MOW 0411 100 KOHM 5%
R 61022
S 873229601100 DRW 6,5 2,7 OHM 10%
R 61031 879005002500 ESTR.SK10-A 470 OHM LIN
R 61033
S 870537005800 MOW 0922 100 OHM 10% LI
R 61041 879005001700 ESTR.SK10-A 220 OHM LIN
R 61313 879005005400 ESTR.SK10-A 22 KOHM LIN
R 62049
S 876634915500 MSW SI 0414 2,7 MOHM 5% LI
SI 60001
S 831562006800 SI LOET T2A 250V
SI 60201 S 831560702600 SI LOET T100MA 250V
SI 61022 S 831561902800 SI LOET T1,6A 250V
SI 61026
S 831562102700 SI LOET T2,5A 250V
SI 61036 S 831562102700 SI LOET T2,5A 250V
SI 61061 S 831562022500 SI LOET T2A 250V
SI 61066
S 831562022500 SI LOET T2A 250V
T 21211 830340129900 TRANS.BF299 G
T 40010 830328736800 TRANS.BC 368
T 50028 830221054400 TRANS BD544B/ BD538
T 50029 830221054300 TRANS BD543B/ BD537
T 52003 830221804300 TRANS.BDX 43
T 53001 830262533100 TRANS 2SC5331
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 720108000000, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
T 60006 830280505000 TRANS IRFPC50
TR 52001 092468679700 UEBERTRAGER
S292016800100 TRAFO DIODEN-SPLIT DIGI
TR 53010
TR 60001 S 292015699700 SPERRWANDLERTRAFO
TR 60220
S292016199700 SPERRWANDLERTRAFO KPL
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
DRIVER TRANSFORMER
DIODE SPLIT TRANSFORMER
REVERSE CONVERTER
TRANSFORMER
REVERSE CONVERTER
TRANSFORMER
Ersatzteilliste
Spare Parts List
11 / 2000
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
297040153300 CHASSIS-FS-STEREO CHASSIS TV STEREO
0100.000 295041623600 X BAUSTEIN SIGNAL / ZF+TUNER MODULE SIGNAL / IF+TUNER
0247.000 293031196600 EURO-AV BUCHSENLEISTE 21-POL SW EURO-AV SOCKET STRIP 21 P BLACK
0247.000 293031196800 EURO-AV BUCHSENLEISTE 21-POL OR EURO-AV SOCKET STRIP 21 P ORANGE
0400.000 295042090500 X FEATURE-BOX BASIC ++/BASIC 3 FEATURE-BOX BASIC ++/BASIC 3
WW. 295042091500 X FEATURE-BOX BASIC 3 FEATURE-BOX BASIC 3
0401.000 297006320201 HALTER BAUSTEIN HOLDER MODULE
0405.000 293040508500 NETZTEIL STAND BY POWER SUPPLY STAND BY
0406.000 297006131104 NETZTEILAUFNAHME HOLDER POWER SUPPLY
2200.000
S 293033995100 NETZ EINBAUGERAETESTECKER APPLIANCE COUPLER W.CABLE
2310.000
S 293033892101 VORSCHALTDROSSEL KPL LOETBAR SERIES REACTOR CPL SOLDERING
2310.000 S 293033892102 VORSCHALTDROSSEL KPL STECKBAR SERIES REACTOR CPL INSERT
2400.000 293031530100 MONTAGECLIP T60006 MOUNTING CLIP T60006
2410.000 293031530107 MONTAGECLIP T53001 MOUNTING CLIP T53001
2420.000 293031530200 MONTAGECLIP IC40020 MOUNTING CLIP IC40020
2430.000 293031531200 MONTAGECLIP D60006 MOUNTING CLIP D60006
2440.000 293031531208 12 MONTAGECLIP MOUNTING CLIP
2445.000 293031531605 MONTAGECLIP T52003 MOUNTING CLIP T52003
2450.000 293031561800 2 FOLIE WAERMELEITEND D60006/T60006 FOIL HEAT CONDUCTING D60006/T60006
2460.000 293031562000 10 FOLIE WAERMELEITEND D61026/61036 FOIL HEAT CONDUCTING D61026/61036
2470.000 293031562100 2 FOLIE WAERMELEITEND D53071/53072 FOIL HEAT CONDUCTING D53071/53072
2480.000 293031562301 FOLIE WAERMELEITEND T53001 FOIL HEAT CONDUCTING T53001
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 40013 845299619000 ELKO 2200UF 20% 35V
C 40031 845299614700 ELKO 1000UF 20% 25V
C 40032 845299614700 ELKO 1000UF 20% 25V
C 40033 845299614700 ELKO 1000UF 20% 25V
C 50012 845299614700 ELKO 1000UF 20% 25V
C 50026 845299614700 ELKO 1000UF 20% 25V
C 53012 851591160200 FOKO FKP1 142PF 2,5% 2000V
C 53071 851591169000 FOKO FKP1 9000PF 3,5% 2000V
C 60001 865008112500 KERKO HV C 1000PF 20% 1KV
C 60006 865006704600 KERKO HV C 100PF 20% 1KV
C 60009 851591104000 FOKO FKP1 220PF 10% 1600V
C 60012 865008111100 KERKO HV C 270PF 20% 2KV
C 60023 865008112500 KERKO HV C 1000PF 20% 1KV
C 60024 865008112500 KERKO HV C 1000PF 20% 1KV
C 60026 865008112500 KERKO HV C 1000PF 20% 1KV
C 60027 865008112500 KERKO HV C 1000PF 20% 1KV
C 60028 845199712400 ELKO #6 300UF +50-20% 385V
CHASSIS-FS-STEREO CUC 1836 BASIC ++/INL 4:3
CHASSIS TV STEREO CUC 1836 BASIC ++/INL 4:3
d©
CUC 1836 BASIC ++/INL 4:3 CUC 1836 BASIC ++/INL 4:3
KEIN E-TEIL NO SPARE PART
D53071/53072/61016/61026/61036 D53071/53072/61016/61026/61036
IC50010/61001/6106/61030/61040 IC50010/61001/6106/61030/61040
T50028/50029 T50028/50029
IC50010/61001/61006/61030/61040 IC50010/61001/61006/61030/61040
T50028/50029/52003 T50028/50029/52003
X=SIEHE GESONDERTE E-LISTE X=SEE SEPARATE PARTS LIST
WW.=WAHLWEISE WW.=OPTIONAL
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
WW. 844330605900 ELKO 15 300/330UF 385V
C 61004 845299614700 ELKO 1000UF 20% 25V
C 61016 851591103800 FOKO FKP1 100PF 10% 1600V
C 61021 865006704600 KERKO HV C 100PF 20% 1KV
C 61026 865006704600 KERKO HV C 100PF 20% 1KV
C 61032 845299614700 ELKO 1000UF 20% 25V
C 61036 865006704600 KERKO HV C 100PF 20% 1KV
C 61037 845209705700 ELKO 28 1000UF 63V
C 61042 845299610700 ELKO 2200UF 20% 16V
C 61061 865006704600 KERKO HV C 100PF 20% 1KV
C 61066 865006704600 KERKO HV C 100PF 20% 1KV
C 62048
S 866009823400 KERKO SI 1000PF 20% 400V
C 70509 845299614700 ELKO 1000UF 20% 25V
CD 21201 830953414900 MELF-DIODE LL 4148
CD 21202 830953414900 MELF-DIODE LL 4148
CD 21203 830953414900 MELF-DIODE LL 4148
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Ķ
TV
MATERIAL-NR. / PART NO.: 297040153300
CUC 1830 / 1836 / 1929 Ersatzteillisten / Spare Parts Lists
Page 44
58 GRUNDIG Service
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
Ersatzteillisten / Spare Parts Lists CUC 1830 / 1836 / 1929
CD 21206 832531310300 MELF DIODE BAV103
CD 32315 830945533100 MELF Z-DIODE 33B 0,5W
CD 34513 830953414900 MELF-DIODE LL 4148
CD 34517 830953414900 MELF-DIODE LL 4148
CD 40008 830945510100 MELF-Z DIODE 10 B 0,5W
CD 40015 830953414900 MELF-DIODE LL 4148
CD 41011 830953414900 MELF-DIODE LL 4148
CD 43025 830953414900 MELF-DIODE LL 4148
CD 52003 830953414900 MELF-DIODE LL 4148
CD 53019 830953414900 MELF-DIODE LL 4148
CD 55003 830945504000 MELF-Z DIODE 3,9 B 0,5W
CD 55004 830953414900 MELF-DIODE LL 4148
CD 58001 830953414900 MELF-DIODE LL 4148
CD 58004 830953414900 MELF-DIODE LL 4148
CD 58007 830945502800 MELF Z-DIODE 2,7 B 0,5W
CD 58011 830953414900 MELF-DIODE LL 4148
CD 58012 830953414900 MELF-DIODE LL 4148
CD 58021 830953414900 MELF-DIODE LL 4148
CD 58022 830953414900 MELF-DIODE LL 4148
CD 70501 830945505200 MELF-Z DIODE 5,1 B 0,5W
CD 70506 830953414900 MELF-DIODE LL 4148
CD 70507 830953414900 MELF-DIODE LL 4148
CD 70517 830953414900 MELF-DIODE LL 4148
CD 70553 830953414900 MELF-DIODE LL 4148
CD 80060 830953414900 MELF-DIODE LL 4148
CD 80081 830953414900 MELF-DIODE LL 4148
CD 80085 830953414900 MELF-DIODE LL 4148
CD 80091 830945503400 MELF Z-DIODE 3,3 B 0,5W
CD 81004 830953414900 MELF-DIODE LL 4148
CIC43010 830581455100 SMD IC MC14551BD/R2
CT 32308 830100385800 SMD TRANS BC858B/ BC857B
CT 32310 830100385800 SMD TRANS BC858B/ BC857B
CT 32312 830100385800 SMD TRANS BC858B/ BC857B
CT 32315 830100385800 SMD TRANS BC858B/ BC857B
CT 40010 830100484800 SMD TRANS BC848B/ BC847B
CT 43060 830100484800 SMD TRANS BC848B/ BC847B
CT 43088 830100484800 SMD TRANS BC848B/ BC847B
CT 43089 830100385800 SMD TRANS BC858B/ BC857B
CT 43091 830100385800 SMD TRANS BC858B/ BC857B
CT 43092 830100484800 SMD TRANS BC848B/ BC847B
CT 43093 830100484800 SMD TRANS BC848B/ BC847B
CT 43094 830100484800 SMD TRANS BC848B/ BC847B
CT 43095 830100484800 SMD TRANS BC848B/ BC847B
CT 46005 830100484800 SMD TRANS BC848B/ BC847B
CT 58012 830100484800 SMD TRANS BC848B/ BC847B
CT 61301 830100484800 SMD TRANS BC848B/ BC847B
CT 61316 830100484800 SMD TRANS BC848B/ BC847B
CT 70505 830100484800 SMD TRANS BC848B/ BC847B
CT 80002 830100685800 SMD TRANS BC858C/ BC857C
CT 80085 830100385800 SMD TRANS BC858B/ BC857B
CT 81001 830100484800 SMD TRANS BC848B/ BC847B
CT 81004 830100484800 SMD TRANS BC848B/ BC847B
D 21212 830921502000 DIODE 1 N 4004
D 32356 830921502000 DIODE 1 N 4004
D 32357 830921502000 DIODE 1 N 4004
D 40006
S 830921502000 DIODE 1 N 4004
D 50013 830951628300 DIODE BYV 28-200 RA
D 52006 830921502000 DIODE 1 N 4004
D 53008 830920100500 DIODE BA157
D 53019 830970900300 Z DIODE ZY 51
D 53071 830920435900 DIODE BY359 1500
D 53072 830920423000 DIODE BY 229-600
D 54001 830920100500 DIODE BA157
D 55012 830972033300 Z DIODE 33 C 0,5W
D 60006 830982088000 DIODE MUR 880 WW.BYT 08 P
D 60012 830951675400 DIODE BYT53B
D 60014 830920002100 DIODE BAV21
D 60023 830856052000 GLR.B 380 C 3700/2200
D 60216 830920002100 DIODE BAV21
D 60217 830920115900 DIODE BA159
S 830966318000 Z-DIODE BZT03D180
D 60218
D 61001 830951675400 DIODE BYT53B
D 61011 830951603800 DIODE BYV38
D 61012 830951603800 DIODE BYV38
D 61016 830982088000 DIODE MUR 880 WW.BYT 08 P
D 61021
S 830951717200 DIODE BYW172D
D 61026 830982084000 DIODE MUR 840/BYV 29-400
D 61033 830921502000 DIODE 1 N 4004
D 61036 830982084000 DIODE MUR 840/BYV 29-400
D 61061
S 830951717200 DIODE BYW172D
D 61066 S 830951717200 DIODE BYW172D
D 70508 830972011600 Z-DIODE 15 C 0,5W
IC 32310 830520570000 IC 78M05 2%
IC 34510 830533478000 IC TDA4780V3/ V4
IC 40020 830533726100 IC TDA7262
IC 41010 830533300600 IC TDA3006
IC 43080 830536642500 IC TEA6425
IC 50010 830534417300 IC TDA4173AF
IC 55010 830533814500 IC TDA8145
IC 58010 830520439300 IC LM393P
IC 60010 830535460500 IC TDA4605/3
IC 60220 830536150100 IC TEA1501 N1
IC 61001 830520431700 IC LM317T
IC 61006 830520431700 IC LM317T
IC 61030 830520431700 IC LM317T
IC 61040 830520435000 IC LM350T
IC 61310 830520435700 IC LM358N
IC 80040 830521006500 IC MC33164P-5RP
IC 80050 830515855000 SMD IC SDA5250D12
IC 80060 197983260200 IC 27C040-150NS PROG.KPL
IC 80065 830512400800 IC M24C08B1/ M24C08-BN6
IC 80070 830560241000 IC ST24W02CB1/ M24C02-BN6
IC 80090 830520439300 IC LM393P
L 32342 814052324900 DR ST 0411-GRP 10UH 10%
L 34517 814052636100 DR 0411 10UH 5%
L 46021 814052290300 DR ST 0411 1,5UH 2%
L 53001 810498205600 FERRITPERLE HF70 BTL 3,5X6
