23 036
EUROSTYLE COSMOPOLITAN
SINGLE HOLE SINGLE-HANDLE S-SIZE
BATHROOM FAUCET 1.2 GPM
STANDARD SPECIFICATION:
• GROHE SilkMove®
• GROHE StarLight®
• GROHE EcoJoy™
• GROHE QuickFix® installation
7
⁄8” Faucet height (when in use)
• 7
• 4” Spout reach
5
⁄16” Aerator height
• 3
• Solid brass body
• Single lever handle
1
⁄2” Nylon braided flex hoses
• 23
• 1.2gpm (WaterSense)
PRODUCT FEATURES: CERTIFICATIONS: AVAILABLE FINISHES:
2303600A
• ADA
• WaterSense
• CEC Certified
• Low Lead Certified
• CALGreen Compliant
• Massachusetts Plumbing Board Approved
• Energy Policy Act of 1992
• NSF 61
• CSA B 12 5.1
• AS M E A112 .18 .1
• Complies with lead plumbing laws
NOTE: Install this product according to the installation guide. ADA, CSA compliant when installed to the specific requirements of these regulations.
We reserve the right to make revisions without notice to product specifications. 12-06-2021
US
Tel: 1.630.582.7711 Fax: 1.630.582.7722
For the most current Specification Sheet,
go to www.grohe.us.
Canada
Tel: 1.888.644.7643 Fax: 1.905.366.2071
For the most current Specification Sheet,
go to www.grohe.ca.
Page 2
23 036
EUROSTYLE COSMOPOLITAN
SINGLE HOLE SINGLE-HANDLE S-SIZE
BATHROOM FAUCET 1.2 GPM
TECHNICAL DATA:
Product Height 6-3 /16 in
Product Length 5-7/8 in
Fitting Spout Height 3- 5 /16 in
Fitting Spout Reach 4 in
Fitting Handle Height 6-3 /16 in
GPM (Min)-GPM (Max) 1.2 gal (US)/min
Fitting No of Holes Required 1
