Gree SG-DEH-30E-1, DP1-30E-03, SG-DEH-45E-1, DP1-45E-03, SG-DEH-70E-1 Operating Instructions Manual
...
Models
SG-DEH-30E-1 (DP1-30E-03)
SG-DEH-45E-1 (DP1-45E-03)
SG-DEH-70E-1 (DP1-70E-03)
General Dehumidifier Information
RECOMMENDED HUMIDITY LEVELS ACCORDING TO ENERGY STAR
Spring/Summer: 30% - 50%
Fall/Winter: 30% - 40%
WARM AIR EXHAUST IS NORMAL
During operation your dehumidifier will exhaust warm air from the top of the unit. This is normal operation.
EMPTYING THE BUCKET
The more moisture your dehumidifier removes from the air, the more often you may have to empt
(unless you are using the continuous drainage option). The number of times the bucket will be emptied
depends on the dehumidifier model.
Model5HIHUHQFH
SG-DEH-30(-1/DP1-30(-03
SG-DEH-45(-1/DP1-45(-03
Pints of moisture removed per every
24 hour period
30 Pints
45 Pints
Maximum number of times to empty
the bucket when operating at full
capacity during a 24 hour period
Up to 3 times
Up to 5 times
y the bucket
SG-DEH-70E-1/DP1-70E-03
70 Pints
Up to 4 times
LESS MOISTURE BEING REMOVED OVER TIME IS A GOOD THING!
Using a dehumidifier will cause your area to maintain a more comfortable humidity level. Over time, this
humidity level will become more and more stable. Due to the stable humidity level in the area, t
dehumidifier will need to remove less and less moisture over time.
Please do not be concerned if the dehumidifier is removing less moisture from the air or the bucket is taking
longer to fill up. This is a direct result of your dehumidifier creating a more stable humidity level in your area.
he
DON’T REMOVE THE STYROFOAM IN THE BUCKET!
All Soleus Air dehumidifiers are equipped with a reliable Styrofoam float system. The Styrofoam located inside the float in the bucket is essential to the bucket full system working properly. Please do not r
Styrofoam from the float.
emove the
2
FEATURES
Removes up to 30/45/70 pints (depending on model) of moisture from the air every 24 hours. This is not the bucket size.
Adjustable humidistat for precise humidity control.
Digital humidistat displays set humidity level and current room
humidity level.
Operates at temperatures down to 41°F. Perfect for basement
use in the winter.
Automatic defrost function melts away ice from frozen coils for
continuous, worry-free operation.
3 Speed fan allows you to choose between maximum dehumidifying power or close to silent operation.
Bucket full indicator and audible alarm signals as soon as the
bucket is full and ready to be emptied.
Automatic shut-off timer automatically turns off the unit after 2 or
4 hours.
Ultra quiet operation allows for use almost anywhere. Perfect for
heavy traffic areas like a family room or bedroom.
Loss of power protection remembers all settings even when
power is interrupted.
Auto-restart automatically continues operation when power is restored. No need to manually restart the dehumidifier.
Thank you for choosing a Sole
us Air Powered by Gree Portable Dehumidifier. This owner’s manual
will provide you with valuable information necessary for the proper care and maintenance of your
new product. Please take a few moments to thoroughly read the instructions and familiarize yourself
with all the operational aspects of your ne
w Dehumidifier.
For your own records, please attach a copy of your sales receipt to this manual. Also, write the store
name/location, date purchased, and serial number below:
Store Name: ____________________________________________________
Location: ______________________________________________________
Date Purchased: _________________________________________________
Serial Numb
IMPORT
er (located on back of unit): ______________________________
ANT INSTRUCTIONS
Before installing and using your dehumidifier, please read this owner’s manual carefully. Store this manual in a
safe place for future reference.
1) Always place the unit on a level surface.
2) Never use or store gasoline or other flammable vapor or liquid near this unit unless instructed by this
manual.
3) Maintain at least 12-18 inches clearance space around this unit. Do not block or cover air inlet or outlet
grilles.
4) The unit must be connected to a correctly grounded power supply.
5) Do not start or stop the unit by inserting or pulling out the power plug.
