GRUNDFOS INSTRUCTIONS
UPZCV-3, 4, 6
Multi-zone valve control
Installation and operating instructions
English (US)
English (US) Installation and operating instructions
Original installation and operating
instructions.
These installation and operating instructions
describe Grundfos UPZCV-3, -4, -6. Sections
1-4 give the information necessary to be able to
unpack, install and start up the product in a safe
way.
Sections 5-8 give important information about
the product, as well as information on service
and disposal of the product.
CONTENTS
Page
1. General information
1.1 UPZCV-3, -4, -6
1.2 Limited warranty
1.3 Symbols used in this document
2. Receiving the product
2.1 Inspecting the product
3. Installing the product
3.1 Mechanical installation
3.2 Electrical installation
4. Starting up the product
4.1 LED diagnostics
4.2 DIP switch settings
5. Product introduction
5.1 Features and benefits
5.2 Identification
6. Servicing the product
6.1 Service parts
7. Technical data
8. Disposing of the product
1. General information
WARNING
Prior to installation, read these
installation and operating instructions.
Installation and operation must
comply with local regulations and
accepted codes of good practice.
This booklet should be left with the
owner of the pump for future
reference and information regarding
its operation.
WARNING
The use of this product requires
experience with and knowledge of the
product. Persons with reduced
physical, sensory or mental
capabilities must not use this product,
unless they are under supervision or
have been instructed in the use of the
product by a person responsible for
their safety. Children must not use or
play with this product.
1.1 UPZCV-3, -4, -6
2
This is a multi-zone valve control relay for
2
domestic hydronic heating systems. It provides
control when zoning with pumps or low voltage
2
zone valves.
3
3
1.2 Limited warranty
3
Products manufactured by GRUNDFOS are
3
warranted to the original user only to be free of
3
defects in material and workmanship for a period
of 24 months from date of installation, but not
4
more than 36 months from date of manufacture.
7
GRUNDFOS' liability under this warranty shall
7
be limited to repairing or replacing at
7
GRUNDFOS’ option, without charge, F.O.B.
GRUNDFOS’ factory or authorized service
8
station, any product of GRUNDFOS’
8
manufacture. GRUNDFOS will not be liable for
8
any costs of removal, installation, transportation,
9
or any other charges which may arise in
connection with a warranty claim. Products
9
which are sold but not manufactured by
9
GRUNDFOS are subject to the warranty
9
provided by the manufacturer of said products
and not by GRUNDFOS’ warranty. GRUNDFOS
will not be liable for damage or wear to products
caused by abnormal operating conditions,
accident, abuse, misuse, unauthorized alteration
or repair, or if the product was not installed in
accordance with GRUNDFOS printed
installation and operating instructions.
To obtain service under this warranty, the
defective product must be returned to the
distributor or dealer of GRUNDFOS products
from which it was purchased together with proof
of purchase and installation date, failure date,
and supporting installation data. Unless
otherwise provided, the distributor or dealer will
contact GRUNDFOS or an authorized service
station for instructions. Any defective product to
be returned to GRUNDFOS or a service station
must be sent freight prepaid; documentation
supporting the warranty claim and/or a Return
Material Authorization must be included if so
instructed.
2
MANUFACTURER WILL NOT BE LIABLE FOR
Caution
Caution
Base plate
ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES, LOSSES, OR EXPENSES ARISING
FROM INSTALLATION, USE, OR ANY OTHER
CAUSES. THERE ARE NO EXPRESS OR
IMPLIED WARRANTIES, INCLUDING
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, WHICH EXTEND
BEYOND THOSE WARRANTIES DESCRIBED
OR REFERRED TO ABOVE. EXCEPT AS
EXPRESSLY HEREIN PROVIDED THE GOODS
ARE SOLD "AS IS", THE ENTIRE RISK AS TO
QUALITY AND FITNESS FOR A PARTICULAR
PURPOSE, AND PERFORMANCE OF THE
GOODS IS WITH THE BUYER, AND SHOULD
THE GOODS PROVE DEFECTIVE
FOLLOWING THEIR PURCHASE, THE BUYER
AND NOT THE MANUFACTURER,
DISTRIBUTOR, OR RETAILER ASSUMES THE
ENTIRE RISK OF ALL NECESSARY
SERVICING OR REPAIR.
