Page 1
MODEL T33296
MOBILE MITER SAW STAND
OWNER'S MANUAL
(For models manufactured since 07/23)
COPYRIGHT © AUGUST, 2023 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#CR22861 PRINTED IN TAIWAN
***Keep for Future Reference***
V1.0 8.2 3
Page 2
This manual provides critical safety instructions on the proper setup,
operation, maintenance, and service of this machine/tool. Save this
document, refer to it often, and use it to instruct other operators.
Failure to read, understand and follow the instructions in this manual
may result in fire or serious personal injury—including amputation,
electrocution, or death.
The owner of this machine/tool is solely responsible for its safe use.
This responsibility includes but is not limited to proper installation in
a safe environment, personnel training and usage authorization,
proper inspection and maintenance, manual availability and comprehension, application of safety devices, cutting/sanding/grinding tool
integrity, and the usage of personal protective equipment.
The manufacturer will not be held liable for injury or property damage
from negligence, improper training, machine modifications or misuse.
Some dust created by power sanding, sawing, grinding, drilling, and
other construction activities contains chemicals known to the State
of California to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement and other masonry products.
• Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals:
Work in a well ventilated area, and work with approved safety equipment, such as those dust masks that are specially designed to filter
out microscopic particles.
Page 3
Table of Contents
INTRODUCTION............................................................................................................................... 2
Contact Info.................................................................................................................................2
Specifications ..............................................................................................................................2
Manual Accuracy.........................................................................................................................2
SECTION 1: SAFETY....................................................................................................................... 3
Safety Instructions for Machinery................................................................................................3
Additional Safety for Miter Saw Stands .....................................................................................5
SECTION 2: SETUP ......................................................................................................................... 6
Unpacking ...................................................................................................................................6
Needed for Setup ........................................................................................................................6
Inventory......................................................................................................................................6
Site Considerations .....................................................................................................................7
Assembly.....................................................................................................................................8
Installing Miter Saw ...................................................................................................................11
SECTION 3: OPERATIONS ........................................................................................................... 13
Operation Overview ..................................................................................................................13
Folding & Unfolding Miter Saw Stand .......................................................................................14
SECTION 4: ACCESSORIES......................................................................................................... 15
SECTION 5: MAINTENANCE......................................................................................................... 16
Schedule ...................................................................................................................................16
Cleaning & Protecting ...............................................................................................................16
Inspection & Maintenance.........................................................................................................16
Clamping Adjustment ................................................................................................................17
SECTION 6: PARTS....................................................................................................................... 18
Main...........................................................................................................................................18
Clamping Rail............................................................................................................................20
WARRANTY & RETURNS ............................................................................................................. 21
Page 4
We stand behind our machines! If you have questions or need help, contact us with the information
below. Before contacting, make sure you get the
serial number
from the
machine ID label. This will help us help you faster.
We want your feedback on this manual. What did
you like about it? Where could it be improved?
Please take a few minutes to give us feedback.
Email: manuals@grizzly.com
We are proud to provide a high-quality owner’s
manual with your new machine!
We
instructions, specifications, drawings, and photographs
in this manual. Sometimes we make mistakes, but
our policy of continuous improvement also means
that
you receive is
slightly different than shown in the manual
If you find this to be the case, and the difference
between the manual and machine leaves you
confused or unsure about something
check our
website for an updated version. W
current
manuals and
on our web-
site at
Alternatively, you can call our Technical Support
for help. Before calling, make sure you write
down the
serial number
from the machine ID label (see below). This
information is required for us to provide proper
tech support, and it helps us determine if updated
documentation is available for your machine.
INTRODUCTION
Contact Info
and manufacture date
Grizzly Technical Support
1815 W. Battlefield
Springfield, MO 65807
Phone: (570) 546-9663
Email: techsupport@grizzly.com
Grizzly Documentation Manager
P.O. Box 2069
Bellingham, WA 98227-2069
Manual Accuracy
made every effort to be exact with the
sometimes the machine
.
,
e post
manual updates for free
www.grizzly.com.
manufacture date and
Maximum Miter Saw Size............................12 in.
Maximum Capacity (Table Only).............350 lbs.
Operating Length..........................57-1/2 - 124 in.
Operating Height ..................... 33-3/4 - 37-3/4 in.
Net Weight ................................................61 lbs.
Shipping Weight .......................................71 lbs.
Collapsed Dimensions..... 56-1/2 x 23 x 10-1/8 in.
Specifications
Manufacture Date
Serial Number
-2-
Model T33296 (Mfd. Since 07/23)
Page 5
SECTION 1: SAFETY
For Your Own Safety, Read Instruction
Manual Before Operating This Machine
The purpose of safety symbols is to attract your attention to possible hazardous conditions.
This manual uses a series of symbols and signal words intended to convey the level of importance of the safety messages. The progression of symbols is described below. Remember that
safety messages by themselves do not eliminate danger and are not a substitute for proper
accident prevention measures. Always use common sense and good judgment.
