MODEL G0490ZX

8" JOINTER w/SPIRAL

CUTTERHEAD

OWNER'S MANUAL

(For models manufactured since 01/24)

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

#KSLW22697 PRINTED IN CHINA

***Keep for Future Reference***

V2. 0 7. 24

This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators.

Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.

The owner of this machine/tool is solely responsible for its safe use. This responsibility includes but is not limited to proper installation in a safe environment, personnel training and usage authorization, proper inspection and maintenance, manual availability and comprehension, application of safety devices, cutting/sanding/grinding tool integrity, and the usage of personal protective equipment.

The manufacturer will not be held liable for injury or property damage from negligence, improper training, machine modifications or misuse.

Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are:

• Lead from lead-based paints.

• Crystalline silica from bricks, cement and other masonry products.

• Arsenic and chromium from chemically-treated lumber.

Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure to these chemicals: Work in a well ventilated area, and work with approved safety equipment, such as those dust masks that are specially designed to filter out microscopic particles.

Table of Contents

INTRODUCTION ............................................... 2

Contact Info Manual Accuracy Identification Controls & Components Machine Data Sheet

SECTION 1: SAFETY

Safety Instructions for Machinery Additional Safety for Jointers

SECTION 2: POWER SUPPLY

SECTION 3: SETUP

Needed for Setup Unpacking Inventory Hardware Recognition Chart Cleanup Site Considerations Assembly Dust Collection Test Run Recommended Adjustments

SECTION 4: OPERATIONS

Operation Overview Stock Inspection & Requirements Setting Depth of Cut Squaring Stock Surface Planing Edge Jointing Bevel Cutting Rabbet Cutting

................................................... 2

........................................... 2

................................................... 3

................................. 4

...................................... 6

....................................... 8

.................. 8

....................... 10

...................... 11

....................................... 13

......................................... 13

.................................................... 13

...................................................... 14

....................... 15

........................................................ 16

...................................... 17

..................................................... 18

............................................. 22

....................................................... 23

........................ 23

............................ 24

..................................... 24

............... 25

.................................... 26

............................................ 27

........................................... 28

............................................... 29

............................................... 30

............................................. 31

SECTION 5: ACCESSORIES

SECTION 6: MAINTENANCE

Schedule Cleaning & Protecting Lubrication

SECTION 7: SERVICE

Troubleshooting Checking/Adjusting Cutterhead Guard Tensioning/Replacing V-Belt Aligning Pulleys Rotating/Replacing Indexable Inserts Checking/Adjusting Table Parallelism Setting Outfeed Table Height Adjusting Infeed Table Stop Bolts Calibrating Depth Scale Setting Fence Stops

SECTION 8: WIRING

Wiring Safety Instructions Wiring Diagram Electrical Components

SECTION 9: PARTS

Main Cabinet Labels & Cosmetics

WARRANTY & RETURNS

...................................................... 34

................................................... 35

................................... 36

........................................... 36

........................................... 42

.................................... 50

...................................... 51

............................................ 52

....................................... 55

............................................................. 55

......................................................... 58

..................................... 60

......................... 33

......................... 34

.................................. 34

........................ 41

....................... 48

............................... 49

............................ 51

................................. 53

.............................. 61

........ 39

.......... 43

.......... 44

................ 49

We stand behind our machines! If you have questions or need help, contact us with the information below. Before contacting, make sure you get the

serial number

from the

machine ID label. This will help us help you faster.

We want your feedback on this manual. What did you like about it? Where could it be improved? Please take a few minutes to give us feedback.

Email: manuals@grizzly.com

We are proud to provide a high-quality owner’s manual with your new machine!

instructions, specifications, drawings, and photographs in this manual. Sometimes we make mistakes, but our policy of continuous improvement also means that

you receive is

slightly different than shown in the manual

If you find this to be the case, and the difference between the manual and machine leaves you confused or unsure about something

check our

website for an updated version. W

current

manuals and

on our web-

site at

Alternatively, you can call our Technical Support for help. Before calling, make sure you write down the

serial number

from the machine ID label (see below). This information is required for us to provide proper tech support, and it helps us determine if updated documentation is available for your machine.

INTRODUCTION

Contact Info

and manufacture date

Grizzly Technical Support

1815 W. Battlefield Springfield, MO 65807 Phone: (570) 546-9663

Email: techsupport@grizzly.com

Grizzly Documentation Manager

P.O. Box 2069

Bellingham, WA 98227-2069

Manual Accuracy

made every effort to be exact with the

sometimes the machine

e post

manual updates for free

www.grizzly.com.

manufacture date and

Like all machinery there is potential danger when operating this machine. Accidents are frequently caused by lack of familiarity or failure to pay attention. Use this machine with respect and caution to decrease the risk of operator injury. If normal safety precautions are overlooked or ignored, serious personal injury may occur.

No list of safety guidelines can be complete. Every shop environment is different. Always consider safety first, as it applies to your individual working conditions. Use this and other machinery with caution and respect. Failure to do so could result in serious personal injury, damage to equipment, or poor work results.

Manufacture Date

Serial Number

-2-

Model G0490ZX (Mfd. Since 01/24)

Identification

Become familiar with the names and locations of the controls and features shown below to better understand the instructions in this manual.

Outfeed

Table

Outfeed Table

Adjustment Lever

Fence

Outfeed Table

Lock

Infeed Table

Lock

Fence Tilt Handle

Control Panel

Infeed

Table

Infeed Table

Adjustment Lever

Fence

Tilt Plunger

Fence

Tilt Lock

Fence

Lock

Pedal

Assembly

Dust Port

For Your Own Safety Read Instruction Manual Before Operating Jointer

a) Wear eye protection. b) Always keep cutterhead and drive guards in place and in proper operating condition. ALWAYS

replace cutterhead guard after rabbeting operations. c) Never make jointing or rabbeting cuts deeper than 1⁄8" or planing cuts deeper than 1⁄16". d) Always use hold-down or push blocks when jointing material narrower than 3" or surface

planing material thinner than 3". e) Never perform jointing, planing, or rabbeting cuts on pieces shorter than 10" in length.

Model G0490ZX (Mfd. Since 01/24)

-3-

To reduce your risk of serious injury, read this entire manual BEFORE

Controls &

Components

using machine.

Refer to Figures 1–4 and the following descrip- tions to become familiar with the basic controls and components of this machine. Understanding these items and how they work will help you understand the rest of the manual and stay safe when operating this machine.

Figure 2. Fence, infeed table controls, and

depth-of-cut scale.

Fence: Guides workpiece as it moves across

cutterhead and determines angle of cut.

Infeed Table Lock: Loosens to allow adjust-

ment of infeed table height; tightens to secure infeed table.

Figure 1. Power controls.

A. POWER Switch w/Disabling Key: Turns

power to machine ON or OFF. Remove yellow/orange key to disable switch.

START Button: Turns motor ON.

STOP Button: Turns motor OFF.

Infeed Table: Supports workpiece before it

reaches cutterhead. Position of infeed table relative to cutterhead determines depth of cut.

Infeed Table Adjustment Lever: Adjusts

height of infeed table (when infeed table lock is loosened).

Depth-of-Cut Scale: Indicates cutting depth

of a single pass.

-4-

Model G0490ZX (Mfd. Since 01/24)

I. Fence Tilt Handle: Tilts fence throughout its

range of motion from 45°–135° (45° outward).

45° Fence Stop: Stops fence at 45°.

90° Fence Stop: When engaged, stops

fence at 90°.

135° Fence Stop: Stops fence at 135° (45°

outward).

Fence Tilt Lock: Secures fence tilt setting at

desired angle.

Figure 3. Fence controls. Figure 4. Cutterhead guard and outfeed table

controls.

Outfeed Table: Supports workpiece after

it passes over cutterhead. For safety and best results, outfeed table must be properly adjusted relative to cutterhead inserts before ANY operations (see Page 48 for additional details).

Cutterhead Guard: Covers cutterhead

until pushed out of the way by workpiece during operation. When workpiece leaves cutterhead, guard springs back to its starting position.

Note: Even when fence is resting against

fence stops, tilt lock must be tightened before starting machine.

Fence Lock: Loosens to allow adjustment of

fence position along width of tables; tightens to secure fence.

Outfeed Table Lock: Loosens to allow

adjustment of outfeed table height; tightens to secure outfeed table.

Outfeed Table Adjustment Lever:

Adjusts height of outfeed table. Typically only used when setting outfeed table even with cutterhead inserts or when servicing cutterhead.

Model G0490ZX (Mfd. Since 01/24)

-5-

MACHINE DATA

SHEET

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901

MODEL G0490ZX 8" JOINTER WITH SPIRAL CUTTERHEAD

Product Dimensions:

Weight.............................................................................................................................................................. 508 lbs.

Width (side-to-side) x Depth (front-to-back) x Height............................................................... 76-1/2 x 24 x 45-1/2 in.

Footprint (Length x Width)............................................................................................................... 44-1/2 x 16-1/2 in.

Shipping Dimensions:

Carton #1

Type................................................................................................................................................ Wood Crate

Content................................................................................................................................................. Machine

Weight.................................................................................................................................................... 415 lbs.

Length x Width x Height............................................................................................................. 81 x 24 x 14 in.

Must Ship Upright......................................................................................................................................... Yes

Carton #2

Type................................................................................................................................................ Wood Crate

Content...................................................................................................................................................... Stand

Weight.................................................................................................................................................... 178 lbs.

Length x Width x Height............................................................................................................. 40 x 21 x 33 in.

Must Ship Upright......................................................................................................................................... Yes

Electrical:

Power Requirement........................................................................................................... 220V, Single-Phase, 60 Hz

Full-Load Current Rating........................................................................................................................................ 14A

Minimum Circuit Size.............................................................................................................................................. 20A

Connection Type....................................................................................................................................... Cord & Plug

Power Cord Included.............................................................................................................................................. Yes

Power Cord Length.............................................................................................................................................. 98 in.

Power Cord Gauge......................................................................................................................................... 12 AWG

Plug Included.......................................................................................................................................................... Yes

Included Plug Type................................................................................................................................................ 6-20

Switch Type.................................................................................. ON/OFF Push Button Switches w/Shut-Off Paddle

-6-

Motors:

Main

Horsepower................................................................................................................................................ 3 HP

Phase............................................................................................................................................ Single-Phase

Amps............................................................................................................................................................ 14A

Speed................................................................................................................................................ 3450 RPM

Type................................................................................................................. TEFC Capacitor-Start Induction

Power Transfer ............................................................................................................................................ Belt

Bearings..................................................................................................... Shielded & Permanently Lubricated

Centrifugal Switch/Contacts Type......................................................................................................... External

Model G0490ZX (Mfd. Since 01/24)

Main Specifications:

Main Specifications

Fence Information

Cutterhead Information

Cutter Insert Information

Jointer Size.................................................................................................................................................. 8 in.

Bevel Jointing............................................................................................................................. 0 - 45 deg. L/R

Maximum Width of Cut................................................................................................................................ 8 in.

Maximum Depth of Cut............................................................................................................................. 1/8 in.

Minimum Workpiece Length...................................................................................................................... 10 in.

Minimum Workpiece Thickness................................................................................................................ 1/2 in.

Maximum Rabbeting Depth...................................................................................................................... 1/2 in.

Number of Cuts Per Minute..................................................................................................................... 21,636

Fence Length............................................................................................................................................. 36 in.

Fence Width.......................................................................................................................................... 1-1/4 in.

Fence Height............................................................................................................................................... 5 in.

Fence Stops............................................................................................................................. 45, 90, 135 deg.

Cutterhead Type........................................................................................................................................ Spiral

Cutterhead Diameter............................................................................................................................. 3-3/8 in.

Number of Cutter Rows.................................................................................................................................... 4

Number of Indexable Cutters.......................................................................................................................... 40

Cutterhead Speed............................................................................................................................. 5409 RPM

Cutter Insert Type.................................................................................................................. Indexable Carbide

Cutter Insert Length.................................................................................................................................. 14mm

Cutter Insert Width.................................................................................................................................... 14mm

Cutter Insert Thickness............................................................................................................................... 2mm

Table Information

Table Length.............................................................................................................................................. 76 in.

Table Width.................................................................................................................................................. 8 in.

Table Thickness.................................................................................................................................... 1-1/2 in.

Floor to Table Height........................................................................................................................... 32-5/8 in.

Table Adjustment Type................................................................................................................... Lever Action

Table Movement Type.................................................................................................................. Parallelogram

Construction

Body Assembly.................................................................................................................................... Cast Iron

Cabinet.................................................................................................................................... Pre-formed Steel

Fence Assembly.................................................................................................................................. Cast Iron

Guard.......................................................................................................................................... Die Cast Metal

Table....................................................................................................................... Precision-Ground Cast Iron

Paint Type/Finish.................................................................................................................................... Enamel

Other Information

Number of Dust Ports....................................................................................................................................... 1

Dust Port Size.............................................................................................................................................. 4 in.

Mobile Base............................................................................................................................................. Built-In

Other Specifications:

Country of Origin ................................................................................................................................................ China

Warranty ........................................................................................................................................................... 1 Year

Approximate Assembly & Setup Time ............................................................................................................. 2 Hours

Serial Number Location .................................................................................................................................. ID Label

ISO 9001 Factory .................................................................................................................................................. Yes

Certified by a Nationally Recognized Testing Laboratory (NRTL) ......................................................................... Yes

Model G0490ZX (Mfd. Since 01/24)

-7-

SECTION 1: SAFETY

For Your Own Safety, Read Instruction

Manual Before Operating This Machine

The purpose of safety symbols is to attract your attention to possible hazardous conditions.

This manual uses a series of symbols and signal words intended to convey the level of importance of the safety messages. The progression of symbols is described below. Remember that safety messages by themselves do not eliminate danger and are not a substitute for proper accident prevention measures. Always use common sense and good judgment.

Indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, MAY result in minor or moderate injury. It may also be used to alert against unsafe practices.

Alerts the user to useful information about proper operation of the

NOTICE

machine to avoid machine damage.

Safety Instructions for Machinery

OWNER’S MANUAL. Read and understand this

owner’s manual BEFORE using machine.

TRAINED OPERATORS ONLY. Untrained operators have a higher risk of being hurt or killed. Only allow trained/supervised people to use this machine. When machine is not being used, disconnect power, remove switch keys, or lock-out machine to prevent unauthorized use—especially around children. Make your workshop kid proof!

DANGEROUS ENVIRONMENTS. Do not use machinery in areas that are wet, cluttered, or have poor lighting. Operating machinery in these areas greatly increases the risk of accidents and injury.

MENTAL ALERTNESS REQUIRED. Full mental alertness is required for safe operation of machinery. Never operate under the influence of drugs or alcohol, when tired, or when distracted.

ELECTRICAL EQUIPMENT INJURY RISKS. You can be shocked, burned, or killed by touching live electrical components or improperly grounded machinery. To reduce this risk, only allow qualified service personnel to do electrical installation or repair work, and always disconnect power before accessing or exposing electrical equipment.

DISCONNECT POWER FIRST. nect machine from power supply BEFORE making adjustments, changing tooling, or servicing machine. This prevents an injury risk from unintended startup or contact with live electrical components.

EYE PROTECTION. Always wear ANSI-approved safety glasses or a face shield when operating or observing machinery to reduce the risk of eye injury or blindness from flying particles. Everyday eyeglasses are NOT approved safety glasses.

Always discon-

-8-

Model G0490ZX (Mfd. Since 01/24)

may damage the wires inside. Do not handle

WEARING PROPER APPAREL. Do not wear loose clothing, gloves, neckties, or jewelry that can become entangled in moving parts. Always tie back or cover long hair. Wear non-slip footwear to reduce risk of slipping and losing control or accidentally contacting cutting tool or moving parts.

HAZARDOUS DUST. Dust created by machinery operations may cause cancer, birth defects, or long-term respiratory damage. Be aware of dust hazards associated with each workpiece material. Always wear a NIOSH-approved respirator to reduce your risk.

HEARING PROTECTION. Always wear hearing protection when operating or observing loud machinery. Extended exposure to this noise without hearing protection can cause permanent hearing loss.

REMOVE ADJUSTING TOOLS. Tools left on machinery can become dangerous projectiles upon startup. Never leave chuck keys, wrenches, or any other tools on machine. Always verify removal before starting!

USE CORRECT TOOL FOR THE JOB. Only use this tool for its intended purpose—do not force it or an attachment to do a job for which it was not designed. Never make unapproved modifications—modifying tool or using it differently than intended may result in malfunction or mechanical failure that can lead to personal injury or death!

AWKWARD POSITIONS. Keep proper footing and balance at all times when operating machine. Do not overreach! Avoid awkward hand positions that make workpiece control difficult or increase the risk of accidental injury.

CHILDREN & BYSTANDERS. Keep children and bystanders at a safe distance from the work area. Stop using machine if they become a distraction.

GUARDS & COVERS. Guards and covers reduce accidental contact with moving parts or flying debris. Make sure they are properly installed, undamaged, and working correctly BEFORE operating machine.

FORCING MACHINERY. Do not force machine. It will do the job safer and better at the rate for which it was designed.

NEVER STAND ON MACHINE. Serious injury may occur if machine is tipped or if the cutting tool is unintentionally contacted.

STABLE MACHINE. Unexpected movement during operation greatly increases risk of injury or loss of control. Before starting, verify machine is stable and mobile base (if used) is locked.

USE RECOMMENDED ACCESSORIES. Consult

this owner’s manual or the manufacturer for rec-

ommended accessories. Using improper accessories will increase the risk of serious injury.

UNATTENDED OPERATION. To reduce the risk of accidental injury, turn machine OFF and ensure all moving parts completely stop before walking away. Never leave machine running while unattended.

MAINTAIN WITH CARE. Follow all maintenance instructions and lubrication schedules to keep machine in good working condition. A machine that is improperly maintained could malfunction, leading to serious personal injury or death.

DAMAGED PARTS. Regularly inspect machine for damaged, loose, or mis-adjusted parts—or any condition that could affect safe operation. Immediately repair/replace BEFORE operating machine. For your own safety, DO NOT operate machine with damaged parts!

MAINTAIN POWER CORDS. When disconnecting cord-connected machines from power, grab and pull the plug—NOT the cord. Pulling the cord

cord/plug with wet hands. Avoid cord damage by keeping it away from heated surfaces, high traffic areas, harsh chemicals, and wet/damp locations.

EXPERIENCING DIFFICULTIES. If at any time you experience difficulties performing the intended operation, stop using the machine! Contact our Technical Support at (570) 546-9663.

Model G0490ZX (Mfd. Since 01/24)

-9-

Kickback or

cutterhead to reach full speed before feeding.

Loose knives or

Additional Safety for Jointers

Serious cuts, amputation, entanglement, or death can occur from contact with rotating cutterhead or other moving components! Flying chips from cutting operations can cause eye injuries or blindness. Workpieces or inserts/knives thrown by cutterhead (kickback) can strike nearby operator or bystanders with deadly force. To reduce the risk of serious personal injury from these hazards, operator and bystanders MUST completely heed the hazards and warnings below.

KICKBACK. Occurs when workpiece is ejected

from machine at a high rate of speed. Kickback injuries occur from getting struck by workpiece or hands being pulled into cutterhead. To reduce the risk of kickback, only use proper workpieces, safe feeding techniques, and proper machine setup or maintenance.

GUARD REMOVAL. Operating jointer without guards unnecessarily exposes operator to knives/ inserts and other hazardous moving parts. Except when rabbeting, never operate jointer or allow it to be connected to power if any guards are removed. Turn jointer OFF and disconnect power before clearing any shavings or sawdust from around cutterhead. After rabbeting or maintenance is complete, immediately replace all guards and ensure they are properly installed/adjusted before resuming regular operations.

DULL OR DAMAGED KNIVES/INSERTS. Dull or damaged knives/inserts increase risk of kickback and cause poor workpiece finish. Only use sharp, undamaged knives/inserts.

OUTFEED TABLE ALIGNMENT. Setting outfeed table too high can cause workpiece to hit table or get stuck while feeding. Setting outfeed table too low may cause workpiece to rock or shift while feeding. Both of these results will increase risk of kickback. Always keep outfeed table even with knives/inserts at highest point during rotation.

INSPECTING STOCK. Impact injuries or kickback may result from using improper workpieces. Thoroughly inspect and prepare workpiece before cutting. Verify workpiece is free of nails, staples, loose knots or other foreign material. Always joint warped workpieces with cupped side facing down.

MAXIMUM CUTTING DEPTH. To reduce risk of kickback, never cut deeper than

⁄8" per pass.

GRAIN DIRECTION. Jointing against the grain or end grain can increase risk of kickback. It also requires more cutting force, which produces chatter or excessive chip out. Always joint or surface plane WITH the grain.

CUTTING LIMITATIONS. Cutting workpieces that do not meet minimum dimension requirements can result in kickback or accidental contact with cutterhead. Never perform jointing, planing, or rabbeting cuts on pieces smaller than specified in machine data sheet.

PUSH BLOCKS. Push blocks reduce risk of accidental cutterhead contact with hands. Always use push blocks when planing materials less than 3" high or wide. Never pass your hands directly over cutterhead without a push block.

WORKPIECE SUPPORT. Poor workpiece support or loss of workpiece control while feeding will increase risk of kickback or accidental contact with cutterhead. Support workpiece with fence continuously during operation. Support long stock with auxiliary tables if necessary.

FEED WORKPIECE PROPERLY.

accidental cutterhead contact may result if workpiece is fed into cutterhead the wrong way. Allow

Never start jointer with workpiece touching cutterhead. Always feed workpiece from infeed side to outfeed side without stopping until cut is complete. Never move workpiece backwards while feeding.

SECURE KNIVES/INSERTS. improperly set inserts can be thrown from cutterhead with dangerous force. Always verify knives/ inserts are secure and properly adjusted before operation. Straight knives should never project more than

⁄8" (0.125 ") from cutterhead body.

-10-

Model G0490ZX (Mfd. Since 01/24)

For your own safety and protection of

Before installing the machine, consider the availability and proximity of the required power supply circuit. If an existing circuit does not meet the requirements for this machine, a new circuit must be installed. To minimize the risk of electrocution, fire, or equipment damage, installation work and electrical wiring must be done by an electrician or qualified service personnel in accordance with all applicable codes and standards.

or equipment damage may occur if machine is not properly grounded and connected to power

The full-load current rating is the amperage a machine draws at 100% of the rated output power. On machines with multiple motors, this is the amperage drawn by the largest motor or sum of all motors and electrical devices that might operate at one time during normal operations.

The full-load current is not the maximum amount of amps that the machine will draw. If the machine is overloaded, it will draw additional amps beyond the full-load rating.

If the machine is overloaded for a sufficient length of time, damage, overheating, or fire may result— especially if connected to an undersized circuit. To reduce the risk of these hazards, avoid overloading the machine during operation and make sure it is connected to a power supply circuit that meets the specified circuit requirements.

Note: Circuit requirements in this manual apply to a dedicated circuit—where only one machine will be running on the circuit at a time. If machine will be connected to a shared circuit where multiple machines may be running at the same time, consult an electrician or qualified service personnel to ensure circuit is properly sized for safe operation.

A power supply circuit includes all electrical equipment between the breaker box or fuse panel in the building and the machine. The power supply circuit used for this machine must be sized to safely handle the full-load current drawn from the machine for an extended period of time. (If this machine is connected to a circuit protected by fuses, use a time delay fuse marked D.)

This machine is prewired to operate on a power supply circuit that has a verified ground and meets the following requirements:

SECTION 2: POWER SUPPLY

Availability

Electrocution, fire, shock,

supply.

Full-Load Current Rating

Circuit Information

property, consult an electrician if you are unsure about wiring practices or electrical codes in your area.

Full-Load Current Rating at 240V ..... 14 Amps

Model G0490ZX (Mfd. Since 01/24)

Circuit Requirements

Nominal Voltage .........208V, 22 0V, 23 0V, 24 0V

..........................................................60 Hz

Cycle Phase Power Supply Circuit Plug/Receptacle

........................................... Single-Phase

......................... 20 Amps

............................. NEMA 6-20

-11-

No adapter should be used with plug. If

Improper connection of the equipment-grounding wire can result in a risk of electric shock. The wire with green insulation (with or without yellow stripes) is the equipment-grounding wire. If repair or replacement of the power cord or plug is necessary, do not connect the equipment-grounding wire to a live (current carrying) terminal.

Check with a qualified electrician or service personnel if you do not understand these grounding requirements, or if you are in doubt about whether the tool is properly grounded. If you ever notice that a cord or plug is damaged or worn, disconnect it from power, and immediately replace it with

We do not recommend using an extension cord with this machine. If you must use an extension cord, only use it if absolutely necessary and only on a temporary basis.

Extension cords cause voltage drop, which can damage electrical components and shorten motor life. Voltage drop increases as the extension cord size gets longer and the gauge size gets smaller (higher gauge numbers indicate smaller sizes).

Any extension cord used with this machine must be in good condition and contain a ground wire and matching plug/receptacle. Additionally, it must meet the following size requirements:

Grounding Requirements

This machine MUST be grounded. In the event of certain malfunctions or breakdowns, grounding reduces the risk of electric shock by providing a path of least resistance for electric current.

This machine is equipped with a power cord that has an equipment-grounding wire and a grounding plug. Only insert plug into a matching receptacle (outlet) that is properly installed and grounded in accordance with all local codes and ordinances. DO NOT modify the provided plug!

GROUNDED

6-20 RECEPTACLE

Current Carrying Prongs

6-20 PLUG

Serious injury could occur if you connect machine to power before completing setup process. DO NOT connect to power until instructed later in this manual.

Grounding Pin

Figure 5. Typical 6-20 plug and receptacle.

plug does not fit available receptacle, or if machine must be reconnected for use on a different type of circuit, reconnection must be performed by an electrician or qualified service personnel, and it must comply with all local codes and ordinances.

-12-

Extension Cords

Minimum Gauge Size ........................... 14 AWG

Maximum Length (Shorter is Better)

Model G0490ZX (Mfd. Since 01/24)

.......50 ft.

This machine was carefully packaged for safe transport. When unpacking, separate all enclosed items from packaging materials and inspect them for shipping damage.

please

IMPORTANT: Save all packaging materials until you are completely satisfied with the machine and have resolved any issues between Grizzly or the shipping agent. You MUST have the original pack-

aging to file a freight claim. It is also extremely helpful if you need to return your machine later.

SECTION 3: SETUP

Needed for Setup

This machine presents serious injury hazards to untrained users. Read through this entire manual to become familiar with the controls and operations before starting the machine!

Wear safety glasses during the entire setup process!

HEAVY LIF T! Straining or crushing injury may occur from improperly lifting machine or some of its parts. To reduce this risk, get help from other people and use a forklift (or other lifting equipment) rated for weight of this machine.

The following items are needed, but not included, for the setup/assembly of this machine.

Description Qty

• Additional Person ....................................... 1

• Safety Glasses (for each person) ............... 1

• Forklift or Hoist w/Lifting Straps

(rated for at least 700 lbs.) ......................... 1

• Wrenches or Sockets 10, 13mm ..........1 Ea.

• Wrenches or Sockets 17mm....................... 2

• Straightedge 4' ........................................... 1

• Phillips Head Screwdriver #2 ..................... 1

• Flat Head Screwdriver 1⁄4"........................... 1

• Prybar ......................................................... 1

• Power Drill w/Phillips Bit #2 ........................ 1

• Dust Collection System .............................. 1

• Dust Hose 4" .............................................. 1

• Hose Clamps 4" ......................................... 2

• Cleaner/Degreaser (Page 16) .... As Needed

• Disposable Shop Rags ............... As Needed

• Disposable Gloves ..................... As Needed

Unpacking

Model G0490ZX (Mfd. Since 01/24)

If items are damaged

call us immediately at (570) 546-9663.

