Grandstream Networks GXW 4024, GXW 4004-8 User Manual

Analog IP Gateway GXW40xx Quick Installation Guide

Part Number:

Document Version Number: 1.0

418-02007-10

GXW 4004/8

GXW 4024

Grandstream Networks, Inc., 1297 Beacon St., 2nd Flr, Brookline, MA 02446 USA

Tel: [phone], FAX: [phone]

www.grandstream.com

Last updated on April 1, 2008

1

Grandstream Analog IP Gateway GXW40xx Quick Installation Guide

WARNING: Please DO NOT power cycle the GXW40xx during system boot up or firmware upgrade.

You may corrupt firmware images and cause the unit to malfunction.

WARNING:

non-qualified power adapter may possibly damage the unit.

Overview

The GXW40xx series has a compact and quiet design (no fans) and offers superb audio quality, rich
feature functionality, strong security protection, and good manageability. It is auto-configurable, remotely
manageable and scalable.

The GXW40xx features 4, 8 or 24 port FXS interface for analog telephones. It supports 2 SIP account
profiles, caller ID for various countries/regions, T.38 fax, flexible dialing plans, security protection
(SIPS/TLS/SRTP), comprehensive voice codecs including G.711 (a/u-law), G.723.1, G.726, G.729A/B/E
and iLBC. In addition, GXW4004/4008 has dual 10M/100Mbps network ports with integrated router, PSTN
life line in case of power failure, and an RS232 serial port for administration.

Equipment Packaging

Use only the power adapter included in the GXW40xx package. Using an alternative

Unpack and check all accessories

y one device unit
y one Ethernet cable
y one 12V universal power adapter

Application Diagram

There are three scenarios where the GXW40xx series can be effectively used to enable any business to
leverage the benefits of VoIP and the Internet.

Grandstream Networks, Inc., 1297 Beacon St., 2nd Flr, Brookline, MA 02446 USA

Tel: [phone], FAX: [phone]

www.grandstream.com

Last updated on April 1, 2008

2

Scenario One:

GXW40xx FXS Gateway Configuration
PBX Scenario, VoIP

Scenario Two:

GXW40xx FXS Gateway Configuration
No PBX Scenario, VoIP

Grandstream Networks, Inc., 1297 Beacon St., 2nd Flr, Brookline, MA 02446 USA

Tel: [phone], FAX: [phone]

www.grandstream.com

Last updated on April 1, 2008

3

Scenario Three:

GXW40xx & GXW410x Scenario

Maintain toll-free calling across locations

Connect the GXW40xx

Please use the equipment included in the packaging. Using any other power source may da mage the
product.

1. Connect one or more standard touch-tone analog telephones (or fax machine) to FXS ports.

2. Connect a PSTN telephone line to LINE port (optional, GXW4004/4008 only).

3. Insert the Ethernet cable into the WAN (GXW4004/4008) or LAN (GXW4024) port and connect the other
end of the Ethernet cable to an uplink port (a switch, router or a modem, etc.).

4. Connect a PC to the LAN port (optional, GXW4004/4008 only).

5. Insert the power adapter into the GXW40xx and connect it to an electrical outlet.

6. Using the GXW40xx embedded web server or IVR (Interactive Voice Prompt) menu, you can further
configure the device using either a static IP or DHCP.

Configuring the GXW40xx using a Web Browser

1. From the analog phone, press *** to get into the IVR menu. Enter option 02 (GXW4004/4008) or 002
(GXW4024) to obtain the GXW40xx’s IP address.

2. For GXW4004/4008, please enable the “WAN side HTTP/Telnet access” option by entering IVR
option 12 and press 9. A reboot or power cycle of the device is required this change. You can also
access the GXW4004/4008’s web configuration from a PC connected to the LAN port via 1 92.168.2.1.