Indicates an imminently hazardous situation which, if not avoided,
WILL result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
COULD result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
MAY result in minor or moderate injury. It may also be used to alert
against unsafe practices.
Alerts the user to useful information about proper operation of the
NOTICE
machine to avoid machine damage.
Safety Instructions for Machinery
OWNER’S MANUAL. Read and understand this
owner’s manual BEFORE using machine.
TRAINED OPERATORS ONLY. Untrained operators have a higher risk of being hurt or killed.
Only allow trained/supervised people to use this
machine. When machine is not being used, disconnect power, remove switch keys, or lock-out
machine to prevent unauthorized use—especially
around children. Make your workshop kid proof!
DANGEROUS ENVIRONMENTS. Do not use
machinery in areas that are wet, cluttered, or have
poor lighting. Operating machinery in these areas
greatly increases the risk of accidents and injury.
MENTAL ALERTNESS REQUIRED. Full mental
alertness is required for safe operation of machinery. Never operate under the influence of drugs or
alcohol, when tired, or when distracted.
ELECTRICAL EQUIPMENT INJURY RISKS.
You can be shocked, burned, or killed by touching
live electrical components or improperly grounded
machinery. To reduce this risk, only allow qualified
service personnel to do electrical installation or
repair work, and always disconnect power before
accessing or exposing electrical equipment.
DISCONNECT POWER FIRST.
nect machine from power supply BEFORE making adjustments, changing tooling, or servicing
machine. This prevents an injury risk from unintended startup or contact with live electrical components.
EYE PROTECTION. Always wear ANSI-approved
safety glasses or a face shield when operating or
observing machinery to reduce the risk of eye
injury or blindness from flying particles. Everyday
eyeglasses are NOT approved safety glasses.
Always discon-
Model T33296 (Mfd. Since 07/23)
-3-
Page 6
WEARING PROPER APPAREL. Do not wear
loose clothing, gloves, neckties, or jewelry that
can become entangled in moving parts. Always tie
back or cover long hair. Wear non-slip footwear to
reduce risk of slipping and losing control or accidentally contacting cutting tool or moving parts.
HAZARDOUS DUST. Dust created by machinery
operations may cause cancer, birth defects, or
long-term respiratory damage. Be aware of dust
hazards associated with each workpiece material. Always wear a NIOSH-approved respirator to
reduce your risk.
HEARING PROTECTION. Always wear hearing protection when operating or observing loud
machinery. Extended exposure to this noise
without hearing protection can cause permanent
hearing loss.
REMOVE ADJUSTING TOOLS. Tools left on
machinery can become dangerous projectiles
upon startup. Never leave chuck keys, wrenches,
or any other tools on machine. Always verify
removal before starting!
USE CORRECT TOOL FOR THE JOB. Only use
this tool for its intended purpose—do not force
it or an attachment to do a job for which it was
not designed. Never make unapproved modifications—modifying tool or using it differently than
intended may result in malfunction or mechanical
failure that can lead to personal injury or death!
AWKWARD POSITIONS. Keep proper footing
and balance at all times when operating machine.
Do not overreach! Avoid awkward hand positions
that make workpiece control difficult or increase
the risk of accidental injury.
CHILDREN & BYSTANDERS. Keep children and
bystanders at a safe distance from the work area.
Stop using machine if they become a distraction.
GUARDS & COVERS. Guards and covers reduce
accidental contact with moving parts or flying
debris. Make sure they are properly installed,
undamaged, and working correctly BEFORE
operating machine.
FORCING MACHINERY. Do not force machine.
It will do the job safer and better at the rate for
which it was designed.
NEVER STAND ON MACHINE. Serious injury
may occur if machine is tipped or if the cutting
tool is unintentionally contacted.
STABLE MACHINE. Unexpected movement during operation greatly increases risk of injury or
loss of control. Before starting, verify machine is
stable and mobile base (if used) is locked.
USE RECOMMENDED ACCESSORIES. Consult
this owner’s manual or the manufacturer for recommended accessories. Using improper accessories will increase the risk of serious injury.
UNATTENDED OPERATION. To reduce the
risk of accidental injury, turn machine OFF and
ensure all moving parts completely stop before
walking away. Never leave machine running
while unattended.
MAINTAIN WITH CARE. Follow all maintenance
instructions and lubrication schedules to keep
machine in good working condition. A machine
that is improperly maintained could malfunction,
leading to serious personal injury or death.
DAMAGED PARTS. Regularly inspect machine
for damaged, loose, or mis-adjusted parts—or
any condition that could affect safe operation.
Immediately repair/replace BEFORE operating
machine. For your own safety, DO NOT operate
machine with damaged parts!
MAINTAIN POWER CORDS. When disconnecting cord-connected machines from power, grab
and pull the plug—NOT the cord. Pulling the cord
may damage the wires inside. Do not handle
cord/plug with wet hands. Avoid cord damage by
keeping it away from heated surfaces, high traffic
areas, harsh chemicals, and wet/damp locations.
