English (US) Installation and operating instructions

Original installation and operating instructions.

CONTENTS

Page

1. Limited warranty

Products manufactured by Grundfos Pumps Corporation (Grundfos) are warranted to the original user only to be free of defects in material and workmanship for a period of 24 months from date of installation, but not more than 30 months from date of manufacture. Grundfos' liability under this warranty shall be limited to repairing or replacing at Grundfos’ option, without charge, F.O.B. Grundfos’ factory or authorized service station, any product of Grundfos manufacture. Grundfos will not be liable for any costs of removal, installation, transportation, or any other charges that may arise in connection with a warranty claim.

Products which are sold, but not manufactured by Grundfos, are subject to the warranty provided by the manufacturer of said products and not by Grundfos' warranty.

Grundfos will not be liable for damage or wear to products caused by abnormal operating conditions, accident, abuse, misuse, unauthorized alteration or repair, or if the product was not installed in accordance with Grundfos' printed installation and operating instructions and accepted codes of good practice. The warranty does not cover normal wear and tear.

To obtain service under this warranty, the defective product must be returned to the distributor or dealer of Grundfos' products from which it was purchased together with proof of purchase and installation date, failure date and supporting installation data. Unless otherwise provided, the distributor or dealer will contact Grundfos or an authorized service station for instructions. Any defective product to be returned to Grundfos or a service station must be sent freight prepaid; documentation supporting the warranty claim and/or a Return Material Authorization must be included if so instructed.

Grundfos will not be liable for any incidental or consequential damages, losses, or expenses arising from installation, use, or any other causes. There are no express or implied warranties, including merchantability or fitness for a particular purpose, which extend beyond those warranties described or referred to above. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages and some jurisdictions do not allow limitations on how long implied warranties may last. Therefore, the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from jurisdiction to jurisdiction.

Products which are repaired or replaced by Grundfos or authorized service center under the provisions of these limited warranty terms will continue to be covered by Grundfos warranty only through the remainder of the original warranty period set forth by the original purchase date.

1. Limited warranty

4

2. Symbols used in this document

5

3. Applications

5

3.1 Pumped liquids

5

4. Identification

5

4.1 Nameplate

5

4.2 Type key

6

5. Operating conditions

6

5.1 Temperatures

6

6. Installation

6

6.1 Mechanical installation

6

6.2 Electrical installation

7

7. Operation

8

7.1 Start-up

8

8. Maintenance and service

8

8.1 Maintenance

8

8.2 Service

8

9. Fault finding

9

10. Technical data

10

10.1 Sound pressure level

10

10.2 Vibration level

10

10.3 Dimensions

10

10.4 Liquid level

11

11. Disposal

12

Warning Prior to installation, read these

installation and operating instructions. Installation and operation must comply with local regulations and accepted codes of good practice.

5

English (US)

2. Symbols used in this d ocument

3. Applications

The Grundfos MTA pump is a single-stage centrifugal pump designed for the pumping of cooling lubricants and cutting oil for machine tools.

3.1 Pumped liqu ids

4. Identification

4.1 Nameplate

Fig. 1 Example of nameplate

Warning If these safety instructions are not

observed, it may result in pe rsonal injury.

Warning If these instructions are not

observed, it may lead to electric shock with consequent risk of serious personal injury or death.

Note

Notes or instructions that make the job easier and ensure safe operation.

Pump type

Max. particle size

[inch (mm)]

MTA 30 MTA 60

0.16 - 0.20 (4 - 5)

MTA 90 MTA 120 MTA 200

0.31 - 0.39

(8 - 10)

MTA 20H MTA 40H MTA 70H MTA 100H

0.16 - 0.20 (4 - 5)

Max. kinematic viscosity [cSt] 90

Warning Do not use the pump for flammable

liquids, such as diesel oil, petrol or similar liquids.

