THE INDUSTRY LEADER
Over 90 Years Strong
GREENLEE.COM Professional. Nothing Less.™
Page 2
BUILDING AMERICA
SINCE 1862
Since the day we invented the knockout in 1928, we’ve made it our
mission to build for the world’s expert tradespeople. For decades,
our manufacturing plant in Rockford, IL has been building the widest
range of high-quality hole-making products for trade professionals.
Greenlee knockouts are known as industry-leading products that allow
professionals like you to complete any job more quickly and reliably.
As the industry evolves and technology advances, we continue our
90-year legacy of providing optimal knockout solutions.
2
Page 3
NEXT GENERATION OF KNOCKOUTS
• Punch up to 10-gauge mild steel or 12-gauge
stainless steel. Also punches aluminum, brass,
copper berglass and plastics.
• Slug-Buster® punch prole splits slugs for
easy slug removal
• Knurled edge on punches for better grip
• New die design optimized for widest range
of materials and drivers
• Taller die–no spacers required
• Laser marking for quick part identication
• Die alignment markings for improved punching accuracy
KD-2
Professional. Nothing Less.™
K2P-2
• Easy threading – draw studs with “dog-point” tip
helps eliminate cross threading. Hex key access
for easy removal from tool
• No sleeves required
DSH-7/16
KNOCKOUT UPGRADE SETS
Interested in using your existing Greenlee
knockout driver with the new knockouts?
Upgrade your knockouts and case to t
your driver.
CAT. NO. UPC NO. DESCRIPTION
KCC4-LS 783310088028 Slug-Buster® 1/2” to 4” for Battery-Hydraulic Drivers
KCC2-LS 783310088004 Slug-Buster® 1/2” to 2” for Battery-Hydraulic Drivers
KCC4-767 783310088011 Slug-Buster® 1/2” to 4” for Ram and Hand Pump
KCC2-767 783310087991 Slug-Buster® 1/2” to 2” for Ram and Hand Pump
KCC2-QD 783310087984 Slug-Buster® 1/2” to 2” for Quick Draw® and Quick Draw® 90
DSH-3/4
DSH-1-1/8
DSBB-3/4
DSBB-7/16
3
Page 4
7-TON AND 11-TON BATTERY-HYDRAULIC DRIVERS
Compact, fast, and powerful battery-hydraulic knockout drivers capable of punching up to 4-inch
conduit sized holes in mild steel, stainless steel, aluminum, brass, copper, berglass and plastics.
7-TON
7-TON PUNCHING FORCE
Punch up to:
4” conduit up to 12 ga mild steel
3” conduit up to 10 ga mild steel
2” conduit up to 12 ga stainless steel
11-TON
11-TON PUNCHING FORCE
Punch up to:
4” conduit up to 10 ga mild steel
4” conduit up to 10 ga stainless steel
AUTO
AUTO
PATENT-PENDING
AUTO-STOP FEATURE
Detects punch completion and
automatically stops, helping to
prevent damage to knockout parts
LS50L2 LS100X Intelli-PUNCH™
360° ROTATING HEAD
Rugged patent-pending swivel
design to easily punch at any angle
RUGGED NECK
Increased durability and life of tool
TIMESAVER
Punch faster, with a maximum
cycle time of 8 seconds
COMPACT, ERGONOMIC DESIGN
Provides easy one-handed operation
and an ergonomic tapered grip
4
AUTO-RETRACT TECHNOLOGY
Pressure-sensing technology accurately
detects punch completion and automatically
retracts the ram, helping to prevent
damage to knockout parts
COMPATIBILITY
Works with all Greenlee knockouts and
other major brands designed for use with a
hydraulic tool. Same draw studs used with
the Intelli-PUNCH, LS50 and 746 ram
BATTERY PLATFORM
Powerful long-lasting Makita® 18V Li-Ion
battery, quickly charges in 30 minutes
i-press® SOFTWARE
Monitor tool performance and set service intervals
via i-press Bluetooth® communication. LS50
compatible with Gator Eye® desktop software.
