Grundfos Sololift+ PWC-3 Installation And Operating Instructions Manual

GRUNDFOS INSTRUCTIONS

Sololif t+ PWC-3

Installation and operating instruc tion s

Declaration of Conformity

We, Grundfos, declare under our sole responsibility that the product
Sololift+ PWC-3, to which this declaration relates, is in conformity with
these Council directives on the approximation of the laws of the EC
member states:

– Machinery Directive (2006/42/EC).

Standard used: EN 809: 2000.

– Low Voltage Directive (2006/95/EC).

Standards used: EN 60335-1: 2007 and EN 60335-2-41: 2003.

– EMC Directive (2004/108/EC).

Standards used: EN 61000-6-2 and EN 61000-6-3.

Construction Products Directive (89/106/EEC).

–

Standard used: EN 12050-3.

Déclaration de Conformité

Nous, Grundfos, déclarons sous notre seule responsabilité, que le
produit Sololift+ PWC-3, auquel se réfère cette déclaration, est
conforme aux Directives du Conseil concernant le rapprochement des
législations des Etats membres CE relatives aux normes énoncées
ci-dessous :
– Directive Machines (2006/42/CE).

Norme utilisée : EN 809 : 2000.

– Directive Basse Tension (2006/95/CE).

Normes utilisées : EN 60335-1 : 2007 et EN 60335-2-41 : 2003.

– Directive Compatibilité Electromagnétique CEM (2004/108/CE).

Normes utilisées : EN 61000-6-2 et EN 61000-6-3.

Directive sur les Produits de Construction (89/106/CEE)

–

Norme utilisée : EN 12050-3.

Declaración de Conformidad

Nosotros, Grundfos, declaramos bajo nuestra propia responsabilidad
que el producto Sololift+ PWC-3, al cual se refiere esta declaración,
está conforme con las Directivas del Consejo en la aproximación de las
leyes de los Estados Miembros del EM:
– Directiva de Maquinaria (2006/42/CE).

Norma aplicada: EN 809: 2000.

– Directiva de Baja Tensión (2006/95/CE).

Normas aplicadas: EN 60335-1: 2007 y EN 60335-2-41: 2003.

– Directiva EMC (2004/108/CE).

Normas aplicadas: EN 61000-6-2 y EN 61000-6-3.

Directiva de Productos de Construcción (89/106/CEE).

–

Norma aplicada: EN 12050-3.

Δήλωση Συμμόρφωσης

Εμείς, η Grundfos, δηλώνουμε με αποκλειστικά δική μας ευθύ νη ότι τα
προϊόντα Sololift+ PWC-3, στα οποία αναφέρεται η παρ ούσα δήλωση,
συμμορφώνοντ αι με τις εξής Οδηγίες του Συμβουλίου περί προσέγγισης
των νομοθεσιών των κρατών μελών της ΕΕ:
– Οδηγία γι α μηχανήματα (2006/42/EC).

Πρότυπο που χρησιμοποιήθηκε: EN 809: 2000.

– Οδηγία χα μηλή ς τά σης (2006/95/EC).

Πρότυπα που χρησιμοποιήθηκαν: EN 60335-1: 2007 και

EN 60335-2-41: 2003.

– Οδηγία Ηλεκτρομαγνητικής Συμβατότητας

Πρότυπα που χρησιμοποιήθηκαν: EN 61000-6-2 και EN 61000-6-3

– Οδηγία Παραγωγής Προϊόντων (89/106/EEC).

Πρότυπο που χρησιμοποιήθηκε: EN 12050-3.

(EMC) (2004/108/EC).

Försäkran om överensstämmelse

Vi, Grundfos, försäkrar under ansvar att produkten Sololift+ PWC-3,
som omfattas av denna försäkran, är i överensstämmelse med rådets
direktiv om inbördes närmande till EU-medlemsstaternas lagstiftning,
avseende:
– Maskindirektivet (2006/42/EG).

Tillämpad standard: EN 809: 2000.

– Lågspänningsdirektivet (2006/95/EG).

Tillämpade standarder: EN 60335-1: 2007 och
EN 60335-2-41: 2003.

– EMC-direktivet (2004/108/EG).

Tillämpade standarder: EN 61000-6-2 och EN 61000-6-3.

Byggproduktdirektivet (89/106/EEG).

–

Tillämpad standard: EN 12050-3.

Konformitätserklärung

Wir, Grundfos, erklären in alleiniger Verantwortung, dass das Produkt
Sololift+ PWC-3, auf das sich diese Erklärung bezieht, mit den
folgenden Richtlinien des Rates zur Angleichung der Rechtsvorschriften
der EU-Mitgliedsstaaten übereinstimmt:

– Maschinenrichtlinie (2006/42/EG).

Norm, die verwendet wurde: EN 809: 2000.

