GRAUPNER WEGA, WEGA 2068 Operating Instructions Manual
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical modifications reserved! 03/2011
1
Operating Instructions for the WEGA model boat, Order No.: 2068
Brief description of the full-size vessel
As the basis for our model we selected a typical schooner with topsail schooner rig. The term schooner was
originally applied to two-masted sailing ships whose aft mast was taller than the forward one, but later - from
the nineteenth century on - schooners were also built with several masts. Nowadays these vessels are
generally operated as museum ships, and can be admired at international sailing events. A small number of
these vessels are still operated as regular sail-training ships.
Brief description of the model
Ready-made model (ARTR)
GRP hull
Wooden deck and superstructure with lacquered finish
Laser-cut ABS internal superstructure panels
Metal and plastic detail fittings and small parts
Ready-made rigging, easily installed
Ready-made sails with sewn panels
Hull, superstructure etc. spray-finished using matt paints
Factory-installed SPEED 600 class electric motor
Relatively easy installation of receiving system components
Set contents: model, boatstand, small items
Specification
Overall length approx. 1300 mm
Beam approx. 275 mm
Overall height approx. 1150 mm
All-up weight approx. 8.5 kg
Scale approx. 1 : 30
Manufacturer’s declaration from Graupner GmbH & Co KG
Content of the manufacturer’s declaration
If material defects or manufacturing faults should arise in a product distributed by us in the Federal Republic of
Germany and purchased by a consumer (§ 13 BGB), we, Graupner GmbH & Co. KG, D-73230 Kirchheim/Teck,
Germany, acknowledge the obligation to correct those defects within the limitations described below.
The consumer is not entitled to exploit this manufacturer’s declaration if the failure in the usability of the product
is due to natural wear, use under competition conditions, incompetent or improper use (including incorrect
installation) or external influences.
This manufacturer’s declaration does not affect the consumer’s legal or contractual rights regarding defects
arising from the purchase contract between the consumer and the vendor (dealer).
Extent of the guarantee
If a claim is made under guarantee, we undertake at our discretion to repair or replace the defective goods. We
will not consider supplementary claims, especially for reimbursement of costs relating to the defect (e.g. installation / removal costs) and compensation for consequent damages unless they are allowed by statute. This
does not affect claims based on legal regulations, especially according to product liability law.
Guarantee requirements
The purchaser is required to make the guarantee claim in writing, and must enclose original proof of purchase
(e.g. invoice, receipt, delivery note) and this guarantee card. He must send the defective goods to us at his own
cost, using the following address:
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical modifications reserved! 03/2011
2
Gliders
Brunel Drive, Newark, Nottinghamshire, NG242EG
The purchaser should state the material defect or manufacturing fault, or the symptoms of the fault, in as accurate a manner as possible, so that we can check if our guarantee obligation is applicable.
The goods are transported from the consumer to us and from us to the consumer at the risk of the consumer.
Duration of validity
This declaration only applies to claims made to us during the claim period as stated in this declaration. The
claim period is 24 months from the date of purchase of the product by the consumer from a dealer in the
Federal Republic of Germany (date of purchase). If a defect arises after the end of the claim period, or if the
evidence or documents required according to this declaration in order to make the claim valid are not presented
until after this period, then the consumer forfeits any rights or claims from this declaration.
Limitation by lapse of time
If we do not acknowledge the validity of a claim based on this declaration within the claim period, all claims
based on this declaration are barred by the statute of limitations after six months from the time of
implementation; however, this cannot occur before the end of the claim period.
Applicable law
This declaration, and the claims, rights and obligations arising from it, are based exclusively on the pertinent
German Law, without the norms of international private law, and excluding UN re tail law.
Important safety notes
You have purchased a kit which can be assembled to produce a fully working RC model boat when fitted out
with the appropriate accessories. As manufacturers, we at GRAUPNER are not in a position to influence the
way you install, operate and maintain the boat, nor the other components used in connection with the model.
For this reason we are obliged to deny all liability for loss, damage or costs which are incurred due to the
incompetent or incorrect use and operation of our products, or which are connected with such operation in any
way. Unless otherwise prescribed by binding law, the obligation of the GRAUPNER company to pay
compensation, regardless of the legal argument employed, is excluded. This includes personal injury, death,
damage to buildings, loss of trade or turnover, interruption of business or other indirect or direct damages which
are caused by the operation of the model.