Some jurisdictions do not allow the exclusion or
limitation of implied warranties of
merchantability and fitness for a particular
purpose, of incidental or consequential damages
and some jurisdictions do not allow limitations
on how long implied warranties may last or
require you to pay certain expenses as set forth
above. Therefore, the above limitations or
exclusions may not apply to you. This warranty
gives you specific legal rights and you may also
have other rights which vary from jurisdiction to
jurisdiction.
1.3 Symbols used in this document
2. Receiving the product
2.1 Inspecting the product
Examine the components carefully to make sure
no damage has occurred to the pump during
shipment.
3. Installing the product
WARNING
Electrical shock and potential circuit
damage. Disconnect the power
supply before beginning installation.
All wiring must comply with national
and local electrical codes, ordinances
and regulations. Failure to follow
electrical codes could result in
serious personal injury, death, and
property damages.
CAUTION
Disconnect the power supply before
changing any DIP switch settings.
3.1 Mechanical installation
3.1.1 Installing the base
Attach the base firmly to the wall surface with
four screws and anchors using the key holes
provided.
English (US)
WARNING
If you do not observe these safety
instructions, it may result in personal
injury.
WARNING
If you do not observe these
instructions, it may lead to electric
shock with consequent risk of serious
personal injury or death.
CAUTION
If you do not observe these safety
instructions, it may result in
malfunction or damage to the
equipment.
Fig. 1 Attach the base plate to the wall
with screws and anchors
TM06 5607 5015
3
English (US)
Caution
3.2 Electrical installation
CAUTION
Class 2 wiring must be segregated
from the wiring of Class 1 circuits.
When Class 2 wiring is routed with
Class 1 wiring, the Class 2 wiring
insulation must be rated for the
minimum voltage of the Class 1
wiring. Segregation is not required if
all circuits are wired as Class 1,
electric light or power circuits.
3.2.1 Wiring connections
• All electrical connections must be made
using copper wire only.
• 12-16 AWG wire is recommended for 120
VAC connections.
• 12-22 AWG wire for thermostat connections.
• 12-22 AWG wire for 24 VAC connections.
• Use approved UL conduit fittings.
You can find additional wiring schematics,
specs, and troubleshooting help online at
www.grundfos.us/controls.
4
L
N
L
N
L
N
L
N
C
B
A
X
X
X
X
R
W
C
R
W
C
R
W
C
R
W
C
R
W
C
R
W
C
4
3
2
1
4
3
2
1
4
3
2
1
4
3
2
1
4
3
2
1
4
3
2
1
L
N
OFF
OFF
OFF
OFF
Master
SW1
Pump Exercise ON
Priority 30 min.
Slave
Priority ON
Exercise 30 sec./72 hrs.
During priority demand
Secondary Pump ON
Boiler Pump ON
60 minutes
30 sec./14 days
Dip switches
3
1
2
RRhWC
Jumper
Mod/con boiler
Jumper
Jumper
2-wire zone
valve
TACO
570*
3-wire
zone
valve
4-wire zone
valve
#1 and #2 - motor terminals
#3 and #4 - end switch
terminals
Aquastat
2-wire
thermostat
3-wire
thermostat
4-wire
thermostat
500 mA fuse
500 mA fuse
24 VAC
40 VA
Transformer
24 VAC
40 VA
Transformer
Ground
screws
on the
base
English (US)
Fig. 2 UPZCV-6 multi-zone valve board layout
DIP switches
The DIP switch settings are also listed in section 4.2 DIP switch settings. See fig. 2.
Master/Slave: Allows expansion to additional UPZC units.
