GRAUPNER 2201 User Manual
72 ft Yacht
Order No.: 2201
2
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
Table of contents
Foreword .................................................................................................................................... 2
Model summary description ........................................................................................................ 3
Intended usage .......................................................................................................................... 4
Symbols and their meanings ...................................................................................................... 4
Warning and safety notices ........................................................................................................ 4
Conformity declaration................................................................................................................ 7
Environmental protection notices ................................................................................................ 8
Graupner GmbH & Co KG manufacturer's declaration ............................................................... 8
Assembly instructions ............................................................................................................... 10
Foreword
Thank you for choosing to purchase the Graupner model "72 ft Yacht", order no. 2201. Graupner
models stand for high quality. We pay great attention to stability at the key points in series
production. Due to extensive prefabrication, including motor and rudder system, as well as the high
degree of detail made possible by the CNC processing, this model replicates the original yacht very
closely.
It is quite important that these instructions are read completely prior to assembly and
first-time use of the model. The safety rules stated in these instructions must be
followed during trial runs as well as initial use and thereafter.
3
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
Model summary description
This 72 ft yacht the result of a yacht study made by the Munich designer Jochen Kinder. It
was introduced in 2012 at the yacht exhibition in Dubai. J. Kinder Designs has been
successfully designing high-tech products for the international maritime market as well as
premium consumer products for over 25 years.
• This is one of the models in the GRAUPNER PREMIUM product line series, the series of
particularly high quality finished models offering a degree of detail previously unachieved
on the market.
• In order to achieve such high-quality results, the hull is made of stable GRP material, the
superstructure and deck are made of laser-formed ABS parts and many small parts made
of metal are already attached. The hull, superstructure parts, the masts and fittings are
spray painted and the decorative items are attached. Thanks to its many details and
fitting parts, this model gives a particularly authentic impression of the original.
• Installation of the RC components is made simple by the generously sized openings in
the deck. Their installation can be accomplished quickly. Only the installation of the RC
components and rechargeable battery as well as some minor soldering work are
necessary to make the model operable.
Technical data
Length, about 1007 mm
Breath, about 270 mm
Total height, about 500 mm
Total weight, about 7 kg
Scale, about 1:20
• Delivered items: GRP hull, deck, superstructure parts and ship stand made of laserformed ABS, railing and other small parts made of metal, two motors, rudder system, preattached trim decals, instructions in German, English and French.
4
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
Intended usage
This model is designed to be a ship model for operation on bodies of water which meet the
stipulations described in these instructions and is only suitable for this purpose. No
guarantee or liability is accepted for any improper handling outside the scope of these
stipulations.
Symbols and their meanings
Attention!
This symbol calls attention to the injury risks associated with operating a propeller which must absolutely be observed
by the user! Any disregard for the adjacent notices can lead to severe injuries for the operator.
Attention!
This symbol calls attention to the injury risks associated with operating a propeller which must absolutely be observed
by the user! Any disregard for the adjacent notices can lead to imbalance of the propeller, can severely damage the
model and can produce most severe injuries for persons in the vicinity as a consequence of hurled parts.
Attention!
This symbol calls attention to the following notices which must absolutely be observed by the user! Any disregard for
the adjacent notices can impair safe operation and even endanger the operator.
Attention!
This symbol calls attention to bans which must absolutely be observed by the user! Any disregard for the adjacent bans
can impair the model's functionality and endanger the operator.
This symbol calls attention to notices which must absolutely be observed by the operator to ensure safe operation of a
device.
This symbol calls attention to notices about care of the model which must absolutely be observed to ensure its long
service life.
Warning and safety notices
This is a model that – together with appropriate accessories – can become a functional RC model.
GRAUPNER cannot monitor adherence to the assembly and operating instructions for the model nor
can GRAUPNER supervise the installation, operation or maintenance of the model and its
components. Therefore GRAUPNER accepts no liability whatsoever for losses, damage or costs that
arise from improper operation, improper behavior or which are associated with same in any manner.
Unless mandated by prevailing law, the obligation of the GRAUPNER company to provide damage
compensation arising from the use of the model, regardless of the grounds, is excluded (this
exclusion includes personal injury, death, damage to buildings or structures as well as sales and
business losses, consequential damage for business interruption or other direct and indirect
consequential damages).
Total liability under all circumstances and in each case is limited to the amount actually paid for this
model.
5
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
Attention!
Never reach into a running propeller or attempt to hold the propeller by hand when it is operating. This leads to hand
injuries. Rotational forces can readily cause the propeller to get out of control.
Attention!
Never put objects/foreign materials into a running propeller. Always ensure that objects/foreign materials cannot get
into the propeller when it is running. If this does happen, the propeller's sudden imbalance can cause heavy damage to
the model. Persons in the vicinity can be severely injured by parts hurled through the air.
Attention!
Never dwell in front or back of a propeller. Improper assembly or unforeseen circumstances can cause the propeller to
come off of its shaft.
Stop the propeller if unusual noises are heard.
Attention!
The propeller must be securely attached. Do not direct the propeller toward persons or animals, do not test the
propeller in the hand. Never dwell in front of a propeller. Unforeseen circumstances can cause the propeller to come off
of its shaft. Persons in the vicinity can be severely injured by parts hurled through the air.
Attention!
Do not touch any part of the drive train (i.e. motor + propeller + shaft) while it is operating as this can lead to injuries.
Allow the motor, shaft, regulator and battery time to cool off after operation before touching any of these parts!
Warning!
Operating the model while under the influence of medication, alcohol, drugs, etc. is forbidden.
Attention!
Ensure that the operation of model boats is permitted on the given body of water.
Attention!
The operator of a model ship must be aware of the legal stipulations before putting a model ship into operation because
a model ship is subject to applicable laws. Applicable laws are always to be followed in every case. In this respect, pay
attention to the laws applicable in the given country. Before operating the model for the first time, check if your private
liability insurance provides coverage for model ships of this type. If this is not the case, obtain special liability insurance
coverage for RC models.
Warning!
Any deviation from the model's instructions can have an effect on the model's functionality and operational safety. This
must be avoided under all circumstances.
Warning!
The model has been designed for operation on water and is only suitable for this purpose. Any other use can lead to
property damage and/or personal injuries. You are responsible for safe operation of the model and the safety of other
persons and animals.
Attention!
The model may only be operated with accessories which we recommend as otherwise functionality cannot be
guaranteed.
Attention!
The commissioning and operation of the model is solely at the risk of the operator. Only cautious, considered handling
during operation of the model will prevent personal injuries and property damage.
Attention!
This model is not suitable for children under 14 years of age.
Attention!
Protruding model parts can be sharp and the antennas and masts can cause eye injuries.
Attention!
Pay attention to the potential dangers associated with the tools that are used.
