Grant 61213 User Manual

MODEL NUMBER

Congratulations on the purchase of your new GRANT REVOLUTION steering wheel. This wheel is a
direct replacement for your original factory steering wheel with spoke mounted control switches. The
original factory airbag (SIR) module must be removed and transferred to the new GRANT wheel.

This wheel will fit the following vehicle:

Chevrolet - 2010 Camaro All with Leather Wrapped Steering Wheel Only

These GRANT Instructions use the factory shop manual procedures for the removal and
reinstallation of the steering wheel and airbag module. Before proceeding with the replacement
of your original steering wheel, it is necessary to read and understand all these instructions. By
reading them first, you can become familiar with the steps and terminology used. Please take
note of the following directives used throughout these instructions:

NOTICE - GRANT recommends that installation be performed by a qualified service provider such

as your local GM dealer, a certified mechanic, collision repair shop or a local airbag service
center. Many of these service centers will come to your home or place of business to change out
the air bag and wheel for a nominal fee. To find these providers check the internet for “airbag
service”, “mobile airbag service” or check the yellow pages.

CAUTION

ALWAYS WEAR SAFETY GLASSES WHEN REPAIRING OR HANDLING AN AIR BAG.
ALWAYS CARRY A LIVE AIR BAG MODULE WITH THE TRIM COVER POINTED AWAY FROM YOUR

BODY.
ALWAYS PLACE A LIVE AIR BAG MODULE ON A BENCH OR OTHER SURFA CE WITH THE TRIM

COVER FACING UP.

NEVER PROBE THE CONNECTORS ON THE AIR BAG MODULE.

AIR BAG MODULES WITH DISCOLORED OR DAMAGED COVERS OR DEPLOYMENT DOORS
MUST BE REPLACED, NOT REPAINTED.

Tools required: 3-4mm Allen Wrench Safety Glasses
Socket Set
Torque Wrench

GM AIRBAG STEERING WHEEL REPLACEMENT PROCEDURES

IMPORTANT - PLEASE READ

ALWAYS CAUTION NEVER NOTICE NOTE

DISABLING AND REMOVAL OF THE SIR (AIRBAG) MODULE

1. Position the steering wheel so that it is pointed straight ahead. Write down all of your radio presets
as these may be lost when you disconnect the battery cable.

2. NOTICE - Disconnect the negative battery cable and wait at least 1 full minute for the circuit to
completely discharge before proceeding. CAUTION: Failure to fully deplete the backup power
supply could result in an accidental deployment and possible injury.

3. Using a 3-4mm (1/8”-5/32”) Allen wrench release the 2 spring fasteners by pushing inward through
the access holes. The access holes are located on both sides of the steering wheel just behind the
silver plastic trim.

4. The airbag module will pop up as each side is released, when both sides are free lift and partially
remove the airbag module from the steering wheel in order to expose the electrical connectors on the
back side. Take care not to pull on any of the wiring. See illustration above.

5. The airbag electrical connections have a safety locking connector-position assurance (CPA) clip that
must be released before you can remove the electrical connectors from the module.

6. Disconnect the electrical connectors from the airbag module by squeezing them and pulling away.

7. Remove the airbag module from the steering wheel and place the module face up on the floor, seat
or work bench. If you carry the module make sure the trim cover is pointed AWAY from your body.