Bluetooth is a registered trademark of BLUETOOTH SIG, INC.
Page 5
LS50L11B4
Professional. Nothing Less.™
LS50 7-TON BATTERY-HYDRAULIC KNOCKOUT KITS
CAT. NO. UPC NO. DESCRIPTION
LS50L11B4 783310037743 Slug-Buster® 1/2” to 4” Conduit
LS50L11B 783310049562 Slug-Buster® 1/2” to 2” Conduit
LS50L11A 783310049517 Driver, Draw Studs, Battery, Charger, and Case
LS50LB 783310011316 Driver and Case Only
LS50L2 783310088042 Driver Only
Intelli-PUNCH™ 11-TON BATTERY-HYDRAULIC KNOCKOUT KITS
CAT. NO. UPC NO. DESCRIPTION
LS100X11SB4 783310064848 Slug-Buster® 1/2” to 4”
LS100X11SB4X 783310064855 Slug-Buster® 1/2” to 3” and 4”
LS100X11SB 783310064831 Slug-Buster® 1/2” to 2”
LS100X11A 783310064824 Driver, Draw Studs, Batteries, Charger
and Case
LS100XB 783310064817 Driver and Case Only
LS100X 783310088059 Driver Only
LS100X11SB4
Fits Greenlee LS50L2 or LS100X tool,
two batteries and a charger
KCC4-LS
KNOCKOUT UPGRADE SETS FOR BATTERY-HYDRAULIC DRIVERS
CAT. NO. UPC NO. DESCRIPTION
KCC4-LS 783310088028 Slug-Buster® 1/2” to 4”
KCC2-LS 783310088004 Slug-Buster® 1/2” to 2”
DRAW STUDS FOR BATTERY-HYDRAULIC DRIVERS
CAT. NO. UPC NO. DESCRIPTION
DSH-7/16 783310090632 7/16” Hydraulic Draw Stud for 1/2”
Conduit Size Knockouts
DSH-3/4 783310090663 3/4” Hydraulic Draw Stud for 3/4” to 2”
Conduit Size Knockouts
DSH-1-1/8 783310090670 1-1/8” Hydraulic Draw Stud for 2-1/2” to
4” Conduit Size Knockouts
7304
LARGE DIAMETER KNOCKOUT EXPANSION SET
CAT. NO.
UPC NO.
DESCRIPTION
7304 783310028154 Standard Round 2-1/2”, 3’’,
3-1/2” and 4”
5
Page 6
11-TON MANUAL-HYDRAULIC DRIVERS
The compact design with 11 tons of punching force is capable of punching up to 4” conduit
size holes in 10-gauge mild steel and 12-gauge stainless steel; also punches aluminum,
brass, copper, berglass and plastics. The hand pump and foot pump options allow for a
variety of operation orientations.