L 53002 810498205600 FERRITPERLE HF70 BTL 3,5X6
L 53003 810498205600 FERRITPERLE HF70 BTL 3,5X6
L 53011 814050524900 DR A AX-GA 10UH 10%
L 53012 092401140400 DROSSEL 1,5 MH/COIL 1.5 MH
L 53021 292031229700 LINEARITAETSREGLER (70CM)
L 53074 092468595500 BRUECKENSPULE M.KERN
L 55014 092458160100 O/W AUSKOPPELSPULE
L 60006 297017390800 DAEMPFUNGSPERLE
L 61011 810498201400 DAEMPF-PERLE 433003038102
L 61016 810498201400 DAEMPF-PERLE 433003038102
L 61021 810498201400 DAEMPF-PERLE 433003038102
L 61026 810498201400 DAEMPF-PERLE 433003038102
L 61036 810498201400 DAEMPF-PERLE 433003038102
L 61061 810498201400 DAEMPF-PERLE 433003038102
L 61062 814050506500 DR A AX-GA 47UH 5%
L 61066 810498201400 DAEMPF-PERLE 433003038102
L 61067 814050506500 DR A AX-GA 47UH 5%
L 70508 092410359700 STABKERNDROSSEL
L 70555 814052636100 DR 0411 10UH 5%
OK 60031
S 830600001200 OPTOKOPPLER CNY17F1
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
FERRITE BEAD
LINEARITY CONTROL
BRIDGE COIL W.CORE
E/W DECOUPLING COIL
DAMPING BEAD
DAMPING BEAD
BAR CORE CHOKE COIL
OK 60046 S830600001200 OPTOKOPPLER CNY17F1
Q 32305 838243918500 QUARZ 18,432 MHZ
Q 80055 860233115500 KERRES #155 18MHZ
R 21101
S 870532102000 MOW 0411 6,2 OHM 5%
R 32315 S 870537009900 MOW 0922 12 KOHM 5% LI
R 32357 S 870112102700 KSW SI B 12 OHM 5% LI
R 32359 S 870032904700 KSW NB 0207 82 OHM 5% LI
R 40013
S 870532907300 MOW 0411 1 KOHM 5% LI
R 40017 S 870032900700 KSW NB 0207 1,8 OHM 5% LI
R 40027
S 870032900700 KSW NB 0207 1,8 OHM 5% LI
R 40031 S 870032903100 KSW NB 0207 18 OHM 5% LI
R 41016 S 870032902700 KSW NB 0207 12 OHM 5% LI
R 43004
S 870112101300 KSW SI B 3,3 OHM 5% LI
R 43098 S 870112101300 KSW SI B 3,3 OHM 5% LI
R 50007 S 876632740500 MSW 0207 1,5 OHM 1%
R 50008
S 876632740500 MSW 0207 1,5 OHM 1%
R 50027 S 870012120500 KSW 0207 1,5 OHM 5% LI
R 50029 S 876635705900 MSW 0414 270 OHM 5%
R 52001
S 870532122300 MOW 0411 8,2 OHM 5%
R 52003 S 873506403900 DRW 4 39 OHM 5%
R 52006
S 870536100700 MOW 0617 1,8 OHM 5% LI
R 53002 S 870012120500 KSW 0207 1,5 OHM 5% LI
R 53003 S 870012120500 KSW 0207 1,5 OHM 5% LI
R 53008
S 870032909700 KSW NB 0207 10 KOHM 5% LI
R 53011 870522702100 MOW 0411 6,8 OHM 5%
R 53016
S 873028002100 DRW SI S11 7W 6,8 OHM 5%
R 53021 S 870536925700 MOW 0617 220 OHM 10% LI
R 54001
S 873500303300 DRW 0,75W 0,33 OHM 10%
R 55012 S 870536906500 MOW 0617 470 OHM 5% LI
R 55014 S 870123081700 NKS 3 4,7 OHM 5%
R 58001 876509830400 MSW 0207 20 KOHM 2%
R 60001 870006913100 KSW 0617 270 KOHM
R 60002 870006914100 KSW 0617 680 KOHM
R 60008 873017930100 DRW 7 15 KOHM 10% ST
R 60012 870004904100 KSW 0411 47 OHM 5%
R 60016
S 870537004300 MOW 0922 56 OHM 5% LI
R 60028 876504412700 MSW 0414 180 KOHM 5%
R 60029
S 870536911300 MOW 0617 47 KOHM 5% LI
R 60212 S 876504915300 MSW SI 0414 2,2 MOHM VDE
R 61001 879005001700 ESTR.SK10-A 220 OHM LIN
R 61018 870522132100 MOW 0411 100 KOHM 5%
R 61022
S 873229601100 DRW 6,5 2,7 OHM 10%
R 61031 879005002500 ESTR.SK10-A 470 OHM LIN
R 61033 S 870537005800 MOW 0922 100 OHM 10% LI
R 61041 879005001700 ESTR.SK10-A 220 OHM LIN
R 61313 879005005400 ESTR.SK10-A 22 KOHM LIN
R 62049
S 876634915500 MSW SI 0414 2,7 MOHM 5% LI
SI 60001
S 831562006800 SI LOET T2A 250V
SI 60201 S 831560702600 SI LOET T100MA 250V
SI 61022
S 831561902800 SI LOET T1,6A 250V
SI 61026 S 831562102700 SI LOET T2,5A 250V
SI 61036 S 831562102700 SI LOET T2,5A 250V
SI 61061
S 831562022500 SI LOET T2A 250V
SI 61066 S 831562022500 SI LOET T2A 250V
T 21211 830340129900 TRANS.BF299 G
T 40010 830328736800 TRANS.BC 368
T 50028 830221054400 TRANS BD544B/ BD538
T 50029 830221054300 TRANS BD543B/ BD537
T 52003 830221804300 TRANS.BDX 43
T 53001 830262533100 TRANS 2SC5331
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 720108000000, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
T 60006 830280505000 TRANS IRFPC50
TR 52001 092458129600 TREIBERUEBERTRAGER
S292210330100 TRAFO DIODEN-SPLIT
TR 53010
TR 60001
S292015669700 TRAFO SPERRWANDLER
TR 60220
S292016199700 SPERRWANDLERTRAFO KPL
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
DRIVER TRANSFORMER
DIODE SPLIT TRANSFORMER
REVERSE CONVERTER
TRANSFORMER
REVERSE CONVERTER
TRANSFORMER
Page 45
GRUNDIG Service 59
Ķ
Ersatzteilliste
Spare Parts List
7 / 98
ERSETZT AUSGABE 5/98
SUBSTITUTE EDITION 5/98
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
29701 096 6200 CHASSIS-FS-STEREO CUC1836 DIGI-BASIC CHASSIS TV STEREO CUC1836 DIGI-BASIC
0100.000 29504 102 3400 X BAUSTEIN SIGNAL/ZF+TUNER MODULE SIGNAL/IF+TUNER
WW. 29504 102 3600 X BAUSTEIN SIGNAL/ZF+TUNER MODULE SIGNAL/IF+TUNER
0300.000 29504 103 4200 X FEATURE-BOX FEATURE-BOX
0400.000 29304 050 2900 NETZTEIL STAND BY POWER SUPPLY STAND BY
1040.000 29700 632 0100 HALTER BAUSTEIN HOLDER MODULE
1080.000 29303 119 6600 EURO-AV BUCHSENLEISTE 21-P.SCHWARZ EURO-AV SOCKET STRIP 21 P BLACK
1082.000 29303 119 6800 EURO-AV BUCHSENLEISTE 21-P.ORANGE EURO-AV SOCKET STRIP 21 P ORANGE
S 29303 399 5100 NETZ EINBAUGERAETESTECKER M.LTG APPLIANCE COUPLER W.CABLE
2300.000
2410.000 29303 153 0100 MONTAGECLIP D60006/T53001 MOUNTING CLIP D60006/T53001
2430.000 29303 153 1200 MONTAGECLIP D53071/53072/60006/61016/ MOUNTING CLIP D53071/53072/60006/61016/
2440.000 29303 153 1600 MONTAGECLIP T52003 MOUNTING CLIP T52003
2450.000 29303 156 2300 FOLIE WAERMELEITEND T53001 FOIL HEAT CONDUCTING T53001
2460.000 29303 156 1800 FOLIE WAERMELEITEND D60006/T60006 FOIL HEAT CONDUCTING D60006/T60006
2470.000 29303 156 2000 FOLIE WAERMELEITEND D61016/61026/ FOIL HEAT CONDUCTING D61016/61026/
2480.000 29303 156 2100 FOLIE WAERMELEITEND D53071/53072 FOIL HEAT CONDUCTING D53071/53072
POS. NR. MATERIAL-NR BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C40013 84529 961 9000 ELKO 2200UF 20% 35V
C40031 84529 961 4700 ELKO 1000UF 20% 25V
C40032 84529 961 4700 ELKO 1000UF 20% 25V
C40033 84529 961 4700 ELKO 1000UF 20% 25V
C50012 84529 961 4700 ELKO 1000UF 20% 25V
C50026 84529 961 4700 ELKO 1000UF 20% 25V
C53012 85159 116 0200 FKP1 142PF 2,5% 2000V
C53071 85159 117 0300 FOKO FKP1 0,013UF 2000V
C60001 86500 811 2500 HV-KERKO 1000PF 20%
C60006 86500 670 4600 HV-KERKO 100PF 20% 1000V
C60009 85159 110 4000 FKP1 220PF 10% 1600V1000V
C60012 86500 811 1100 HV-KERKO 270PF 20% 2000V
C60023 86500 811 2500 HV-KERKO 1000PF 20%1000V
C60024 86500 811 2500 HV-KERKO 1000PF 20%1000V
C60026 86500 811 2500 HV-KERKO 1000PF 20%1000V
C60027 86500 811 2500 HV-KERKO 1000PF 20%1000V
C60224 85159 110 3800 FKP1 100PF 10% 1600V
C61004 84529 961 4700 ELKO 1000UF 20% 25V
C61016 85159 110 3800 FKP1 100PF 10% 1600V
C61021 86500 670 4600 HV-KERKO 100PF 20% 1000V
C61026 86500 670 4600 HV-KERKO 100PF 20% 1000V
C61032 84529 961 4700 ELKO 1000UF 20% 25V
C61036 86500 670 4600 HV-KERKO 100PF 20% 1000V
CHASSIS-FS-STEREO CUC 1836 DIGI-BASIC
CHASSIS-TV-STEREO CUC 1836 DIGI-BASIC
SACH-NR. / PART NO.: 29701 096 6200
d©
KEIN ET-EIL NO SPARE PART
61026/61036/61056/T50028/50029/IC50010/ 61026/61036/61056/T50028/50029/IC50010/
61001/61006/61030/61040/61050 61001/61006/61030/61040/61050
61036/61056/T50028/50029/52003/IC50010/ 61036/61056/T50028/50029/52003/IC50010/
61001/61006/61030/61040/61050 61001/61006/61030/61040/61050
X = SIEHE GESONDERTE E-LISTE X = SEE SEPARATE PARTS LIST
WW. = WAHLWEISE WW. = OPTIONAL
POS. NR. MATERIAL-NR BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C61037 84520 970 5700 ELKO 28 1000UF 63V
C61042 84529 961 0700 ELKO 2200UF 20% 16V
C61061 86500 670 4600 HV-KERKO 100PF 20% 1000V
C61064 84529 961 5000 ELKO 2200UF 20% 25V
C61066 86500 670 4600 HV-KERKO 100PF 20% 1000V
C62021
S 86600 982 3800 SI-KERKO B-SS 2200PF 400V
C62022
S 86600 982 3800 SI-KERKO B-SS 2200PF 400V
C62048 S 86600 982 3400 SI-KERKO B-SS 1000PF 400V
C70509 84529 961 4700 ELKO 1000UF 20% 25V
CD21201 83250 041 4800 SMD DIODE LS 4148
CD21202 83250 041 4800 SMD DIODE LS 4148
CD21203 83250 041 4800 SMD DIODE LS 4148
CD21206 83253 131 0300 MELF DIODE BAV103
CD32315 83094 553 3100 MELF Z-DIODE 33B 0,5
CD34513 83250 041 4800 SMD DIODE LS 4148
CD34517 83250 041 4800 SMD DIODE LS 4148
CD40008 83094 551 0100 MELF-Z DIODE 10 B 0,
CD40015 83250 041 4800 SMD DIODE LS 4148
CD41011 83250 041 4800 SMD DIODE LS 4148
CD43025 83250 041 4800 SMD DIODE LS 4148
CD52003 83250 041 4800 SMD DIODE LS 4148
CD53019 83250 041 4800 SMD DIODE LS 4148
TV
POS. NR. MATERIAL-NR BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
CD55003 83094 550 4000 MELF-Z DIODE 3,9 B 0
CD55004 83250 041 4800 SMD DIODE LS 4148
CD58001 83250 041 4800 SMD DIODE LS 4148
CD58004 83250 041 4800 SMD DIODE LS 4148
CD58007 83094 550 2800 MELF Z-DIODE 2,7 B 0
CD58011 83250 041 4800 SMD DIODE LS 4148
CD58012 83250 041 4800 SMD DIODE LS 4148
CD58021 83250 041 4800 SMD DIODE LS 4148
CD58022 83250 041 4800 SMD DIODE LS 4148
CD60201 83250 041 4800 SMD DIODE LS 4148
CD60202 83250 041 4800 SMD DIODE LS 4148
CD60223 83250 041 4800 SMD DIODE LS 4148
CD70501 83094 550 5200 MELF-Z DIODE 5,1 B 0
CD70506 83250 041 4800 SMD DIODE LS 4148
CD70507 83250 041 4800 SMD DIODE LS 4148
CD70517 83250 041 4800 SMD DIODE LS 4148
CD70553 83250 041 4800 SMD DIODE LS 4148
CD80060 83250 041 4800 SMD DIODE LS 4148
CD80081 83250 041 4800 SMD DIODE LS 4148
CD80085 83250 041 4800 SMD DIODE LS 4148
CD80091 83094 550 3400 MELF Z-DIODE 3,3 B 0
CD81004 83250 041 4800 SMD DIODE LS 4148
CIC43010 83058 145 5100 SMD IC MC14551BD/R2
CT32308 83010 038 5800 SMD-TRANS.BC 858 B
CT32310 83010 038 5800 SMD-TRANS.BC 858 B
CT32312 83010 038 5800 SMD-TRANS.BC 858 B
CT32315 83010 038 5800 SMD-TRANS.BC 858 B
CT40010 83010 048 4800 SMD-TRANS.BC 848 B
CT43060 83010 048 4800 SMD-TRANS.BC 848 B
CT43088 83010 048 4800 SMD-TRANS.BC 848 B
CT43089 83010 038 5800 SMD-TRANS.BC 858 B
CT43091 83010 038 5800 SMD-TRANS.BC 858 B
CT43092 83010 048 4800 SMD-TRANS.BC 848 B
