GP
is
Grey Pneumatic (GP) through our
industrial, assembl
with heavy duty, high quality impact and specialty sockets. We carry a complete
line of Impact Socket sets and individuals from 1/4" drive thru 2-1/2" and #5 spline
drive with hex sizes up to 8". We also offer a large selection of star impact drivers,
impact hex drivers, triple square drivers, stripped nut/wheel lock removers, torque
limiting extensions plus Impact chisels and accessories.
GP sockets and tools using the highest quality chrome-molybdenum alloy steel and
state-of-the-art manufacturing processes and equipment. Thorough and exact heat
treatment, as well as rigid quality control, ensures the correct balance of strength
and durability to deliver outstanding performance at the most competitive cost.
GP Tools are available through Automotive and Industrial warehouse distributors,
tool stores, mobile tool truck dealers, tire equipment and supply warehouses and
other sources that service these markets.
GP offers Fast and Reliable service to all of our distributors and their customers.
, mining, maintenance, construction, and energy industries
y
distributors supplies the world’s automotive,
GP Tools carry a
Lifetime Warranty.
All GP Impact Sockets feature
the GP “High Torque” Drive
Benefits are:
Increased Strength
from the thinnest part of the socket wall toward the
thicker section, resulting in increased strength.
Increased Torque
to be applied than on standard hex impact sockets.
Easier Access to Tight Areas
to reduce the socket wall thickness, increasing access to tight areas.
Reduced Wear
broader contact area, reducing the chance of rounding off fasteners.
- Transfers the pressure
GP " High Torque"
drive offers many
- Allows up to 20% more torque
- The shift in pressure allows us
- Our impact sockets grip the fastener across a
All GP Sockets feature
extra-large size markings
for quick identification.
benefits.
Page 3
1/4” Surface Drive Impact Socket Sets
Fractional / SAE Sizes Metric Sizes
1/4” Surface Drive Impact Socket Sets
Contents
1/4” Drive Impact Sockets
3/8” Drive Impact Sockets
1/2” Drive Impact Sockets
3/4” Drive Impact Sockets
1” Drive Impact Sockets
1-1/2” Drive Impact Sockets
2-1/2” Drive Impact Sockets
#5 Spline Impact Sockets
13
41
72
92
118
127
132
2
3/8" 1/4"
1/2"
1" 3/4"Star DUO
1-1/2"
2-1/2"
#5
Spline
1/4” through 1/2” Drive
Hex Drivers 1/4” through 1-1/2” Drive
Star Drivers 1/4” through 1/2” Drive
Triple Square Drivers 3/8” through 1/2” Drive
Torque Limiting Impact Sockets and Extensions
Special Application
Wheel Service Items
Impact Socket Displays
136
145
160
169
175
179
181
186
HEX
Triple
Square
Torque
Limiting
Specials
Wheel
Service
Displays
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Impact Chisels for Pneumatic Hammers
Key:
193
Chisels
2
1
Page 4
1/4” Surface Drive Impact Socket Sets
1/4” Drive Impact Socket Set
No. 9771
1/4
” Drive Master Set
This set contains every socket in our 1/4” surface drive line, plus 3 extensions, universal joint
and 1/4” to 3/8” adapter in a molded storage case with handle. Great for use on impact
wrenches, air ratchets as well as hand ratchets.
71 piece set contents:
10 Pieces Standard Length:
3/16”, 7/32”, 1/4”, 9/32”, 5/16”,11/32”, 3/8”, 7/16”,
1/2”, 9/16”
10 Pieces Deep Length:
3/16”, 7/32”, 1/4”, 9/32”, 5/16”, 11/32”, 3/8”, 7/16”,
1/2”, 9/16”
14 Pieces Metric Standard Length:
4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm, 9mm,
10mm, 11mm, 12mm, 13mm, 14mm, 15mm
14 Pieces Metric Deep Length:
4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm, 9mm,
10mm, 11mm, 12mm, 13mm, 14mm, 15mm
6 Pieces Standard Universal:
1/4”, 5/16”, 3/8”, 7/16”, 1/2”, 9/16”
12 Pieces Metric Standard Universal:
5mm, 5.5mm, 6mm, 7mm, 8mm, 9mm, 10mm, 11mm,
12mm, 13mm, 14mm, 15mm
1 Piece Each:
2”, 4”, & 6” Extensions
1/4” Universal Joint
1/4” F. x 3/8” M. Adapter
Molded Storage Case
Always wear safety goggles when using Impact Tools.
Warning:
1
2
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
Page 5
1/4” Surface Drive Impact Socket Sets
1/4” Surface Drive Impact Socket Sets
1/4” Drive Impact Socket Sets
No. 9748
1/4
” Drive Standard & Deep Length Master Set
This set contains all standard and deep length sockets in both fractional and metric sizes.
Packaged in a blow mold case for organized storage.
48 piece set contents:
10 Pieces Standard Length:
3/16”, 7/32”, 1/4”, 9/32”, 5/16”,11/32”, 3/8”, 7/16”,
1/2”, 9/16”
10 Pieces Deep Length:
3/16”, 7/32”, 1/4”, 9/32”, 5/16”, 11/32”, 3/8”, 7/16”,
1/2”, 9/16”
14 Pieces Metric Standard Length:
4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm, 9mm,
10mm, 11mm, 12mm, 13mm, 14mm, 15mm
14 Pieces Metric Deep Length:
4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm, 9mm,
10mm, 11mm, 12mm, 13mm, 14mm, 15mm
Molded Storage Case
No. 9728M
1/4
” Drive Standard & Deep Length Metric Master Set
28 piece set contents:
14 Pieces Metric Standard Length:
4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm, 9mm,
10mm, 11mm, 12mm, 13mm, 14mm, 15mm
14 Pieces Metric Deep Length:
4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm, 9mm,
10mm, 11mm, 12mm, 13mm, 14mm, 15mm
Molded Storage Case
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
3
Page 6
1/4” Surface Drive Impact Socket Sets
1/4” Drive Impact Socket Sets
No. 9710
No. 9710D
1/4
1/4
” Drive Standard Length Fractional Set
10 piece set contents:
906RS ........... 3/16” 912RS ............ 3/8”
907RS ........... 7/32” 914RS ........... 7/16”
908RS ............ 1/4” 916RS ............ 1/2”
909RS ........... 9/32” 918RS ........... 9/16”
910RS ........... 5/16” Molded Storage Case
911RS .......... 11/32”
” Drive Deep Length Fractional Set
10 piece set contents:
906DS ........... 3/16” 912DS ............ 3/8”
907DS ........... 7/32” 914DS ........... 7/16”
908DS ............ 1/4” 916DS ............ 1/2”
909DS ........... 9/32” 918DS ........... 9/16”
910DS ........... 5/16” Molded Storage Case
911DS .......... 11/32”
No. 9714M
No. 9714MD
1/4
1/4
” Drive Standard Length Metric Set
” Drive Deep Length Metric Set
14 piece set contents:
904MS ...........4mm 910MS ...........10mm
945MS .........4.5mm
905MS ...........5mm 912MS ...........12mm
955MS .........5.5mm 913MS ...........13mm
906MS ...........6mm 914MS ...........14mm
907MS ...........7mm 915MS ...........15mm
908MS ...........8mm Molded Storage Case
909MS ...........9mm
911MS ...........11mm
14 piece set contents:
904MDS ..........4mm 910MDS .........10mm
945MDS ........4.5mm 911MDS .........11mm
905MDS ..........5mm 912MDS .........12mm
955MDS ........5.5mm 913MDS .........13mm
906MDS ..........6mm 914MDS .........14mm
907MDS ..........7mm 915MDS .........15mm
908MDS ..........8mm Molded Storage Case
909MDS ..........9mm
Always wear safety goggles when using Impact Tools.
Warning:
1
4
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
Page 7
1/4” Drive Universal & Magnetic Impact Socket Sets
1/4” Surface Drive Impact Socket Sets
1/4” Surface Drive Impact Socket Sets
No. 9706U
No. 9712UM
1/4
1/4
” Drive Standard Length Fractional Universal Set
6 piece set contents:
908US ............ 1/4” 916US ............1/2”
910US
912US ............ 3/8” Molded Storage Case
914US ........... 7/16”
” Drive Standard Length Metric Universal Set
12 piece set contents:
905UMS ..........5mm 911UMS .........11mm
955UMS ........5.5mm 912UMS .........12mm
906UMS ..........6mm 913UMS .........13mm
907UMS ..........7mm 914UMS .........14mm
908UMS ..........8mm 915UMS .........15mm
909UMS ..........9mm Molded Storage Case
910UMS .........10mm
........... 5/16” 918US ...........9/16”
No. 9723G
1/4
” Drive Standard Length Fractional & Metric Magnetic Set
This set contains standard length, fractional and metric sizes along with an extension and
universal joint packaged in a molded storage case. The powerful magnets hold any fastener
securely. Great for use in impact or non-impact applications.
23 piece set contents:
906RG ........... 3/16” 905MG ...........5mm
907RG ........... 7/32” 955MG .........5.5mm
908RG ............ 1/4” 906MG ...........6mm
909RG ........... 9/32” 907MG ...........7mm
910RG ........... 5/16” 908MG ...........8mm
911RG .......... 11/32” 909MG ...........9mm
912RG ............ 3/8” 910MG ..........10mm
914RG ........... 7/16” 911MG ..........11mm
916RG ............ 1/2” 912MG ..........12mm
Molded Storage Case 913MG ..........13mm
914MG ..........14mm
915MG ..........15mm
942E .......2” Extension
929UJ .......1/4” x 1/4”
Universal Joint
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
5
Page 8
1/4” Surface Drive Impact Socket Sets
1/4” Drive Magnetic Impact Socket Sets
No. 9709G
No. 9712MG
1/4” Drive Standard Length Fractional Magnetic Set
1/4” Drive Standard Length Metric Magnetic Set
9 piece set contents:
906RG ........... 3/16” 911RG .......... 11/32”
907RG ........... 7/32” 912RG ............ 3/8”
908RG ............ 1/4” 914RG ........... 7/16”
909RG ........... 9/32” 916RG ............ 1/2”
910RG ........... 5/16” on a Metal Clip Rail
12 piece set contents:
905MG ...........5mm 910MG ..........10mm
955MG .........5.5mm 911MG ..........11mm
906MG ...........6mm
907MG ...........7mm 913MG ..........13mm
908MG ...........8mm 914MG ..........14mm
909MG 9mm 915MG ..........15mm
912MG ..........12mm
Molded Storage Case
No. 9709DG
No. 9712MDG
1/4” Drive Deep Length Fractional Magnetic Set
These Magnetic sockets feature a spring loaded magnet that retracts into the socket for
extended bolt applications.
1/4” Drive Deep Length Metric Magnetic Set
These Magnetic sockets feature a spring loaded magnet that retracts into the socket for
extended bolt applications.
9 piece set contents:
906DG ........... 3/16” 911DG .......... 11/32”
907DG ........... 7/32” 912DG ............ 3/8”
908DG ............ 1/4” 914DG ........... 7/16”
909DG ........... 9/32” 916DG ............ 1/2”
910DG ........... 5/16” on a Metal Clip Rail
12 piece set contents:
905MDG ..........5mm 910MDG .........10mm
955MDG ........5.5mm 911MDG .........11mm
906MDG ..........6mm 912MDG .........12mm
907MDG ..........7mm 913MDG .........13mm
908MDG ..........8mm 914MDG .........14mm
909MDG ..........9mm 915MDG .........15mm
Molded Storage Case
Always wear safety goggles when using Impact Tools.
Warning:
1
6
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
Page 9
1/4” Drive Standard Length Impact Sockets
Surface Drive Impact Sockets are specially designed with a hex opening that allows for quick engagement of a fastener. Ideal for
assembly operations.
1/4
” Drive - Standard Length - Fractional Sizes
1/4” Surface Drive Impact Socket Sets
1/4” Surface Drive Impact Socket Sets
Item Hex
Dimensions (Inches)
Number Size Shape A B C D E
906RS
907RS
908RS
909RS
910RS
911RS
912RS
914RS
916RS
918RS
3/16” l .51 .33 .55 .24 .91
7/32” l .51 .37 .55 .24 .91
1/4” l .51 .41 .55 .28 .91
9/32” l .51 .44 .55 .28 .91
5/16” l .51 .49 .55 .35 .91
11/32” ll .51 .54 .55 .35 .91
3/8” ll .51 .59 .55 .35 .91
7/16” ll .51 .64 .55 .35 .91
1/2” ll .51 .74 .55 .35 .91
9/16” ll .51 .79 .55 .35 .91
Standard Length - Metric Sizes
Length
E
Warning:
Warning:
SHAPE I
Socket End
B
Hex
Depth
D
A
Drive End
Bolt Clearance
Depth
C
SHAPE II
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
Item Hex
Dimensions (Millimeters)
Number Size Shape A B C D E
904MS
945MS
905MS
955MS
906MS
907MS
908MS
909MS
910MS
911MS
912MS
913MS
914MS
915MS
4mm l 13 7.6 14 4 23
4.5mm l 13 8.2 14 6 23
5mm l 13 8.8 14 6 23
5.5mm l 13 9.5 14 6 23
6mm l 13 10.0 14 7 23
7mm l 13 11.3 14 7 23
8mm l 13 12.5 14 9 23
9mm ll 13 13.8 14 9 23
10mm ll 13 15.0 14 9 23
11mm ll 13 16.3 14 9 23
12mm ll 13 17.0 14 9 23
13mm ll 13 18.8 14 9 23
14mm ll 13 20.0 14 9 23
15mm ll 13 21.0 14 9 23
2
7
Page 10
1/4” Surface Drive Impact Socket Sets
e
1/4” Drive Deep Length Impact Sockets
Surface Drive Impact Sockets are specially designed with a hex opening that allows for quick engagement of a fastener. Ideal for
assembly operations.
1/4
” Drive - Deep Length - Fractional Sizes
916DS
Item Hex
Number Size Shape A B C D E
906DS
907DS
908DS
909DS
910DS
911DS
912DS
914DS
916DS
918DS
3/16” l .51 .34 1.61 .24 1.97
7/32” l .51 .37 1.61 .24 1.97
1/4” l .51 .41 1.61 .28 1.97
9/32” l .51 .44 1.61 .28 1.97
5/16” l .51 .49 1.61 .35 1.97
11/32” ll .51 .54 1.61 .35 1.97
3/8” ll .51 .59 1.61 .35 1.97
7/16” ll .51 .64 1.61 .35 1.97
1/2” ll .51 .74 1.61 .35 1.97
9/16” ll .51 .79 1.61 .35 1.97
Dimensions (Inches)
Deep Length - Metric Sizes
Item Hex
Dimensions (Millimeters)
Number Size Shape A B C D E
Depth
Length
E
Hex
D
SHAPE I
Socket End
B
A
Drive End
Bolt Clearanc
Depth
C
904MDS
945MDS
905MDS
955MDS
906MDS
907MDS
908MDS
909MDS
910MDS
911MDS
912MDS
913MDS
914MDS
915MDS
4mm l 13 7.6 41 4 50
4.5mm l 13 8.2 41 6 50
5mm l 13 8.8 41 6 50
5.5mm l 13 9.5 41 6 50
6mm l 13 10.0 41 7 50
7mm l 13 11.3 41 7 50
8mm l 13 12.5 41 9 50
9mm ll 13 13.8 41 9 50
10mm ll 13 15.0 41 9 50
11mm ll 13 16.3 41 9 50
12mm ll 13 17.0 41 9 50
13mm ll 13 18.8 41 9 50
14mm ll 13 20.0 41 9 50
15mm ll 13 21.0 41 9 50
SHAPE II
Always wear safety goggles when using Impact Tools.
Warning:
1
8
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
Page 11
1/4” Drive Universal Impact Sockets
1/4” Surface Drive Impact Socket Sets
1/4” Surface Drive Impact Socket Sets
Surface Drive Impact Sockets are specially designed with a hex opening that allows for quick engagement of a fastener. Ideal for
assembly operations.
1/4
” Drive - Standard Length Universal - Fractional Sizes
Item Hex
Number Size A B C E
908US
910US
912US
914US
916US
918US
1/4” .59 .43 .28 1.69
5/16” .59 .49 .35 1.69
3/8” .59 .59 .35 1.69
7/16” .59 .65 .35 1.69
1/2” .63 .74 .35 1.89
9/16” .63 .78 .35 1.89
Standard Length Universal - Metric Sizes
Dimensions (Inches)
Warning:
Warning:
Socket End
B
Bolt Clearance
C
Depth
Length
E
A
Drive End
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
Item Hex
Number Size A B C E
905UMS
955UMS
906UMS
907UMS
908UMS
909UMS
910UMS
911UMS
912UMS
913UMS
914UMS
915UMS
5mm 15 8.8 6 43
5.5mm 15 9.5 6 43
6mm 15 10.0 7 43
7mm 15 11.5 7 43
8mm 15 12.5 9 43
9mm 15 14.0 9 43
10mm 15 15.0 9 43
11mm 15 16.5 9 43
12mm 16 16.8 9 48
13mm 16 18.8 9 48
14mm 16 19.8 9 48
15mm 16 20.8 9 48
Dimensions (Millimeters)
2
9
Page 12
1/4” Surface Drive Impact Socket Sets
1/4” Drive Standard Length Magnetic Impact Sockets
1/4” Drive Magnetic - Standard Length - Fractional Sizes
Item Hex
Number Size
906RG
907RG
908RG
909RG
910RG
911RG
912RG
914RG
916RG
3/16” I .51 .33 .12 .91
7/32” I .51 .37 .12 .91
1/4” I .51 .41 .12 .91
9/32” I .51 .44 .12 .91
5/16” I .51 .49 .12 .91
11/32” III .51 .54 .16 .91
3/8” III .51 .59 .16 .91
7/16” III .51 .64 .20 .91
1/2” III .51 .74 .20 .91
Dimensions (Inches)
Shape
A B D E
Standard Length - Metric Sizes
Item Hex
Shape
Number Size
905MG
955MG
906MG
907MG
SHAPE I
B
D
E
Magnet
A
908MG
909MG
910MG
911MG
912MG
913MG
914MG
915MG
5mm I 13 8.8 3.0 23
5.5mm I 13 9.5 3.0 23
6mm I 13 10.0 3.0 23
7mm I 13 11.3 3.0 23
8mm I 13 12.5 3.0 23
9mm III 13 13.8 4.0 23
10mm III 13 15.0 4.0 23
11mm III 13 16.3 5.0 23
12mm III 13 17.0 5.0 23
13mm III 13 18.8 5.0 23
14mm III 13 20.0 5.5 23
15mm III 13 21.0 5.5 23
A B D E
SHAPE III
Dimensions (Millimeters)
10
Always wear safety goggles when using Impact Tools.
Warning:
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
Page 13
1/4” Surface Drive Impact Socket Sets
1/4” Drive Deep Length Magnetic Impact Sockets
All deep Magnetic sockets feature a spring loaded magnet that retracts into the socket for extended bolt applications.
1/4” Surface Drive Impact Socket Sets
1/4” Drive Magnetic - Deep Length - Fractional Sizes
Item Hex
Number Size Shape A B C D E
906DG
907DG
908DG
909DG
910DG
911DG
912DG
914DG
916DG
3/16” I .51 .33 .95 .16 1.97
7/32” I .51 .37 .95 .16 1.97
1/4” I .51 .41 .95 .16 1.97
9/32” II .51 .44 .95 .16 1.97
5/16” II .51 .49 .95 .16 1.97
11/32” II .51 .54 .95 .16 1.97
3/8” II .51 .59 .95 .24 1.97
7/16” II .51 .64 .95 .24 1.97
1/2” II .51 .74 .95 .28 1.97
Dimensions (Inches)
Deep Length - Metric Sizes
B
D
E
Spring
A
SHAPE I
C
Bolt
Clearance
Depth
Magnet
Item Hex
Number Size Shape A B C D E
905MDG
955MDG
906MDG
907MDG
908MDG
909MDG
910MDG
911MDG
912MDG
913MDG
914MDG
915MDG
5mm I 13 8.8 24 4 50
5.5mm I 13 9.5 24 4 50
6mm I 13 10.0 24 4 50
7mm I 13 11.3 24 4 50
8mm I 13 12.5 24 4 50
9mm II 13 13.8 24 4 50
10mm II 13 15.0 24 6 50
11mm II 13 16.3 24 6 50
12mm II 13 17.0 24 6 50
13mm II 13 18.8 24 7 50
14mm II 13 20.0 24 7 50
15mm II 13 21.0 24 8 50
Dimensions (Millimeters)
Warning:
Warning:
SHAPE II
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
11
Page 14
1/4” Surface Drive Impact Socket Sets
1/4” Drive Impact Attachments
1/4
” Drive Adapter
1/4
” Drive Universal Joint
1/4
” Drive Extensions
Socket
E
A
B
Item Female Male Retention
Number End
938A
1/4” 3/8” Friction Ball .54 1.02
*See page 179 for New Reducing Sleeve Adapters
End Device A E
Socket
Dimensions (Inches)
Dimensions (Inches)
Item Retention
E
A
Number Size
929UJ
1/4” x 1/4” Friction Ball .63 .71 1.69
Device A B E
Socket
Dimensions (Inches)
Item Retention
Number Description
Standard Extensions
942E
2” Extension Friction Ball .51 1.97
944E
4” Extension Friction Ball .51 3.94
946E
6” Extension Friction Ball .51 5.91
Device A E
12
E
A
Standard
1
Warning:
Warning:
Locking
Socket Retention Device Key for 1/4” Drive Adapters, Extensions & Universal Joints
FB
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
FB
Friction Ball
A spring loaded steel ball that lines up with the socket retainer hole. Use caution when using
this system because the socket is held in place only by spring pressure on the steel ball.
Do NOT run the tool when the socket is OFF the fastener.
Locking Extensions
These extensions feature a positive locking ball and sliding collar for quick release of
sockets and accessories. Useful in hard to reach areas where a positive lock on the
socket is required.
9703QL
943QL
946QL
952QL
958QL
964QL
3 pc. Locking Extension Set -
3” Locking Extension .51 2.95
6” Locking Extension .51 5.91
12” Locking Extension .51 11.81
18” Locking Extension .51 17.72
24” Locking Extension .51 24.02
NEW
includes 3”, 6”, 12”
Page 15
3/8” Drive Fractional Impact Socket Sets
No. 1213
No. 1213SD
3/8
3/8
” Drive Standard Length Fractional Set
” Drive Semi-Deep Length Fractional Set
NEW
SEMI-DEEP
12 piece set contents:
1010R ...........5/16” 1022R .......... 11/16”
1012R ............3/8” 1024R ............ 3/4”
1014R ...........7/16” 1026R .......... 13/16”
1016R ............1/2” 1028R ............ 7/8”
1018R ...........9/16” 1030R .......... 15/16”
1020R ............5/8” 1032R .............. 1”
Molded Storage Case
12 piece set contents:
1010SD .......... 5/16” 1022SD ......... 11/16”
1012SD ........... 3/8” 1024SD ........... 3/4”
1014SD .......... 7/16” 1026SD ......... 13/16”
1016SD ........... 1/2” 1028SD ........... 7/8”
1018SD .......... 9/16” 1030SD ......... 15/16”
1020SD ........... 5/8” 1032SD ............. 1”
Molded Storage Case
No. 1213D
Warning:
Warning:
3/8
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
” Drive Deep Length Fractional Set
12 piece set contents:
1010D ...........5/16” 1022D .......... 11/16”
1012D ............3/8” 1024D ............ 3/4”
1014D ...........7/16” 1026D .......... 13/16”
1016D ............1/2” 1028D ............ 7/8”
1018D ...........9/16” 1030D .......... 15/16”
1020D ............5/8” 1032D .............. 1”
Molded Storage Case
13
2
Page 16
3/8” Drive Metric Impact Socket Sets
No. 1213M
No. 1213MSD
3/8
3/8
” Drive Standard Length Metric Set
” Drive Semi-Deep Length Metric Set
NEW
SEMI-DEEP
13 piece set contents:
1007M ............7mm 1014M ...........14mm
1008M ............8mm 1015M ...........15mm
1009M ............9mm 1016M ...........16mm
1010M ...........10mm 1017M ...........17mm
1011M ...........11mm 1018M ...........18mm
1012M ...........12mm 1019M ...........19mm
1013M ...........13mm Molded Storage Case
13 piece set contents:
1007MSD .........7mm 1014MSD ........14mm
1008MSD .........8mm 1015MSD ........15mm
1009MSD .........9mm 1016MSD ........16mm
1010MSD ........10mm 1017MSD ........17mm
1011MSD ........11mm 1018MSD ........18mm
1012MSD ........12mm 1019MSD ........19mm
1013MSD ........13mm Molded Storage Case
14
No. 1213MD
3/8
” Drive Deep Length Metric Set
13 piece set contents:
1007MD ..........7mm 1014MD. . . . . . . . . .14mm
1008MD ..........8mm 1015MD. . . . . . . . . .15mm
1009MD ..........9mm 1016MD. . . . . . . . . .16mm
1010MD .........10mm 1017MD. . . . . . . . . .17mm
1011MD .........11mm 1018MD. . . . . . . . . .18mm
1012MD .........12mm 1019MD. . . . . . . . . .19mm
1013MD .........13mm Molded Storage Case
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 17
3/8” Drive Impact Socket Set
No. 1281
3/8
” Drive Fractional & Metric Master Socket Set
This set contains our most popular 3/8” drive 6 point sockets and universals with extended range
metric sizes up to 22mm. Also included is a 3” extension, universal joint and 1/4" hex to 3/8”
square adapter for use with hex drive impact tools. All packed in a compact, low profile, blow
molded storage case which can be used as a tool box organizer when the cover is removed.
