Manual
mz-12PRO HoTT
12 channel 2,4 GHz transmitter
No. S1002.PRO
EN
EN
Manual part 1
Copyright © Graupner/SJ GmbH
Index
Introduction ............................................................................. 5
Service Centre .......................................................................... 5
Intended use ............................................................................ 6
Target group ....................................................................................6
Package content ....................................................................... 6
Technical data .......................................................................... 7
Symbols explication ................................................................. 7
Safety notes.............................................................................. 7
For your safety by handling the transmitter ..................................8
For your safety by handling the battery .........................................9
Description of the transmitter ............................................... 11
Control elements on the transmitter ...........................................11
Connections and fixtures ..............................................................13
Attaching the transmitter neck-strap ........................................... 13
Jack socket ....................................................................................13
Data socket.................................................................................... 13
Micro USB charging socket ........................................................... 13
Display and touchpad ...................................................................14
Symbols in the display ..................................................................14
Symbols in the info list .................................................................. 14
Display of the transmitter mode .................................................. 14
Commissioning ....................................................................... 15
Settings by the first use ................................................................15
Start display ..................................................................................15
Control sticks length adjustment .................................................. 16
Opening/closing the transmitter housing .................................... 16
Neutralizing the control sticks ...................................................... 17
Brake spring and ratchet ...............................................................17
Control sticks centering force ....................................................... 17
S1002.PRO_jh_V1
General commissioning ................................................................18
Binding ..........................................................................................18
Transmitter power supply ............................................................. 18
Inserting the battery ..................................................................... 18
Battery charging ............................................................................18
Low voltage warning .....................................................................20
3 / 28
Battery use timer in the display....................................................20
Use and menu functions ........................................................ 20
Four-way keys ...............................................................................20
Short-Cuts .....................................................................................21
Function field in the display ......................................................... 22
Hidden mode ................................................................................22
Stick calibration .............................................................................22
Servo display .......................................................................... 23
Firmware update .................................................................... 25
Transmitter software update ........................................................25
Declaration of conformity ...................................................... 26
Notes on environmental protection ...................................... 27
Care and maintenance ........................................................... 27
Warranty ................................................................................ 27
4 / 28
S1002.PRO_jh_V1
Introduction
Thank you very much for purchasing a Graupner mz-12PRO HoTT
transmitter.
Read this manual carefully to achieve the best results with your
transmitter and first of all to safely control your models. If you experience any trouble during operation, take the instructions to help or
ask your dealer or Graupner Service Centre.
Notice
This manual is composed by two parts. Part 1 is contained in the
product's package content. Part 2 can be found in its last version on
www.graupner.de by the related item page.
Due to technical changes, the information may be changed in this
manual without prior notice. Keep updated by regularly checking
our own website,
www.graupner.de to be always updated with the
products and firmware.
This product complies with national and European legal requirements.
To maintain this condition and to ensure safe operation, you must
read and follow this user manual and all the safety notes before
using the product!
Service Centre
Note
This manual is part of that product. It contains important information concerning operation and handling. Keep these instructions for
future reference and give it to third person in case you gave the
product.
Graupner Central Service
Graupner/SJ GmbH
Henriettenstrasse 96
D-73230 Kirchheim / Teck
Servicehotline
(+49) (0)7021/722-130
Monday - Thursday:
9:15 am - 4:00 pm
Friday:
9:15 am - 1:00 pm
service@graupner.de
Graupner USA
3941 Park Dr Suite 20-571
Website: www.graupnerusa.com
Phone: +1 855-572-4746
El Dorado Hills, CA 95762
Email:service@graupnerusa.com
Graupner in Internet For the service centers outside Germany please refer to our web site
www.graupner.de
S1002.PRO_jh_V1
5 / 28
Intended use
Target group
This remote-control system may only be used for the purpose specified by the manufacturer for operation of remote control models
without passengers. Any other type of use is impermissible and may
damage the system and cause significant property damage and/or
personal injury. No warranty or liability is therefore offered for any
improper use not covered by these provisions.
Read through this entire manual before you attempt to install or use
the transmitter.