Under all circumstances and in all cases the company’s overall liability is limited to the amount which you
actually paid for this model.
The model is operated at the sole risk of the operator. To avoid injury to persons and damage to
property please handle your model boat carefully and operate it conscientiously at all times.
Before you run the boat for the first time it is important to check that your private third party insurance policy
provides cover when you are operating model boats of this kind. If you are not sure, take out a special
insurance policy designed to cover the risks of RC modelling.
These safety notes are important, and must be kept in a safe place. If you ever dispose of the model, be sure to
pass them on to the new owner.
The following points are important, and must be observed at all times:
This model is not suitable for children or young persons under fourteen years of age.
The projecting parts of the model may be sharp, and the tips of aerials and masts could cause eye injuries.
The parent or guardian must supervise the model’s assembly, as there are certain dangers inherent in the
use of tools and adhesives.
Always operate the model carefully when there are persons or animals in the water. Always keep well
clear of people and animals.
Do not run your boat in protected sites, animal or plant sanctuaries or sites of special scientific interest
(SSSI). Check with your local authority that the location you wish to use is suitable for model boats.
Never run the model in salt water.
Never operate your boat in adverse conditions, e.g. rain, storm, wind above Beaufort Scale 3, choppy
water or strong currents.
Since the model is dependent upon the wind, it should only be operated in light breezes of 1 to 2 Beaufort
(defined as ‘leaves moving slightly in the wind’). In stronger winds the boat may heel over severely and be
impossible to control; in the worst case it could take on so much water that it sinks. The boat is also
unsuitable for gusty conditions.
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical modifications reserved! 03/2011
3
Before you run the model check that the radio control system is working reliably, and that all connections
are secure.
If dry cells are to be used as power supply, remember that they must never be recharged. Only batteries
marked specifically as ‘rechargeable’ can safely be recharged.
It is important to check the effective range of the radio control system before each session: switch on the
transmitter and receiving system, ask a friend to hold the transmitter, and walk about 100 m away, holding
the model. Your assistant should operate the controls constantly, and the model must respond reliably.
Check whether the channel you wish to use is not already occupied. Never switch the system on if you are
not sure whether “your” channel is already in use.
Note that other transmitters and radio equipment are capable of causing serious interference to your model.
If possible, ensure that no equipment of this type is in use in the vicinity while you are operating your
model.
Never work on the model’s power system unless the drive battery is isolated from the system.
When the drive battery is connected, make sure that you and everybody else always keep clear of the area
around the propeller, as this represents a serious injury risk.
Do not exceed the recommended operating voltage. Higher voltages may cause the motor and / or the
speed controller to overheat, and the electrical wiring could even melt. If this should happen, a fire could
start, in which case the model would be wrecked.
Check that all the drive train components work smoothly and freely. This applies in particular when you are
running the model, as leaves and other detritus can get caught up in the power train. If this happens, the
motor, the speed controller and / or the rudder servo may be ruined due to overloading.
Before running the model check that the sheets are free-moving, and have not become tangled or caught
up on the model.
Dry cells and rechargeable batteries must never be short-circuited. Do not allow them to come into direct
contact with water.
Remove the drive battery and any dry cells from the boat and the transmitter before storing the model.
Do not subject the boat to severe humidity, heat, cold or dirt.
Secure the model and the transmitter carefully when transporting them, as they may be seriously damaged
if they are free to slide about.
Never operate the model on moving water (e.g. a river): as it could be washed away downstream if the
wind changes, if interference occurs, or if the battery is depleted.
If you have to salvage the model, take care not to risk your own life or that of others.
Check regularly that the boat is completely watertight, as it may sink if too much water enters the hull.
Before every run check the model for damage which could allow water to penetrate the hull.
Allow the model to dry out thoroughly after every session.
Care and maintenance
Clean the model carefully after every run, and remove any water which has penetrated the hull. If water
gets inside any of the RC components, dry them out and send them to your nearest GRAUPNER Service
Centre for checking.
Clean the model and the transmitter using suitable cleaning agents only. A lint-free cloth is ideal. Never use
chemical cleaners, solvents, methylated spirit, white spirit or similar.
Notes on operating the model boat