Warning:
Warning:
81 piece set contents:
12 Pieces Fractional Standard Length:
5/16”, 3/8”, 7/16”, 1/2”, 9/16”, 5/8”, 11/16”, 3/4”,
13/16”, 7/8”, 15/16”, 1”
12 Pieces Fractional Deep Length:
5/16”, 3/8”, 7/16”, 1/2”, 9/16”, 5/8”, 11/16”, 3/4”,
13/16”, 7/8”, 15/16”, 1”
16 Pieces Metric Standard Length:
7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm,
17mm, 18mm, 19mm, 20mm, 21mm, 22mm
16 Pieces Metric Deep Length:
7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm,
17mm, 18mm, 19mm, 20mm, 21mm, 22mm
12 Pieces Standard Length Fractional Universal:
5/16”, 3/8”, 7/16”, 1/2”, 9/16”, 5/8”, 11/16”, 3/4”,
13/16”, 7/8”, 15/16”, 1”
10 Pieces Standard Length Metric Universal:
10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, 18mm, 19mm
1 Piece Each:
3” Extension
3/8” Universal Joint
1/4” Hex x 3/8” Square Adapter
Molded Storage Case
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
15
Page 18
3/8” Drive Impact Socket Sets
No. 1242RD
3/8
” Drive Standard & Deep Length Master Set
Set contains both Fractional and Metric sizes standard and deep lengths plus a 3” extension
and universal joint packaged in a molded case for easy transport and storage.
42 piece set contents:
8 Pieces Fractional Standard Length:
5/16”, 3/8”, 7/16”, 1/2”, 9/16”, 5/8”, 11/16”, 3/4”
8 Pieces Fractional Deep Length:
5/16”, 3/8”, 7/16”, 1/2”, 9/16”, 5/8”, 11/16”, 3/4”
12 Pieces Metric Standard Length:
8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm,
16mm, 17mm, 18mm, 19mm
12 Pieces Metric Deep Length:
8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm,
16mm, 17mm, 18mm, 19mm
1 Piece Each:
3” Extension
3/8” Universal Joint
Molded Storage Case
No. 1226M
3/8" Drive Standard & Deep Length Metric Master Set
26 piece set contents:
13 Pieces Metric Standard Length:
7mm, 8mm, 9mm, 10mm, 11mm, 12mm,13mm,
14mm, 15mm, 16mm, 17mm, 18mm, 19mm
13 Pieces Metric Deep Length:
7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm,
14mm, 15mm, 16mm, 17mm, 18mm, 19mm
Molded Storage Case
16
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 19
3/8” Drive Impact Socket Sets
No. 1229DM*
3/8
” Drive Deep Length Set
29 piece set contents:
12 Pieces Fractional Deep Length:
5/16”, 3/8”, 7/16”, 1/2”, 9/16”, 5/8”, 11/16”, 3/4”,
13/16”, 7/8”, 15/16”, 1”
14 Pieces Metric Deep Length:
8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm,
16mm, 17mm, 18mm, 19mm, 21mm, 22mm
1 Piece Each:
3” Extension
1/2” Female x 3/8” Male Adapter
3/8” Universal Joint
Set contains deep length Fractional and Metric sizes plus a 3” extension, universal joint and
adapter packaged in a molded storage case for easy transport and storage.
*Patent Number DES.395,166
No. 1100
Warning:
Warning:
Molded Storage Case
3/8
” Drive Impact Adapter & Extension Set
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
6 piece set contents:
1128A*
.................
1138A
..................
1129UJ
................
1140E
....................... 1-3/4”
1143E
...........................3”
1146E
...........................6”
All items use the Friction Ball Retainer.
* Reducing Adapters are not covered by the Gp Warranty.
3/8” F. x 1/4” M. Adapter
3/8” F. x 1/2” M. Adapter
3/8” x 3/8” Universal Joint
Molded Storage Case
Extension
Extension
Extension
2
17
Page 20
3/8” Drive 12-Point Fractional Impact Socket Sets
No. 1202
No. 1202SD
3/8
3/8
” Drive 12-Point Standard Length Fractional Set
12 piece set contents:
1110R .........5/16” 1122R .........11/16”
1112R ..........3/8” 1124R ...........3/4”
1114R .........7/16” 1126R .........13/16”
1116R ..........1/2” 1128R ...........7/8”
1118R .........9/16” 1130R .........15/16”
1120R ..........5/8” 1132R ............1”
” Drive 12-Point Semi-Deep Length Fractional Set
NEW
SEMI-DEEP
12 piece set contents:
1110SD ........5/16” 1122SD ........11/16”
1112SD .........3/8” 1124SD ..........3/4”
1114SD ........7/16” 1126SD ........13/16”
1116SD .........1/2” 1128SD ..........7/8”
1118SD ........9/16” 1130SD ........15/16”
1120SD .........5/8” 1132SD ........... 1”
Molded Storage Case
Molded Storage Case
18
No. 1202D
3/8
” Drive 12-Point Deep Length Fractional Set
12 piece set contents:
1110D .........5/16” 1122D ......... 11/16”
1102D ..........3/8” 1124D ........... 3/4”
1114D .........7/16” 1126D ......... 13/16”
1116D ..........1/2” 1128D ........... 7/8”
1118D .........9/16” 1130D ......... 15/16”
1120D ..........5/8” 1132D ........... . 1”
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Molded Storage Case
Page 21
3/8” Drive 12-Point Metric Impact Socket Sets
No. 1203M
No. 1203MSD
3/8
3/8
” Drive 12-Point Standard Length Metric Set
13 piece set contents:
1107M .........7mm 1114M ........ 14mm
1108M .........8mm 1115M ........ 15mm
1109M .........9mm 1116M ........ 16mm
1110M ........10mm 1117M ........ 17mm
1111M ........11mm 1118M ........ 18mm
1112M ........12mm 1119M ........ 19mm
1113M ........13mm Molded Storage Case
” Drive 12-Point Semi-Deep Length Metric Set
NEW
SEMI-DEEP
13 piece set contents:
1107MSD .......7mm 1114MSD...... 14mm
1108MSD .......8mm 1115MSD...... 15mm
1109MSD .......9mm 1116MSD...... 16mm
1110MSD ......10mm 1117MSD...... 17mm
1111MSD ......11mm 1118MSD...... 18mm
1112MSD ......12mm 1119MSD...... 19mm
1113MSD ......13mm Molded Storage Case
No. 1203MD
Warning:
Warning:
3/8
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
” Drive 12-Point Deep Length Metric Set
13 piece set contents:
1107MD . . . . . . . . 7mm 1114MD....... 14mm
1108MD . . . . . . . . 8mm 1115MD....... 15mm
1109MD . . . . . . . . 9mm 1116MD....... 16mm
1110MD . . . . . . . 10mm 1117MD....... 17mm
1111MD . . . . . . . 11mm 1118MD....... 18mm
1112MD . . . . . . . 12mm 1119MD....... 19mm
1113MD . . . . . . . 13mm Molded Storage Case
2
19
Page 22
3/8” Drive 12-Point Impact Socket Set
No. 1642RD 3/8” Drive 12-Point Standard & Deep Length Master Set
Set contains both Fractional and Metric sizes standard and deep lengths plus a 3” extension
and universal joint packaged in a molded case for easy transport and storage.
42 piece set contents:
8 Pieces Fractional Standard Length:
5/16”, 3/8”, 7/16”, 1/2”, 9/16”, 5/8”, 11/16”, 3/4”
8 Pieces Fractional Deep Length:
5/16”, 3/8”, 7/16”, 1/2”, 9/16”, 5/8”, 11/16”, 3/4”
12 Pieces Metric Standard Length:
8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm,
15mm, 16mm, 17mm, 18mm, 19mm
12 Pieces Metric Deep Length:
8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm,
15mm, 16mm, 17mm, 18mm, 19mm
1 Piece Each:
3” Extension
3/8" Universal Joint
Molded Storage Case
20
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 23
3/8” Drive Fractional Universal Impact Socket Sets
No. 1212U
No. 1212USD
3/8
3/8
” Drive Standard Length Fractional Universal Set
12 piece set contents:
1010U ......... 5/16” 1022U .........11/16”
1012U .......... 3/8” 1024U ...........3/4”
1014U .........7/16” 1026U ......... 13/16”
1016U ..........1/2” 1028U ........... 7/8”
1018U .........9/16” 1030U ......... 15/16”
1020U ..........5/8” 1032U ............ 1”
Molded Storage Case
” Drive Semi-Deep Length Fractional Universal Set
12 piece set contents:
1010USD .........5/16” 1022USD ........ 11/16”
1012USD ..........3/8” 1024USD .......... 3/4”
1014USD .........7/16” 1026USD ........ 13/16”
1016USD ..........1/2” 1028USD .......... 7/8”
1018USD .........9/16” 1030USD ........ 15/16”
1020USD ..........5/8” 1032USD ............ 1”
Molded Storage Case
No. 1212UD
3/8
NEW
SEMI-DEEP
” Drive Deep Length Fractional Universal Set
12 piece set contents:
1010UD ........5/16” 1022UD. . . . . . . . 11/16”
1012UD .........3/8” 1024UD. . . . . . . . . 3/4”
1014UD ........7/16” 1026UD. . . . . . . . 13/16”
1016UD .........1/2” 1028UD. . . . . . . . . 7/8”
1018UD ........9/16” 1030UD. . . . . . . . 15/16”
1020UD .........5/8” 1032UD. . . . . . . . . . . 1”
Molded Storage Case
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
21
Page 24
3/8” Drive Metric Universal Impact Socket Sets
No. 1210UM 3/8” Drive Standard Length Metric Universal Set
10 piece set contents:
1010UM .........10mm 1015UM. . . . . . . . . .15mm
1011UM .........11mm 1016UM. . . . . . . . . .16mm
1012UM .........12mm 1017UM. . . . . . . . . .17mm
1013UM .........13mm 1018UM. . . . . . . . . .18mm
1014UM .........14mm 1019UM. . . . . . . . . .19mm
Molded Storage Case
No. 1210UMSD
3/8
” Drive Semi-Deep Length Metric Universal Set
No. 1210UMD 3/8” Drive Deep Length Metric Universal Set
10 piece set contents:
1010UMSD .......10mm 1015UMSD .......15mm
1011UMSD .......11mm 1016UMSD .......16mm
1012UMSD .......12mm 1017UMSD .......17mm
1013UMSD .......13mm 1018UMSD .......18mm
1014UMSD .......14mm 1019UMSD .......19mm
Molded Storage Case
NEW
SEMI-DEEP
10 piece set contents:
1010UMD ........10mm 1015UMD ........15mm
1011UMD ........11mm 1016UMD ........16mm
1012UMD ........12mm 1017UMD ........17mm
1013UMD ........13mm 1018UMD ........18mm
1014UMD ........14mm 1019UMD ........19mm
Molded Storage Case
22
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 25
3/8” Drive 12-Point Universal Impact Socket Sets
No. 1612U
3/8
” Drive 12-Point Standard Length Fractional Universal Set
12 piece set contents:
1110U ......... 5/16” 1122U .........11/16”
1112U .......... 3/8” 1124U ...........3/4”
1114U .........7/16” 1126U ......... 13/16”
1116U ..........1/2” 1128U ........... 7/8”
1118U .........9/16” 1130U ......... 15/16”
1120U ..........5/8” 1132U ............ 1”
Molded Storage Case
No. 1610UM
3/8
” Drive 12-Point Standard Length Metric Universal Set
10 piece set contents:
1110UM ....... 10mm 1115UM .......15mm
1111UM ....... 11mm 1116UM .......16mm
1112UM ........12mm 1117UM .......17mm
1113UM ........13mm 1118UM .......18mm
1114UM ........14mm 1119UM .......19mm
Molded Storage Case
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
23
Page 26
3/8” Drive Magnetic Impact Socket Sets
No. 1224G
3/8
” Drive Standard Length Fractional & Metric Magnetic Set
This set contains standard length, fractional and metric sizes along with an extension and
universal joint packaged in a molded storage case. The powerful magnets hold any fastener
securely. Great for use in impact or non-impact applications.
24 piece set contents:
1008RG ...........1/4” 1007MG ..........7mm
1010RG ..........5/16” 1008MG ..........8mm
1012RG ...........3/8” 1009MG ..........9mm
1014RG ..........7/16” 1010MG .........10mm
1016RG ...........1/2” 1011MG .........11mm
1018RG ..........9/16” 1012MG .........12mm
1020RG ...........5/8” 1013MG .........13mm
1022RG .........11/16” 1014MG .........14mm
1024RG ...........3/4” 1015MG .........15mm
Molded Storage Case 1016MG .........16mm
1017MG .........17mm
1018MG .........18mm
1019MG .........19mm
1143E ...... 3” Extension
1129UJ ......3/8” x 3/8”
Universal Joint
No. 1209G
No. 1213MG
3/8
” Drive Standard Length Fractional Magnetic Set
3/8
” Drive Standard Length Metric Magnetic Set
9 piece set contents:
1008RG ...........1/4” 1016RG ...........1/2”
1010RG ..........5/16” 1018RG ..........9/16”
1012RG ...........3/8” 1020RG ...........5/8”
1014RG ..........7/16” 1022RG .........11/16”
On a Metal Clip Rail 1024RG ........... 3/4”
13 piece set contents:
1007MG ..........7mm 1013MG .........13mm
1008MG ..........8mm 1014MG .........14mm
1009MG ..........9mm 1015MG .........15mm
1010MG .........10mm 1016MG .........16mm
1011MG .........11mm 1017MG .........17mm
1012MG .........12mm 1018MG .........18mm
On a Metal Clip Rail 1019MG .........19mm
24
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 27
3/8” Drive Magnetic Impact Socket Sets
No. 1209DG
No. 1213MDG
3/8
” Drive Deep Length Fractional Magnetic Set
These Magnetic sockets feature a spring loaded magnet that retracts into the socket for extended bolt
applications.
3/8
” Drive Deep Length Metric Magnetic Set
These Magnetic sockets feature a spring loaded magnet that retracts into the socket for extended bolt
applications.
9 piece set contents:
1008DG ...........1/4” 1016DG ...........1/2”
1010DG ..........5/16” 1018DG ..........9/16”
1012DG ...........3/8” 1020DG ...........5/8”
1014DG ..........7/16” 1022DG .........11/16”
On a Metal Clip Rail 1024DG ........... 3/4”
13 piece set contents:
1007MDG .........7mm 1013MDG ........13mm
1008MDG .........8mm 1014MDG ........14mm
1009MDG .........9mm 1015MDG ........15mm
1010MDG ........10mm 1016MDG ........16mm
1011MDG ........11mm 1017MDG ........17mm
1012MDG ........12mm 1018MDG ........18mm
On a Metal Clip Rail 1019MDG ........19mm
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
25
Page 28
3/8” Drive Pipe Plug Impact Sockets
No. 1211P
3/8
” Drive Pipe Plug Socket Set
11 piece set contents:
Male Sizes Female Sizes
1006PP ..........3/16” 1008FP ...........1/4”
1008PP ...........1/4” 1009FP ..........9/32”
1009PP ..........9/32” 1010FP ..........5/16”
1010PP ..........5/16” 1011FP .........11/32”
1011PP .........11/32” 1012FP ...........3/8”
1012PP ...........3/8” Molded Storage Case
3/8
” Drive Individual Pipe Plug Sockets
B
E
A
MALE
E
A
FEMALE
Item
Number Size
Male Sizes
1006PP
1008PP
1009PP
1010PP
1011PP
1012PP
Female Sizes
B
1008FP
1009FP
1010FP
1011FP
1012FP
11/32” .75 .28 1.18
11/32” .75 .28 .98
3/16” .75 .28 1.18
1/4” .75 .28 1.18
9/32” .75 .28 1.18
5/16” .75 .28 1.18
3/8” .75 .28 1.18
1/4” .75 .20 .98
9/32” .75 .28 .98
5/16” .75 .28 .98
3/8” .75 .28 .98
Dimensions (Inches)
A B E
26
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 29
No. 1202UP
D
3/8” Drive Spark Plug Impact Sockets
3/8
” Drive Universal Swivel Spark Plug Socket Set
These universal swivel sockets are designed to remove spark plugs in hard to reach areas.
They can be used with a hand ratchet or impact wrench. Each socket includes a
replaceable rubber spark plug retainer.
Individual Sockets and Parts
2 piece set contents:
1020UP .........5/8”
1026UP .......13/16”
Packaged in a molded storage tray.
Rubber
Insert
E
No. 1202DUP
B
A
3/8
Item Hex
Number Size A B C D E
C
1020UP
1026UP
5/8” .94 .83 2.47 1.60 4.04
13/16” .94 1.06 2.20 1.65 3.85
Replacement Rubber Inserts Fits Size
1020RI
1026RI
” Drive Double Swivel Spark Plug Socket Set
These double swivel sockets are designed to remove spark plugs in hard to reach areas
and are especially useful on transverse mounted engines. They can be used with a hand
ratchet or impact wrench. Each socket includes a replaceable rubber spark plug retainer.
Dimensions (Inches)
5/8”
13/16”
2 piece set contents:
1020UP .........5/8”
1026UP .......13/16”
Packaged in a molded storage tray.
Warning:
Warning:
B
Rubber
Insert
E
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
C
D
A
Individual Sockets and Parts
Dimensions (Inches)
Item Hex
Number Size A B C D E
1020DUP
1026DUP
Replacement Rubber Inserts Fits Size
1020RI
1026RI
5/8” .75 .83 2.47 1.57 5.06
13/16” .75 1.06 2.20 1.64 4.86
5/8”
13/16”
2
27
Page 30
3/8” Drive Standard Length Impact Sockets
3/8” Drive - Standard Length - Fractional Sizes
Item Hex
Number Size
1010R
1012R
1014R
1016R
1018R
1020R
1022R
1024R
1026R
1028R
1030R
1032R
ANSI Specifications B107.2
5/16” I .75 .49 .69 .31 1.18
3/8” I .75 .57 .69 .31 1.18
7/16” I .75 .67 .69 .35 1.18
1/2” II .75 .75 .69 .35 1.18
9/16” II .79 .79 .69 .43 1.18
5/8” II .93 .93 .69 .47 1.18
3/4” II 1.02 1.02 .69 .51 1.18
13/16” II 1.10 1.10 .69 .51 1.18
15/16” II 1.26 1.26 .69 .51 1.18
1” II 1.34 1.34 .69 .51 1.18
Dimensions (Inches)
Shape
A B C D E
11/16” II .94 .94 .69 .47 1.18
7/8” II 1.18 1.18 .69 .51 1.18
Length
E
Hex
Depth
SHAPE I
Socket End
D
SHAPE II
B
A
Drive End
Bolt Clearance
Depth
C
Standard Length - Metric Sizes
Item Hex
Number Size
1007M
1008M
1009M
1010M
1011M
1012M
1013M
1014M
1015M
1016M
1017M
1018M
1019M
1020M
1021M
1022M
7mm I 19 11.5 17.5 8 30
8mm I 19 12.5 17.5 8 30
9mm I 19 14.0 17.5 8 30
10mm I 19 15.0 17.5 8 30
11mm I 19 17.0 17.5 9 30
12mm II 19 19.0 17.5 9 30
13mm II 19 19.0 17.5 10 30
14mm II 20 20.0 17.5 11 30
15mm II 22 22.0 17.5 11 30
16mm II 24 24.0 17.5 12 30
17mm II 24 24.0 17.5 12 30
18mm II 25 25.0 17.5 12 30
19mm II 26 26.0 17.5 13 30
20mm II 28 28.0 17.5 13 30
21mm II 28 28.0 17.5 13 30
22mm II 30 30.0 17.5 13 30
Dimensions (Millimeters)
Shape
A B C D E
28
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 31
3/8” Drive Semi-Deep Length Impact Sockets
3/8” Drive - Semi-Deep Length - Fractional Sizes
Item Hex
Number Size
1010SD
1012SD
1014SD
1016SD
1018SD
1020SD
1022SD
1024SD
1026SD
1028SD
1030SD
1032SD
NEW
SEMI-DEEP
Dimensions (Inches)
Shape
A B C D E
5/16” I .69 .50 1.14 .25 1.63
3/8” I .69 .56 1.14 .28 1.63
7/16” I .75 .66 1.14 .34 1.63
1/2” II .75 .75 1.14 .41 1.63
9/16” II .81 .81 1.14 .41 1.63
5/8” II .91 .91 1.14 .41 1.63
11/16” II .97 .97 1.14 .44 1.63
3/4” II 1.05 1.05 1.14 .46 1.63
13/16” II 1.13 1.13 1.14 .50 1.63
7/8” II 1.19 1.19 1.14 .53 1.63
15/16” II 1.28 1.28 1.14 .53 1.63
1” II 1.34 1.34 1.14 .56 1.63
Length
E
Hex
Depth
SHAPE I
Socket End
D
SHAPE II
B
A
Drive End
Bolt Clearance
Depth
C
Semi-Deep Length - Metric Sizes
Item Hex
Number Size
1007MSD
1008MSD
1009MSD
1010MSD
1011MSD
1012MSD
1013MSD
1014MSD
1015MSD
1016MSD
1017MSD
1018MSD
1019MSD
7mm I 17.2 11.6 29 5.6 41
8mm I 17.2 12.8 29 6.4 41
9mm I 17.2 14.0 29 7.1 41
10mm I 17.2 15.1 29 9.7 41
11mm I 17.2 16.4 29 9.7 41
12mm II 18.0 18.0 29 9.7 41
13mm II 19.6 19.6 29 10.4 41
14mm II 20.4 20.4 29 10.4 41
15mm II 21.2 21.2 29 10.4 41
16mm II 22.7 22.7 29 10.4 41
17mm II 24.3 24.3 29 11.2 41
18mm II 25.1 25.1 29 11.2 41
19mm II 26.7 26.7 29 11.7 41
Shape
Dimensions (Millimeters)
A B C D E
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
29
Page 32
3/8” Drive Deep Length Impact Sockets
3/8” Drive - Deep Length - Fractional Sizes
Item Hex
Number Size
1010D
1012D
1014D
1016D
1018D
1020D
1022D
1024D
1026D
1028D
1030D
1032D
ANSI Specifications B107.2
5/16” I .75 .49 1.93 .47 2.48
3/8” I .75 .57 2.01 .47 2.56
7/16” I .75 .67 2.01 .87 2.56
1/2” II .75 .75 2.09 .87 2.56
9/16” II .79 .79 2.09 .87 2.56
5/8” II .93 .93 2.09 .94 2.56
3/4” II 1.02 1.02 2.09 .94 2.56
13/16” II 1.10 1.10 2.09 .94 2.56
15/16” II 1.26 1.26 2.09 .94 2.56
1” II 1.34 1.34 2.09 .94 2.56
Dimensions (Inches)
Shape
A B C D E
11/16” II .94 .94 2.09 .94 2.56
7/8” II 1.18 1.18 2.09 .94 2.56
Length
E
Hex
Depth
D
SHAPE I
Socket End
B
A
Drive End
SHAPE II
Bolt
Clearance
Depth
C
Deep Length - Metric Sizes
Item Hex
Number Size
1007MD
1008MD
1009MD
1010MD
1011MD
1012MD
1013MD
1014MD
1015MD
1016MD
1017MD
1018MD
1019MD
1020MD
1021MD
1022MD
7mm I 19 11.5 49 12 63
8mm I 19 12.5 49 12 63
9mm I 19 14.0 51 12 65
10mm I 19 15.0 51 22 65
11mm I 19 17.0 51 22 65
12mm II 19 19.0 53 22 65
13mm II 19 19.0 53 22 65
14mm II 20 20.0 53 22 65
15mm II 22 22.0 53 22 65
16mm II 24 24.0 53 24 65
17mm II 24 24.0 53 24 65
18mm II 26 25.0 53 24 65
19mm II 26 26.0 53 24 65
20mm II 28 28.0 53 24 65
21mm II 28 28.0 53 24 65
22mm II 30 30.0 53 24 65
Dimensions (Millimeters)
Shape
A B C D E
30
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 33
3/8” Drive 12-Point Standard Length Impact Sockets
3/8” Drive 12-Point - Standard Length - Fractional Sizes
Item 12-Point
Number Size
1110R
1112R
1114R
1116R
1118R
1120R
1122R
1124R
1126R
1128R
1130R
1132R
ANSI Specifications B107.2
5/16” I .75 .49 .71 .24 1.18
3/8” I .75 .57 .71 .24 1.18
7/16” I .75 .67 .71 .31 1.18
1/2” II .75 .75 .71 .35 1.18
9/16” II .79 .79 .71 .43 1.18
5/8” II .93 .93 .71 .43 1.18
3/4” II 1.02 1.02 .71 .51 1.18
13/16” II 1.10 1.10 .71 .59 1.18
15/16” II 1.26 1.26 .71 .63 1.18
1” II 1.34 1.34 .71 .63 1.18
Dimensions (Inches)
Shape
A B C D E
11/16” II .94 .94 .71 .43 1.18
