4. FAQS
Q1: Does the charging speed of Green Power power charger vary?
A: The charging speed of power charger vary with different operating and environmental
conditions, mainly consist of weather, positioning, obstructions.
Q2: Are Green Power power charger waterproof?
A: Green Power Ample 200 are IP65 rated, which means rain wet will not affect the normal use.
Caution: If you wish to clean your solar panel, use a gentle stream of water and do not use
seawater or corrosive liquid.
Q3: Can Green Power power charger store power themselves?
A: Power charger convert solar energy into electricity and pass it as a DC current to an GP
power station, as opposed to storing power themselves.
GREEN POWER Ample 200 Portable Power Charger
5. PACKAGE CONTENT
Power Charger Carrying bag
USER MANUAL
User Manual &
Warranty Card
1. SAFETY GUIDELINES
Please read these safety guidelines before using your new Green Power Ample 200
• The product has waterproof function, such as rain wet will not affect the normal use. But
please do not immerse the product in water.
• Do not use the product during severe weather conditions, such as thunderstorms, strong
winds, and hailstorms.
• Do not pierce the product with sharp objects, break it open with a hammer, or step on it.
• In order to increase the efficiency of the product, keep it perpendicular to sunlight when
using it.
• Do not contact the product with strong corrosive objects.
• Do not charge automotive battery directly.
2. SPECIFICATIONS
Technical Date
Peak Power 200W
Open Circuit Voltage
Max Power Voltage
Short Circuit Current
Max Power Current
Efficiency 22%
Cell Type Monocrystalline silicon
Connector Type MC4
Operating & Storage Temperature -40° F to 185° F (-40° C to 85° C)
Power Chargers number 50W*4pcs
General Info
Net weight 16.8lbs(7.66kg)
Unfolded Dimensions
Folded Dimensions 22*22.2*1.4in(56*56.4*5cm)
Warranty 12 months
43.2V
36V
5.83A
5.56A
88*22.2*1in(224*56.4*2.5cm)
MC4
Solar Charging Cable
(in Green Power Mars package)
Power Charger
3.2 Wire Power Chargers In Series
1. Connect the male connector of one power charger to the female connector of the other
power charger;
2. Connect the power charger MC4 Connectors to the Solar Charging Cable (in Green
Power Mars package);
3. Connect the DC connector on the Solar Charging Cable to the DC Input port on the
portable power station.
NOT RECOMMENDED FOR SLR-PS700
SLR-SP700 is limited to a maximum of 200W input for Solar.
Portable Power Station
3. USAGE STATEMENT
3.1 Single Power Charger
1. Connect the power charger MC4 Connectors to the Solar Charging Cable (in Green
Power Mars package);
2. Connect the DC connector on the Solar Charging Cable to the DC Input port on the
portable power station.
Note: Output is Voltage aditional
So Max. Power Voltage could
potentially exceed 100V!