CT43093 83010 048 4800 SMD-TRANS.BC 848 B
CT43094 83010 048 4800 SMD-TRANS.BC 848 B
CT43095 83010 048 4800 SMD-TRANS.BC 848 B
CT46005 83010 048 4800 SMD-TRANS.BC 848 B
CT58012 83010 048 4800 SMD-TRANS.BC 848 B
CT60203 83010 048 4800 SMD-TRANS.BC 848 B
CT60206 83010 068 5800 SMD-TRANS.BC 858 C
CT60213 83010 038 5800 SMD-TRANS.BC 858 B
CT61301 83010 048 4800 SMD-TRANS.BC 848 B
CT61316 83010 048 4800 SMD-TRANS.BC 848 B
CT70505 83010 048 4800 SMD-TRANS.BC 848 B
CT80002 83010 068 5800 SMD-TRANS.BC 858 C
CT80085 83010 038 5800 SMD-TRANS.BC 858 B
CT81001 83010 048 4800 SMD-TRANS.BC 848 B
CT81004 83010 048 4800 SMD-TRANS.BC 848 B
D21212 83092 150 2000 DIODE 1 N 4004 -GA
D32356 83092 150 2000 DIODE 1 N 4004 -GA
D32357 83092 150 2000 DIODE 1 N 4004 -GA
D40006
S 83092 150 2000 DIODE 1 N 4004 -GA
D50013 83095 162 8300 DIODE BYV 28-200 RA
D52006 83092 150 2000 DIODE 1 N 4004 -GA
D53008 83092 010 0500 DIODE BA157
D53019 83097 090 0300 Z DIODE ZY 51 ITT
D53071 83092 043 5900 DIODE BY359 1500 PHI
D53072 83092 042 3000 DIODE BY 229-600
D54001 83092 010 0500 DIODE BA157
D55012 83097 203 3300 Z DIODE 33 C 0,5W
D60006 83098 208 8000 DIODE MUR 880 WW.BYT
D60012 83095 167 5400 DIODE BYT53B TFK/ EG
D60014 83092 000 2100 DIODE BAV21 ITT/ TFK
D60023 83085 605 2000 GLR.B 380 C 3700/220
D60202 83097 201 3100 Z DIODE 13 B 0,5W
D60203 83097 200 8300 Z DIODE 8,2 B 0,5W
D60207 83092 150 2000 DIODE 1 N 4004 -GA
POS. NR. MATERIAL-NR BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
D60208 83092 150 2000 DIODE 1 N 4004 -GA
D60221 83092 011 5900 DIODE BA159
S 83096 631 8000 Z-DIODE BZT03D180
D60222
D60223
S 83096 631 8000 Z-DIODE BZT03D180
D61001 83095 167 5400 DIODE BYT53B TFK/ EG
D61011 83095 160 3800 DIODE BYV38 TFK
D61012 83095 160 3800 DIODE BYV38 TFK
D61016 83098 208 8000 DIODE MUR 880 WW.BYT
D61021
S 83095 171 7200 DIODE BYW 172 D/SK 3
D61026 83098 208 4000 DIODE MUR 840/BYV 29
D61033 83092 150 2000 DIODE 1 N 4004 -GA
D61036 83098 208 4000 DIODE MUR 840/BYV 29
D61061
S 83095 171 7200 DIODE BYW 172 D/SK 3
D61066
S 83095 171 7200 DIODE BYW 172 D/SK 3
D70508 83097 201 1600 Z-DIODE 15 C 0,5W AV
IC32300 83057 954 0000 SMD IC MSP3400C-PS P
IC32310 83052 057 0000 IC 78M05 2%
IC34510 83053 347 8000 IC TDA4780V3
IC40020 83053 372 6100 IC TDA7262 SGS
IC40020 83053 372 6100 IC TDA7262 SGS
IC41010 83053 330 0600 IC TDA3006 SMI
IC43080 83053 664 2500 IC TEA6425 SGS
IC50010 83053 441 7300 IC TDA4173AF
IC55010 83053 381 4500 IC TDA8145
IC58010 83052 043 9300 IC LM393P TID/ 393N
IC60010 83053 546 0500 IC TDA4605/3
IC61001 83052 043 1700 IC LM317T NSC/MOT/SG
IC61006 83052 043 1700 IC LM317T NSC/MOT/SG
IC61030 83052 043 1700 IC LM317T NSC/MOT/SG
IC61040 83052 043 5000 IC LM350T
IC61310 83052 043 5700 IC LM358N NSC/TID/MO
IC80040 83052 100 6500 IC MC33164P-5RP
IC80050 83051 585 5000 SMD IC SDA5250D12
IC80060 19798 318 0500 IC 27C040-150NS PROG
IC80065 83051 240 0800 IC ST24C08 SGS
IC80070 83056 024 1000 IC X24C02P XICOR/ ST
IC80090 83052 043 9300 IC LM393P TID/ 393N
L32342 81405 232 4900 DR ST 0411-GRP 10UH
L34517 81405 263 6100 DR 0411 10UH 5%
L46021 81405 229 0300 DR ST 0411 1,5UH 2%
L53001 81049 820 5600 FERRITPERLE HF70 BTL
L53002 81049 820 5600 FERRITPERLE HF70 BTL
L53003 81049 820 5600 FERRITPERLE HF70 BTL/
L53011 81405 052 4900 DR A AX-GA 10UH 10%
L53012 09240 114 0400 DROSSEL 1,5 MH/CHOKE COIL
L53021 29203 122 9700 LINEARITAETSREGLER /
L53074 09246 859 6400 SPULE BRUECKE M.KERN/
L55014 09245 816 0100 O/W AUSKOPPELSPULE/
L60006 29701 739 0800 DAEMPFUNGSPERLE UV 9
L61011 81049 820 1400 DAEMPFUNGSPERLE 4330
L61016 81049 820 1400 DAEMPFUNGSPERLE 4330
L61021 81049 820 1400 DAEMPFUNGSPERLE 4330
L61026 81049 820 1400 DAEMPFUNGSPERLE 4330
L61036 81049 820 1400 DAEMPFUNGSPERLE 4330
L61061 81049 820 1400 DAEMPFUNGSPERLE 4330/
L61062 81405 050 6500 DR A AX-GA 47UH 5%
L61066 81049 820 1400 DAEMPFUNGSPERLE 4330/
L61067 81405 050 6500 DR A AX-GA 47UH 5%
L70508 09241 035 9700 STABKERNDROSSEL/
L70555 81405 263 6100 DR 0411 10UH 5% AV61
FERRITE BEAD
LINEARITY CONTROL
BRIDGE COIL
E/W DECOUPLING COIL
DAMPING BEAD
DAMPING BEAD
BAR CORE CHOKE COIL
CUC 1830 / 1836 / 1929 Ersatzteillisten / Spare Parts Lists
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Page 46
60 GRUNDIG Service
POS. NR. MATERIAL-NR BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
OK60031
OK60046S 83060 000 1200 OPTOKOPPLER CNY17F1/
Q32305 83824 391 8600 QUARZ #439-9 18,432M
Q80055 86023 311 5500 KERRES #155 18MHZ RA
R21101
R32315 S 87053 700 9900 MOW 0922 12 KOHM 5%
R32357 S 87011 210 2700 KSW SI B 12 OHM 5%
R32359
R40013 S 87053 290 7300 MOW 0411 1 KOHM 5%
R40017
R40027 S 87003 290 0700 KSW NB 0207 1,8 OHM
R40031 S 87003 290 3100 KSW NB 0207 18 OHM
R41016
R43004 S 87011 210 1300 KSW SI B 3,3 OHM 5%
R43098 S 87011 210 1300 KSW SI B 3,3 OHM 5%
R52001
R52006 S 87053 690 0300 MOW 0617 1,2 OHM 5%
R53008 S 87003 290 9700 KSW NB 0207 10 KOHM
R53011 87052 270 2100 MOW 0411 6,8 OHM 5%
R53021
R55012
R60016 S 87053 700 4300 MOW 0922 56 OHM 5%
R60029 S 87053 691 1300 MOW 0617 47 KOHM 5%
R60207
R61001 87900 500 1700 ESTR.SK10-A 220 OHM
R61018 87052 213 2100 MOW 0411 100 KOHM 10
R61031 87900 500 2500 ESTR.SK10-A 470 OHM
R61033
R61041 87900 500 1700 ESTR.SK10-A 220 OHM
R61313 87900 500 5400 ESTR.SK10-A 22 KOHM
SI60001
SI60201
SI61022 S 83156 190 2800 LOET-SI.-GR 1,6 A/T
SI61026 S 83156 210 2700 SI LOET T2,5A 250V A
SI61036
SI61061 S 83156 202 2500 LOET-SI.-GR 2 A/T
SI61066 S 83156 202 2500 LOET-SI.-GR 2 A/T
T21211 83034 012 9900 TRANS.BF299 G ITT/PB
T40010 83032 873 6800 TRANS.BC 368 GEG.AMM
T50028 83022 105 4400 TRANS.BD 538 WW. BD
T50029 83022 105 4300 TRANS.BD 537 SGS WW.
T52003 83022 180 4300 TRANS.BDX 43
T53001 83026 253 3100 TRANS 2SC5331
T60006 83028 050 5000 TRANS IRF PC50 IRF/
T60223 83022 690 9100 TRANS.BUZ 90 A TYP 2
TR52001 09246 867 9700 UEBERTRAGER VOGT/
TR53010
TR60001
TR60220
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 72010 800 0000, sowie zusätzlich die eventuell
abweichenden, landesspezifischen Vorschriften!
S 83060 000 1200 OPTOKOPPLER CNY17F1/
S 87053 210 2100 MOW 0411 6,8 OHM 5%
S 87003 290 4700 KSW NB 0207 82 OHM
S 87003 290 0700 KSW NB 0207 1,8 OHM
S 87003 290 2700 KSW NB 0207 12 OHM
S 87053 212 2300 MOW 0411 8,2 OHM 5%
S 87053 690 6300 MOW 0617 390 OHM 5%
S 87053 690 6500 MOW 0617 470 OHM 5%
S 87003 290 1700 KSW NB 0207 4,7 OHM
S 87053 700 5800 MOW 0922 100 OHM 10%
S 83156 202 2500 LOET-SI.-GR 2 A/T
S 83156 070 2600 LOET-SI.-GR 100 MA/T
S 83156 210 2700 SI LOET T2,5A 250V A
S 29201 680 0100 TRAFO DIODEN-SPLIT
S 29201 569 9700 TRAFO SPERRWANDLER/
S 29201 701 9700 TRAFO STAND-BY/
TRANSFORMER
DIODE SPLIT TRANSFORMER
B.O.-TYPE CONVERTER
TRANSFORMER
TRANSFORMER STAND-BY
POS. NR. MATERIAL-NR BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 72010 800 0000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Ķ
Ersatzteilliste
Spare Parts List
11 / 99
ERSETZT AUSGABE 7/98
SUBSTITUTE EDITION 7/98
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
29701 096 6800 CHASSIS-FS-STEREO DIGI BASIC ++ CHASSIS-TV-STEREO DIGI BASIC ++
0200.000 29504 162 3400 X BAUSTEIN SIGNAL / ZF+TUNER MODULE SIGNAL / IF+TUNER
WW. 29504 162 3600 X BAUSTEIN SIGNAL / ZF+TUNER MODULE SIGNAL / IF+TUNER
0247.000 29303 119 6600 EURO-AV BUCHSENLEISTE 21-POL. SW EURO-AV SOCKET STRIP 21 P BLACK
0247.000 29303 119 6800 EURO-AV BUCHSENLEISTE 21-POL. OR EURO-AV SOCKET STRIP 21 P ORANGE
0400.000 29504 103 4201 X FEATURE-BOX DIGI BASIC ++ FEATURE-BOX DIGI BASIC ++
0400.000
S 29304 050 8200 NETZTEIL STAND BY POWER SUPPLY STAND BY
WW. S 29304 050 2900 NETZTEIL STAND BY POWER SUPPLY STAND BY
0450.000 29700 613 1103 NETZTEILAUFNAHME HOLDER POWER SUPPLY
0451.000 29700 632 0109 HALTER BAUSTEIN HOLDER MODULE
2200.000
S 29303 399 5100 NETZ EINBAUGERAETESTECKER APPLIANCE COUPLER W.CABLE
2400.000 29303 153 0100 MONTAGECLIP T60006 MOUNTING CLIP T60006
2410.000 29303 153 0200 MONTAGECLIP IC40020 MOUNTING CLIP IC40020
2430.000 29303 153 1200 2 MONTAGECLIP D60006/61016 MOUNTING CLIP D60006/61016
2431.000 29303 153 1208 11 MONTAGECLIP D53071/53072/61026/ MOUNTING CLIP D53071/53072/61026/
2440.000 29303 153 1605 MONTAGECLIP T52003 MOUNTING CLIP T52003
2450.000 29303 156 0300 GLIMMERSCHEIBE T53001 MICA WASHER T53001
2460.000 29303 156 1800 FOLIE WAERMELEITEND T60006 FOIL HEAT CONDUCTING T60006
2470.000 29303 156 2000 11 FOLIE WAERMELEITEND D61006/61016/ FOIL HEAT CONDUCTING D61006/61016/
2480.000 29303 156 2100 2 FOLIE WAERMELEITEND D53071/53072 FOIL HEAT CONDUCTING D53071/53072
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 40013 84529 961 9000 ELKO 2200UF 20% 35V
C 40031 84529 961 4700 ELKO 1000UF 20% 25V
C 40032 84529 961 4700 ELKO 1000UF 20% 25V
C 40033 84529 961 4700 ELKO 1000UF 20% 25V
C 50012 84529 961 4700 ELKO 1000UF 20% 25V
C 50026 84529 961 4700 ELKO 1000UF 20% 25V
C 53012 85159 116 0200 FOKO FKP1 142PF 2,5% 2000V
C 53071 85159 114 0900 FOKO FKP1 0,01UF 3,5% 2000V
C 60001 86500 811 2500 HV-KERKO 1000PF 20% 1KV
C 60006 86500 670 4600 HV-KERKO 100PF 20% 1KV
C 60009 85159 110 4000 FOKO FKP1 220PF 10% 1600V
C 60012 86500 811 1100 HV-KERKO 270PF 20% 2KV
C 60023 86500 811 2500 HV-KERKO 1000PF 20% 1KV
C 60024 86500 811 2500 HV-KERKO 1000PF 20% 1KV
C 60026 86500 811 2500 HV-KERKO 1000PF 20% 1KV
C 60027 86500 811 2500 HV-KERKO 1000PF 20% 1KV
C 60028 84433 060 5900 ELKO 15 300/330UF 385V
WW. 84519 971 2400 ELKO #6 300UF +50-20% 385
C 60224 85159 110 3800 FOKO FKP1 100PF 10% 1600V
CHASSIS-FS-STEREO DIGI BASIC ++ CUC 1836 INL
CHASSIS TV STEREO DIGI BASIC ++ CUC 1836 INL
MATERIAL-NR. / PART NO.: 29701 096 6800
d©
CUC 1836 INL CUC 1836 INL
KEIN E-TEIL NO SPARE PART
61036/IC50010/61001/61006/61030/61040/ 61036/IC50010/61001/61006/61030/61040/
T50028/50029 T50028/50029
61026/61036/IC50010/61001/61006/61030/ 61026/61036/IC50010/61001/61006/61030/