-13-

The following is a list of items shipped with your machine. Before beginning setup, lay these items out and inventory them.

If any non-proprietary parts are missing (e.g. a nut or a washer), we will gladly replace them; or for the sake of expediency, replacements can be obtained at your local hardware store.

Inventory

Inventory (Figures 6–7) Qty

A. Tab le ........................................................... 1

Fence Carriage ........................................... 1

Fence ......................................................... 1

Cutterhead Guard ....................................... 1

E. Fence Tilt Handle ....................................... 1

Loose Tools:

— Wrench 8/10mm ...................................... 1

— Wrench 12/14mm .................................... 1

—Hex Wrenches 2.5, 4, 5, 6, 8mm

Push Blocks ................................................ 2

Cabinet w/Motor ......................................... 1

Control Panel Pedestal (Inside Cabinet) .... 1

Pedal Assembly .......................................... 1

K. Belt Guard .................................................. 1

V- B e lt 8P K-1172 .......................................... 1

Dust Port .................................................... 1

......1 Ea.

Figure 6. G0490ZX Box 1 Inventory.

Hardware Bag (Not Shown)

• Carriage Bolts M8-1.25 x 30 (Motor) .......... 2

Flat Washers 8mm (Motor) ......................... 2

•

Hex Nuts M8-1.25 (Motor) .......................... 2

•

Hex Bolt M8-1.25 x 50 (Pedal/Cabinet) ...... 1

•

Flat Washer 8mm (Pedal/Cabinet) ............. 1

•

Hex Bolts M10-1.5 x 55 (Pedal/Cabinet) ..... 2

•

Flat Washers 10mm (Pedal/Cabinet) .......... 2

•

Hex Nuts M10-1.5 (Wheel/Cabinet) ............ 2

•

Cap Screws M8-1.25 x 25 (Table/Cabinet) . 8

•

Lock Washers 8mm (Table/Cabinet) .......... 8

•

Flat Washers 8mm (Table/Cabinet) ............ 8

•

Flange Bolts M6-1 x 12 (Belt Guard) .......... 2

•

Flat Washers 6mm (Belt Guard)................. 2

•

Hex Nuts M6-1 (Belt Guard) ....................... 2

•

• Driver Bits Torx T20 ................................... 2

L-Wrenches Torx T20 ................................. 2

•

Flat Hd Torx Screws T20 M6-1 x 15 ........... 3

•

Indexable Carbide Inserts 14 x 14 x 2mm .. 3

•

Figure 7. G0490ZX Box 2 Inventory.

NOTICE

If you cannot find an item on this list, carefully check around/inside the machine and packaging materials. Often, these items get lost in packaging materials while unpacking or they are pre-installed at the factory.

-14-

Model G0490ZX (Mfd. Since 01/24)

Hardware Recognition Chart

USE THIS CHART TO MATCH UP

HARDWARE DURING THE INVENTORY AND ASSEMBLY PROCESS.

Flat Head Cap Screw

5mm

Model G0490ZX (Mfd. Since 01/24)

5mm

-15-

parts of the

The unpainted surfaces of your machine are coated with a heavy-duty rust preventative that prevents corrosion during shipment and storage. This rust preventative works extremely well, but it will take a little time to clean.

Be patient and do a thorough job cleaning your machine. The time you spend doing this now will give you a better appreciation for the proper care of your machine's unpainted surfaces.

There are many ways to remove this rust preventative, but the following steps work well in a wide variety of situations. Always follow the manufac-

turer’s instructions with any cleaning product you

use and make sure you work in a well-ventilated area to minimize exposure to toxic fumes.

Before cleaning, gather the following:

• Disposable rags

• Cleaner/degreaser (WD•40 works well)

• Safety glasses & disposable gloves

• Plastic paint scraper (optional)

Basic steps for removing rust preventative:

Many cleaning solvents

work in a well-ventilated

Cleanup

Gasoline and petroleum products have low flash points and can explode or cause fire if used to clean machinery. Avo i d using these products to clean machinery.

Put on safety glasses.

Coat the rust preventative with a liberal

amount of cleaner/degreaser, then let it soak for 5–10 minutes.

Wipe off the surfaces. If your cleaner/degreas-

er is effective, the rust preventative will wipe off easily. If you have a plastic paint scraper, scrape off as much as you can first, then wipe off the rest with the rag.

are toxic if inhaled. Only

area.

NOTICE

Avoid harsh solvents like acetone or brake parts cleaner that may damage painted surfaces. Always test on a small, inconspicuous location first.

T23692—Orange Power Degreaser

A great product for removing the waxy shipping grease from the non-painted machine during clean up.

Order online at

www.grizzly.com

Call 1-800-523-4777

Repeat Steps 2–3 as necessary until clean,

then coat all unpainted surfaces with a quality metal protectant to prevent rust.

-16-

Figure 8. T23692 Orange Power Degreaser.

Model G0490ZX (Mfd. Since 01/24)

Weight Load

Refer to the of your machine. Make sure that the surface upon which the machine is placed will bear the weight of the machine, additional equipment that may be installed on the machine, and the heaviest workpiece that will be used. Additionally, consider the weight of the operator and any dynamic loading that may occur when operating the machine.

Space Allocation

Consider the largest size of workpiece that will be processed through this machine and provide enough space around the machine for adequate operator material handling or the installation of auxiliary equipment. With permanent installations, leave enough space around the machine to open or remove doors/covers as required by the maintenance and service described in this manual.

See below for required space allocation.

Physical Environment

The physical environment where the machine is operated is important for safe operation and longevity of machine components. For best results, operate this machine in a dry environment that is free from excessive moisture, hazardous chemicals, airborne abrasives, or extreme conditions. Extreme conditions for this type of machinery are generally those where the ambient temperature range exceeds 41°–104°F; the relative humidity range exceeds 20%–95% (non-condensing); or the environment is subject to vibration, shocks,

Place this machine near an existing power source. Make sure all power cords are protected from traffic, material handling, moisture, chemicals, or other hazards. Make sure to leave enough space around machine to disconnect power supply or

Lighting around the machine must be adequate enough that operations can be performed safely. Shadows, glare, or strobe effects that may distract or impede the operator must be eliminated.

Site Considerations

Machine Data Sheet for the weight

or bumps.

Electrical Installation

Children or untrained people may be seriously injured by this machine. Only install in an access restricted location.

Minimum 30"

apply a lockout/tagout device, if required.

Lighting

Wall

761⁄2"

24"

= Electrical Connection

Figure 9. Minimum working clearances.

Model G0490ZX (Mfd. Since 01/24)

-17-

The machine must be fully assembled before it can be operated. Before beginning the assembly process, refer to

and gather

all

To ensure the assembly process

goes smoothly, first clean any

covered or coated in heavy-duty rust preventative (if applicable).

Assembly

Attach motor to motor mount brackets with (4)

M8-1.25 x 30 carriage bolts, 8mm flat washers, and M8-1.25 hex nuts (two sets from inventory and two sets removed in Step 6), as shown in Figure 10.

Needed for Setup

listed items.

parts that are

To assemble machine:

With help from another person, tip cabinet

shipping box upside down, then lift shipping box off cabinet.

Place a piece of cardboard on floor, tip cabi-

net over so cabinet top is on cardboard, then remove plastic from cabinet.

Reach inside cabinet and remove accesso-

ries box, V-belt, and dust port.

Remove control panel pedestal and fasteners

from inside cabinet and set aside.

Remove rear cabinet panel.

6. Reach inside cabinet and remove (2) M8-1.25

x 30 carriage bolts, 8mm hex nuts, and 8mm flat washers that secure motor to cabinet top.

Note: Pulley alignment and V-belt installation

will take place in later steps.

Motor Mount Brackets

x 4

Figure 10. Motor installed.

10. Attach pedal assembly to right side of cabi-

net with (1) M8-1.25 x 50 hex bolt, 8mm flat washer, and (2) M10-1.5 x 55 hex bolts, 10mm flat washers, and M10-1.5 hex nuts (see Figure 11).

Note: Retain fasteners so they can be used

to install motor in a later step.

Using cardboard to protect cabinet, and

another person to hold motor, place cabinet on left side so dust chute is facing down.

Place motor on two motor mount brackets

with pulley facing rear of cabinet, as shown in Figure 10.

-18-

x 2

Figure 11. Installing pedal assembly.

Model G0490ZX (Mfd. Since 01/24)

From inside cabinet, insert power cord plug

11.

through same hole in cabinet that control panel pedestal cord is in.

With help from another person, place cabinet

12.

upright.

Attach dust port to cabinet with pre-installed

13.

Phillips screws and flat washers, as shown in Figure 12.

x 4

Figure 12. Installing dust port.

With another person to steady load, carefully

16.

lift table over cabinet and align eight mounting holes in cabinet with holes in bottom of table.

Note: Make sure cutterhead pulley is facing

rear of cabinet.

17. Attach table to cabinet with (8) M8-1.25 x 25

cap screws, 8mm lock washers, and 8mm flat washers (see Figure 14).

x 8

Remove (2) hex nuts and flat washers from

14.

underneath shipping crate that hold table to crate.

Wrap lifting straps around infeed and outfeed

15.

table, as illustrated in Figure 13, then attach them to forklift or hoist.

Figure 13. Using lifting straps to lift table.

Figure 14. Securing table to cabinet.

18.

Attach control panel pedestal to back of

infeed table with (2) M10-1.5 x 25 cap screws, 10mm lock washers, and 10mm flat washers removed in Step 4 (see Figure 15).

x 2

Model G0490ZX (Mfd. Since 01/24)

Figure 15. Installing control panel pedestal.

-19-

19.

Use a straightedge to check alignment of

cutterhead and motor pulleys (see Figure 16).

Cutterhead

Touching

Evenly

Fence Carriage

Motor

Straightedge

Figure 16. Pulleys aligned.

— If pulleys are not aligned, loosen (4) hex

nuts on carriage bolts shown in Figure 17, shift motor horizontally to align pulleys, then secure carriage bolts.

x 2

Figure 18. Fence carriage installed.

Wrap V-belt around cutterhead and motor

21.

pulleys (see Figure 19). Make sure ribs of V-belt are seated in pulley grooves.

Figure 17. Motor adjustment.

20. Use (2) pre-installed cap screws and flat

washers to install fence carriage to rear of table, as shown in Figure 18.

-20-

Figure 19. V-belt installed.

Model G0490ZX (Mfd. Since 01/24)

22. Loosen flange nuts on carriage bolts secur-

ing motor mounting brackets, let motor slide down to place tension on V-belt, then tighten flange nuts (see Figure 20).

x 2

Figure 22. Installing fence.

25. Install fence tilt handle (see Figure 23).

Figure 20. Motor mount carriage bolts.

Note: When properly tensioned, there is

approximately

⁄4" deflection of V-belt as mod-

erate pressure is applied midway between pulleys, as illustrated in Figure 21. If necessary, apply downward pressure on motor to attain proper V-belt tension.

Cutterhead Pulley

Approximately

/4" Deflection

Motor Pulley

Figure 21. Correct V-belt deflection when

properly tensioned.

Fence Tilt

Handle

Figure 23. Installing fence tilt handle.

26. Use (2) M6-1 x 12 flange bolts, 6mm flat

washers, and M6-1 hex nuts to install belt guard under fence carriage (see Figure 24).

x 2

Verify outfeed table height is set correctly with

23. inserts at top dead center (TDC) (see Setting Outfeed Table Height on Page 48) and all

inserts are securely tightened in cutterhead.

Use (2) pre-installed cap screws on fence

24. carriage to install fence (see Figure 22).

Model G0490ZX (Mfd. Since 01/24)

Belt Guard

Figure 24. Installing belt guard.

-21-

27. Install rear cabinet panel.

28. Set fence to 90º and move it all the way back.

29. Insert cutterhead guard shaft into extension

fence, as shown in Figure 25, so shaft flat is facing set screw, then tighten set screw against shaft.

Figure 25. Installing cutterhead guard.

Dust Collection

DO NOT operate Model G0490ZX without an adequate dust collection system. This jointer creates substantial amounts of wood dust while operating. Failure to use a dust collection system can result in short and long-term respiratory illness.

Recommended CFM at Dust Port: 400 CFM

Do not confuse this CFM recommendation with the rating of the dust collector. To determine the CFM at the dust port, you must consider these variables: (1) CFM rating of the dust collector, (2) hose type and length between the dust collector and the machine, (3) number of branches or wyes, and (4) amount of other open lines throughout the system. Explaining how to calculate these variables is beyond the scope of this manual. Consult an expert or purchase a good dust collection "how-to" book.

The cutterhead guard is a critical safety feature of this jointer. You MUST verify its operation before using the jointer! Failure to properly install this guard will greatly increase risk of serious personal injury.

30. Verify proper operation of cutterhead guard

by setting fence to 90°, moving fence to rear of table, then pulling cutterhead guard back and letting it go. It should spring back over cutterhead and contact fence without dragging across outfeed table.

If cutterhead guard DOES NOT spring

—

back over cutterhead and contact fence, or if it drags across outfeed table, then it must be adjusted (see Checking/Adjusting Cutterhead Guard on Page 39 for com- plete instructions).

To connect a dust collection hose:

Fit 4" dust hose over dust port on left side

of cabinet and secure in place with a hose clamp (see Figure 26).

Tug hose to make sure it does not come off.

Note: A tight fit is necessary for proper per-

formance.

-22-

Figure 26. Example of dust hose connected to

dust port.

Model G0490ZX (Mfd. Since 01/24)

Once assembly is complete, test run the machine to ensure it is properly connected to power and safety components are functioning correctly.

