Gro Clock User Manual
How to use your
Frequently asked questions
Q. If the power is turned off, does the clock remember the correct time?
A. When the power goes off, the clock ‘freezes’ all the settings, including the main time, the wake up times
and brightness settings. Therefore if the power goes off for a few seconds and then back on, the time
will have been paused for a few seconds. However if the power was off say for 3 hours, then the time
will be out by 3 hours and will therefore need re–setting.
Q. If I need to keep the power on to maintain the correct time, should I worry about
electricity consumption?
A. No, your clock uses LEDs so it’s naturally energy efficient. However it also has a built–in energy saving
mode. One hour after the wake up time has activated, the clock automatically turns off coloured LED
lights and runs on a tiny amount of electricity. To re–activate just press any key and the colour LEDs will
come back.
Q. What is the difference between the night–time and day–time nap mode?
A. In a way they are very similar because the clock works in exactly the same way in both modes. Once
activated, the clock will count down and the star will change into the sun at the time set in each
mode. The reason there are two modes is so that parents who are putting their children to sleep during
the day and at night can have the two different times stored, which saves them from having to re–set
the wake up times every session.
Q. Can I make the alarm sound at any time and in any mode?
A. Yes! The time you set for the alarm is independent of the night–time or day–time nap modes. Therefore
you could have the sun coming up silently at 7am and then the alarm sounding at 7.30am.
Q. How do I know if the alarm will sound?
A. The alarm bell icon appears in the cheek of the sun/star when the alarm is switched on.
Q. How can I stop my child from playing with buttons and changing the settings?
A. Very easily, by using the key–lock function, which is similar to the function on mobile phones. (See page 5).
Q. Is there a demo mode so I can show my child how it changes from the sun to Mr Star?
A. Yes! There is a built–in demo mode which runs through all the sun and Mr Star transitions. To set the
Demo mode on, just press and hold the UP button for three seconds and the clock will show all the
transitions on a continuous loop. To turn off the Demo mode, simply press and hold the UP button for
three seconds.
Q. My screen has frozen and is not responding to the controls.
A. Switch the clock off at the mains, wait a few seconds and switch back on.
If you have any other questions, please call our customer services helpline on 0844 557 2983.
Safety
Your clock is a safe low voltage device, powered from a small mains operated power unit. For your
continued safety and the reliability of your clock, please observe the normal electrical safety precautions:
This product is not a toy. Please ensure that it is kept out of reach of children and never allow your child
to play with either the power unit or the connecting lead
Keep the product away from water and moisture. It’s intended for indoor use only
Repairs should be carried–out only by a competent engineer. There are no customer adjustments or
fuses inside the clock case
The clock has been designed to be robust, but it may be broken if dropped
The connecting lead is low voltage only, but for reliability reasons it should be treated with care
To completely disconnect the power unit, the AC/DC adapter must be unplugged from the mains
Access to the AC/DC adapter should not be obstructed whilst in use
Electro–static discharge may affect the working of your Gro–clock. If this occurs, simply switch the unit
off for several seconds and the unit will re–set
The apparatus and AC/DC adaptor shall not be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, shall be placed on apparatus and AC/DC adaptor
For use only with the power supply KB1B–060–0200D, manufactured by KS
IMPORTANT! KEEP FOR FUTURE REFERENCE
6 7
Technical Information
Height: 14.5cm
Weight: 393g
Mains Supply Voltage: 230V, 50Hz.
Power Unit: 6V at 200mA.
Your Gro–clock is fully compliant with the following EU legislation:
The EuP Regulation EC 278/2009 on external power supplies
The Low Voltage Directive: 2006/95/EC
The EMC Directive: 2004/108/EEC
The RoHS Directive: 2002/95/EC
Further information printed on rear and base of clock
When the time comes to dispose of this equipment, please help protect our environment by means of
proper disposal. Your local authorities will have special return and disposal facilities available for you.
UK, USA and worldwide PCT patents and Design rights applied for.
Patent pending
gro–group international ltd trading as The Gro Company.
The Gro Company is a trademark of gro–group holdings ltd.
All text and images © 2010 gro–group holdings ltd.
The Gro Company reserve the right to amend the product specification at any time.
All rights reserved.
IMPORTANT! KEEP FOR FUTURE REFERENCE
GCM EN 004
Manufactured and distributed worldwide by:
The Gro Company, Linhay Business Park, Ashburton, Devon TQ13 7UP, UK
UK Tel: +44 (0)844 557 2960 www.gro.co.uk
GCM EN 004.indd 1 25/05/2011 15:48
3 simple steps to use your
Step 1 Getting to know your clock
Step 2 Set the clock time
1. Select the settings menu by repeatedly pressing the button
2. Select the clock symbol by pressing the button 2 times
3. Select the hour by pressing the and buttons and then the button
4. Select the minutes by pressing the and buttons and then the button
5. Select AM or PM by pressing the button and then the button
6. Select ON or OFF by pressing the button, to choose whether the digital clock is displayed during
the timer count–down and then the button
7. Press the button to display the digital clock
Step 3 Setting the getting–up time
The Gro–clock has two independent “getting–up” modes, one for night–time sleep and one for day–time naps.