– Niederspannungsrichtlinie (2006/95/EG).

Normen, die verwendet wurden: EN 60335-1: 2007 und
EN 60335-2-41: 2003.

– EMV-Richtlinie (2004/108/EG).

Normen, die verwendet wurden: EN 61000-6-2 und EN 61000-6-3.

Bauprodukterichtlinie (89/106/EWG).

–

Norm, die verwendet wurde: EN 12050-3.

Dichiarazione di Conformità

Grundfos dichiara sotto la sua esclusiva responsabilità che il prodotto
Sololift+ PWC-3, al quale si riferisce questa dichiarazione, è conforme
alle seguenti direttive del Consiglio riguardanti il riavvicinamento delle
legislazioni degli Stati membri CE:
– Direttiva Macchine (2006/42/CE).

Norma applicata: EN 809: 2000.

– Direttiva Bassa Tensione (2006/95/CE).

Norme applicate: EN 60335-1: 2007 e EN 60335-2-41: 2003.

– Direttiva EMC (2004/108/CE).

Norme applicate: EN 61000-6-2 e EN 61000-6-3.

Direttiva Prodotti da Costruzione (89/106/CEE)

–

Norma applicata: EN 12050-3.

Declaração de Conformidade

A Grundfos declara sob sua única responsabilidade que o produto
Sololift+ PWC-3, ao qual diz respeito esta declaração, está em
conformidade com as seguintes Directivas do Conselho sobre a
aproximação das legislações dos Estados Membros da CE:
– Directiva Máquinas (2006/42/CE).

Norma utilizada: EN 809: 2000.

– Directiva Baixa Tensão (2006/95/CE).

Normas utilizadas: EN 60335-1: 2007 e EN 60335-2-41: 2003.

– Directiva EMC (compatibilidade electromagnética) (2004/108/CE).

Normas utilizadas: EN 61000-6-2 e EN 61000-6-3.

– Directiva Produtos Construção (89/106/CEE).

Norma utilizada: EN 12050-3.

Overeenkomstigheidsverklaring

Wij, Grundfos, verklaren geheel onder eigen verantwoordelijkheid dat
het product Sololift+ PWC-3 waarop deze verklaring betrekking heeft, in
overeenstemming is met de Richtlijnen van de Raad in zake de
onderlinge aanpassing van de wetgeving van de EG lidstaten
betreffende:
– Machine Richtlijn (2006/42/EC).

Gebruikte norm: EN 809: 2000.

– Laagspannings Richtlijn (2006/95/EC).

Gebruikte normen: EN 60335-1: 2007 en EN 60335-2-41: 2003.

– EMC Richtlijn (2004/108/EC).

Gebruikte normen: EN 61000-6-2 en EN 61000-6-3.

– Bouwproducten Richtlijn (89/106/EEC).

Gebruikte norm: EN 12050-3.

Vaatimustenmukaisuusvakuutus

Me, Grundfos, vakuutamme omalla vastuullamme, että tuote Sololift+
PWC-3, jota tämä vakuutus koskee, on EY:n jäsenvaltioiden
lainsäädännön yhdenmukaistamiseen tähtäävien Euroopan neuvoston
direktiivien vaatimusten mukainen seuraavasti:
– Konedirektiivi (2006/42/EY).

Sovellettu standardi: EN 809: 2000.

– Pienjännitedirektiivi (2006/95/EY).

Sovellettavat standardit: EN 60335-1: 2007 ja EN 60335-2-41: 2003.

– EMC-direktiivi (2004/108/EY).

Sovellettavat standardit: EN 61000-6-2 ja EN 61000-6-3.

– Rakennustuotedirektiivi (89/106/ETY).

Sovellettu standardi: EN 12050-3.

2

Overensstemmelseserklæring

Vi, Grundfos, erklærer under ansvar at produktet Sololift+ PWC-3 som
denne erklæring omhandler, er i overensstemmelse med disse af
Rådets direktiver om indbyrdes tilnærmelse til EF-medlemsstaternes
lovgivning:
– Maskindirektivet (2006/42/EF).

Anvendt standard: EN 809: 2000.

– Lavspændingsdirektivet (2006/95/EF).

Anvendte standarder: EN 60335-1: 2007 og EN 60335-2-41: 2003.

– EMC-direktivet (2004/108/EF).

Anvendte standarder: EN 61000-6-2 og EN 61000-6-3.

Byggevaredirektivet (89/106/EØF).

–

Anvendt standard: EN 12050-3.

Декларация о соответствии

Мы, компания Grundfos, со всей ответственн остью за являем, что
изделия Sololift+ PWC-3, к которым относится на стоящая
декларация, соответствуют следующим Директивам Совета
Евросоюза об унификации законодательных предписаний стран­членов ЕС:
– Механические устройства (2006/42/ЕС).