If you find an unusual problem during the test run, immediately stop the machine, disconnect it from power, and fix the problem BEFORE operating the machine again. The

table in the

SERVICE section of this manual can help.

DO NOT start machine until all preceding setup instructions have been performed. Operating an improperly set up machine

ed results that can lead to serious injury,

Serious injury or death can result from

Test Run

Troubleshooting

Remove switch disabling key, as shown in

Figure 27.

The Test Run consists of verifying the following:

1) The motor powers up and runs correctly, and

2) the switch disabling key disables the switch

properly.

using this machine BEFORE understanding its controls and related safety information. DO NOT operate, or allow others to operate, machine until the information is understood.

may result in malfunction or unexpect-

death, or machine/property damage.

Figure 27. Removing switch key from paddle

switch.

Try to start machine with paddle switch dis-

abling key removed. Machine should not start.

— If machine does not start, switch disabling

feature is working correctly.

— If machine does start, immediately stop

machine. Switch disabling feature is not working correctly. This safety feature must work properly before proceeding with regular operations. Call Tech Support for help.

Recommended

Adjustments

To test run machine:

1. Clear all setup tools away from machine.

2. Ensure POWER switch is in down position.

3. Connect machine to power supply.

4. Move POWER switch to up position to turn

machine ON.

Press START button to start motor. Verify

motor operation, then press STOP button to stop motor.

The motor should run smoothly and without

unusual problems or noises.

Model G0490ZX (Mfd. Since 01/24)

For your convenience, the adjustments listed below have been performed at the factory and no further setup is required to operate your machine. However, because of the many variables involved with shipping, we recommend that you at least verify the following adjustments to ensure the best possible results from your new machine.

Factory adjustments that should be verified:

Table Parallelism (Page 44).

•

Calibrating Depth Scale (Page 49).

•

Setting Fence Stops (Page 50).

•

-23-

The purpose of this overview is to provide the novice machine operator with a basic understanding of how the machine is used during operation, so the

discussed

later in this manual

Due to the generic nature of this overview, it is not intended to be an instructional guide. To learn more about specific operations, read this entire manual,

training from experienced machine operators, and do additional research outside of this manual by reading "how-to" books, trade magazines, or websites.

To reduce your risk of serious injury, read this entire manual BEFORE

ing loss can occur while operating this

SECTION 4: OPERATIONS

Operation Overview

machine controls/components

are easier to understand.

seek additional

To complete a typical operation, the operator does the following:

Examines workpiece to verify it is safe and

suitable for jointing.

Adjusts fence for width of workpiece and

locks it in place.

Adjusts fence tilt, if necessary.

Adjusts infeed table height to set depth of cut

per pass.

Ensures cutterhead guard position and oper-

ation are functioning properly.

Puts on safety glasses, respirator, hearing

protection, and any other required protective equipment.

using machine.

Eye injuries, respiratory problems, or hear-

tool. Wear personal protective equipment to reduce your risk from these hazards.

If you are not experienced with this type of machine, WE STRONGLY RECOMMEND that you seek additional training outside of this manual. Read books/magazines or get formal training before beginning any projects. Regardless of the content in this section, Grizzly Industrial will not be held liable for accidents caused by lack of training.

-24-

Starts dust collection and jointer.

Using push blocks as needed, holds

workpiece firmly against infeed table and fence, and feeds workpiece into cutterhead at a steady and controlled rate until entire length of workpiece has been cut and it clears the cutterhead on the outfeed table side.

Repeats cutting process described above

until desired results are achieved.

Stops jointer and dust collection.

10.

Model G0490ZX (Mfd. Since 01/24)

• Scrape all glue off the workpiece before

Glue deposits on the workpiece,

hard or soft, will gum up the cutterhead and

• Remove foreign objects from the work-

Make sure that any stock you process with the jointer is clean and free of dirt, nails, staples, tiny rocks or any other foreign objects that could damage the cutterhead. These particles could also cause a spark as they strike the cutterhead and create a fire

Wood stacked on a concrete

or dirt surface can have small pieces of con-

• Make sure all stock is sufficiently dried

Wood with a moisture content over 20% will cause unnecessary wear on the cutters and poor cutting results. Excess moisture can also hasten rust and corrosion.

Follow these rules when choosing and jointing stock:

• DO NOT joint or surface plane stock that

Injury to the operator or damage to the workpiece can occur if a knot becomes dislodged during the

• DO NOT joint or surface plane against the

Cutting against the grain

increases the likelihood of kickback, as well

• Jointing and surface planing with the

grain produces a better finish and is safer

Cutting with the grain is described as feeding the stock on the jointer so the grain points down and toward you as viewed

If the grain changes direction along the edge of the board, decrease the cutting depth and make additional passes.

• Only cut natural wood. This jointer is only

designed for cutting natural wood stock.

wood, laminates, drywall, backer board, metals, glass, stone, tile, products with lead-based paint, or products that contain asbestos. Cutting these may lead to injury or machine damage.

Stock Inspection &

jointing.

Requirements

contains large or loose knots.

cutting operation.

grain direction.

as tear-out on the workpiece.

for the operator.

on the edge of the stock (see Figure below).

Note:

produce poor results.

piece.

hazard.

IMPORTANT:

crete or stone pressed into the surface.

before jointing.

Edge Jointing

10" Min.

CORRECT

INCORRECT

Figure 28. Proper grain alignment with the

Never use it to cut MDF, particle board, ply-

Model G0490ZX (Mfd. Since 01/24)

cutterhead.

With Grain

Against Grain

/4" Min.

Surface Planing

10" Min.

/2" Min.

/4" Min.

Figure 29. Minimum stock dimensions for jointer.

-25-

Setting Depth of Cut

The depth of cut on a jointer is the amount of material removed from the bottom of the workpiece as it passes over the cutterhead.

The depth of cut is set by adjusting the height of the infeed table relative to the carbide inserts at TDC (top dead center).

Depth-of-Cut Scale

The depth of cut can be referenced directly from the depth scale located on the front of the jointer (see Figures 31–32).

Note: The depth scale can be calibrated or "zeroed" if it is not correct. Refer to Calibrating Depth Scale on Page 49 for more information.

DO NOT exceed 1⁄8" depth of cut per pass

when edge jointing and

pass when surface planing on this machine

or kickback and serious injury may occur!

⁄16" depth of cut per

Adjusting Infeed Table Height

To adjust the infeed table height, loosen the infeed table lock, use the infeed table adjustment lever to raise or lower table, then tighten the lock to secure the setting (see Figure 30).

Infeed Table Lock

Figure 31. Location of depth-of-cut scale.

Depth Scale

Pointer

Scale

-26-

Infeed

Table

Adjustment

Lever

Figure 30. Infeed table controls.

Figure 32. Depth-of-cut components location.

Model G0490ZX (Mfd. Since 01/24)

Squaring stock involves four steps performed in the order below:

1. Surface Plane on Jointer—Concave face of

workpiece is surface planed flat with jointer.

2. Surface Plane on a Thickness Planer—

Opposite face of workpiece is surface planed flat with a thickness planer.

3. Edge Joint on Jointer—Concave edge of

workpiece is jointed flat with jointer.

4. Rip Cut on a Table Saw—Jointed edge

of workpiece is placed against a table saw fence and opposite edge cut off.

Squaring Stock

Opposite Edge

Rip Cut with

Table Saw

Previously

Jointed Edge

Previously Surface

Planed Face

Model G0490ZX (Mfd. Since 01/24)

-27-

To surface plane on jointer:

1. Stock Inspection &

2. Set infeed table height to desired cutting

To minimize risk of kickback,

" per pass

5. Place workpiece firmly against fence and

To ensure workpiece remains

of workpiece

head while keeping it firmly against fence

Keep hands at least 4" away from cutterhead during the entire cut. Instead of allowing a hand to pass directly over cutterhead, lift it up and over cutterhead, and safely reposition it on the outfeed side to continue supporting workpiece. Use push blocks whenever practical to further reduce risk of

When squaring up stock, cut opposite side of workpiece with a planer instead of the jointer to ensure both sides are parallel.

Failure to use push blocks when surface

ing rotating cutterhead, which will cause serious personal injury. ALWAYS use push

The purpose of surface planing (see example

Figures

on the jointer is to make one flat face on a piece of stock to prepare it for thickness planing on a planer.

Surface Planing

below)

planing could result in your hands contact-

Inspect stock to ensure it is safe and suitable

for the operation (see Requirements section).

depth for each pass.

CAUTION:

do not exceed a cutting depth of when surface planing.

Set fence to 90°.

⁄16

blocks when surface planing on jointer!

Figure 33. Example of surface planing

operations.

Start jointer.

infeed table.

CAUTION:

stable during cut, concave sides must face toward table and fence.

Feed workpiece completely across cutter-

and tables during the entire cut.

CAUTION:

accidental hand contact with cutterhead.

Repeat Step 6 until entire surface is flat.

Figure 34. Illustration of surface planing results.

-28-

Removed

Surface

Tip:

Model G0490ZX (Mfd. Since 01/24)

To edge joint on jointer:

Stock Inspection &

Surface

3. Set infeed table height to desired cutting

To minimize risk of kickback,

6. Place workpiece firmly against fence and

To ensure workpiece remains

of workpiece

head while keeping it firmly against fence

When squaring up stock, cut opposite edge of workpiece with a table saw instead of the jointer—otherwise, both edges of workpiece will not be parallel with each other.

Edge jointing (see example Figures below) produces a flat and true surface along the side of a workpiece by removing uneven areas.

essential step for

or rough stock and when preparing a workpiece for joinery or finishing.

Edge Jointing

Inspect stock to ensure it is safe and suitable

for the operation (see Requirements section).

squaring up warped

Figure 35. Example of edge jointing operation.

It is

Surface plane workpiece (see

Planing section).

depth for each pass.

CAUTION:

do not exceed a cutting depth of

Set fence to 90°.

Start jointer.

infeed table with concave side facing down.

CAUTION:

stable during cut, concave sides must face toward table and fence.

Feed workpiece completely across cutter-

and tables during the entire cut.

CAUTION:

⁄8" per pass

Figure 36. Illustration of edge jointing results.

Model G0490ZX (Mfd. Since 01/24)

Removed

Surface

accidental hand contact with cutterhead.

Repeat Step 6 until the entire edge is flat.

Tip:

-29-

To bevel cut on jointer:

Stock Inspection &

Surface

4. Set infeed table height to cutting depth

Cutting depth for bevel cuts is

, depending on

workpiece against table and fence with firm pressure, and feed workpiece over cutter-

When your leading hand gets within 4" of the cutterhead, lift it up and over cutterhead, and place push block on portion

. Now, focus your pressure on outfeed end of the workpiece while feeding, and repeat same action with your trailing hand when it

keep

your hands safe, DO NOT let them get closer

at any time

you are satisfied with the results.

Bevel cuts (see example Figures below) can be made by setting the fence at the desired angle and feeding the workpiece firmly along the fence face, with the bottom inside corner firmly against the table. The cutting process typically requires multiple passes or cuts to bevel the entire edge of a workpiece.

Bevel Cutting

Inspect stock to ensure it is safe and suitable

for the operation (see Requirements section).

Surface plane workpiece (see

Planing section).

Edge joint workpiece (see Edge Jointin

section).

Figure 37. Fence setup for a bevel cut of 45°.

desired for each pass.

CAUTION:

typically between hardness and width of stock.

Set fence tilt to desired angle of cut.

Place workpiece against fence and infeed

table with concave side face down.

Start jointer.

With a push block in your leading hand, press

head with a push block in your trailing hand.

CAUTION:

of the workpiece once it is 4" past cutterhead

⁄16" and 1⁄8"

Figure 38. Illustration of bevel cutting results.

-30-

Removed

Surface

gets within 4" of cutterhead. To help

than 4" from moving cutterhead during operation!

Repeat cutting process, as necessary, until

Model G0490ZX (Mfd. Since 01/24)

A rabbet cut removes a portion of a workpiece edge, so it fits together with an opposing, equally sized rabbet cut on another workpiece (see example

. This is a classic method of

joining two workpieces that is simple, yet strong.

This jointer can be used to make high-quality rabbet cuts, but there are some situations—whether it

s due to an excessively large/small workpiece size or rabbet cutting width/depth—when it will not be safe or appropriate for making the rabbet cut on this jointer. In these cases, you need to use another tool or method for rabbet cutting that will be a safer alternative.

alternatively be made using a table saw, router, or even a hand saw. As with any type of cutting operation, always consider your safety first and use good

Typically, rabbet cutting with a jointer requires the cutterhead guard to be removed first, so the workpiece can slide along the rabbeting ledge during the cut. However, it is possible to make rabbet cuts with workpieces up to 1

without removing the cutterhead guard. This is done by performing the rabbet cut with the workpiece on end (similar to when you are edge jointing).

Rabbet Cutting

Figure below)

Removed

Surface

Rabbet Joints

To rabbet cut on jointer:

Inspect stock to ensure it is safe and suitable

1. for the operation (see Stock Inspection & Requirements on Page 25).

2. Set infeed table height to desired cutting

depth for each pass.

CAUTION: For safety reasons, cutting

depth should never exceed

Remove cutterhead guard if necessary to per-

form operation (see Figure 39).

Guard Installed

⁄8" per pass.

rabbet cut can

Model G0490ZX (Mfd. Since 01/24)

judgement!

" thick

Guard Removed

Figure 39. Examples of typical rabbet cutting

operations.

-31-

When cutterhead guard is removed,

essary exposure to cutterhead, always

Feed workpiece completely across cutterhead

while keeping it firmly against fence and tables during entire cut.

attempting any other cut besides a rabbet directly exposes operator to moving cutterhead. To minimize risk of injury and unnec-

keep cutterhead guard installed when possible, and ALWAYS immediately replace it after performing rabbet cuts.