Graupner/SJ constantly works on the development of all products;
we reserve the right to change the item, its technology and equipment.
The product is not a toy. It is not suitable for children under 14 years.
The operation of the mz-12PRO HoTT transmitter must be performed by experienced modelers. If you do not have sufficient knowledge about dealing with radio-controlled models, please contact an
experienced modeler or a model club.
Package content
Transmitter mz-12PRO HoTT
LiPo transmitter battery
Transmitter strap
Receiver (optional)
Transmitter manual (Part 1)
Receiver manual (optional)
The programming manual (manual part 2) can be found in its last
version on
www.graupner.de by the related item page.
6 / 28
S1002.PRO_jh_V1
Technical data
!
!
Symbols explication
Transmitter mz-12PRO HoTT
Frequency band 2,4 … 2,4835 GHz
Modulation FHSS
Transmitting power 100 mW EIRP
Control functions 12 functions of which 4 can be trimmed
Temperature range -10 … +55 °C
Antenna Integrated antenna
Operating voltage 3,4 … 5,5 V
Power consumption approx. 180 mA
Dimensions approx. 190 x 185 x 90 mm
Weight approx. 700 g with batteries
Note
The technical data of the optional receiver are available in the manual included in the receiver package content.
Always observe the information indicated by this warning sign. Particularly those which are additionally marked with the CAUTION or
WARNING. The signal word WARNING indicates the potential for
serious injury, the signal word CAUTION indicates possibility of
lighter injuries.
Safety notes
The signal word Note indicates potential malfunctions.
Attention indicates potential damages to objects.
These safety instructions are intended not only to protect the product, but also for your own and other people’s safety. Therefore please
read this section very carefully before using the product!
Do not carelessly leave the packaging material lying around,
since it might become a dangerous toy for children.
Persons, including children, with reduced physical, sensory or
mental capabilities, or lack of experience or knowledge, or not
capable to use safely the transmitter must not use the transmitter without supervision or instruction by a responsible person.
Operation and use of radio-controlled models needs to be
learned! If you have never operated a model of this type before,
start carefully and make yourself familiar with the model's reactions to the remote control commands. Proceed always responsibly.
S1002.PRO_jh_V1
7 / 28
Inform yourself before flying your
!
!
model on which maximum altitude
you can fly in the uncontrolled
airspace over the starting position
and do not exceed it.
Before you start using the remote control model, you have to
check the further relevant laws and regulations. These laws you
must obey in every case. Pay attention to the possibly different
laws of the countries.
The insurance is mandatory for all kinds of model operation. If
you already have one, so please inform yourself if the operation
of the respective model is covered by your insurance. If this is not
the case, conclude a special liability insurance policy for models.
Protect all equipment from dust, dirt, moisture. All equipment
must be protected from vibration as well as excessive heat or
cold. The models may only be operated remotely in normal outside temperatures such as from -10°C to +55°C.
First, always perform a range and function test on the ground
before you start using your model. Only so you can grant a safe
use! How to perform a range test is explained in the Part 2 of the
manual.
Only operate ALL your HoTT components using the current soft-
ware version.
Start a data log every time you use your model. With a log-data
an occurred technical defect can be recognized and verified.
Only so it is possible to considerate an eventual compliant.
For your safety by handling the transmitter
WARNING
Also while programming the transmitter, make sure that a connected motor cannot accidentally start. Disconnect the fuel supply or drive battery beforehand.
CAUTION
Risk of fire! Avoid every kind of short-circuit in all sockets of the
transmitter! Use only the suitable connectors. In no case the electronic component of the transmitter may be changed or modified.
Due to licensing reasons, any reconstruction and/or modification
of the product is prohibited.
8 / 28
S1002.PRO_jh_V1
Note
!
During transport protect the model and the transmitter from damages.
For your safety by handling the battery
CAUTION
Protect all equipment from dust, dirt, moisture. Only use in dry
locations.
Do not use any damaged battery. Risk of injury!
Any alterations to the battery can cause serious injury. Risk of
fire!
Batteries may not be heated, burned, short-circuited or charged
with excessive current or with reversed polarity.