Применявшийся стандарт: EN 809: 2000.

– Низковольтное оборудование (2006/95/EC).

Применявшиеся стандарты: EN 60335-1: 2007 и

EN 60335-2-41: 2003.

– Электромагнитная совместимост ь (2004/108/EC).

Применявшиеся стандарты: EN 61000-6-2 и EN 61000-6-3.

Директива на строительные материалы и конструкции

–

(89/106/ЕЭС).
Применявшийся стандарт : EN 12050-3.

Izjava o skladnosti

V Grundfosu s polno odgovornostjo izjavljamo, da so naši izdelki
Sololift+ PWC-3, na katere se ta izjava nanaša, v skladu z naslednjimi
direktivami Sveta o približevanju zakonodaje za izenačevanje pravnih
predpisov držav članic ES:

– Direktiva o strojih (2006/42/ES).

Uporabljena norma: EN 809: 2000.

– Direktiva o nizki napetosti (2006/95/ES).

Uporabljeni normi: EN 60335-1: 2007 in EN 60335-2-41: 2003.

– Direktiva o elektromagnetni združljivosti (EMC) (2004/108/ES).

Uporabljeni normi: EN 61000-6-2 in EN 61000-6-3.

– Direktiva konstruiranja proizvoda (89/106/EGS).

Uporabljena norma: EN 12050-3.

Deklaracija o konformitetu

Mi, Grundfos, izjavljujemo pod vlastitom odgovornošću da je proizvod
Sololift+ PWC-3, na koji se ova izjava odnosi, u skladu sa direktivama
Saveta za usklađivanje zakona država članica EU:

– Direktiva za mašine (2006/42/EC).

Korišćen standard: EN 809: 2000.

– Direktiva niskog napona (2006/95/EC).

Korišćeni standardi: EN 60335-1: 2007 i EN 60335-2-41: 2003.

– EMC direktiva (2004/108/EC).

Korišćeni standardi: EN 61000-6-2 i EN 61000-6-3.

– Direktiva o konstrukciji proizvoda (89/106/EEC).

Korišćen standard: EN 12050-3.

Декларация за съответствие

Ние, фирма Grundfos, заявяваме с пълна отгово рност, че продукта
Sololift+ PW C-3, за който се от нася настоящата декларация,

отговаря на следните указания на Съвета за уеднаквяване на
правните разпоредби на държавите членки на ЕС:

– Директива за машините (2006/42/EC).

Приложен стандарт: EN 809: 2000.

– Директива за нисковолтови системи (2006/95/EC).

Приложени стандарт и: EN 60335-1: 2007 и EN 60335-2-41: 2003.

– Директива за електромагнитна съвместимост (2004/108/EC).

Приложени стандарти: EN 61000-6-2 и

– Директива за строителни продукти (89/106/EEC).

Приложени стандарти: EN 12050-3.

EN 61000-6-3.

Deklaracja zgodności

My, Grundfos, oświadczamy z pełną odpowiedzialnością, że nasze
wyroby Sololift+ PWC-3, których deklaracja niniejsza dotyczy, są
zgodne z następującymi wytycznymi Rady d/s ujednolicenia przepisów
prawnych krajów członkowskich WE:
– Dyrektywa Maszynowa (2006/42/WE).

Zastosowana norma: EN 809: 2000.

– Dyrektywa Niskonapięciowa (LVD) (2006/95/WE).

Zastosowane normy: EN 60335-1: 2007 oraz EN 60335-2-41: 2003.

– Dyrektywa EMC (2004/108/WE).

Zastosowane normy: EN 61000-6-2 oraz EN 61000-6-3.

– Dyrektywa Wyrobów Budowlanych (89/106/WE).

Zastosowana norma: EN 12050-3.

Megfelelőségi nyilatkozat

Mi, a Grundfos, egyedüli felelősséggel kijelentjük, hogy a Sololift+ PWC­3 termék, amelyre jelen nyilatkozik vonatkozik, megfelel az Európai Unió
tagállamainak jogi irányelveit összehangoló tanács alábbi előírásainak:
– Gépek (2006/42/EK).

Alkalmazott szabvány: EN 809: 2000.

– Kisfeszültségű Direktíva (2006/95/EK).

Alkalmazott szabványok: EN 60335-1: 2007 és
EN 60335-2-41: 2003.

– EMC Direktíva (2004/108/EK).

Alkalmazott szabványok: EN 61000-6-2 és EN 61000-6-3.

–Építőipari Termék Direktíva (89/106/EGK).

Alkalmazott szabvány: EN 12050-3.

Izjava o usklađenosti

Mi, Grundfos, izjavljujemo pod vlastitom odgovornošću da je proizvod
Sololift+ PWC-3, na koji se ova izjava odnosi, u skladu s direktivama
ovog Vijeća o usklađivanju zakona država članica EU:

– Direktiva za strojeve (2006/42/EZ).