7/8” II 1.18 1.18 .71 .59 1.18
Length
E
Hex
Depth
SHAPE I
Socket End
D
Drive End
SHAPE II
Standard Length - Metric Sizes
Item 12-Point
Shape
Number Size
1107M
1108M
1109M
1110M
1111M
B
Bolt Clearance
Depth
C
A
1112M
1113M
1114M
1115M
1116M
1117M
1118M
1119M
1120M
1121M
1122M
7mm I 19 11.5 18 5 30
8mm I 19 12.5 18 6 30
9mm I 19 14.0 18 6 30
10mm I 19 15.0 18 7 30
11mm I 19 17.0 18 8 30
12mm II 19 19.0 18 9 30
13mm II 19 19.0 18 9 30
14mm II 20 20.0 18 11 30
15mm II 22 22.0 18 11 30
16mm II 24 24.0 18 11 30
17mm II 24 24.0 18 11 30
18mm II 25 25.0 18 13 30
19mm II 26 26.0 18 13 30
20mm II 28 28.0 18 13 30
21mm II 28 28.0 18 15 30
22mm II 30 30.0 18 15 30
A B C D E
Dimensions (Millimeters)
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
31
Page 34
3/8” Drive 12-Point Semi-Deep Length Impact Sockets
3/8” Drive 12-Point - Semi-Deep Length - Fractional Sizes
Item 12-Point
Number Size
1110SD
1112SD
1114SD
1116SD
1118SD
1120SD
1122SD
1124SD
1126SD
1128SD
1130SD
1132SD
5/16” I .69 .50 1.14 .25 1.63
3/8” I .69 .56 1.14 .28 1.63
7/16” I .75 .66 1.14 .34 1.63
1/2” II .75 .75 1.14 .41 1.63
9/16” II .81 .81 1.14 .41 1.63
5/8” II .91 .91 1.14 .41 1.63
11/16” II .97 .97 1.14 .44 1.63
3/4” II 1.05 1.05 1.14 .46 1.63
13/16” II 1.13 1.13 1.14 .50 1.63
7/8” II 1.19 1.19 1.14 .53 1.63
15/16” II 1.28 1.28 1.14 .53 1.63
1” II 1.34 1.34 1.14 .56 1.63
NEW
SEMI-DEEP
Dimensions (Inches)
Shape
A B C D E
Length
E
Hex
Depth
SHAPE I
Socket End
D
SHAPE II
B
A
Drive End
Bolt Clearance
Depth
C
Semi-Deep Length - Metric Sizes
Item 12-Point
Number Size
1107MSD
1108MSD
1109MSD
1110MSD
1111MSD
1112MSD
1113MSD
1114MSD
1115MSD
1116MSD
1117MSD
1118MSD
1119MSD
7mm I 17.2 11.6 29 5.6 41
8mm I 17.2 12.8 29 6.4 41
9mm I 17.2 14.0 29 7.1 41
10mm I 17.2 15.1 29 9.7 41
11mm I 17.2 16.4 29 9.7 41
12mm II 18.0 18.0 29 9.7 41
13mm II 19.6 19.6 29 10.4 41
14mm II 20.4 20.4 29 10.4 41
15mm II 21.2 21.2 29 10.4 41
16mm II 22.7 22.7 29 10.4 41
17mm II 24.3 24.3 29 11.2 41
18mm II 25.1 25.1 29 11.2 41
19mm II 26.7 26.7 29 11.7 41
Shape
Dimensions (Millimeters)
A B C D E
32
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 35
3/8” Drive 12-Point Deep Length Impact Sockets
3/8” Drive 12-Point - Deep Length - Fractional Sizes
Item 12-Point
Number Size
1110D
1102D
1114D
1116D
1118D
1120D
1122D
1124D
1126D
1128D
1130D
1132D
ANSI Specifications B107.2
5/16” I .75 .49 2.01 .24 2.48
3/8” I .75 .57 2.09 .24 2.56
7/16” I .75 .67 2.09 .31 2.56
1/2” II .75 .75 2.09 .35 2.56
9/16” II .79 .79 2.09 .43 2.56
5/8” II .93 .93 2.09 .43 2.56
3/4” II 1.02 1.02 2.09 .43 2.56
13/16” II 1.10 1.10 2.09 .59 2.56
15/16” II 1.26 1.26 2.09 .63 2.56
1” II 1.34 1.34 2.09 .63 2.56
Dimensions (Inches)
Shape
A B C D E
11/16” II .94 .94 2.09 .43 2.56
7/8” II 1.18 1.18 2.09 .59 2.56
Length
E
Hex
Depth
D
SHAPE I
Socket End
B
A
Drive End
SHAPE II
Bolt
Clearance
Depth
C
Deep Length - Metric Sizes
Item 12-Point
Number Size
1107MD
1108MD
1109MD
1110MD
1111MD
1112MD
1113MD
1114MD
1115MD
1116MD
1117MD
1118MD
1119MD
1120MD
1121MD
1122MD
7mm I 19 11.5 51 5 63
8mm I 19 12.5 51 6 63
9mm I 19 14.0 53 6 65
10mm I 19 15.0 53 7 65
11mm I 19 17.0 53 8 65
12mm II 19 19.0 53 9 65
13mm II 19 19.0 53 9 65
14mm II 20 20.0 53 11 65
15mm II 22 22.0 53 11 65
16mm II 24 24.0 53 11 65
17mm II 24 24.0 53 11 65
18mm II 25 25.0 53 13 65
19mm II 26 26.0 53 13 65
20mm II 28 28.0 53 13 65
21mm II 28 28.0 53 15 65
22mm II 30 30.0 53 15 65
Dimensions (Millimeters)
Shape
A B C D E
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
33
Page 36
3/8” Drive Standard Length Universal Impact Sockets
3/8” Drive - Standard Length Universal - Fractional Sizes
Item Hex
Dimensions (Inches)
Number Size A B C D E
1010U
1012U
1014U
1016U
1018U
1020U
1022U
1024U
1026U
1028U
1030U
1032U
ANSI Specifications B107.2
5/16” .94 .55 .51 .35 2.09
3/8” .94 .59 .51 .35 2.09
7/16” .94 .67 .51 .35 2.09
1/2” .94 .75 .51 .43 2.09
9/16” .94 .83 .51 .43 2.09
5/8” .94 .91 .51 .43 2.09
11/16” .94 .98 .51 .43 2.09
3/4” .94 1.06 .51 .43 2.09
13/16” .94 1.18 .51 .43 2.09
7/8” .94 1.26 .51 .43 2.09
15/16” .94 1.34 .51 .43 2.09
1” .94 1.42 .51 .43 2.09
Standard Length - Metric Sizes
Item Hex
Number Size A B C D E
B
D
E
A
C
1008UM
1009UM
1010UM
1011UM
1012UM
1013UM
1014UM
1015UM
1016UM
1017UM
1018UM
1019UM
1020UM
1021UM
1022UM
8mm 24 14 13 9 53
9mm 24 15 13 9 53
10mm 24 15 13 9 53
11mm 24 17 13 9 53
12mm 24 19 13 11 53
13mm 24 19 13 11 53
14mm 24 21 13 11 53
15mm 24 22 13 11 53
16mm 24 23 13 11 53
17mm 24 25 13 11 53
18mm 24 25 13 11 53
19mm 24 27 13 11 53
20mm 24 30 13 11 53
21mm 24 30 13 11 53
22mm 24 32 13 11 53
Dimensions (Millimeters)
34
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 37
3/8” Drive Semi-Deep Length Universal Impact Sockets
B
3/8” Drive - Semi-Deep Length Universal - Fractional Sizes
Item Hex
Number Size A B C D E
1010USD
1012USD
1014USD
1016USD
1018USD
1020USD
1022USD
1024USD
1026USD
1028USD
1030USD
1032USD
ANSI Specifications B107.2
NEW
SEMI-DEEP
Dimensions (Inches)
5/16” .94 .50 1.02 .35 2.60
3/8” .94 .56 1.02 .35 2.60
7/16” .94 .66 1.02 .43 2.60
1/2” .94 .75 1.02 .43 2.60
9/16” .94 .81 1.02 .43 2.60
5/8” .94 .91 1.02 .43 2.60
11/16” .94 .97 1.02 .43 2.60
3/4” .94 1.05 1.02 .47 2.60
13/16” .94 1.13 1.02 .47 2.60
7/8” .94 1.19 1.02 .47 2.60
15/16” .94 1.28 1.02 .47 2.60
1” .94 1.34 1.02 .47 2.60
Semi-Deep Length Universal - Metric Sizes
Item Hex
Number Size A B C D E
D
E
A
C
1010UMSD
1011UMSD
1012UMSD
1013UMSD
1014UMSD
1015UMSD
1016UMSD
1017UMSD
1018UMSD
1019UMSD
10mm 24 15.1 26 9 66
11mm 24 16.4 26 9 66
12mm 24 18.0 26 11 66
13mm 24 19.0 26 11 66
14mm 24 20.4 26 11 66
15mm 24 21.2 26 11 66
16mm 24 22.7 26 11 66
17mm 24 24.3 26 11 66
18mm 24 25.1 26 11 66
19mm 24 26.7 26 12 66
Dimensions (Millimeters)
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
35
Page 38
3/8” Drive Deep Length Universal Impact Sockets
3/8” Drive - Deep Length Universal - Fractional Sizes
Item Hex
Dimensions (Inches)
Number A B C D E
1010UD
1012UD
1014UD
1016UD
1018UD
1020UD
1022UD
1024UD
1026UD
1028UD
1030UD
1032UD
ANSI Specifications B107.2
5/16” .94 .55 1.18 .47 3.09
3/8” .94 .59 1.34 .79 3.11
7/16” .94 .67 1.42 .79 3.15
1/2” .94 .75 1.42 .79 3.15
9/16” .94 .83 1.42 .79 3.15
5/8” .94 .91 1.42 .79 3.15
11/16” .94 .98 1.42 .79 3.15
3/4” .94 1.06 1.42 .98 3.15
13/16” .94 1.18 1.42 .98 3.15
7/8” .94 1.26 1.42 1.02 3.15
15/16” .94 1.34 1.42 1.17 3.15
1” .94 1.42 1.42 1.17 3.15
Deep Length - Metric Sizes
B
D
C
E
A
Item Hex
Number Size
1008UMD
1009UMD
1010UMD
1011UMD
1012UMD
1013UMD
1014UMD
1015UMD
1016UMD
1017UMD
1018UMD
1019UMD
1020UMD
1021UMD
1022UMD
8mm 24 14 34 20 78
9mm 24 15 34 20 78
10mm 24 15 34 20 78
11mm 24 15 36 20 80
12mm 24 17 36 20 80
13mm 24 19 36 20 80
14mm 24 19 36 20 80
15mm 24 21 36 20 80
16mm 24 22 36 20 80
17mm 24 23 36 20 80
18mm 24 25 36 20 80
19mm 24 27 36 25 80
20mm 24 30 36 25 80
21mm 24 30 36 25 80
22mm 24 32 36 25 80
A B C D E
Dimensions (Millimeters)
36
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 39
3/8” Drive 12-Point Standard Length Universal Impact Sockets
3/8” Drive 12-Point - Standard Length Universal - Fractional Sizes
Item 12-Point
Number Size A B C D E
1110U
1112U
1114U
1116U
1118U
1120U
1122U
1124U
1126U
1128U
1130U
1132U
5/16” .94 .55 .51 .35 2.09
3/8” .94 .59 .51 .35 2.09
7/16” .94 .67 .51 .35 2.09
1/2” .94 .75 .51 .43 2.09
9/16” .94 .83 .51 .43 2.09
5/8” .94 .91 .51 .43 2.09
11/16” .94 .98 .51 .43 2.09
3/4” .94 1.06 .51 .43 2.09
13/16” .94 1.18 .51 .43 2.09
7/8” .94 1.26 .51 .43 2.09
15/16” .94 1.34 .51 .43 2.09
1” .94 1.42 .51 .43 2.09
ANSI Specifications B107.2
Dimensions (Inches)
Standard Length - Metric Sizes
Item 12-Point
Number Size A B C D E
B
D
E
A
C
1108UM
1109UM
1110UM
1111UM
*
1112UM
1113UM
1114UM
1115UM
1116UM
1117UM
1118UM
1119UM
1120UM
1121UM
1122UM
* Socket is Designed for Ford Driveshaft Bolts
8mm 24 14 13 9 53
9mm 24 15 13 9 53
10mm 24 15 13 9 53
11mm 24 17 13 9 53
12mm 24 19 13 11 53
13mm 24 19 13 11 53
14mm 24 21 13 11 53
15mm 24 22 13 11 53
16mm 24 23 13 11 53
17mm 24 25 13 11 53
18mm 24 25 13 11 53
19mm 24 27 13 11 53
20mm 24 30 13 11 53
21mm 24 30 13 11 53
22mm 24 32 13 11 53
Dimensions (Millimeters)
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
37
Page 40
3/8” Drive Standard Length Magnetic Impact Sockets
3/8” Drive Magnetic - Standard Length - Fractional Sizes
Item Hex
Number Size Shape
1008RG
1010RG
1012RG
1014RG
1016RG
1018RG
1020RG
1022RG
1024RG
1/4” I .75 .47 .12 1.18
5/16” I .75 .55 .12 1.18
3/8” I .75 .62 .16 1.18
7/16” I .75 .71 .20 1.18
1/2” III .75 .79 .20 1.18
9/16” I .87 .85 .24 1.18
5/8” III .87 .94 .24 1.18
11/16” III .87 1.00 .24 1.18
3/4” III .87 1.08 .28 1.18
Dimensions (Inches)
A B D E
Standard Length - Metric Sizes
SHAPE I
Item Hex
Number Size Shape
1007MG
1008MG
1009MG
1010MG
1011MG
1012MG
1013MG
SHAPE II
B
D
E
Magnet
A
1014MG
1015MG
1016MG
1017MG
1018MG
1019MG
7mm I 19 12.5 3 30
8mm I 19 14.0 3 30
9mm I 19 15.0 4 30
10mm I 19 16.5 4 30
11mm I 19 17.5 5 30
12mm II 19 19.0 5 30
13mm I 22 20.0 5 30
14mm I 22 21.5 6 30
15mm II 22 22.0 6 30
16mm III 22 24.0 6 30
17mm III 22 25.0 6 30
18mm III 22 26.0 7 30
19mm III 22 27.5 7 30
A B D E
SHAPE III
Dimensions (Millimeters)
38
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 41
3/8” Drive Deep Length Magnetic Impact Sockets
All deep Magnetic sockets feature a spring loaded magnet that retracts into the socket for extended bolt applications.
3/8” Drive Magnetic - Deep Length - Fractional Sizes
Item
Number Size Shape
1008DG
1010DG
1012DG
1014DG
1016DG
1018DG
1020DG
1022DG
1024DG
B
D
E
Spring
A
SHAPE I
SHAPE II
C
Bolt
Clearance
Depth
Magnet
Deep Length - Metric Sizes
Item Hex
Number Size Shape
1007MDG
1008MDG
1009MDG
1010MDG
1011MDG
1012MDG
1013MDG
1014MDG
1015MDG
1016MDG
1017MDG
1018MDG
1019MDG
1/4” I .75 .47 1.69 .16 2.17
5/16” I .75 .55 1.69 .16 2.17
3/8” I .75 .62 1.69 .20 2.17
7/16” I .75 .71 1.69 .24 2.17
1/2” III .75 .79 1.69 .24 2.17
9/16” I .87 .85 1.69 .28 2.17
5/8” III .87 .94 1.69 .28 2.17
11/16” III .87 1.01 1.69 .28 2.17
3/4” III .87 1.08 1.69 .31 2.17
7mm I 19 12.5 43 4 55
8mm I 19 14.0 43 4 55
9mm I 19 15.0 43 4 55
10mm I 19 16.5 43 5 55
11mm I 19 17.5 43 6 55
12mm II 19 19.0 43 6 55
13mm I 22 20.0 43 6 55
14mm I 22 21.5 43 6 55
15mm II 22 22.0 43 7 55
16mm III 22 24.0 43 7 55
17mm III 22 25.0 43 7 55
18mm III 22 26.0 43 8 55
19mm III 22 27.5 43 8 55
A B C D E
A B C D E
Dimensions (Inches)
Dimensions (Millimeters)
Warning:
Warning:
SHAPE III
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
39
2
Page 42
3/8” Drive Impact Attachments
3/8
” Drive Adapters
3
/8
” Drive Universal Joints
1129UJ
(Standard)
3
/8
” Drive Extensions
E
1129TUJ
(Thin-Wall)
Socket
Dimensions (Inches)
Item Female Male Retention
Number End
*
1128A
*
1128AL
A
B
1138A
1138AL
* Reducing Adapters are not covered by the GP Warranty.
* See page 179 for New Reducing Sleeve Adapters
3/8” 1/2” Friction Ball .87 1.42
3/8” 1/4” Friction Ball .87 1.26
3/8” 1/4” Locking Pin .87 1.26
3/8” 1/2” Locking Pin .87 1.42
End Device A E
Socket
Dimensions (Inches)
Item Retention
Number Size
E
1129UJ
1129UJL
*1129TUJ
A
* 1129TUJ is a thin-wall design that provides extra clearance in tight spaces.
Due to the thin wall design the 1129TUJ is not covered by the GP Warranty.
3/8” x 3/8” Friction Ball .94 1.02 1.97
3/8” x 3/8” Locking Pin .94 1.02 1.97
3/8” x 3/8” Friction Ball .69 .77 1.85
Device A B E
Standard
Locking
FB
Do NOT run the tool when the
socket is OFF the fastener.
Item Socket
Number Description Retention Device A E
Standard Extensions
1140E
1143E
1143EL
1146E
1146EL
1152E
1152EL
E
A
Socket Retention Device Key for 3/8” Drive Adapters, Extensions & Universal Joints
LP
FB
A spring loaded steel ball that lines up with the socket
retainer hole. Use caution when using this system
because the socket is held in place only by spring
pressure on the steel ball.
Locking Extensions
These extensions feature a positive locking ball and sliding collar for quick release of
sockets and accessories. Useful in hard to reach areas where a positive lock on the
socket is required.
1103QL
1143QL
1146QL
1152QL
1158QL
1164QL
Friction Ball
1-3/4” Extension Friction Ball .75 1.73
3” Extension Friction Ball .75 2.95
3” Extension Locking Pin .75 2.95
6” Extension Friction Ball .75 5.91
6” Extension Locking Pin .75 5.91
12” Extension Friction Ball .75 11.80
12” Extension Locking Pin .75 11.80
NEW
3 pc. Locking Extension Set -
3” Locking Extension .75 2.95
6” Locking Extension .75 5.91
12” Locking Extension .75 11.81
18” Locking Extension .75 18.11
24” Locking Extension .75 24.02
LP
Locking Pin
Spring loaded pin, simply line up with socket retainer
hole and press pin. To release socket, insert object
through retainer hole and press pin.
includes 3”, 6”, 12”
Dimensions (Inches)
40
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 43
1/2” Drive Impact Socket Sets
No. 1312
No. 1312D
1/2
1/2
” Drive Standard Length Fractional Set
13 piece set contents:
2014R ...........7/16” 2028R ............ 7/8”
2016R ............1/2” 2030R .......... 15/16”
2018R ...........9/16” 2032R .............. 1”
2020R ............5/8” 2034R ..........1-1/16”
2022R ..........11/16” 2036R ...........1-1/8”
2024R ............3/4” 2040R ...........1-1/4”
2026R ..........13/16” Molded Storage Case
” Drive Deep Length Fractional Set
13 piece set contents:
2014D ...........7/16” 2028D ............ 7/8”
2016D ............1/2” 2030D .......... 15/16”
2018D ...........9/16” 2032D .............. 1”
2020D ............5/8” 2034D ..........1-1/16”
2022D ..........11/16” 2036D ...........1-1/8”
2024D ............3/4” 2040D ...........1-1/4”
2026D ..........13/16” Molded Storage Case
No. 1412M
No. 1412MD
1/2
1/2
” Drive Standard Length Metric Set
14 piece set contents:
2010M ...........10mm 2018M ...........18mm
2011M ...........11mm 2019M ...........19mm
2012M ...........12mm 2021M ...........21mm
2013M ...........13mm 2022M ...........22mm
2014M ...........14mm 2026M ...........26mm
2015M ...........15mm 2027M ...........27mm
2016M ...........16mm Molded Storage Case
2017M ...........17mm
” Drive Deep Length Metric Set
14 piece set contents:
2010MD .........10mm 2018MD. . . . . . . . . .18mm
2011MD .........11mm 2019MD. . . . . . . . . .19mm
2012MD .........12mm 2021MD. . . . . . . . . .21mm
2013MD .........13mm 2022MD. . . . . . . . . .22mm
2014MD .........14mm 2026MD. . . . . . . . . .26mm
2015MD .........15mm 2027MD. . . . . . . . . .27mm
2016MD .........16mm Molded Storage Case
2017MD .........17mm
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
41
Page 44
1/2” Drive Fractional Impact Socket Master Sets
No. 1319
1/2
” Drive Standard Length Fractional Master Set
This set includes standard length Fractional sizes from 3/8” through 1-1/2”. The set is
packaged in a convenient molded case with handle for easy transportation. The cover
of the case may be removed to allow the bottom to be used as a tool box organizer.
19 piece set contents:
2012R ............3/8” 2032R .............. 1”
2014R ...........7/16” 2034R ..........1-1/16”
2016R ............1/2” 2036R ...........1-1/8”
2018R ...........9/16” 2038R ..........1-3/16”
2020R ............5/8” 2040R ...........1-1/4”
2022R ..........11/16” 2042R ..........1-5/16”
2024R ............3/4” 2044R ...........1-3/8”
2026R ..........13/16” 2046R ..........1-7/16”
2028R ............7/8” 2048R ...........1-1/2”
2030R ..........15/16” Molded Storage Case
No. 1319D
1/2
” Drive Deep Length Fractional Master Set
This set includes deep length Fractional sizes from 3/8” through 1-1/2”. The set is
packaged in a convenient molded case with handle for easy transportation. The cover
of the case may be removed to allow the bottom to be used as a tool box organizer.
19 piece set contents:
2012D ............3/8” 2032D .............. 1”
2014D ...........7/16” 2034D ..........1-1/16”
2016D ............1/2” 2036D ...........1-1/8”
2018D ...........9/16” 2038D ..........1-3/16”
2020D ............5/8” 2040D ...........1-1/4”
2022D ..........11/16” 2042D ..........1-5/16”
2024D ............3/4” 2044D ...........1-3/8”
2026D ..........13/16” 2046D ..........1-7/16”
2028D ............7/8” 2048D ...........1-1/2”
2030D ..........15/16” Molded Storage Case
42
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 45
1/2” Drive Metric Impact Socket Master Sets
No. 1326M
1/2
” Drive Standard Length Metric Master Set
This set includes standard length Metric sizes from 10mm through 36mm. The set is
packaged in a convenient molded case with handle for easy transportation. The cover
of the case may be removed to allow the bottom to be used as a tool box organizer.
26 piece set contents:
2010M ...........10mm 2023M ...........23mm
2011M ...........11mm 2024M ...........24mm
2012M ...........12mm 2025M ...........25mm
2013M ...........13mm 2026M ...........26mm
2014M ...........14mm 2027M ...........27mm
2015M ...........15mm 2028M ...........28mm
2016M ...........16mm 2029M ...........29mm
2017M ...........17mm 2030M ...........30mm
2018M ...........18mm 2032M ...........32mm
2019M ...........19mm 2033M ...........33mm
2020M ...........20mm 2034M ...........34mm
2021M ...........21mm 2035M ...........35mm
2022M ...........22mm 2036M ...........36mm
Molded Storage Case
No. 1326MD
1/2” Drive Deep Length Metric Master Set
This set includes deep length Metric sizes from 10mm through 36mm. The set is
packaged in a convenient molded case with handle for easy transportation. The cover
of the case may be removed to allow the bottom to be used as a tool box organizer.
26 piece set contents:
2010MD .........10mm 2023MD. . . . . . . . . .23mm
2011MD .........11mm 2024MD. . . . . . . . . .24mm
2012MD .........12mm 2025MD. . . . . . . . . .25mm
2013MD .........13mm 2026MD. . . . . . . . . .26mm
2014MD .........14mm 2027MD. . . . . . . . . .27mm
2015MD .........15mm 2028MD. . . . . . . . . .28mm
2016MD .........16mm 2029MD. . . . . . . . . .29mm
2017MD .........17mm 2030MD. . . . . . . . . .30mm
2018MD .........18mm 2032MD. . . . . . . . . .32mm
2019MD .........19mm 2033MD. . . . . . . . . .33mm
2020MD .........20mm 2034MD. . . . . . . . . .34mm
2021MD .........21mm 2035MD. . . . . . . . . .35mm
2022MD .........22mm 2036MD. . . . . . . . . .36mm
Molded Storage Case
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
43
Page 46
1/2” Drive Impact Socket Sets
No. 1328RD
1/2
” Drive Standard & Deep Length Fractional Set
Set contains both standard & deep length Fractional sizes, plus a universal joint and
3” extension packaged in a molded case for easy transport & storage.
28 piece set contents:
Deep Sizes
2014D ...........7/16” 2028D ............ 7/8”
2016D ............1/2” 2030D .......... 15/16”
2018D ...........9/16” 2032D .............. 1”
2020D ............5/8” 2034D ..........1-1/16”
2022D ..........11/16” 2036D ...........1-1/8”
2024D ............3/4” 2040D ...........1-1/4”
2026D ..........13/16”
Standard Sizes
2014R ...........7/16” 2028R ............ 7/8”
2016R ............1/2” 2030R .......... 15/16”
2018R ...........9/16” 2032R .............. 1”
2020R ............5/8” 2034R ..........1-1/16”
2022R ..........11/16” 2036R ...........1-1/8”
2024R ............3/4” 2040R ...........1-1/4”
2026R ..........13/16”
2229UJ Universal Joint
2243E 3” Extension
Molded Storage Case
No. 1430MRD
1/2
” Drive Standard & Deep Length Metric Set
Set contains both standard & deep length Metric sizes, plus a universal joint and
3” extension packaged in a molded case for easy transport & storage.