While they are being charged, the batteries must be placed on a
non-flammable, heat-resistant and non-conductive surface.
Combustible or highly flammable objects are to be kept away
from the charging area. Batteries must be monitored while they
are being charged.
The maximum quick charging current specified for the respec-
tive cell type may not be exceeded.
If the battery heats up above 60°C while it is being charged, stop
charging and let the battery cool down to approximately 30 40°C.
Never charge batteries that have already been charged, are hot
or are not fully discharged. If a cell in a battery pack has become
particularly hot following a quick-charge process, this may indicate a defect in that cell. Do not use the battey pack any more!
The batteries must not be modified. Do not directly solder or
weld the cells.
If handled improperly, there is a danger of fire, explosion, irrita-
tion and burns. To extinguish a fire use: water, CO
Leaked electrolyte is caustic and should not be touched or come
into contact with your eyes. In case of emergency, rinse with a
large quantity of water and consult a Med. Doctor.
Always charge the battery fully.
2
, sand.
S1002.PRO_jh_V1
The maximum charging current permitted may not be exceeded.
Never leave the charger unattended when it is connected to the
power supply.
Please charge your batteries only in rooms fitted with a smoke
detector.
9 / 28
Special instructions
To charge and discharge batteries, only use specifically designed
chargers/dischargers with balancer connector.
The white connector (cell count + 1 pole) is designed for the con-
nection to a LiPo balancer or a battery charger as a single cell
charger with a manual cell balancer. Always charge the battery
with the balancer connector.
Safety notes for stocking batteries
Batteries may only be stored in non completely discharged con-
dition.
Batteries may only be stored in dry rooms with an ambient tem-
perature of +5°C to +25°C.
Stock the LiPo batteries with a cell voltage of about 3,8V. If the
cell voltage falls below 3 V, then the battery must be necessarily
charged. Deep discharge and storage in discharge status (cell
voltage < 3V) make the battery useless.
Charge and transport your batteries always in a safety bag.
10 / 28
S1002.PRO_jh_V1
Description of the transmitter
Control elements on the transmitter
1
13
14
15
16 17
2
3
4
5
12
11
1 Integrated antenna
2 Eyelet for neck strap
3 Proportional dial DV
4 2 way switch SW 3
5 3 way switch SW 6 and 7
6 Right stick
7 Right four way keys
8 Trim
9 On/off switch
10 LCD
11 Left four way keys
12 Left stick
13 3 way switch SW 4 and 5
14 2 way switch SW 1
15 2 way switch SW 2
16 Carrying handle
17 Central status LED
8
9
108
7
6
S1002.PRO_jh_V1
11 / 28
1
2
1
1
1
mz-12PRO
1
1
11 3 4
1 Case screws
2 Battery case cover
3 3,5 mm jack to connect earphones or a DSC cable.
4 Data socket to connect a smart box and to update the transmitter
5 Micro USB port, charge port, update port, joystick function
5
1
12 / 28
S1002.PRO_jh_V1
Connections and fixtures
Attaching the transmitter neck-strap
On the upper side of the transmitter there is an eyelet which can be
used to hook a neck-strap.
Jack socket
The port for a 3,5 mm jack is located on the back of the transmitter.
Depending on the settings in the menu (OHRH or DSC) this interface
can be used as a earphone port or as a DSC cable port.
Ear phones port
Though this interface both acoustic signals and voice messages are
emitted.
The volume can be controlled by "Voice volume" and "Signal volume" in the general settings.
DSC connection
Through a DSC cable the port can serve to use the transmitter with
a simulator o to connect it with another one in Teacher/pupil mode.
Switch the DSC mode in the "General settings menu". In this way you
can change the base display too. Right in the display appears "DSC".
Data socket
To ensure a correct DSC connection, observe the following:
1. Perform any necessary adaptations in the menu.
2. When using the transmitter with a flight simulator or during the
teacher-pupil operation, set the On/Off switch always on the "Off"
position. Connect one end of the DSC cable in the DSC port of the
transmitter.
