Electric glider model
V-VENTURE
2 / 16
9910.100_WD_V1
3 / 16
9910.100_WD_V1
Index
Introduction ............................................................................4
Service Centre ........................................................................4
Intended use .........................................................................5
Package content ....................................................................5
Technical data ........................................................................5
Symbols explication ................................................................6
Safety notes ...........................................................................6
Declaration of conformity ......................................................13
Notes on environmental protection .......................................14
Care and maintenance .........................................................14
Warranty ...............................................................................14
4 / 16
9910.100_WD_V1
Introduction
Thank you very much for purchasing the Graupner V-VENTURE.
This electric glider model is extremely versatile.
Read this manual carefully to achieve the best results with your
V-VENTURE and first of all to safely control your models. If you
experience any trouble during operation, take the instructions to
help or ask your dealer or Graupner Service Centre.
Due to technical changes, the information may be changed in
this manual without prior notice. Be always updated by checking periodically on our website, www.graupner.de to be always
uptodate with the products and firmwares.
This product complies with national and European legal requirements.
To maintain this condition and to ensure safe operation, you must
read and follow this user manual and the safety notes before using
the product!
Note
This manual is part of that product. It contains important information
concerning operation and handling. Keep these instructions for future
reference and give it to third person in case you gave the product.
Service Centre
Graupner Central Service
Graupner/SJ GmbH
Henriettenstrasse 96
D-73230 Kirchheim / Teck
Servicehotline
(+49) (0)7021/722-130
Monday - Thursday
9:15 am - 5:00 pm
Friday
9:15 am - 1:00 pm
Graupner USA
OPENHHBBY LLC
3245 University Ave
Suite 1520
San Diego, CA 92104
Website: www.graupnerusa.com
Phone: +1 855-572-4746
Email:service@openhobby.com
Graupner in Internet For the service centers outside Germany please refer to our web
site www.graupner.de
5 / 16
9910.100_WD_V1
Intended use
The V-VENTURE is a ready to fly, remote-controlled airplane
model.
The V-VENTURE is designed exclusively to be used as a battery-powered, radio controlled model, any other use is not
allowed. For any improper use no warranty or liability is accepted.
Read through this entire manual before you attempt to install or
use the V-VENTURE.
Graupner/SJ constantly works on the development of all products; we reserve the right to change the item, its technology and
equipment.
Target group
The product is not a toy. It is not suitable for children under 14
years. The installation and operation of the V-VENTURE must be
performed by experienced modellers. If you do not have sufficient knowledge about dealing with radio-controlled models,
please contact an experienced modeller or a model club.
Package content
Ready fuselage with assembled V-tail and removable can-
opy
Half-wing pair
CF bayonet
Manual
Technical Data
Wingspan approx. 1350 mm
Length o.a. approx. 860mm
Wing profile HQ 3,0/12
Elevator profile NACA 009
Wing area approx. 21,7 dm²
Tailplane area approx. 5,0 dm²
Total surface area approx. 26,7 dm²
Total surface load approx. 20,6 g/dm
Flight weight approx. 550 g
6 / 16
9910.100_WD_V1
Symbols explication
!
Always observe the information indicated by this warning sign.
Particularly those which are additionally marked with the CAU-
TION or WARNING. The signal word WARNING indicates the potential for serious injury, the signal word CAUTION indicates possibil-
ity of lighter injuries.
The signal word Note indicates potential malfunctions.
Attention indicates potential damages to objects.
Safety notes
General
!
These safety instructions are intended not only to protect the
product, but also for your own and other people’s safety. Therefore please read this section very carefully before using the product!
Do not carelessly leave the packaging material lying around,
since it might become a dangerous toy for children.
Persons, including children, with reduced physical, sensory
or mental capabilities or lack of experience or knowledge, or
not capable to use safely the transmitter must not use the
transmitter without supervision or instruction by a responsible person.
Operation and use of radio-controlled models needs to be
lernt! If you have never operated a model of this type before,
start carefully and make yourself familiar with the model's
reactions to the remote control commands. Proceed always
responsibly. This also means that you have for your own protection liability insurance.
Protect all equipment from dust, dirt, moisture. All equip-
ment must be protected from vibration as well as excessive
heat or cold. The models may only be operated remotely in
normal outside temperatures such as from -10°C to +55°C.
The insurance is mandatory for all kinds of model operation.
Always fly with a safe distance away from people and objects,
never fly low over people or directly towards them!
Never fly the model near power lines, industrial sites, resi-
dential areas, public roads, school yards or playgrounds etc.