30 piece set contents:
Deep Sizes
2010MD .........10mm 2017MD. . . . . . . . . .17mm
2011MD .........11mm 2018MD. . . . . . . . . .18mm
2012MD .........12mm 2019MD. . . . . . . . . .19mm
2013MD .........13mm 2020MD. . . . . . . . . .20mm
2014MD .........14mm 2021MD. . . . . . . . . .21mm
2015MD .........15mm 2022MD. . . . . . . . . .22mm
2016MD .........16mm 2024MD. . . . . . . . . .24mm
Standard Sizes
2010M ..........10mm 2017M ...........17mm
2011M ..........11mm 2018M ...........18mm
2012M ..........12mm 2019M ...........19mm
2013M ..........13mm 2020M ...........20mm
2014M ..........14mm 2021M ...........21mm
2015M ..........15mm 2022M ...........22mm
2016M ..........16mm 2024M ...........24mm
2229UJ Universal Joint
2243E 3” Extension
Molded Storage Case
44
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 47
1/2” Drive Impact Socket Sets
No. 1324D
1/2
” Drive Deep Length Fractional Set
Set contains deep length Fractional sizes from 5/16” through 1-1/2”, plus three extensions
and a universal joint packaged in a molded case for easy transport and storage.
24 piece set contents:
2010D ...........5/16” 2030D .......... 15/16”
2012D ............3/8” 2032D .............. 1”
2014D ...........7/16” 2034D ..........1-1/16”
2016D ............1/2” 2036D ...........1-1/8”
2018D ...........9/16” 2038D ..........1-3/16”
2020D ............5/8” 2040D ...........1-1/4”
2022D ..........11/16” 2042D ..........1-5/16”
2024D ............3/4” 2044D ...........1-3/8”
2026D ..........13/16” 2046D ..........1-7/16”
2028D ............7/8” 2048D ...........1-1/2”
2229UJ 1/2” Universal Joint
2243E 3” Extension
2245E 5” Extension
2210E 10” Extension
Molded Storage Case
No. 1512DM*
1/2” Drive Deep Length Fractional & Metric Set
Set contains deep length Fractional and Metric sizes, plus two flip sockets and extension
for wheel service, packaged in a molded case for easy transport & storage.
30 piece set contents:
Fractional Deep Sizes
2014D ...........7/16” 2028D ............ 7/8”
2016D ............1/2” 2030D .......... 15/16”
2018D ...........9/16” 2032D .............. 1”
2020D ............5/8” 2034D ..........1-1/16”
2022D ..........11/16” 2036D ...........1-1/8”
2024D ............3/4” 2040D ...........1-1/4”
2026D ..........13/16”
Metric Deep Sizes
2010MD .........10mm 2017MD. . . . . . . . . .17mm
2011MD .........11mm 2018MD. . . . . . . . . .18mm
2012MD .........12mm 2019MD. . . . . . . . . .19mm
2013MD .........13mm 2021MD. . . . . . . . . .21mm
2014MD .........14mm 2022MD. . . . . . . . . .22mm
2015MD .........15mm 2026MD. . . . . . . . . .26mm
2016MD .........16mm 2027MD. . . . . . . . . .27mm
2146DT 3/4” x 13/16” Flip Socket
2192DT 19mm x 21mm Flip Socket
2243E 3” Extension
Molded Storage Case
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
*Pat. No. Des. 392,463
2
45
Page 48
1/2” Drive Extra-Deep Impact Sockets
No. 1313XD
1/2
” Drive Extra-Deep Length Fractional Set
This set contains Extra-Deep length Fractional sizes for extra reach in extended bolt
applications packaged in a molded case for easy transport and storage. Additional
Fractional and Metric sizes are available individually.
13 piece set contents:
2016XD ...........1/2” 2030XD ......... 15/16”
2018XD ..........9/16” 2032XD ............. 1”
2020XD ...........5/8” 2034XD .........1-1/16”
2022XD .........11/16” 2036XD ..........1-1/8”
2024XD ...........3/4” 2040XD ..........1-1/4”
2026XD .........13/16” 2042XD .........1-5/16”
2028XD ...........7/8” Molded Storage Case
1/2” Drive Extra-Deep Length Fractional Sockets
Number Size Shape A B C D E
2010XD
2012XD
2014XD
2016XD
2018XD
2020XD
2022XD
2024XD
2026XD
2028XD
2030XD
2032XD
2034XD
2036XD
2038XD
2040XD
2042XD
2044XD
2046XD
2048XD
Five (5) inches overall length, with over 4-3/8” bolt clearance depth.
Item Hex
5/16” I .94 .59 4.33 .51 5.00
3/8” I .94 .63 4.33 .55 5.00
7/16” I .94 .71 4.33 .55 5.00
1/2” I .94 .79 4.33 .55 5.00
9/16” I .94 .87 4.33 .94 5.00
5/8” II .94 .95 4.33 .94 5.00
11/16” II 1.02 1.02 4.33 .94 5.00
3/4” II 1.10 1.10 4.33 .94 5.00
13/16” II 1.18 1.18 4.33 .94 5.00
7/8” II 1.26 1.26 4.33 .94 5.00
15/16” II 1.34 1.34 4.33 .94 5.00
1” II 1.42 1.42 4.33 .94 5.00
1-1/16” II 1.50 1.50 4.33 .94 5.00
1-1/8” III 1.50 1.58 4.33 .94 5.00
1-3/16” III 1.50 1.65 4.33 .94 5.00
1-1/4” III 1.50 1.73 4.33 .94 5.00
1-5/16” III 1.50 1.81 4.33 .94 5.00
1-3/8” III 1.50 1.91 4.33 .94 5.00
1-7/16” III 1.50 1.99 4.33 .94 5.00
1-1/2” III 1.50 2.07 4.33 .94 5.00
Dimensions (Inches)
46
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 49
1/2” Drive Extra-Deep Length Metric Sockets
1/2” Drive Extra-Deep Impact Sockets
Five (5) inches overall length, with over 4-3/8” bolt clearance depth.
Hex
Number Size Shape A B C D E
2010XMD
2011XMD
2012XMD
2013XMD
2014XMD
2015XMD
2016XMD
2017XMD
2018XMD
2019XMD
2020XMD
2021XMD
2022XMD
2023XMD
2024XMD
2025XMD
2026XMD
2027XMD
2028XMD
2029XMD
2030XMD
2032XMD
2033XMD
2034XMD
2035XMD
2036XMD
10mm I 24 17.0 110 14 127
11mm I 24 18.0 110 14 127
12mm I 24 19.0 110 14 127
13mm I 24 20.0 110 14 127
14mm I 24 22.0 110 24 127
15mm II 24 24.0 110 24 127
16mm II 24 24.0 110 24 127
17mm II 26 26.0 110 24 127
18mm II 26 26.0 110 24 127
19mm II 28 28.0 110 24 127
20mm II 30 30.0 110 24 127
21mm II 30 30.0 110 24 127
22mm II 32 32.0 110 24 127
23mm II 32 32.0 110 24 127
24mm II 34 34.0 110 24 127
25mm II 36 36.0 110 24 127
26mm II 36 36.0 110 24 127
27mm II 38 38.0 110 24 127
28mm II 38 40.0 110 24 127
29mm III 38 40.0 110 24 127
30mm III 38 42.0 110 24 127
32mm III 38 44.0 110 24 127
33mm III 38 45.0 110 24 127
34mm III 38 46.0 110 24 127
35mm III 38 48.5 110 24 127
36mm III 38 48.5 110 24 127
Dimensions (Millimeters)
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
47
Page 50
1/2” Drive 12-Point Fractional Impact Socket Master Sets
No. 1719
1/2
” Drive 12-Point Standard Length Fractional Master Set
This set includes standard length Fractional sizes from 3/8” through 1-1/2”. The set is
packaged in a convenient molded case with handle for easy transportation. The cover
of the case may be removed to allow the bottom to be used as a tool box organizer.
19 piece set contents:
2112R ............3/8” 2132R .............. 1”
2114R ...........7/16” 2134R ..........1-1/16”
2116R ............1/2” 2136R ...........1-1/8”
2118R ...........9/16” 2138R ..........1-3/16”
2120R ............5/8” 2140R ...........1-1/4”
2122R ..........11/16” 2142R ..........1-5/16”
2124R ............3/4” 2144R ...........1-3/8”
2126R ..........13/16” 2146R ..........1-7/16”
2128R ............7/8” 2148R ...........1-1/2”
2130R ..........15/16” Molded Storage Case
No. 1719D
1/2
” Drive 12-Point Deep Length Fractional Master Set
This set includes deep length Fractional sizes from 3/8” through 1-1/2”. The set is
packaged in a convenient molded case with handle for easy transportation. The cover
of the case may be removed to allow the bottom to be used as a tool box organizer.
19 piece set contents:
2112D ............3/8” 2132D .............. 1”
2114D ...........7/16” 2134D ..........1-1/16”
2116D ............1/2” 2136D ...........1-1/8”
2118D ...........9/16” 2138D ..........1-3/16”
2120D ............5/8” 2140D ...........1-1/4”
2122D ..........11/16” 2142D ..........1-5/16”
2124D ............3/4” 2144D ...........1-3/8”
2126D ..........13/16” 2146D ..........1-7/16”
2128D ............7/8” 2148D ...........1-1/2”
2130D ..........15/16” Molded Storage Case
48
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 51
1/2” Drive 12-Point Metric Impact Socket Master Sets
No. 1726M
1/2
” Drive 12-Point Standard Length Metric Master Set
This set includes standard length Metric sizes from 10mm through 36mm. The set is
packaged in a convenient molded case with handle for easy transportation. The cover
of the case may be removed to allow the bottom to be used as a tool box organizer.
26 piece set contents:
2110M ...........10mm 2123M ...........23mm
2111M ...........11mm 2124M ...........24mm
2112M ...........12mm 2125M ...........25mm
2113M ...........13mm 2126M ...........26mm
2114M ...........14mm 2127M ...........27mm
2115M ...........15mm 2128M ...........28mm
2116M ...........16mm 2129M ...........29mm
2117M ...........17mm 2130M ...........30mm
2118M ...........18mm 2132M ...........32mm
2119M ...........19mm 2133M ...........33mm
2120M ...........20mm 2134M ...........34mm
2121M ...........21mm 2135M ...........35mm
2122M ...........22mm 2136M ...........36mm
Molded Storage Case
No. 1726MD
1/2” Drive 12-Point Deep Length Metric Master Set
This set includes deep length Metric sizes from 10mm through 36mm. The set is
packaged in a convenient molded case with handle for easy transportation. The cover
of the case may be removed to allow the bottom to be used as a tool box organizer.
26 piece set contents:
2110MD .........10mm 2123MD. . . . . . . . . .23mm
2111MD .........11mm 2124MD. . . . . . . . . .24mm
2112MD .........12mm 2125MD. . . . . . . . . .25mm
2113MD .........13mm 2126MD. . . . . . . . . .26mm
2114MD .........14mm 2127MD. . . . . . . . . .27mm
2115MD .........15mm 2128MD. . . . . . . . . .28mm
2116MD .........16mm 2129MD. . . . . . . . . .29mm
2117MD .........17mm 2130MD. . . . . . . . . .30mm
2118MD .........18mm 2132MD. . . . . . . . . .32mm
2119MD .........19mm 2133MD. . . . . . . . . .33mm
2120MD .........20mm 2134MD. . . . . . . . . .34mm
2121MD .........21mm 2135MD. . . . . . . . . .35mm
2122MD .........22mm 2136MD. . . . . . . . . .36mm
Molded Storage Case
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
49
Page 52
1/2” Drive Universal Impact Socket Sets
No. 1314U
No. 1314UD
1/2
1/2
” Drive Standard Length Fractional Universal Set
14 piece set contents:
2014U ...........7/16” 2028U ............ 7/8”
2016U ............1/2” 2030U .......... 15/16”
2018U ...........9/16” 2032U .............. 1”
2020U ............5/8” 2034U ..........1-1/16”
2022U ..........11/16” 2036U ...........1-1/8”
2024U ............3/4” 2038U ..........1-3/16”
2026U ..........13/16” 2040U ...........1-1/4”
Molded Storage Case
” Drive Deep Length Fractional Universal Set
14 piece set contents:
2014UD .......... 7/16” 2028UD ...........7/8”
2016UD ........... 1/2” 2030UD .........15/16”
2018UD .......... 9/16” 2032UD .............1”
2020UD ........... 5/8” 2034UD .........1-1/16”
2022UD ......... 11/16” 2036UD ..........1-1/8”
2024UD ........... 3/4” 2038UD .........1-3/16”
2026UD ......... 13/16” 2040UD ..........1-1/4”
Molded Storage Case
No. 1313UM
No. 1313UMD
1/2
1/2
” Drive Standard Length Metric Universal Set
13 piece set contents:
2012UM .........12mm 2019UM. . . . . . . . . .19mm
2013UM .........13mm 2020UM. . . . . . . . . .20mm
2014UM .........14mm 2021UM. . . . . . . . . .21mm
2015UM .........15mm 2022UM. . . . . . . . . .22mm
2016UM .........16mm 2023UM. . . . . . . . . .23mm
2017UM .........17mm 2024UM. . . . . . . . . .24mm
2018UM .........18mm Molded Storage Case
” Drive Deep Length Metric Universal Set
13 piece set contents:
2012UMD ........12mm 2019UMD ........19mm
2013UMD ........13mm 2020UMD ........20mm
2014UMD ........14mm 2021UMD ........21mm
2015UMD ........15mm 2022UMD ........22mm
2016UMD ........16mm 2023UMD ........23mm
2017UMD ........17mm 2024UMD ........24mm
2018UMD ........18mm Molded Storage Case
50
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 53
1/2” Drive 12-Point Universal Impact Socket Sets
No. 1714U
1/2
” Drive 12-Point Standard Length Fractional Universal Set
14 piece set contents:
2114U ...........7/16” 2128U ............ 7/8”
2116U ............1/2” 2130U .......... 15/16”
2118U ...........9/16” 2132U .............. 1”
2120U ............5/8” 2134U ..........1-1/16”
2122U ..........11/16” 2136U ...........1-1/8”
2124U ............3/4” 2138U ..........1-3/16”
2126U ..........13/16” 2140U ...........1-1/4”
Molded Storage Case
No. 1713UM
1/2
” Drive 12-Point Standard Length Metric Universal Set
13 piece set contents:
2112UM .........12mm 2119UM. . . . . . . . . .19mm
2113UM .........13mm 2120UM. . . . . . . . . .20mm
2114UM .........14mm 2121UM. . . . . . . . . .21mm
2115UM .........15mm 2122UM. . . . . . . . . .22mm
2116UM .........16mm 2123UM. . . . . . . . . .23mm
2117UM .........17mm 2124UM. . . . . . . . . .24mm
2118UM .........18mm Molded Storage Case
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
51
Page 54
1/2” Drive Magnetic Impact Socket Sets
No. 1511G
No. 1512MG
1/2” Drive Standard Length Fractional Magnetic Set
1/2” Drive Standard Length Metric Magnetic Set
11 piece set contents:
2012RG ...........3/8” 2022RG .........11/16”
2014RG ..........7/16” 2024RG ...........3/4”
2016RG ...........1/2” 2026RG .........13/16”
2018RG ..........9/16” 2028RG ...........7/8”
2020RG ...........5/8” 2030RG .........15/16”
On a Metal Clip Rail 2032RG ............. 1”
12 piece set contents:
2010MG .........10mm 2016MG .........16mm
2011MG .........11mm 2017MG .........17mm
2012MG .........12mm 2018MG .........18mm
2013MG .........13mm 2019MG .........19mm
2014MG .........14mm 2020MG .........20mm
2015MG .........15mm 2021MG .........21mm
On a Metal Clip Rail
No. 1511DG 1/2” Drive Deep Length Fractional Magnetic Set
These magnetic sockets feature a spring loaded magnet that retracts into the socket for
extended bolt applications.
No. 1512MDG 1/2” Drive Deep Length Metric Magnetic Set
These magnetic sockets feature a spring loaded magnet that retracts into the socket for
extended bolt applications.
11 piece set contents:
2012DG ...........3/8” 2022DG .........11/16”
2014DG ..........7/16” 2024DG ...........3/4”
2016DG ...........1/2” 2026DG .........13/16”
2018DG ..........9/16” 2028DG ...........7/8”
2020DG ...........5/8” 2030DG .........15/16”
On a Metal Clip Rail 2032DG ............. 1”
12 piece set contents:
2010MDG ........10mm 2016MDG ........16mm
2011MDG ........11mm 2017MDG ........17mm
2012MDG ........12mm 2018MDG ........18mm
2013MDG ........13mm 2019MDG ........19mm
2014MDG ........14mm 2020MDG ........20mm
2015MDG ........15mm 2021MDG ........21mm
On a Metal Clip Rail
52
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 55
1/2” Drive 8-Point Standard Length Impact Sockets
No. 1311S
1/2
” Drive 8-Point Standard Length Fractional Socket Set
Set contains eleven (11) 8-point standard length sockets packaged in a molded case for easy transportation and
storage. These sockets are commonly referred to as double-square or railroad sockets. Available individually below.
11 piece set contents:
2516S ............1/2” 2528S ............ 7/8”
2518S ...........9/16” 2530S .......... 15/16”
2520S ............5/8” 2532S .............. 1”
2522S ..........11/16” 2534S ..........1-1/16”
2524S ............3/4” 2536S ...........1-1/8”
2526S ..........13/16” Molded Storage Case
1/2” Drive 8-Point - Standard Length - Fractional Sizes
Item 8-Point
Number Size
Length
E
Hex
Depth
SHAPE I
SHAPE II
Socket End
D
Drive End
SHAPE III
B
A
Bolt Clearance
Depth
C
2516S
2518S
2520S
2522S
2524S
2526S
2528S
2530S
2532S
2534S
2536S
1/2” II .94 .94 .83 .35 1.50
9/16” II 1.02 1.02 .83 .43 1.50
5/8” II 1.10 1.10 .83 .43 1.50
11/16” II 1.18 1.18 .83 .43 1.50
3/4” II 1.34 1.34 .91 .51 1.57
13/16” II 1.42 1.42 .91 .59 1.57
7/8” II 1.50 1.50 .91 .59 1.57
15/16” III 1.50 1.65 1.10 .71 1.77
1” III 1.50 1.73 1.10 .71 1.77
1-1/16” II 1.83 1.83 1.30 .75 1.97
1-1/8” II 1.93 1.93 1.30 .75 1.97
Dimensions (Inches)
Shape
A B C D E
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
53
Page 56
1/2” Drive 8-Point Deep Length Impact Sockets
No. 1311SD
1/2
” Drive 8-Point Deep Length Fractional Socket Set
Set contains eleven (11) 8-point deep length sockets packaged in a molded case for easy
transportation and storage. These sockets are commonly referred to as double-square or
railroad sockets. Available individually below.
11 piece set contents:
2516SD ........... 1/2” 2528SD ........... 7/8”
2518SD .......... 9/16” 2530SD ......... 15/16”
2520SD ........... 5/8” 2532SD ............. 1”
2522SD ......... 11/16” 2534SD .........1-1/16”
2524SD ........... 3/4” 2536SD ..........1-1/8”
2526SD ......... 13/16” Molded Storage Case
54
1/2” Drive 8-Point - Deep Length - Fractional Sizes
Item 8-Point
Number Size Shape A B C D E
2516SD
2518SD
2520SD
2522SD
2524SD
2526SD
2528SD
2530SD
2532SD
2534SD
2536SD
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
1/2” II .94 .94 2.60 .35 3.27
9/16” II 1.02 1.02 2.60 .43 3.27
5/8” II 1.10 1.10 2.60 .43 3.27
11/16” II 1.18 1.18 2.60 .43 3.27
3/4” II 1.34 1.34 2.60 .51 3.27
13/16” II 1.42 1.42 2.60 .59 3.27
7/8” II 1.50 1.50 2.87 .59 3.54
15/16” III 1.50 1.65 2.87 .71 3.54
1” III 1.50 1.73 2.87 .71 3.54
1-1/16” III 1.83 1.83 2.87 .75 3.54
1-1/8” III 1.93 1.93 2.87 .75 3.54
Dimensions (Inches)
Page 57
1/2” Drive Pipe Plug Impact Sockets
No. 1308P
1/2
” Drive Pipe Plug Socket Set
8 piece set contents:
Male Sizes
2008PP ...........1/4” 2014PP .......... 7/16”
2009PP ..........9/32” 2016PP ........... 1/2”
2010PP ..........5/16” 2018PP .......... 9/16”
2012PP ...........3/8” 2020PP ........... 5/8”
Molded Storage Case
1/2
” Drive Individual Male Pipe Plug Sockets
Item Male
Number Size
2008PP
2009PP
2010PP
2012PP
2014PP
2016PP
2018PP
2020PP
3/8” .98 .32 1.50
9/16” 1.02 .32 1.50
9/32” .98 .32 1.50
5/16” .98 .32 1.50
7/16” .98 .32 1.50
Dimensions (Inches)
A B E
1/4” .98 .32 1.50
1/2” .98 .32 1.50
5/8” 1.14 .32 1.50
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
55
2
Page 58
1/2” Drive Axle/Spindle Nut Impact Sockets
No. 1705SN 1/2” Drive Axle/Spindle Nut Socket Set
This set contains five (5) popular axle/spindle nut impact socket sizes. Packaged in a convenient molded case.
5 piece set contents:
2730MD ....30mm Deep 2735MD. . . . . 35mm Deep
2732MD ....32mm Deep 2736MD. . . . . 36mm Deep
2734MD ....34mm Deep Molded Storage Case
1/2” Drive Axle/Spindle Nut Impact Sockets
These sockets are designed specifically to remove axle/spindle nuts on passenger and light trucks and
are of a heavy duty design. They are also useful in any application that requires a heavy duty socket.
Item Hex
Number Size A B C D E
2730MD
2732MD
2734MD
2735MD
2736MD
30mm 43 43 72 21.5 89
32mm 43 45 72 21.5 89
34mm 43 48 72 21.5 89
35mm 43 50 72 21.5 89
36mm 43 52 72 21.5 89
Dimensions (Millimeters)
56
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 59
1/2” Drive 12-Point Axle/Spindle Nut Impact Sockets
No. 1708SN 1/2” Drive - 12 Point - Axle/Spindle Nut Socket Set
This set contains eight (8) popular 12 point axle/spindle nut impact socket sizes. Fits axle nuts on Toyota
Tundra, Sequoia, Tacoma and Lexus LX570 as well as most other vehicles. Packaged in a convenient
molded case with handle.
8 piece set contents:
2129MD ....29mm Deep
2130MD ....30mm Deep
2132MD ....32mm Deep
2134MD ....34mm Deep
2135MD ....35mm Deep
2136MD ....36mm Deep
2138MD ....38mm Deep
2139MD ....39mm Deep
Molded Storage Case
1/2” Drive - 12 Point -
Axle/Spindle Nut Impact Sockets
These sockets are specifically designed to remove Axle/Spindle nuts on passenger cars and light trucks.
Item 12-Point
Number Size A B C D E
2129MD
2130MD
2132MD
2134MD
2135MD
2136MD
2138MD
2139MD
Dimensions (Millimeters)
29mm 38 40 73 24 90
30mm 38 42 73 24 90
32mm 38 44 73 24 90
34mm 38 46 73 36 90
35mm 38 48.5 73 36 90
36mm 38 48.5 73 36 90
38mm 38 52.5 73 36 90
39mm 44 54.5 76 36 93
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
57
2
Page 60
1/2” Drive Wheel Service Impact Sockets
1/2” Drive Extra-Thin Wall “Flip” Sockets
Unique hex opening on each end so that a single socket can accommodate
two hex sizes. Extra-thin wall design for easy access to recessed wheel nuts.
*
2146DT
*
2192DT
*Extra-Thin Wall Impact Sockets are not covered by the GP Warranty.
3/4” x 13/16” 1.10 1.02 .59 .87 2.99
19mm x 21mm 1.10 1.02 .59 .87 2.99
No. 1504FW 1/2” Drive Thin Wall “Flip” Socket Set
A set of four (4) thin wall “flip” style impact sockets that have two different
hex sizes in each socket. Sockets are designed for auto and light truck wheel
fasteners. Use with 1/2” drive extended shank impact tools or regular shank
impact tools with an extension.
1/2” Drive Thin Wall “Flip” Sockets
Hex
Dimensions (Inches)
Size A B C D E
4 piece set contents:
2346D .....3/4” x 13/16” 2349D .....7/8” x 15/16”
2392D ....19mm x 21mm 2351D ...... 1” x 1-1/16”
All items in this set carry the GP Lifetime Warranty.
Plastic Tray
58
Unique hex opening on each end so that a single socket can accommodate
two hex sizes. Thin wall design to fit most recessed wheel nuts.
Dimensions (Inches)
No. 2189D
1/2
Item Hex
Number Size A B C D E
2346D
2392D
2349D
2351D
3/4” x 13/16” 1.18 .91 .59 .87 2.99
19mm x 21mm 1.18 1.10 .59 .87 2.99
7/8” x 15/16” 1.34 1.26 1.00 1.20 3.27
1” x 1-1/16” 1.50 1.42 1.00 1.20 3.27
GP Lifetime Warranty
” Drive Damaged Nut “Flip” Socket
This “flip” style socket features 18.5mm hex on one end and 19.5mm hex on the other. It is designed
to remove 19mm lug nuts with missing or distorted caps found on GM or Chrysler vehicles.
Features include:
• 18.5mm side fits 19mm lug nuts with missing chrome covers.
• 19.5mm side fits 19mm lug nuts with damaged or distorted caps.