3. Switch the transmitter on.
ATTENTION
When your transmitter is directly connected to a desktop computer
by a connecting cable (DSC cable) and/or a computer interface is
connected to your simulator, the transmitter may be destroyed
by electrostatic discharge. This type of connection should therefore
only be used if you protect yourself from electrostatic discharge
while operating the simulator by wearing a commercially available
grounding armband. Graupner therefore strongly recommends
only using wireless simulators.
The lower pins are suitable for connection of a smart box or an external bluetooth module.
Micro USB charging socket
S1002.PRO_jh_V1
For the function please see section "battery charging"
13 / 28
Display and touchpad
M-01
1:23h
Stop
Flug
1:23
11:12
5.5V
5.4V
NR
5.1V
GRAUBELE
normal
1
2
3 4
5
6
7
8
4
9
4 10
1 Model name
2 Memory 1 ... 250
3 Model type display (plane/heli, copter, car, boat)
4 Optical display of the trim position
5 Flight chronometer in min:s (forward/reverse)
6 Flight timer in min:s (forward/reverse)
7 Battery voltage (when a determined threshold is trespassed a warn
message is displayed, contemporary a warn signal is emitted).
8 Battery use timer since last charge in h:min
9 Display of the transmitter mode
10 Flight phases switching between flight phases through switch.
Symbols in the display
Symbols in the info list
Display of the transmitter mode
0.0 V
5.2 V
No receiver in range
Display of the signal strength of the signal coming back from receiver
Button lock inactive / active
The active model memory is bound to a receiver
No connection to receiver
Current operating voltage of the receiver power supply with symbol
display of the power supply charge state
NR: normal mode
TP: Teacher/pupil mode
14 / 28
S1002.PRO_jh_V1
Commissioning
Settings by the first use
1
3
Start display
2
1 Adjusting screw of the brake spring for throttle/brake stick
2 Neutralizing screw
3 Stick self centering force adjust screws
After the transmitter is switched on by fixed wing of type "Motor on
C1 front/rear" the position of the output 1, so as in hely model the
output 6 connected servo, will be verified. If the related servo is out
of the idle position and because of the danger connected to a rotating motor, the RF module remains off for safety reasons.
3
Please select
RF on/off?
ON
S1002.PRO_jh_V1
OFF
In all other cases by switching on the transmitter the RF module will
be switched on too and in the center of the display it will appear the
message "RF ON/OFF".
You can wait until the message disappears automatically or you can
shorten the waiting time manually, by pushing the ENT button ()
of the right four-way button.
15 / 28
RF on/off?
Please select
!
ON
OFF
pushing the or button of the left four-way button which move
the black field, in this way the "ON" is shown normally and "OFF" is
inverted represented.
Control sticks length adjustment
Length of both control stick can be adjusted. Hold down the bottom
half of the knurled grip, and loosen the screwed connection by turning the top part:
You can now lengthen or shorten the control stick by screwing it up
or down. Then clamp the top and bottom part of the grip by rotating them against each other.
Opening/closing the transmitter housing
The transmitter should be opened only in the following cases:
If a self centering stick has to be converted in non self centering
If a non self centering stick has to be converted in self centering
During this waiting time you can also switch the RF module off by
To set the control stick centering force
CAUTION
Never switch the transmitter on while the housing is open! Risk of
short-circuit!
Open step by step:
Before opening the housing switch the transmitter off.
Open the battery case.
Remove the battery holder lifting it from one side, without forcing
it, release it from the velcro tape.
Unplug the connector.
Unscrew the eight screws with a crossscrewdriver.
Hold both housing halves with both hands and let the screws fall on
a proper surface turning the transmitter upside-down.
Rotate the lower half carefully and fold it to the bottom.
Note
Cables connect the lower half of the housing with the upper part
electronic components. This connection must not be damaged! Do
not touch the electronic boards.
16 / 28
S1002.PRO_jh_V1
Neutralizing the control sticks
Closing step by step:
Check if the upper and the lower part of the transmitter housing are
correctly coupled and the tiny cables are properly placed.
Screw the housing screws in their original position.
Connect the battery holder.
Both control sticks can be set from neutralizing to non-neutralizing.
Neutralizing step by step:
Locate in the left control stick gimbal the screw surrounded by a
white circle in the picture.