TM05 1444 2711

Pos. Description

1 Production code ((YYWW)) 2 Product number 3 Type designation (see 4.2 Type key) 4 Serial number 5 Model 6 Frequency 7 Supply voltage 8 Full-load current

9 Maximum current 10 Motor input power 11 Rated spee d 12 Rated flow 13 Rated head

14

Efficiency class

(applies only to MTA 200) 15 Motor enclosure class 16 Motor insulation class 17 Rated motor output power

18

Maximum temperature of pumped

liquid 19 Pipe connection 20 Motor drive-end bearing 21 Motor non-drive-end bearing

Type PN

PC f U I

1/1

lmax P

1

n Q

nom

Hnom

60

3x208-230

1.2

1.5

240

3505

10 25

Hz V A A W min GPM Feet

f U I

1/1

lmax P

1

n Q

nom

Hnom

60

460

0.7

0.8

246

3510

10

25

IE3 77.0

Hz V A A W min GPM Feet

Eff. IE3 80.7 % Eff. % IP Insulation class54F

Rated P

2

tliq

Pipe conn. DE NDE

NPT / ” 6204ZZ 6202ZZ

HP°F1/4

140

MTA 60-180 A-WB-A-B 97123456 1028

Model A SN

0003

Made in Korea

-1 -1

3

4

123 45

6 7 8

9 10 11 12 13 14 15

16

17

18 19 20

21

6

English (US)

4.2 Type key

5. Operating conditions

5.1 Temperatures

6. Installation

6.1 Mechanical installation

6.1.1 Pump position

Fig. 2 Correct mounting position

The pump is designed for tank mounting in the vertical position. The pump is positioned in a hole cut into the cover of the tank (upper side) and secured to the tank by hexagon head screws through the holes in the mounting flange. We recommend to fit a sealing gasket between pump flange and tank.

For ventilation and cooling, leave a clearance of minimum 2" (50 mm) above the motor.

The pump is designed for indoor operation only. Do not spray liquids directly on the motor.

Example MTA 60 H -180 -A -WB -A -B

Type range Rated flow [l/min] Pressure type Installation length [mm]

Pump version

A = Standard version

Thread type

WB = Internal NPT thread W = Internal Rp thread

Impeller material

A = PAA GF50 B = Bronze

Suction

T=Top B=Bottom

Permissible liquid temperature [°F (°C)]

+32 to

+140

(0 to +60)

Maximum permissible ambient temperature during operation [°F (°C)]

+104

(+40)

Permissible ambient temperature during storage [°F (°C)]

-58 to +158 (-50 to

+70)

Warning Position the pump so that persons

cannot accidentally come into contact with hot surfaces.

Warning Position the pump so that persons

cannot accidentally come into contact with the rotating parts.

Note

MTA pumps can only be mounted in the vertical position.

TM05 1690 4411

Mín. 2"

7

English (US)

6.1.2 Terminal box positions

The terminal box of most of the MTA pump types can be turned to another position after delivery. See the table below.

● The terminal box can be turned to another position after delivery.

( ● ) The terminal box cannot be turned to

another position after delivery.

Fig. 3 Possible terminal box positions

(top view)

To turn the terminal box to another position, do as follows:

1. Remove the bolts securing the motor to the pump.

2. Turn the motor to the required position.

3. Refit and tighten the bolts securing the motor to the pump.

Connect the electric motor to the power supply as shown in the diagram in the terminal box cover.

6.2 Electrical installation

6.2.1 Electrical connection

Carry out the electrical connection according to local regulations.

Check that the supply voltage and frequency correspond to the values stated on the nameplate.

The operating voltage and frequency are marked on the pump nameplate. Make sure that the motor is suitable for the power supply available.

The motor must be connected to a motor-protective circuit breaker.

We do not recommend operation via frequency converter.

Pump type

Terminal box positions

9 o’clock

(standard)

3 o’clock

MTA 30

●●

MTA 60

●●

MTA 90

●●

MTA 120

●

( ● )

MTA 200

●

( ● )

MTA 20H

●●

MTA 40H

●●

MTA 70H

●●

MTA 100H

●

( ● )

TM05 1759 3611TM05 1760 3611

Outlet

Standard

9 o’clock

Outlet

3 o’clock

Warning Before making connections in the

pump terminal box, make sure the power supply has been switched off.

8

English (US)

7. Operation

7.1 Start-up

The pump can be started against an open or a closed discharge valve.

Before starting the pump:

• Make sure that all pipe connections are tight.