EXPERIENCING DIFFICULTIES. If at any time
you experience difficulties performing the intended operation, stop using the machine! Contact our
Technical Support at (570) 546-9663.
-4-
Model T33296 (Mfd. Since 07/23)
Page 7
Additional Safety for Miter Saw Stands
Serious cuts, amputation, or death can occur from contact with rotating saw blade during
operation. Workpieces, broken blades, or flying particles thrown by blade can blind or strike
operators or bystanders with deadly force. To reduce the risk of these hazards, operator and
bystanders MUST completely heed the hazards and warnings below.
HAND & BODY POSITIONING. Keep hands at
least 4" away from spinning saw blade and out
of blade path when cutting. Only operate at front
of machine. Never reach behind or around blade
and never support the workpiece cross handed.
WORKPIECE SUPPORT. To maintain maximum
control and reduce risk of blade contact from binding or kickback, always ensure stable, adequate
support for long/large workpieces. Always keep
workpiece stationary, flat, and firmly held against
table/fence when cutting to avoid loss of control.
Secure workpieces with clamps whenever possible. Only cut one workpiece at a time—do not
cut stacks. Warped material may cause binding
so it must be clamped with outside bowed face
toward fence so there is no gap between workpiece, fence, and table along line of cut.
DULL/DAMAGED SAW BLADES. Broken saw
blade teeth can become deadly projectiles. Do
not operate with damaged, cracked, or badly worn
blades. Inspect for damage before each use.
CUTTING CORRECT MATERIAL. Never cut ferrous materials as they increase risk of operator
injury and can produce sparks or flying particles
that may jam. Only cut natural and man-made
wood products, laminate-covered wood products,
and some plastics. Inspect workpiece for warping
or embedded materials like nails or other foreign
objects before cutting.
CHANGING BLADES. Accidental startup while
changing saw blade can result in serious injury.
Always disconnect power before changing blades
and wear gloves to protect hands. Do not use
blades with different diameters or arbor hole
shapes/sizes. Always ensure blade is oriented
with marked blade rotation direction.
BLADE ADJUSTMENTS. Adjusting blade miter
or tilt during operation increases risk of crashing blade and sending metal fragments flying at
operator or bystanders. Only adjust blade when
blade is completely stopped and saw is disconnected from power and be sure to lock settings
and adjust fence to properly support workpiece
and clear guard and blade before operation.
SAW OPER ATION . Ensure miter stand is placed
on level, firm work surface before use and clear
all tools, wood scraps, etc., as debris can be
thrown at high speeds. Always allow blade to
reach full speed before contacting workpiece.
When cut is finished, allow blade to completely
stop before removing workpiece. Hold handle
firmly when making non-through cuts and when
releasing trigger before saw head is completely in
down position.
BLADE GUARD. Make sure blade guard is
installed, working correctly, and used for all cuts.
Promptly repair or replace if damaged. Re-install
immediately after servicing saw blade.
SMALL WORKPIECES. If hands slip during
cut while holding small workpieces with fingers,
serious personal injury could occur. Always support small, narrow, and round workpieces with
appropriate type of clamping fixture. Do not cut
workpieces that are too small to effectively support or require hands/fingers to be closer than 4"
away from blade.
Model T33296 (Mfd. Since 07/23)
JAMMED OR CUT-OFF PIECES. To avoid risk
of injury due to blade contact, turn saw OFF and
allow blade to completely stop before removing
cut-off pieces. Unplug saw before working to free
jammed pieces. Never use your hands to move
cut-off pieces away from blade while saw is running. Do not use stop blocks that may wedge cutoff pieces against saw blade.
-5-
Page 8
SECTION 2: SETUP
This machine was carefully packaged for safe
transport. When unpacking, separate all enclosed
items from packaging materials and inspect them
for shipping damage.
,
please
IMPORTANT:
you are completely satisfied with the machine and
have resolved any issues between Grizzly or the
shipping agent. You MUST have the original pack-
aging to file a freight claim. It is also extremely
helpful if you need to return your machine later.
The following is a list of items shipped with your
machine. Before beginning setup, lay these items
out and inventory them.
If any non-proprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
This machine presents
serious injury hazards
to untrained users. Read
through this entire manual to become familiar with
the controls and operations before starting the
machine!
Wear safety glasses during
the entire setup process!
Unpacking
If items are damaged
call us immediately at (570) 546-9663.