• “Flip” design is for use with extended anvil impact
wrenches or with an extension.
• GP Lifetime Warranty
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 61
1/2” Drive Extra-Thin Wall Wheel Service Impact Sockets
1500DW* 1/2” Drive Extra-Thin Wall Set For Wheel Service
Twelve (12) - 1/2” drive extra-thin wall designed deep fractional and metric impact sockets.
The extra-thin wall design allows easy access to recessed wheel nuts where space is limited.
EXTRA
THINWALL
Due to the extra-thin wall design, they should only be used on wheel nuts where limited torque
is applied. For use only with 1/2” drive tools. DO NOT use reducing adapters.
12 piece set contents:
2024DT ..........3/4” T.W. 2017MDT ....... 17mm T.W.
2026DT ........13/16” T.W. 2019MDT ....... 19mm T.W.
2028DT ..........7/8” T.W. 2021MDT ....... 21mm T.W.
2032DT ...........1” T.W. 2022MDT ....... 22mm T.W.
2034DT .......1-1/16” T.W. 2023MDT ....... 23mm T.W.
2146DT .. 3/4” x 13/16” T.W. 2192DT . .19mm x 21mm T.W.
*Extra-Thin Wall Impact Sockets are not covered by the GP Warranty.
Molded Storage Case
1/2” Drive Extra-Thin Wall Sockets
EXTRA
THINWALL
These extra-thin wall deep impact sockets are designed to allow easy access to recessed
wheel nuts where space is limited. Due to the extra-thin wall design, they should be used
only on passenger and light truck wheel nuts. Use Only with 1/2” Drive Tools. DO NOT use
with reducing adapters.
Item Hex
Number Size A B C D E
Dimensions (Inches)
Fractional Sizes
*
2024DT
*
2026DT
*
2028DT
*
2030DT
*
2032DT
*
2034DT
3/4” 1.02 1.02 2.40 .75 3.07
13/16” 1.10 1.10 2.40 .94 3.07
7/8” 1.18 1.18 2.40 .94 3.07
15/16” 1.26 1.26 2.40 .94 3.07
1” 1.34 1.34 2.40 .94 3.07
1-1/16” 1.42 1.42 2.40 .94 3.07
Metric Sizes
*
2017MDT
*
2019MDT
*
2021MDT
*
2022MDT
*
2023MDT
*Extra-Thin Wall Impact Sockets are not covered by the GP Warranty.
17mm .95 .95 1.58 .67 3.07
19mm 1.02 1.02 1.58 .75 3.07
21mm 1.10 1.10 1.58 .95 3.07
22mm 1.16 1.16 1.58 .95 3.07
23mm 1.20 1.20 1.58 .95 3.07
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
59
Page 62
1/2” Drive Wheel/Nut Protector Impact Sockets
1/2
” Drive Extra-Thin Wall Wheel/Nut Protector Sockets
These unique extra-thin wall impact sockets are for use on alloy wheels with decorative lug nuts. They feature
protective (color-coded) plastic sleeves and internal plastic inserts to prevent damage to expensive alloy wheels and
decorative lug nuts. They should be used only on passenger and light truck wheel nuts. USE ONLY WITH 1/2” DRIVE
AIR TOOLS. DO NOT USE REDUCING ADAPTERS. Available individually or in Sets below.
No. 1511TP* 1/2
Item Hex Sleeve
Number Size Color A B C D E F
Fractional Sizes
*
2024TP
*
2026TP
*
2028TP
*
2030TP
*
2032TP
*
2034TP
Metric Sizes
*
2017MTP
*
2019MTP
*
2021MTP
*
2022MTP
*
2023MTP
*Extra-Thin Wall Impact Sockets are not covered by the GP Warranty.
1-1/16” Light Green 1.50 1.42 1.42 .91 1.75 3.07
3/4” Yellow 1.10 1.02 1.10 .71 1.75 3.15
13/16” Dark Green 1.18 1.10 1.18 .91 1.75 3.15
7/8” Purple 1.26 1.18 1.26 .91 1.75 3.15
15/16” Tan 1.34 1.26 1.26 .91 1.75 3.07
1” Light Blue 1.42 1.34 1.34 .91 1.75 3.07
17mm Red 1.02 .95 1.02 .63 1.75 3.15
19mm Dark Blue 1.10 1.02 1.10 .71 1.75 3.15
21mm Gray 1.18 1.10 1.18 .91 1.75 3.15
22mm Orange 1.26 1.16 1.24 .91 1.75 3.15
23mm Brown 1.26 1.20 1.28 .91 1.75 3.15
” Drive Extra-Thin Wall Wheel/Nut Protector Socket Set
11 piece set contents:
2024TP ......... 3/4” 2017MTP ...... 17mm
2026TP ....... 13/16” 2019MTP ...... 19mm
2028TP ......... 7/8” 2021MTP ...... 21mm
2030TP ....... 15/16” 2022MTP ...... 22mm
2032TP .......... 1” 2023MTP ...... 23mm
2034TP ...... 1-1/16” Molded Storage Case
*Extra-Thin Wall Impact Sockets are not covered by GP Warranty.
Dimensions (Inches)
(All Impact Sockets listed above)
60
No. 1505TP* 1/2
” Drive Extra-Thin Wall Wheel/Nut Protector Socket Set
Set includes five (5) of the most popular fractional sizes listed above:
5 piece set contents:
3/4”, 13/16”, 7/8”, 1” & 1-1/16”
Molded Storage Case
*Extra-Thin Wall Impact Sockets are not covered by GP Warranty.
No. 1503TP* 1/2
” Drive Extra-Thin Wall Wheel/Nut Protector Socket Set
Set includes three (3) of the most popular metric sizes listed above:
3 piece set contents:
17mm, 19mm, 21mm
Molded Storage Case
*Extra-Thin Wall Impact Sockets are not covered by GP Warranty.
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 63
1/2” Drive Standard Length Impact Sockets
1/2” Drive - Standard Length - Fractional Sizes
ANSI Specifications B107.2
Item Hex
Number Size Shape A B C D E
2010R
5/16” I .87 .59 .83 .35 1.50
2012R
3/8” I .87 .63 .83 .47 1.50
2014R
7/16” I .87 .71 .83 .47 1.50
2016R
1/2” I .87 .79 .83 .47 1.50
2018R
9/16” I .94 .87 .83 .47 1.50
2020R
5/8” II .98 .98 .83 .47 1.50
2022R
11/16” II 1.02 1.02 .83 .51 1.50
2024R
3/4” II 1.10 1.10 .83 .51 1.50
2026R
13/16” II 1.18 1.18 .83 .55 1.50
2028R
7/8” II 1.26 1.26 .83 .59 1.50
2030R
15/16” II 1.34 1.34 .83 .59 1.50
2032R
1” II 1.42 1.42 .83 .59 1.50
2034R
1-1/16” II 1.50 1.50 .91 .67 1.57
2036R
1-1/8” III 1.50 1.57 .91 .67 1.57
2038R
1-3/16” III 1.50 1.65 .91 .67 1.57
2040R
1-1/4” III 1.50 1.73 .91 .67 1.57
2042R
1-5/16” III 1.50 1.77 1.02 .75 1.69
2044R
1-3/8” III 1.50 1.91 1.30 .94 1.97
2046R
1-7/16” III 1.50 1.99 1.30 .94 1.97
2048R
1-1/2” III 1.50 2.07 1.30 .94 1.97
2050R
1-9/16” III 1.73 2.20 1.69 .94 2.36
2052R
1-5/8” III 1.73 2.30 1.69 1.06 2.36
2054R
1-11/16” III 1.73 2.40 1.69 1.06 2.36
2056R
1-3/4” III 1.73 2.48 1.69 1.06 2.36
2058R
1-13/16” III 1.73 2.56 2.09 1.18 2.76
2060R
1-7/8” III 1.73 2.66 2.09 1.18 2.76
2062R
1-15/16” III 1.73 2.72 2.09 1.18 2.76
2064R
2” III 2.05 2.80 2.09 1.26 2.76
2066R
2-1/16” III 2.05 2.85 2.09 1.26 2.76
2068R
2-1/8” III 2.05 2.95 2.09 1.26 2.76
2070R
2-3/16” III 2.05 3.01 2.09 1.38 2.76
2072R
2-1/4” III 2.05 3.07 2.09 1.38 2.76
Dimensions (Inches)
Standard Length - Metric Sizes
Item Hex
Number Size Shape A B C D E
2008M
8mm I 22 15.0 21 9 38
2009M
9mm I 22 15.0 21 12 38
2010M
10mm I 22 17.0 21 12 38
2011M
11mm I 22 19.0 21 12 38
2012M
12mm I 22 19.0 21 12 38
2013M
13mm I 24 20.0 21 12 38
2014M
14mm I 24 22.0 21 12 38
2015M
15mm I 25 23.0 21 12 38
2016M
16mm II 25 25.0 21 12 38
2017M
17mm II 26 26.0 21 13 38
2018M
18mm II 26 26.0 21 13 38
2019M
19mm II 28 28.0 21 13 38
2020M
20mm II 30 30.0 21 13 38
2021M
21mm II 30 30.0 21 13 38
2022M
22mm II 32 32.0 21 13 38
2023M
23mm II 32 32.0 21 13 38
2024M
24mm II 34 34.0 21 13 38
2025M
25mm II 36 36.0 21 14 38
2026M
26mm II 36 36.0 21 14 38
2027M
27mm II 38 38.0 23 17 40
2028M
28mm III 38 40.0 23 17 40
2029M
29mm III 38 40.0 23 17 40
2030M
30mm III 38 42.0 23 17 40
2032M
32mm III 38 44.0 23 17 40
2033M
33mm III 38 45.0 26 19 43
2034M
34mm III 38 46.0 33 24 50
2035M
35mm III 38 48.5 33 24 50
2036M
36mm III 38 48.5 33 24 50
Dimensions (Millimeters)
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
61
Page 64
1/2” Drive Deep Length Impact Sockets
1/2” Drive - Deep Length - Fractional Sizes
Item Hex
Number Size Shape A B C D E
2010D
2012D
2014D
2016D
2018D
2020D
2022D
2024D
2026D
2028D
2030D
2032D
2034D
2036D
2038D
2040D
*
2040HD
2042D
2044D
2046D
2048D
2050D
2052D
2054D
ANSI Specifications B107.2
2056D
2058D
2060D
2062D
2064D
2066D
2068D
2070D
2072D
*For Heavy Duty Wheel Service Work
Dimensions (Inches)
5/16” I .87 .59 2.65 .51 3.27
3/8” I .87 .63 2.65 .55 3.27
7/16” I .87 .71 2.65 .55 3.27
1/2” I .87 .79 2.65 .55 3.27
9/16” I .94 .87 2.65 .95 3.27
5/8” II .94 .94 2.65 .95 3.27
11/16” II 1.02 1.02 2.65 .95 3.27
3/4” II 1.10 1.10 2.65 .95 3.27
13/16” II 1.18 1.18 2.65 .95 3.27
7/8” II 1.26 1.26 2.92 .95 3.54
15/16” II 1.34 1.34 2.92 .95 3.54
1” II 1.42 1.42 2.92 .95 3.54
1-1/16” II 1.50 1.50 2.92 .95 3.54
1-1/8” III 1.50 1.57 2.92 .95 3.54
1-3/16” III 1.50 1.73 2.92 .95 3.54
1-1/4” III 1.50 1.73 2.92 .95 3.54
1-1/4” III 1.50 1.85 2.68 1.22 3.35
1-5/16” III 1.50 1.77 2.92 1.35 3.54
1-3/8” III 1.50 1.91 2.92 1.35 3.54
1-7/16” III 1.50 1.99 2.92 1.35 3.54
1-1/2” III 1.50 2.07 2.92 1.45 3.54
1-9/16” III 1.73 2.20 3.03 2.28 3.66
1-5/8” III 1.73 2.30 3.03 2.28 3.66
1-11/16” III 1.73 2.40 3.03 2.28 3.66
1-3/4” III 1.73 2.48 3.03 2.28 3.66
1-13/16” III 1.73 2.56 3.03 2.28 3.66
1-7/8” III 1.73 2.66 3.03 2.28 3.66
1-15/16” III 1.73 2.72 3.03 2.28 3.66
2” III 2.05 2.80 3.03 2.28 3.66
2-1/16” III 2.05 2.85 3.03 2.28 3.66
2-1/8” III 2.05 2.95 3.03 2.28 3.66
2-3/16” III 2.05 3.01 3.03 2.28 3.66
2-1/4” III 2.05 3.07 3.03 2.28 3.66
Deep Length - Metric Sizes
Item Hex
Number Size Shape A B C D E
2008MD
2009MD
2010MD
2011MD
2012MD
2013MD
2014MD
2015MD
2016MD
2017MD
2018MD
2019MD
2020MD
2021MD
2022MD
2023MD
2024MD
2025MD
2026MD
2027MD
2028MD
2029MD
2030MD
2032MD
2033MD
2034MD
2035MD
2036MD
8mm I 22 15.0 66 14 83
9mm I 22 15.0 66 14 83
10mm I 22 17.0 66 14 83
11mm I 22 18.0 66 14 83
12mm I 22 19.0 66 14 83
13mm I 24 20.0 66 14 83
14mm I 24 22.0 66 24 83
15mm II 24 24.0 66 24 83
16mm II 26 24.0 66 24 83
17mm II 26 26.0 66 24 83
18mm II 26 26.0 66 24 83
19mm II 28 28.0 66 24 83
20mm II 30 30.0 66 24 83
21mm II 30 30.0 66 24 83
22mm II 32 32.0 73 24 90
23mm II 32 32.0 73 24 90
24mm II 34 34.0 73 24 90
25mm II 36 36.0 73 24 90
26mm II 36 36.0 73 24 90
27mm II 38 38.0 73 24 90
28mm III 38 40.0 73 24 90
29mm III 38 40.0 73 24 90
30mm III 38 42.0 73 24 90
32mm III 38 44.0 73 24 90
33mm III 38 45.0 73 34 90
34mm III 38 46.0 73 34 90
35mm III 38 48.5 73 34 90
36mm III 38 48.5 73 34 90
Dimensions (Millimeters)
62
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 65
1/2” Drive 12-Point Standard Length Impact Sockets
1/2” Drive 12-Point - Standard Length - Fractional Sizes
Item 12-Point
Number Size Shape A B C D E
2112R
2114R
2116R
2118R
2120R
2122R
2124R
2126R
2128R
2130R
2132R
2134R
2136R
2138R
2140R
2142R
2144R
2146R
2148R
ANSI Specifications B107.2
3/8” I .94 .63 .83 .47 1.50
7/16” I .94 .71 .83 .47 1.50
1/2” I .94 .79 .83 .47 1.50
9/16” I .94 .87 .83 .47 1.50
5/8” I .94 .94 .83 .47 1.50
11/16” II .94 1.02 .83 .51 1.50
3/4” II 1.02 1.10 .83 .51 1.50
13/16” II 1.10 1.18 .83 .55 1.50
7/8” II 1.18 1.26 .83 .59 1.50
15/16” II 1.26 1.34 1.10 .79 1.77
1” II 1.34 1.42 1.10 .79 1.77
1-1/16” II 1.42 1.50 1.30 .94 1.97
1-1/8” III 1.50 1.56 1.30 .94 1.97
1-3/16” III 1.50 1.64 1.30 .94 1.97
1-1/4” III 1.50 1.72 1.30 .94 1.97
1-5/16” III 1.50 1.75 1.30 .94 1.97
1-3/8” III 1.50 1.84 1.30 .94 1.97
1-7/16” III 1.50 1.90 1.30 .94 1.97
1-1/2” III 1.50 1.98 1.30 .94 1.97
Dimensions (Inches)
Standard Length - Metric Sizes
Item 12-Point
Number Size Shape A B C D E
2110M
2111M
2112M
2113M
2114M
2115M
2116M
2117M
2118M
2119M
2120M
2121M
2122M
2123M
2124M
2125M
2126M
2127M
2128M
2129M
2130M
2132M
2133M
2134M
2135M
2136M
10mm I 17 21 12 38
11mm I 24 18 21 12 38
12mm I 24 19 21 12 38
13mm I 24 20 21 12 38
14mm I 24 22 21 12 38
15mm II 24 24 21 12 38
16mm II 24 24 21 12 38
17mm II 26 26 21 13 38
18mm II 26 26 21 13 38
19mm II 28 28 21 13 38
20mm II 30 30 21 14 38
21mm II 30 30 21 14 38
22mm II 32 32 21 15 38
23mm II 32 32 21 15 38
24mm II 34 34 28 20 45
25mm II 36 36 28 20 45
26mm II 36 36 33 24 50
27mm II 38 38 33 24 50
28mm III 38 40 33 24 50
29mm III 38 40 33 24 50
30mm III 38 42 33 24 50
32mm III 38 44 33 24 50
33mm III 38 45 33 24 50
34mm III 38 46 33 24 50
35mm III 38 47 33 24 50
36mm III 38 48 33 24 50
Dimensions (Millimeters)
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
63
Page 66
1/2” Drive 12-Point Deep Length Impact Sockets
1/2” Drive 12-Point - Deep Length - Fractional Sizes
Item 12-Point
Number Size Shape A B C D E
2112D
2114D
2116D
2118D
2120D
2122D
2124D
2126D
2128D
2130D
2132D
2134D
2136D
2138D
2140D
2142D
2144D
2146D
2148D
ANSI Specifications B107.2
I .87 .63 2.60 .55 3.27
7/16” I .87 .71 2.60 .55 3.27
1/2” I .87 .79 2.60 .55 3.27
9/16” I .94 .87 2.60 .94 3.27
5/8” II .94 .94 2.60 .94 3.27
11/16” II 1.02 1.02 2.60 .94 3.27
3/4” II 1.10 1.10 2.60 .94 3.27
13/16” II 1.18 1.18 2.60 .94 3.27
7/8” II 1.26 1.26 2.87 .94 3.54
15/16” II 1.34 1.34 2.87 .94 3.54
1” II 1.42 1.42 2.87 .94 3.54
1-1/16” II 1.50 1.50 2.87 .94 3.54
1-1/8” III 1.50 1.57 2.87 .94 3.54
1-3/16” III 1.50 1.65 2.87 .94 3.54
1-1/4” III 1.50 1.73 2.87 .94 3.54
1-5/16” III 1.50 1.77 2.87 .94 3.54
1-3/8” III 1.50 1.91 2.87 .94 3.54
1-7/16” III 1.50 1.99 2.87 .94 3.54
1-1/2” III 1.50 2.07 2.87 .94 3.54
Dimensions (Inches)
Deep Length - Metric Sizes
Item 12-Point
Number Size Shape A B C D E
2110MD
2111MD
2112MD
2113MD
2114MD
2115MD
2116MD
2117MD
2118MD
2119MD
2120MD
2121MD
2122MD
2123MD
2124MD
2125MD
2126MD
2127MD
2128MD
2129MD
2130MD
2132MD
2133MD
2134MD
2135MD
2136MD
2138MD
2139MD
10mm I 22 17.0 66 14 83
11mm I 22 18.0 66 14 83
12mm I 22 19.0 66 14 83
13mm I 24 20.0 66 14 83
14mm I 24 22.0 66 24 83
15mm II 24 24.0 66 24 83
16mm II 24 24.0 66 24 83
17mm II 26 26.0 66 24 83
18mm II 26 26.0 66 24 83
19mm II 28 28.0 66 24 83
20mm II 30 30.0 66 24 83
21mm II 30 30.0 66 24 83
22mm II 32 32.0 73 24 90
23mm II 32 32.0 73 24 90
24mm II 34 34.0 73 24 90
25mm II 36 36.0 73 24 90
26mm II 36 36.0 73 24 90
27mm II 38 38.0 73 24 90
28mm III 38 40.0 73 24 90
29mm III 38 40.0 73 24 90
30mm III 38 42.0 73 24 90
32mm III 38 44.0 73 24 90
33mm III 38 45.0 73 36 90
34mm III 38 46.0 73 36 90
35mm III 38 48.5 73 36 90
36mm III 38 48.5 73 36 90
38mm III 38 52.5 73 36 90
39mm III 44 54.5 76 36 93
Dimensions (Millimeters)
64
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 67
1/2” Drive Standard Length Universal Impact Sockets
1/2” Drive - Standard Length Universal - Fractional Sizes
Item Hex
Number Size A B C D E
2012U
2014U
2016U
2018U
2020U
2022U
2024U
2026U
2028U
2030U
2032U
2034U
2036U
2038U
2040U
ANSI Specifications B107.2
3/8” 1.10 .59 .63 .51 2.56
7/16” 1.10 .67 .63 .51 2.56
1/2” 1.10 .75 .63 .51 2.56
9/16” 1.10 .87 .63 .51 2.56
5/8” 1.10 .91 .63 .51 2.56
11/16” 1.26 1.02 .63 .51 2.56
3/4” 1.26 1.10 .63 .51 2.56
13/16” 1.26 1.18 .63 .51 2.56
7/8” 1.26 1.26 .63 .51 2.56
15/16” 1.26 1.34 .63 .51 2.56
1” 1.26 1.42 .63 .51 2.56
1-1/16” 1.26 1.50 .63 .51 2.56
1-1/8” 1.26 1.57 .71 .51 2.76
1-3/16” 1.26 1.65 .79 .51 2.83
1-1/4” 1.26 1.73 .79 .40 2.83
Dimensions (Inches)
Standard Length - Metric Sizes
Item Hex
Number Size A B C D E
2010UM
2011UM
2012UM
2013UM
2014UM
2015UM
2016UM
2017UM
2018UM
2019UM
2020UM
2021UM
2022UM
2023UM
2024UM
10mm 28 15 16 13 65
11mm 28 17 16 13 65
12mm 28 19 16 13 65
13mm 28 20 16 13 65
14mm 28 22 16 13 65
15mm 28 23 16 13 65
16mm 28 23 16 13 65
17mm 32 26 16 13 65
18mm 32 26 16 13 65
19mm 32 28 16 13 65
20mm 32 30 16 13 65
21mm 32 30 16 13 65
22mm 32 32 16 13 65
23mm 32 32 16 13 65
24mm 32 34 16 13 65
Dimensions (Millimeters)
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
65
Page 68
1/2” Drive Deep Length Universal Impact Sockets
1/2” Drive - Deep Length Universal - Fractional Sizes
Item Hex
Number Size A B C D E
2012UD
2014UD
2016UD
2018UD
2020UD
2022UD
2024UD
2026UD
2028UD
2030UD
2032UD
2034UD
2036UD
2038UD
2040UD
ANSI Specifications B107.2
3/8” 1.10 .59 1.57 .55 3.54
7/16” 1.10 .67 1.57 .79 3.54
1/2” 1.10 .75 1.57 .79 3.54
9/16” 1.10 .87 1.57 .79 3.54
5/8” 1.10 .91 1.57 .79 3.54
11/16” 1.26 1.02 1.57 .79 3.54
3/4” 1.26 1.10 1.57 .98 3.54
13/16” 1.26 1.18 1.57 .98 3.54
7/8” 1.26 1.26 1.57 .98 3.54
15/16” 1.26 1.34 1.57 .98 3.54
1” 1.26 1.42 1.57 .98 3.54
1-1/16” 1.26 1.50 1.57 .98 3.54
1-1/8” 1.26 1.57 1.57 .98 3.54
1-3/16” 1.26 1.65 1.57 .98 3.54
1-1/4” 1.26 1.73 1.57 .98 3.54
Dimensions (Inches)
Deep Length - Metric Sizes
Item Hex
Number Size A B C D E
2010UMD
2011UMD
2012UMD
2013UMD
2014UMD
2015UMD
2016UMD
2017UMD
2018UMD
2019UMD
2020UMD
2021UMD
2022UMD
2023UMD
2024UMD
10mm
11mm
12mm
13mm
14mm
15mm
16mm
17mm
18mm
19mm
20mm
21mm
22mm
23mm
24mm
28 15 40 14 90
28 17 40 20 90
28 19 40 20 90
28 20 40 20 90
28 22 40 20 90
28 23 40 20 90
28 23 40 20 90
32 26 40 20 90
32 26 40 20 90
32 28 40 25 90
32 30 40 25 90
32 30 40 25 90
32 32 40 25 90
32 32 40 25 90
32 34 40 25 90
Dimensions (Millimeters)
66
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 69
1/2” Drive 12-Point Standard Length Universal Impact Sockets
1/2” Drive 12-Point - Standard Length Universal - Fractional Sizes
Item 12-Point
Number Size A B C D E
2114U
2116U
2118U
2120U
2122U
2124U
2126U
2128U
2130U
2132U
2134U
2136U
2138U
2140U
ANSI Specifications B107.2
7/16” 1.10 .67 .63 .51 2.56
1/2” 1.10 .75 .63 .51 2.56
9/16” 1.10 .83 .63 .51 2.56
5/8” 1.10 .91 .63 .51 2.56
11/16” 1.26 1.02 .63 .51 2.56
3/4” 1.26 1.10 .63 .51 2.56
13/16” 1.26 1.18 .63 .51 2.56
7/8” 1.26 1.26 .63 .51 2.56
15/16” 1.26 1.34 .63 .51 2.56
1” 1.26 1.42 .63 .51 2.56
1-1/16” 1.26 1.50 .63 .51 2.56
1-1/8” 1.26 1.57 .83 .71 2.76
1-3/16” 1.26 1.65 .91 .79 2.83
1-1/4” 1.26 1.73 .91 .79 2.83
Dimensions (Inches)
Standard Length - Metric Sizes
Item 12-Point
Number Size A B C D E
2110UM
2111UM
2112UM
2113UM
2114UM
2115UM
2116UM
2117UM
2118UM
2119UM
2120UM
2121UM
2122UM
2123UM
2124UM
10mm 28 15 16 13 65
11mm 28 17 16 13 65
12mm 28 19 16 13 65
13mm 28 20 16 13 65
14mm 28 22 16 13 65
15mm 28 23 16 13 65
16mm 28 23 16 13 65
17mm 32 26 16 13 65
18mm 32 26 16 13 65
19mm 32 28 16 13 65
20mm 32 30 16 13 65
21mm 32 30 16 13 65
22mm 32 32 16 13 65
23mm 32 32 16 13 65
24mm 32 34 16 13 65
Dimensions (Millimeters)
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
2
67
Page 70
1/2” Drive Standard Length Magnetic Impact Sockets
1/2” Drive Magnetic - Standard Length - Fractional Sizes
Item Hex
Number Size
2012RG
2014RG
2016RG
2018RG
2020RG
2022RG
2024RG
2026RG
2028RG
2030RG
2032RG
3/8” I .99 .69 .16 1.50
7/16” I .99 .75 .20 1.50
1/2” I .99 .83 .20 1.50
9/16” I .99 .91 .24 1.50
5/8” I 1.18 .98 .24 1.50
11/16” I 1.18 1.06 .24 1.50
3/4” I 1.18 1.14 .28 1.50
13/16” III 1.18 1.22 .31 1.50
7/8” III 1.18 1.30 .31 1.50
15/16” III 1.18 1.38 .39 1.77
1” III 1.18 1.46 .39 1.77
Dimensions (Inches)
Shape
A B D E
Standard Length - Metric Sizes
Item Hex
Number Size
2010MG
2011MG
2012MG
2013MG
2014MG
2015MG
2016MG
2017MG
2018MG
2019MG
2020MG
2021MG
10
mm I 25 17.5 4 38
11
mm I 25 18.7 5 38
12
mm I 25 20.0 5 38
13
mm I 25 21.0 5 38
14
mm I 25 22.5 6 38
15
mm I 30 23.7 6 38
16
mm I 30 25.0 6 38
17
mm I 30 26.5 6 38
18
mm I 30 27.5 7 38
19
mm I 30 29.0 7 38
20
mm II 30 30.0 7 38
21
mm III 30 31.0 8 38
Dimensions (Millimeters)
Shape
A B D E
68
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 71
1/2” Drive Deep Length Magnetic Impact Sockets
All deep magnetic sockets feature a spring loaded magnet that retracts into the socket for extended bolt applications.