Korištena norma: EN 809: 2000.

– Direktiva za niski napon (2006/95/EZ).

Korištene norme: EN 60335-1: 2007 i EN 60335-2-41: 2003.

– Direktiva za elektromagnetsku kompatibilnost (2004/108/EZ).

Korištene norme: EN 61000-6-2 i EN 61000-6-3.

– Uredba o konstrukciji proizvoda (89/106/EEZ).

Korištena norma: EN 12050-3.

Declaraţie de Conformitate

Noi, Grundfos, declarãm pe propria rãspundere cã produsele Sololift+
PWC-3, la care se referã aceastã declaraþie, sunt în conformitate cu
aceste Directive de Consiliu asupra armonizãrii legilor Statelor Membre
CE:

– Directiva Utilaje (2006/42/CE).

Standard utilizat: EN 809: 2000.

– Directiva Tensiune Joasă (2006/95/CE).

Standarde utilizate: EN 60335-1: 2007 şi EN 60335-2-41: 2003.

– Directiva EMC (2004/108/CE).

Standarde utilizate: EN 61000-6-2 şi EN 61000-6-3

– Directiva referitoare la produsele pentru construcţii (89/106/CEE).

Standard utilizat: EN 12050-3.

Prohlášení o shodě

My firma Grundfos prohlašujeme na svou plnou odpovědnost, že
výrobek Sololift+ PWC-3, na nějž se toto prohlášení vztahuje, je v
souladu s ustanoveními směrnice Rady pro sblížení právních předpisů
členských států Evropského společenství v oblastech:

–Směrnice pro strojní zařízení (2006/42/ES).

Použitá norma: EN 809: 2000.

–Směrnice pro nízkonapět’ové aplikace (2006/95/ES).

Použité normy: EN 60335-1: 2007 a EN 60335-2-41: 2003.

–Směrnice pro elektromagnetickou kompatibilitu (EMC)

(2004/108/ES).
Použité normy: EN 61000-6-2 a EN 61000-6-3.

– Smìrnice o konstrukci výrobkù (89/106/ES).

Použitá norma: EN 12050-3.

3

Prehlásenie o konformite

My firma Grundfos prehlasujeme na svoju plnú zodpovednost’, že
výrobok Sololift+ PWC-3, na ktorý sa toto prehlásenie vzt’ahuje, je v
súlade s ustanovením smernice Rady pre zblíženie právnych predpisov
členských štátov Európskeho spoločenstva v oblastiach:
– Smernica pre strojové zariadenie (2006/42/EC).

Použitá norma: EN 809: 2000.

– Smernica pre nízkonapät’ové aplikácie (2006/95/EC).

Použité normy: EN 60335-1: 2007 a EN 60335-2-41: 2003.

– Smernica pre elektromagnetickú kompatibilitu (2004/108/EC).

Použité normy: EN 61000-6-2 a EN 61000-6-3.

– Smernica o konštrukcií výrobkov (89/106/EEC).

Použité normy: EN 12050-3.

Vastavusdeklaratsioon

Meie, Grundfos, deklareerime enda ainuvastutusel, et toode Sololift+
PWC-3, mille kohta käesolev juhend käib, on vastavuses EÜ Nõukogu
direktiividega EMÜ liikmesriikide seaduste ühitamise kohta, mis
käsitlevad:
– Masinate ohutus (2006/42/EC).

Kasutatud standard: EN 809: 2000.

– Madalpinge direktiiv (2006/95/EC).

Kasutatud standardid: EN 60335-1: 2007 ja EN 60335-2-41: 2003.

– Elektromagnetiline ühilduvus (EMC direktiiv) (2004/108/EC).

Kasutatud standardid: EN 61000-6-2 ja EN 61000-6-3.

– Ehitustoodete direktiiv (89/106/EEC).

Kasutatud standardid: EN 12050-3.

Paziņojums par atbilstību prasībām

Sabiedrība GRUNDFOS ar pilnu atbildību dara zināmu, ka produkts
Sololift+ PWC-3, uz kuru attiecas šis paziņojums, atbilst šādām
Padomes direktīvām par tuvināšanos EK dalībvalstu likumdošanas
normām:
–Mašīnbūves di rektīva (2006/42/EK).

Piemērotais standarts: EN 809: 2000.

– Zema sprieguma direktīva (2006/95/EK).

Piemērotie standarti: EN 60335-1: 2007 un EN 60335-2-41: 2003.

– Elektromagnētiskās saderības direktīva (2004/108/EK).

Piemērotie standarti: EN 61000-6-2 un EN 61000-6-3.

–Būv materiālu direktīva (89/106/EEK).