Save all packaging materials until
Needed for Setup
Inventory
Inventory (Figures 1–2) Qty
A. Miter Stand Assembly ............................... 1
B. Clamping Rails ........................................... 2
— Carriage Bolts M8-1.25 x 55.................. 4
— Flat Washers 8mm ................................ 4
— Lock Nuts M8-1.25................................. 4
C. Offset Mounts............................................. 2
— Carriage Bolts M8-1.25 x 16.................. 2
— Flat Washers 8mm ................................ 2
— Hex Nuts M8-1.25.................................. 2
D. Handle Bars................................................ 2
— Phlp Hd Screws M6-1 x 45.................... 4
— Hex Nuts M6-1 ...................................... 4
E. Skid Rail ..................................................... 1
— Phlp Hd Screws M6-1 x 45.................... 4
— Hex Nuts M6-1 ...................................... 4
F. T-Supports.................................................. 2
— Knobs .................................................... 2
— Carriage Bolts M6-1 x 55....................... 2
G. Angle Flanges ............................................ 2
— Knob Bolts ............................................. 2
H. Wheels ....................................................... 2
— Axle Bolts M12-1.75 x 120...................... 2
— Lock Nuts M12-1.75 ............................... 2
The following items are needed, but not included,
for setup and assembly of this machine.
Description Qty
• Hex Wrench 6mm....................................... 1
• Phillips Head Screwdriver #2 ..................... 1
• Combination Wrench 10mm....................... 1
• Combination Wrench 19mm....................... 1
• Adjustable Wrench 0–20mm...................... 1
-6-
A
Figure 1. Miter stand assembly inventory.
Model T33296 (Mfd. Since 07/23)
Page 9
Consider anticipated workpiece sizes and additional space needed for auxiliary stands, work
tables, or other machinery when establishing a
location for this machine in the shop. Below is
the minimum amount of space needed for the
B
C
If you cannot find an item on this list, carefully check around/inside the machine and
packaging materials. Often, these items get
lost in packaging materials while unpacking or they are pre-installed at the factory.
NOTICE
Site Considerations
Placement Location
D
124"
E
F
G
H
Figure 2. T33296 inventory small parts.
261/2"
571/2"
Figure 3. Minimum working clearances.
Model T33296 (Mfd. Since 07/23)
-7-
Page 10
Assembly
The machine must be fully assembled before it
can be operated. Before beginning the assembly
process, refer to
and gather
all
To ensure the assembly process
goes smoothly, first clean any
covered or coated in heavy-duty rust preventative (if
applicable).
3. While holding foot pedal in its unlocked position, grasp foot bar shown in Figure 6 and
lift upward until foot pedal elevation lock
engages with lock lug shown in Figure 7.
Needed for Setup
listed items.
parts that are
To assemble miter stand:
Place miter stand table-side down, and orient
1.
as shown in Figure 4.
Foot
Bar
Elevation Lock
Stow Lock
Figure 6. Lifting foot bar.
Lock Lug
Figure 4. Miter stand table-side down.
2. Press foot pedal down until stow lock disen-
gages lock ring shown in
Stow Lock
Figure 5. Releasing stow lock.
-8-
Figure 5.
Foot Pedal
Lock Ring
Elevation Lock
Figure 7. Elevation lock engaged with lock lug.
4. At this point miter stand will be locked in its
fully unfolded position, as shown in Figure 8.
Figure 8. Miter stand locked upside down.
Model T33296 (Mfd. Since 07/23)
Page 11
5. Locate (2) wheels, (2) M12-1.75 x 120 hex
bolts, and (2) 12mm lock nuts.
6. Insert bolt through wheel, so it protrudes
through domed hub.
7. Install wheel and bolt onto stand, so there is
a gap between frame and wheel, as shown in
Figure 9. Do not over-tighten locking nut or
wheel will bind.
11. Making sure stand stays locked in unfolded
position, invert stand to upright position, as
shown in Figure 11.
Gap
Locking Nut
Domed Hub
Figure 9. Wheel installed with gap.
8. Install remaining wheel, bolt, and lock nut.
9. Locate and lay-out skid frame, (4) M6-1 x 45
Phillips head screws, and (4) M6-1 lock nuts.
10. Attach skid frame as shown in Figure 10,
and make sure to install screws with nuts on
inside of stand and screw heads on outside
of stand.
Figure 11. Miter stand unfolded and upright.
12. Locate (2) T-supports, (2) M6-1 x 55 carriage
bolts, (2) knobs, and (2) knob bolts.
13. Attach T-support onto support tube using
knob bolt, as shown in Figure 12.
14. Install angle flange using M6-1 x 55 carriage
bolt and knob, as shown in Figure 12.
T-Support
x 2
Knob
Angle Flange
Nuts On Inside
Screw Heads
Outside
Skid Frame
Figure 10. Skid frame installed.
Model T33296 (Mfd. Since 07/23)
Knob Bolt
Figure 12. T-support angle flange installed.
15. Install remaining T-support and angle flange.
16. Locate (2) handle bars, (4) M6-1 x 45 Phillips
head screws, (4) M6-1 lock nuts.
17. Position both handle bars pointing downward, as shown in Figure 14, and fasten
using screws making sure smooth heads are
facing outward.
-9-
Page 12
18. Locate (2) clamping rails, (4) M8-1.25 x 55
carriage bolts, (4) 8mm flat washers, and (4)
M8-1.25 lock nuts.
19. Loosely install carriage bolts, washers, and
nuts in slots of clamping rails, as shown in
Figure 13. These fasteners are used for
mounting most miter saws.