• Make sure that the pump is immersed to the recommended level.

• Make sure that chip trays are not blocked by impurities.

Start the pump as follows:

1. See the correct direction of rotation of the pump on the motor fan cover or on the sight glass. When seen from the top, the pump should rotate counter-clockwise.

2. Start the pump and check the direction of rotation.

Fig. 4 Motor fan cover with indication of

the correct direction of rotation

Fig. 5 Sight glass with indication of the

correct direction of rotation

8. Maintenance and service

8.1 Maintenance

Pumps installed in accordance with these instructions require very little maintenance.

8.1.1 Lubrication

The motor ball bearings are grease-packed and sealed for life. No further lubrication is necessary.

8.1.2 Filters

Chip trays, filters, etc. should be cleaned at regular intervals to ensure a correct flow of liquid. This will also increase the pump l ife.

8.1.3 Periodic checks

Make the following checks at regular intervals, depending on the conditions and time of operation.

• Check the quantity of liquid and operating pressure.

• Check that there are no leaks.

• Check that the motor is not overheating.

• Check the tripping of the motor-protective circuit breaker.

• Check that all control devices are operating satisfactorily.

If the above checks do not reveal any abnormal operating details, no further checks are necessary.

Should any faults be found, see section 9. Fault finding.

8.2 Service

8.2.1 Contaminated pumps

Before the pump is returned to Grundfos for service, the certificate of cleanliness must be filled in and sent to Grundfos. See page 10. If Grundfos is requested to service the pump, it must be cleaned before it is returned.

If the above is not fulfilled, Grundfos can refuse to accept the pump for service. Possible costs of returning the pump are to be paid by the customer.

TM04 8004 2610TM04 8003 2610

Warning If used for a liquid which is

injurious to health or toxic, the pump will be classified as contaminated.

9

English (US)

9. Fault finding

Warning Before starting fault finding, switch off the power supply.

Make sure that the power supply cannot be accidentally switched on.

Fault Cause Remedy

1. Motor does not run when power supply is switched on.

a) Supply failure. Connect the power supply. b) Fuses are blown. Replace the fuses. c) Motor-protective circuit breaker

has tripped.

Reactivate the motor protection.

d) Main contacts in motor-protective

circuit breaker are not making contact or the coil is faulty.

Replace the contacts or the magnetic coil.

e) Control circuit is defective. Repair the control circuit. f) Motor is defective. Replace the pump.

2. Motor-protective circuit breaker trips immediately when power supply is switched on.

a) Fuse on one phase is blown. Replace the fuse. b) Contacts in motor-protective

circuit breaker are faulty.

Replace the contacts in the motor-protective circuit breaker.

c) Cable connection is loose or

faulty.

Fasten or replace the cable

connection. d) Motor winding is defective. Replace the pump. e) Pump mechanically blocked. Remove the mechanical blocking of

the pump. f) Overload setting is too low. Set the motor-protective circuit

breaker correctly.

3. Motor-protective circuit breaker trips occasionally.

a) Overload setting is too low. Set the motor-protective circuit

breaker correctly.

b) Low voltage at peak times. Check the power supply.

4. Motor-protective circuit breaker has not tripped, but the pump does not run.

a) Check 1 a), b), d) and e).

5. Pump runs, but gives no liquid, or pump capacity is not constant.

a) Pump inlet partly blocked by

impurities.

Clean the inlet.

b) Liquid level in tank is too low. Increase the liquid level. c) Pump rotates in the wrong

direction.

Change the direction of rotation of the motor by switching any two of the phases.

10

English (US)

10. Technical data

10.1 Sound pressure level

10.2 Vibration level

Vibration velocity RMS < 0.07 in/s (1.8 mm/s). Vibration according to ISO 10816-1 class IB.

10.3 Dimensions

10.3.1 Installation dimensions

Fig. 6 Installation dimensions

Enclosure class to IEC 60034-5 IP54 Insulation class F Maximum voltage fluctuation to

IEC 60034

± 10 %

Recommended maximum number of starts per hour

250

Note

Pay attention to potential condensation problems in humid areas.