Turn the screw toward the inside of the transmitter until the relevant
control stick can move freely from stop to stop, or turn it outward
until the control stick resets itself independently.
Note
The right control stick gimbal is specular to the left one, so that here
the screw is located left under the middle.
Brake spring and ratchet
Control sticks centering force
VERTICAL
HORIZONTAL
The outboard screw of the two marked in the figure adjust the braking force.
The inboard screw adjusts the strength of the ratchet for the respective control stick.
Note
The right control stick gimbal is specular to the left one, so that here
the screws are located right on the top side.
The control sticks' restoring force can also be adjusted. The adjustment is located next to the return springs.
By turning the respective adjust screw the spring force can be
adjusted.
Right turn = return harder
Left turn = return softer
S1002.PRO_jh_V1
Note
The right control stick gimbal is specular to the left one, so that here
the screws are located left in the middle.
17 / 28
General commissioning
Binding
Model
memory
M.Type
Phase
D/R
ExpoTxadjust.
Stick mode
Timers 10:01
Rcv. Output
Bind
Range test
Servo
adjust.
curve
C1
Control
adjust.
Wing
mix
1
C1
–––
99s
The description of the binding process can be found in the Part
2 of the manual.
To use a transmitter you must associate a receiver to the transmitter.
This binding process is essential for the use of the model!
The precise binding process follow-up is described in the section
"Binding" of the Part 2 of the manual and in the related receiver
manual.
Note
The process is different for the various receiver types.
Binding-principle step by step:
1. Select the "main settings" menu in the transmitter
2. switch the RF module OFF
3. Connect the power supply to the receiver
... receiver with binding button:
• Push and hold the binding button at the receiver
• Start the binding process in your transmitter in the main settings
menu
Transmitter power supply
Inserting the battery
Battery charging
... or receiver without binding button:
• The receiver is automatically in binding mode after switch on
• Start the binding process in your transmitter in the main settings
menu
4. If the binding process has been unsuccessful, repeat the process.
The mz-12PRO HoTT transmitter is normally delivered with a
rechargeable battery.
Note
Pay attention when inserting the battery to the correct position and
make sure the contacts are solid.
Interruptions of the power supply to the transmitter during the use
of the models can lead to big danger for your self and for other people.
Through the micro USB port you can charge the transmitter battery.
Use the included USB cable to connect the transmitter to a suitable
USB port and charge the transmitter battery. If the transmitter is
switched on the charge time is longer than if the transmitter is
switched off.
18 / 28
S1002.PRO_jh_V1
USB connected 7
!
PC COM Port
Joystick
Battery charge
Signal volume
Back port OHRH
DATA sel. Telemetry
DSC output PPM12
USBjoystick 0~100
3
As soon as you connect the USB cable to the transmitter a selection
menu appears.. Here you can set up the function of the micro USB
port.
PC COM Port
Select this setting for updates with your PC.
Joystick
For use in a PC with a flight simulator. In this function the PC recognizes the transmitter as a joystick. You can select the control area in
the "Base settings" menu in the line "USBjoistick". The control travel
can be set within 0 % and 100% or within -100% and +100%. The
standard setting for the most flight simulators is 0% to 100%.
Battery charging
Battery charge only, no data transmission
In the upper right corner this indication shows a countdown, this is
the time during which the indication is displayed. You can select
through the arrow keys up and down.
You have two charge possibilities:
1. Removing the battery from its case and charging it with a charger
WARNING
The charger should always be supervised during charge and it
should be used only in rooms fitted with a smoke detector.
Removing transmitter battery
Remove the battery case cover. Then remove and disconnect the
battery plug by carefully pulling on the supply cable.
Charge the battery following the charger manual.
Inserting the transmitter battery
Connect the battery plug in the transmitter socket. Make sure that
the polarity is correct. Pay attention to the respective "+" and "-"
symbols near the socket.
Red= + Black/brown = -
Place the battery into its compartment and close the cover.