Note: You may have to select different fasteners depending on your model of miter
saw.
20. Grasp clamping rail handle and depress lock
trigger with index finger.
24. Verify that miter stand has been assembled
completely, and that it matches what is
shown in Figure 14.
Skid
Frame
Handle
Bars
21. Engage far end of clamping rail on miter
stand table as shown in Figure 13.
Clamping Rail Fully Engaged
Handle
Trigger
This End First
Figure 13. Clamping rail installation.
22. Keeping far end engaged with table and lock
trigger depressed, push handle end down
until clamping rail fully engages on table by
releasing lock trigger.
Figure 14. Assembly complete.
25. On each end of miter stand table, unlock
each rail lock lever (see Figure 15) and slide
rails out from their retracted position (see
Figure 16) until they hit their internal stops,
then lock in place.
Operation should be smooth and levers
should lock T-support rails securely in place.
Rail Lock Lever
T-Support Rail
23. Install remaining clamping rail.
-10-
Figure 15. T-support rail lock lever.
Figure 16. T-support rails fully extended.
Model T33296 (Mfd. Since 07/23)
Page 13
Installing Miter Saw
The Model T33296 miter saw stand features two
adjustable clamping rails that have a series of
(8.2mm) slots that run along the top of each rail.
When carriage bolts are used in these slots, along
with the ability of the mounting rails to be slid right
and left, one can mount most miter saws with
blades up to 12".
In the event that a miter saw has an obscure base
casting/mounting design, additional offset mounting brackets (see Figure 18) have been included
to accommodate for unique bolt patterns. In the
event the offset brackets will not work, one can
also fasten a
rails and then fasten the miter saw to the board.
There is an array of other machines such as small
planers and jointers that are mountable to this
miter saw stand; however, we do not recommend
this use. Since the workpiece needs to be pushed
in the direction that the stand rolls, the stand can
move during workpiece feeding increasing likelihood of workpiece kickback and possible injury.
3
⁄4" thick flat board to the mounting
3
⁄8"
If installing or removing saw from table
alone, you may have to overreach, adding
extra stress to lower back. To avoid lower
back injury, get assistance from a second
person when installing or removing saw.
To install miter saw:
1. Position clamping rails on table so handles
are on rear of miter saw, and weight of saw is
centered in middle of table (see Figure 17).
The reason for this rear handle positioning is
that when miter saw rails are unclamped and
removed from table, majority of saw weight is
as close to your body as possible for easier
lifting and placement control. However, for
maximum safety we recommend help from a
second person for removal and installation.
Saw Back
Rest
Do not mount a planer/jointer, or any other
machine on this stand that has an infeed
direction that matches the direction that the
stand rolls. If you do, you create a risk of
miter stand moving during workpiece feeding resulting in possible workpiece kickback and severe injury.
This miter stand presents the risk of hand
and fingers being pinched. When folding
and unfolding this miter stand, keep fingers
and hands away from all pivot and pinch
points.
Rear of
Saw
Clamping
Rail Handle
Figure 17. Miter saw and table alignment.
Model T33296 (Mfd. Since 07/23)
-11-
Page 14
2. Lock clamping rails to stand table so they
stay parallel when mounting miter saw.
3. Position miter saw on clamping rails, so
miter saw back rest is parallel with table
and its center of gravity lies in center of
table.
4. When satisfied with miter saw location in
relation to miter stand, fasten miter saw
to rails using (4) carriage bolts, applicable
nuts, and washers shown in Figure 18.
Clamping Rail Handles
on Same Side as
Back-Side of Saw
Note: Different carriage bolts, washers, and
nuts may have to be used to accommodate
some miter saw bases.
To prevent cracking or bending of miter saw
base do not use impact tools to tighten fasteners; only tighten by hand.
Nuts and Washers,
as Applicable
-12-
Carriage
Bolt
Offset Mounting
Bracket
Figure 18. Mounting miter saw.
Model T33296 (Mfd. Since 07/23)
Page 15
SECTION 3: OPERATIONS
To reduce your risk of
serious injury, read this
entire manual BEFORE
ing loss can occur while operating this
Keep hair, clothing, and
ing parts at all times.
Entanglement can result
in death, amputation, or
Operation Overview
To complete a typical operation, operator
does the following:
1. Visually verifies miter saw is firmly mounted
and rails are locked to miter stand table.
2. Uses handle bars and wheels to roll miter
stand to work area.
using machine.
Eye injuries, respiratory problems, or hear-
tool. Wear personal protective equipment to
reduce your risk from these hazards.
jewelry away from mov-
severe crushing injuries!
3. Uses handle bars and foot bar to stabilize
and support weight of stand and saw.
4. Presses foot pedal to release stow lock and
lowers stand until elevation lock engages.
5. Verifies miter stand is fully locked in unfolded
position, is stable, and able to support miter
saw operations without moving.
6. Verifies workpiece to be cut does not over-
load stand and/or bend T-support rails when
extended (adds additional support if needed).
