Greentech pureAir MOTION User Manual

Automobile Air Purification
Owner’s Manual
WELCOME
2
Thank you for your purchase of the pureAir MOTION. The technology in the unit is
designed to clean your vehicle’s breathing space of smoke, bacteria, viruses, VOC’s
(Volatile Organic Compounds), dust and other particulates. With minimal cleaning and
maintenance, you can keep MOTION in its optimal working condition.
1 Motion Air Purier
1 12V DC Power Cable
1 Owner’s Manual
Records:
Purchase Date: _____________________________________________________________________________
Model Number: ____________________________________________________________________________
Serial Number:______________________________________________________________________________
Retailer Name: _____________________________________________________________________________
Retailer Phone: _____________________________________________________________________________
TABLE OF CONTENTS
Uses & Features ........................................................... 4
Warnings ................................................................ 5
Product Introduction / Control Panel and Unit Top ............................. 6
Product Introduction / Unit Rear ............................................ 7
Setup ................................................................. 8 - 9
Operation ........................................................... 10 - 11
Maintenance ........................................................ 12 - 14
Cleaning ............................................................ 15 - 16
Product Specications ..................................................... 17
Warranty Information ...................................................... 18
Copyright © 2015 GreenTech Environmental, LLC. | All Rights Reserved
3
USES & FEATURES
4
NOTE: MOTION is not a medical device and should not be used to alleviate any respiratory issues
you may have. Please consult your doctor before using the MOTION if you are worried that the machine could cause adverse effects.
Uses
• Clean and removes particulates from your breathing space
Signicantly reduces bacteria, viruses, & VOC’s in the air
Features
• Cleanable Unit Body and Filter
• Replaceable ION Generator
• Quiet Operation
• Convenient Design
• 4 Hour Auto Shut-Off
WARNINGS
NOTE: For your safety, please read through these warnings before using MOTION.
Do not change settings on the unit while driving.
Do not place in a location that will obstruct your view while driving.
Do not block either air vent.
Be careful with liquids near the unit.
Unplug this unit before cleaning or maintenance.
Unplug this unit when not in use.
Mechanical or Electrical Maintenance must be performed by the manufacturer or
licensed professional. Failure to adhere to this will void your warranty.
If there is any damage to the unit or wiring, stop using immediately and contact the
manufacturer for repairs or replacement.
Copyright © 2015 GreenTech Environmental, LLC. | All Rights Reserved
5
PRODUCT INTRODUCTION / Control Panel & Unit Top
6
1
Air Vent Out
2
Mode/Fan Speed
3
Fan Speed Indicator
Ion Generator Replacement Light
5
Ion Generator Lifetime Reset
6
Clean Filter Light
1
2
344
5
6
PRODUCT INTRODUCTION / Unit Rear
7
Ion Generator
8
DC Power Plug In
9
Filter
10
Rear Cover Release
7
8
Copyright © 2015 GreenTech Environmental, LLC. | All Rights Reserved
11
DC Power Adapter
11
9
10
7
8
SETUP
Push on the Rear Unit Cover Release Button and slide the plate down and off the unit.
Place the DC Plug in the DC Power Plug In and situate the cord in one of its two cable ports along the side of the unit.
Replace the Rear Unit Cover.
SETUP
Secure the Power Plug into the Vehicle’s 12V Outlet.
Place the unit in a cup holder or another secure location that will not distract the driver.
Copyright © 2015 GreenTech Environmental, LLC. | All Rights Reserved
9
OPERATION
10
NOTE: To improve the Ion Output, use MOTION in conjunction with your vehicle’s Air Conditioning.
WARNING: Do not change settings on MOTION while driving your vehicle.
Push the Mode Button once. The unit will now run in Low Output Mode. (Denoted by One Arrow on Fan Speed Indicator)
Pushing the Mode Button again will change to High Output
Mode. (Denoted by Two Arrows on Fan Speed Indicator)
OPERATION
Pushing the Mode Button a third time will turn the unit OFF.
NOTE: MOTION will save the last mode used when you turn your car OFF and back ON.
NOTE: MOTION has an automatic shut-off feature that will power the unit down after 4 hours; this is to prevent a battery drain if your outlet is not controlled by the vehicle’s ignition.
Copyright © 2015 GreenTech Environmental, LLC. | All Rights Reserved
11
MAINTENANCE
12
Your MOTION will need maintenance from time to time in order to keep it functioning at its best ability.
WARNING: Remove the Power Plug from the Vehicle’s 12V Outlet before performing any
maintenance. Failure to do so could result in an electrical shock.