4. Set fence to 90° and near front of jointer,

so amount of exposed cutterhead in front of fence matches size of desired rabbet.

Start jointer.

6. Place workpiece firmly against fence and

infeed table.

CAUTION: To ensure workpiece remains

stable during cut, concave sides of workpiece must face toward table and fence.

CAUTION: Keep hands at least 4" away

from cutterhead during the entire cut. Instead of allowing a hand to pass directly over cutterhead, lift it up and over cutterhead, and safely reposition it on the outfeed side to continue supporting workpiece. Use push blocks whenever practical to further reduce risk of accidental hand contact with cutterhead.

Repeat Step 7 until rabbet is cut to depth.

Re-install cutterhead guard if removed in

9. Step 3 (see Checking/Adjusting Cutterhead Guard on Page 39).

-32-

Model G0490ZX (Mfd. Since 01/24)

order online at www.grizzly.com or call 1-800-523-4777

Installing unapproved accessories may

SECTION 5: ACCESSORIES

cause machine to malfunction, resulting in serious personal injury or machine damage. To reduce this risk, only install accessories recommended for this machine by Grizzly.

NOTICE

Refer to our website or latest catalog for additional recommended accessories.

H7319—Indexable Carbide Inserts (10 Pack)

These indexable carbide inserts can be rotated to provide four factory sharp edges before replacement. Inserts measure 14 x 14 x 2mm.

G0862—3 HP Portable Cyclone Dust Collector

The capstone of our line of affordable, high- quality cyclones, the G0862 features a 3 HP motor, a whopping 1941 CFM of airflow capacity, and a 45-gallon collection capacity. It's packed with features like a quick-release collection drum, latching system, high-efficiency, two-stage separation driven by a 16" aluminum impeller, durable powder coated finish, and a heavy-duty steel frame and housing.

Figure 40. Replacement carbide inserts for

Model G0490ZX.

Model G0490ZX (Mfd. Since 01/24)

Figure 41. Model G0862 3 HP Portable Cyclone

Dust Collector.

-33-

To reduce risk of shock or accidental startup, always disconnect machine from

The cleaning process for this machine is simple. Vacuum excess wood chips and sawdust, and wipe off the remaining dust with a dry cloth. If any resin has built up, use a resin dissolving cleaner to remove it. Treat all unpainted cast iron and steel with a non-staining lubricant after cleaning.

SECTION 6: MAINTENANCE

Cleaning &

Protecting

power before adjustments, maintenance, or service.

Schedule

For optimum performance from this machine, this maintenance schedule must be strictly followed.

Ongoing

To minimize your risk of injury and maintain proper machine operation, shut down the machine immediately if you ever observe any of the items below, and fix the problem before continuing operations:

• Loose mounting bolts.

• Dust or debris on and around machine. Dull or damaged cutterhead inserts.

• Unprotected cast-iron surfaces.

• Worn or damaged wires.

• Any other unsafe condition.

•

Monthly Check

• V-belt tension, damage, or wear (Page 41).

• Clean/vacuum dust buildup from inside cabi-

net and off motor.

Protect the unpainted cast iron surfaces on the table by wiping the table clean after every use— this ensures moisture from wood dust does not remain on bare metal surfaces.

Keep tables rust-free with regular applications of quality lubricants.

Recommended Metal Protectants

G5562—SLIPIT® 1 Qt. Gel G5563—SLIPIT

11 Oz . Spray

-34-

Figure 42. Recommended products for

protecting unpainted cast-iron and steel.

Model G0490ZX (Mfd. Since 01/24)

Since all bearings are sealed and permanently lubricated, simply leave them alone until they need to be replaced. DO NOT lubricate them.

It is essential to clean components before lubricating them because dust and chips build up on lubricated components and make them hard to move. Simply adding more grease to them will not yield smooth moving components.

Clean the components below with mineral spirits or other oil/grease solvent cleaner and shop rags.

Lubrication

SB1365—South Bend Way Oil-ISO 68

Infeed/Outfeed Table Controls

Oil Type ................ SB1365 or ISO 68 Equivalent

Oil Amount

Frequency.......................................... As Needed

Lubricate the infeed/outfeed table adjustment lever components with light machine oil as needed (see Figure 44). Wipe off excess oil and sawdust with a cloth.

............................................Thin Coat

Figure 43. Recommended product for machine

lubrication.

Figure 44. Adjustment lever lubrication location.

Fence

Oil Type ................ SB1365 or ISO 68 Equivalent

Oil Amount Lubrication Frequency

Place one or two drops of light machine oil on fence pivot points (see Figure 45) as needed.

...........................................1–2 Drops

....................... As Needed

Figure 45. Fence lubrication locations.

Model G0490ZX (Mfd. Since 01/24)

-35-

Review the troubleshooting procedures in this section if a problem develops with your machine. If you need replacement parts or additional help with a procedure, call our Technical Support.

the

serial number and manufacture date of your machine before calling.

SECTION 7: SERVICE

Troubleshooting

Motor & Electrical

Symptom Possible Cause Possible Solution

Machine does not start, or power supply breaker immediately trips after startup.

Machine stalls or is underpowered.

1. POWER switch in OFF position.

2. POWER switch disabling key removed.

3. Incorrect power supply voltage or circuit size.

4. Power supply circuit breaker tripped or fuse blown.

5. Motor wires connected incorrectly.

6. Thermal overload relay has tripped/at fault.

7. Start capacitor at fault.

8. Centrifugal switch adjustment/contact points at fault.

9. Contactor not energized/at fault.

10. Wiring broken, disconnected, or corroded.

11. ON/OFF button(s) at fault.

12. Motor or motor bearings at fault.

1. Workpiece material unsuitable for machine.

2. Feed rate/cutting speed too fast.

3. Workpiece crooked; fence loose or misadjusted.

4. Machine undersized for task.

5. Belt slipping/pulleys misaligned.

6. Motor wires connected incorrectly.

7. Pulley/sprocket slipping on shaft.

8. Motor overheated.

9. Run capacitor at fault.

10. Extension cord too long.

11. Contactor not energized/at fault.

12. Centrifugal switch/contact points at fault.

13. Motor or motor bearings at fault.

1. Move POWER switch to ON position.

2. Install POWER switch disabling key.

3. Ensure correct power supply voltage and circuit size.

4. Ensure circuit is free of shorts. Reset circuit breaker or replace fuse.

5. Correct motor wiring connections (Page 51).

6. Reset. Adjust or replace if at fault.

7. Test/replace if at fault.

8. Adjust centrifugal switch/clean contact points. Replace either if at fault.

9. Test all legs for power; replace if necessary.

10. Fix broken wires or disconnected/corroded connections.

11. Replace button(s).

12. Replace motor.

1. Only cut wood/ensure moisture is below 20% (Page 25).

2. Decrease feed rate/cutting speed.

3. Straighten or replace workpiece/adjust fence (Page 50).

4. Use sharp inserts; reduce feed rate/depth of cut (Page 26).

5. Clean/tension/replace belt (Page 41); ensure pulleys are aligned (Page 41).

6. Correct motor wiring connections.

7. Tighten/replace loose pulley/shaft.

8. Clean motor, let cool, and reduce workload.

9. Test/repair/replace.

10. Move machine closer to power supply; use shorter extension cord (Page 12).

11. Test all legs for power; repair/replace if at fault.

12. Adjust centrifugal switch/clean contact points. Replace either if at fault.

13. Replace motor.

Note: Please gather

-36-

Model G0490ZX (Mfd. Since 01/24)

Motor & Electrical (Cont.)

Symptom Possible Cause Possible Solution

Machine has vibration or noisy operation.

1. Motor or component loose.

2. Mobile cabinet feet not adjusted properly.

3. V-belt worn, loose, pulleys misaligned or belt slapping cover.

4. Insert(s) at fault.

5. Pulley loose.

6. Motor mount loose/broken.

7. Motor fan rubbing on fan cover.

8. Cutterhead bearings at fault.

9. Centrifugal switch needs adjustment/at fault.

10. Motor bearings at fault.

1. Replace damaged or missing bolts/nuts; tighten if loose.

2. Adjust mobile cabinet feet to stabilize machine.

3. Inspect/replace belt (Page 41). Re-align pulleys if necessary (Page 41).

4. Rotate/replace insert(s) (Page 43).

5. Secure pulley on shaft (Page 42).

6. Tighten/replace.

7. Fix/replace fan cover; replace loose/damaged fan.

8. Replace bearing(s)/re-align cutterhead.

9. Adjust/replace if at fault.

10. Test by rotating shaft; rotational grinding/loose shaft requires bearing replacement.

Operation

Symptom Possible Cause Possible Solution

Table(s) hard to adjust.

Excessive snipe (gouge in end of board that is uneven with rest of cut); back of workpiece is concave.

Workpiece stops in middle of cut; front of workpiece is concave.

Workpiece chipping, tear-out, indentations, or overall rough cuts.

1. Table lock(s) engaged/partially engaged.

2. Table stop(s) blocking movement.

1. Outfeed table set too low.

2. Operator pushing down on trailing end (infeed side) of workpiece as it leaves cutterhead.

1. Outfeed table set too high. 1. Align outfeed table with cutterhead inserts at top dead

1. Workpiece is rough or has loose knots/

surface aws; not suitable for jointing.

2. Not feeding workpiece to cut "with" the grain.

3. Dull inserts.

4. Nicked or chipped insert(s).

5. Feeding workpiece too fast.

6. Excessive depth of cut.

7. Lack of proper dust collection or clogged dust port.

1. Completely loosen table lock(s) (Page 4).

2. Loosen/reset table stop(s) (Page 49).

1. Align outfeed table with cutterhead inserts at top dead

center (Page 48).

2. Focus most of the workpiece pressure against outfeed table while cutting.

center (Page 48).

1. Inspect workpiece. Use smooth stock without loose knots/surface aws (Page 25).

2. Flip workpiece 180° before feeding again.

3. Rotate/replace inserts (Page 43).

4. Rotate/replace inserts (Page 43).

5. Reduce feed rate.

6. Reduce depth of cut (Page 26).

7. Clear blockages, ensure dust collection is operating

efciently; upgrade dust collector.

Model G0490ZX (Mfd. Since 01/24)

-37-

Operation (Cont.)

Symptom Possible Cause Possible Solution

Fuzzy grain left in workpiece.

Long lines or ridges that run along length of workpiece.

Uneven cutter marks, wavy surface, or chatter marks across face of workpiece.

Glossy surface; scorching or burn marks on workpiece.

Workpiece is concave or convex along its length after jointing.

Workpiece edges not square; tapered cut produced.

1. Wood has high moisture content.

2. Dull inserts.

1. Nicked or chipped inserts.

2. Loose or incorrectly installed insert(s).

3. Dirt or debris under insert(s).

1. Feeding workpiece too fast.

2. Insert(s) not properly adjusted or dirt or debris under insert(s).

1. Dull inserts.

2. Feed rate too slow.

1. Workpiece not held with even pressure against outfeed table during cut.

2. Workpiece too uneven at start of operation.

3. Tables not parallel with cutterhead and each other.

1. Fence not square to table(s); fence tilt unlocked.

2. Warped infeed or outfeed table.

3. Insert(s) not adjusted at even heights in cutterhead.

1. Ensure wood moisture content is less than 20%. Allow

to dry if necessary (Page 25).

2. Rotate/replace inserts (Page 43).

1. Rotate/replace inserts (Page 43).

2. Remove/replace insert(s) and install properly

(Page 43).

3. Remove insert(s), clean bottom of insert/cutterhead

mounting pocket and re-install (Page 43).

1. Reduce feed rate.

2. Remove, clean, and re-install any inserts that are

"raised" in cutterhead (Page 43).

1. Rotate/replace inserts (Page 43).

2. Increase feed rate.

1. Apply even, downward pressure against workpiece throughout entire travel along outfeed side during cut.

2. Take partial cuts to remove extreme high spots before doing a full pass.

3. Verify/adjust table parallelism (Page 44).

1. Square fence to table(s) (Page 50); lock fence.

2. Regrind/replace table.

3. Remove, clean, and re-install any inserts that are "raised" in cutterhead (Page 43).

-38-

Model G0490ZX (Mfd. Since 01/24)

Checking/Adjusting

Cutterhead Guard

The cutterhead guard is designed to reduce the risk of accidental contact with hands or fingers with the spinning cutterhead. When properly installed and functioning correctly, the guard automatically rotates clear of the cutterhead during the cutting operation and then springs back over the cutterhead as soon as the operation is complete.

To check/adjust cutterhead guard:

DISCONNECT MACHINE FROM POWER!

2. Loosen fence lock, move fence all the way

back, then tighten fence lock.

Pull cutterhead guard back and let it go. It

should spring back over cutterhead and rest against fence (see Figure 46).

— If cutterhead guard does spring back

over cutterhead and rest against fence, cutterhead guard is properly tensioned. Proceed to Step 7.

— If cutterhead guard does not spring back

over cutterhead and rest against fence, proceed to Step 4.

In order to function as intended, the guard must be installed as low as possible over the infeed table without actually touching it (approximately

⁄16 " above infeed table), and it must have enough

spring tension at the mounting shaft to quickly reposition itself against the fence after it is rotated away from the cutterhead and released. Before performing rabbeting operations, adjust guard height to just clear outfeed table.

Items Needed Qty

Heavy Leather Gloves ..................................1 Pr.

Hex Wrenches 4, 6mm Straight Jaw Pliers 10"

................................ 1 Ea.

...................................... 1

Figure 46. Cutterhead guard against fence.

Model G0490ZX (Mfd. Since 01/24)

-39-

4. Put on heavy leather gloves and loosen cap

screw securing cutterhead guard clamp just enough so cutterhead guard moves freely (see Figure 47). DO NOT remove cap screw.

Guard Clamp

Figure 47. Location of cutterhead guard clamp

and cap screw.