S1002.PRO_jh_V1
2. Through the USB port by charging with USB cable
The transmitter battery can be charged by the current supplied by
the USB port (5 V/max. 0.5 A). The charging process is shown through
the red lightning Graupner text. The indication quits when, with
switched off transmitter, the battery is full.
19 / 28
Low voltage warning
GRAUBELE
#01
3.5V
0:22h
S
Flug
Batt. must
be re-
«normal »
charged !!
x
K78
Mx
0:00.0
0:00.0
HoTT
0.0V
The transmitter battery voltage should be monitored in the display
during operation. In case the voltage drops under a preset threshold,
standard setting 3,6 V, an acoustic warning signal is emitted and in
the display appears in a window "battery needs charging".
Now at the latest, the operation must be stopped and the transmitter battery must be charged!
Battery use timer in the display
The battery use timer is shown in the lower left part of the display.
The battery use time is added at every use. After every charge the
timer is reset to "00:00". This happens only if the battery voltage
increases at least of 0,3V or if the battery is full.
Use and menu functions
Four-way keys
Keys left of the display
Four-way keys (up, down, right, left)
TLM
ENT
ESC
VIEW
By pushing one of these buttons in the base display the "Telemetry
data display" will appear.
By pushing the keys you can scroll the list according to the arrow
direction.
By simultaneous pushing the keys
you can reset the value of an
already selected parameter which had been already modified
(CLEAR).
Pushing simultaneously the button
and will cause a jump
from the transmitter's base screen or from almost any menu position to the "Hidden mode" menu.
Keys to the left of the display
Four-way keys:
ENT button
Pushing the ENT key will cause a jump from the displayed base screen
which appears as soon as the transmitter is switched on to the
multi-function menu
By pushing the ENT key it is possible to accede to a previously selected
menu point.
20 / 28
Within the setting menu activate and deactivate or confirm by pushing the ENT key.
ESC button
Pressing the ESC button brings about a stepwise return to function
selection or back to the basic display. Any setting changed in the
meantime is retained.
S1002.PRO_jh_V1
Short-Cuts
VIEW button
Pushing the four-way keys will cause a jump from the transmitter's
base screen or from almost any menu position to the "Servo display"
menu.
TLM button
Pushing the TLM key will cause a jump from the transmitter's base
screen or from almost any menu position to the telemetry menu.
Note
In the event the four way keys do not exhibit any functionality immediately after switching the transmitter off and then on again right
away, this is not a fault. Just switch the transmitter off again then
wait for several seconds before switching it on again
CLEAR
Brief simultaneous touch of the
keys of the left four way keys will
restore the active entry fi eld's changed parameter value back to its
default value.
"Servo screen"
Brief simultaneous activation of the VIEW key of the right four-way
keys will cause a jump from the transmitter's base screen or from
almost any menu position to the "Servo display" menu,
"Telemetry" menu
To recall the "Telemetry menu" from the base display of the transmitter, push the TLM key of the right four-way keys.
To come back to the base menu push the ESC key.
Graphic display of telemetry data
Pushing one of the selection keys
of the left four-way keys will
cause a jump from the base screen directly to the transmitter's
graphic display of telemetry data.
"HIDDEN MODE"
Pushing simultaneously the selection keys
and of the four-way
keys will cause a jump from the transmitter's base screen or from
almost any menu position to the "Hidden mode" menu.
Key lock
The four-way keys can be locked by pushing simultaneously the TLM
and VIEW keys for about 1 second.
The key lock function is displayed by a lock symbol: The controls
remain operational. Push again the TLM and VIEW keys for about 1
second to remove the key lock.
S1002.PRO_jh_V1
21 / 28
Function field in the display
Depending on the given menu, certain function fields will appear on
the bottom display line.
A marked function is activated by pushing the SET key.
SET SEL STO SYM ASY
Hidden mode
HIDDEN MODE
STICK CALIBRATION
Function field:
SET (SET) Setting
SEL (SELECT) Selection
STO (STORE) Store
SYM Set values symmetrically
ASY Set values asymmetrically
Switch symbol field
(assignment of all types of
switches)
Within a menu, change to the
Second page (menu continuation)
The menu "Hidden Mode" can be reached from almost any menu
position.
push and hold the left, the right and the lower keys of the left fourway keys.
