Page 1
Position Qty. Description Single Price
1 Price on requestCM5-4 A-R-G-V-AQQV
Note! Product picture may differ from actual product
Product No.: 96806788
CM is a compact horizontal multistage centrifugal pump, close-coupled with a:
3-phase, 220-240D/380-415Y V, 50 HzHz. Foot mounted motor.
The pump is with axial suction port and radial discharge port including a special designed
mechanical shaft seal in the solution AQQV.
Shaft, impellers, chambers and filling plugs are made of stainless steel.
Suction and discharge are made of Stainless steel.
The CM can also operate as a CME by connecting the motor to a CUE. Please find more
information in the CUE part of Win/WebCAPS.
Liquid:
Liquid temperature range: -20 .. 90 °C
Liquid temp: 20 °C
Density: 998.2 kg/m³
Technical:
Speed for pump data: 2900 rpm
Actual calculated flow: 4.7 m³/h
Resulting head of the pump: 28.8 m
Shaft seal: AQQV
Maximum operating pressure: 16 bar
Approvals on nameplate: CE,WRAS,ACS
Materials:
Pump housing: Stainless steel
DIN W.-Nr. 1.4401
AISI 316
Impeller: Stainless steel
DIN W.-Nr. 1.4401
AISI 316
Rubber: FKM
Installation:
Maximum ambient temperature: 55 °C
Maximum operating pressure: 16 bar
Max pressure at stated temp: 16 bar / 90 °C
Flange standard: WHITWORTH THREAD RP
Pump inlet: Rp 1 1/4
Pump outlet: Rp 1
Electrical data:
Printed from Grundfos CAPS
1/5
Page 2
Position Qty. Description Single Price
Rated power - P2: 0.84 kW
Mains frequency: 50 Hz
Rated voltage: 3 x 220-240D/380-415Y V
Service factor: 1
Rated current: 3,0-3,5/1,6-1,9 A
Rated speed: 2750-2810 rpm
Enclosure class (IEC 34-5): 55
Insulation class (IEC 85): F
Others:
Net weight: 14.1 kg
Gross weight: 16.6 kg
Printed from Grundfos CAPS
2/5
Page 3
Description Value
Product name: CM5-4 A-R-G-V-AQQV
Product No: 96806788
EAN number: 5700310917351
Technical:
Speed for pump data 2900 rpm
Actual calculated flow: 4.7 m³/h
Resulting head of the pump: 28.8 m
Impellers: 4
Shaft seal: AQQV
Maximum operating pressure 16 bar
Approvals on nameplate: CE,WRAS,ACS
Pump version: A
Model: A
Materials:
Pump housing: Stainless steel
DIN W.-Nr. 1.4401
AISI 316
Impeller: Stainless steel
DIN W.-Nr. 1.4401
AISI 316
Material code: G
Rubber: FKM
Code for rubber: V
Installation:
Maximum ambient temperature: 55 °C
Maximum operating pressure 16 bar
Max pressure at stated temp 16 bar / 90 °C
Flange standard: WHITWORTH THREAD RP
Connect code: R
Pump inlet: Rp 1 1/4
Pump outlet: Rp 1
Liquid:
Liquid temperature range -20 .. 90 °C
Liquid temp: 20 °C
Density: 998.2 kg/m³
Electrical data:
Rated power - P2: 0.84 kW
Mains frequency: 50 Hz
Rated voltage: 3 x 220-240D/380-415Y V
Service factor: 1
Rated current: 3,0-3,5/1,6-1,9 A
Rated speed: 2750-2810 rpm
Enclosure class (IEC 34-5): 55
Insulation class (IEC 85): F
Motor protec: NO
Others:
Net weight: 14.1 kg
Gross weight: 16.6 kg
(m)
36
32
28
24
20
16
12
(kW)
0.8
0.6
0.4
0.2
H
8
4
0
P
0
CM5-4 3* 230 V, 50 Hz
Pumped liquid = Wasser
Liquid temperature = 20 °C
Density = 998.2 kg/m³
Q(m³/h)0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5
P1
P2
Page 4
96806788 CM5-4 50 Hz
(m)
40
36
32
28
24
20
16
H
CM5-4 3* 230 V, 50 Hz
Pumped liquid = Wasser
Liquid temperature = 20 °C
Density = 998.2 kg/m³
12
(kW)
0.8
0.6
0.4
8
4
0
P
Q(m³/h)0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5 6
P1
P2
0.2
0
Printed from Grundfos CAPS
4/5
Page 5
96806788 CM5-4 50 Hz
Rp 1
Rp 1 1/4
184
RP 3/8
89.5
124.5
149
363
96
137
273.5
214
165
75
142
125
RP 3/8
10
Note! All units are in [mm] unless others are stated.
Disclaimer: This simplified dimensional drawing does not show all details.
Printed from Grundfos CAPS
158
5/5