With cutterhead guard resting against fence,

use straight-jaw pliers to rotate cutterhead

guard clamp a

⁄4 turn clockwise, then tighten

cap screw to secure guard clamp, as shown in Figure 48.

Clockwise

Rotation

6. Pull cutterhead guard back and let it go. It

should spring back over cutterhead and rest against fence.

— If cutterhead guard does spring back

over cutterhead and rest against fence, cutterhead guard is properly tensioned. Proceed to Step 7.

— If cutterhead guard does not spring back

over cutterhead and rest against fence, repeat Steps 4–5 until properly adjusted, then proceed to Step 7.

Verify cutterhead guard height is as low as

possible (approximately 1⁄8" above infeed table) without dragging on infeed table/rabbeting extension.

— If cutterhead guard is as low as possible

without dragging on infeed table/rabbeting extension, cutterhead guard height is correct. No further adjustment is required.

— If cutterhead guard is not as low as possible

or drags on infeed table/rabbeting extension, loosen set screw securing cutterhead guard shaft, position cutterhead guard until

it is approximately

⁄8" above infeed table,

then tighten set screw (see Figure 49).

Cap

Screw

Fence

Cutterhead

Guard Clamp

Figure 48. Rotating cutterhead guard clamp

(tables removed for clarity).

-40-

Figure 49. Location of cutterhead guard shaft

set screw.

Model G0490ZX (Mfd. Since 01/24)

Tensioning/

Replacing V-Belt

To ensure optimum power transmission from the motor to the cutterhead, the V-belt must be in good condition (free from cracks, fraying and wear) and properly aligned and tensioned.

After approximately 16 hours of operation, belt will stretch and seat into pulley grooves. The belt needs to be re-tensioned after this initial break-in period to ensure optimum power transfer and maximum overall life of the belt.

Items Needed Qty

Additional Person .............................................. 1

Replacement V-Belt (P0490ZX224) Phillips Head Screwdriver #2 Wrenches or Sockets 12, 13mm

............................ 1

.................. 1

.................1 Ea.

Belt and pulleys will be hot after operation. Allow them to cool before handling.

5. Press belt with moderate pressure in cen-

ter to check belt tension. Belt is correctly tensioned when there is approximately deflection when pushed (see Figure 51).

— If there is more than 1⁄4" deflection when

you check belt tension, repeat the tensioning procedure until it is correct.

Cutterhead Pulley

Approximately

/4" Deflection

Motor Pulley

⁄4"

Tensioning V-Belt

1. DISCONNECT MACHINE FROM POWER!

2. Remove cabinet rear panel and belt guard.

3. Loosen hex nuts on carriage bolts securing

motor (see Figure 50). DO NOT completely remove hex nuts securing carriage bolts.

x 4

Figure 51. Correct belt deflection when properly

tensioned.

Tighten motor mount hex nuts (see Figure

50), and install cabinet rear panel and belt

guard.

Replacing V-Belt

1. DISCONNECT MACHINE FROM POWER!

2. Remove cabinet rear panel and belt guard.

3. Loosen hex nuts on carriage bolts securing

motor (see Figure 50).

Have another person lift motor as you remove

belt and replace it with a new one. Make sure ribs of belt are seated in pulley grooves.

Follow Steps 4–5 in Tensioning Belt proce-

dure to set correct belt tension.

Figure 50. Motor adjustment location.

Press down on motor to keep tension on belt.

Model G0490ZX (Mfd. Since 01/24)

Tighten motor mount hex nuts (see Figure

50), and install cabinet rear panel and belt

guard.

-41-

Aligning Pulleys

Pulley alignment is another important factor in power transmission and belt life. The pulleys should be parallel to each other and in the same plane (coplanar) for optimum performance.

The pulleys can be adjusted by loosening the pulley set screws, aligning the pulleys, and retightening the set screws.

Tools Needed Qty

Hex Wrench 3mm .............................................. 1

Straightedge 4' Phillips Head Screwdriver #2 Wrenches or Sockets 12, 13mm

.................................................. 1

............................ 1

.................1 Ea.

Straightedge

Cutterhead

Touching

Evenly

To align pulleys:

DISCONNECT MACHINE FROM POWER!

2. Remove cabinet rear panel and belt guard.

3. Place straightedge against pulleys to check

their alignment (see Figure 52).

Note: This can also be done visually (without

a straightedge) if you do not have a straightedge available that will fit; however, the most accurate results will come from using a straightedge.

Motor

Figure 52. Example of checking pulley

alignment.

— If they are not aligned, loosen set screws

on cutterhead or motor pulley as needed to align pulleys, then tighten set screws (see Figure 53).

Pulley

Straightedge

x 2

-42-

Figure 53. Example of motor pulley set screw

locations.

Replace cabinet rear panel and belt guard.

Model G0490ZX (Mfd. Since 01/24)

Rotating/Replacing

Indexable Inserts

The Model G0490ZX spiral cutterhead is equipped with 4-sided indexable carbide inserts. Each insert can be removed, rotated, and re-installed to use any of its four cutting edges. If one cutting edge becomes dull or damaged, simply rotate it 90º (see Figure 54) to use a sharp cutting edge.

Figure 54. Rotating indexable carbide inserts.

Cutterhead inserts are extremely sharp. Wear heavy leather gloves to avoid the risk of serious personal injury during the following steps.

To replace or rotate indexable insert:

1. DISCONNECT MACHINE FROM POWER!

Set fence to 90° and move it all the way back.

Remove cutterhead guard, and lower infeed

table as far down as it will go.

Remove belt guard to expose cutterhead

pulley.

Rotate pulley as needed to make inserts

accessible for removal or rotation.

Remove any sawdust from head of carbide

insert Torx screw.

Each insert has a reference dot on one corner. As the insert is rotated, the reference dot location can be used as an indicator of which edges are used and which are new. Replace insert when the reference dot has been used and rotated back to its starting position.

Items Needed

• Heavy Leather Gloves .......................... 1 Pair

• Safety Glasses (per person)........................ 1

Flat Hd Torx Screws

•

T20 M6-1 x 15 ..............................As Needed

Indexable Carbide Inserts

•

14 x 14 x 2mm ..............................As Needed

Torx Bit T-20 1⁄4" Shank ............................... 1

•

• T-Handle Bit Driver 1⁄4" ................................. 1

• Wrench or Socket 10mm ............................. 1

• Hex Wrench 4mm ........................................ 1

• Torque Wrench 0–50 in.-lb. ......................... 1

• Clean Shop Rags .........................As Needed

• Degreaser .....................................As Needed

• Light Machine Oil .........................As Needed

Put on heavy leather gloves to protect fingers

and hands.

Remove Torx screw and indexable insert

(see Figure 55).

Cutterhead

Insert

Torx

Screw

Figure 55.

Example of cutterhead inserts and

Torx screws.

Model G0490ZX (Mfd. Since 01/24)

-43-

9. Clean all dust and dirt off insert and cutterhead

pocket from which insert was removed, and replace insert so a fresh, sharp edge is facing outward.

Checking/Adjusting

Table Parallelism

—If all four insert cutting edges have been

used, replace insert with a new one. Always position reference dot in same position when installing a new insert to aid in rotational sequencing.

Note: Proper cleaning is critical to achiev-

ing a smooth finish. Dirt or dust trapped between insert and cutterhead will slightly raise insert, and make noticeable marks on your workpieces the next time you cut.

Lubricate Torx screw threads with a light

10.

machine oil, wipe excess oil off threads, and torque Torx screw to 48–50 inch pounds.

Note: Excess oil may squeeze between

insert and cutterhead or in screw hole, thereby lifting insert or screw slightly and affecting workpiece finishes.

Install belt guard and raise infeed table.

11.

If the tables are not parallel with the cutterhead or each other, then poor cutting results and kickback can occur.

Needed Qty

Tools

Straightedge 4' .................................................. 1

Hex Wrench 4mm Hammer Center Punch

............................................. As Needed

.............................................. 1

..................................... As Needed

Checking Outfeed Table

1. DISCONNECT MACHINE FROM POWER!

2. Remove cutterhead guard, fence, and rear

cabinet panel.

Loosen outfeed table lock, and loosen jam

nuts and positive stop bolts located on the rear of machine just behind outfeed table (see Figure 56).

Install cutterhead guard back over cutterhead,

12.

making sure that spring tension in guard is properly set so guard springs back over cutterhead when it is pulled back and released, as shown in Checking/Adjusting Cutterhead Guard on Page 39.

Stop Bolts

Figure 56. Outfeed table positive stop bolts.

-44-

Model G0490ZX (Mfd. Since 01/24)

Black Lines Represent Straightedge

Rotate motor pulley so that you can access

cutterhead body with straightedge between insert rows (see Figure 57).

Straightedge

Checking Infeed Table

1. Follow all steps in Checking Outfeed Table

on Page 44 to first make sure that outfeed table is parallel with cutterhead.

Adjust outfeed table height (see Setting

2. Outfeed Table Height on Page 48).

Outfeed Table

Figure 57. Adjusting outfeed table even with

cutterhead body.

Place straightedge on outfeed table so it hangs

over cutterhead, then lower outfeed table until straightedge just touches cutterhead body.

Place straightedge in positions shown in

6. Figure 58. In each position, straightedge

should touch cutterhead and sit flat on outfeed table.

Black Lines Represent Straightedge Positions From Overhead View

Rotate cutterhead so inserts will not inter-

fere, then place straightedge across infeed/ outfeed tables and adjust infeed table even with outfeed table (see Figure 59).

Straightedge

InfeedOutfeed

Figure 59. Infeed and outfeed tables set evenly.

4. Place straightedge in positions shown in Figure 60. In each position, the straightedge

should sit flat against both outfeed table and infeed table.

Positions from Overhead View

Figure 58. Straightedge positions for verifying if

outfeed table is parallel with cutterhead.

— If straightedge touches cutterhead body

and sits flat across outfeed table in each position, then outfeed table is already parallel with cutterhead. Follow Checking Infeed Table instructions on this page.

— If straightedge does not touch cutterhead

Model G0490ZX (Mfd. Since 01/24)

and sit flat on outfeed table in any of the positions, then outfeed table is not parallel with cutterhead. Perform Adjusting Table

Parallelism procedure on Page 46.

Figure 60. Straightedge positions for checking

infeed/outfeed table parallelism.

—If straightedge sits flat against both infeed

and outfeed tables, then tables are parallel. Install cutterhead guard, fence, and rear cabinet panel.

—If straightedge does not sit flat against

both infeed and outfeed tables in any of positions, proceed to Adjusting Table Parallelism on Page 46.

-45-

Adjusting Table Parallelism

For safe and proper cutting results, the tables must be parallel with the cutterhead. Adjusting them to be parallel is a task of precision and patience, and may take up to one hour to complete. Luckily, this is considered a permanent adjustment and should not need to be repeated for the life of the machine.

Due to the complex nature of this task, we recommend that you double check the current table positions to make sure that they really need to be adjusted before starting.

IMPORTANT: The steps below are intended to be performed directly after the steps involved in checking the outfeed table parallelism. Do not continue until you have performed those steps.

To adjust table parallelism:

Place straightedge on outfeed table so it hangs

over cutterhead, and lower outfeed table until straightedge just touches cutterhead body (see Figure 61).

The tables have four eccentric bushings under each corner that allow the tables to be adjusted parallel. These eccentric bushings are locked in place by set screws and adjust when rotated.

The correct order for adjusting the table parallelism is to first adjust the outfeed table parallel with the cutterhead to within 0.010"-0.012", then adjust the infeed table parallel with the outfeed table.

When setting the outfeed table, all measurements must be made from the cutterhead body—NOT the inserts.

Straightedge

Outfeed Table

Figure 61. Adjusting outfeed table even with

cutterhead body.

Remove top set screw from (4) eccentric

bushings under outfeed table, and loosen set screws underneath removed set screws (see Figure 62).

x 4

-46-

Eccentric

Bushing

(1 of 4)

Figure 62. Eccentric bushing and set screw

location.

Model G0490ZX (Mfd. Since 01/24)

Black Lines Represent Straightedge

3. Place straightedge in one of the positions shown in Figure 63, and adjust table by turning eccentric bushings as needed with so that straightedge touches cutterhead while lying flat across outfeed table. Repeat this step with each remaining straightedge position as many times as necessary until outfeed table is parallel with cutterhead to within 0.010"–

0.012".

Note: Setting outfeed table parallel to

cutterhead within 0.010"-0.012" will produce high quality results. Going lower than this number will produce minimal gain.

Straightedge

Outfeed Table

Infeed Table

Figure 65. Infeed and outfeed tables set evenly.

Place straightedge in one of the positions

shown in Figure 64, and adjust eccentric bushings under infeed table so straightedge lies flat against both tables.

Black Lines Represent Straightedge Positions From Overhead View

Figure 63. Straightedge positions for verifying if

outfeed table is parallel with cutterhead.

Repeat Step 3 with each remaining straight-

edge position as many times as necessary until outfeed table is parallel with cutterhead.

Tighten/replace set screws in eccentric bush-

ings on outfeed table.

Remove set screw from each of the (4)

eccentric bushings under infeed table, and loosen set screws underneath those removed set screws.

Positions from Overhead View

Figure 64. Straightedge positions for checking

infeed/outfeed table parallelism.

Repeat Step 8 with each remaining straight-

edge positions as many times as necessary until infeed table is parallel with outfeed table.

Tighten/replace set screws in eccentric bush-

10.

ings on infeed table.

Perform Setting Outfeed Table Height on

11. Page 48.

Rotate cutterhead out of the way and place

straightedge halfway across infeed and outfeed tables, then adjust infeed table even with outfeed table (see Figure 65).

Model G0490ZX (Mfd. Since 01/24)

-47-

Setting Outfeed

Table Height

To help ensure safe operation and the best cutting results, set the outfeed table height level with the inserts when they are at top-dead-center (TDC). If the outfeed table is set too low, the workpiece will be tapered from front to back or there will be snipe (a gouge in the end of the board that is uneven with the rest of the cut). If the outfeed table is set too high, the workpiece will hit the edge of the outfeed table during operation, increasing the chance of kickback.