6) Do not use an adapter plug or extension cord.
7) Do not use the unit in the immediate surroundings of a bath, a shower or a swimming pool.
8) Do not insert anything into the air outlet. Do not obstruct air inlet or outlet grills unless instructed by this
manual.
9) Do not let children play near this unit.
10) Always inspect the cord for signs of damage before use. If the power cord is damaged, it must be replaced
by the manufacturer or a qualified service technician.
11) When cleaning the unit, always turn the unit off and unplug the power cord.
12) Keep the unit away from any potential fire hazard.
13) Never put your hand inside the unit to prevent injury from the fan blades.
4
PACKAGE CONTENTS
Portable Dehumidifier
Operating Instructions
SPECIFICATIONS
• Noise level is measured at a distance of 3.28
• Power consumption is measured when the fan runs at the highest speed setting.
• These specifications are for reference only. For actual data, please refer to the rating label on the back of the unit.
Model Number
Reference Number DP1-30E-03 DP1-45E-03 DP1-70E-03
Dehumidifying
Power
(Watts)
Air Flow Volume
(High/Med/Low)
Power Source 115 V / 60 HZ
Rated Current (Amps) 3.7 A
Sound Pressure Level dB(A)
(max)
Weight 33.1 bls
Dimensions
Consumption
(WxDxH)
Capacity
ft away from the front of the unit.
G-DEH-30(-1
S
30
Pints
per day
320 Watts
118 / 106 / 94 CFM
56 dB(A)
13. 573 ” x 1
0.25” x 19.5 ”
S
G-DEH-45
45
Pin
ts per
480 Watts
94 / 82 CFM
106 /
115 V / 60
5.1A
6 dB(A)
5
36.3 lbs
13. 573 ” x 1
(-1
day
HZ
0.25” x 19.5 ”
SG-DEH-70E-1
70 Pints per day
745 Watts
175 /
194 /
1
115 V / 60 HZ
7.5A
56 dB(A)
45 lbs
15.375” x 11” x 23.625”
56 CFM
E
nergy
St
Yes
ar
Yes
Yes
DISCLAIMER
ALL INFORMATION AND THE TECHNICAL SPECIFICATIONS PRESENTED
PRESENTATION OF THE MANUFACTURER. SOLEUS INTERNATIONAL HAS NOT CONDUCTED INDEPENDENT
TEST TO THE INFORMATION AND THE SPECIFICATIONS PRESENTED HEREWITHIN.
5
IN THIS USER’S MANUAL ARE THE
CONTROL PANEL & DIGITAL DISPLAY
TIMER INDICATORS
TIMER BUTTON
FAN SPEED BUTTON
FAN SPEED INDICATORS
INCREASE/DECREASE
ROOM HUMIDITY
CONTINUOUS
MODE INDICATOR
FILTER BUTTON
AND INDICATOR
BUCKET FULL
INDICATOR
POWER BUTTON
AND INDICATOR
6
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
1) When first operating the dehumidifier, run it in Continuous mode for 24 hours.
2) Power On and Off - Press the POWER button once to manually turn the unit on. Press the POWER
3) Humidity Selection - Press the “+” or “-” buttons to choose the desired relative humidity in the room.
4) Fan Speed Control - Press the FAN SPEED Button to cycle through the different fan speeds: High,
button once more to turn the unit off.
Each press of the button will change the desired room humidity by 5%. The room humidity is selectable
from 35%-80% or continuous. The unit will cycle on and off to maintain the humidity level chosen on the
digital display. If you want the dehumidifier to operate continuously regardless of the room humidity, press
the (-) buttons until you see “CO” on the digital display. This will enable continuous operation and the
“Continue” indicator will light up on the control panel.
Medium, and low. The fan speed can be visually distinguished by the fan speed indicators on the control
panel.
5) Timer - To program the unit to automatically turn off, press the TIMER button when the unit is on. You
can select either 2 or 4 hours with the Timer. Once the desired time (2 or 4 hours) is over, the unit will
automatically shut down.