7. Unlocks mounting rails, slides miter saw to
saw operation location, and locks rails in
place.
8. Adjusts T-supports and support rails to sup-
port workpiece for miter saw operations.
9. Puts on PPE, connects saw to power, and
performs operation, per saw owner's manual.
If you are not experienced with this type
of machine, WE STRONGLY RECOMMEND
that you seek additional training outside of
this manual. Read books/magazines or get
formal training before beginning any projects. Regardless of the content in this section, Grizzly Industrial will not be held liable
for accidents caused by lack of training.
Model T33296 (Mfd. Since 07/23)
10. Disconnects saw from power, locks saw, and
stows power cord.
11. Unlocks mounting rails, slides rail against
stop bolt, and locks rails and saw in its stow
location.
12. Uses handle bars and foot bar to stabilize
and support weight of stand and saw.
13. Presses foot pedal to release elevation lock,
and lifts stand until stow lock engages and
locks stand in folded vertical position.
14. Verifies stow lock is fully engaged and rolls
miter stand to storage area.
-13-
Page 16
Folding & Unfolding
Miter Saw Stand
This miter stand has two locking positions: Folded
for stowage or unfolded for saw operations. When
the stand is unfolded for use, for maximum stability
and load bearing safety, saw must be locked at the
operation location shown in Figure 19.
Saw
Operation
Location
Stop Bolt
Folding Miter Stand
1.
Lock saw in stow location (see
2. Hold handle bars firmly and place right foot
on foot bar, as shown in Figure 21.
3. Unload saw weight by lifting handle bars, roll
right foot forward, and press toe against foot
pedal to unlock elevation lock latch.
4. Keep foot firmly on foot bar and lift upward on
handle bars the rest of the way until stand is
heard locking in vertical folded position.
Figure 20
).
Figure 19. Saw operation location.
Before folding the miter stand for stowage, move
the miter saw to the saw stow location (as far away
from the wheels as possible) or until one rail contacts the stop bolt, as shown in Figure 20. This
weight distribution gives better leverage when the
stand is being folded and unfolded. In this position
the stand is not as top heavy when carted on its
wheels in its vertical folded position.
Saw
Stow
Location
Handle Bar
Foot Pedal
Foot Bar
Figure 21. User control positions.
Unfolding Miter Stand
1. Position hands and foot, as shown in Figure
21, pull down on handle bars, unloading saw
weight, then roll right foot forward pressing
toe against foot pedal to unlock stow latch.
-14-
Rail Against
Stop Bolt
Figure 20. Saw stow location.
2. Keep foot firmly on foot bar and lower handle
bars until stand is heard locking in unfolded
position.
Move and lock saw in operation location, as
3.
shown in
Figure 19
Model T33296 (Mfd. Since 07/23)
.
Page 17
SECTION 4: ACCESSORIES
Installing unapproved accessories may
order online at www.grizzly.com or call 1-800-523-4777
cause machine to malfunction, resulting in
serious personal injury or machine damage.
To reduce this risk, only install accessories
recommended for this machine by Grizzly.
G1163P—1 HP Floor-Model Dust Collector
G0710—1 HP Wall-Mount Dust Collector
G3591—30 Micron Replacement Bag
H4340—3.0 Micron Upgrade Bag
Excellent point-of-use dust collectors that can
be used next to the machine with only a small
amount of ducting. Specifications: 537 CFM, 7.2"
static pressure, 1.5 cubic foot bag, and 30-micron
filter. Motor is 1 HP, 120V/240V, 7A /3.5A.
NOTICE
Refer to our website or latest catalog for
additional recommended accessories.
D2273—Single-Roller Stand
D2274—5-Roller Stand
These roller stands are invaluable when working solo in any shop for outfeeding and support
tasks. With 15
and adjustable height of 26
all steel construction make them convenient and
rugged.
7
⁄8" wide rollers, 250 lb. capacity,
1
⁄2 "–44 1⁄2 " height, and
Model G0710
Model G1163P
Figure 23. Point-of-use dust collectors.
Figure 22. D2273 and D2274 single- and 5-roller
stands.
Model T33296 (Mfd. Since 07/23)
-15-
Page 18
SECTION 5: MAINTENANCE
To reduce risk of shock or
accidental startup, always
disconnect machine from
power before adjustments,
Inspection &
Maintenance
After long-term or heavy use the miter stand
maintenance, or service.
Schedule
mechanisms may wear.
To maintain safe working order and trouble-free
locking, periodically inspect all miter stand wear
points and tighten/repair/replace parts as needed.
For optimum performance from this miter stand,
follow this maintenance schedule.
Ongoing
To minimize your risk of injury and maintain proper operation, stop using miter stand and saw if
you ever observe or suspect any of the problems
listed below. Fix any problem before continuing
operations:
Daily Check
• Inadequate locking of clamping rails.
• Loose/worn nuts and bolts at pivot locations.
• Worn or bent foot pedal, lock hooks, or pins.
• Loose table fasteners or wheels.
• Loose or missing saw mounting fasteners.