Stick calibration
1
–100 %
3
5
7
9
11
0%
0%
0%
0%
0%
10
12
If the center position of your self-neutralizing control stick does not
precisely correspond to 0% control travel, you can check and correct
it as follows.
Stick calibration step by step:
Move to the "Model memory" menu and initialize a free model
memory. Whether the model to be initialized is a winged aircraft or
a helicopter is irrelevant.
2
4
6
8
0%
0%
0%
0%
0%
0%
Move to the "Servo display" menu, pressing the VIEW key of the right
four-way keys, without any interim change to trim settings or other
program settings.
In this menu point you can check if your sticks are correctly centered.
Bring then all the sticks in the middle position. If the sticks are correctly placed, this display should ideally look like the one shown on
the left.
Otherwise the graph bars show current setting percentages for control stick control functions which are not self-neutralizing.
22 / 28
S1002.PRO_jh_V1
11
1
3
5
7
9
–100 %
0%
0%
0%
0%
0%
10
12
2
4
6
8
0%
+100 %
0%
0%
0%
0%
One after the other, put both sticks into each of their four possible
limit positions without exerting force at the limit position and check
if the value are between -100% and +100%.
If you note that the sticks do not reach the desired values, move to
the "Stick calibration" line in the "HIDDEN MODE" menu and push
the ENT key on the right four-way keys to confirm.
The flashing arrows indicate in which direction you have to push the
sticks.
STICK CALIBRATION
CONTRAST
LANGUAGE
VOICE
STICK CALI.
CONTRAST
LANGUAGE
VOICE
STICK CALI.
STICK CALIBRATION
+102%
Servo display
1
–100 %
3
5
7
9
11
0%
0%
0%
0%
0%
10
12
0%
2
4
6
8
ENGLISH
DEUTSCH
ENGLISH
DEUTSCH
0%
0%
0%
0%
0%
0%
0
cyclically select the positions of the four calibrated sticks.
With the selection keys
of the left four-way keys allow you to
Move the stick to the end course of the indicated direction.
Confirm the calibration by pushing the ENT key.
Pushing the ESC key will terminate the process and return to the submenu "Stick cali.".
Example: Bring here the respective left blinking selection arrow of
0
the right stick to the left limit. Tip on the SET key. So the calibration
of the right stick left limit. The circle in the middle of the stylized stick
blinks as confirmation.
The optical display of the current servo position can be seen by pushing the VIEW key () of the right four-way keys from the base display
so as from almost every other menu positions.
The current setting of each servo is displayed precisely between
-150% and +150% of the normal path taking into account the control
and servo settings, dual rate/expo functions, the interaction between
the linear and curve mixes, etc.
0% equals the middle position of the servo.
S1002.PRO_jh_V1
You can therefore check your settings without having to turn on the
receiver.
Attention
You have however to carefully test all the program steps on the
model before first use to make sure there are no errors!
For normal fixed wing models, the display follows the assignment
below:
23 / 28
Bar 1 Throttle/brake servo or airbrake right
Bar 2 Aileron or left aileron
Bar 3 Elevator
Bar 4 Rudder
Bar 5 Aileron right / free channel
Bar 6 Flap (left) / free channel or 2nd elevator servo
For helicopter models, the display follows the assignment below:
Bar 1 Pitch or roll (2) or nick (2) servo
Bar 2 Roll (1) servo
Bar 3 Nick (1) servo
Bar 4 Yaw servo (gyro)
Bar 5 Gyro or Nick (2) Servo
Bar 6 Throttle servo or speed controller
Pushing the ESC key () of the right four-way keys you turn back to
the related output point.
Good to know!
Note that the servo display refers exclusively to the original sequence
of the servos, that is, it does not refer to any changes to the outputs
made in the "Transmitter settings" menu, or via telemetry in
the "Receiver output " submenu of the "Transmitter setting" menu.
Good to know!
The count of the channels displayed in this menu refers to the 12
control channels available in this transmitter mz-12PRO HoTT. The
number of usable channels depends on the type of receiver as well
as the number of connected servos and may therefore be significantly less.The number of usable channels depends on the type of
receiver as well as the number of connected servos and may therefore be significantly less.