61040/T50028/50029 61040/T50028/50029
X = SIEHE GESONDERTE E-LISTE X = SEE SEPARATE PARTS LIST
WW. = WAHLWEISE WW. = OPTIONAL
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 61004 84529 961 4700 ELKO 1000UF 20% 25V
C 61016 85159 110 3800 FOKO FKP1 100PF 10% 1600V
C 61021 86500 670 4600 HV-KERKO 100PF 20% 1KV
C 61026 86500 670 4600 HV-KERKO 100PF 20% 1KV
C 61032 84529 961 4700 ELKO 1000UF 20% 25V
C 61036 86500 670 4600 HV-KERKO 100PF 20% 1KV
C 61037 84520 970 5700 ELKO 28 1000UF 63V
C 61042 84529 961 0700 ELKO 2200UF 20% 16V
C 61061 86500 670 4600 HV-KERKO 100PF 20% 1KV
C 61066 86500 670 4600 HV-KERKO 100PF 20% 1KV
C 62021
S 86600 982 3800 SI-KERKO B-SS 2200PF 20% 400V
C 62022 S 86600 982 3800 SI-KERKO B-SS 2200PF 20% 400V
C 62048
S 86600 982 3400 SI-KERKO B-SS 1000PF 20% 400V
C 70509 84529 961 4700 ELKO 1000UF 20% 25V
CD 21201 83250 041 4800 SMD DIODE LS 4148
CD 21202 83250 041 4800 SMD DIODE LS 4148
CD 21203 83250 041 4800 SMD DIODE LS 4148
CD 21206 83253 131 0300 MELF DIODE BAV103
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Ersatzteillisten / Spare Parts Lists CUC 1830 / 1836 / 1929
TV
Page 47
GRUNDIG Service 61
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
CUC 1830 / 1836 / 1929 Ersatzteillisten / Spare Parts Lists
CD 32315 83094 553 3100 MELF Z-DIODE 33B 0,5W
CD 34513 83250 041 4800 SMD DIODE LS 4148
CD 34517 83250 041 4800 SMD DIODE LS 4148
CD 40008 83094 551 0100 MELF-Z DIODE 10 B 0,5W
CD 40015 83250 041 4800 SMD DIODE LS 4148
CD 41011 83250 041 4800 SMD DIODE LS 4148
CD 43025 83250 041 4800 SMD DIODE LS 4148
CD 52003 83250 041 4800 SMD DIODE LS 4148
CD 53019 83250 041 4800 SMD DIODE LS 4148
CD 55003 83094 550 4400 MELF Z-DIODE 4,3 B 0,5W
CD 55004 83250 041 4800 SMD DIODE LS 4148
CD 58001 83250 041 4800 SMD DIODE LS 4148
CD 58004 83250 041 4800 SMD DIODE LS 4148
CD 58007 83094 550 2800 MELF Z-DIODE 2,7 B 0,5W
CD 58011 83250 041 4800 SMD DIODE LS 4148
CD 58012 83250 041 4800 SMD DIODE LS 4148
CD 58021 83250 041 4800 SMD DIODE LS 4148
CD 58022 83250 041 4800 SMD DIODE LS 4148
CD 60201 83250 041 4800 SMD DIODE LS 4148
CD 60202 83250 041 4800 SMD DIODE LS 4148
CD 60223 83250 041 4800 SMD DIODE LS 4148
CD 70501 83094 550 5200 MELF-Z DIODE 5,1 B 0,5W
CD 70506 83250 041 4800 SMD DIODE LS 4148
CD 70507 83250 041 4800 SMD DIODE LS 4148
CD 70517 83250 041 4800 SMD DIODE LS 4148
CD 70553 83250 041 4800 SMD DIODE LS 4148
CD 80060 83250 041 4800 SMD DIODE LS 4148
CD 80081 83250 041 4800 SMD DIODE LS 4148
CD 80085 83250 041 4800 SMD DIODE LS 4148
CD 80091 83094 550 3400 MELF Z-DIODE 3,3 B 0,5W
CD 81004 83250 041 4800 SMD DIODE LS 4148
CIC43010 83058 145 5100 SMD IC MC14551BD/R2 MOT
CT 32308 83010 038 5800 SMD TRANS BC858B
CT 32310 83010 038 5800 SMD TRANS BC858B
CT 32312 83010 038 5800 SMD TRANS BC858B
CT 32315 83010 038 5800 SMD TRANS BC858B
CT 40010 83010 048 4800 SMD-TRANS.BC 848 B
CT 43060 83010 048 4800 SMD-TRANS.BC 848 B
CT 43088 83010 048 4800 SMD-TRANS.BC 848 B
CT 43089 83010 038 5800 SMD TRANS BC858B
CT 43091 83010 038 5800 SMD TRANS BC858B
CT 43092 83010 048 4800 SMD-TRANS.BC 848 B
CT 43093 83010 048 4800 SMD-TRANS.BC 848 B
CT 43094 83010 048 4800 SMD-TRANS.BC 848 B
CT 43095 83010 048 4800 SMD-TRANS.BC 848 B
CT 46005 83010 048 4800 SMD-TRANS.BC 848 B
CT 58012 83010 048 4800 SMD-TRANS.BC 848 B
CT 60203 83010 048 4800 SMD-TRANS.BC 848 B
CT 60206 83010 068 5800 SMD-TRANS.BC 858 C
CT 60213 83010 038 5800 SMD TRANS BC858B
CT 61301 83010 048 4800 SMD-TRANS.BC 848 B
CT 61316 83010 048 4800 SMD-TRANS.BC 848 B
CT 70505 83010 048 4800 SMD-TRANS.BC 848 B
CT 80002 83010 068 5800 SMD-TRANS.BC 858 C
CT 80085 83010 038 5800 SMD TRANS BC858B
CT 81001 83010 048 4800 SMD-TRANS.BC 848 B
CT 81004 83010 048 4800 SMD-TRANS.BC 848 B
D 21212 83092 150 2000 DIODE 1 N 4004 -GA
D 32356 83092 150 2000 DIODE 1 N 4004 -GA
D 32357 83092 150 2000 DIODE 1 N 4004 -GA
D 40006
S 83092 150 2000 DIODE 1 N 4004 -GA
D 50013 83095 162 8300 DIODE BYV 28-200
D 52006 83092 150 2000 DIODE 1 N 4004 -GA
D 53008 83092 010 0500 DIODE BA157
D 53019 83097 090 0300 Z DIODE ZY 51 ITT
D 53071 83092 043 5900 DIODE BY359 1500 PHI
D 53072 83092 042 3000 DIODE BY 229-600
D 54001 83092 010 0500 DIODE BA157
D 55012 83097 203 3300 Z DIODE 33 C 0,5W
D 60006 83098 208 8000 DIODE MUR 880
D 60012 83095 167 5400 DIODE BYT53B TFK
D 60014 83092 000 2100 DIODE BAV21 ITT/ TFK
D 60023 83085 605 2000 GLR.B 380 C 3700/2200
D 60202 83097 201 3100 Z DIODE 13 B 0,5W
D 60203 83097 200 8300 Z DIODE 8,2 B 0,5W
D 60207 83092 150 2000 DIODE 1 N 4004
D 60208 83092 150 2000 DIODE 1 N 4004
D 60216 83092 000 2100 DIODE BAV21 ITT/ TFK
D 60217 83092 011 5900 DIODE BA159
S 83096 631 8000 Z-DIODE BZT03D180
D 60218
D 60221 83092 011 5900 DIODE BA159
D 60222
S 83096 631 8000 Z-DIODE BZT03D180
D 60223
S 83096 631 8000 Z-DIODE BZT03D180
D 61001 83095 167 5400 DIODE BYT53B TFK
D 61001 83095 167 5400 DIODE BYT53B TFK
D 61011 83095 160 3800 DIODE BYV38 TFK
D 61012 83095 160 3800 DIODE BYV38 TFK
D 61016 83098 208 8000 DIODE MUR 880
D 61021
S 83095 171 7200 DIODE BYW172D TEMIC
D 61026 83098 208 4000 DIODE MUR 840
D 61033 83092 150 2000 DIODE 1 N 4004 -GA
D 61036 83098 208 4000 DIODE MUR 840
D 61061
S 83095 171 7200 DIODE BYW172D TEMIC
D 61066 S 83095 171 7200 DIODE BYW172D TEMIC
D 70508 83097 201 1600 Z-DIODE 15 C 0,5W
IC 32300 83057 954 1000 SMD IC MSP3410B-PS PLCC
IC 32310 83052 057 0000 IC 78M05 2%
IC 34510 83053 347 8000 IC TDA4780V3/ V4
IC 40020 83053 372 6100 IC TDA7262 SGS
IC 40020 83053 372 6100 IC TDA7262 SGS
IC 41010 83053 330 0600 IC TDA3006 SMI
IC 43080 83053 664 2500 IC TEA6425 SGS
IC 50010 83053 441 7300 IC TDA4173AF
IC 55010 83053 381 4500 IC TDA8145
IC 58010 83052 043 9300 IC LM393P TID/ 393N RAY
IC 60010 83053 546 0500 IC TDA4605/3
IC 60220 83053 615 0100 IC TEA1501 N1 TIP8 PHI
IC 61001 83052 043 1700 IC LM317T NSC/MOT/SGS
IC 61006 83052 043 1700 IC LM317T NSC/MOT/SGS
IC 61030 83052 043 1700 IC LM317T NSC/MOT/SGS
IC 61040 83052 043 5000 IC LM350T
IC 61310 83052 043 5700 IC LM358N NSC/TID/MOT/RAY
IC 80040 83052 100 6500 IC MC33164P-5RP
IC 80050 83051 585 5000 SMD IC SDA5250D12
IC 80060 19798 318 3300 IC 27C040-150NS PROG.KPL
IC 80065 83051 240 0800 IC M24C08B1
IC 80070 83056 024 1000 IC ST24W02CB1
IC 80090 83052 043 9300 IC LM393P TID/ 393N RAY
L 32342 81405 232 4900 DR ST 0411-GRP 10UH 10%
L 34517 81405 263 6100 DR 0411 10UH 5%
L 46021 81405 229 0300 DR ST 0411 1,5UH 2%
L 53001 81049 820 5600 FERRITPERLE HF70 BTL 3,5X
L 53002 81049 820 5600 FERRITPERLE HF70 BTL 3,5X
L 53003 81049 820 5600 FERRITPERLE HF70 BTL 3,5X
L 53011 81405 052 4900 DR A AX-GA 10UH 10%
L 53012 09240 114 0400 DROSSEL 1,5 MH/CHOKE COIL
L 53021 29203 122 9700 LINEARITAETSREGLER (70CM)
L 53074 09246 859 5500 BRUECKENSPULE M.KERN
L 55014 09245 816 0100 O/W AUSKOPPELSPULE
L 60006 29701 739 0800 DAEMPFUNGSPERLE UV 930 30
L 61011 81049 820 1400 DAEMPF-PERLE 433003038102
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
FERRITE BEAD
LINEARITY CONTROL
BRIDGE COIL
E/W DECOUPLING COIL
L 61016 81049 820 1400 DAEMPF-PERLE 433003038102
L 61021 81049 820 1400 DAEMPF-PERLE 433003038102
L 61026 81049 820 1400 DAEMPF-PERLE 433003038102
L 61036 81049 820 1400 DAEMPF-PERLE 433003038102
L 61061 81049 820 1400 DAEMPF-PERLE 433003038102
L 61062 81405 050 6500 DR A AX-GA 47UH 5%
L 61066 81049 820 1400 DAEMPF-PERLE 433003038102
L 61067 81405 050 6500 DR A AX-GA 47UH 5%
L 70508 09241 035 9700 STABKERNDROSSEL
L 70555 81405 263 6100 DR 0411 10UH 5%
OK 60031
S 83060 000 1200 OPTOKOPPLER CNY17F1
OK 60046
S 83060 000 1200 OPTOKOPPLER CNY17F1
Q 32305 83824 391 8500 QUARZ 18,432 MHZ
Q 80055 86023 311 5500 KERRES #155 18MHZ RAD
R 21101
S 87053 210 2000 MOW 0411 6,2 OHM 5%
R 21212 87000 075 4900 KSW 0207 1,5 MOHM 5%
R 32315
S 87053 700 9900 MOW 0922 12 KOHM 5%
R 32357
S 87011 210 2700 KSW SI B 12 OHM 5%
R 32359 S 87003 290 4700 KSW NB 0207 82 OHM 5%
R 40013 S 87053 290 7300 MOW 0411 1 KOHM 5%
R 40017 S 87003 290 0700 KSW NB 0207 1,8 OHM 5%
R 40027
S 87003 290 0700 KSW NB 0207 1,8 OHM 5%
R 40031 S 87003 290 3100 KSW NB 0207 18 OHM 5%
R 41016
S 87003 290 2700 KSW NB 0207 12 OHM 5%
R 43004 S 87011 210 1300 KSW SI B 3,3 OHM 5%
R 43098 S 87011 210 1300 KSW SI B 3,3 OHM 5%
R 50007
S 87663 274 0500 MSW 0207 1,5 OHM 1%
R 50008 S 87663 274 0500 MSW 0207 1,5 OHM 1%
R 50027 S 87001 212 0500 KSW 0207 1,5 OHM 5%
R 50029
S 87663 570 5900 MSW 0414 270 OHM 5%
R 52001 S 87053 212 2300 MOW 0411 8,2 OHM 5%
R 52003 S 87350 640 3900 DRW 4 39 OHM 5%
R 52006
S 87053 690 0500 MOW 0617 1,5 OHM 5%
R 53002 S 87001 212 0500 KSW 0207 1,5 OHM 5%
R 53003 S 87001 212 0500 KSW 0207 1,5 OHM 5%
R 53008
S 87003 290 9700 KSW NB 0207 10 KOHM 5%
R 53016 S 87302 800 2100 DRW SI S11 7W 6,8 OHM 5%
R 53021 S 87053 692 5700 MOW 0617 220 OHM 10%
R 54001
S 87350 030 3300 DRW 0,75W 0,33 OHM 10%
R 55012 S 87053 690 6500 MOW 0617 470 OHM 5%
R 55014 S 87012 308 1700 NKS 3 4,7 OHM 5%
R 58001 87650 983 0400 MSW 0207 20 KOHM 2%
R 60008 87301 793 0100 DRW 7 15 KOHM 10%
R 60016
S 87053 700 4300 MOW 0922 56 OHM 5%
R 60029 S 87053 691 1300 MOW 0617 47 KOHM 5%
R 60207 S 87003 290 1700 KSW NB 0207 4,7 OHM 5%
R 60211
S 87650 491 5500 MSW 0414 2,7 MOHM VDE
R 60212 S 87650 491 5300 MSW 0414 2,2 MOHM VDE
R 60212
S 87650 491 5500 MSW 0414 2,7 MOHM VDE
R 61001 87900 500 1700 ESTR.SK10-A 220 OHM LIN
R 61022
S 87322 960 1100 DRW 6,5 2,7 OHM 10% KP296
R 61031 87900 500 2500 ESTR.SK10-A 470 OHM LIN
R 61033
S 87053 700 5800 MOW 0922 100 OHM 10%
R 61041 87900 500 1700 ESTR.SK10-A 220 OHM LIN
R 61313 87900 500 5400 ESTR.SK10-A 22 KOHM LIN
R 62049
S 87663 491 5500 MSW SI 0414 2,7 MOHM 5%
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 72010 800 0000, sowie zusätzlich die eventuell
abweichenden, landesspezifischen Vorschriften!