Piemērotie standarti: EN 12050-3.

Uygunluk Bildirgesi

Grundfos olarak bu beyannameye konu olan Sololift+ PWC-3
ürünlerinin, AB Üyesi Ülkelerin kanunlarını birbirine yaklaştırma üzerine
Konsey Direktifleriyle uyumlu olduğunun yalnızca bizim
sorumluluğumuz altında olduğunu beyan ederiz:
– Makineler Yönetmeliği (2006/42/EC).

Kullanılan standart: EN 809: 2000.

–Düşük Voltaj Yönetmeliği (2006/95/EC).

Kullanılan standartlar: EN 60335-1: 2007 ve EN 60335-2-41: 2003.

– EMC Diretifi (2004/108/EC).

Kullanılan standartlar: EN 61000-6-2 ve EN 61000-6-3.

–Yapı Ürünleri Yönergesi (89/106/EEC).

Kullanılan standartlar: EN 12050-3.

Atitikties deklaracija

Mes, Grundfos, su visa atsakomybe pareiškiame, kad gaminys Sololift+
PWC-3, kuriam skirta ši deklaracija, atitinka šias Tarybos Direktyvas dėl
Europos Ekonominės Bendrijos šalių narių įstatymų suderinimo:
–Mašinų direktyva (2006/42/EB).

Taikomas standartas: EN 809: 2000.

–Žemų į tampų direktyva (2006/95/EB).

Taikomi standartai: EN 60335-1: 2007 ir EN 60335-2-41: 2003.

– EMS direktyva (2004/108/EB).

Taikomi standartai: EN 61000-6-2 ir EN 61000-6-3.

– Statybos produktų direktyva (89/106/EEB).

Taikomi standartai: EN 12050-3.

Свідчення про відповідність вимогам

Компанія Grundfos заявляє про свою виключну відповідальність за
те, що продукт Sololift+ PWC-3, на який пош ирюється дана
декларація, відповідає таким рекомендаціям Ра ди з уніфік ації
правових норм країн - членів ЕС:
– Механічні прилади (2006/42/ЕС).

Стандарти, що застосовувалися: EN 809: 2000.

– Низька напруга (2006/95/EC).

Стандарти, що застосовувалися: EN 60335-1: 2007 та

EN 60335-2-41: 2003.

– Електромагнітна сумісність (2004/108/EC).

Стандарти, що застосовувалися: EN 61000-6-2 та EN 61000-6-3.

– Директива з конструкції продукції (89/106/EEC).

Стандарти, що застосовувалися: EN 12050-3.

Bjerringbro, 15th May 2010

Svend Aage Kaae
Technical Director

Grundfos Holding A/S

Poul Due Jensens Vej 7

8850 Bjerringbro, Denmark

Person authorised to compile technical file and

empowered to sign the EC declaration of conformity.

4

Sololift+ PWC-3

Installation and operating instructions 6
Montage- und Betriebsanleitung 14
Notice d'installation et d'entretien 23
Istruzioni di installazione e funzionamento 31
Instrucciones de instalación y funcionamiento 39
Instruções de instalação e funcionamento 47
Οδηγίες εγκατάστασης και λειτουργίας 55
Installatie- en bedieningsinstructies 63
Monterings- och driftsinstruktion 71
Asennus- ja käyttöohjeet 79
Monterings- og driftsinstruktion 87
Instrukcja montażu i eksploatacji 95
Руководство по монтажу и эксплуатации 104
Szerelési és üzemeltetési utasítás 113
Navodila za montažo in obratovanje 122
Montažne i pogonske upute 131
Uputstvo za montažu i upotrebu 140
Instrucţiuni de instalare şi utilizare 149
Упътване за монтаж и експлоатация 157
Montážní a provozní návod 166
Návod na montáž a prevádzku 175
Montaj ve kullanım kılavuzu 184
Paigaldus- ja kasutusjuhend 194
Įrengimo ir naudojimo instrukcija 202
Uzstādīšanas un ekspluatācijas instrukcija 210

Інструкції з монтажу та експлуатації 218

5

Original installation and operating instructions.

CONTENTS

Page

1. General description

1.1 Applications

1.2 Pumped liquids

2. Product description

2.1 Accessories included

2.2 Dimensions

3. Installation

3.1 Electrical installation

3.2 Mechanical installation

3.3 Connection in top co ve r

3.4 Side connection

3.5 Connection of disc ha rg e pi p e

3.6 Pipework

4. Start-up

5. Maintenan c e

6. Fault finding chart

7. Service kits

8. Technical data

9. Disposal

Before beginning installation
procedures, th ese in sta llati on an d
operating instructions should be
studied caref ully. The in stal latio n and
operation should a l so be i n a cco rda nce
with local re gu l at io n s a n d ac ce p te d
codes of good practice.