6) Bucket Full
- When the water bucket is full of water, the unit will automatically shut off , make a beeping
noise, and the Bucket Full Indicator will light up. The dehumidifier will not function until the water
bucket is emptied and placed back inside the unit. The bucket should be cleaned every few weeks to prevent the growth of mold, mildew and bacteria. Use a mild detergent to clean the bucket. Once clean, completely dry the bucket and place it back inside the dehumidifier.
NOTE: Support
both hands when emptying
bucket with
7) Clean Filter - When the filter needs to be cleaned, the filter indicator will
light up. Remove the filter and clean with warm, soapy water. Dry thoroughly before replacing the filter. Once the filter is completely dry, place the filter back in
the unit and press the FILTER button to reset the filter indicator.
If the filter is torn or unusable, order a new filter by calling our customer service.
NOTE: When the bucket is full or removed from the machine, the compressor
will turn off, but the fan will continue to run for a few minutes. This is completely normal. The dehumidifier will not be removing moisture from the air at
this time.
7
CHOOSING A LOCA TION
A Dehumi
cent enclosed storage area, such as a closet, unless there is adequate circulation of air
in and out of the area.
• Do not use outdoors
difier operating in a basement will have little no effect in drying out an adja-
YES NO
Above
41° F
Below
41° F
• This dehumidifier is intended for indoor residential applications only. This unit
should not be used for commercial or indust r i al applicat i ons
• Place the dehumidifier on a smooth , level floor surface that is strong enough to
support the unit with a full bucket of water.
• Place the dehumidifier in an area where the temperature will not fall below 41°F.
The coils can become covered with frost at temperatures below 41°F, which may
reduce performance
• Use the dehumidifier in cooking, laundry, bathing and dishwashing areas that have
excessive moisture. NOTE: Place the dehumidifier away from a clothes dryer.
• Use the dehumidifier to prevent moisture damage anywhere books or valuables
are stored.
• Use the dehumidifier in a basement to help prevent moisture damage.
• The dehumidifier must be operated in an enclosed area to be most effective.
• Close all doors, windows and other outside openings to the room.
AUTOMATIC DEFROST
When frost builds up on the evaporator coils, the compressor will cycle off and the fan will continue to run un til the frost disappears.
When the coils is completely defrosted, the compressor or fan (depending on the model) will automatically restart and
dehumidification will resume.
CONTINUOUS DRAINAGE HOSE
Water can be automatically emptied by attaching a hose to the continuous drainage port on the side of the dehumidifier. This will
allow the unit to run continuously (depending on the selected humidity level) without having to empty the water bucket. To drain,
simply attach a standard garden hose (not included). The thread standard for garden hoses in the US and its territories is known as
GHT or "garden hose thread" which has an outer diameter of 1 1/16 inches (1.0625 inches or 27.0 mm) and a pitch of 11.5 TPI.
• Remove the bucket from the front of the unit.
• Open the drain cover on the side of the dehumidifier.
• Thread a garden hose (not supplied) onto the nozzle, cut to length and lead to the floor drain.
• Replace the bucket in the dehumidifier.
NOTE: The bucket must be in place and securely seated for the dehumidifier to operate.
ATTENTION: When using continuous drainage option, place dehumidifier on a level surface and make sure garden hose
is clear of any obstructions and is directed downward. Press down drain door so it rests on top of the hose.
Placing dehumidifier on an uneven surface or improper hose installation may result in water filling up the
bucket and causing the unit to shut off. Empty water bucket if shut off occurs, then check dehumidifier
location and hose for proper setup.
8
TROUBLESHOOTING
Problem Possible Causes Solutions
humidifier is unplugged. Make sure the dehumidifier’s plug is pushed completely into
Dehumidifier does not start
The de
the outlet.
Dehumidifier does not dry the
air as it should
The fuse is blown / circuit breaker
is tripped.
Dehumidifier has reached its
present level or the bucket is full.
Bucket is not in the proper
position.
Power Failure. There is a protective time delay (up to 3 min.) to prevent trip-
Not enough time allowed for unit
to remove moisture.
Airflow is restricted. Make sure there are no curtains, blinds, or furniture blocking
Dirty filter. See the Clean Filter section on Page .