• Bent or cracked stand frame welds.
• Missing loose, or damaged skid pads.
• Bent or cracked clamping rails and handles.
• Bent or cracked workpiece rails or T-supports.
• Loose or inadequate locking of workpiece
rails or T-supports.
Cleaning &
Protecting
Cleaning the Model T33296 is easy. Vacuum
excess sawdust and wipe off remaining dust with
a dry cloth. If any resin has built up, use a resin
dissolving cleaner to remove it. Extend workpiece
support rails completely and wipe surfaces clean
with a rag moistened with mineral spirits. Lightly
oil lock knob threads to prevent rust.
-16-
The key areas to inspect for maintenance are as
follows:
• Verify that rubber handle bar grips are tight
on handle bars and have no chance of slipping off.
• Inspect clamping rail handles and make certain they are undamaged and crack free.
• Inspect foot pedal mechanism for any damage, wear, broken spring, or loose fasteners.
• Remove and inspect T-support lock knobs
for serviceable threads, then clean and oil
threads.
• Inspect wheels axle bolts for secure lock
nuts, and apply light machine oil to wheel
axle bolts.
• Remove from tires and skid pads any imbedded staples, nails, and any other item that
may scratch floors. Replace any missing skid
pad screws.
• Inspect and test rail locking mechanism and
lock shoe for any damage and for smooth
and easy locking. If rail locking is inadequate,
or will not lock, see
Page 17
.
Model T33296 (Mfd. Since 07/23)
Clamping Adjustment
on
Page 19
Clamping
Adjustment
Place rail on miter stand table and test clamp-
4.
ing adjustment. When clamped, trigger lock
will click indicating rail is locked to miter table
and rail will not move.
After a period of time, the tension mechanism
in the clamping rails will need to be adjusted.
Rail clamping should be snug enough to prevent
movement, but not overly tight where trigger lock
operation is prevented. This adjustment may be
done with the saw installed on the rails, or with
the rails removed.
Tools Needed Qty
Phillips Head Screwdriver #2 ............................ 1
Combination Wrench 10mm.............................. 1
To adjust clamping of mounting rails:
DISCONNECT SAW FROM POWER!
1.
2.
Unlock clamping rail.
3.
Loosen lock nut shown in Figure 24 and
turn adjusting screw to increase or decrease
clamping of rail.
Lock Nut
Ensure
Figure 25
If trigger lock shows substantial wear, or it
does not lock correctly after clamping adjustment, replace
Trigger Lock
Lock Bolt
When satisfied with clamping adjustment, hold
5.
screw in position and tighten lock nut.
clamping
fully engage lock bars.
Figure 25. Engaged trigger lock.
rail trigger lock shown in
clamping
rail assembly.
Clamping Rail
Handle
Adjustment Screw
Figure 24.
Clamping
Lock Shoe
rail adjustment.
6.
Repeat procedure on remaining clamping rail.
Model T33296 (Mfd. Since 07/23)
-17-
Page 20
SECTION 6: PARTS
1
29
We do our best to stock replacement parts when possible, but we cannot guarantee that all parts shown
are available for purchase. Call (800) 523-4777 or visit www.grizzly.com/parts to check for availability.
Main
4
2
3
7
6
57
60
56
56
40
42
5
39
18
59
5
10
8
37
38
56
36
55
53
54
54
51
49
48
47
46
52
50
44
45
54
52
56
42
42
41
43
12
10
14
58
24
34
24
27
33
17
30
19
25
26
31
29
13
9
35
30
32
29
30
15
18
16
29
29
30
20
21
22
23
28
29
-18-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
Model T33296 (Mfd. Since 07/23)
Page 21
Main Parts List
REF PART # DES CRIP TION REF PART # DES CRIP TION
1 PT33296001 KNOB M6-1, 6-LOBE, D44 32 PT33296032 SKID PAD B
2 PT33296002 TUBE CAP 44MM 33 PT33296033 LOCK NUT M4-.7
3 PT33296003 SQUARE TUBE CAP 30 X 30MM 34 PT33296034 PHLP HD SCR M4-.7 X 12
4 PT33296004 CARRIAGE BOLT M6-1 X 55 35 PT33296035 FORWARD SUPPORT
5 PT33296005 SQUARE TUBE CAP 35 X 35MM 36 PT33296036 LOCK NUT M12-1.75
6 PT33296006 CLEVIS PIN 37 PT33296037 HEX NUT M6-1
7 PT33296007 ECCENTRIC HANDLE 38 PT33296038 PHLP HD SCR M6-1 X 45
8 PT33296008 LOCK NUT M8-1.25 39 PT33296039 HANDLE BAR
9 PT33296009 FRONT LEG SEAT 40 PT33296040 RUBBER HAND GRIP
10 PT33296010 HEX NUT M8-1.25 41 PT33296041 LOCK NUT M6-1
12 PT33296012 CAP SCREW M8-1.25 X 20 42 PT33296042 HEX BOLT M12-1.75 X 120
13 PT33296013 HEX BOLT M8-1.25 X 45 43 PT33296043 HOOK
14 PT33296014 TABLE 44 PT33296044 FOOT PEDAL
