Gritomatic HAPSTONE-V5-BBS Manual Manual

1. TECHNICAL SPECIFICATIONS AND FEATURES

Dimensions and weight:

Knife sharpener dimensions (ready to work) 64х16х21 cm (25”x 6 ¼”x 8 ¼”)
Shipping dimensions 38x28x7 cm (15”x 11”x 2 ¾”)
Horizontal shaft 64 cm (25”)
Knife sharpener weight 3.2 kg (7 lbs)

Features of the HAPSTONE PRO knife sharpener:

All parts are made of metal and covered with powder coating which provides

excellent coverage and excellent resistance to physical damage.

The universal stone holder is made of aluminum, which is suitable for the installation

of sharpening stones ranging from 10 to 20 cm (from 4” to 8”) in length. The stone
holder is designed so that forms with bevels at 45 degrees and 90 degrees can be
inserted.

Angle indicator marks are on the pivot rod (at 15, 18, 20, 25 and 30 degrees).
The set includes a thickness compensator which allows the use of sharpening stones

of different thickness while maintaining the chosen sharpening angle.

The blade table is covered with rubber.
The neodymium magnet is installed to facilitate knife fastening and the sharpening

process.

The knife sharpener is supplied with an aluminum guide which can be used as a

holding strap to help fasten knives more securely.

HAPSTONE PRO is vibration resistant due to rubber tips on the supporting legs.
Bundles and optional accessories are available.

2. STANDARD CONFIGURATION

HAPSTONE PRO knife sharpener 1 pc.
Black marker 1 pc.
Thickness compensator 1 pc.
Hex key 1 pc.
Wrench 1 pc.
Brunox oil 10 ml (0.3 oz) bottle 1 pc.
Manual 1 pc.
Carton box 1 pc.