Warning
The use of this product requires

experience with and knowledge of the
product.
Persons with reduced physical,
sensory or mental c apabi liti es mus t not
use this product, unless they are under
supervision or have been instructed in
the use of the product by a person
responsible for their safety.
Children mus t not us e or pl ay with thi s
product.

1.1 Applications

Sololift+ PWC-3 is typically used fo r:

• toilets, cabinet showers and washbasins in for
instance toilet trailers and

• toilets, c abinet showers and washbasins installed
in connection with the renovation or

6

modernisation of existing buildings, where the

6

location may be re mote fr om th e m ai n so il pipe s o

6

that a natural slope cannot be established.

7

Sololift+ PWC-3 is only suitable for pum ping

8

wastewater from a cabi net sho wer an d a washb asi n

8

as well as sewage wa te r from a toile t c on taini ng
toilet paper and faeces. The pumping of liquids

9

containing other material may cause faults and limit

9

the scope of our guarantee.

9

10

1.2 Pumped liquids

10

Wastewater from a cabinet shower and a washbasin

10

as well as sewage wa te r from a toile t c on taini ng

10

toilet paper and faeces.

10

Liquid temperature: Maximum 40 °C.
Ordinary liquids for cleaning of the units connected.

11

pH value: 4 to 10.

12

Note:

13

Sololift+ PWC-3 must not pump:

13

• strong chemicals or solvents

13

• objects such as plastic, cardboard, sanitary
towels, diapers, hair (it is advisable to install a
strainer in a cabinet shower for collection of hair),
tampons, metal objects (clips, hair pins etc.),
stones, building materials, floor cloths and
condoms.

1. General description

Sololift+ PWC-3 is a comp act au toma tic l ift ing st ati on
suitable for pumping of wastewater off places where
wastewater canno t be led dir ec tly to the se wer by
means of a natural downward slope.

6

2. Product description

1

2

3

7

8

9

4

6

5

The Sololift+ PWC-3 tank is made of lig ht pla stic
material with an easy-to-clean surface. Installed
correctly, the Sololift+ PWC-3 is m ain te na n ce- fr ee .
Sololift+ PWC-3 has three connections besides the
toilet connection .

A cutter systems chops up objects in the wastewater
entering the tank.

The motor is ve ry p ow e rf ul and designed fo r
demanding applications and continuous operation.

Sololift+ PWC-3 is equipped with a le vel switch for
automatic start and stop of the pump. See start and
stop levels in section 8. Technical data.

The tank is vented through a carbon filter in the vent
valve in the top co ver.

Fig. 1

TM02 9375 2504

Pos. Description

1 Discharge connection
2 Connection in top cover
3 Side connection
4 Floor fittings
5 Vent valve
6 Connecting cable
7Top cover
8Tank
9 Toilet connection

7

2.1 Accessories inc luded

ACDEFGH

529

500

172

327.5

270.5

180

513

DN 40

DN 40

The following parts are supplied with Solo lift+
PWC-3 for the installation. The letters will be used
when describing the installation.

Fig. 2

Quantity Description Pos.

Rubber sleeves for connection

2

in top cover (∅40)

1 Discharge elbow (∅32) C

Metal clips for toilet connectio n,

8

sleeve and discharge elbow
Blanking plugs for side

2

TM02 9376 1408

connection
2 Screws for floor fittin gs F
2 Floor fitti ng s G
1 Non-retur n val ve H

2.2 Dimensions

The following dimensional s ket ches sh ow the dimen sion s o f Solo lift+ PWC -3.

A

D

E

Fig. 3

8

TM02 9344 2504

3. Installation

C

Rp

Ra

ø40

max. 6 m

-3 %

-1 %

-3 %

ø23/28/32 mm

The installation must be carried out according to
local regulations and directives. Sololift+ PWC-3
must be installed in the same room as the units
connected.

Please note that al l S o lolift+ mo d els m ust b e
accessible for maintenance and repair. Engineers
will not be able to c arry o ut serv ice or r epair of th e
unit without ea sy access.

3.1 Electrical i nstallat i on

The electrical installation must only be carried
out by trained personnel.

Sololift+ PWC-3 must be connected to a voltage
supply according to the nameplate.

The installation must include an earth
leakage circuit breaker for protection
against earth fault currents. This
ensures pro t ec tion when us in g a
Schuko plug or another alternative to a
plug with earth pin.

Sololift+ PWC- 3 mu st be con nec te d to a
mains switch with a minimum contact
gap of 3 mm in all poles.

The lifting station must be protected
against water splashes in accordance
with regulat io n s.

3.1.1 Wiring di agr am

3.2.1 Siphonage

If the connection to the sewer is below the bottom of
the lifting station, it is advisable to install a vent valve
to prevent siph ona ge.