DAMPING BEAD
DAMPING BEAD
BAR CORE CHOKE COIL
29304 050 8200
29304 050 2900
S 83156 200 6800 SI LOET T2A 250V MST250/2
SI 60001
SI 60201
S 83156 070 2600 SI LOET T100MA 250V
S 83156 190 2800 SI LOET T1,6A 250V
SI 61022
SI 61026
S 83156 210 2700 SI LOET T2,5A 250V
SI 61036 S 83156 210 2700 SI LOET T2,5A 250V
SI 61061 S 83156 202 2500 SI LOET T2A 250V
SI 61066 S 83156 202 2500 SI LOET T2A 250V
T 21211 83034 012 9900 TRANS.BF299 G ITT/PBF259
T 40010 83032 873 6800 TRANS.BC 368
T 50028 83022 105 4400 TRANS BD544B TID/ BD538
T 50029 83022 105 4300 TRANS BD543B TID/ BD537
T 52003 83022 180 4300 TRANS.BDX 43
T 53001 83026 253 3100 TRANS 2SC5331
T 60006 83028 050 5000 TRANS IRFPC50 IRF/ 2SK26
T 60223 83022 690 9100 TRANS.BUZ 90 A TYP 2/3 TY
TR 52001 09245 812 9600 TREIBERUEBERTRAGER
TR 53010
S 29221 033 0100 TRAFO DIODEN-SPLIT DIGI
TR 60001
S 29201 566 9700 TRAFO SPERRWANDLER
TR 60220
S 29201 701 9700 TRAFO STAND-BY
TR 60220S 29201 617 9700 TRAFO SPERRWANDLER KPL
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 72010 800 0000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
TRANSFORMER
DIODE SPLIT TRANSFORMER
B.O.TYPE CONVERTER
TRANSFORMER
29304 050 2900
29304 050 8200
B.O.-TYPE CONVERTER
TRANSFORMER
Page 48
62 GRUNDIG Service
Ersatzteilliste
Spare Parts List
10 / 99
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
0100.000 29504 162 3400 X BAUSTEIN SIGNAL / ZF+TUNER MODULE SIGNAL / IF+TUNER
WW. 29504 162 3600 X BAUSTEIN SIGNAL / ZF+TUNER MODULE SIGNAL / IF+TUNER
0247.000 29303 119 6600 EURO-AV BUCHSENLEISTE 21-POL. SW EURO-AV SOCKET STRIP 21 P BLACK
0248.000 29303 119 6800 EURO-AV BUCHSENLEISTE 21-POL. OR EURO-AV SOCKET STRIP 21 P ORANGE
0400.000
0400.000
0401.000 29504 103 4201 X FEATURE-BOX DIGI BASIC ++ FEATURE-BOX DIGI BASIC ++
0450.000 29700 613 1103 NETZTEILAUFNAHME HOLDER POWER SUPPLY
0451.000 29700 632 0109 HALTER BAUSTEIN HOLDER MODULE
0600.000 29305 108 0700 X GESCHW.-MODULATIONSPLATTE SPEED MODULATION BOARD
0920.000
1070.000 29305 025 3600 DYN.FOKUSSIERUNGSPLATTE DYN.FOCUSING BOARD
2200.000
2400.000 29303 153 0100 2 MONTAGECLIP T53001/60006 MOUNTING CLIP T53001/60006
2410.000 29303 153 0200 MONTAGECLIP IC40020 MOUNTING CLIP IC40020
2420.000 29303 153 1200 3 MONTAGECLIP D53071/53072/60006 MOUNTING CLIP D53071/53072/60006
2430.000 29303 153 1208 10 MONTAGECLIP D61016/61026/61036/ MOUNTING CLIP D61016/61026/61036/
2440.000 29303 153 1605 MONTAGECLIP T52003 MOUNTING CLIP T52003
2450.000 29303 156 1800 2 FOLIE WAERMELEITEND D60006/T60006 FOIL HEAT CONDUCTING D60006/T60006
2460.000 29303 156 2000 11 FOLIE WAERMELEITEND D61016/61026/ FOIL HEAT CONDUCTING
2470.000 29303 156 2100 2 FOLIE WAERMELEITEND D53071/53072 FOIL HEAT CONDUCTING D53071/53072
2480.000 29303 156 2300 FOLIE WAERMELEITEND T53001 FOIL HEAT CONDUCTING T53001
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 40013 84529 961 9000 ELKO 2200UF 20% 35V
C 40031 84529 961 4700 ELKO 1000UF 20% 25V
C 40032 84529 961 4700 ELKO 1000UF 20% 25V
C 40033 84529 961 4700 ELKO 1000UF 20% 25V
C 50012 84529 961 4700 ELKO 1000UF 20% 25V
C 50026 84529 961 4700 ELKO 1000UF 20% 25V
C 53012 85159 116 0200 FOKO FKP1 142PF 2,5% 2000V
C 53071 85159 117 0500 FOKO FKP1 0,014UF 3,5% 2000V
C 60001 86500 811 2500 HV-KERKO 1000PF 20% 1KV
C 60006 86500 670 4600 HV-KERKO 100PF 20% 1KV
C 60009 85159 110 4000 FOKO FKP1 220PF 10% 1600V
C 60012 86500 811 1100 HV-KERKO 270PF 20% 2KV
C 60023 86500 811 2500 HV-KERKO 1000PF 20% 1KV
C 60024 86500 811 2500 HV-KERKO 1000PF 20% 1KV
Ķ
CHASSIS-FS-STEREO DIGI BASIC ++ CUC 1929
CHASSIS TV STEREO DIGI BASIC ++ CUC 1929
d©
29701 096 8100 CHASSIS-FS-STEREO DIGI-BASIC ++ CHASSIS TV STEREO DIGI-BASIC ++
S 29304 050 2900 NETZTEIL STAND BY POWER SUPPLY STAND BY
S 29304 050 8200 NETZTEIL STAND BY POWER SUPPLY STAND BY
S 29303 230 0200 FUNKENSTRECKE 1,6KV SPARK GAP 1.6KV
S 29303 399 5100 NETZ EINBAUGERAETESTECKER APPLIANCE COUPLER W.CABLE
CUC 1929 CUC 1929
KEIN E-TEIL NO SPARE PART
KEIN E-TEIL NO SPARE PART
IC50010/61006/61030/61040/61050 IC50010/61006/61030/61040/61050
T50028/50029 T50028/50029
61036/IC50010/61006/61030/61040/61050/ 61036/IC50010/61006/61030/61040/61050/
T50028/50029/52003 T50028/50029/52003
X = SIEHE GESONDERTE E-LISTE X = SEE SEPARATE PARTS LIST
WW. = WAHLWEISE WW. = OPTIONAL
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 60026 86500 811 2500 HV-KERKO 1000PF 20% 1KV
C 60027 86500 811 2500 HV-KERKO 1000PF 20% 1KV
C 60028 84519 971 2400 ELKO #6 300UF +50-20% 385V
C 60028 84433 060 5900 ELKO 15 300/330UF 385V
C 60224 85159 110 3800 FOKO FKP1 100PF 10% 1600V
C 61004 84529 961 4700 ELKO 1000UF 20% 25V
C 61016 85159 110 3800 FOKO FKP1 100PF 10% 1600V
C 61021 86500 670 4600 HV-KERKO 100PF 20% 1KV
C 61026 86500 670 4600 HV-KERKO 100PF 20% 1KV
C 61032 84529 961 4700 ELKO 1000UF 20% 25V
C 61036 86500 670 4600 HV-KERKO 100PF 20% 1KV
C 61037 84520 970 5700 ELKO 28 1000UF 63V
C 61042 84529 961 0700 ELKO 2200UF 20% 16V
C 61061 86500 670 4600 HV-KERKO 100PF 20% 1KV
MATERIAL-NR. / PART NO.: 29701 096 8100
TV
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 61064 84529 961 5000 ELKO 2200UF 20% 25V
C 61066 86500 670 4600 HV-KERKO 100PF 20% 1KV
C 62021
S 86600 982 3800 SI-KERKO B-SS 2200PF 20%
S 86600 982 3800 SI-KERKO B-SS 2200PF 20%
C 62022
C 62048
S 86600 982 3400 SI-KERKO B-SS 1000PF 20%
C 64006 85159 116 0100 FKP1 150PF +0-10% 2000V
C 70509 84529 961 4700 ELKO 1000UF 20% 25V
CD 21221 83250 041 4800 SMD DIODE LS 4148
CD 21222 83250 041 4800 SMD DIODE LS 4148
CD 21231 83250 041 4800 SMD DIODE LS 4148
CD 21232 83250 041 4800 SMD DIODE LS 4148
CD 32315 83094 553 3100 MELF Z-DIODE 33B 0,5W
CD 34513 83250 041 4800 SMD DIODE LS 4148
CD 34517 83250 041 4800 SMD DIODE LS 4148
CD 40008 83094 551 0100 MELF-Z DIODE 10 B 0,5W
CD 40015 83250 041 4800 SMD DIODE LS 4148
CD 41011 83250 041 4800 SMD DIODE LS 4148
CD 43025 83250 041 4800 SMD DIODE LS 4148
CD 52003 83250 041 4800 SMD DIODE LS 4148
CD 53019 83250 041 4800 SMD DIODE LS 4148
CD 55003 83094 550 4400 MELF Z-DIODE 4,3 B 0,5W
CD 55004 83250 041 4800 SMD DIODE LS 4148
CD 58001 83250 041 4800 SMD DIODE LS 4148
CD 58004 83250 041 4800 SMD DIODE LS 4148
CD 58007 83094 550 2800 MELF Z-DIODE 2,7 B 0,5W
CD 58011 83250 041 4800 SMD DIODE LS 4148
CD 58012 83250 041 4800 SMD DIODE LS 4148
CD 58021 83250 041 4800 SMD DIODE LS 4148
CD 58022 83250 041 4800 SMD DIODE LS 4148
CD 60201 83250 041 4800 SMD DIODE LS 4148
CD 60202 83250 041 4800 SMD DIODE LS 4148
CD 60223 83250 041 4800 SMD DIODE LS 4148
CD 70501 83094 550 5200 MELF-Z DIODE 5,1 B 0,5W
CD 70506 83250 041 4800 SMD DIODE LS 4148
CD 70507 83250 041 4800 SMD DIODE LS 4148
CD 70517 83250 041 4800 SMD DIODE LS 4148
CD 70521 83094 550 5200 MELF-Z DIODE 5,1 B 0,5W
CD 70522 83094 550 3300 MELF-Z DIODE 3,3 C 0,5W
CD 70523 83250 041 4800 SMD DIODE LS 4148
CD 70553 83250 041 4800 SMD DIODE LS 4148
CD 80060 83250 041 4800 SMD DIODE LS 4148
CD 80081 83250 041 4800 SMD DIODE LS 4148
CD 80085 83250 041 4800 SMD DIODE LS 4148
CD 80091 83094 550 3400 MELF Z-DIODE 3,3 B 0,5W
CD 81004 83250 041 4800 SMD DIODE LS 4148
CIC43010 83058 145 5100 SMD IC MC14551BD/R2
CT 21221 83010 068 4800 SMD-TRANS.BC 848 C
CT 21233 83010 068 4800 SMD-TRANS.BC 848 C
CT 32308 83010 038 5800 SMD TRANS BC858B
CT 32310 83010 038 5800 SMD TRANS BC858B
CT 32312 83010 038 5800 SMD TRANS BC858B
CT 32315 83010 038 5800 SMD TRANS BC858B
CT 40010 83010 048 4800 SMD-TRANS.BC 848 B
CT 43060 83010 048 4800 SMD-TRANS.BC 848 B
CT 43088 83010 048 4800 SMD-TRANS.BC 848 B
CT 43089 83010 038 5800 SMD TRANS BC858B
CT 43091 83010 038 5800 SMD TRANS BC858B
CT 43092 83010 048 4800 SMD-TRANS.BC 848 B
CT 43093 83010 048 4800 SMD-TRANS.BC 848 B
CT 43094 83010 048 4800 SMD-TRANS.BC 848 B
CT 43095 83010 048 4800 SMD-TRANS.BC 848 B
CT 46005 83010 048 4800 SMD-TRANS.BC 848 B
CT 58012 83010 048 4800 SMD-TRANS.BC 848 B
CT 60203 83010 048 4800 SMD-TRANS.BC 848 B
CT 60206 83010 068 5800 SMD-TRANS.BC 858 C
CT 60213 83010 038 5800 SMD TRANS BC858B
CT 61301 83010 048 4800 SMD-TRANS.BC 848 B
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
CT 61316 83010 048 4800 SMD-TRANS.BC 848 B
CT 70505 83010 048 4800 SMD-TRANS.BC 848 B
CT 70520 83010 068 4800 SMD-TRANS.BC 848 C
CT 70525 83010 068 5800 SMD-TRANS.BC 858 C
CT 80002 83010 068 5800 SMD-TRANS.BC 858 C
CT 80085 83010 038 5800 SMD TRANS BC858B
CT 81001 83010 048 4800 SMD-TRANS.BC 848 B
CT 81004 83010 048 4800 SMD-TRANS.BC 848 B
D 21212 83092 150 2000 DIODE 1 N 4004
D 32356 83092 150 2000 DIODE 1 N 4004
D 32357 83092 150 2000 DIODE 1 N 4004
D 40006
S 83092 150 2000 DIODE 1 N 4004
D 50013 83095 162 8300 DIODE BYV 28-200
D 52006 83092 150 2000 DIODE 1 N 4004
D 53008 83092 010 0500 DIODE BA157
D 53019 83097 090 0300 Z DIODE ZY 51
D 53071 83092 043 5900 DIODE BY359 1500
D 53072 83092 042 3000 DIODE BY 229-600
D 54001 83092 010 0500 DIODE BA157
D 55012 83097 203 3300 Z DIODE 33 C 0,5W
D 60006 83098 208 8000 DIODE MUR 880
D 60012 83095 167 5400 DIODE BYT53B
D 60014 83092 000 2100 DIODE BAV21
D 60023 83085 605 2000 GLR.B 380 C 3700/2200
D 60202 83097 201 3100 Z DIODE 13 B 0,5W
D 60203 83097 200 8300 Z DIODE 8,2 B 0,5W
D 60207 83092 150 2000 DIODE 1 N 4004
D 60208 83092 150 2000 DIODE 1 N 4004
D 60216 83092 000 2100 DIODE BAV21
D 60217 83092 011 5900 DIODE BA159
D 60218
S 83096 631 8000 Z-DIODE BZT03D180
D 60221 83092 011 5900 DIODE BA159
D 60222 S 83096 631 8000 Z-DIODE BZT03D180
D 60223
S 83096 631 8000 Z-DIODE BZT03D180
D 61001 83095 167 5400 DIODE BYT53B
D 61011 83095 160 3800 DIODE BYV38
D 61012 83095 160 3800 DIODE BYV38
D 61016 83098 208 8000 DIODE MUR 880
D 61021
S 83095 171 7200 DIODE BYW172D