7 / 16
9910.100_WD_V1
All model fliers must behave in such a way that public safety,
especially other people and property, as well as orderly flying operations is not jeopardized or disrupted.
Inform passers-by and spectators before the start of the
dangers posed by your model and exhort them to keep a
safe distance.
Checklist before starting
Before every use, check the range and functioning. For this
purpose switch on the transmitter and the receiving system.
Check that all controls are in neutral position, function properly and turn down the correct side.
When flying a model aircraft for the first time, it is advanta-
geous if an experienced helper stands aside in the review
and the first flights.
Propellers powered by a motor represent a constant risk of
injury. Do not touch them with any part of the body! A fast-rotating propeller can cut off a finger!
Keep well out of the rotational plane of the propeller! A part
of it or the entire propeller could broke and fly off at high
speed, hitting you or third parties. This can cause serious
injury. Make sure that no object gets in touch with a revolving propeller!
The blockage of the propeller, for any object must be
excluded.
Check each time before the model itself and everything
attached to it (e.g. propeller, tail plane etc.) is in good condition and undamaged. The model may be taken in operation only after removal of all defects.
Radio interference caused by unknown sources can occur
without warning! The model is then uncontrollable and completely unpredictable!
Do not leave the radio control system unattended, to prevent operation by third parties.
Electric motor should be activated only if there is nothing in
the rotational plane of the propeller. Do not attempt to stop
the spinning propeller. Power the electric motors only with
the propeller installed.
!
8 / 16
9910.100_WD_V1
The attitude of the model must always be clearly visible
throughout the flight to ensure always a safely use and avoid
problems. Familiarize yourself during the flight, if any malfunction / interference becomes noticeable, the landing must
be initiated immediately for safety reasons. You always give
way to other aircraft. Start and landing strips should be kept
free of people and other obstacles.
Required tools and adhesives (not included)
Allen key 1,5 mm*
Cyano glue * No.5821
Activator for cyano glue * No.953.150
Phillips screwdriver *.
* These items are required for any repairs.
Recommended accessories (not included)
mz-10 HoTT No. S1001.DE
LiPo battery charger ULTRAMAT 14 plus No. 6464
Charge cable XT60 No. S8386
LiPo battery 20 C 2/2500 7,4 V No. 7633.2
Replacement parts (not included)
Canopy cover No. 9910.1
Fuselage half-shells 1 pair No. 9910.2
Wing-half 1 pair No. 9910.3
V-tail half 1 pair No. 9910.4
Propeller 6x4,5 inches No. 9910.12
Motor mount No. 9910.17
Linkages, pushrods and hardware No. 9910.18
CF bayonet No. 9910.20
Propeller adapter for Ø 2,3 mm shaft No. 9910.29
9 / 16
9910.100_WD_V1
COMPACT 2612-1950 7,4 V BL-Motor No. 9910.81
COMPACT CONTROL 20A BEC
BL-Controller No. 9910.82
Elevator servo DS 1223 No. 7890
Aileron servo DS 1223
with 500 mm servo cable No. 7890.500
LiPo battery 20C 2/2200 7,4 V No. 7632.2
Fuselage representation
1. Trim weight 10 g, is glued
2. Receiver position, receiver is not included
3. Elevator servo DS 1223 No. 7890
4. XT60 connector
5. COMPACT CONTROL 20A No. 9910.82, is already installed
6. COMPACT 2612-1950 7,4 V BL-Motor No. 9910.81
7. Propeller adapter for Ø 2,3 mm shaft, No. 9910.29
8. Propeller 6x4,5 inches No. 9910.12
9. Motor mount No. 9910.17
1
5
2 3
4 69 7 8
10 / 16
9910.100_WD_V1
Model assembly
The model is ready to fly after a few assembly steps, the following instructions should be observed carefully so that safe operation is ensured.
To open the canopy hold it securely laterally and pull to the top.
After removing the canopy, the two wing panels with the CF
bayonet (4) are inserted in the fuselage, then the servo cables
(5) and (2) are led out in the fuselage through the related holes.
Tip: the insertion of the wing panels will be easier if just before
placing them you press a little both naps (3) of the left wing
panel. After some assemblies the wing panel will get together
without too much pressure and installing them will be easier.
Occupation of the optional receiver
Install the receiver, pass the antenna from the bottom through
the guide tube. The guide tube is on the left side of the fuselage
over the elevator servo. Connect the servo cables according to
the representation.
free
Aileron right
free
Elevator
Aileron left
Speed controller
L
No. S1012
11 / 16
9910.100_WD_V1
Installing the optional LiPo battery
Insert the battery with the connection cable facing to the front.