1/2” Drive Magnetic - Deep Length - Fractional Sizes
Item Hex
Number Size
2012DG
2014DG
2016DG
2018DG
2020DG
2022DG
2024DG
2026DG
2028DG
2030DG
2032DG
3/8” I .98 .69 2.40 .20 3.07
7/16” I .98 .75 2.40 .20 3.07
1/2” I .98 .83 2.40 .24 3.07
9/16” I .98 .91 2.40 .28 3.07
5/8” I 1.18 .98 2.40 .28 3.07
11/16” I 1.18 1.06 2.40 .28 3.07
3/4” I 1.18 1.14 2.40 .31 3.07
13/16” III 1.18 1.22 2.40 .35 3.07
7/8” III 1.18 1.30 2.40 .35 3.07
15/16” III 1.18 1.38 2.40 .43 3.07
1” III 1.18 1.46 2.40 .43 3.07
Dimensions (Inches)
Shape
A B C D E
Deep Length - Metric Sizes
Item Hex
Number Size
2010MDG
2011MDG
2012MDG
2013MDG
2014MDG
2015MDG
2016MDG
2017MDG
2018MDG
2019MDG
2020MDG
2021MDG
10mm I 25 17.5 61 5 78
11mm I 25 18.7 61 5 78
12mm I 25 20.0 61 6 78
13mm I 25 21.0 61 6 78
14mm I 25 22.5 61 7 78
15mm I 30 23.7 61 7 78
16mm I 30 25.0 61 7 78
17mm I 30 26.5 61 7 78
18mm I 30 27.5 61 8 78
19mm I 30 29.0 61 8 78
20mm II 30 30.0 61 8 78
21mm III 30 31.0 61 9 78
Dimensions (Millimeters)
Shape
A B C D E
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
69
2
Page 72
1/2” Drive Impact Attachments
1/2
” Drive Adapters
E
1/2
” Drive Extra-Long Reducing Adapters
2257AL
Socket
Item Female Male Retention
Number End
*
2228A 1/2”
*
2228AL 1/2”
A
Extra-long impact socket reducing adapters, forged in a single piece for extra strength and durability.
2238A
2238AL
* Reducing Adapters are not covered by the GP Warranty.
* See page 179 for New Reducing Sleeve Adapters
2277AL
1/2”
1/2”
End Device A E
3/8”
Friction Ball .98 1.50
3/8”
Locking Pin .98 1.50
3/4”
Friction Ball 1.18 1.89
3/4”
Locking Pin 1.18 1.89
2267AL
Dimensions (Inches)
1/2
” Drive Universal Joints
2229UJ
(Standard)
2229TUJ
(Thin-Wall)
Item Overall Female Male Retention
Number Length
*
2257AL 18”
*
2267AL 24”
*
2277AL 36”
* Reducing Adapters are not covered by the GP Warranty.
End End Device A E
1/2”
3/8”
Locking Pin .98 18.11
1/2”
3/8”
Locking Pin .98 24.00
1/2”
3/8”
Locking Pin .98 36.00
Socket
Item Retention
Number Size Device A B E
2229UJ 1/2” x 1/2”
2229UJL 1/2” x 1/2”
*
2229TUJ 1/2” x 1/2”
* 2229TUJ is a thin-wall design that provides extra clearance in tight spaces.
Due to the thin wall design the #2229TUJ is not covered by the GP Warranty.
Friction Ball 1.26 1.32 2.36
Locking Pin 1.26 1.32 2.36
Friction Ball .93 1.00 2.36
Socket
Dimensions (Inches)
Dimensions (Inches)
70
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 73
1/2
” Drive Extensions
1/2” Drive Impact Attachments
Standard
Locking
Socket
Dimensions (Inches)
Item Retention
Number Description
Device A E
Standard Extensions
2243E 3” Extension
*
2243EH 3” H.D. Extension
2243EL
2245E
*
2245EH 5” H.D. Extension
2245EL
2247E
2247EL
2210E
2210EL
3” Extension
5” Extension
5” Extension
7” Extension
7” Extension
10” Extension
10” Extension
Friction Ball .98 2.95
Friction Ball 1.18 2.95
Locking Pin .98 2.95
Friction Ball .98 4.92
Friction Ball 1.18 4.92
Locking Pin .98 4.92
Friction Ball .98 6.89
Locking Pin .98 6.89
Friction Ball .98 9.84
Locking Pin .98 9.84
Extra-Long Extensions
E
A
2259EL
2269EL
2279EL
*Heavy Duty Extensions for severe service applications.
Locking Extensions
These locking extensions feature a positive locking ball and sliding collar for quick release
of sockets and accessories. Useful in hard to reach areas where a positive lock on the
socket is required.
2203QL
18” Extension
24” Extension
36” Extension
Locking Pin .98 18.11
Locking Pin .98 24.00
Locking Pin .98 36.00
NEW
3 pc. Locking Extension Set -
includes 3”, 7”, 12”
No. 2200
1/2
FB
Do NOT run the tool when the
socket is OFF the fastener.
2243QL
2247QL
2252QL
2259QL
2269QL
2279QL
3” Locking Extension .98 2.95
7” Locking Extension .98 6.89
12” Locking Extension .98 11.81
18” Locking Extension .98 18.11
24” Locking Extension .98 24.02
36” Locking Extension .98 35.43
” Drive Impact Adapter & Extension Set
6 piece set contents:
2228A* ..................1/2” F. x 3/8” M. Adapter
2238A ...................1/2” F. x 3/4” M. Adapter
2229UJ .................1/2” x 1/2” Universal Joint
2243E ............................ 3” Extension
2245E ............................ 5” Extension
2247E ............................ 7” Extension
All items use the Friction Ball Retainer.
*Reducing adapters are not covered by the GP Lifetime Warranty.
Socket Retention Device Key for 1/2” Drive Adapters, Extensions & Universal Joints
LP
Friction Ball
FB
A spring loaded steel ball that lines up with the socket
retainer hole. Use caution when using this system
because the socket is held in place only by spring
pressure on the steel ball.
LP
Locking Pin
Spring loaded pin, simply line up with socket retainer
hole and press pin. To release socket, insert object
through retainer hole and press pin.
Molded Storage Case
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
71
2
Page 74
3/4” Drive 6-Point Impact Socket Sets
No. 8029
No. 8029D
3/4
3/4
” Drive Standard Length Fractional Set
29 piece set contents:
3024R ..........3/4” 3044R ........1-3/8” 3064R .......... 2”
3026R ........13/16” 3046R .......1-7/16” 3066R ...... 2-1/16”
3028R ..........7/8” 3048R ........1-1/2” 3068R ....... 2-1/8”
3030R ........15/16” 3050R .......1-9/16” 3070R ...... 2-3/16”
3032R ...........1” 3052R ........1-5/8” 3072R ....... 2-1/4”
3034R .......1-1/16” 3054R ......1-11/16” 3074R ...... 2-5/16”
3036R ........1-1/8” 3056R ........1-3/4” 3076R ....... 2-3/8”
3038R .......1-3/16” 3058R ......1-13/16” 3078R ...... 2-7/16”
3040R ........1-1/4” 3060R ........1-7/8” 3080R ....... 2-1/2”
3042R .......1-5/16” 3062R ......1-15/16” Molded Storage Case
” Drive Deep Length Fractional Set
29 piece set contents:
3024D ..........3/4” 3044D ........1-3/8” 3064D .......... 2”
3026D ........13/16” 3046D .......1-7/16” 3066D ...... 2-1/16”
3028D ..........7/8” 3048D ........1-1/2” 3068D ....... 2-1/8”
3030D ........15/16” 3050D .......1-9/16” 3070D ...... 2-3/16”
3032D ...........1” 3052D ........1-5/8” 3072D ....... 2-1/4”
3034D .......1-1/16” 3054D ......1-11/16” 3074D ...... 2-5/16”
3036D ........1-1/8” 3056D ........1-3/4” 3076D ....... 2-3/8”
3038D .......1-3/16” 3058D ......1-13/16” 3078D ...... 2-7/16”
3040D ........1-1/4” 3060D ........1-7/8” 3080D ....... 2-1/2”
3042D .......1-5/16” 3062D ......1-15/16” Molded Storage Case
No. 8026M
No. 8026MD
3/4
3/4
” Drive Standard Length Metric Set
26 piece set contents:
3019M ........19mm 3028M .......28mm 3038M ....... 38mm
3020M ........20mm 3029M .......29mm 3040M ....... 40mm
3021M ........21mm 3030M .......30mm 3041M ....... 41mm
3022M ........22mm 3031M .......31mm 3042M ....... 42mm
3023M ........23mm 3032M .......32mm 3043M ....... 43mm
3024M ........24mm 3033M .......33mm 3044M ....... 44mm
3025M ........25mm 3034M .......34mm 3046M ....... 46mm
3026M ........26mm 3035M .......35mm 3050M ....... 50mm
3027M ........27mm 3036M .......36mm Metal Case
” Drive Deep Length Metric Set
26 piece set contents:
3019MD ......19mm 3028MD ......28mm 3038MD ...... 38mm
3020MD ......20mm 3029MD ......29mm 3040MD ...... 40mm
3021MD ......21mm 3030MD ......30mm 3041MD ...... 41mm
3022MD ......22mm 3031MD ......31mm 3042MD ...... 42mm
3023MD ......23mm 3032MD ......32mm 3043MD ...... 43mm
3024MD ......24mm 3033MD ......33mm 3044MD ...... 44mm
3025MD ......25mm 3034MD ......34mm 3046MD ...... 46mm
3026MD ......26mm 3035MD ......35mm 3050MD ...... 50mm
3027MD ......27mm 3036MD ......36mm Metal Case
72
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 75
3/4” Drive 12-Point Impact Socket Sets
No. 8129
No. 8129D
3/4
3/4
” Drive 12-Point Standard Length Fractional Set
29 piece set contents:
3124R ..........3/4” 3144R ........1-3/8” 3164R .......... 2”
3126R ........13/16” 3146R .......1-7/16” 3166R ...... 2-1/16”
3128R ..........7/8” 3148R ........1-1/2” 3168R ....... 2-1/8”
3130R ........15/16” 3150R .......1-9/16” 3170R ...... 2-3/16”
3132R ...........1” 3152R ........1-5/8” 3172R ....... 2-1/4”
3134R .......1-1/16” 3154R ......1-11/16” 3174R ...... 2-5/16”
3136R ........1-1/8” 3156R ........1-3/4” 3176R ....... 2-3/8”
3138R .......1-3/16” 3158R ......1-13/16” 3178R ...... 2-7/16”
3140R ........1-1/4” 3160R ........1-7/8” 3180R ....... 2-1/2”
3142R .......1-5/16” 3162R ......1-15/16” Metal Case
” Drive 12-Point Deep Length Fractional Set
29 piece set contents:
3124D ..........3/4” 3144D ........1-3/8” 3164D .......... 2”
3126D ........13/16” 3146D .......1-7/16” 3166D ...... 2-1/16”
3128D ..........7/8” 3148D ........1-1/2” 3168D ....... 2-1/8”
3130D ........15/16” 3150D .......1-9/16” 3170D ...... 2-3/16”
3132D ...........1” 3152D ........1-5/8” 3172D ....... 2-1/4”
3134D .......1-1/16” 3154D ......1-11/16” 3174D ...... 2-5/16”
3136D ........1-1/8” 3156D ........1-3/4” 3176D ....... 2-3/8”
3138D .......1-3/16” 3158D ......1-13/16” 3178D ...... 2-7/16”
3140D ........1-1/4” 3160D ........1-7/8” 3180D ....... 2-1/2”
3142D .......1-5/16” 3162D ......1-15/16” Metal Case
No. 8126M
No. 8126MD
3/4
3/4
” Drive 12-Point Standard Length Metric Set
26 piece set contents:
3119M ........19mm 3128M .......28mm 3138M ....... 38mm
3120M ........20mm 3129M .......29mm 3140M ....... 40mm
3121M ........21mm 3130M .......30mm 3141M ....... 41mm
3122M ........22mm 3131M .......31mm 3142M ....... 42mm
3123M ........23mm 3132M .......32mm 3143M ....... 43mm
3124M ........24mm 3133M .......33mm 3144M ....... 44mm
3125M ........25mm 3134M .......34mm 3146M ....... 46mm
3126M ........26mm 3135M .......35mm 3150M ....... 50mm
3127M ........27mm 3136M .......36mm Metal Case
” Drive 12-Point Deep Length Metric Set
26 piece set contents:
3119MD ......19mm 3128MD ......28mm 3138MD ...... 38mm
3120MD ......20mm 3129MD ......29mm 3140MD ...... 40mm
3121MD ......21mm 3130MD ......30mm 3141MD ...... 41mm
3122MD ......22mm 3131MD ......31mm 3142MD ...... 42mm
3123MD ......23mm 3132MD ......32mm 3143MD ...... 43mm
3124MD ......24mm 3133MD ......33mm 3144MD ...... 44mm
3125MD ......25mm 3134MD ......34mm 3146MD ...... 46mm
3126MD ......26mm 3135MD ......35mm 3150MD ...... 50mm
3127MD ......27mm 3136MD ......36mm Metal Case
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
73
2
Page 76
3/4” Drive Impact Socket Sets
No. 8034
No. 8034D
3/4
3/4
” Drive Standard Length Fractional Set
8 piece set contents:
3032R ..............1” 3044R ...........1-3/8”
3034R ..........1-1/16” 3046R ..........1-7/16”
3036R ...........1-1/8” 3048R ...........1-1/2”
3040R ...........1-1/4” Molded Storage Case
3042R ..........1-5/16”
” Drive Deep Length Fractional Set
8 piece set contents:
3032D ..............1” 3044D ...........1-3/8”
3034D ..........1-1/16” 3046D ..........1-7/16”
3036D ...........1-1/8” 3048D ...........1-1/2”
3040D ...........1-1/4” Molded Storage Case
3042D ..........1-5/16”
No. 8134M
No. 8134MD
3/4
3/4
” Drive Standard Length Metric Set
8 piece set contents:
3026M ...........26mm 3035M ...........35mm
3027M ...........27mm 3036M ...........36mm
3029M ...........29mm 3038M ...........38mm
3030M ...........30mm Molded Storage Case
3032M ...........32mm
” Drive Deep Length Metric Set
8 piece set contents:
3026MD .........26mm 3035MD. . . . . . . . . .35mm
3027MD .........27mm 3036MD. . . . . . . . . .36mm
3029MD .........29mm 3038MD. . . . . . . . . .38mm
3030MD .........30mm Molded Storage Case
3032MD .........32mm
74
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 77
3/4” Drive Impact Socket Sets
No. 8038 3/4
No. 8038D 3/4
” Drive Standard Length Fractional Set
14 piece set contents:
3024R ............3/4” 3040R ...........1-1/4”
3026R ..........13/16” 3042R ..........1-5/16”
3028R ............7/8” 3044R ...........1-3/8”
3030R ..........15/16” 3046R ..........1-7/16”
3032R ..............1” 3048R ...........1-1/2”
3034R ..........1-1/16” 3052R ...........1-5/8”
3036R ...........1-1/8” Molded Storage Case
3038R ..........1-3/16”
” Drive Deep Length Fractional Set
14 piece set contents:
3024D ............3/4” 3040D ...........1-1/4”
3026D ..........13/16” 3042D ..........1-5/16”
3028D ............7/8” 3044D ...........1-3/8”
3030D ..........15/16” 3046D ..........1-7/16”
3032D ..............1” 3048D ...........1-1/2”
3034D ..........1-1/16” 3052D ...........1-5/8”
3036D ...........1-1/8” Molded Storage Case
3038D ..........1-3/16”
No. 8313
Warning:
3/4
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
” Drive 12-Point Standard Length Fractional Set
13 piece set contents:
3124R ............3/4” 3140R ...........1-1/4”
3126R ..........13/16” 3144R ...........1-3/8”
3128R ............7/8” 3148R ...........1-1/2”
3130R ..........15/16” 3152R ...........1-5/8”
3132R ..............1” 3156R ...........1-3/4”
3134R ..........1-1/16” 3160R ...........1-7/8”
3136R ...........1-1/8” Molded Storage Case
75
2
Page 78
3/4” Drive Impact Socket Sets
No. 8032 3/4
No. 8370 3/4
” Drive Wheel Service Set
A complete 3/4” drive set designed for servicing truck wheels.
11 piece set contents:
3024D ...........3/4” Deep 3038D ........ 1-3/16” Deep
3026D .........13/16” Deep 3040DT ....1-1/4” T.W. Deep
3028D ...........7/8” Deep 3033MD ....... 33mm Deep
3032D .............1” Deep 3048DB. . . 1-1/2” Deep Budd
3034DT ....1-1/16” T.W. Deep 3313S .......13/16” Square
3036DT .....1-1/8” T.W. Deep Metal Case
” Drive Truck Pinion Locknut Set
A set of seven (7) extra-thin wall deep length impact sockets for removing/installing transmission and differential
end yoke locknuts* on a wide variety of trucks. You no longer need to modify an impact socket, or purchase
expensive, custom designed hand sockets to service these parts. Because of the extra-thin wall design, larger
drive impact tools with reducing adapters should not be used with these impact sockets.
*Use caution and follow the manufacturer’s recommendations when servicing these par ts.
7 piece set contents:
3764D ..............2” 3780D ...........2-1/2”
3768D ...........2-1/8” 3784D ...........2-5/8”
3772D ...........2-1/4” 3788D ...........2-3/4”
3776D ...........2-3/8” Plastic Tray & Metal Case
76
3/4
” Drive Deep Length Truck Pinion Locknut Impact Sockets
Item Hex
Number Size A B C D E
3764D
3768D
3772D
3776D
3780D
3784D
3788D
3755M
Socket End Dia.
B
Hex
D
Depth
Length
E
A
Drive End Dia.