Priority ON: Zone 1 operates as priority and the other zones are switched off for a selectable 30- or
60-minute timeout.
Pump Exercise ON: The pumps will operate for 30 seconds every 72 hours or every 14 days.
Boiler ON/Secondary ON: During the PRIORITY demand, select whether the PRIMARY PUMP is
ON or OFF.
TM06 5338 5115
5
English (US)
C
B
A
C
B
A
Master
Slave
Master
Slave
E
X
P
A
N
S
I
O
N
E
X
P
A
N
S
I
O
N
Master board
Slave board
Caution
Multi-zone valve board expansion
Fig. 3 UPZCV multi-zone valve board expansion
See fig. 3.
• You can only use the MASTER controller
with PRIORITY.
• When priority calls, the MASTER board will
produce 5 VDC between terminals B and C.
This tells the SLAVE board to turn off any
zones that are calling for heat. This also will
close the contacts XX PRIORITY.
• When there is a demand for heat, the SLAVE
board will produce 5 VDC between terminals
A and C. This tells the MASTER board to
activate any boiler or secondary pumps and
close the contacts XX MAIN.
• You can connect the pump and valve boards.
• When the SLAVE board calls for heat, the
secondary pump will be powered. If a boiler
pump and secondary pump are to be used,
connect them to the same terminals.
• You can use the low voltage wire to connect
the ABC terminals.
• Connect the 120 VAC power supply to each
board.
CAUTION
Connect the L and N terminals the
same way on each board. If switched,
a differential of 240 VAC can occur
resulting in damage to the equipment.
TM06 5606 5015
6
4. Starting up the product
UPZCV-6 6 Valve Zone Relay
Part Number: 98863570
Input: 120VAC 50/60Hz 20A MAX
CAUTION,
RISK OF ELECTRICAL SHOCK -
DISCONNECT POWER PRIOR TO SERVICING
ATTENTION, RISQUE DE CHOC ÉLÉCTRIQUE -
DÉCONNECTEZ LA PUISSANCE AVANT D’ENTRETENIR
ZONE 1
ZONE 2
ZONE 3
ZONE 4
ZONE 5
ZONE 6
Certified to CSA C22.2 No 24
Conforms to UL Standard 873
Listed
The power indicator light "Grundfos" is
lit when you power on the unit.
The LED lights will be green
when there is a call for heat.
The LED lights will turn
amber when the zone valve
end-switch is closed.
Caution
OFF
OFF
OFF
OFF
Master
Pump Exercise ON
Priority 30 min.
Slave
Priority ON
Exercise 30 sec./72 hrs.
During priority demand
Secondary Pump ON
Boiler Pump ON
60 minutes
30 sec./14 days
4.1 LED diagnostics
Fig. 4 The indicator lights located on the control plate
4.2 DIP switch settings
CAUTION
Disconnect the power supply before
changing any DIP switch settings.
Master/Slave
Allows expansion to additional Grundfos UPZC
units.
English (US)
TM06 5587 5015
Priority ON
Zone 1 operates as priority and the other
zones are switched off for a selectable 30 or
60-minute timeout.
Pump Exercise ON
Pumps will operate for 30 seconds every 72
hours or every 14 days.
Boiler ON/Secondary ON
You can control the BOILER PUMP and
SECONDARY PUMP to ON/OFF during
PRIORITY demand.
7
English (US)
Production code
YYWW
PC1542
1542
Circuit board
Carton label
5. Product introduction
5.1 Features and benefits
• Compatible with 2-, 3-, and 4-wire low
voltage controllers or thermostats.
• Wiring ease with 120 VAC, ground and low
voltage screw terminal inputs.
• Low voltage end-switch output terminals for
the zone valves.
• Replaceable 40 VA transformer (snap-fit) for
the zone valve controllers only.
• Zone priority with selectable time-out
feature.
• Pump exercise feature, selectable 72 hours
or 14 days.