D 61026 83098 208 4000 DIODE MUR 840/BYV 29-400/
D 61033 83092 150 2000 DIODE 1 N 4004 -GA
D 61036 83098 208 4000 DIODE MUR 840/BYV 29-400/
D 61061
S 83095 171 7200 DIODE BYW172D
D 61066 S 83095 171 7200 DIODE BYW172D
D 64011 83092 000 2100 DIODE BAV21
D 64012 83092 000 2100 DIODE BAV21
D 64013 83092 000 2100 DIODE BAV21
D 64014 83092 000 2100 DIODE BAV21
D 70508 83097 201 1600 Z-DIODE 15 C 0,5W
IC 32300 83057 954 1000 SMD IC MSP3410B-PS PLCC
IC 32310 83052 057 0000 IC 78M05 2%
IC 34510 83053 347 8000 IC TDA4780V3/ V4
IC 40020 83053 372 6100 IC TDA7262
IC 41010 83053 330 0600 IC TDA3006
IC 43080 83053 664 2500 IC TEA6425
IC 50010 83053 441 7300 IC TDA4173AF
IC 55010 83053 381 4500 IC TDA8145
IC 58010 83052 043 9300 IC LM393P
IC 60010 83053 546 0500 IC TDA4605/3
IC 60220 83053 615 0100 IC TEA1501 N1
IC 61001 83052 043 1700 IC LM317T
IC 61006 83052 043 1700 IC LM317T
IC 61030 83052 043 1700 IC LM317T
IC 61040 83052 043 5000 IC LM350T
IC 61050 83052 043 1700 IC LM317T
IC 61310 83052 043 5700 IC LM358N
IC 80040 83052 100 6500 IC MC33164P-5RP
IC 80050 83051 585 5000 SMD IC SDA5250D12
Ersatzteillisten / Spare Parts Lists CUC 1830 / 1836 / 1929
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Page 49
GRUNDIG Service 63
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
IC 80060 19798 318 3200 IC 27C040-150NS PROG.KPL
IC 80065 83051 240 0800 IC M24C08B1/ M24C08-BN6
IC 80070 83056 024 1000 IC ST24W02CB1/ M24C02-BN6
IC 80090 83052 043 9300 IC LM393P
L 32342 81405 232 4900 DR ST 0411-GRP 10UH 10%
L 34517 81405 263 6100 DR 0411 10UH 5%
L 46021 81405 229 0300 DR ST 0411 1,5UH 2%
L 53001 81049 820 5600 FERRITPERLE HF70 BTL 3,5X6
L 53002 81049 820 5600 FERRITPERLE HF70 BTL 3,5X6
L 53003 81049 820 5600 FERRITPERLE HF70 BTL 3,5X6
L 53011 81405 052 4900 DR A AX-GA 10UH 10%
L 53012 09240 114 0400 DROSSEL 1,5 MH/CHOKE COIL
L 53021 29203 122 9700 LINEARITAETSREGLER (70CM)
L 53074 09246 859 6300 SPULE BRUECKE M.KERN
L 55014 09245 816 0100 O/W AUSKOPPELSPULE
L 60006 29701 739 0800 DAEMPFUNGSPERLE UV
L 61011 81049 820 1400 DAEMPF-PERLE
L 61016 81049 820 1400 DAEMPF-PERLE
L 61021 81049 820 1400 DAEMPF-PERLE
L 61026 81049 820 1400 DAEMPF-PERLE
L 61036 81049 820 1400 DAEMPF-PERLE
L 61061 81049 820 1400 DAEMPF-PERLE
L 61062 81405 050 6500 DR A AX-GA 47UH 5%
L 61066 81049 820 1400 DAEMPF-PERLE
L 61067 81405 050 6500 DR A AX-GA 47UH 5%
L 70508 09241 035 9700 STABKERNDROSSEL
L 70555 81405 263 6100 DR 0411 10UH 5%
OK 60031
S83060 000 1200 OPTOKOPPLER CNY17F1
OK 60046 S83060 000 1200 OPTOKOPPLER CNY17F1
Q 32305 83824 391 8500 QUARZ 18,432 MHZ
Q 80055 86023 311 5500 KERRES #155 18MHZ
R 21101
S 87053 210 2000 MOW 0411 6,2 OHM 5%
R 32315 S 87053 700 9900 MOW 0922 12 KOHM 5%
R 32357
S 87011 210 2700 KSW SI B 12 OHM 5%
R 32359 S 87003 290 4700 KSW NB 0207 82 OHM 5%
R 40013 S 87053 290 7300 MOW 0411 1 KOHM 5%
R 40017
S 87003 290 0700 KSW NB 0207 1,8 OHM 5%
R 40027 S 87003 290 0700 KSW NB 0207 1,8 OHM 5%
R 40031
S 87003 290 3100 KSW NB 0207 18 OHM 5%
R 41016 S 87003 290 2700 KSW NB 0207 12 OHM 5%
R 43004 S 87011 210 1300 KSW SI B 3,3 OHM 5%
R 43098
S 87011 210 1300 KSW SI B 3,3 OHM 5%
R 50007 S 87663 274 1000 MSW 0207 2,4 OHM 1%
R 50008 S 87663 274 1000 MSW 0207 2,4 OHM 1%
R 50027
S 87001 212 0500 KSW 0207 1,5 OHM 5%
R 50029 S 87663 570 5900 MSW 0414 270 OHM 5%
R 52001 S 87053 290 1700 MOW 0411 4,7 OHM 5%
R 52003
S 87350 640 3900 DRW 4 39 OHM 5%
R 52006 S 87053 690 0100 MOW 0617 1 OHM 5%
R 53002 S 87001 212 0500 KSW 0207 1,5 OHM 5%
R 53003
S 87001 212 0500 KSW 0207 1,5 OHM 5%
R 53008 S 87003 290 9700 KSW NB 0207 10 KOHM 5%
R 53011 87052 270 2100 MOW 0411 6,8 OHM 5%
R 53016
S 87302 800 2100 DRW SI S11 7W 6,8 OHM 5%
R 53021 S 87053 690 6300 MOW 0617 390 OHM 5%
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 72010 800 0000, sowie zusätzlich die eventuell
abweichenden, landesspezifischen Vorschriften!
FERRITE BEAD
LINEARITY CONTROL
BRIDGE COIL
E/W DECOUPLING COIL
DAMPING BEAD
DAMPING BEAD
BAR CORE CHOKE COIL
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
S 87350 030 3300 DRW 0,75W 0,33 OHM 10%
R 54001
R 55012
S 87053 690 6500 MOW 0617 470 OHM 5%
R 55014 S 87012 308 1700 NKS 3 4,7 OHM 5%
R 60001 87000 691 3100 KSW 0617 270 KOHM
R 60002 87000 691 4100 KSW 0617 680 KOHM
R 60008 87301 793 0100 DRW 7 15 KOHM 10%
R 60012 87000 490 4100 KSW 0411 47 OHM 5%
R 60016
S 87053 700 4300 MOW 0922 56 OHM 5%
R 60028 87650 441 2700 MSW 0414 180 KOHM 5%
R 60029
S 87053 691 1300 MOW 0617 47 KOHM 5%
R 60207 S 87003 290 1700 KSW NB 0207 4,7 OHM 5%
R 60211 S 87650 491 5500 MSW 0414 2,7 MOHM VDE
R 60212 S 87650 491 5300 MSW 0414 2,2 MOHM VDE
R 60212
S 87650 491 5500 MSW 0414 2,7 MOHM VDE
R 61001 87900 500 1700 ESTR.SK10-A 220 OHM LIN
R 61018 87052 213 2100 MOW 0411 100 KOHM 10%
R 61022
S 87322 960 1100 DRW 6,5 2,7 OHM 10%
R 61031 87900 500 2500 ESTR.SK10-A 470 OHM LIN
R 61033
S 87053 700 5800 MOW 0922 100 OHM 10%
R 61041 87900 500 1700 ESTR.SK10-A 220 OHM LIN
R 61313 87900 500 5400 ESTR.SK10-A 22 KOHM LIN
R 62049
S 87663 491 5500 MSW SI 0414 2,7 MOHM 5%
R 65541 83112 120 7000 PTC C 890 A120-A70
R 65542
S 87053 690 7300 MOW 0617 1 KOHM 5%
SI 60001
S 83156 200 6800 SI LOET T2A 250V
SI 60201 S 83156 070 2600 SI LOET T100MA 250V
SI 61022
S 83156 190 2800 SI LOET T1,6A 250V
SI 61026 S 83156 210 2700 SI LOET T2,5A 250V
SI 61036 S 83156 210 2700 SI LOET T2,5A 250V
SI 61061 S 83156 202 2500 SI LOET T2A 250V
SI 61066
S 83156 202 2500 SI LOET T2A 250V
T 40010 83032 873 6800 TRANS.BC 368
T 50028 83022 105 4400 TRANS BD544B
T 50029 83022 105 4300 TRANS BD543B
T 52003 83022 180 4300 TRANS.BDX 43
T 53001 83026 253 3100 TRANS 2SC5331
T 60006 83028 050 5000 TRANS IRFPC50
T 60223 83022 690 9100 TRANS.BUZ 90 A TYP 2/3
T 64016 83032 876 3900 TRANS.BC 639
TR 52001 09246 867 9700 UEBERTRAGER VOGT
TR 53010
S29201 680 0100 TRAFO DIODEN-SPLIT DIGI
TR 60001
S29201 573 9700 TRAFO SPERRWANDLER
TR 60220 S 29201 617 9700 TRAFO SPERRWANDLER KPL
TR 60220
S29201 701 9700 TRAFO STAND-BY
TR 64001
S29201 447 9700 FOKUSSIERUEBERTRAGER
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 72010 800 0000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
29304 050 8200
29304 050 2900
TRANSFORMER
DIODE SPLIT TRANSFORMER
29304 050 8200
B.O.-TYPE CONVERTER
TRANSFORMER
29305 050 2900
FOCUS TRANSFORMER
Ersatzteilliste
Spare Parts List
3 / 2000
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
29701 096 8300 CHASSIS-FS-STEREO CHASSIS TV STEREO
0200.000 29524 162 3400 X BAUSTEIN SIGNAL/ZF+TUNER MODULE SIGNAL/IF+TUNER
0200.000 29524 162 3600 X BAUSTEIN SIGNAL/ZF+TUNER MODULE SIGNAL/IF+TUNER
0247.000 29303 119 6600 EURO-AV BUCHSENLEISTE 21-POL SW EURO-AV SOCKET STRIP 21 P BLACK
0247.000 29303 119 6800 EURO-AV BUCHSENLEISTE 21-POL OR EURO-AV SOCKET STRIP 21 P ORANGE
0400.000 29504 103 4201 X FEATURE-BOX DIGI BASIC ++ FEATURE-BOX DIGI BASIC ++
0400.000
S 29304 050 2900 NETZTEIL STAND BY POWER SUPPLY STAND BY
WW.
S 29304 050 8200 NETZTEIL STAND BY POWER SUPPLY STAND BY
0450.000 29700 613 1103 NETZTEILAUFNAHME HOLDER POWER SUPPLY
0451.000 29700 632 0109 HALTER BAUSTEIN HOLDER MODULE
2200.000
S 29303 399 5100 NETZ EINBAUGERAETESTECKER APPLIANCE COUPLER W.CABLE
2400.000 29303 153 0100 2 MONTAGECLIP T60006/53001 MOUNTING CLIP T60006/53001
2410.000 29303 153 0200 MONTAGECLIP IC40020 MOUNTING CLIP IC40020
2430.000 29303 153 1200 3 MONTAGECLIP D53071/53072/60002 MOUNTING CLIP D53071/53072/60002
2430.000 29303 153 1208 9 MONTAGECLIP D61016/61026/61036/ MOUNTING CLIP D61016/61026/61036/
2440.000 29303 153 1605 MONTAGECLIP T52003 MOUNTING CLIP T52003
2450.000 29303 156 2300 FOLIE WAERMELEITEND T53001 FOIL HEAT CONDUCTING T53001
2460.000 29303 156 1800 FOLIE WAERMELEITEND D60006 FOIL HEAT CONDUCTING D60006
2470.000 29303 156 2000 9 FOLIE WAERMELEITEND D6006/61036/ FOIL HEAT CONDUCTING D6006/61036/
2480.000 29303 156 2100 2 FOLIE WAERMELEITEND T53071/53072 FOIL HEAT CONDUCTING T53071/53072
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 40013 84529 961 9000 ELKO 2200UF 20% 35V
C 40031 84529 961 4700 ELKO 1000UF 20% 25V
C 40032 84529 961 4700 ELKO 1000UF 20% 25V
C 40033 84529 961 4700 ELKO 1000UF 20% 25V
C 50012 84529 961 4700 ELKO 1000UF 20% 25V
C 50026 84529 961 4700 ELKO 1000UF 20% 25V
C 53012 85159 116 0200 FOKO FKP1 142PF 2,5% 2000V
C 53071 85159 117 0300 FOKO FKP1 0,013UF 3,5% 2000V
C 60001 86500 811 2500 KERKO HV C 1000PF 20% 1KV
C 60006 86500 670 4600 KERKO HV C 100PF 20% 1KV
C 60009 85159 110 4000 FOKO FKP1 220PF 10% 1600V
C 60012 86500 811 1100 KERKO HV C 270PF 20% 2KV
C 60023 86500 811 2500 KERKO HV C 1000PF 20% 1KV
C 60024 86500 811 2500 KERKO HV C 1000PF 20% 1KV
C 60026 86500 811 2500 KERKO HV C 1000PF 20% 1KV
C 60027 86500 811 2500 KERKO HV C 1000PF 20% 1KV
C 60028 84433 060 5900 ELKO 15 300/330UF 385V MA
C 60028 84519 971 2400 ELKO #6 300UF +50-20% 385V
C 60224 85159 110 3800 FOKO FKP1 100PF 10% 1600V
C 61004 84529 961 4700 ELKO 1000UF 20% 25V
CHASSIS-FS-STEREO CUC 1836 DIGI BASIC ++/INL 4:3
CHASSIS TV STEREO CUC 1836 DIGI BASIC ++/INL 4:3
d©
CUC 1836 DIGI BASIC ++/INL 4:3 CUC 1836 DIGI BASIC ++/INL 4:3
KEIN E-TEIL NO SPARE PART
IC50010/61001/61006/61040/ IC50010/61001/61006/61040/
T50028/50029 T50028/50029
IC 50010/61001/61006/61040/ IC 50010/61001/61006/61040/
T50028/50029/52003 T50028/50029/52003
X = SIEHE GESONDERTE E-LISTE X = SEE SEPARATE PARTS LIST
WW. = WAHLWEISE WW. = OPTIONAL
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 61016 85159 110 3800 FOKO FKP1 100PF 10% 1600V
C 61021 86500 670 4600 KERKO HV C 100PF 20% 1KV
C 61026 86500 670 4600 KERKO HV C 100PF 20% 1KV
C 61032 84529 961 4700 ELKO 1000UF 20% 25V