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Bolt Clearance
Depth
C
3765M
2” 2.36 2.65 3.00 1.02 4.10
2-1/8” 2.48 2.81 3.00 1.02 4.10
2-1/4” 2.60 2.99 3.00 1.02 4.10
2-3/8” 2.76 3.15 3.00 1.02 4.10
2-1/2” 2.87 3.27 3.00 1.02 4.10
2-5/8” 2.99 3.42 3.00 1.02 4.10
2-3/4” 3.07 3.60 3.00 1.02 4.10
55mm 2.52 2.85 3.00 1.02 4.10
65mm 2.91 3.33 3.00 1.02 4.10
Dimensions (Inches)
Page 79
3/4” Drive Standard Length Impact Sockets
3/4” Drive - Standard Length - Fractional Sizes
ANSI Specifications B107.2
Hex
D
Depth
E
SHAPE I
SHAPE II
B
Bolt Clearance
C
Depth
Item Hex
Number Size Shape P O R1 A B C D E
3016R
3018R
3020R
3022R
3024R
3026R
3028R
3030R
3032R
3034R
3036R
3038R
3040R
3042R
3044R
3046R
3048R
3050R
3052R
3054R
3056R
3058R
3060R
3062R
3064R
3066R
3068R
3070R
3072R
3074R
3076R
3078R
3080R
3082R
3084R
3086R
3088R
3090R
3092R
3094R
3096R
1/2" I 3220 3210 3110 1.50 0.87 0.98 0.35 1.97
9/16" I 3220 3210 3110 1.50 1.00 0.98 0.43 1.97
5/8" I 3220 3210 3110 1.50 1.08 0.98 0.43 1.97
11/16" I 3220 3210 3110 1.50 1.14 0.98 0.47 1.97
3/4" I 3220 3210 3110 1.50 1.18 0.98 0.51 1.97
13/16" I 3220 3210 3110 1.50 1.26 1.06 0.59 2.05
7/8" I 3220 3210 3110 1.50 1.34 1.06 0.59 2.05
15/16" I 3220 3210 3110 1.50 1.42 1.06 0.63 2.05
1" III 3220 3210 3110 1.50 1.57 1.06 0.63 2.05
1-1/16" III 3220 3210 3110 1.50 1.57 1.06 0.75 2.05
1-1/8" III 3221 3211 3111 1.65 1.65 1.06 0.83 2.05
1-3/16" III 3221 3212 3111 1.73 1.73 1.06 0.83 2.05
1-1/4" III 3221 3212 3111 1.73 1.73 1.06 0.87 2.05
1-5/16" III 3221 3212 3111 1.73 1.85 1.22 0.87 2.20
1-3/8" III 3221 3212 3111 1.73 1.97 1.22 0.87 2.20
1-7/16" III 3221 3212 3111 1.73 2.01 1.22 0.98 2.20
1-1/2" III 3221 3212 3111 1.73 2.09 1.22 0.98 2.20
1-9/16" III 3221 3212 3111 1.73 2.20 1.46 0.98 2.44
1-5/8" III 3221 3212 3111 1.73 2.28 1.46 1.06 2.44
1-11/16" III 3221 3212 3111 1.73 2.50 1.46 1.06 2.44
1-3/4" III 3221 3212 3111 1.73 2.56 1.46 1.06 2.44
1-13/16" III 3221 3212 3111 1.73 2.64 1.69 1.18 2.68
1-7/8" III 3221 3212 3111 1.73 2.68 1.69 1.18 2.68
1-15/16" III 3221 3212 3111 1.73 2.76 1.77 1.18 2.76
2" III 4520 4511 3112 2.13 2.80 1.85 1.26 2.83
2-1/16" III 4520 4511 3112 2.13 2.91 1.85 1.26 2.83
2-1/8" III 4520 4511 3112 2.13 3.03 1.85 1.26 2.83
2-3/16" III 4520 4511 3112 2.13 3.03 1.93 1.38 2.91
2-1/4" III 4520 4511 3112 2.13 3.15 1.93 1.38 2.91
2-5/16" III 4520 4511 3112 2.13 3.23 1.97 1.46 2.95
2-3/8" III 4520 4511 3112 2.13 3.31 1.97 1.46 2.95
2-7/16" III 4520 4511 3112 2.13 3.39 1.97 1.46 2.95
2-1/2" III 4520 4511 3112 2.13 3.46 1.97 1.46 2.95
2-9/16" III 4520 4511 3112 2.13 3.54 2.09 1.57 3.07
2-5/8" III 4520 4511 3112 2.13 3.62 2.17 1.57 3.15
2-11/16" III 4520 4511 3112 2.13 3.70 2.17 1.57 3.15
2-3/4" III 4520 4511 3112 2.13 3.78 2.17 1.57 3.15
2-13/16" III 4520 4511 3112 2.13 3.86 2.28 1.65 3.27
2-7/8" III 4520 4511 3112 2.13 3.94 2.28 1.65 3.27
2-15/16" III 4521 4512 - 2.52 4.02 2.28 1.65 3.27
3" III 4521 4512 - 2.52 4.09 2.36 1.77 3.35
Retaining Devices Dimensions (Inches)
Retaining Devices Key
OP
R1
SHAPE III
Warning:
A
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Pin and O-Ring
One Piece
77
2
Page 80
3/4” Drive Standard Length Impact Sockets
3/4” Drive - Standard Length - Metric Sizes
ANSI Specifications B107.2
Item Hex
Number Size Shape P O R1 A B C D E
3019M
3020M
3021M
3022M
3023M
3024M
3025M
3026M
3027M
3028M
3029M
3030M
3031M
3032M
3033M
3034M
3035M
3036M
3038M
3040M
3041M
3042M
3043M
3044M
3046M
3050M
19mm I 3220 3210 3110 38 30 25 13 50
20mm I 3220 3210 3110 38 31 27 14 52
21mm I 3220 3210 3110 38 32 27 15 52
22mm I 3220 3210 3110 38 34 27 15 52
23mm I 3220 3210 3110 38 35 27 16 52
24mm I 3220 3210 3110 38 36 27 16 52
25mm II 3220 3210 3110 38 38 27 16 52
26mm III 3220 3210 3110 38 40 27 16 52
27mm III 3220 3210 3110 38 40 27 19 52
28mm II 3221 3211 3111 42 42 27 19 52
29mm II 3221 3211 3111 42 42 27 21 52
30mm II 3221 3212 3111 44 44 27 21 52
31mm II 3221 3212 3111 44 44 27 21 52
32mm II 3221 3212 3111 44 44 27 22 52
33mm III 3221 3212 3111 44 47 31 22 52
34mm III 3221 3212 3111 44 48 31 22 56
35mm III 3221 3212 3111 44 50 31 22 56
36mm III 3221 3212 3111 44 51 31 25 56
38mm III 3221 3212 3111 44 53 31 25 56
40mm III 3221 3212 3111 44 56 37 25 62
41mm III 3221 3212 3111 44 58 37 27 62
42mm III 3221 3212 3111 44 61 37 27 62
43mm III 3221 3212 3111 44 63 38 27 63
44mm III 3221 3212 3111 44 65 38 27 63
46mm III 3221 3212 3111 44 67 38 30 63
50mm III 4520 4511 3112 54 71 47 32 72
Retaining Devices Dimensions (Millimeters)
78
SHAPE I
SHAPE II
B
Retaining Devices Key
OP
R1
E
Hex
Depth
D
A
Bolt Clearance
C
Depth
SHAPE III
Pin and O-Ring
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
One Piece
Page 81
3/4” Drive - Deep Length - Fractional Sizes
3/4” Drive Deep Length Impact Sockets
ANSI Specifications B107.2
SHAPE I
SHAPE II
Hex
D
Depth
E
B
Bolt Clearance
Depth
C
Item Hex
Number Size Shape P O R1 A B C D E
3016D
3018D
3020D
3022D
3024D
3026D
3028D
3030D
3032D
3034D
3036D
3038D
3040D
3042D
3044D
3046D
3048D
3050D
3052D
3054D
3056D
3058D
3060D
3062D
3064D
3066D
3068D
3070D
3072D
3074D
3076D
3078D
3080D
3082D
3084D
3086D
3088D
3090D
3092D
3094D
3096D
1/2" I 3220 3210 3110 1.50 0.87 2.36 0.51 3.35
9/16" I 3220 3210 3110 1.50 1.00 2.36 0.55 3.35
5/8" I 3220 3210 3110 1.50 1.08 2.36 0.63 3.35
11/16" I 3220 3210 3110 1.50 1.14 2.36 0.67 3.35
3/4" I 3220 3210 3110 1.50 1.18 2.36 0.75 3.35
13/16" I 3220 3210 3110 1.50 1.26 2.36 0.87 3.35
7/8" I 3220 3210 3110 1.50 1.34 2.36 0.87 3.35
15/16" I 3220 3210 3110 1.50 1.42 2.36 0.94 3.35
1" III 3220 3210 3110 1.50 1.57 2.36 0.98 3.35
1-1/16" III 3220 3210 3110 1.50 1.57 2.36 1.06 3.35
1-1/8" II 3221 3211 3111 1.65 1.65 2.36 1.14 3.35
1-3/16" II 3221 3212 3111 1.73 1.73 2.36 1.18 3.35
1-1/4" III 3221 3212 3111 1.73 1.93 2.36 1.26 3.35
1-5/16" III 3221 3212 3111 1.73 1.97 2.36 1.34 3.35
1-3/8" III 3221 3212 3111 1.73 1.97 2.36 1.38 3.35
1-7/16" III 3221 3212 3111 1.73 2.01 2.36 1.46 3.35
1-1/2" III 3221 3212 3111 1.73 2.28 2.76 1.50 3.74
1-9/16" III 3221 3212 3111 1.73 2.28 2.76 1.50 3.74
1-5/8" III 3221 3212 3111 1.73 2.36 2.76 1.50 3.74
1-11/16" III 3221 3212 3111 1.73 2.48 2.76 1.50 3.74
1-3/4" III 3221 3212 3111 1.73 2.56 2.76 1.50 3.74
1-13/16" III 3221 3212 3111 1.73 2.64 2.76 1.50 3.74
1-7/8" III 3221 3212 3111 1.73 2.68 2.76 1.50 3.74
1-15/16" III 3221 3212 3111 1.73 2.76 2.76 1.50 3.74
2" III 4520 4511 3112 2.13 2.80 2.76 1.57 3.74
2-1/16" III 4520 4511 3112 2.13 2.91 2.76 1.57 3.74
2-1/8" III 4520 4511 3112 2.13 3.03 2.76 1.57 3.74
2-3/16" III 4520 4511 3112 2.13 3.03 2.95 1.57 3.94
2-1/4" III 4520 4511 3112 2.13 3.15 2.95 1.57 3.94
2-5/16" III 4520 4511 3112 2.13 3.23 2.95 1.57 3.94
2-3/8" III 4520 4511 3112 2.13 3.31 3.15 1.65 4.13
2-7/16" III 4520 4511 3112 2.13 3.39 3.15 1.65 4.13
2-1/2" III 4520 4511 3112 2.13 3.46 3.15 1.65 4.13
2-9/16" III 4520 4511 3112 2.13 3.54 3.15 2.60 4.13
2-5/8" III 4520 4511 3112 2.13 3.62 3.15 2.60 4.13
2-11/16" III 4520 4511 3112 2.13 3.70 3.15 2.60 4.13
2-3/4" III 4520 4511 3112 2.13 3.78 3.15 2.60 4.13
2-13/16" III 4520 4511 3112 2.13 3.86 3.27 2.68 4.25
2-7/8" III 4520 4511 3112 2.13 3.94 3.27 2.68 4.25
2-15/16" III 4521 4512 - 2.52 4.02 3.27 2.68 4.25
3" III 4521 4512 - 2.52 4.09 3.35 2.76 4.33
Retaining Devices Dimensions (Inches)
Retaining Devices Key
OP
R1
SHAPE III
Warning:
A
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Pin and O-Ring
One Piece
79
2
Page 82
3/4” Drive Deep Length Impact Sockets
3/4” Drive - Deep Length - Metric Sizes
ANSI Specifications B107.2
SHAPE I
Item Hex
Number Size Shape P O R1 A B C D E
3019MD
3020MD
3021MD
3022MD
3023MD
3024MD
3025MD
3026MD
3027MD
3028MD
3029MD
3030MD
3031MD
3032MD
3033MD
*3033MHD
3034MD
3035MD
3036MD
3038MD
3040MD
3041MD
3042MD
3043MD
3044MD
3046MD
3050MD
*Heavy Duty Impact Socket for Hub-Piloted Truck Wheel Fasteners
19mm I 3220 3210 3110 38 30 60 19 85
20mm I 3220 3210 3110 38 31 60 20 85
21mm I 3220 3210 3110 38 32 60 21 85
22mm I 3220 3210 3110 38 34 60 22 85
23mm I 3220 3210 3110 38 35 60 23 85
24mm I 3220 3210 3110 38 36 60 24 85
25mm II 3220 3210 3110 38 38 60 25 85
26mm III 3220 3210 3110 38 40 60 26 85
27mm III 3220 3210 3110 38 40 60 27 85
28mm II 3221 3211 3111 42 42 60 28 85
29mm II 3221 3211 3111 42 42 60 29 85
30mm II 3221 3212 3111 44 44 60 30 85
31mm II 3221 3212 3111 44 44 60 31 85
32mm III 3221 3212 3111 44 49 60 32 85
33mm III 3221 3212 3111 44 50 60 33 85
33mm III 3221 3212 3111 44 51 70 33 95
34mm III 3221 3212 3111 44 50 60 34 85
35mm III 3221 3212 3111 44 50 60 35 85
36mm III 3221 3212 3111 44 51 60 36 85
38mm III 3221 3212 3111 44 57 70 38 95
40mm III 3221 3212 3111 44 58 70 38 95
41mm III 3221 3212 3111 44 58 70 38 95
42mm III 3221 3212 3111 44 62 70 38 95
43mm III 3221 3212 3111 44 63 70 38 95
44mm III 3221 3212 3111 44 65 70 38 95
46mm III 3221 3212 3111 44 67 70 38 95
50mm III 4520 4511 3112 54 71 70 38 95
Retaining Devices Dimensions (Millimeters)
80
SHAPE II
B
E
Hex
Depth
D
A
Bolt Clearance
Depth
C
Retaining Devices Key
OP
R1
SHAPE III
Pin and O-Ring
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
One Piece
Page 83
3/4” Drive 12-Point Standard Length Impact Sockets
SHAPE II
SHAPE I
3/4” Drive 12-Point - Standard Length - Fractional Sizes
Item 12-Point
Number Size Shape P O R1 A B C D E
3124R
3126R
3128R
3130R
3132R
3134R
3136R
3138R
3140R
3142R
3144R
3146R
3148R
3150R
3152R
3154R
3156R
3158R
3160R
3162R
3164R
3166R
3168R
3170R
3172R
3174R
3176R
3178R
3180R
3/4" I 3221 3212 3111 1.73 1.30 0.98 0.51 1.97
13/16" I 3221 3212 3111 1.73 1.38 0.98 0.59 1.97
7/8" I 3221 3212 3111 1.73 1.46 0.98 0.59 1.97
15/16" I 3221 3212 3111 1.73 1.54 0.98 0.71 1.97
1" I 3221 3212 3111 1.73 1.61 0.98 0.71 1.97
1-1/16" III 3221 3212 3111 1.73 1.69 1.14 0.75 2.13
1-1/8" III 3221 3212 3111 1.73 1.75 1.14 0.83 2.13
1-3/16" III 3221 3212 3111 1.73 1.85 1.14 0.83 2.13
1-1/4" III 3221 3212 3111 1.73 1.93 1.22 0.87 2.20
1-5/16" III 3221 3212 3111 1.73 2.01 1.22 0.87 2.20
1-3/8" III 3221 3212 3111 1.73 2.09 1.22 0.87 2.20
1-7/16" III 3221 3212 3111 1.73 2.17 1.22 0.98 2.20
1-1/2" III 3221 3212 3111 1.73 2.24 1.30 0.98 2.28
1-9/16" III 3221 3212 3111 1.73 2.32 1.30 0.98 2.28
1-5/8" III 3221 3212 3111 1.73 2.40 1.30 1.06 2.28
1-11/16" III 3221 3212 3111 1.73 2.50 1.50 1.06 2.48
1-3/4" III 3221 3212 3111 1.73 2.54 1.50 1.06 2.48
1-13/16" III 3221 3212 3111 1.73 2.64 1.50 1.18 2.48
1-7/8" III 3221 3212 3111 1.73 2.68 1.69 1.18 2.68
1-15/16" III 3221 3212 3111 1.73 2.76 1.77 1.18 2.76
2" III 4520 4511 3112 2.13 2.83 1.85 1.26 2.83
2-1/16" III 4520 4511 3112 2.13 2.91 1.85 1.26 2.83
2-1/8" III 4520 4511 3112 2.13 3.03 1.85 1.26 2.83
2-3/16" III 4520 4511 3112 2.13 3.09 1.93 1.38 2.91
2-1/4" III 4520 4511 3112 2.13 3.15 1.93 1.38 2.91
2-5/16" III 4520 4511 3112 2.13 3.23 1.97 1.46 2.95
2-3/8" III 4520 4511 3112 2.13 3.31 1.97 1.46 2.95
2-7/16" III 4520 4511 3112 2.13 3.39 1.97 1.46 2.95
2-1/2" III 4520 4511 3112 2.13 3.46 1.97 1.46 2.95
Retaining Devices Dimensions (Inches)
D
E
SHAPE III
Warning:
SHAPE I
B
C
A
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Retaining Devices Key
OP
Pin and O-Ring
R1
One Piece
81
2
Page 84
3/4” Drive 12-Point Standard Length Impact Sockets
3/4” Drive 12-Point - Standard Length - Metric Sizes
Item 12-Point
Number Size Shape P O R1 A B C D E
3119M
3120M
3121M
3122M
3123M
3124M
3125M
3126M
3127M
3128M
3129M
3130M
3131M
3132M
3133M
3134M
3135M
3136M
3138M
3140M
3141M
3142M
3143M
3144M
3146M
3150M
19mm I 3221 3212 3111 44 33.0 25 13 50
20mm I 3221 3212 3111 44 34.0 25 14 50
21mm I 3221 3212 3111 44 35.0 25 15 50
22mm I 3221 3212 3111 44 37.0 25 15 50
23mm I 3221 3212 3111 44 38.0 25 16 50
24mm I 3221 3212 3111 44 39.0 25 18 50
25mm I 3221 3212 3111 44 41.0 25 18 50
26mm I 3221 3212 3111 44 42.0 25 18 50
27mm I 3221 3212 3111 44 43.0 29 19 54
28mm II 3221 3212 3111 44 44.0 29 19 54
29mm III 3221 3212 3111 44 45.0 29 21 54
30mm III 3221 3212 3111 44 47.0 29 21 54
31mm III 3221 3212 3111 44 48.0 31 21 56
32mm III 3221 3212 3111 44 49.0 31 22 56
33mm III 3221 3212 3111 44 51.0 31 22 56
34mm III 3221 3212 3111 44 52.0 31 22 56
35mm III 3221 3212 3111 44 53.0 31 22 56
36mm III 3221 3212 3111 44 54.0 31 25 56
38mm III 3221 3212 3111 44 57.0 33 25 58
40mm III 3221 3212 3111 44 59.0 33 25 58
41mm III 3221 3212 3111 44 60.0 33 27 58
42mm III 3221 3212 3111 44 62.0 33 27 58
43mm III 3221 3212 3111 44 63.5 38 27 63
44mm III 3221 3212 3111 44 64.5 38 27 63
46mm III 3221 3212 3111 44 67.0 38 30 63
50mm III 4520 4511 3112 54 71.0 47 32 72
Retaining Devices Dimensions (Millimeters)
82
SHAPE I
SHAPE II
B
D
E
A
C
Retaining Devices Key
OP
R1
SHAPE III
Pin and O-Ring
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
One Piece
Page 85
3/4” Drive 12-Point Deep Length Impact Sockets
SHAPE II
SHAPE I
3/4” Drive 12-Point - Deep Length - Fractional Sizes
Item 12-Point
Number Size Shape P O R1 A B C D E
3124D
3126D
3128D
3130D
3132D
3134D
3136D
3138D
3140D
3142D
3144D
3146D
3148D
3150D
3152D
3154D
3156D
3158D
3160D
3162D
3164D
3166D
3168D
3170D
3172D
3174D
3176D
3178D
3180D
3/4" I 3221 3212 3111 1.73 1.30 2.76 0.75 3.74
13/16" I 3221 3212 3111 1.73 1.38 2.76 0.87 3.74
7/8" I 3221 3212 3111 1.73 1.46 2.76 0.87 3.74
15/16" I 3221 3212 3111 1.73 1.54 2.76 0.94 3.74
1" I 3221 3212 3111 1.73 1.61 2.76 0.98 3.74
1-1/16" III 3221 3212 3111 1.73 1.69 2.76 1.06 3.74
1-1/8" III 3221 3212 3111 1.73 1.75 2.76 1.14 3.74
1-3/16" III 3221 3212 3111 1.73 1.85 2.76 1.18 3.74
1-1/4" III 3221 3212 3111 1.73 1.93 2.76 1.26 3.74
1-5/16" III 3221 3212 3111 1.73 2.01 2.76 1.34 3.74
1-3/8" III 3221 3212 3111 1.73 2.09 2.76 1.38 3.74
1-7/16" III 3221 3212 3111 1.73 2.17 2.76 1.46 3.74
1-1/2" III 3221 3212 3111 1.73 2.24 2.76 1.50 3.74
1-9/16" III 3221 3212 3111 1.73 2.32 2.76 1.50 3.74
1-5/8" III 3221 3212 3111 1.73 2.40 2.76 1.50 3.74
1-11/16" III 3221 3212 3111 1.73 2.50 2.76 1.50 3.74
1-3/4" III 3221 3212 3111 1.73 2.54 2.76 1.50 3.74
1-13/16" III 3221 3212 3111 1.73 2.64 2.95 1.50 3.94
1-7/8" III 3221 3212 3111 1.73 2.68 2.95 1.50 3.94
1-15/16" III 3221 3212 3111 1.73 2.76 2.95 1.50 3.94
2" III 4520 4511 3112 2.13 2.83 2.95 1.57 3.94
2-1/16" III 4520 4511 3112 2.13 2.91 2.95 1.57 3.94
2-1/8" III 4520 4511 3112 2.13 3.03 2.95 1.57 3.94
2-3/16" III 4520 4511 3112 2.13 3.09 3.15 1.57 4.13
2-1/4" III 4520 4511 3112 2.13 3.15 3.15 1.57 4.13
2-5/16" III 4520 4511 3112 2.13 3.23 3.15 1.57 4.13
2-3/8" III 4520 4511 3112 2.13 3.31 3.15 1.65 4.13
2-7/16" III 4520 4511 3112 2.13 3.39 3.15 1.65 4.13
2-1/2" III 4520 4511 3112 2.13 3.46 3.15 1.65 4.13
Retaining Devices Dimensions (Inches)
Hex
D
Depth
E
SHAPE III
Warning:
SHAPE I
B
Bolt Clearance
Depth
C
A
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Retaining Devices Key
OP
Pin and O-Ring
R1
One Piece
83
2
Page 86
3/4” Drive 12-Point Deep Length Impact Sockets
3/4” Drive 12-Point - Deep Length - Metric Sizes
Item 12-Point
Number Size Shape P O R1 A B C D E
3119MD
3120MD
3121MD
3122MD
3123MD
3124MD
3125MD
3126MD
3127MD
3128MD
3129MD
3130MD
3131MD
3132MD
3133MD
3134MD
3135MD
3136MD
3138MD
3140MD
3141MD
3142MD
3143MD
3144MD
3146MD
3150MD
19mm I 3221 3212 3111 44 33.0 70 19 95
20mm I 3221 3212 3111 44 34.0 70 20 95
21mm I 3221 3212 3111 44 35.0 70 21 95
22mm I 3221 3212 3111 44 37.0 70 22 95
23mm I 3221 3212 3111 44 38.0 70 23 95
24mm I 3221 3212 3111 44 39.0 70 24 95
25mm I 3221 3212 3111 44 41.0 70 25 95
26mm I 3221 3212 3111 44 42.0 70 26 95
27mm I 3221 3212 3111 44 43.0 70 27 95
28mm II 3221 3212 3111 44 44.0 70 28 95
29mm III 3221 3212 3111 44 45.0 70 29 95
30mm III 3221 3212 3111 44 47.0 70 30 95
31mm III 3221 3212 3111 44 48.0 70 31 95
32mm III 3221 3212 3111 44 49.0 70 32 95
33mm III 3221 3212 3111 44 51.0 70 33 95
34mm III 3221 3212 3111 44 52.0 70 34 95
35mm III 3221 3212 3111 44 53.0 70 35 95
36mm III 3221 3212 3111 44 54.0 70 36 95
38mm III 3221 3212 3111 44 57.0 70 38 95
40mm III 3221 3212 3111 44 59.0 70 38 95
41mm III 3221 3212 3111 44 60.0 70 38 95
42mm III 3221 3212 3111 44 62.0 70 38 95
43mm III 3221 3212 3111 44 63.5 70 38 95
44mm III 3221 3212 3111 44 64.5 70 38 95
46mm III 3221 3212 3111 44 67.0 75 38 100
50mm III 4520 4511 3112 54 71.0 75 38 100
Retaining Devices Dimensions (Millimeters)
84
SHAPE I
SHAPE II
B
E
Hex
Depth
D
Bolt Clearance
Depth
C
Retaining Devices Key
OP
R1
A
SHAPE III
Pin and O-Ring
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
One Piece
Page 87
3/4” Drive - Universal - Fractional Sizes
3/4” Drive Universal Impact Sockets
Item Hex
Number Size P O R1 A B C D E
3024U
3026U
3028U
3030U
3032U
3034U
3036U
3038U
3040U
3042U
3044U
3046U
3048U
3050U
3052U
3054U
3056U
3058U
3060U
3/4” 3221 3212 3111 1.73 1.26 0.79 0.51 3.74
13/16" 3221 3212 3111 1.73 1.38 0.79 0.55 3.74
7/8" 3221 3212 3111 1.73 1.46 0.79 0.55 3.74
15/16" 3221 3212 3111 1.73 1.54 0.79 0.59 3.74
1" 3221 3212 3111 1.73 1.61 0.91 0.63 3.94
1-1/16" 3221 3212 3111 1.73 1.69 0.91 0.67 3.94
1-1/8" 3221 3212 3111 1.73 1.73 0.91 0.71 3.94
1-3/16" 3221 3212 3111 1.73 1.85 0.91 0.71 3.94
1-1/4" 3221 3212 3111 1.73 1.93 1.06 0.79 4.13
1-5/16" 3221 3212 3111 1.73 2.01 1.06 0.83 4.13
1-3/8" 3221 3212 3111 1.73 2.09 1.06 0.87 4.13
1-7/16" 3221 3212 3111 1.73 2.13 1.14 0.91 4.33
1-1/2" 3221 3212 3111 1.73 2.24 1.14 0.94 4.33
1-9/16" 3221 3212 3111 1.73 2.36 1.14 0.94 4.33
1-5/8" 3221 3212 3111 1.73 2.36 1.38 1.06 4.53
1-11/16" 3221 3212 3111 1.73 2.50 1.38 1.06 4.53
1-3/4" 3221 3212 3111 1.73 2.54 1.38 1.18 4.53
1-13/16" 3221 3212 3111 1.73 2.62 1.38 1.18 4.53
1-7/8" 3221 3212 3111 1.73 2.68 1.38 1.18 4.53
Retaining Devices Dimensions (Inches)
Universal - Metric Sizes
Item Hex
Number Size P O R1 A B C D E
3019UM
3020UM
B
D
C
E
A
3021UM
3022UM
3023UM
3024UM
3025UM
3026UM
3027UM
3028UM
3029UM
3030UM
3031UM
3032UM
3033UM
3034UM
3035UM
3036UM
3037UM
3038UM
3039UM
3040UM
3041UM
3042UM
3043UM
3044UM
3045UM
3046UM
19mm 3221 3212 3111 44 32.0 20 13 95
20mm 3221 3212 3111 44 34.0 20 14 95
21mm 3221 3212 3111 44 35.0 20 14 95
22mm 3221 3212 3111 44 37.0 20 14 95
23mm 3221 3212 3111 44 38.0 20 14 95
24mm 3221 3212 3111 44 39.0 20 15 95
25mm 3221 3212 3111 44 41.0 23 16 100
26mm 3221 3212 3111 44 42.0 23 16 100
27mm 3221 3212 3111 44 43.0 23 17 100
28mm 3221 3212 3111 44 44.0 23 18 100
29mm 3221 3212 3111 44 46.0 23 18 100
30mm 3221 3212 3111 44 47.0 23 18 100
31mm 3221 3212 3111 44 48.0 27 19 105
32mm 3221 3212 3111 44 49.0 27 20 105
33mm 3221 3212 3111 44 51.0 27 21 105
34mm 3221 3212 3111 44 52.0 27 22 105
35mm 3221 3212 3111 44 53.0 27 22 105
36mm 3221 3212 3111 44 54.0 29 23 110
37mm 3221 3212 3111 44 56.0 29 24 110
38mm 3221 3212 3111 44 57.0 29 24 110
39mm 3221 3212 3111 44 59.0 29 24 110
40mm 3221 3212 3111 44 60.0 29 24 110
41mm 3221 3212 3111 44 60.0 35 27 115
42mm 3221 3212 3111 44 62.0 35 27 115
43mm 3221 3212 3111 44 63.5 35 27 115
44mm 3221 3212 3111 44 64.5 35 30 115
45mm 3221 3212 3111 44 66.0 35 30 115
46mm 3221 3212 3111 44 66.5 35 30 115
Retaining Devices Dimensions (Millimeters)
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
85
2
Page 88
3/4” Drive 8-Point Impact Sockets
SHAPE I
A
E
B
C
SHAPE III
D
SHAPE II
SHAPE III
SHAPE II
SHAPE I
3/4
” Drive 8-Point - Standard Length - Fractional Sizes
Item 8-Point
Number Size Shape P O R1 A B C D E
New
3524S
3526S
3528S
3530S
3532S
3534S
3536S
3538S
3540S
3542S
3544S
3546S
3548S
3/4" I 3220 3210 3110 1.57 1.57 0.98 0.51 1.97
13/16" I 3221 3211 3111 1.65 1.65 0.98 0.59 1.97
7/8" I 3221 3212 3111 1.73 1.73 0.98 0.59 1.97
15/16" III 3221 3212 3111 1.75 1.81 1.06 0.71 2.05
1" III 3221 3212 3111 1.75 1.97 1.06 0.71 2.05
1-1/16" III 3221 3212 3111 1.75 2.09 1.14 0.75 2.13
1-1/8" III 3221 3212 3111 1.75 2.20 1.14 0.75 2.13
1-3/16" III 3221 3212 3111 1.75 2.28 1.14 0.83 2.13
1-1/4" III 3221 3212 3111 1.75 2.40 1.22 0.87 2.20
1-5/16" III 3221 3212 3111 1.75 2.50 1.22 0.87 2.20
1-3/8" III 3221 3212 3111 1.75 2.60 1.22 0.87 2.20
1-7/16" III 3221 3212 3111 1.75 2.68 1.22 0.94 2.20
1-1/2" III 3221 3212 3111 1.75 2.76 1.30 0.94 2.28
Retaining Devices Dimensions (Inches)
B
D
E
A
C
SHAPE I
3/4” Drive 8-Point - Deep Length - Fractional Sizes
Item 8-Point
Number Size Shape P O R1 A B C D E
3524SD
3526SD
3528SD
3530SD
3532SD
3534SD
3536SD
3538SD
3540SD
3542SD
New
3544SD
3546SD
3548SD
Retaining Devices Key
OP
3/4" I 3220 3210 3110 1.57 1.57 2.76 0.51 3.74
13/16" I 3221 3211 3111 1.65 1.65 2.76 0.59 3.74
7/8" I 3221 3212 3111 1.73 1.73 2.76 0.59 3.74
15/16" III 3221 3212 3111 1.75 1.81 2.76 0.71 3.74
1" III 3221 3212 3111 1.75 1.97 2.76 0.71 3.74
1-1/16" III 3221 3212 3111 1.75 2.09 2.76 0.75 3.74
1-1/8" III 3221 3212 3111 1.75 2.20 2.76 0.75 3.74
1-3/16" III 3221 3212 3111 1.75 2.28 2.76 0.83 3.74
1-1/4" III 3221 3212 3111 1.75 2.40 2.76 0.87 3.74
1-5/16" III 3221 3212 3111 1.75 2.50 2.76 0.87 3.74
1-3/8" III 3221 3212 3111 1.75 2.60 2.76 0.87 3.74
1-7/16" III 3221 3212 3111 1.75 2.68 2.76 0.94 3.74
1-1/2" III 3221 3212 3111 1.75 2.76 2.76 0.94 3.74
R1
Retaining Devices Dimensions (Inches)
B
Hex
D
Depth
E
Bolt Clearance
Depth
C
86
1
Warning:
Pin and O-Ring
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
One Piece
A
SHAPE III
Page 89
3/4” Drive Special Application Impact Sockets
3/4
” Drive Extra-Deep Thin Wall Sockets
B
Designed for truck wheel service when removing lug nuts that are deeply recessed and where
space is very limited.