Night–time sleep — setting the morning getting–up time
This is the time that the clock will change from showing the blue stars (time to sleep) into showing the
yellow sun (time to get–up)
1. Select the settings menu by repeatedly pressing the button and then the button
2. Select the night–time alarm symbol by pressing the button and then the button
3. Select the hour by pressing the and buttons and then the button
4. Select the minutes by pressing the and buttons and then the button
5. Select AM by use of the button and then the button
6. To activate the function, press the button repeatedly until the large sun with small flashing inset
star appears, then press the button. The clock will now slowly change to a blue multi–star screen
and the count–down will commence
Note: Daily activation of the function soon becomes an important part of the going–to–sleep
routine and needs to be done in order to set your clock
Following the sun rise sequence, the sun symbol will remain displayed for two hours, before changing to the
energy saving mode where only the clock is displayed. To deactivate the function, press the button.
5
4
32
What the screen shows
The Gro–clock has four screens which are
accessed by repeated pressing of the button:
1. Digital clock
2. Night–time sleep (sun with flashing icon)
3. Day–time nap (sun with flashing
icon)
4. Settings menu
What the buttons do
Enters
Changes screen
and steps up
digital display
Changes screen
and steps down
digital display
Settings menu
Set clock
Set night–time
sleep
Set day–time
nap
LED brightness
Set audible alarm
Day–time nap — setting the getting–up time
This function works in the same way as the night–time function, with the clock again changing from the
blue stars into a yellow sun, showing your child that it is now OK to get-up.
1. Select the settings menu by repeatedly pressing the button and then the button
2. Select the day-time alarm symbol by pressing the button twice and then the button
3. Select the hour by pressing the and buttons and then the button
4. Select the minutes by pressing the and buttons and then the button
5. Select AM or PM by pressing the button and then the button
6. To activate the function, press the button repeatedly until the large sun with small flashing inset
sun appears, then press the button. The clock will now slowly change to a blue multi-star screen
and the count-down will commence
Note: Daily activation of the function soon becomes an important part of the going–to–sleep
routine and needs to be done in order to set your clock
Following the sun rise sequence, the sun symbol will remain displayed for two hours, before changing to the
energy saving mode where only the clock is displayed. To deactivate the function, press the button.
Additional Features
Setting the audible alarm
When your child reaches the age where a wake–up call becomes an advantage, the Gro–clock has an
audible alarm which may be set to occur whilst using any of the 3 main modes.
1. Select the settings menu by repeatedly pressing the button and then the button
2. Select the audible alarm symbol by pressing the button 3 times and then the button
3. Select the hour by pressing the and buttons and then the button
4. Select the minutes by pressing the and buttons and then the button
5. Select AM or PM by pressing the button and then the button
6. To activate the function, press the button to select the flashing symbol and then press the button
7. Press the button to display the digital clock
The alarm is now on and the setting is identified by the symbol in all modes.
The audible alarm sound may be cancelled by pressing either the or buttons.
To turn off the audible alarm
1. Select the settings menu by repeatedly pressing the button and then the button
2. Select the audible alarm symbol by pressing the button 3 times and then the button
3. Select the audible alarm symbol by pressing the button 3 times
4. Cancel the alarm by pressing the button to select the symbol and then the button
5. The alarm is now off
Setting the brightness
If the brightness level of the blue screen is too high at night. The level can be adjusted.
1. Select the settings menu by repeatedly pressing the button and then the button
2. Select the brightness symbol by pressing the button 4 times and then the button
3. Select the required brightness by pressing the and buttons and then the button
4. Press the button to display the digital clock
Key–lock feature
The Gro–clock has a key–lock feature, similar to mobile phones. The key–lock is best used once the sleep
modes have been activated. To switch on the key–lock just press the button and HOLD for 3 seconds
until you see a cross in the big star’s cheek. This means the key–lock is now on. To check it’s working
press or and a cross will appear on the screen. To unlock the feature, just press and hold the
button for 3 seconds until you hear a beep.
Top tip: practice this so that the child does not see you pressing and holding the keys!
The stars…
At the start there are 12 stars around Mr Star. In order to show your children the passing of time these
stars will go out evenly over the sleep or nap time. For example, if you set the Gro–clock for 12 hours, one
star will go out every hour, or if you set for 1 hour nap one star will go out every 5 minutes. When the clock
reaches the getting–up time that you set, the star disappears into a sun–rise and the sun appears.
GCM EN 004.indd 2 25/05/2011 15:48
