GRAUPNER Quick LiPo 15 Instructions Manual
GRAUPNER/SJ GmbH. Henriettenstr. 96, KG 73230 KIRCHHEIM/TECK GERMANY
2013/11/25
Quick LiPo 15
LiPo charger
Order no.: 64018
English
INNOVATION & TECHNOLOGY
Instructions
2
English
Foreword ......................................................................3
Intended use
.................................................................3
Technical data...............................................................3
Delivered items
.............................................................4
Explanation of symbols.................................................5
Warning and safety notices
..........................................5
Information on handling batteries
.................................7
General operating notices
............................................9
Care and maintenance
...............................................10
Graupner/SJ GmbH manufacturer's declaration
........11
Operating elements
....................................................12
Connecting the battery
...............................................12
Connecting to the Tx/Rx socket
..................................13
Using the charger for the rst time
.............................13
Charging process for LiPo batteries
...........................14
Error messages and warnings
....................................14
Environmental protection information
.........................15
Declaration of conformity
............................................15
Table of contents
Attention!
You must read these instructions
in full before using the charger
for the rst time.
Please comply with the
instructions on disposal
and environmental protection
on page 15
!
3
INNOVATION & TECHNOLOGY
English
Foreword
T o enable you to make full use of all the features of your new charger , read the following description
carefully and in full prior to using the charger for the rst time. In particular, please observe the
warning and safety notices. These instructions must be kept in a safe place and handed over to
any subsequent user of the charger.
Intended use
In the QUICK LiPo 15, you have acquired a sophisticated product with excellent features. Its state-ofthe-art semi-conductor technology controlled by a powerful microprocessor provides excellent charging
properties, means that the charger is easy to use and ensures optimum reliability. The QUICK LiPo 15
can be used to charge virtually all lithium polymer batteries used in model-building. Connect the charger's
100 ~ 240 V AC input to a mains wall socket or the charger's DC input to a car battery or power supply unit
with a capacity of at least 10 A with 11 to 15 VDC.
Notice!
Always follow the charging instructions of the battery manufacturers and adhere to the charging current
and charging times. The quick-charge process may only be used by batteries that have explicitly been
described as suitable for the high charging current that this involves. Please be aware that new batteries
may only reach their full capacity after several charging/discharging cycles. Charging may also be
terminated prematurely when new batteries are used. You must carry out a series of test charges to
check that the automatic termination function is working correctly and reliably and that the battery is being
charged to the correct capacity.
Input voltage:
100 - 240 VAC
11 - 15 VDC
Battery:
Charging currents/power 0.5 A, 2.5 A / max. 15 W with 100 ~ 240 VAC mains connection
0.5 A, 2.5 A, 4 A / max. 40 W with 11 - 15 VDC connection
LiPo batteries:
Number of cells 1 - 3 cells
Charging process automatic
Miscellaneous:
No-load current consumption approx. 60 mA
Trickle charging 0 ~ 250 mA (automatically 1/20 of the set charging current)
Undervoltage termination approx. 11.0 V
Overvoltage and undervoltage warning yes
Reverse polarity warning yes
Safety timer 90 mins
Approx. weight 300 g
Approx. dimensions (LxWxH) 115 x 95 x 40 mm
Technical data
4
English
Delivered items
The requirements placed on rechargeable batteries vary depending on how they are used. This in turn means
that various types of connectors are required. Please note that connections, names and polarities may vary
from one manufacturer to another. You must therefore only ever use compatible original connectors of the
same type.
You must also only use original charging cables with a sufficient wire cross-section.
The set includes:
• QUICK LiPo 15 charger
• Instructions
5
INNOVATION & TECHNOLOGY
English
Explanation of symbols
Attention!
This symbol calls attention to the following notices which must be observed unconditionally
by the user. Any disregard for the accompanying notices can impair safe operation and even
endanger the operator.
Warning!
This symbol calls attention to prohibitions which must be observed unconditionally by the
user. Any disregard for the accompanying prohibitions can impair functionality and endanger
the operator.
Care and maintenance!
This symbol calls attention to notices regarding care and maintenance of the product which
should be observed by the operator in order to ensure a long service life for the product.
Notice!
This symbol calls attention to notices which should be observed by the operator to ensure
safe operation of the device.
Tip!
This symbol calls attention to tips and expertise, such as how to avoid potential difculties or
damage, and is an aid in solving potential problems.
Disposal instructions
This symbol calls attention to the following notices regarding how individual materials
and products must be disposed of by the user.
!
Warning and safety notices
Attention!
Protect the charger against dust, moisture, rain, heat (e.g. direct sunlight) and vibrations.
Only use in dry locations.
Attention!
The slots in the housing are used to cool the device and must not be covered or sealed.
The device must be positioned so that the air can circulate without restriction.
Attention!
Do not connect several chargers to one power strip – danger of overloading the socket –
re hazard!
Attention!
The charger is suitable for connection to a 12 V car battery or power supply unit
(11 to 15 VDC). Never connect an AC voltage to the DC voltage input. Fire hazard!
No modications whatsoever may be made to the charger.
!
!
!
!
