Grizzly T26900 User Manual

MODEL T26900

52" 10-DRAWER TOOL CHEST

INSTRUCTIONS

For questions or help with this product contact Tech Support at [phone] or [e-mail]

Introduction

The Model T26900 10-Drawer Tool Chest (see
Figure 1) comes fully assembled except for
two side handles. Follow instructions below for
assembly, operation, and maintenance.

Figure 1. Model T26900.

• To reduce risk of crushing injuries from
tool chest tipping over on you:
— Do not stand on tool chest or in drawers.
— Only open one drawer at a time.
— Only move or transport tool chest with

all drawers closed and locked.

• Do not exceed weight capacities:
— Max individual drawer weight limit

is 50 lbs.

— Max tool chest weight limit (including

contents) is 400 lbs.

• Do not allow children to have unsupervised
access to tool chest.

Inventory

Description Qty

A. Tool Box w/Drawers.................................... 1

B. Keys ............................................................ 2

C. Side Handles .............................................. 2

D. Hex Bolts M8-1.25 x 16 .............................. 4

Assembly

1. Place chest on flat, level surface capable of

supporting weight when fully loaded.

2. Attach each side handle using two M8-1.25 x
16 hex bolts (see Figure 2).

x 2

Side

Handle

Figure 2. Side handle installed.

Locking & Unlocking Chest

To lock chest, close all drawers and top, then lock
top with key.

To unlock chest, unlock top with key, then open
top first to access drawers.

COPYRIGHT © AUGUST, 2014 BY GRIZZLY INDUSTRIAL, INC.

NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

FOR MODELS MANUFACTURED SINCE 08/2014 #WK16747 PRINTED IN CHINA

V1.0 8 .14

Removing & Installing Drawers

The drawers can be removed and re-installed if
an object inside causes them to not close fully.

To remove and install drawers:

1. Open top.

2. Fully extend drawer and remove contents.

3. Push left locking tab down and hold, then pull

right locking tab up and hold (see Figure 3).

Right Locking Tab

Maintenance

• Use soft, clean cloth, and standard cleaning

solution to remove grease, dirt, or oil. Do not
use solvents or flammable cleaning liquids.

• Lubricate drawer slides as needed with dry

lubricant.

• Use graphite to lubricate lock annually.

Left Locking Tab

Figure 3. Location of drawer locking tabs.

4. Pull drawer out.

5. Apply a thin layer of dry lubricant to drawer

slides.

6. To re-install, insert drawer runners into slides
and push drawer in until it stops. The lock­ing tabs will automatically snap into place to
secure the drawer in the slides.

-2-

T26900 10-Drawer Tool Chest (Mfd. 08/14)