Tools Needed Qty

Straightedge 4' .................................................. 1

Open-End Wrench 17mm Hex Wrenches 3, 4, 8mm Phillips Head Screwdriver #2

.................................................................. 1

Pliers

.................................. 1

............................ 1

4. Place straightedge on outfeed table so it hangs over cutterhead, then use motor pulley to rotate cutterhead until one insert is at TDC (its highest point during rotation), as shown in Figures 68–69.

Top Dead

Center

Figure 67. Cutterhead insert at TDC.

Straightedge

To set outfeed table height:

DISCONNECT MACHINE FROM POWER!

2. Remove cutterhead guard, fence, and rear

cabinet panel.

Loosen outfeed table lock, then loosen jam

nuts and positive stop bolts located at rear of machine just behind outfeed table (see Figure 66).

Stop Bolts

Outfeed Infeed

Figure 68. Using straightedge to check outfeed

table height.

Use outfeed table adjustment lever to set

outfeed table so insert barely touches straightedge, as shown in Figure 68.

Tighten outfeed table lock so outfeed table

will not move during operation.

Tighten jam nuts and positive stop bolts.

8. Install cutterhead guard, fence, and rear

cabinet panel.

Figure 66. Outfeed table positive stop bolts.

-48-

Model G0490ZX (Mfd. Since 01/24)

Straightedge

Adjusting Infeed

Calibrating Depth

Table Stop Bolts

The infeed table on the Model G0490ZX has positive stop bolts that, when properly set up, allow the operator to quickly adjust the infeed table between finish/final cuts and shaping/heavy cuts.

\We recommend setting the minimum depth of cut

⁄32" and the maximum depth of cut to 1⁄8" for

to most operations.

DO NOT exceed 1⁄8" cut per pass on this machine or the risk of kickback and serious injury will be greatly increased!

Each positive stop bolt controls top or bottom range of table movement (see Figure 69). Jam nuts lock positive stop bolts in position so they will not move during operation.

Scale

The depth scale can be calibrated or "zeroed" to make sure the cutting depth shown on the scale matches the actual cutting depth (per pass).

Tools Needed Qty

Straightedge 4' .................................................. 1

Hex Wrench 2.5mm

To calibrate depth scale:

DISCONNECT MACHINE FROM POWER!

Set outfeed table height (see Setting Outfeed

2. Table Height on Page 48).

Rotate cutterhead until insert is no longer at

TDC, extend straightedge over both tables, then raise infeed table even with outfeed table, as shown in Figure 70.

........................................... 1

InfeedOutfeed

Top Height

Stop Bolt

Bottom Height

Stop Bolt

Figure 69. Positive stop bolts for infeed table.

Tools Needed Qty

Open-End Wrench 17mm .................................. 1

.................................................................. 1

Pliers

Figure 70. Infeed table even with outfeed table.

4. Loosen flat head cap screw on depth scale

pointer, adjust scale pointer to zero, then secure (see Figure 71).

Depth

Scale

Pointer

Model G0490ZX (Mfd. Since 01/24)

Figure 71. Depth scale pointer adjusted to zero.

-49-

Setting Fence Stops

Setting 90° Fence Stop

1. DISCONNECT MACHINE FROM POWER!

The fence stops simplify the task of adjusting the

fence to 45˚, 90˚, and 135˚ (45˚ outward).

Tools Needed Qty

Square 45°, 90° ...........................................1 Ea.

Phillips Head Screwdriver #2 Sliding Bevel Open-End Wrenches 10mm Hex Wrench 4mm

...................................................... 1

.............................................. 1

............................ 1

.............................. 2

Setting 45° Fence Stop

1. DISCONNECT MACHINE FROM POWER!

2. Loosen fence tilt lock knob and tilt fence

approximately 45° onto stop bolt, then place 45° square against fence and table (see

Figure 72).

2. Loosen set screw in plunger lock collar, then

loosen fence tilt lock (see Figure 74).

Using a 90° square, adjust fence to 90° posi-

tion, then tighten set screw in plunger lock collar.

If required, loosen Phillips head screw on

fence tilt scale, adjust fence tilt scale indicator to 0°, then secure (see Figure 74).

Plunger Lock Collar

Fence Tilt Lock

Fence Tilt Scale

Fence Tilt

Scale Indicator

Figure 72. Fence adjusted 45˚.

3. Loosen jam nut on 45° positive stop bolt

shown in Figure 73.

45° Positive

Stop Bolt

Jam Nut

Figure 73. 45° positive stop bolt location.

Figure 74. Adjusting fence to 90˚.

Setting 135° Fence Stop

1. DISCONNECT MACHINE FROM POWER!

2. Loosen fence tilt lock, and position fence

against 135° stop bolt.

Loosen jam nut on 135˚ positive stop bolt

(see Figure 75).

135° Positive

Stop Bolt

Jam Nut

Figure 75. Adjusting fence 135˚.

4. Adjust stop bolt until fence is exactly 45°

while resting on bolt (verify angle with 45° square), then tighten jam nut loosened in Step 3.

-50-

Adjust 135˚ positive stop bolt until fence is

135° while resting on bolt (check angle with a sliding bevel set to 135°), then tighten jam nut loosened in Step 3.

Model G0490ZX (Mfd. Since 01/24)

These pages are current at the time of printing. However, in the spirit of improvement, we may make changes to the electrical systems of future machines. Compare the manufacture date of your machine to the one stated in this manual, and study this section carefully.

If there are differences between your machine and what is shown in this section, call Technical Support at (570) 546-9663 for assistance BEFORE making any changes to the wiring on your machine. An updated wiring diagram may be available.

number and manufacture date of your

machine before calling. This information can be found on the main machine label.

SECTION 8: WIRING

Note: Please gather the serial

Wiring Safety Instructions

SHOCK HAZARD. Working on wiring that is con-

nected to a power source is extremely dangerous. Touching electrified parts will result in personal injury including but not limited to severe burns, electrocution, or death. Disconnect the power from the machine before servicing electrical components!

MODIFICATIONS. Modifying the wiring beyond what is shown in the diagram may lead to unpredictable results, including serious injury or fire. This includes the installation of unapproved aftermarket parts.

WIRE CONNECTIONS. All connections must be tight to prevent wires from loosening during machine operation. Double-check all wires disconnected or connected during any wiring task to ensure tight connections.

CIRCUIT REQUIREMENTS. You MUST follow the requirements at the beginning of this manual when connecting your machine to a power source.

WIRE/COMPONENT DAMAGE. Damaged wires or components increase the risk of serious personal injury, fire, or machine damage. If you notice that any wires or components are damaged while performing a wiring task, replace those wires or components.

MOTOR WIRING. The motor wiring shown in these diagrams is current at the time of printing but may not match your machine. If you find this to be the case, use the wiring diagram inside the motor junction box.

CAPACITORS/INVERTERS. Some capacitors and power inverters store an electrical charge for up to 10 minutes after being disconnected from the power source. To reduce the risk of being shocked, wait at least this long before working on capacitors.

EXPERIENCING DIFFICULTIES. If you are experiencing difficulties understanding the information included in this section, contact our Technical Support at (570) 546-9663.

The photos and diagrams included in this section are best viewed in color. You can view these pages in color at www.grizzly.com.

Model G0490ZX (Mfd. Since 01/24)

-51-

Ground

6-20 Plug

Wiring Diagram

Ground

Hot

220

VAC

Hot

Ground

CB-10

PL-BA9

CB-10

STOP BUTTON

NHD NLB22-F11RI

PL-BA9

CB-01

POWER SWITCH

KEDU HY-18N 20A

START BUTTON

NHD NLB22-F10GI

CONTROL PANEL

L1 N1

L1 L1

1L1 5L3 21NC

3L2

Contactor

NHD C-12D

220V

2T1 6T3

4T2

OL Relay

NHD NTH-32

2T1 6T34T2

96 95

22NC

Motor

Junction Box

Ground

S Capacitor

CD60 300μF

250VAC

R Capacitor

CBB60 70μF

450VAC

Ground

MAG SWITCH 220V

NHD MS-12D1I7N172P

-52-

READ ELECTRICAL SAFETY

ON PAGE 51!

MOTOR 220V

Model G0490ZX (Mfd. Since 01/24)

Electrical Components

Figure 76. Control panel wiring overview.

Model G0490ZX (Mfd. Since 01/24)

READ ELECTRICAL SAFETY

ON PAGE 51!

-53-

Electrical Components (Cont.)

Figure 77. Cabinet electrical overview.

Figure 79. Motor junction box.

Figure 78. Magnetic switch assembly.

-54-

READ ELECTRICAL SAFETY

ON PAGE 51!

Model G0490ZX (Mfd. Since 01/24)

We do our best to stock replacement parts when possible, but we cannot guarantee that all parts shown are available for purchase. Call (800) 523-4777 or visit www.grizzly.com/parts to check for availability.

139

SECTION 9: PARTS

Main

109

108

107

104

106

105

103

100

102

126 128

130

134

119

120

140

142

141

138

143

65 66

136

137

144

127

129

117

113

114

101

110

118

112

115

70 71

111

116

135

132

131

133

Model G0490ZX (Mfd. Since 01/24)

BUY PARTS ONLI NE AT GRIZZLY.COM!

Scan QR code to visit our Parts Store.

-55-

Main Parts List

REF P ART # DES CRIPTI ON REF PART # DES CRIPTI ON

1 P0490ZX001 BUS HI NG 55 P0490ZX055 LOCK NUT M12-1.75 2 P0490ZX002 LEVER HANDLE M10-1.5 X 80, 66L 56 P0490ZX056 ADJUSTABLE BLOCK 4 P0490ZX004 ECCE NTRI C S HAFT 57 P0490ZX057 PIVOT BRACKET 5 P0490ZX005 SET SCREW M6-1 X 16 58 P0490ZX058 LEVER HANDLE M12-1.75 X 25, 329L 6 P0490ZX006 SET SCREW M8-1.25 X 12 60 P0490ZX060 CAP SCREW M8-1.25 X 40 7 P0490ZX007 FENCE CARRI AGE 61 P0490ZX061 CLAMP PLATE 8 P0490ZX008 HEX NUT M6-1 62 P0490ZX062 CAP SCREW M8-1.25 X 80 9 P0490ZX009 HEX BOLT M6-1 X 25 63 P0490ZX063 G UARD CLA MP 10 P0490ZX010 SHAFT W/2 HOLES 64 P0490ZX064 CUTTERHEAD G UARD 11 P0490ZX011 CAP SCREW M8-1.25 X 30 65 P0490ZX065 TORSI ON S PRI NG 12 P0490ZX012 COLLAR 66 P0490ZX066 ROLL PIN 3 X 16 13 P0490ZX013 HEX NUT M8-1 . 2 5 67 P0490ZX067 SPRING RETAINER 14 P0490ZX014 FLAT WASHE R 8MM 68 P0490ZX068 MEDI UM A DJ US TMENT SCRE W M10- 1. 5 X 5 0 15 P0490ZX015 ECCENTRI C S HAFT 69 P0490ZX069 HEX NUT M1 0-1 . 5 16 P0490ZX016 FENCE GI B 70 P0490ZX070 SET SCREW M6-1 X 10 CONE-PT 17 P0490ZX017 CAP SCREW M5-.8 X 16 71 P0490ZX071 SET SCREW M6-1 X 10 18 P0490ZX018 FENCE SUPPPORT 72 P0490ZX072 MEDI UM ADJ USTMENT S CREW M10 -1. 5 X 110 19 P0490ZX019 FLAT WASHER 10MM 73 P0490ZX073 EXTENSION SPRING 3.8 X 21. 3 X 70.6 20 P0490ZX020 CAP SCREW M10-1.5 X 30 74 P0490ZX074 SLOTTED PIN W/HOLE 21 P0490ZX021 HEX NUT M12-1.75 75 P0490ZX075 TABLE BASE 22 P0490ZX022 FLAT WASHER 14 X 38 X 5MM 76 P0490ZX076 CHIP BREAKER 23 P0490ZX023 INDEX PIN KNOB 77 P0490ZX077 FL AT WAS HER 6MM 24 P0490ZX024 ROLL PIN 3 X 30 78 P0490ZX078 HEX BOLT M6-1 X 12 25 P0490ZX025 COMPRESSION SPRING 1 X 10 X 24 79 P0490ZX079 ADJUSTABLE HANDLE M8-1.25 X 30, 106L 26 P0490ZX026 INDEX P I N S HAFT 80 P0490ZX080 FLAT WASHER 9 X 30 X 5MM 27 P0490ZX027 SWIVEL 81 P0490ZX081 ECCENTRI C BUSHI NG 28 P0490ZX028 HEX BOLT M6-1 X 25 82 P0490ZX082 TABLE SHAFT 20 X 282MM 29 P0490ZX029 HEX NUT M6-1 83 P0490ZX083 SET SCREW M8-1.25 X 10 30 P0490ZX030 SET SCREW M8-1.25 X 12 84 P0490ZX084 TABLE SHAFT 20 X 284MM 31 P0490ZX031 LOCK COLLAR 85 P0490ZX085 POINTER 32 P0490ZX032 SET SCREW M8-1.25 X 12 86 P0490ZX086 FL AT HD SCR M4 -. 7 X 1 0 33 P0490ZX033 LOCK COLLAR 87 P0490ZX087 ROLL PIN 3 X 10 34 P0490ZX034 CLAMP 88 P0490ZX088 HEIGHT SCALE 35 P0490ZX035 THREADED CLA MP 89 P0490ZX089 RIVET 2 X 4 NAMEPLATE, STEEL 36 P0490ZX036 PHLP HD SCR M6-1 X 16 90 P0490ZX090 MEDI UM A DJ US TMENT SCRE W M10- 1. 5 X 9 0 37 P0490ZX037 FLAT WASHE R 6MM 91 P0490ZX091 HEX BOLT M6-1 X 25 38 P0490ZX038 POINTER 92 P0490ZX092 LOCK WASHER 6MM 39 P0490ZX039 FLAT WASHER 6.5 X 16 X 3 93 P0490ZX093 BUMPER 40 P0490ZX040 ADJUSTABLE HANDLE M10-1.5 X 40, 111L 94 P0490ZX094 SLOTTED PIN W/HOLE M10-1.5 X 40 41 P0490ZX041 FLAT WASHER 10MM 95 P0490ZX095 OUTFEED TABLE 42 P0490ZX042 LOCK WASHER 10MM 96 P0490ZX096 OUTFEED TABLE LIP 43 P0490ZX043 CAP SCREW M10-1.5 X 25 97 P0490ZX097 FLAT WA SHER 6 MM 44 P0490ZX044 FLANGE BOLT M6-1 X 12 98 P0490ZX098 CAP SCREW M6-1 X 20 45 P0490ZX045 CONTROL PANEL BOX 99 P0490ZX099 REAR BEARING PILLOW BLOCK 46 P0490ZX046 CONTROL PANEL 100 P0490ZX100 BALL BEARING 6005-2RS 47 P0490ZX047 PHLP HD SCR M4-.7 X 8 101 P0490ZX101 SPI RA L CUTTERHE AD 8" 48 P0490ZX048 CONTROL PANEL PEDESTAL 102 P0490ZX102 KEY 6 X 6 X 32 49 P0490ZX049 INFEED TABLE 103 P0490ZX103 I NT RE TAI NI NG RI NG 47MM 50 P0490ZX050 TABLE SHAFT 20 X 202MM 104 P0490ZX104 FRONT BEARING PILLOW BLOCK 51 P0490ZX051 RABBETING TABLE 105 P0490ZX105 LOCK WASHER 8MM 52 P0490ZX052 CAP SCREW M6-1 X 20 106 P0490ZX106 CAP SCREW M8-1.25 X 80 53 P0490ZX053 CAP SCREW M6-1 X 12 107 P0490ZX107 CUTTERHEA D PULL EY 54 P0490ZX054 CHIP DEFL ECTOR

