Grizzly H7673 User Manual

DELUXE MINI HVLP SPRAY GUN

MODEL H7673

INSTRUCTION MANUAL

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

#PC7347 PRINTED IN CHINA

Table of Contents

SECTION 1: SAFETY .......................................................................................................4

Additional Safety Instructions for HVLP Spray Guns .................................................6

SECTION 2: INTRODUCTION .........................................................................................7

Foreword .....................................................................................................................7

Tool Data ....................................................................................................................7

Contact Info ................................................................................................................7

SECTION 3: SET UP ........................................................................................................8

Unpacking ...................................................................................................................8

Inventory .....................................................................................................................8

Assembly ....................................................................................................................9

Controls ......................................................................................................................9

SECTION 4: OPERATIONS ...........................................................................................10

Spraying ....................................................................................................................10

Atomizing Cap and Fan Adjustments .......................................................................12

SECTION 5: MAINTENANCE ........................................................................................13

Cleaning ....................................................................................................................13

Lubrication ................................................................................................................14

Troubleshooting ........................................................................................................15

Parts Breakdown ......................................................................................................17

WARRANTY AND RETURNS ........................................................................................18

Model H7673 HVLP Spray Gun -3-

SECTION 1: SAFETY

For Your Own Safety Read Instruction Manual

Before Operating This Equipment

The purpose of safety symbols is to attract your attention to possible hazardous conditions. This manual uses a series of symbols and signal words which are intended to convey the level of importance of the safety messages. The progression of symbols is described below. Remember that safety messages by themselves do not eliminate danger and are not a substitute for proper accident prevention measures.

Indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, MAY result in minor or moderate injury. It may also be used to alert against unsafe practices.

NOTICE

This symbol is used to alert the user to useful information about proper operation of the equipment.

Safety Instructions For Pneumatic Tools

1. KEEP ALL SAFETY DEVICES IN

PLACE and in working order.

2. REMOVE ADJUSTING KEYS AND

WRENCHES. Form habit of check-

ing to see that keys and adjusting wrenches are removed from tool before operation.

3. KEEP WORK AREA CLEAN

Cluttered areas and benches invite accidents.

4. DO NOT USE IN DANGEROUS

ENVIRONMENT. Do not use pneu-

matic tools in damp or wet locations, or where any flammable or noxious fumes may exist. Keep work area well lighted.

5. KEEP CHILDREN AND VISITORS

AWAY. All children and visitors

should be kept at a safe distance from work area.

6. MAKE WORKSHOP CHILD

PROOF by locking your shop and

shutting off air valves.

7. DO NOT FORCE TOOL. It will do

the job better and safer at the rate for which it was designed.

8. USE THE RIGHT TOOL. Do not force tool or attachment to do a job for which it was not designed.

9. DO NOT USE UNDER THE INFLUENCE OF DRUGS OR ALCOHOL.

Model H7673 HVLP Spray Gun-4-

Safety Instructions For Pneumatic Tools

10. USE PROPER AIR HOSE for the

tool. Make sure your air hose is in good condition and is long enough to reach your work without stretching.

11. WEAR PROPER APPAREL. Do not wear loose clothing, gloves, neck ties, rings, bracelets, or other jewelry which may get caught in moving parts. Non-slip footwear is recommended. Wear a protective hair covering to contain long hair.

12. ALWAYS USE SAFETY GLASSES.

Also use a face or dust mask if cutting operation is dusty. Everyday eyeglasses only have impact resistant lenses, they are NOT safety glasses.

13. WEAR APPROVED HEARING PROTECTION.

14. SECURE WORK. Use clamps or a

vise to hold work when practical. It is safer than using your hand and frees both hands to operate tool.

15. DO NOT OVERREACH. Keep prop er footing and balance at all times.

16. MAINTAIN TOOLS WITH CARE.

Keep tools lubricated and clean for best and safest performance. Follow instructions for lubricating and changing accessories.

17. REDUCE THE RISK OF UNINTENTIONAL STARTING. Do

not carry tool with hand on trig ger and always disconnect from air when not in use.

18. DISCONNECT TOOLS before servicing and changing accessories.

19. USE THE RECOMMENDED ACCESSORIES. Consult the

owner’s manual for recommended

accessories. The use of improper accessories may cause risk of inju ry.

20. CHECK DAMAGED PARTS.

Before further use of the tool, a guard or other part that is damaged should be carefully checked to determine that it will operate properly and perform its intended function. Check for alignment of moving parts, binding of moving parts, breakage of parts, mounting, and any other conditions that may affect its operation. A guard or other part that is damaged should be properly repaired or replaced.

21. NEVER LEAVE UNATTENDED TOOL CONNECTED TO AIR.

Disconnect the air hose and do not leave tool until it is relieved of any built up pressure.

22. NEVER ALLOW UNTRAINED USERS TO USE THIS TOOL WHILE UNSUPERVISED.

23. IF YOU ARE UNSURE OF THE INTENDED OPERATION, STOP USING THE TOOL. Seek formal

training or research books or maga zines that specialize in pneumatic tools.

Model H7673 HVLP Spray Gun -5-

Additional Safety Instructions for HVLP Spray

Guns

1. READ THIS MANUAL. This manual

contains proper operating instructions for this spray gun.

2. RE AD MATER IAL LA BE LS

and MATERIAL SAFETY DATA SHEETS (MSDS). Read and know

all the instructions on the packaging label and the MSDS before opening the package. This information could save your life.

3. ALWAYS WEAR A NIOSH AP PROVED RE S PIRATO R WHEN SPRAYING OR WORKING AROUND FINISHING MATERIALS.

4. FIRE EXTINGUISHERS. Always

have a fully charged multi class or class B fire extinguisher in the immediate area.

5. FLAMMABLE MATERIAL. NEVER spray near open flame or where any spark could occur.

6. FRESH AIR. Always provide adequate exhaust to keep area free of built up vapors, NEVER spray in an enclosed space.

7. DI SC ON NECT COMPRESS ED AIR. Always disconnect the spray

gun from compressed air before cleaning, changing attachments or when performing maintenance of any kind on this tool.

8. PROTECTIVE CLOTHING. Protect exposed skin from overspray by wearing a protective suit or other approved garment.

9. INAPPROPRIATE USE. DO NOT point or shoot spray gun directly at yourself or another person or animals. Do not attempt to use the spray gun for any other use than it was intended.

10. STORAGE. Thoroughly clean and dry spray gun before storage. Store in an approved cabinet.

11. SOLVENTS. Always store solvents and shop towels soaked in solvent in approved containers.

12. EYE PROTECTION. Wear eye protection whenever spraying or cleaning. Solvents and chemicals can cause serious eye injury, which could lead to blindness.

13. OPERATI NG PRESSURE. DO NOT exceed the recommended

inlet air pressure. Excessive pressure could cause the spray gun to burst or cause other internal equipment damage.

14. LOCAL LAWS. Consult local authorities regarding exhaust and waste disposal requirements.

Model H7673 HVLP Spray Gun-6-