C 61036 86500 670 4600 KERKO HV C 100PF 20% 1KV
C 61037 84520 970 5700 ELKO 28 1000UF 63V
C 61042 84529 961 0700 ELKO 2200UF 20% 16V
C 61061 86500 670 4600 KERKO HV C 100PF 20% 1KV
C 61066 86500 670 4600 KERKO HV C 100PF 20% 1KV
C 62021
S 86600 982 3800 SI-KERKO B-SS 2200PF 20% 400V
C 62022
S 86600 982 3800 SI-KERKO B-SS 2200PF 20% 400V
C 62048 S 86600 982 3400 SI-KERKO B-SS 1000PF 20% 400V
C 70509 84529 961 4700 ELKO 1000UF 20% 25V
CD 21201 83250 041 4800 SMD DIODE LS 4148
CD 21202 83250 041 4800 SMD DIODE LS 4148
CD 21203 83250 041 4800 SMD DIODE LS 4148
CD 21206 83253 131 0300 MELF DIODE BAV103
CD 32315 83094 553 3100 MELF Z-DIODE 33B 0,5W
CD 34513 83250 041 4800 SMD DIODE LS 4148
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Ķ
TV
MATERIAL-NR. / PART NO.: 29701 096 8300
CUC 1830 / 1836 / 1929 Ersatzteillisten / Spare Parts Lists
Page 50
64 GRUNDIG Service
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
Ersatzteillisten / Spare Parts Lists CUC 1830 / 1836 / 1929
CD 34517 83250 041 4800 SMD DIODE LS 4148
CD 40008 83094 551 0100 MELF-Z DIODE 10 B 0,5W
CD 40015 83250 041 4800 SMD DIODE LS 4148
CD 41011 83250 041 4800 SMD DIODE LS 4148
CD 43025 83250 041 4800 SMD DIODE LS 4148
CD 52003 83250 041 4800 SMD DIODE LS 4148
CD 53019 83250 041 4800 SMD DIODE LS 4148
CD 55003 83094 550 4000 MELF-Z DIODE 3,9 B 0,5W
CD 55004 83250 041 4800 SMD DIODE LS 4148
CD 58001 83250 041 4800 SMD DIODE LS 4148
CD 58004 83250 041 4800 SMD DIODE LS 4148
CD 58007 83094 550 2800 MELF Z-DIODE 2,7 B 0,5W
CD 58011 83250 041 4800 SMD DIODE LS 4148
CD 58012 83250 041 4800 SMD DIODE LS 4148
CD 58021 83250 041 4800 SMD DIODE LS 4148
CD 58022 83250 041 4800 SMD DIODE LS 4148
CD 60201 83250 041 4800 SMD DIODE LS 4148
CD 60202 83250 041 4800 SMD DIODE LS 4148
CD 60223 83250 041 4800 SMD DIODE LS 4148
CD 70501 83094 550 5200 MELF-Z DIODE 5,1 B 0,5W
CD 70506 83250 041 4800 SMD DIODE LS 4148
CD 70507 83250 041 4800 SMD DIODE LS 4148
CD 70517 83250 041 4800 SMD DIODE LS 4148
CD 70553 83250 041 4800 SMD DIODE LS 4148
CD 80060 83250 041 4800 SMD DIODE LS 4148
CD 80081 83250 041 4800 SMD DIODE LS 4148
CD 80085 83250 041 4800 SMD DIODE LS 4148
CD 80091 83094 550 3400 MELF Z-DIODE 3,3 B 0,5W
CD 81004 83250 041 4800 SMD DIODE LS 4148
CIC 4301083058 145 5100 SMD IC MC14551BD/R2
CT 32308 83010 038 5800 SMD TRANS BC858B/ BC857B
CT 32310 83010 038 5800 SMD TRANS BC858B/ BC857B
CT 32312 83010 038 5800 SMD TRANS BC858B/ BC857B
CT 32315 83010 038 5800 SMD TRANS BC858B/ BC857B
CT 40010 83010 048 4800 SMD TRANS BC848B/ BC847B
CT 43060 83010 048 4800 SMD TRANS BC848B/ BC847B
CT 43088 83010 048 4800 SMD TRANS BC848B/ BC847B
CT 43089 83010 038 5800 SMD TRANS BC858B/ BC857B
CT 43091 83010 038 5800 SMD TRANS BC858B/ BC857B
CT 43092 83010 048 4800 SMD TRANS BC848B/ BC847B
CT 43093 83010 048 4800 SMD TRANS BC848B/ BC847B
CT 43094 83010 048 4800 SMD TRANS BC848B/ BC847B
CT 43095 83010 048 4800 SMD TRANS BC848B/ BC847B
CT 46005 83010 048 4800 SMD TRANS BC848B/ BC847B
CT 58012 83010 048 4800 SMD TRANS BC848B/ BC847B
CT 60203 83010 048 4800 SMD TRANS BC848B/ BC847B
CT 60206 83010 068 5800 SMD TRANS BC858C/ BC857C
CT 60213 83010 038 5800 SMD TRANS BC858B/ BC857B
CT 61301 83010 048 4800 SMD TRANS BC848B/ BC847B
CT 61316 83010 048 4800 SMD TRANS BC848B/ BC847B
CT 70505 83010 048 4800 SMD TRANS BC848B/ BC847B
CT 80002 83010 068 5800 SMD TRANS BC858C/ BC857C
CT 80085 83010 038 5800 SMD TRANS BC858B/ BC857B
CT 81001 83010 048 4800 SMD TRANS BC848B/ BC847B
CT 81004 83010 048 4800 SMD TRANS BC848B/ BC847B
D 21212 83092 150 2000 DIODE 1 N 4004
D 32356 83092 150 2000 DIODE 1 N 4004
D 32357 83092 150 2000 DIODE 1 N 4004
D 40006
S 83092 150 2000 DIODE 1 N 4004
D 50013 83095 162 8300 DIODE BYV 28-200
D 52006 83092 150 2000 DIODE 1 N 4004
D 53008 83092 010 0500 DIODE BA157
D 53019 83097 090 0300 Z DIODE ZY 51
D 53071 83092 043 5900 DIODE BY359 1500
D 53072 83092 042 3000 DIODE BY 229-600
D 54001 83092 010 0500 DIODE BA157
D 55012 83097 203 3300 Z DIODE 33 C 0,5W
D 60006 83098 208 8000 DIODE MUR 880 WW.BYT 08 P
D 60012 83095 167 5400 DIODE BYT53B/ EGP10B
D 60014 83092 000 2100 DIODE BAV21
D 60023 83085 605 2000 GLR.B 380 C 3700/2200
D 60202 83097 201 3100 Z DIODE 13 B 0,5W
D 60203 83097 200 8300 Z DIODE 8,2 B 0,5W
D 60207 83092 150 2000 DIODE 1 N 4004
D 60208 83092 150 2000 DIODE 1 N 4004
D 60216 83092 000 2100 DIODE BAV21
D 60217 83092 011 5900 DIODE BA159
S 83096 631 8000 Z-DIODE BZT03D180
D 60218
D 60221 83092 011 5900 DIODE BA159
D 60222
S 83096 631 8000 Z-DIODE BZT03D180
D 60223 S 83096 631 8000 Z-DIODE BZT03D180
D 61001 83095 167 5400 DIODE BYT53B/ EGP10B
D 61001 83095 167 5400 DIODE BYT53B/ EGP10B
D 61011 83095 160 3800 DIODE BYV38
D 61012 83095 160 3800 DIODE BYV38
D 61016 83098 208 8000 DIODE MUR 880 WW.BYT 08 P
D 61021
S 83095 171 7200 DIODE BYW172D
D 61026 83098 208 4000 DIODE MUR 840/ BYV 29-400
D 61033 83092 150 2000 DIODE 1 N 4004
D 61036 83098 208 4000 DIODE MUR 840/ BYV 29-400
D 61061
S 83095 171 7200 DIODE BYW172D
D 61066 S 83095 171 7200 DIODE BYW172D
D 70508 83097 201 1600 Z-DIODE 15 C 0,5W
IC 32300 83057 954 1000 SMD IC MSP3410B-PS
IC 32310 83052 057 0000 IC 78M05 2%
IC 34510 83053 347 8000 IC TDA4780V3/ V4
IC 40020 83053 372 6100 IC TDA7262
IC 40020 83053 372 6100 IC TDA7262
IC 41010 83053 330 0600 IC TDA3006
IC 43080 83053 664 2500 IC TEA6425
IC 50010 83053 441 7300 IC TDA4173AF
IC 55010 83053 381 4500 IC TDA8145
IC 58010 83052 043 9300 IC LM393P/ 393N RAY/M
IC 60010 83053 546 0500 IC TDA4605/3
IC 60220 83053 615 0100 IC TEA1501 N1
IC 61001 83052 043 1700 IC LM317T
IC 61006 83052 043 1700 IC LM317T
IC 61030 83052 043 1700 IC LM317T
IC 61040 83052 043 5000 IC LM350T
IC 61310 83052 043 5700 IC LM358N
IC 80040 83052 100 6500 IC MC33164P-5RP/ TS831-5I
IC 80050 83051 585 5000 SMD IC SDA5250D12
IC 80060 19798 318 3300 IC 27C040-150NS PROG.KPL
IC 80065 83051 240 0800 IC M24C08B1/ M24C08-BN6
IC 80070 83056 024 1000 IC ST24W02CB1/ M24C02-BN6
IC 80090 83052 043 9300 IC LM393P/ 393N RAY/M
L 32342 81405 232 4900 DR ST 0411-GRP 10UH 10%
L 34517 81405 263 6100 DR 0411 10UH 5%
L 46021 81405 229 0300 DR ST 0411 1,5UH 2%
L 53001 81049 820 5600 FERRITPERLE HF70 BTL 3,5X
L 53002 81049 820 5600 FERRITPERLE HF70 BTL 3,5X
L 53003 81049 820 5600 FERRITPERLE HF70 BTL 3,5X
L 53011 81405 052 4900 DR A AX-GA 10UH 10%
L 53012 09240 114 0400 DROSSEL 1,5 MH
L 53021 29203 122 9700 LINEARITAETSREGLER
L 53074 09246 859 6100 BRUECKENSPULE M.KERN
L 55014 09245 816 0100 O/W AUSKOPPELSPULE
L 60006 29701 739 0800 DAEMPFUNGSPERLE UV 930 30
L 61011 81049 820 1400 DAEMPF-PERLE 433003038102
L 61016 81049 820 1400 DAEMPF-PERLE 433003038102
L 61021 81049 820 1400 DAEMPF-PERLE 433003038102
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
FERRITE BEAD
LINEARITY CONTROL
BRIDGE COIL
E/W DECOUPLING COIL
L 61026 81049 820 1400 DAEMPF-PERLE 433003038102
L 61036 81049 820 1400 DAEMPF-PERLE 433003038102
L 61061 81049 820 1400 DAEMPF-PERLE 433003038102
L 61062 81405 050 6500 DR A AX-GA 47UH 5%
L 61066 81049 820 1400 DAEMPF-PERLE 433003038102
L 61067 81405 050 6500 DR A AX-GA 47UH 5%
L 70508 09241 035 9700 STABKERNDROSSEL
L 70555 81405 263 6100 DR 0411 10UH 5%
OK 60031
S 83060 000 1200 OPTOKOPPLER CNY17F1/ CNY1
OK 60046S 83060 000 1200 OPTOKOPPLER CNY17F1/ CNY1
Q 32305 83824 391 8500 QUARZ 18,432 MHZ
Q 80055 86023 311 5500 KERRES #155 18MHZ
R 21101
S 87053 210 2000 MOW 0411 6,2 OHM 5%
R 32315 S 87053 700 9900 MOW 0922 12 KOHM 5%
R 32357
S 87011 210 2700 KSW SI B 12 OHM 5%
R 32359 S 87003 290 4700 KSW NB 0207 82 OHM 5%
R 40013
S 87053 290 7300 MOW 0411 1 KOHM 5%
R 40017 S 87003 290 0700 KSW NB 0207 1,8 OHM 5%
R 40027 S 87003 290 0700 KSW NB 0207 1,8 OHM 5%
R 40031
S 87003 290 3100 KSW NB 0207 18 OHM 5%
R 41016 S 87003 290 2700 KSW NB 0207 12 OHM 5%
R 43004 S 87011 210 1300 KSW SI B 3,3 OHM 5%
R 43098
S 87011 210 1300 KSW SI B 3,3 OHM 5%
R 50007 S 87663 274 0500 MSW 0207 1,5 OHM 1%
R 50008
S 87663 274 0500 MSW 0207 1,5 OHM 1%
R 50027 S 87001 212 0500 KSW 0207 1,5 OHM 5%
R 50029 S 87663 570 5900 MSW 0414 270 OHM 5%
R 52001 S 87053 212 2300 MOW 0411 8,2 OHM 5%
R 52003
S 87350 640 3900 DRW 4 39 OHM 5%
R 52006 S 87053 690 0300 MOW 0617 1,2 OHM 5%
R 53002 S 87001 212 0500 KSW 0207 1,5 OHM 5%
R 53003
S 87001 212 0500 KSW 0207 1,5 OHM 5%
R 53008 S 87003 290 9700 KSW NB 0207 10 KOHM 5%
R 53011 87052 270 2100 MOW 0411 6,8 OHM 5%
R 53016
S 87302 800 2100 DRW SI S11 7W 6,8 OHM 5%
R 53021 S 87053 690 6300 MOW 0617 390 OHM 5%
R 54001
S 87350 030 3300 DRW 0,75W 0,33 OHM 10%
R 55012 S 87053 690 6500 MOW 0617 470 OHM 5%
R 55014 S 87012 308 1700 NKS 3 4,7 OHM 5%
R 58001 87650 983 0400 MSW 0207 20 KOHM 2%
R 60001 87000 691 3100 KSW 0617 270 KOHM .
R 60002 87000 691 4100 KSW 0617 680 KOHM
R 60008 87301 793 0100 DRW 7 15 KOHM 10%
R 60012 87000 490 4100 KSW 0411 47 OHM 5%
R 60016
S 87053 700 4300 MOW 0922 56 OHM 5%
R 60028 87650 441 2700 MSW 0414 180 KOHM 5%
R 60029
S 87053 691 1300 MOW 0617 47 KOHM 5%
R 60207 S 87003 290 1700 KSW NB 0207 4,7 OHM 5%
R 60211
S 87650 491 5500 MSW SI 0414 2,7 MOHM VDE
R 60212 S 87650 491 5500 MSW SI 0414 2,7 MOHM VDE
R 60212 87650 491 5300 MSW SI 0414 2,2 MOHM VDE
R 61001 87900 500 1700 ESTR.SK10-A 220 OHM LIN
R 61018 87052 213 2100 MOW 0411 100 KOHM 10%
R 61022
S 87322 960 1100 DRW 6,5 2,7 OHM 10%
R 61031 87900 500 2500 ESTR.SK10-A 470 OHM LIN
R 61033
S 87053 700 5800 MOW 0922 100 OHM 10%
R 61041 87900 500 1700 ESTR.SK10-A 220 OHM LIN
R 61313 87900 500 5400 ESTR.SK10-A 22 KOHM LIN
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 72010 800 0000, sowie zusätzlich die eventuell
abweichenden, landesspezifischen Vorschriften!