– The pumps will be turned on for 30
seconds every 72 hours or 14 days in
order to prevent pumps from seizing up.
This feature will only work if there is a
jumper wire connecting the ZR ZC
terminals on the pump controller.
• Boiler demand terminals.
– The two terminals, labeled MAIN XX, are
wired to the boiler. When the contacts
close, the boiler starts and will come up to
a preset temperature for hydronic heating.
• DHW terminal.
– The two terminals, labeled PRIORITY XX,
are wired to the boiler. When the contacts
close, the boiler starts and will come up to
a preset temperature for domestic hot
water heating.
• Front facing LED indicator lights on the
cover.
• Side-mounted terminal connections for ease
of wiring and installation.
5.2 Identification
5.2.1 Part numbers
Model Description Part number
UPZCV-3
UPZCV-4
UPZCV-6
5.2.2 Production code
The production code represents the date of
manufacture. You find the production code on
the circuit board and the carton label.
Example:
PC 1542 = year 2015, week 42.
Fig. 5 Locating production code
Three-valve zone
control
Four-valve zone
control
Six-valve zone
control
98863567
98863568
98863570
8
6. Servicing the product
6.1 Service parts
Part Description Part number
24 VAC transformer Kit, UPZC transformer, 24 VAC - 40 VA 98996452
5 A fuse Kit, UPZC pump fuse, 5-pack 98996468
250 mA fuse Kit, UPZC transformer fuse, pump board 250 mA, 5-pack 98996472
500 mA fuse Kit, UPZC transformer fuse, pump board 500 mA, 5-pack 98996473
7. Technical data
Three-zone valve Four-zone valve Six-zone valve
Model number UPZCV-3 UPZCV-4 UPZCV-6
Part number 98863567 98 863568 98863570
Input power 60 Hz 120 VAC
Transformer voltage
Thermostat output [A] 0.375 0.5 0.75
Maximum single phase motor rating,
per zone [A]
Maximum combined load rating:
output @ 120 VAC [A]
Temperature range (storage) [°F (°C)] 50-100 (10-38)
Temperature range
(maximum operation) [°F (°C)]
Maximum operating humidity range
[%] RH
Number of knockouts 12
Size of knockouts [in. (mm)] 0.875 (22)
Dimensions, W x H x D [in. (mm)] 8.15 x 10.67 x 2.72 (208 x 272 x 70)
Approvals CSA 22.2 No. 24/UL Standard 873
Relay type Sealed
Cover panel ABS - fire rated
Base material Galvanized steel
Terminal block (side mounted) PA66
Front display lights LED
24 VAC
40 VA, Class 2
24 VAC
40 VA, Cl ass 2
5
20
0-100 (-18 - +38)
90
24 VAC
80 VA (40 VA x 2),
Class 2
English (US)
8. Disposing of the product
This product or parts of it must be disposed of in
an environmentally sound way:
1. Use the public or private waste collection
service.
2. If this is not possible, contact the nearest
Grundfos company or service workshop.
Subject to alterations.
9
10
Grundfos Kansas City
17100 West 118th Terrace
Olathe, Kansas 66061
Phone: +1-913-227-3400
Fax: +1-913-227-3500
www.grundfos.us
Grundfos Canada
2941 Brighton Road
Oakville, Ontario L6H 6C9 Canada
Phone: +1-905 829 9533
Fax: +1-905 829 9512
www.grundfos.ca
Grundfos México
Boulevard TLC No. 15
Parque Industrial Stiva Aeropuerto
C.P. 66600 Apodaca, N.L. Mexico
Phone: +011-52-81-8144 4000
Fax: +011-52-81-8144 4010
www.grundfos.mx
Grundfos companies
99028538 0216
ECM: 1173390
www.grundfos.com
© Copyright Grundfos Holding A/S
owned by Grundfos Holding A/S or Grundfos A/S, Denmark. All rights reserved worldwide.
The name Grundfos, the Grundfos logo, and be think innovate are registered trademarks
Loading...