D
C
E
A
3/4
” Drive Budd Wheel Socket - 1-1/2” Limited Hex
B
D
C
E
A
3/4
” Drive Budd Wheel Socket - 1-1/2” Deep Hex
Item Hex
Number Size A B C D E
3034DT
3036DT
3040DT
3041MDT
Special 1-1/2” hex deep heavy duty impact socket designed for outer cap nuts on budd-style
truck wheels. The 1-1/2” hex depth is limited to help prevent socket contact with the wheel.
The socket is deep style to eliminate contact with the inner cap nut.
1-1/16” 1.69 1.57 3.27 1.69 4.25
1-1/8” 1.69 1.65 3.27 1.69 4.25
1-1/4” 1.77 1.77 3.27 1.69 4.25
41mm 45 54.5 83 43 108
Item Hex
Number Size A B C D E
3048DB
1-1/2” 2.24 2.24 2.83 .55 3.82
Dimensions (Inches/Millimeters)
Dimensions (Inches)
B
D
E
A
3/4
” Drive Combination Budd Wheel Sockets
B
D
E
A
Special 1-1/2” hex deep heavy duty impact socket designed for outer cap nuts on budd-style
truck wheels. The 1-1/2” hex depth is deep in length. The socket is a deep style to eliminate
contact with the inner cap nut.
C
Item Hex
Number Size A B C D E
3048DS
Removes and installs budd-type wheel fasteners. Sockets have two openings, eliminating the
need for two separate sockets. Fractional and metric sizes.
C
1-1/2” 2.36 2.36 3.03 2.70 4.02
Item Hex Square
Number Size Size A B C D E
3223C
3235MC
3241MC
1-1/2” 13/16” 2.24 2.24 2.83 .55 3.82
35mm 17mm 52 54 65 13 90
41mm 21mm 54 58 83 14 97
Dimensions (Inches)
Dimensions (Inches/Millimeters)
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
87
2
Page 90
3/4” Drive Special Application Impact Sockets
3/4
” Drive 4-Point (Square) Standard Length Sockets
Designed specifically for inner budd-style square fasteners on truck wheels. Fractional and
metric sizes.
B
D
E
A
3/4
” Drive 4-Point (Square) Deep Length Socket
B
D
E
A
3/4
” Drive 4-Point Heavy Duty (Square) Socket
Item Square
Number Size A B D E
3313S
3315S
3317S
3319S
3320S
3321S
Designed for inner budd-style square fasteners on truck wheels where a deep style impact
socket is desired.
15/16” 1.73 1.73 .94 2.44
19mm 40 40 24 52
20mm 44 42 24 62
13/16” 1.73 1.65 .94 2.44
17mm 44 40 24 62
21mm 44 42 24 62
Item Square
Dimensions (Inches/Millimeters)
Dimensions (Inches)
Number Size A B D E
3313SL
13/16” 1.73 1.65 2.28 3.74
E
3/4
” Drive 6-Point Extra-Long Sockets
D
E
Designed specifically for inner budd-style square fasteners on truck wheels.
B
D
Item Square
Number Size A B D E
A
B
C
Extra-long impact sockets in popular sizes for use on truck wheels and other applications
where a long reach is required. They reduce torque loss and eliminate the need for an
extension on 3/4” drive impact tools with short anvils.
3433MDL
3434DL
3436DL
3440DL
3448DL
A
3713SL
3313SHD
Item
13/16” 2.01 1.65 1.34 2.44
Dimensions (Inches/Millimeters)
Number Size A B C D E
33mm Hex 44 48 70 40 230
1-1/16” Hex 1.73 1.65 2.76 1.57 9.06
1-1/8” Hex 1.73 1.69 2.76 1.57 9.06
1-1/4” Hex 1.73 1.85 2.76 1.57 9.06
1-1/2” Hex 1.73 2.13 2.76 1.57 9.06
13/16” Square 1.73 1.69 2.76 1.57 9.06
Dimensions (Inches)
88
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 91
3/4
” Drive Adapters
3/4” Drive Impact Attachments
3/4
” Drive to #5 Spline Adapter
Socket
Dimensions (Inches)
Item Female Male Retention
Number End
*
E
A
3008A
*
3008AL
3009A
3009AB
3009AL
Extra Long Adapter
3079AB
* Reducing Adapters are not covered by the Gp Warranty.
* See page 179 for New Reducing Sleeve Adapters
3/4” 1” Pin Hole 1.73 2.48
3/4” 1/2” Friction Ball 1.73 2.28
3/4” 1/2” Locking Pin 1.73 2.28
3/4” 1” Friction Ball 1.73 2.48
3/4” 1” Locking Pin 1.73 2.48
3/4” 1” Friction Ball 1.73 6.89
E
A
Item Female Male Retention
Number End
3011A
5500RK
3/4” #5 Spline Pin Hole 2.13 4.13
Repair Kit for No. 3011A, No. 4011A, & No. 6011A
End Device A E
Socket
Dimensions (Inches)
End Device A E
3/4
” Drive Extensions
E
A
Socket Retention Device Key for 3/4” Drive Adapters, Extensions & Universal Joints
FB
Do NOT run the tool when the socket is OFF the fastener.
LPPH
Item Retention
Number Description
3003E
3003EB
3003EL
3007E
3007EB
3007EL
3010E
3010EB
3010EL
3013E
3013EB
3013EL
Pin Hole
PH
Uses Ret Ring® or Pin &
O-ring to secure socket.
The most secure system
available. Recommended
for 3/4” drive and larger
impact wrenches.
3” Extension Pin Hole 1.73 2.95
3” Extension Friction Ball 1.73 2.95
3” Extension Locking Pin 1.73 2.95
7” Extension Pin Hole 1.73 6.89
7” Extension Friction Ball 1.73 6.89
7” Extension Locking Pin 1.73 6.89
10” Extension Pin Hole 1.73 9.84
10” Extension Friction Ball 1.73 9.84
10” Extension Locking Pin 1.73 9.84
13” Extension Pin Hole 1.73 12.99
13” Extension Friction Ball 1.73 12.99
13” Extension Locking Pin 1.73 12.99
FB
Friction Ball
A spring loaded steel ball
that lines up with the socket
retainer hole. Use caution
when using this system
because the socket is held
in place only by spring
pressure on the steel ball.
Device A E
Socket
LP
Locking Pin
Spring loaded pin, simply
line up with socket retainer
hole and press pin.
To release socket, insert
object through retainer hole
and press pin.
Dimensions (Inches)
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
89
2
Page 92
3/4” Drive Impact Attachments
3/4
” Drive Universal Joint
3/4
” Drive Socket O-Rings & Retaining Pins
E
Item
Number Description A E
3006UJ
A
3/4” x 3/4” w/Pin Hole 1.73 4.13
Dimensions (Inches)
PINS
Item Fits Socket Pin Pin
Number Drive End Diameters Diameter Length
3220
1.42” - 1.57” (36mm - 40mm) .16” (4mm) 1.18” (30mm)
3221
1.65” - 1.75” (42mm - 44mm) .16” (4mm) 1.38” (35mm)
4520
1.89” - 2.24” (48mm - 57mm) .20” (5mm) 1.77” (45mm)
O-RINGS
Item Fits Socket O-Ring O-Ring
Number Drive End Diameters I.D. Thickness
3210
1.42” - 1.57” (36mm - 40mm) 1.22” (31mm) .20” (5mm)
3211
1.65” - 1.69” (42mm - 43mm) 1.34” (34mm) .20” (5mm)
3212
1.73” (44mm) 1.48” (37.5mm) .20” (5mm)
4511
2.13” - 2.44” (54mm - 62mm) 1.85” (47mm) .20” (5mm)
90
3/4” Ret Ring® One Piece Impact Socket Retainers
1 3
1
Warning:
Step 1
Place Ret Ring® over
impact square drive,
put on impact socket
aligning retention holes,
then insert center-pin
through retention holes.
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
The Ret Ring® connects an impact socket onto an impact wrench, extension, adapter or
universal joint. One-piece, molded of new space age polyurethane, with a steel insert for
added safety. Available for 3/4”, 1” and 1-1/2” drive impact sockets. 3/4” drive sizes listed
below. For a complete listing and cross-reference to other manufacturer’s part numbers see
page 117.
Item Square Fits Socket
Number Drive Size Ends “A” Diameters
3110
3111
3112
3/4” 2.13” - 2.24” (54mm - 56mm)
2
Step 2
Push center-pin
completely
through hole.
3/4” 1.50” (38mm)
3/4” 1.65” - 1.77” (42mm - 44mm)
Step 3
Pull O-ring up
into groove on
opposite side.
Page 93
3/4” Drive Accessories
No. 30T20
3/4
” Drive T-Handle Tool
This tool features a sliding drive head that allows for use in tight spaces. The head is held in
place by a friction pin so it can slide flush with the ends of the bar. A Friction ball retainer holds
sockets securely to the drive. When used as a breaker bar the 20" handle provides extra leverage.
Item Drive
Dimensions (Inches)
Number Size A B C D E
30T20
3/4” 1.58 .78 1.66 2.52 19.87
D
C
A
E
B
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
91
2
Page 94
1” Drive Standard Length Fractional Impact Socket Sets
No. 9021
No. 9016
1” Drive - Standard Length - Fractional Set
21 piece set contents:
4024R ............3/4” 4046R ..........1-7/16”
4026R ..........13/16” 4048R ...........1-1/2”
4028R ............7/8” 4050R ..........1-9/16”
4030R ..........15/16” 4052R ...........1-5/8”
4032R ..............1” 4054R .........1-11/16”
4034R ..........1-1/16” 4056R ...........1-3/4”
4036R ...........1-1/8” 4058R .........1-13/16”
4038R ..........1-3/16” 4060R ...........1-7/8”
4040R ...........1-1/4” 4062R .........1-15/16”
4042R ..........1-5/16” 4064R ..............2”
4044R ...........1-3/8” Metal Case
1” Drive - Standard Length - Fractional Set
16 piece set contents:
4066R ..........2-1/16” 4082R ..........2-9/16”
4068R ...........2-1/8” 4084R ...........2-5/8”
4070R ..........2-3/16” 4086R .........2-11/16”
4072R ...........2-1/4” 4088R ...........2-3/4”
4074R ..........2-5/16” 4090R .........2-13/16”
4076R ...........2-3/8” 4092R ...........2-7/8”
4078R ..........2-7/16” 4094R .........2-15/16”
4080R ...........2-1/2” 4096R ..............3”
Metal Case
92
No. 9011
1” Drive - Standard Length - Fractional Set
11 piece set contents:
4100R ...........3-1/8” 4124R ...........3-7/8”
4104R ...........3-1/4” 4128R ..............4”
4108R ...........3-3/8” 4132R ...........4-1/8”
4112R ...........3-1/2” 4136R ...........4-1/4”
4116R ...........3-5/8” 4144R ...........4-1/2”
4120R ...........3-3/4” Metal Case
Ordering the 3 sets above will provide complete coverage in 1” Drive Standard Length Fractional sizes.
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 95
1” Drive Deep Length Fractional Impact Socket Sets
No. 9021D
No. 9016D
1” Drive - Deep Length - Fractional Set
21 piece set contents:
4024D ............3/4” 4046D ..........1-7/16”
4026D ..........13/16” 4048D ...........1-1/2”
4028D ............7/8” 4050D ..........1-9/16”
4030D ..........15/16” 4052D ...........1-5/8”
4032D ..............1” 4054D .........1-11/16”
4034D ..........1-1/16” 4056D ...........1-3/4”
4036D ...........1-1/8” 4058D .........1-13/16”
4038D ..........1-3/16” 4060D ...........1-7/8”
4040D ...........1-1/4” 4062D .........1-15/16”
4042D ..........1-5/16” 4064D ..............2”
4044D ...........1-3/8” Metal Case
1” Drive - Deep Length - Fractional Set
16 piece set contents:
4066D ..........2-1/16” 4082D ..........2-9/16”
4068D ...........2-1/8” 4084D ...........2-5/8”
4070D ..........2-3/16” 4086D .........2-11/16”
4072D ...........2-1/4” 4088D ...........2-3/4”
4074D ..........2-5/16” 4090D .........2-13/16”
4076D ...........2-3/8” 4092D ...........2-7/8”
4078D ..........2-7/16” 4094D .........2-15/16”
4080D ...........2-1/2” 4096D ..............3”
Metal Case
No. 9011D
1” Drive - Deep Length - Fractional Set
11 piece set contents:
4100D ...........3-1/8” 4124D ...........3-7/8”
4104D ...........3-1/4” 4128D ..............4”
4108D ...........3-3/8” 4132D ...........4-1/8”
4112D ...........3-1/2” 4136D ...........4-1/4”
4116D ...........3-5/8” 4144D ...........4-1/2”
4120D ...........3-3/4” Metal Case
Ordering the 3 sets above will provide complete coverage in 1” Drive Deep Length Fractional sizes.
Always wear safety goggles when using Impact Tools.
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
93
2
Page 96
1” Drive Standard Length Metric Impact Socket Sets
No. 9026M
No. 9020M
1” Drive - Standard Length - Metric Set
1” Drive - Standard Length - Metric Set
ALL
NEW
26 piece set contents:
4019M ...........19mm 4032M ...........32mm
4020M ...........20mm 4033M ...........33mm
4021M ...........21mm 4034M ...........34mm
4022M ...........22mm 4035M ...........35mm
4023M ...........23mm 4036M ...........36mm
4024M ...........24mm 4037M ...........37mm
4025M ...........25mm 4038M ...........38mm
4026M ...........26mm 4039M ...........39mm
4027M ...........27mm 4040M ...........40mm
4028M ...........28mm 4041M ...........41mm
4029M ...........29mm 4042M ...........42mm
4030M ...........30mm 4043M ...........43mm
4031M ...........31mm 4044M ...........44mm
Metal Case
20 piece set contents:
4045M ...........45mm 4056M ...........56mm
4046M ...........46mm 4057M ...........57mm
4047M ...........47mm 4058M ...........58mm
4048M ...........48mm 4060M ...........60mm
4050M ...........50mm 4062M ...........62mm
4051M ...........51mm 4063M ...........63mm
4052M ...........52mm 4065M ...........65mm
4053M ...........53mm 4067M ...........67mm
4054M ...........54mm 4070M ...........70mm
4055M ...........55mm 4075M ...........75mm
Metal Case
94
No. 9011M
1” Drive - Standard Length - Metric Set
11 piece set contents:
4076M ...........76mm 4095M ...........95mm
4077M ...........77mm 40100M .........100mm
4078M ...........78mm 40105M .........105mm
4080M ...........80mm 40110M .........110mm
4085M ...........85mm 40115M .........115mm
4090M ...........90mm Metal Case
Ordering the 3 sets above will provide complete coverage in 1” Drive Standard Length Metric sizes.
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Page 97
No. 9026MD
1” Drive Deep Length Metric Impact Socket Sets
1” Drive - Deep Length - Metric Set
ALL
NEW
26 piece set contents:
4019MD .........19mm 4032MD. . . . . . . . . .32mm
4020MD .........20mm 4033MD. . . . . . . . . .33mm
4021MD .........21mm 4034MD. . . . . . . . . .34mm
4022MD .........22mm 4035MD. . . . . . . . . .35mm
4023MD .........23mm 4036MD. . . . . . . . . .36mm
4024MD .........24mm 4037MD. . . . . . . . . .37mm
4025MD .........25mm 4038MD. . . . . . . . . .38mm
4026MD .........26mm 4039MD. . . . . . . . . .39mm
4027MD .........27mm 4040MD. . . . . . . . . .40mm
4028MD .........28mm 4041MD. . . . . . . . . .41mm
4029MD .........29mm 4042MD. . . . . . . . . .42mm
4030MD .........30mm 4043MD. . . . . . . . . .43mm
4031MD .........31mm 4044MD. . . . . . . . . .44mm
Metal Case
No. 9020MD
No. 9011MD
1” Drive - Deep Length - Metric Set
20 piece set contents:
4045MD .........45mm 4056MD. . . . . . . . . .56mm
4046MD .........46mm 4057MD. . . . . . . . . .57mm
4047MD .........47mm 4058MD. . . . . . . . . .58mm
4048MD .........48mm 4060MD. . . . . . . . . .60mm
4050MD .........50mm 4062MD. . . . . . . . . .62mm
4051MD .........51mm 4063MD. . . . . . . . . .63mm
4052MD .........52mm 4065MD. . . . . . . . . .65mm
4053MD .........53mm 4067MD. . . . . . . . . .67mm
4054MD .........54mm 4070MD. . . . . . . . . .70mm
4055MD .........55mm 4075MD. . . . . . . . . .75mm
Metal Case
1” Drive - Deep Length - Metric Set
11 piece set contents:
4076MD .........76mm 4095MD. . . . . . . . . .95mm
4077MD .........77mm 40100MD. . . . . . . .100mm
4078MD .........78mm 40105MD. . . . . . . .105mm
4080MD .........80mm 40110MD. . . . . . . .110mm
4085MD .........85mm 40115MD. . . . . . . .115mm
4090MD .........90mm Metal Case
Ordering the 3 sets above will provide complete coverage in 1” Drive Deep Length Metric sizes.
Always wear safety goggles when using Impact Tools.
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
95
2
Page 98
1” Drive 12-Point Standard Length Fractional Impact Socket Sets
No. 9121
No. 9116
1” Drive 12-Point - Standard Length - Fractional Set
21 piece set contents:
4224R ............3/4” 4246R ..........1-7/16”
4226R ..........13/16” 4248R ...........1-1/2”
4228R ............7/8” 4250R ..........1-9/16”
4230R ..........15/16” 4252R ...........1-5/8”
4232R ..............1” 4254R .........1-11/16”
4234R ..........1-1/16” 4256R ...........1-3/4”
4236R ...........1-1/8” 4258R .........1-13/16”
4238R ..........1-3/16” 4260R ...........1-7/8”
4240R ...........1-1/4” 4262R .........1-15/16”
4242R ..........1-5/16” 4264R ..............2”
4244R ...........1-3/8” Metal Case
1” Drive 12-Point - Standard Length - Fractional Set
16 piece set contents:
4266R ..........2-1/16” 4282R ..........2-9/16”
4268R ...........2-1/8” 4284R ...........2-5/8”
4270R ..........2-3/16” 4286R .........2-11/16”
4272R ...........2-1/4” 4288R ...........2-3/4”
4274R ..........2-5/16” 4290R .........2-13/16”
4276R ...........2-3/8” 4292R ...........2-7/8”
4278R ..........2-7/16” 4294R .........2-15/16”
4280R ...........2-1/2” 4296R ..............3”
ALL
NEW
Metal Case
96
No. 9111
Ordering the 3 sets above will provide complete coverage in 1” Drive 12-Point Standard Length Fractional sizes.
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
1” Drive 12-Point - Standard Length - Fractional Set
11 piece set contents:
4300R ...........3-1/8” 4324R ...........3-7/8”
4304R ...........3-1/4” 4328R ..............4”
4308R ...........3-3/8” 4332R ...........4-1/8”
4312R ...........3-1/2” 4336R ...........4-1/4”
4316R ...........3-5/8” 4344R ...........4-1/2”
4320R ...........3-3/4” Metal Case
Page 99
No. 9121D
1” Drive 12-Point Deep Length Fractional Impact Socket Sets
1” Drive 12-Point - Deep Length - Fractional Set
21 piece set contents:
4224D ............3/4” 4246D ..........1-7/16”
4226D ..........13/16” 4248D ...........1-1/2”
4228D ............7/8” 4250D ..........1-9/16”
4230D ..........15/16” 4252D ...........1-5/8”
4232D ..............1” 4254D .........1-11/16”
4234D ..........1-1/16” 4256D ...........1-3/4”
4236D ...........1-1/8” 4258D .........1-13/16”
4238D ..........1-3/16” 4260D ...........1-7/8”
4240D ...........1-1/4” 4262D .........1-15/16”
4242D ..........1-5/16” 4264D ..............2”
4244D ...........1-3/8” Metal Case
ALL
NEW
No. 9116D
No. 9111D
1” Drive 12-Point - Deep Length - Fractional Set
16 piece set contents:
4266D ..........2-1/16” 4282D ..........2-9/16”
4268D ...........2-1/8” 4284D ...........2-5/8”
4270D ..........2-3/16” 4286D .........2-11/16”
4272D ...........2-1/4” 4288D ...........2-3/4”
4274D ..........2-5/16” 4290D .........2-13/16”
4276D ...........2-3/8” 4292D ...........2-7/8”
4278D ..........2-7/16” 4294D .........2-15/16”
4280D ...........2-1/2” 4296D ..............3”
Metal Case
1” Drive 12-Point - Deep Length - Fractional Set
11 piece set contents:
4300D ...........3-1/8” 4324D ...........3-7/8”
4304D ...........3-1/4” 4328D ..............4”
4308D ...........3-3/8” 4332D ...........4-1/8”
4312D ...........3-1/2” 4336D ...........4-1/4”
4316D ...........3-5/8” 4344D ...........4-1/2”
4320D ...........3-3/4” Metal Case
Ordering the 3 sets above will provide complete coverage in 1” Drive 12-Point Deep Length Fractional sizes.
Always wear safety goggles when using Impact Tools.
Warning:
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Use only properly matched fractional or metric sizes.
97
2
Page 100
1” Drive 12-Point Standard Length Metric Impact Socket Sets
No. 9126M
No. 9120M
1” Drive 12-Point - Standard Length - Metric Set
1” Drive 12-Point - Standard Length - Metric Set
ALL
NEW
26 piece set contents:
4119M ...........19mm 4132M ...........32mm
4120M ...........20mm 4133M ...........33mm
4121M ...........21mm 4134M ...........34mm
4122M ...........22mm 4135M ...........35mm
4123M ...........23mm 4136M ...........36mm
4124M ...........24mm 4137M ...........37mm
4125M ...........25mm 4138M ...........38mm
4126M ...........26mm 4139M ...........39mm
4127M ...........27mm 4140M ...........40mm
4128M ...........28mm 4141M ...........41mm
4129M ...........29mm 4142M ...........42mm
4130M ...........30mm 4143M ...........43mm
4131M ...........31mm 4144M ...........44mm
Metal Case
20 piece set contents:
4145M ...........45mm 4156M ...........56mm
4146M ...........46mm 4157M ...........57mm
4147M ...........47mm 4158M ...........58mm
4148M ...........48mm 4160M ...........60mm
4150M ...........50mm 4162M ...........62mm
4151M ...........51mm 4163M ...........63mm
4152M ...........52mm 4165M ...........65mm
4153M ...........53mm 4167M ...........67mm
4154M ...........54mm 4170M ...........70mm
4155M ...........55mm 4175M ...........75mm
Metal Case
98
No. 9111M
1” Drive 12-Point - Standard Length - Metric Set
11 piece set contents:
4176M ...........76mm 4195M ...........95mm
4177M ...........77mm 41100M .........100mm
4178M ...........78mm 41105M .........105mm
4180M ...........80mm 41110M .........110mm
4185M ...........85mm 41115M .........115mm
4190M ...........90mm Metal Case
Ordering the 3 sets above will provide complete coverage in 1” Drive 12-Point Standard Length Metric sizes.
1
Warning:
Always wear safety goggles when using Impact Tools.
Use only properly matched fractional or metric sizes.
Loading...