24 / 28
S1002.PRO_jh_V1
Firmware update
The programs and files which are also required for updating the
transmitter combined into one software package can be downloaded from
www.graupner.de.
Download this software package from the Internet, and unpack it on
your computer. All other information can be found in internet in the
same page where the software package is available.
Firmware updates of the transmitter can be performed through the
micro USB port on the back side.
Note
Please note that compatible firmware is required for reliable
communication between the HoTT components. The programs
and files that are required to update are therefore combined into
a single file.
The current firmware version can be found on the Internet at
www.graupner.de.
Only operate your transmitter using the current software ver-
sion. these information can also be found at: www.graupner.de
=> Service & Support => Update and revision history for
GRAUPNER HoTT components.
Transmitter software update
Connect your switched off transmitter with your PC, by using the
included USB cable, which is supplied with the package content, plug
USB cable directly to the micro USB port of the transmitter and the
other end to a free port in your computer.
Restoring the transmitter software
If a firmware update for the transmitter is unsuccessful or the transmitter program freezes and the transmitter cannot be turned off
using the "POWER" switch, then remove the transmitter's battery
after setting the switch to "POWER = OFF" position, or pull the plug
from the transmitter battery. While making sure that the POWER
switch is in the "OFF" position, wait a few seconds and then turn on
the battery.
Before each update, check the transmitter battery charge or
charge it as a precaution, and save all model memories with the
gr_studio program so that they can be restored if necessary.
Do not disconnect the link to the computer during an update!
Make sure that the link between the transmitter and computer
is operational.
After each update, check to make sure that the models function
correctly.
S1002.PRO_jh_V1
25 / 28
Declaration of conformity
In this case as well, as described in the pages before, download a
current software package from the Internet and open it on your
computer or, if you have already done this, start the program gr_Studio, and follow the information in the section "Restoration" in the
instructions provided in the software package.
S.1002.PRO - mz-12PRO HoTT
Graupner/SJ declares that the product is conform to EU norms.
EMV 2004/108/EC:
EN 301 489-1 V1.9.2
EN 301 489-17 V2.1.1
EN 62479:2010
LVD 2006/95/EC:
EN 60950-1 + A11 + A1 + A12 + A2:2013
R&TTE 1999/5/EC:
EN 300 328 V2.1.1
EN 62311:2008
26 / 28
S1002.PRO_jh_V1
Notes on environmental protection
P
Disposal notes
This symbol on the product, user manual or packaging indicates that
this product must not be disposed of with other household waste at
the end of its life. It must be handed over to the applicable collection
point for the recycling of electrical and electronic equipment.
The materials are recyclable as marked. By recycling, material reusing or other forms of scrap usage you are making an important contribution to environmental protection.
Batteries and accumulators must be removed from the device and
disposed of at an appropriate collection point. Please inquire if necessary from the local authority for the appropriate disposal site.
Care and maintenance
Notes on care
The product does not need any maintenance. Always protect it
against dust, dirt and moisture.
Warranty
Clean the product only with a dry cloth (do not use detergent!) lightly
rub.
The Graupner, Henriettenstrassee 96, 73230 Kirchheim/Teck grants
from the date of purchase of this product for a period of 24 months.
The warranty applies only to the material or operational defects
already existing when you purchased the item. Damage due to misuse, wear, overloading, incorrect accessories or improper handling
are excluded from the guarantee. The legal rights and claims are not
affected by this guarantee. Please check exactly defects before a
claim or send the product, because we have to ask you to pay shipping costs if the item is free from defects.
The present construction or user manual is for informational purposes only and may be changed without prior notice. The current
version can be found on the Internet at www.graupner.de on the
relevant product page. In addition, the company Graupner/SJ has
no responsibility or liability for any errors or inaccuracies that may
appear in construction or operation manuals.
S1002.PRO_jh_V1
No liability can be accepted for printing errors.
27 / 28
FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party
responsible for compliance could void the user‘s authority to operate
the equipment.
• NOTE
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- _Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Loading...