15 PT33296015 BRAKE TONGUE 45 PT33296045 FLAT WASHER 6MM
16 PT33296016 BRAKE WASHER 46 PT33296046 HEX BOLT M6-1 X 20
17 PT33296017 E-CLIP 4MM 47 PT33296047 TORSION SPRING
18 PT33296018 LOCK SEAT 48 PT33296048 FLAT WASHER 6MM
19 PT33296019 TAP SCREW M4.8 X 9.5 49 PT33296049 HEX BOLT M6-1 X 55
20 PT33296020 ANGLE FLANGE 50 PT33296050 FOOT BAR
21 PT33296021 ROLLER BRACKET 51 PT33296051 FLAT WASHER 12MM
22 PT33296022 KNOB BOLT M6-1 X 25, 6-LOBE, D44 52 PT33296052 AXLE BOLT M12-1.75 X 45, 12 X 88
23 PT33296023 BEAM 53 PT33296053 WHEEL
24 PT33296024 CAP SCREW M8-1.25 X 16 54 PT33296054 LOCK NUT M12-1.75
25 PT33296025 FLAT WASHER 8MM 55 PT33296055 TUBE CAP 38MM
26 PT33296026 REAR LEG SEAT 56 PT33296056 FLAT WASHER 12MM
27 PT33296027 HEX BOLT M10-1.5 X 60 57 PT33296057 SUPPORT FRAME
28 PT33296028 SKID PAD A 58 PT33296058 MACHINE ID LABEL
29 PT33296029 FLAT HD TAP SCREW M3.5 X 9.5 59 PT33296059 GRIZZLY LOGO LABEL
30 PT33296030 FLAT HD TAP SCREW M4.8 X 13 60 PT33296060 PINCH HAZARD LABEL
31 PT33296031 SKID RAIL
Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes
off or becomes unreadable, the owner of this machine MUST replace it in the original location
before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com.
Model T33296 (Mfd. Since 07/23)
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
-19-
Page 22
101
108109110111112113114
119
122
118
Clamping Rail
121
102
120
103
104
105
116
115
106
REF PART # DES CRIP TION RE F PART # DESCRI PTION
101 PT33296101 HEX NUT M8-1.25 112 PT33296112 FRONT CLAMP
102 PT33296102 LOCK WASHER 8MM 113 PT33296113 LOCK NUT M5-.8
103 PT33296103 CARRIAGE BOLT M8-1.25 X 60 114 PT33296114 REAR CLAMP
104 PT33296104 PHLP HD SCR M5-.8 X 55 115 PT33296115 HEX NUT M6-1
105 PT33296105 END CAP (FRONT) 116 PT33296116 HEX BOLT M6-1 X 45
106 PT33296106 PULL ROD 118 PT33296118 RAIL
107 PT33296107 CLAMP HANDLE 119 PT33296119 END CAP (REAR)
108 PT33296108 TORSION SPRING 120 PT33296120 CARRIAGE BOLT M8-1.25 X 16
109 PT33296109 ROLL PIN 4 X 28 121 PT33296121 OFFSET MOUNTING BRACKET
110 PT33296110 HOOK 122 PT33296122 FLAT WASHER 8MM
111 PT33296111 ROLL PIN 5 X 28
107
-20-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
Model T33296 (Mfd. Since 07/23)
Page 23
WARRANTY & RETURNS
Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from
the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse,
negligence, accidents, repairs or alterations or lack of maintenance. This is Grizzly’s sole written warranty
and any and all warranties that may be implied by law, including any merchantability or fitness, for any particular purpose, are hereby limited to the duration of this written warranty. We do not warrant or represent
that the merchandise complies with the provisions of any law or acts unless the manufacturer so warrants.
In no event shall Grizzly’s liability under this warranty exceed the purchase price paid for the product and
any legal actions brought against Grizzly shall be tried in the State of Washington, County of Whatcom.
We shall in no event be liable for death, injuries to persons or property or for incidental, contingent, special,
or consequential damages arising from the use of our products.
The manufacturers reserve the right to change specifications at any time because they constantly strive to
achieve better quality equipment. We make every effort to ensure that our products meet high quality and
durability standards and we hope you never need to use this warranty.
In the event you need to use this warranty, contact us by mail or phone and give us all the details. We will
then issue you a “Return Number,’’ which must be clearly posted on the outside as well as the inside of
the carton. We will not accept any item back without this number. Proof of purchase must accompany the
merchandise.
Please feel free to write or call us if you have any questions about the machine or the manual.
Thank you again for your business and continued support. We hope to serve you again soon.
To
you can
applicable information for
take advantage of this warranty, you must register it at https://www.grizzly.com/forms/warranty, or
scan the QR code below to be automatically directed to our warranty registration page. Enter all
the product.
WARRANTY
Page 24
Loading...