If the last pipe section after a horizontal discharge
pipe is vertical, it must be two sizes bigger than the
horizontal pipe. If the horizontal pipe is ∅23, the
vertical pipe sh ould be ∅40. If the horizontal pipe is
∅32, the vertical pipe should be ∅50. See fig. 5.

Fig. 5

3.2.2 Application sketch

TM03 0666 0405TM02 9407 2504

Fig. 4

3.1.2 Motor protection

In case of overtemperature a thermal
overload swit ch cu t s o u t t he mot o r an d
cuts it in wh en t h e m o t or ha s cooled
sufficiently.

3.2 Mechanical i nstallat io n

The floor fittings G must be fitted to preve nt uplift in
case the room is flooded. Sololift+ PWC-3 should be
installed with adequate access for maintenance.

TM02 9286 2204

Fig. 6

3.2.3 Connection to toilet

Sololift+ PWC-3 should be used for a toilet with
horizontal outlet according to EN 33 or EN 37. The
toilet must u s e at le ast 6 litres pe r f l us h.

Push the lifting station against the toilet and pull the
sleeve over the toilet discharge so that the joint is
covered.

Fit the clip and make sure that the sleeve is in the
correct position.

9

1%

max 35m

max 50m

max 60m

max 70m

2 m

3 m

4 m

5 m

max 20m

6 m

1 m

max 80m

3.3 Connection in top cover

Cut off the stub end in the cover usin g a sharp knife
or a saw with fine teeth. The edges must be cut at
right angles t o th e ho le t o en su re a goo d f ast eni n g of
sleeve A. Rem ov e r o ug h ed ge s.

Fig. 7

Secure sleeve A by means of t he metal clip D.

3.4 Side connection

Use sleeve A and me ta l cl i p D. I f a s i de con nec t ion i s
not used, it mus t be blan ke d o f f by me ans o f t he pl ug
E. Lubricate the O-ring, if necessary, before fitting it.

3.4.1 Conne ctio n of ca bin et sho wer
Note: The top of the w at e r tr ap of t h e ca bi ne t s ho we r

must be at least 150 mm above the bottom of the
Sololift+ PWC-3 tank.

Fit the inlet pipe from the cabinet shower to one of
the side connections.

It is advisable to install a strainer in the outlet grating
of the cabinet sh o wer f or co ll e ctio n of h air.

3.5 Connection of discharge pipe

The discharge pipe must be of a material suitable for
raw sewage and have an external diameter of 23, 28
or 32 mm.

It is advisab le to use a minimum ∅25 di scharge pipe
according to E N 12050-3.

Fit the discharge elbow C using clip D.
The non-return valve must be fitted as shown below.

Fig. 8

Adapt the disc harg e elbow C, if nec ess ary, by cut ting
it.

It is advisable to fit a dra in plu g at the bo ttom of the
vertical pipe se ct ion fo r use in case of r epair o f th e
discharge pipe.

3.6 Pipework

The following drawing shows the maximum length of
vertical and horizontal discharge pipes.

It is recommended that the first part of the discharge
pipe is vertical.

All horizontal pipes must have a fall:
Discharge pipe: Minimum 1 % .
Inlet pipes: Minimum 3 %.

If the discharge pipe is more than 10 metres long, a
pipe one size bigger must be used after 10 metres,
for instance a ∅ 28 pipe for the first 10 metres and
then ∅32.

TM02 9296 2204TM03 0145 4204

Fig. 9

The discharg e pi pe m ust b e take n a b ove t he
backflow level (i.e. main sewer level). The pipew ork
from this point must be made w i th pi pe siz es of at
least ∅40.

4. Start-up

1. Check that the installation is correct.

2. Switch on the elec tr icity su pply.

3. Flush th e t oilet and check th a t the pump starts
and stops correct ly.
If the pump star ts, So lolift+ P WC- 3 is r e ad y f or
use.
If the pump do es no t star t, se e s ection 6. Fault
finding chart.

4. Check that all pipes and connections are tight.

Note: The toilet must not be u se d un til Solo lift+
PWC-3 has been connected correctly.

TM02 9410 2504

10

5. Maintenance

Sololift+ PWC-3 is practically maintenance-free.
However, regular use and cleaning will e ns ure
faultless operation and a long operating life.

To prevent unnecessary pumping, it should be
checked that the toile t cist ern and po ssi ble wate r
taps are tight.

Before starting work on the pump,
make sure that th e fus e has be en
removed, th e plug has be en pu lled out
of the socket or the ele c tr ic it y su p pl y
has been switched off. Make sure that
the electricity supply cannot be
accidentally switched on.

All rotating parts must have stopped
moving.

Any repairs to the motor and electric
components must only be performed
by trained service personnel.

Cleaning the Sololift+ PWC-3

Sololift+ PWC-3 is normally kept clean through
regular flushing of the to i let .

