GRD Systems Bliss User Manual

BLISS

BLISS

User's Manual

Thank you for choosing
GRD products

BLISS

User's manual

21

Package

Monitor – 1pc.
Door panel - 1pc.
Wall mounting bracket with screws – 1pc.
Table mounting bracket – 1pc.
Power adaptors – 2pcs.
User's manual – 1pc.

Monitor keys

1. Microphone

2. Display

3. Contrast tuning

4. Brightness tuning

5. Talk volume tuning

6. ”Choose call melody” button

7. ”Answer” button

8. ”Open lock” button

9. „Call melody volume” button

10. „Monitor” button

11. Speaker

Door panel keys

1. Microphone

2. Infrared backlight

3. Camera

4. Speaker

5. ”Call” button

6. Name plate

1

4

3

2

6

5

1

4

3

2

6

5

7

8

9

10

11

Monitor Specication:

Display 4" LCD

Resolution 320 x 240 pixels

Input voltage ~100-240V (50-60 Hz)

Output adaptor voltage 5V, 1.0 A

Power consumption 5 W in working mode
0,1 W in standby mode

Door panel system wireless

Frequency range 2,402 - 2,483 GHz

Operating distance up to 300 m. open area

Image compression MJPG, up to 10-16 frames/sec.

Dimensions 190 mm(H)> х 125mm(W) х 26mm( T)

Temperature range -5˚С ~ 40˚С

Door panel specication:

Camera CMOS

Night mode Infrared backlight

Viewing angle 92˚

Input voltage ~100-240V (50-60 Hz)

Output adaptor voltage 13V, 1.2 A

Power consumption 10 W in working mode
0,1 W in standby mode

Dimensions 142 mm(H)> х 98mm(W) х 38m( T)

Temperature range -20˚С ~ 40˚С