-56-

BUY PARTS ONLI NE AT GRIZZLY.COM!

Scan QR code to visit our Parts Store.

Model G0490ZX (Mfd. Since 01/24)

Main Parts List (Cont.)

REF PART # DESCRIP TION REF PART # DE S CRIPTION

108 P0490ZX108 CUTTERHEAD PULLEY WASHER 129 P0490ZX129 HE X WRENCH 6 MM 109 P0490ZX109 HEX BOLT M8-1.25 X 25 130 P0490ZX130 HE X WRENCH 8 MM 110 P0490ZX110 PHLP HD SCR M6-1 X 10 131 P0490ZX131 WRE NCH 8 X 1 0MM OP EN-ENDS 111 P0490ZX111 FLAT WAS HER 6MM 132 P0490ZX132 WRENCH 12 X 14MM OPEN-ENDS 112 P0490ZX112 TILT SCALE 133 P0490ZX133 PUSH BLOCK 113 P0490ZX113 KNOB M10-1.5, D32, BALL 134 P0490ZX134 DRI VE R BI T TORX T20 114 P0490ZX114 STUD-UDE M10-1.5 X 130, 15, 18 135 P0490ZX135 T- HANDLE TORX T2 0 115 P0490ZX115 SCALE 136 P0490ZX136 STOP BUTTON NHD AC220V 23MM RED 116 P0490ZX116 RIVET 2 X 4 NAMEPLATE, STEEL 137 P0490ZX137 S TART BUTTO N NHD AC22 0V 23 MM GREE N 117 P0490ZX117 FENCE 138 P0490ZX138 P ADDLE SWI TCH KEDU HY1 8 118 P0490ZX118 BALL BEARING 6004-2RS 139 P0490ZX139 STRAIN RELIEF TYPE 3 M20-2.5 X 1.5 119 P0490ZX119 INDEXABLE INSERT 14 X 14 X 2 140 P0490ZX140 CARRIAGE BOLT M4-.7 X 20 120 P0490ZX120 FLAT HD TORX T20 M6-1 X 12 141 P0490ZX141 GRO UND PLA TE 126 P0490ZX126 HEX WRENCH 2 . 5MM 142 P0490ZX142 POWER CORD 12G 3W 98" 6-20P 127 P0490ZX127 HEX WRENCH 4 MM 143 P0490ZX143 MOTOR CORD 12G 3W 31" 128 P0490ZX128 HEX WRENCH 5 MM 144 P0490ZX144 CONTROL PANEL CORD 18G 5W 94"

Model G0490ZX (Mfd. Since 01/24)

BUY PARTS ONLI NE AT GRIZZLY.COM!

Scan QR code to visit our Parts Store.

-57-

200

201

202

Cabinet

203

204

205

230

238-1

238-2

238-14

238-3

238-4

238-5

238-13

238-7

238-6

238-12

238-11

238-8

238-10

238-9

228

228-1

228-4

208

228-3

228-10

227

226

225

209

228-6

224

210

228-7

228-8

206

207

211

213

212

214

215

223

222

229

238

219

216

220

237

236

218

237-3

237-2

234

235

221

217

237-4

237-1

233

231

232

-58-

228-2

228-5

228-11

BUY PARTS ONLI NE AT GRIZZLY.COM!

Scan QR code to visit our Parts Store.

228-12

228-11

Model G0490ZX (Mfd. Since 01/24)

Cabinet Parts List

REF PART # DES CRIPTI ON REF PART # DES CRIPTI ON

200 P0490ZX200 PHLP HD SCR M5-.8 X 16 228-7 P0490ZX228-7 BALL BEARING 6023-2RS REAR 201 P0490ZX201 FLAT WASHER 5MM 228-8 P0490ZX228-8 CENTRIFUGAL SWITCH CONTACT W/PLATE 202 P0490ZX202 REAR PANEL 228-10 P0490ZX228-10 TERMINAL BAR 6P 203 P0490ZX203 FLANGE SCREW M6-1 X 12 228-11 P0490ZX228-11 TAP SCREW M4 X 16 204 P0490ZX204 BELT GUARD 228-12 P0490ZX228-12 JUNCTION BOX COVER 205 P0490ZX205 CABINET 311V2 P0490ZX311V2 MACHINE ID LABEL V2.07.24 206 P0490ZX206 FLAT WASHER 6MM 229 P0490ZX229 CAP SCREW M8-1.25 X 25 207 P0490ZX207 HEX NUT M6-1 230 P0490ZX230 FLAT WASHER 8MM 208 P0490ZX208 PHLP HD SCR M5-.8 X 16 231 P0490ZX231 HEX NUT M5-.8 209 P0490ZX209 FLAT WASHER 5MM 232 P0490ZX232 SWITCH MOUNTING PLATE 210 P0490ZX210 DUST CHUTE 4" 233 P0490ZX233 FLAT WASHER 6MM 211 P0490ZX211 HEX NUT M8-1.25 234 P0490ZX234 PHLP HD SCR M6-1 X 10 212 P0490ZX212 FLAT WASHER 8MM 235 P0490ZX235 FLAT WASHER 5MM 213 P0490ZX213 SLEEVE 236 P0490ZX236 PHLP HD SCR M5-.8 X 12 214 P0490ZX214 WHEEL 13 X 76 X 30MM 237 P0490ZX237 MAG SWITCH NHD MS-12D 3HP 220V 215 P0490ZX215 HEX BOLT M8-1.25 X 65 237-1 P0490ZX237-1 FRONT MAG SWITCH COVER 216 P0490ZX216 MOTOR BRACKET 237-2 P0490ZX237-2 OL RELAY NDH NTH-32 14-17A 217 P0490ZX217 FLANGE NUT M8-1.25 237-3 P0490ZX237-3 REAR MAG SWITCH COVER 218 P0490ZX218 CARRIAGE BOLT M8-1.25 X 25 237-4 P0490ZX237-4 CONTACTOR NHD C-12D 220V 219 P0490ZX219 CARRIAGE BOLT M8-1.25 X 30 238 P0490ZX238 PEDAL ASSEMBLY 220 P0490ZX220 FLAT WASHER 8MM 238-1 P0490ZX238-1 HEX NUT M8-1.25 221 P0490ZX221 HEX NUT M8-1.25 238-2 P0490ZX238-2 FLAT WASHER 8MM 222 P0490ZX222 ADJUSTABLE FOOT M10-1.5 X 45 238-3 P0490ZX238-3 FLAT WASHER 8MM 223 P0490ZX223 HEX NUT M10-1.5 238-4 P0490ZX238-4 HEX NUT M10-1.5 224 P0490ZX224 POLY V-BELT 8PK-1172 238-5 P0490ZX238-5 FLAT WASHER 10MM 225 P0490ZX225 MOTOR PULLEY 238-6 P0490ZX238-6 PEDAL BRACKET 226 P0490ZX226 SET SCREW M6-1 X 6 238-7 P0490ZX238-7 TROLLEY BRACKET 227 P0490ZX227 KEY 5 X 5 X 25 238-8 P0490ZX238-8 HEX BOLT M8-1.25 X 100 228 P0490ZX228 MOTOR 3HP 220V 1-PH 238-9 P0490ZX238-9 EXT RETAINING RING 13MM 228-1 P0490ZX228-1 MOTOR FAN COVER 238-10 P0490ZX238-10 FLAT WASHER 14 X 30 X 3 228-2 P0490ZX228-2 MOTOR FAN 238-11 P0490ZX238-11 CAPTIVE PIN 228-3 P0490ZX228-3 S CAPACITOR 300M 250V 2" X 3-9/16" 238-12 P0490ZX238-12 HEX BOLT M10-1.5 X 55 228-4 P0490ZX228-4 R CAPACTOR 70M 450V 2" X 3-11/16" 238-13 P0490ZX238-13 PEDAL 228-5 P0490ZX228-5 JUNCTION BOX 238-14 P0490ZX238-14 HEX BOLT M8-1.25 X 50 228-6 P0490ZX228-6 BALL BEARING 6025-2RS FRONT

Model G0490ZX (Mfd. Since 01/24)

BUY PARTS ONLI NE AT GRIZZLY.COM!

Scan QR code to visit our Parts Store.

-59-

Labels & Cosmetics

REF P ART # DES CRIPTION RE F P ART # DES CRIPTION

306 P0490ZX306 TOUCH UP PAINT, GRIZZLY BEIGE

302

301

311V2

310

303

304

305

306

307

308

309

301 P0490ZX301 CUTTE RHEAD G UARD LABEL 307 P0490ZX307 GRIZZLY NAMEPLATE - SMALL 302 P0490ZX302 FENCE/CUTTERHEAD LABEL 308 P0490ZX308 MODEL NUMBER LABEL 303 P0490ZX303 CONTROL PANEL FACE LABEL 309 P0490ZX309 GRIZZLY.COM LABEL 304 P0490ZX304 ELECTRICITY LABEL 310 P0490ZX310 TOUCH UP PAINT, GRIZZLY GREEN 305 P0490ZX305 COMBO WARNING LABEL 311V2 P0490ZX311V2 MACHINE ID LABEL V2.07.24

Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes off or becomes unreadable, the owner of this machine MUST replace it in the original location before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com.

-60-

BUY PARTS ONLI NE AT GRIZZLY.COM!

Scan QR code to visit our Parts Store.

Model G0490ZX (Mfd. Since 01/24)

Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse,

negligence, accidents, repairs or alterations or lack of maintenance. This is Grizzly’s sole written warranty

and any and all warranties that may be implied by law, including any merchantability or fitness, for any particular purpose, are hereby limited to the duration of this written warranty. We do not warrant or represent that the merchandise complies with the provisions of any law or acts unless the manufacturer so warrants.

In no event shall Grizzly’s liability under this warranty exceed the purchase price paid for the product and

any legal actions brought against Grizzly shall be tried in the State of Washington, County of Whatcom.

We shall in no event be liable for death, injuries to persons or property or for incidental, contingent, special, or consequential damages arising from the use of our products.

The manufacturers reserve the right to change specifications at any time because they constantly strive to achieve better quality equipment. We make every effort to ensure that our products meet high quality and durability standards and we hope you never need to use this warranty.

In the event you need to use this warranty, contact us by mail or phone and give us all the details. We will

then issue you a “Return Number,’’ which must be clearly posted on the outside as well as the inside of

the carton. We will not accept any item back without this number. Proof of purchase must accompany the merchandise.

Please feel free to write or call us if you have any questions about the machine or the manual.

Thank you again for your business and continued support. We hope to serve you again soon.

For further information about the

scan the QR

code below

WARRANTY & RETURNS

to be automatically directed to our warranty page.

warranty, visit https://www.grizzly.com/forms/warranty or

WARRANTY

Grizzly G0490ZX User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

INTRODUCTION

Contact Info

Manual Accuracy

Identification

SECTION 1: SAFETY

Safety Instructions for Machinery

Additional Safety for Jointers

SECTION 2: POWER SUPPLY

SECTION 3: SETUP

Needed for Setup

Unpacking

Inventory

Hardware Recognition Chart

Cleanup

Site Considerations

Assembly

Dust Collection

Test Run

SECTION 4: OPERATIONS

Operation Overview

Setting Depth of Cut

Squaring Stock

Surface Planing

Edge Jointing

Bevel Cutting

Rabbet Cutting

SECTION 5: ACCESSORIES

SECTION 6: MAINTENANCE

Schedule

Lubrication

SECTION 7: SERVICE

Troubleshooting

Aligning Pulleys

Setting Fence Stops

SECTION 8: WIRING

Wiring Safety Instructions

Wiring Diagram

Electrical Components

SECTION 9: PARTS

Main

Cabinet

Labels & Cosmetics

WARRANTY & RETURNS