DAMPING BEAD
DAMPING BEAD
BAR CORE CHOKE COIL
29304 050 2900
29304 050 82
S 87663 491 5500 MSW SI 0414 2,7 MOHM 5%
R 62049
SI 60001
S 83156 200 6800 SI LOET T2A 250V MST250/2
S 83156 070 2600 SI LOET T100MA 250V
SI 60201
SI 61022
S 83156 190 2800 SI LOET T1,6A 250V
SI 61026
S 83156 210 2700 SI LOET T2,5A 250V
SI 61036 S 83156 210 2700 SI LOET T2,5A 250V
SI 61061 S 83156 202 2500 SI LOET T2A 250V
SI 61066 S 83156 202 2500 SI LOET T2A 250V
T 21211 83034 012 9900 TRANS.BF299 G /PBF259
T 40010 83032 873 6800 TRANS.BC 368
T 50028 83022 105 4400 TRANS BD544B / BD538
T 50029 83022 105 4300 TRANS BD543B / BD537
T 52003 83022 180 4300 TRANS.BDX 43
T 53001 83026 253 3100 TRANS 2SC5331
T 60006 83028 050 5000 TRANS IRFPC50 / 2SK26
T 60223 83022 690 9100 TRANS.BUZ 90 A TYP 2/3 TY
TR 52001 09246 867 9700 UEBERTRAGER
TR 53010
S 29201 680 0100 TRAFO DIODEN-SPLIT
TR 60001
S 29201 569 9700 SPERRWANDLERTRAFO
TR 60220
S 29201 701 9700 TRAFO STAND-BY
TR 60220
S 29201 617 9700 SPERRWANDLERTRAFO KPL
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 72010 800 0000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
TRANSFORMER
DIODE SPLIT TRANSFORMER
B.O.TYPE CONVERTER
TRANSFORMER
29304 050 2900
29304 050 8200
B.O.TYPE CONVERTER
TRANSFORMER
Page 51
GRUNDIG Service 65
Ķ
Ersatzteilliste
Spare Parts List
10 / 99
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
29504 209 0500 FEATURE-BOX BASIC ++/BASIC 3 FEATURE-BOX BASIC ++/BASIC 3
FEATURE-BOX BASIC ++/BASIC 3
MATERIAL-NR. / PART NO.: 29504 209 0500
d©
TV
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
L 01533 81049 820 1400 DAEMPF-PERLE
L 01536 81049 820 1400 DAEMPF-PERLE
L 01537 81049 820 1400 DAEMPF-PERLE
L 01538 81405 265 3400 DR 0411 10UH 10%
L 01543 81405 265 3400 DR 0411 10UH 10%
L 01544 81405 265 3400 DR 0411 10UH 10%
L 01546 81405 265 3400 DR 0411 10UH 10%
L 01563 81405 265 3400 DR 0411 10UH 10%
L 01641 81049 820 1400 DAEMPF-PERLE
L 01651 81049 820 1400 DAEMPF-PERLE
L 01656 81049 820 1400 DAEMPF-PERLE
L 01662 81405 265 3400 DR 0411 10UH 10%
Q 01365 83824 422 0300 QUARZ #442-1 20,25MHZ
Q 01408 83822 495 9700 QUARZ 12,0 MHZ
Q 02015 83823 362 7200 QUARZ #336-1 27MHZ 30PF
DAMPING BEAD
DAMPING BEAD
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
CUC 1830 / 1836 / 1929 Ersatzteillisten / Spare Parts Lists
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
CD 01403 83250 041 4800 SMD DIODE LS 4148
CD 01406 83094 550 5200 MELF-Z DIODE 5,1 B 0,5W
CD 01407 83250 041 4800 SMD DIODE LS 4148
CD 01418 83091 950 4200 SMD DIODE BAR42
CD 01419 83094 550 4000 MELF-Z DIODE 3,9 B 0,5W
CD 01530 83250 041 4800 SMD DIODE LS 4148
CD 01532 83250 041 4800 SMD DIODE LS 4148
CD 01533 83250 041 4800 SMD DIODE LS 4148
CD 01534 83250 041 4800 SMD DIODE LS 4148
CD 01663 83094 550 5200 MELF-Z DIODE 5,1 B 0,5W
CIC01320 83058 397 3300 SMD IC TLC7733ID
CIC01350 83059 932 1100 SMD IC VPC3211A
CIC01360 83059 732 5000 SMD IC CIP3250A-PS-B1
CIC01410 83059 493 6200 SMD IC SDA9362
CIC01640 83059 492 8200 SMD IC SDA9280-B22
CIC02010 83059 494 0100 SMD IC SDA9401G
CIC02020 83057 870 5300 IC M74HC4053RM13TR
CL 01376 81049 823 3300 SMD DAEMPF-PERLE 0805
CL 01377 81049 823 3300 SMD DAEMPF-PERLE 0805
CL 02022 81049 823 3300 SMD DAEMPF-PERLE 0805
CT 01501 83010 048 4900 SMD-TRANS.BC 849 B
CT 01506 83011 660 5100 SMD-TRANS.BCX 51-16
CT 01511 83010 048 4900 SMD-TRANS.BC 849 B
CT 01516 83011 660 5100 SMD-TRANS.BCX 51-16
CT 01521 83010 048 4900 SMD-TRANS.BC 849 B
CT 01526 83011 660 5100 SMD-TRANS.BCX 51-16
CT 01541 83010 048 4800 SMD-TRANS.BC 848 B
CT 01545 83010 048 4800 SMD-TRANS.BC 848 B
CT 01561 83010 048 4800 SMD-TRANS.BC 848 B
CT 01680 83010 048 4800 SMD-TRANS.BC 848 B
CT 01681 83010 048 4800 SMD-TRANS.BC 848 B
CT 01690 83010 048 4800 SMD-TRANS.BC 848 B
CT 01691 83010 048 4800 SMD-TRANS.BC 848 B
CT 02057 83010 038 5800 SMD TRANS BC858B
CT 02058 83010 048 4800 SMD-TRANS.BC 848 B
CT 02059 83010 048 4800 SMD-TRANS.BC 848 B
F 02000 81406 023 1900 FILTER 5X5 #319 4FACH
IC 01310 83052 631 1700 IC LD1117V33C 3,3V 2%
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
L 01306 81405 320 8500 SPULE 5X5 085 SIGN 532085
L 01308 81405 320 8600 SPULE 5X5 086 SIGN 532086
L 01309 81405 269 6600 DR S 18UH 5%
L 01310 81049 820 1400 DAEMPF-PERLE
L 01311 81405 269 6600 DR S 18UH 5%
L 01312 81405 269 6600 DR S 18UH 5%
L 01313 81049 820 1400 DAEMPF-PERLE
L 01314 81405 269 6600 DR S 18UH 5%
L 01315 81049 820 1400 DAEMPF-PERLE
L 01317 81049 820 1400 DAEMPF-PERLE
L 01350 81049 820 1400 DAEMPF-PERLE
L 01351 09241 035 9700 STABKERNDROSSEL
L 01352 81049 820 1400 DAEMPF-PERLE
L 01353 09241 035 9700 STABKERNDROSSEL
L 01358 81405 265 3400 DR 0411 10UH 10%
L 01360 81405 258 9700 DR AX 0411-GA 100UH 5%
L 01361 81049 820 1400 DAEMPF-PERLE
L 01362 81049 820 1400 DAEMPF-PERLE
L 01370 81049 820 1400 DAEMPF-PERLE
L 01372 81049 820 1400 DAEMPF-PERLE
L 01374 81405 258 9700 DR AX 0411-GA 100UH 5%
L 01401 81405 265 3400 DR 0411 10UH 10%
L 01402 81405 265 3400 DR 0411 10UH 10%
L 01403 81405 265 3400 DR 0411 10UH 10%
L 01407 81405 265 3400 DR 0411 10UH 10%
L 01411 81405 265 3600 DR 0411 4,7UH 10%
L 01412 81405 265 3600 DR 0411 4,7UH 10%
L 01421 81049 820 1400 DAEMPF-PERLE
L 01423 81049 820 1400 DAEMPF-PERLE
L 01508 81049 820 1400 DAEMPF-PERLE
L 01509 81405 258 2800 DR AX 0411-GA 2,2UH 10%
L 01518 81049 820 1400 DAEMPF-PERLE
L 01531 81049 820 1400 DAEMPF-PERLE
L 01532 81405 265 3400 DR 0411 10UH 10%
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
DAMPING BEAD
DAMPING BEAD
DAMPING BEAD
BAR CORE CHOKE COIL
DAMPING BEAD
BAR CORE CHOKE COIL
DAMPING BEAD
DAMPING BEAD
DAMPING BEAD
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 72010 800 0000, sowie zusätzlich die eventuell
abweichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 72010 800 0000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Page 52
66 GRUNDIG Service
Ersatzteilliste
Spare Parts List
4 / 2000
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
Ķ
FEATURE BOX BASIC 3
MATERIAL-NR. / PART NO.: 29504 209 1500
d©
29504 209 1500 FEATURE-BOX BASIC 3 FEATURE-BOX BASIC 3
TV
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
L 01537 81049 820 1400 DAEMPF-PERLE 433003038102
L 01538 81405 265 3400 DR 0411 10UH 10%
L 01543 81405 265 3400 DR 0411 10UH 10%
L 01544 81405 265 3400 DR 0411 10UH 10%
L 01546 81405 265 3400 DR 0411 10UH 10%
L 01563 81405 265 3400 DR 0411 10UH 10%
L 01641 81049 820 1400 DAEMPF-PERLE 433003038102
L 01651 81049 820 1400 DAEMPF-PERLE 433003038102
L 01656 81049 820 1400 DAEMPF-PERLE 433003038102
L 01662 81405 265 3400 DR 0411 10UH 10%
Q 01365 83824 422 0300 QUARZ #442-1 13C 20,25MHZ
Q 01408 83822 495 9700 QUARZ #330 2C 12MHZ
Q 02015 83823 362 7200 QUARZ #336-1 13C 27MHZ
DAMPING BEAD
DAMPING BEAD
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
Ersatzteillisten / Spare Parts Lists CUC 1830 / 1836 / 1929
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
CD 01403 83250 041 4800 SMD DIODE LS 4148
CD 01406 83094 550 5200 MELF-Z DIODE 5,1B 0,5W
CD 01407 83250 041 4800 SMD DIODE LS 4148
CD 01418 83091 950 4200 SMD DIODE BAR42
CD 01419 83094 550 4000 MELF-Z DIODE 3,9B 0,5W
CD 01530 83250 041 4800 SMD DIODE LS 4148
CD 01532 83250 041 4800 SMD DIODE LS 4148
CD 01533 83250 041 4800 SMD DIODE LS 4148
CD 01534 83250 041 4800 SMD DIODE LS 4148
CD 01663 83094 550 5200 MELF-Z DIODE 5,1B 0,5W
CIC01320 83058 397 3300 SMD IC TLC7733ID
CIC01350 83059 932 1100 SMD IC VPC3211A
CIC01360 83059 732 5000 SMD IC CIP3250A-PS-B1
CIC01410 83059 493 6100 SMD IC SDA9362-2
CIC01640 83059 492 8200 SMD IC SDA9280-B22
CIC02010 83059 499 4000 SMD IC SDA940GRU
CIC02010 83059 494 0100 SMD IC SDA9401G
CIC02020 83057 870 5300 IC M74HC4053RM13TR
CL 01376 81049 823 3300 SMD DAEMPF-PERLE 0805
CL 01377 81049 823 3300 SMD DAEMPF-PERLE 0805
CL 02022 81049 823 3300 SMD DAEMPF-PERLE 0805
CT 01501 83010 048 4900 SMD-TRANS BC 849 B
CT 01506 83011 660 5100 SMD-TRANS BCX 51-16
CT 01511 83010 048 4900 SMD-TRANS BC 849 B
CT 01516 83011 660 5100 SMD-TRANS BCX 51-16
CT 01521 83010 048 4900 SMD-TRANS BC 849 B
CT 01526 83011 660 5100 SMD-TRANS BCX 51-16
CT 01541 83010 048 4800 SMD TRANS BC848B/BC847B
CT 01545 83010 048 4800 SMD TRANS BC848B/BC847B
CT 01561 83010 048 4800 SMD TRANS BC848B/BC847B
CT 01680 83010 048 4800 SMD TRANS BC848B/BC847B
CT 01681 83010 048 4800 SMD TRANS BC848B/BC847B
CT 01690 83010 048 4800 SMD TRANS BC848B/BC847B
CT 01691 83010 048 4800 SMD TRANS BC848B/BC847B
CT 02057 83010 038 5800 SMD TRANS BC858B/BC857B
CT 02058 83010 048 4800 SMD TRANS BC848B/BC847B
CT 02059 83010 048 4800 SMD TRANS BC848B/BC847B
F 02000 81406 023 1900 FILTER 5X5 #319 4FACH
IC 01310 83052 631 1700 IC LD1117V33C 3,3V 2%
DAMPING BEAD
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
L 01306 81405 320 8500 SPULE 5X5 085 SIGN 532085
L 01308 81405 320 8600 SPULE 5X5 086 SIGN 532086
L 01309 81405 269 6600 DR S 18UH 5%
L 01310 81049 820 1400 DAEMPF-PERLE 433003038102
L 01311 81405 269 6600 DR S 18UH 5%
L 01312 81405 269 6600 DR S 18UH 5%
L 01313 81049 820 1400 DAEMPF-PERLE 433003038102
L 01314 81405 269 6600 DR S 18UH 5%
L 01315 81049 820 1400 DAEMPF-PERLE 433003038102
L 01317 81049 820 1400 DAEMPF-PERLE 433003038102
L 01350 81049 820 1400 DAEMPF-PERLE 433003038102
L 01351 09241 035 9700 STABKERNDROSSEL
L 01352 81049 820 1400 DAEMPF-PERLE 433003038102
L 01353 09241 035 9700 STABKERNDROSSEL
L 01358 81405 265 3400 DR 0411 10UH 10%
L 01360 81405 258 9700 DR AX 0411-GA 100UH 5%
L 01361 81049 820 1400 DAEMPF-PERLE 433003038102
L 01362 81049 820 1400 DAEMPF-PERLE 433003038102
L 01370 81049 820 1400 DAEMPF-PERLE 433003038102
L 01372 81049 820 1400 DAEMPF-PERLE 433003038102
L 01374 81405 258 9700 DR AX 0411-GA 100UH 5%
L 01401 81405 265 3400 DR 0411 10UH 10%
L 01402 81405 265 3400 DR 0411 10UH 10%
L 01403 81405 265 3400 DR 0411 10UH 10%
L 01407 81405 265 3400 DR 0411 10UH 10%
L 01411 81405 265 3600 DR 0411 4,7UH 10%
L 01412 81405 265 3600 DR 0411 4,7UH 10%
L 01421 81049 820 1400 DAEMPF-PERLE 433003038102
L 01423 81049 820 1400 DAEMPF-PERLE 433003038102
L 01508 81049 820 1400 DAEMPF-PERLE 433003038102
L 01509 81405 258 2800 DR AX 0411-GA 2,2UH 10%
L 01518 81049 820 1400 DAEMPF-PERLE 433003038102
L 01531 81049 820 1400 DAEMPF-PERLE 433003038102
L 01532 81405 265 3400 DR 0411 10UH 10%
L 01533 81049 820 1400 DAEMPF-PERLE 433003038102
L 01536 81049 820 1400 DAEMPF-PERLE 433003038102
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
DAMPING BEAD
DAMPING BEAD
DAMPING BEAD
BAR CORE CHOKE
DAMPING BEAD
BAR CORE CHOKE
DAMPING BEAD
DAMPING BEAD
DAMPING BEAD
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Nummer 72010 800 0000, sowie zusätzlich die eventuell
abweichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
!
as provided by the "Safety" Service Manual, part
number 72010 800 0000, as well as the respective
( ! )
national deviations.
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Loading...