Pump type

Rated P2

[W]

L

pA

[dB(A)]

60 Hz

MTA 30 100 < 4 5 MTA 60 180 < 4 5 MTA 90 250 < 4 5 MTA 120 400 < 62 MTA 200 750 < 62 MTA 20H 100 < 45 MTA 40H 180 < 45 MTA 70H 250 < 45 MTA 100H 400 < 62

TM05 1466 2711

Pump type

C

D1

[inch]

D2

[inch (mm)]L[inch (mm)]

X ∅

[inch

MTA 30

1/2"

NPT

5.20

(132)

4.57

(116)

3.94

(100)

0.27 (7)

MTA 60

3/4"

NPT

6.30

(160)

5.63 143

4.43

(112.5)

0.39 (10)

MTA 90

3/4"

NPT

6.30

(160)

6.06

(154)

4.43

(112.5)

0.39 (10)

MTA 120

1 1/4"

NPT

7.09

(180)

6.10

(155)

4.98

(126.5)

0.39 (10)

MTA 200

1 1/2"

NPT

8.66

(220)

7.87

(200)

5.30

(134.5)

0.47 (12)

MTA 20H

1/2"

NPT

5.20

(132)

4.57

(116)

3.94

(100)

0.27 (7)

MTA 40H

3/4"

NPT

6.30

(160)

5.63

(143)

4.43

(112.5)

0.39

(10)

MTA 70H

3/4"

NPT

6.30

(160)

6.06

(154)

4.43

(112.5)

0.39

(10)

MTA 100H 1" NPT

7.09

(180)

6.89

(175)

4.88

(124)

0.39

(10)

* Applies only to MTA 120

11

English (US)

10.3.2 Tank hole and cable entry hole dimensions

Fig. 7 Tank hole an d cable entry h ole

dimensions

10.4 Liquid level

10.4.1 MTA with top suction

Fig. 8 MTA with top suction

* Min. liquid l evel (full performance) ** Min. permissible liquid level

(reduced performance)

TM05 0632 1311

Pump type

Tank hole

Cable entry

hole

D1 ∅

[inch (mm)]

D2 ∅

[inch (mm)]

MTA 30 3.94 (90) 0.87 (22) MTA 60 4.52 (115) 0.87 (22) MTA 90 5.04 (128) 0.87 (22) MTA 120 5.31 (135) 0.87 (22) MTA 200 7.09 (180) 0.87 (22) MTA 20H 3.94 (100) 0.87 (22) MTA 40H 5.31 (135) 0.87 (22) MTA 70H 5.31 (135) 0.87 (22) MTA 100H 6.10 (155) 0.87 (22)

TM04 7992 4211

Pump type

H1

[inch

(mm)]

H2 *

[inch

(mm)]

H3 ** [inch

(mm)]

MTA 30 0.59 (15) 2.36 (60) 1.97 (50) MTA 60 0.79 (20) 2.76 (70) 1.77 (45) MTA 90 0.79 (20) 3.35 (85) 2.28 (58) MTA 120 0.79 (20) 4.33 (110) 2.76 (70) MTA 20H 0.59 (15) 1.97 (50) 1.57 (40) MTA 40H 0.79 (20) 2.76 (70) 1.57 (40) MTA 70H 0.79 (20) 3.15 (80) 1.97 (50) MTA 100H 0.79 (20) 4.34 (110) 2.36 (60)

H1

H2

H3

Max. liquid level

Min. liquid level

Tank

12

English (US)

10.4.2 MTA with bottom suction

Fig. 9 MTA with bottom suction

* Min. liquid level (full performance)

11 . Dis po sa l

This product or parts of it must be disposed of in an environmentally sound way:

1. Use the public or private waste collection service.

2. If this is not possible, contact the nearest Grundfos company or service workshop.

Subject to alterations.