The Humidity Control may not be
set low enough.
Check the house fuse / circuit breaker box and replace fuse or
reset breaker.
The dehumidifier automatically turns off when either condition
occurs. Change to a lower setting or empty the water bucket
and replace properly.
The bucket must be in place and securely seated for the dehumidifier to operate.
ping of the compressor overload. For this reason, the unit may
not start normal dehumidification for 3 min. after it is powered
back on.
When first installed, allow at least 24 hours to maintain the
desired dryness.
the front or back of the dehumidifier. See the Choosing a Lo-
cation section on Page .
For drier air, press the “
ity desired in the room, or set the dehumidifier to CO for maximum dehumidification.
8
7
” but
ton to lower the percent humid-
-
Dehumidifier runs too much The area to be dehumidified is too
Frost appears on the coils The dehumidifier has recently
Controls cannot be set The compressor will turn off and
Fan Noise Air is moving through the unit. This is normal.
Water on the floor Hose connection may be loose. Check the hose connection. See the Drainage Section on Page .
Doors and windows may not be
closed tightly.
Clothes dryer may be blowing
moist air into the room.
Room temperature is too low. Moisture removal is best at higher room temperatures. Lower
large.
Doors and windows are open. Close all doors and windows to the outside.
been turned on or the room
temperature is below 41°F.
the fan will automatically
continue to run for approximately
3 minutes at a fixed setting.
Hose is attached but not draining
into a drain
Check that all doors, windows, and other openings are securely
closed.
Install the dehumidifier away from the dryer. The dryer should
be vented outside.
room temperatures will reduce the moisture removal rate. This
model is designed to operate at temperatures above 41°F.
The capacity of your dehumidifier may not be adequate for the
room size.
This is normal. Frost will usually disappear within 60 minutes.
This is normal. Wait approximately 3 minutes and set the fan
speed at the desired level.
Disconnect the hose if using the bucket or place the hose near a
drain.
9
8
WARRANTY
One Year Limited Warranty
Soleus International Inc. warrants the accompanying Soleus Air Powered by Gree Dehumidifier to be free of
defects in material and workmanship for the applications specified in its operation instruction
year from the date of original retail purchase in the United States.
If the unit exhibits a defect in normal use, Soleus International Inc. will, at its option, either repair or replace it, free of
charge within a reasonable time after the unit is returned during the warranty period.
As a condition to any warranty service obligation, the consumer must present this Warranty Certificate along with a
copy of the original purchase invoice.
THIS WARRANTY DOES NOT COVER:
•
Damage, accidental or otherwise, to the unit while in the possession of a consumer not caused by a defect in
material or workmanship.
•
Damage caused by consumer misuse, tampering, or failure to follow the care and special handling provisions
in the instructions.
mage to the finish of the
Da
•
Damage caused by repairs or alterations of the unit by anyone other than those authorized by Soleus Interna-
•
tional Inc.
Freight and Insurance cost for the warranty service.
•
ALL WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MER
ONE-YEAR DURATION OF THIS EXPRESS LIMITED WARRANTY. SOLEUS INTERNATIONAL INC.
DISCLAIMS ANY LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES AND IN NO EVENT
SHALL SOLEUS INTERNATIONAL INC’S LIABILITY EXCEED THE RETAIL VALUE OF THE UNIT FOR
BREACH OF ANY WRITTEN OR IMPLIED WARRANTY WITH RESPECT TO THIS UNIT.
This warranty covers only new products purchased from our authorized dealers or retailers. It does not cover used, salvaged, or refurbished products.
As some states do not allow the limitation or exclusion of incidental or consequential damages, or do not allow
limitation on implied warranties, the above limitations and exclusions may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights that vary from state to state.
For Technical Support & Warranty Service
Please Call (888) 876-5387
Or Write To:
Soleus International Inc.
20035 E. Walnut Dr, North.
City of Industry, CA 91789 USA
www.soleusair.com
www.greeusa.com
case, or other appearance
parts caused by wear.
Portable
for a period of ONE (1)
CHANT ABILITY ARE LIMITED TO
Loading...