Before connecting the XT60 connector switch on the transmitter and set the motor stop switch or the throttle stick to the
motor "Off" position. Therefore read the transmitter manual. By
connecting the XT60 connector the receiver will be switched
on. After putting the canopy in place the V-VENTURE is ready
to fly.
The movements and travels
The surface travels are already corrected set from the factory
and have the following values. Always measured from the surface edge: Elevator approx. 10 mm both upward and downward, ailerons approx 28 mm upward and 12 mm downward.
The centre of gravity
The center of gravity in the V-VENTURE is between 70 and 80
mm measured from the wing front edge and is properly set from
the factory, while using the suggested LiPo battery. The center
of gravity can be tested for control by holding the model with
two fingers under the center of gravity under the wing. The
model should then be balanced and leveled.
First flight
Fly the already properly prepared model in condition of still or
very low wind, for an unexperienced pilot it would be hard to
control the model in windy conditions. To fly the model is necessary a leveled or lightly inclined in the wind direction free surface. Never fly between buildings or trees. When flying a model
aircraft for the first time, it is advantageous if an experienced
helper stands aside in the model review and the first flights.
Push the model by hand with the motor on in the wind direction,
do not launch it. The proper take off speed will be reached by
a few steps. During the take off the nose of the model should
be lightly (approx. 15°) inclined upward.
A trimming of the model controls particularly after the first take
off is necessary, you can do it through the trim levers beside
and under the controls sticks. Trim the aileron control through
the aileron trim so that the model flies straight on. Trim the elevator control so that while motor is on the model flies lightly
upward and climbs gently.
12 / 16
9910.100_WD_V1
Always land against the wind direction with switched off motor.
Before touching the ground reduce the model flight speed by
gently acting on the elevator control. Always land against the
wind direction.
Pay absolutely attention to unplug the XT60 connector after
each use.
GRAUPNER/SJ Modellbau whishes you many happy flights
with your new V-VENTURE airplane model
13 / 16
9910.100_WD_V1
Declaration of conformity
9910.82 COMPACT CONTROL 20A BEC BL-Controller
Graupner/SJ declares that the product is conform to EU norms.
EN 55014-1: 2006+A1: 2009+A2:2011; EN 61000-3-2: 2014
EN 61000-3-3: 2013; EN 55014-2: 1997+A1: 2001+A2:2008
9910.81 COMPACT 2612-1950 7,4 V BL-Motor
Graupner/SJ declares that the product is conform to EU norms.
EN 61000-6-3: 2007; EN 61000-6-1: 2007
7890 Elevator servo DS 1223
Graupner/SJ declares that the product is conform to EU norms.
EN 61000-6-3: 2007+A1: 2011; EN 61000-3-3: 2013
7890.500 Aileron servo DS 1223 with 500 mm servo cable
Graupner/SJ declares that the product is conform to EU norms.
EN 61000-6-3: 2007+A1: 2011; EN 61000-3-3: 2013
14 / 16
9910.100_WD_V1
Notes on environmental protection
Disposal notes
This symbol on the product, user manual or packaging indicates
that this product must not be disposed of with other household
waste at the end of its life. It must be handed over to the applicable collection point for the recycling of electrical and electronic
equipment.
The materials are recyclable as marked. By recycling, material
reusing or other forms of scrap usage you are making an important contribution to environmental protection.
Batteries and accumulators must be removed from the device
and disposed of at an appropriate collection point. Please inquire
if necessary from the local authority for the appropriate disposal
site.
Care and maintenance
Notes on care
The product does not need any maintenance, it works so as it
is without any special care. In your own interests protect it from
dust, dirt and moisture.
Warranty certificate
The Graupner, Henriettenstrassee 96, 73230 Kirchheim/Teck
grants from the date of purchase of this product for a period of
24 months. The warranty applies only to the material or operational defects already existing when you purchased the item.
Damage due to wear, overloading, incorrect accessories or
improper handling are excluded from the guarantee. The legal
rights and claims are not affected by this guarantee. Please
check exactly defects before a claim or send the product,
because we have to ask you to pay shipping costs if the item is
free from defects.
The present construction or user manual is for informational purposes only and may be changed without prior notice. The current version can be found on the Internet at www.graupner.de
on the relevant product page. In addition, the company Graupner
has no responsibility or liability for any errors or inaccuracies that
may appear in construction or operation manuals.
No liability can be accepted for printing errors.
P
15 / 16
9910.100_WD_V1
Notes
Loading...
