Page 1
MODEL T27877
96" 24-DRAWER TOOL
CABINET
INSTRUCTIONS
For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
Introduction
The Model T27877 24-Drawer Tool Cabinet
requires some assembly. Follow instructions
below for assembly, operation, and maintenance.
Figure 1. Model T27877.
Inventory Qty
• Tool Cabinet with Drawers ........................... 1
• Handles ....................................................... 2
• Keys ............................................................. 2
• Hex Bolts
1
⁄4"-20 x 1⁄2 " .................................. 8
Assembly
Attach handles to each side of tool cabinet
using (4)
Do not over-tighten!
Handle
1
⁄4"-20 x 1⁄2 " hex bolts (see Figure 2).
x 4
• To reduce risk of crushing injuries from
tool cabinet tipping over on you:
— Do not stand on cabinet or in drawers.
— Push cabinet only. Do not pull it.
— Only open one drawer at a time.
— Only move or transport cabinet with all
drawers closed and locked.
• Do not exceed weight capacities:
— Max individual drawer weight limit
is 100 lbs.
— Max tool cabinet weight limit (including
contents) is 1500 lbs.
• To prevent accidental rolling, always lock
brakes after moving cabinet.
• Do not allow children to have unsupervised
access to cabinet.
COPYRIGHT © OCTOBER, 2016 BY GRIZZLY INDUSTRIAL, INC. REVISED NOVEMBER, 2017 (HE)
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
(FOR MODELS MFD. SINCE 09.16) #JH18406 PRINTED IN CHINA
Figure 2. Handle installed.
V1.11.17
Page 2
Locking Drawers
Use the included key to secure the drawers. Only
completely closed drawers lock.
Locking Caster
To lock caster, press down on the caster lock (see
Figure 3). Secure each corner caster to ensure
tool cabinet will not shift position.
Caster Lock
Unlock
Lock
Figure 3. Location of caster lock.
3. Pull drawer out to remove.
4. To re-install, insert drawer runners into slides
and push drawer completely in. The locking tabs will automatically snap into place to
secure the drawer in the slides.
Maintenance
• Use soft, clean cloth and soapy water (use
regular dish soap) to remove grease, dirt, or
oil. Do not use solvents or flammable cleaning liquids.
• Lubricate drawer slides as needed with dry
lubricant (see Figure 5).
• Use graphite to lubricate lock annually.
Removing & Installing Drawers
The drawers can be removed and re-installed if
necessary.
To remove drawers:
1. Fully extend drawer and remove contents.
2. Push left locking tab down and hold, then pull
right locking tab up and hold (see Figure 4).
Note: Large bottom drawers feature two
guides per side.
Drawer
Runner
Right Locking Tab
Figure 5. G4682 Sprayway Dry Coating Lube.
Left Locking Tabs
Figure 4. Location of drawer locking tabs.
-2-
T27877 Tool Cabinet (Mfd. 09/16)
Page 3
T27877 Parts Breakdown & List
Please Note: We do our best to stock replacement parts whenever possible, but we cannot guarantee that all parts shown here
are available for purchase. Call (800) 523-4777 or visit our online parts store at www.grizzly.com to check for availability.
18
10
24
17
23
25
22
21
19
15
13
3
12
20
9
8
11
4
19
1
16
6
5
2
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PT27877001 DRAWER SLIDE SET 15 PT27877015 RIVET 3.8 X 6MM (ALUMINUM)
2 PT27877002 HEX BOLT 3/8-16 X 1 16 PT27877016 RIVET 4 X 6MM (ALUMINUM)
3 PT27877003 HEX BOLT 1/4-20 X 1/2 17 PT27877017 SMALL DRAWER (OUTER)
4 PT27877004 LOCK SET W/2 KEYS 18 PT27877018 LARGE DRAWER (OUTER)
5 PT27877005 CASTER, 6" FIXED 19 PT27877019 SMALL DRAWER (CENTER)
6 PT27877006 CASTER, 6" SWIVEL W/BRAKE 20 PT27877020 LARGE DRAWER (CENTER)
8 PT27877008 CENTER DRAWER LINER 21 PT27877021 WOOD TOP
9 PT27877009 OUTER DRAWER LINER 22 PT27877022 GRIZZLY NAMEPLATE
10 PT27877010 OUTER DRAWER HANDLE 23 PT27877023 WARNING LABEL
11 PT27877011 CENTER DRAWER HANDLE 24 PT27877024 QR CODE LABEL
12 PT27877012 CABINET BODY 25 PT27877025 GRIZZLY.COM LABEL (RED)
13 PT27877013 HANDLE
T27877 Tool Cabinet (Mfd. 09/16)
-3-