TM04 7993 4211

Pump type

H1

[inch

(mm)]

H2 *

[inch

(mm)]

H4

[inch

(mm)]

MTA 30 0.59 (15) 0.79 (20) 0.39 (10) MTA 60 0.79 (20) 0.79 (20) 0.39 (10) MTA 90 0.79 (20) 0.98 (25) 0.59 (15) MTA 120 0.79 (20) 0.98 (25) 0.79 (20) MTA 200 0.98 (25) 0.98 (50) 1.18 (30)

H1

H4

H2

Max. liquid level

Min. liquid level

Tank

32

Appendix

Appendix 1

Certificate of cleanliness

Please provide all pertinent information

Product Description

Product Number Quantity

The rThe r

The r

efef

ef

erer

er

enced prenced pr

enced pr

oducoduc

oduc

tt

t

has been e has been e

has been e

xposed to toxposed to to

xposed to to

xic or hazxic or haz

xic or haz

arar

ar

dous madous ma

dous ma

terials:terials:

terials:

YY

Y

ES NOES NO

ES NO

If yIf y

If y

eses

es

, c, c

, c

omplete SECTomplete SECT

omplete SECT

ION A. If noION A. If no

ION A. If no

, c, c

, c

on

onon

on

tinue to SECTtinue to SECT

tinue to SECT

ION BION B

ION B

..

.

APPLICATION

PP

P

lease speciflease specif

lease specif

y all hazy all haz

y all haz

arar

ar

dous madous ma

dous ma

terials/terials/

terials/

substances used with the rsubstances used with the r

substances used with the r

efef

ef

erer

er

enced prenced pr

enced pr

oducoduc

oduc

t(st(s

t(s

).).

).

PP

P

rr

r

oo

o

vide the Mavide the Ma

vide the Ma

terial Safterial Saf

terial Saf

ety Daety Da

ety Da

ta Sheetta Sheet

ta Sheet

f

f f

f

or all maor all ma

or all ma

terials rterials r

terials r

efef

ef

erer

er

enced or listenced or list

enced or list

pr pr

pr

ecautions to be takecautions to be tak

ecautions to be tak

en when handling theseen when handling these

en when handling these

substances. Alsosubstances. Also

substances. Also

, pr, pr

, pr

oo

o

vide anvide an

vide an

y acy ac

y ac

tions to be taktions to be tak

tions to be tak

en in the een in the e

en in the e

vv

v

enen

en

tt

t

of human c of human c

of human c

onon

on

tactac

tac

tt

t

with an with an

with an

y liquid within the pry liquid within the pr

y liquid within the pr

oducoduc

oduc

tt

t

(e (e

(e

vv

v

enen

en

afaf

af

ter cleaning and/ter cleaning and/

ter cleaning and/

or flushing).or flushing).

or flushing).

The prThe pr

The pr

oducoduc

oduc

tt

t

r r

r

eturned has been deceturned has been dec

eturned has been dec

onon

on

taminatamina

tamina

ted, drted, dr

ted, dr

ained of liquid and is safained of liquid and is saf

ained of liquid and is saf

e to handlee to handle

e to handle

. P. P

. P

rr

r

oo

o

vide decvide dec

vide dec

onon

on

taminatamina

tamina

tion methodtion method

tion method

used.used.

used.

S

ECTION

A: T

OXIC CLEARANCE

(To be completed if applied substances are hazardous)

Initial/DaInitial/Da

Initial/Da

tete

te

The prThe pr

The pr

oducoduc

oduc

tt

t

r r

r

eturned has noteturned has not

eturned has not

handled or been in c handled or been in c

handled or been in c

onon

on

tactac

tac

tt

t

with an with an

with an

y toy to

y to

xic or hazxic or haz

xic or haz

arar

ar

dous substances. dous substances.

dous substances.

The prThe pr

The pr

oducoduc

oduc

tt

t

has been has been

has been

drdr

dr

ained of liquid and is safained of liquid and is saf

ained of liquid and is saf

e to handle

e to handlee to handle

e to handle

..

.

