Grizzly G0758Z User Manual
Model G0758Z is an upgraded version of Model
G0758 with an included X-/Y-/Z-Axis DRO.
NOTE: The column, table, and saddle on this
model have been specially machined to mount the
DRO scales. Thus, the DRO components included with these models cannot be easily retrofitted
onto Model G0758.
: To reduce the risk of serious
injury, you MUST read and understand this
insert—and the entire Model G0758 manual—
BEFORE assembling, installing, or operating
this machine!
If you have any further questions about this
manual insert or the differences between the
Model G0758 and the Model G0758Z, contact
our Technical Support at (570) 546-9663 or email
techsupport@grizzly.com.
MODEL G0758Z
MILL/DRILL W/DRO
MANUAL INSERT
COPYRIGHT © JUNE, 2017 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
(FOR MODELS MANUFACTURED SINCE 02/17) #KB18652 PRINTED IN CHINA
G0758Z Unique Parts
2
10
4
5
6
7
8
9
10
11
12
13
14
15
18
19
19
21
22
23
24
22
19
401
419
410
412
415
1
X
Y
zero
Z
zero
zero
in
mm
mm
inch
411
414
413
48
302
308
G0758Z
Model G0758Z
Specifications
Motor: 600W (3/4 HP), 110V, 10A, 60 Hz
Face Mill Capacity: 2"
Max. Dist. Spindle to Column: 6-5/8"
Weight: 161 lbs.
Max. Dist. Spindle to Table: 8-3/4"
Spindle Taper: R-8
Longitudinal Table Travel: 13-1/8"
Cross Table Travel: 4-1/2"
Drilling Capacity Cast Iron: 5/8"
Drilling Capacity Steel: 1/2"
End Mill Capacity: 5/8"
100 RPM 2000 RPM
– L –
– H –
Mfd. for Grizzly in China
Date Serial Number
1000 RPM50 RPM
309
417
416
414
416
54
403
402
418
406
68
414
408
415
409
405
407
406
404
76
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0758Z001 Z-AXIS SLIDE 407 P0758Z407 CAP SCREW M4-.7 X 8
48 P0758Z048 COLUMN 408 P0758Z408 Y-AXIS DRO SENSOR
54 P0758Z054 TABLE 409 P0758Z409 Y-AXIS SENSOR MOUNTING BLOCK
68 P0758Z068 SADDLE 410 P0758Z410 Y-AXIS METALLIC STRIP 10 X 150MM
76 P0758Z076 BASE 411 P0758Z411 Z-AXIS DRO SENSOR
302 P0758Z302 MODEL NUMBER LABEL 412 P0758Z412 Z-AXIS SENSOR MOUNTING BLOCK
308 P0758Z308 MACHINE ID LABEL 413 P0758Z413 Z-AXIS METALLIC STRIP 10 X 390MM
309 P0758Z309 CONTROL PANEL LABEL 414 P0758Z414 CAP SCREW M3-.5 X 16
401 P0758Z401 DRO DISPLAY UNIT 415 P0758Z415 CAP SCREW M4-.7 X 16
402 P0758Z402 X-AXIS DRO SENSOR 416 P0758Z416 STEEL SLEEVE 5 X 18 X 33L
403 P0758Z403 X-AXIS SENSOR MOUNTING BRACKET 417 P0758Z417 CAP SCREW M5-.8 X 50
404 P0758Z404 X-AXIS METALLIC STRIP 10 X 480MM 418 P0758Z418 CAP SCREW M4-.7 X 8
405 P0758Z405 ALUM BRACKET 30 X 480 419 P0758Z419 DRO POWER CORD 2W 18G 72" 1-15P
406 P0758Z406 FLAT WASHER 4MM
-2-
Model G0758Z (Mfd. Since 02/17)