3. Type the GXW40xx’s IP address in your PC browser.

4. Log in using password “admin” to configure the unit.

Grandstream Networks, Inc., 1297 Beacon St., 2nd Flr, Brookline, MA 02446 USA

Tel: [phone], FAX: [phone]

www.grandstream.com

Last updated on April 1, 2008

4

You will need the following information to configure the GXW40xx via the web browser:

1. IP address, subnet mask and gateway IP if using static IP.

2. SIP server and/or Outbound Proxy FQDN or IP address.

3. User subscriber information: User ID, Authentication IP, Password (provided by your VoIP service
provider).

4. GXW40xx supports “Plug-n-Call” if your ITSP (Internet Telephone Service Provider) provides this
automatic provisioning service. Ensure the gateway has an Internet connection (either DHCP or static
IP in your Internet ready network), then power up the gateway.

5. Please contact your ITSP for additional settings that may be necessary to configure the device.

Important Settings

Most of the settings on the web configuration pages should be kept to default value. But there are some
settings that need to be configured according to the local network environment.

A. NAT Settings

If GXW40xx is connected behind a firewall, an Outbound Proxy or a STUN server must be configured to
solve the NAT issue. Here are four settings that can be useful in such a scenario:

1. STUN Server (under Advanced Settings page)
Enter a STUN Server IP or FQDN in this field.

2. Outbound Proxy (Under Profile pages)
Enter an Outbound Proxy server IP or FQDN.

3. Use Random Ports (under Advanced Settings page)

By default, this field is set to No. It may needs to be set to “Yes” depending on your network environment.

4. NAT Traversal (under the Profile pages)
Set to Yes.

Grandstream Networks, Inc., 1297 Beacon St., 2nd Flr, Brookline, MA 02446 USA

Tel: [phone], FAX: [phone]

www.grandstream.com

Last updated on April 1, 2008

5

B. DTMF Methods

Under Profile pages, there are three DTMF modes to choose from:

y DTMF in-audio
y DTMF via RTP (RFC2833)
y DTMF via SIP INFO

One or more DTMF methods can be selected at the same time.

C. Preferred VOCODER (Codec)

Under Profile pages, user can choose from the following different codecs:
PCMU (G711u), PCMA (G711a), G729A/B/E, G723, G726-16/24/32/40 and iLBC.

D. Firmware Upgrade

Under Advanced Settings page, enter “Firmware Server Path” (IP address or FQDN) under “Firmware
Upgrade and Provisioning” field. Select upgrade protocol TFTP, HTTP or HTTPS accordingly. By default,
“Always Check for New Firmware at Boot up” is selected.

E. Factory Reset

Below are the steps to reset the unit to factory default via the reset button.

1. Unplug the Ethernet cable.

2. Locate a needle sized hole on the back panel of the gateway unit next to the Power connection.

3. Enter a pin in this hole, and press for about 10 seconds till LED changes and a minor click sound.

4. Take out the pin. All configuration settings are restored to factory settings.

Grandstream Networks, Inc. Corporate Headquarters

www.grandstream.com
[e-mail]

Grandstream Networks, Inc., 1297 Beacon St., 2nd Flr, Brookline, MA 02446 USA

1297 Beacon Street, 2
Brookline, MA USA 02446
Tel : [phone] – 9300
Fax: [phone] – 1987

Tel: [phone], FAX: [phone]

www.grandstream.com

Last updated on April 1, 2008

6

nd

Floor,

About Grandstream Networks

Grandstream Networks, Inc. is an award-winning designer and manufacturer of next generation IP voice & video
products for broadband networks. Grandstream’s products deliver superb sound and picture quality, rich telephony

rd

features, full compliance with industry standards, and broad interoperability with most service providers and 3
party SIP based VoIP products. Grandstream is consistently recognized in the VoIP industry for their innovation,
affordability and superior value in their products. Grandstream Networks is a private company headquartered in
Brookline, MA with offices in Los Angeles, Dallas and China. For more information, please visit

www.grandstream.com.

Declaration of Conformity for GXW4004/8: (page 8-9)

Declaration of Conformity for GXW4024: (page 10-11)