For systems which ar e used rarely, occasional
internal cleaning is recommended which is
performed as follows:

1. Switch off the electricity supply.

2. Put detergent into the toilet bowl and flush.

3. Let the dete rg en t work for ap prox. five minute s.

4. Switch on the electricity supply and flush.

5. Flush once again when the Sololift+ PWC-3 has
pumped.

Cleaning the toilet, cabinet shower and
washbasin

After cleaning the units connected, flush the toilet
once more with clean water.

Periods of non-use

If the Sololift+ PWC-3 is not going to be used for a
long period, it is recommended to flush twice with
clean water and t urn off t he wa te r su pply t o all units
connected.

Frost protection

It is advisable to make the lifting station frost-proof if
there is a risk of frost, e.g. in a weekend cottage
during the winter. Empty the tank, seePeriods of
non-use or add antifreeze.

11

6. Fault finding chart

Before starti ng wor k on th e pump , mak e sure th at th e fus e has be en re move d, the plug has
been pulled out of the socket or the electricity supply has been switched off. Make sure that
the electricity supply cannot be accidentally switched on.

All rotating parts must have stopped moving.
Any repairs to the motor and electric components must only be performed by trained service

personnel.

Fault Cause Remedy

1. Motor does not operate when
tank is filled above s tart
level.

2. Motor hums, but does not
operate.

3. Motor operates continuously
or at regular intervals.

4. Motor runs, but does not
evacuate water.

5. Sololift+ evacuates slowly. a) Strainer blocked. Remove and clean strainer.

6. R attlin g n oise fr om So lo lift+,
but waste is cl ea re d.

7. Odour from the tank. a) Carbon filter contaminated. Replace carbon filter.

a) Electrical supply failure. Check electrical supply.
b) Fuse blown.

If new fuse b low s at on ce , e i th er
cable or motor is faulty.

c) Ob st ru cti o n ; t he rm al ov er l o ad

switch tripped.

d) Level switch defective. Replace the lifting station.
a) Impeller obstructed. Remove obstruction and check for

b) Motor/capacitor defective. Replace the lifting station.
a) Water leaking from in let in to

unit.

b) Water leaking back into unit

from discharg e pi p e.
c) Level switch defective. Replace the lifting station.
a) Pump bl oc ked . Clear obstruction.
b) Air in pump. Check tank vent va lve is cle ar.

c) In tern al blo ck age in dis cha rge . Clear obstruc tion.

d) Blockage in discharge pipe. Clear obstruction.

b) Air ventilation blocked. Check operation of vent valve.

c) Dis charge pi pe work in serte d

too far into discha rge elb ow.
d) Discharge pipe is too long or

has an excessive number of

bends.

e) The pump housing is leaky. Replace the lifting station.
a) Solid obstruction hitting impeller

or cutter kni f e.

Replace fuse.
Measure cable and motor. If cable
or motor is defective, replace the
lifting station.

Remove obstruction an d w ait
3-5 minutes until thermal overload
switch has reset.

free rotation.

Check for leaking taps/cister n.

Check internal non-return valve.

Check that carb on fil ter is n ot we t.
Check air blee d hole of pum p
discharge is not blocked.

Check non-return valve is clear.

Check that carb on fil ter is n ot we t.
Check air blee d hole of pum p
discharge is not blocked.

Reduce length o f di sc ha rg e pi p e
inserted into d i sch ar ge e lbo w.

Increase discharge pipe size
(maximum 32 mm).

Change pipewo rk to re duce nu mber
of bends.
Change bends to swept bends.

Remove obstruction.

12

7. Service kits

Subject to alte ra tio ns .

Designation

Top cover 96553044
Tank 96553059
Hose kit 96553019
Wear parts kit 96553050

Product
number

8. Technical data

Supply voltag e:

1 x 220-240 V, 50 Hz.

Power consumption

670 W.

Power factor:

cos phi 0.8.

Speed:

2850.

Rated current:

3.1 A.

Enclosure class:

IP 44.

Insulation class:

F.

Connecting cable:

1.2 m cable H05VV-F3G 0.75 mm² with Schuko plug
or 1.2 m cable H05VV-F3G 1.0 mm² without plug.

Weight:

9.5 kg net
10 kg gross.

Start and stop levels:

Start: 112 mm above tank bottom.
Stop: 92 mm above tank bottom.

Sound pressure level:

61 dB(A).

9. Disposal

Disposal of this pr o du ct or parts of it mus t be carri e d
out according to th e fo llow ing g uid eli ne s.

1. Use the local public or private waste collection
service.

2. In case such waste collection service does not
exist or cannot hand le the mate rials us ed in the
product, please deliver the product or any
hazardous materials form it to your nearest
Grundfos company or service workshop.

13