S

ECTION

B: NON-T

OXIC CLEARANCE

(To be completed if applied substances

arar

ar

e note not

e not

hazardous)

Initial/DaInitial/Da

Initial/Da

tete

te

I herI her

I her

eby declareby declar

eby declar

e thae tha

e tha

tt

t

the c the c

the c

onon

on

tenten

ten

ts of this cts of this c

ts of this c

onsignmenonsignmen

onsignmen

tt

t

ar ar

ar

e fully and accure fully and accur

e fully and accur

aa

a

tely described abotely described abo

tely described abo

vv

v

e by pre by pr

e by pr

oper shipping name and aroper shipping name and ar

oper shipping name and ar

ee

e

classified, packclassified, pack

classified, pack

ed, marked, mark

ed, mark

ed and labeled, and ar

ed and labeled, and ared and labeled, and ar

ed and labeled, and ar

e in all re in all r

e in all r

especespec

espec

ts in prts in pr

ts in pr

oper coper c

oper c

ondition fondition f

ondition f

or tror tr

or tr

ansporanspor

anspor

t, by all modest, by all modes

t, by all modes

, acc, acc

, acc

oror

or

ding to applicableding to applicable

ding to applicable

inin

in

ternaterna

terna

tional and national and na

tional and na

tional gotional go

tional go

vv

v

ernmenernmen

ernmen

tal rtal r

tal r

egulaegula

egula

tions. Health and saftions. Health and saf

tions. Health and saf

ety issues arety issues ar

ety issues ar

e clearly understood and will be give clearly understood and will be giv

e clearly understood and will be giv

enen

en

cc

c

onsideronsider

onsider

aa

a

tion during shipmention during shipmen

tion during shipmen

tt

t

. (A r. (A r

. (A r

epair or inspecepair or inspec

epair or inspec

tion of prtion of pr

tion of pr

oducoduc

oduc

tt

t

will only be under will only be under

will only be under

taktak

tak

en when this ceren when this cer

en when this cer

tificatifica

tifica

te has been cte has been c

te has been c

ompletedompleted

ompleted

and authorizand authoriz

and authoriz

ed by a qualified member of stafed by a qualified member of staf

ed by a qualified member of staf

f emplof emplo

f emplo

yy

y

ed by the red by the r

ed by the r

eturning ceturning c

eturning c

ompanompan

ompan

yy

y

.).)

.)

RR

R

adioacadioac

adioac

tivtiv

tiv

e pre pr

e pr

oducoduc

oduc

ts will notts will not

ts will not

be accepted f be accepted f

be accepted f

or ror r

or r

epairepair

epair

..

. A return material authorization number from Grundfos, along with a completed and signed copy of

this form must accompany the returned product. It is the senders responsibility to package, transport and complete the shipping documents regarding the nature of the product shipped. Irrespective of this, Grundfos reserves the right to reject the service order for other reasons. Grundfos will rely on this representation and will look to the customer for reimbursement of any and all costs, claims or damages incurred, including attorney’s fees, if any representation is not correct.

CC

C

OO

O

MPMP

MP

ANAN

AN

YY

Y

NANA

NA

MEME

ME

NANA

NA

MEME

ME

PP

P

OO

O

SITSIT

SIT

IONION

ION

SIGNASIGNA

SIGNA

TT

T

UU

U

RR

R

EE

E

PHONPHON

PHON

EE

E

GRUNDFOS

Certificate of Cleanliness

Health and Safety Clearance Form

Grundfos Pumps Corporation 17100 W. 118th Terrace Olathe, Kansas 66062 Telephone: 913.227.3400 Fax: 913.227.3500

www.grundfos.com

L-QC-FRM-002 Rev. 08/03

PRINTED IN USA

33

34

Grundfos companies

USA

GRUNDFOS Pumps Corporation 17100 West 118th Terr ace Olathe, Kansas 66061 Phone: +1-913-227-34 00 Telefax: +1-913-227-3500

Canada

GRUNDFOS Canada Inc. 2941 Brighton Road Oakville, Ontario L6H 6C9 Phone: +1-905 829 9533 Telefax: +1-905 829 9512

México

Bombas GRUNDFOS de México S.A. de C.V. Boulevard TLC No. 15 Parque Industrial Stiva Aeropuerto Apodaca, N.L.C.P. 66600 Phone: +52-81-8144 4000 Telefax: +52-81-8144 4010

www.grundfos.com

Being responsible is our foundation

Thinking ahead makes it possible

Innovation is the essence

L-MT-TL-002

98097625 0212

ECM: 1083022

Grundfos MTA Series, MTA 60, MTA 90, MTA 120, MTA 200 Installation And Operating Instructions Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