7310SB 7610SB
11-TON HYDRAULIC KNOCKOUT KITS WITH HAND PUMP
CAT. NO. UPC NO. DESCRIPTION
7310SB 783310343615 Slug-Buster® 1/2” to 4”
7310 783310159100 Standard Round 1/2” to 4”
7309SB 783310088325 Slug-Buster® 1/2”, 3” and 4”
7309 783310088318 Standard Round 1/2”, 3” and 4”
7306SB 783310343608 Slug-Buster® 1/2” to 2”
7306 783310159094 Standard Round 1/2” to 2”
7646 783310159063 Ram/Hand Pump Group, Draw
Studs, and Case Only
6
11-TON HYDRAULIC KNOCKOUT KITS WITH FOOT PUMP
CAT. NO. UPC NO. DESCRIPTION
7610SB 783310071747 Slug-Buster® 1/2” to 4”
7606SB 783310071730 Slug-Buster® 1/2” to 2”
7625 783310250975 Ram/Foot Pump Group, Draw Studs,
and Case Only
Page 7
Fits Greenlee 746A Ram
and 767 Hand Pump
Professional. Nothing Less.™
KCC4-767
KNOCKOUT UPGRADE SETS FOR RAM AND HAND PUMP
CAT. NO. UPC NO. DESCRIPTION
KCC4-767 783310088011 Slug-Buster® 1/2” to 4” Conduit
KCC2-767 783310087991 Slug-Buster® 1/2” to 2” Conduit
DRAW STUDS FOR RAM AND PUMP DRIVERS
CAT. NO. UPC NO. DESCRIPTION
DSH-7/16 783310090632 7/16” Hydraulic Draw Stud for
1/2” Conduit Size Knockouts
DSH-3/4 783310090663 3/4” Hydraulic Draw Stud for 3/4”
to 2” Conduit Size Knockouts
DSH-1-1/8 783310090670 1-1/8” Hydraulic Draw Stud for 2-1/2”
to 4” Conduit Size Knockouts
7304
LARGE DIAMETER KNOCKOUT EXPANSION SET
CAT. NO. UPC NO. DESCRIPTION
7304 783310028154 Standard Round 2-1/2”, 3”, 3-1/2”
and 4”
7
Page 8
8-TON MANUAL-HYDRAULIC DRIVERS
The compact design delivers 8 tons of punching force for portability and fast, easy
one-person operation. Punch 1/2” to 2” conduit size holes in up to 10-gauge mild steel
and 12-gauge stainless steel; also cuts aluminum, brass, copper, berglass and
plastics. Available in three driver orientations.
7906SB
Quick Draw 90
®
• 180° Rotating Head–Right angle driver
head rotates over 180° for maneuverability
in tight work areas
8
QUICK DRAW 90® 8-TON HYDRAULIC KNOCKOUT KITS
CAT. NO. UPC NO. DESCRIPTION
7906SB 783310343004 Slug-Buster® 1/2” to 2”
7904SB 783310337942 Driver, Draw Studs, and Case Only
Page 9
Professional. Nothing Less.™
Quick Draw
®
• Fast, straight-on punching
7806SB
QUICK DRAW® 8-TON HYDRAULIC KNOCKOUT KITS
CAT. NO. UPC NO. DESCRIPTION
7806SB 783310342939 Slug-Buster® 1/2” to 2”
7804SB 783310342922 Driver, Draw Studs, and Case Only
Quick Draw Flex
®
• Flex head allows for maximum exibility in
tight working areas
7906SB
QUICK DRAW FLEX® 8-TON HYDRAULIC KNOCKOUT KITS
CAT. NO. UPC NO. DESCRIPTION
7706SB 783310104766 Slug-Buster® 1/2” to 2”
7704SB 783310104759 Driver, Draw Studs, and Case Only
Fits Greenlee Quick Draw®
or Quick Draw 90® Driver
KCC2-QD
KNOCKOUT UPGRADE SETS FOR QUICK DRAW DRIVERS
CAT. NO. UPC NO. DESCRIPTION
KCC2-QD 783310087984 Slug-Buster® 1/2” to 2” Conduit
DRAW STUDS FOR ALL QUICK DRAW DRIVERS
CAT. NO. UPC NO. DESCRIPTION
DSH-S7/16 783310090649 7/16” Short Hydraulic Draw Stud for
1/2” Conduit Size Knockouts
DSH-S3/4 783310090656 3/4” Short Hydraulic Draw Stud for
3/4” to 2” Conduit Size Knockouts
9
Page 10
RATCHET KITS AND MANUAL SETS
New and improved high-leverage wrench with ve-degree ratcheting mechanism provides
versatility and accessibility in tight spaces. The long, over-mold handle offers greater leverage,
comfort and grip. Punch 1/2” to 2” conduit size holes in 10-gauge mild steel; also punches
aluminum, brass, copper, berglass and plastics.