Ion Generator Replacement Indicator - 16,000 Hours Estimated Lifetime
The Ion Generator Replacement Indicator will light up to notify you if the
Ion Generator is damaged or in need of replacement. If a replacement
Ion Generator is needed, contact your retailer or the manufacturer at
www.GreenTechEnv.com.
Push on the Rear Cover Release Button and slide the Rear Cover down
and off the unit.
MAINTENANCE
Remove the screw holding the Ion Generator in place.
Disconnect the Power Cable and Remove the Ion Generator.
Replace the Ion Generator and the Screw that holds it in place.
Copyright © 2015 GreenTech Environmental, LLC. | All Rights Reserved
13
MAINTENANCE (continued from page 13)
14
Replace the Rear Cover and plug the unit back into the
Vehicle’s 12V Outlet.
6
Turn the MOTION on and hold the Reset Button for 3+ Seconds.
The Ion Generator Indicator Light will ash twice, turn off, and begin
monitoring the new Ion Generator.
CLEANING
Your MOTION will need cleaning from time to time in order to keep it functioning to its best ability.
WARNING: Remove the Power Plug from the Vehicle’s 12V Outlet before performing any cleaning. Failure to do so could result in an electrical shock.
WARNING: Damage may occur while using harsh chemical cleaners to clean your unit.
For best results, use a damp towel to wipe the unit down.
Push on the Rear Cover Release Button and slide the Rear Cover down
and off the unit.
Wash the Rear Cover/Filter under a faucet. Scrub thoroughly.
Copyright © 2015 GreenTech Environmental, LLC. | All Rights Reserved
15
CLEANING (continued from page 15)
16
Dry and replace the Rear Cover.
Turn the MOTION on and hold the Reset Button for 3+ Seconds. The Clean Filter Indicator Light will turn off.
PRODUCT SPECIFICATIONS
17
Model Number
Voltage
Effective Area
Dimensions
Weight
Modes
Electrical Usage
Ion Output
PA-MOTION
12V DC | .14 A
3
3.6 m
6.4” H (162 mm) x 2.8” W (72 mm) x 2.2” D (55 mm)
8.64 oz. (245g)
High
2.3 W
25,000 Ions/cm
Copyright © 2015 GreenTech Environmental, LLC. | All Rights Reserved
3
Low
1.8 W
7,000 Ions/cm
3
WARRANTY INFORMATION
18
LIMITED WARRANTY INFORMATION
Your pureAir MOTION (Product) is warranted to be free from all defects in material and workmanship in normal household use for a period of 1 Year from date of purchase. The warranty is granted only to the original purchaser. The warranty is subject to the following provisions:
Any damages or malfunctions caused by negligence, abuse, or use not in accordance with the Product Owner’s Manual are not covered by this warranty. Likewise, any defects or damages caused by unauthorized service or the use of other than Genuine GreenTech Environmental Parts are not covered.
GreenTech Environmental, LLC will, at its option, repair or replace a defective Product or part(s) for the Product that is/are covered by this warranty. As a matter of warranty policy, GreenTech Environmental, LLC will not refund the customer’s purchase price.
OBTAINING WARRANTY SERVICE
To obtain warranty service you must return the defective product along with proof of purchase to the GreenTech Environmental Authorized Service Center. All shipping costs submitted under this Warranty shall be borne by purchaser. Unless this Warranty is expressly renewed or extended by GreenTech Environmental, LLC, any repaired or replaced part of unit shall be warranted to the original purchaser only for the length of the unexpired portion of the original warranty. For the location of the nearest GreenTech Environmental Authorized Service Center or for other service information, please visit us online at:
www.GreenTechEnv.com/Service
Before any product is sent for service, the customer should contact the GreenTech Environmental Service Center to obtain a Return Merchandise Authorization (RMA) Number. This RMA Number should be clearly written on the box before shipping. All components/parts including the remote (if applicable), manuals, and original packaging should be included in the return if available.
FURTHER LIMITATIONS AND EXCLUSIONS ARE AS FOLLOWS
Any warranty that may be implied in connection with your purchase or use of the Product, including any warranty of merchantability or any warranty for Fitness For A Particular Purpose is limited to the duration of this warranty. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may not apply to you. Your relief for the breach of this warranty is limited to the relief expressly provided above. In no event shall GreenTech Environmental, LLC be liable for any consequential or incidental damages you may incur in connection with your purchase or use of the Product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
This Warranty gives you specic legal rights, and you may also have other rights which vary from state to state.
REGISTRATION
Please register your Product within 10 days of purchase by visiting www.GreenTechEnv.com/Warranty. Registering your new GreenTech product entitles you to the most up-to-date GreenTech warranty and promotion information.