RATCHET WRENCH KITS
CAT. NO. UPC NO. DESCRIPTION
7238SB 783310347576 Slug-Buster® 1/2” to 2”
7240SB 783310028604 Slug-Buster® 1/2”, 3/4” Conduit, 30.5mm
10
7238SB
7237BB
New High-Leverage Ratchet Wrench
MANUAL KNOCKOUT SETS
CAT. NO. UPC NO. DESCRIPTION
7237BB 783310320142 Slug-Buster® 1-1/2” to 2” Conduit
737BB 783310199748 Standard Round 1-1/2” to 2” Conduit
7235BB 783310320135 Slug-Buster® 1/2” to 1-1/4” Conduit
735BB 783310199731 Standard Round 1/2” to 1-1/4” Conduit
MANUAL DRAW STUDS
CAT. NO. UPC NO. DESCRIPTION
DSBB-7/16 783310090601 7/16” Manual Draw Stud for
1/2” Conduit Size Knockouts
DSBB-3/4 783310090625 3/4” Manual Draw Stud for
3/4” to 2” Conduit Size Knockouts
DSBB-1-1/8 783310090687 1-1/8” Manual Draw Stud for 2-1/2” to
4” Conduit Size Knockouts. Use with
3036AVBB Ball-Bearing Nut
Page 11
KNOCKOUT SETS AND INDIVIDUAL PARTS
Professional. Nothing Less.™
®
K2BB-2 K3BB-2
HOLE SIZE SLUG-BUSTER
CONDUIT
SIZE
1/2” 0.89” 22.5 mm K2BB-1/2 K2P-1/2 K3BB-1/2 K3P-1/2 KD-1/2 DSBB-7/16
3/4” 1.12” 28.3 mm K2BB-3/4 K2P-3/4 K3BB-3/4 K3P-3/4 KD-3/4
– – 30.5 mm K2BBM-0305 K2PM-0305 – – KDM-0305
1” 1.36” 34.6 mm K2BB-1 K2P-1 K3BB-1 K3P-1 KD-1
1-1/4” 1.70” 43.2 mm K2BB-1-1/4 K2P-1-1/4 K3BB-1-1/4 K3P-1-1/4 KD-1-1/4
1-1/2” 1.95” 49.6 mm K2BB-1-1/2 K2P-1-1/2 K3BB-1-1/2 K3P-1-1/2 KD-1-1/2
2” 2.42” 61.5 mm K2BB-2 K2P-2 K3BB-2 K3P-2 KD-2
2-1/2” 2.91” 74.0 mm – – K3BB-2-1/2 K3P-2-1/2 KD-2-1/2
3” 3.54” 89.9 mm – – K3BB-3 K3P-3 KD-3
3-1/2” 4.04” 102.7 mm – – K3BB-3-1/2 K3P-3-1/2 KD-3-1/2 DSBB-1-1/8,
4” 4.54” 115.4 mm – – K3BB-4 K3P-4 KD-4
ACTUAL SIZE SET PUNCH SET PUNCH DIE
®
STANDARD ROUND
Standard RoundSlug-Buster
MANUAL
DRAW STUD
DSBB-3/4
DSBB-1-1/8
and 3036AVBB
3037AV, and
3036AVBB
HYDRAULIC
DRAW STUD
DSH-7/16,
DSH-S7/16
DSH-3/4,
DSH-S3/4
DSH-1-1/8
CATALOG NUMBER KEY
Part Type
K2 = Slug-Buster® Punch
K3 = Standard Round Punch
KD = Knockout Die
DS = Draw Stud
Tool Usage
BB = Manual Ball Bearing
H = Hydraulic
Size Type
Default = Conduit (in)
M = Metric (mm)
11
Page 12
MA6631
©2019 Greenlee Tools, Inc. • An ISO 9001 Company • Printed in USA
