Instructions–Parts List
STAINLESS STEEL
307622J
Viscountr I 1000 Pump
Hydraulic pumps designed for medium viscosity corrosive materials.
For professional use only.
1000 psi (6.9 MPa, 69 bar) Maximum Hydraulic Input Pressure
1000 psi (6.9 MPa, 69 bar) Maximum Fluid Outlet Pressure
Part No. 218077, Series B
U.S. Patent No. 4,383,475
Patent 1984 Canada
Brevete 1984
Foreign Patents Pending
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
EN
03833
Table of Contents
Warnings 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
WARNING
EQUIPMENT MISUSE HAZARD
Equipment misuse can cause the equipment to rupture or malfunction and result in serious injury.
INSTRUCTIONS
D This equipment is for professional use only.
D Read all instruction manuals, tags, and labels before operating the equipment.
D Use the equipment only for its intended purpose. If you are uncertain about usage, call your Graco
distributor.
D Do not alter or modify this equipment. Use only genuine Graco parts and accessories.
D Check equipment daily. Repair or replace worn or damaged parts immediately.
Parts 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Data 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mounting Hole Layout 15. . . . . . . . . . . . . . . . . . . . . . . . . .
Warranty 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Information 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D Do not exceed the maximum working pressure of the lowest rated system component. Refer to the
Technical Data on page 14 for the maximum working pressure of this equipment.
D Use fluids and solvents which are compatible with the equipment wetted parts. Refer to the Tech-
nical Data section of all equipment manuals. Read the fluid and solvent manufacturer’s warnings.
D Do not use hoses to pull equipment.
D Route hoses away from traffic areas, sharp edges, moving parts, and hot surfaces. Do not expose
Graco hoses to temperatures above 82_C (180_F) or below –40_C (–40_F).
D Wear hearing protection when operating this equipment.
D Do not lift pressurized equipment.
D Comply with all applicable local, state, and national fire, electrical, and safety regulations.
2 307622J
WARNING
SKIN INJECTION HAZARD
Spray from the gun/valve, hose leaks, or ruptured components can inject fluid into your body and
cause extremely serious injury, including the need for amputation. Fluid splashed in the eyes or on the
skin can also cause serious injury.
D Fluid injected into the skin might look like just a cut, but it is a serious injury. Get immediate surgi-
cal treatment.
D Do not point the gun/valve at anyone or at any part of the body.
D Do not put your hand or fingers over the spray tip/nozzle.
D Do not stop or deflect leaks with your hand, body, glove or rag.
D Do not “blow back” fluid; this is not an air spray system.
D Always have the tip guard and the trigger guard on the gun/valve when spraying.
D Be sure the gun/valve trigger safety operates before spraying.
D Lock the gun/valve trigger safety when you stop spraying.
D Follow the Pressure Relief Procedure on page 8 whenever you: are instructed to relieve pres-
sure; stop spraying; clean, check, or service the equipment; and install or clean the spray tip/
nozzle.
D Tighten all fluid connections before operating the equipment.
D Check the hoses, tubes, and couplings daily. Replace worn, damaged, or loose parts immediately.
Permanently coupled hoses cannot be repaired; replace the entire hose.
D Use only Graco approved hoses. Do not remove any spring guard that is used to help protect the
hose from rupture caused by kinks or bends near the couplings.
MOVING PARTS HAZARD
Moving parts can pinch or amputate your fingers.
D Keep clear of all moving parts when starting or operating the pump.
D Before servicing the equipment, follow the Pressure Relief Procedure on page 8 to prevent the
equipment from starting unexpectedly.
307622J 3
WARNING
FIRE AND EXPLOSION HAZARD
Improper grounding, poor ventilation, open flames or sparks can cause a hazardous condition and
result in a fire or explosion and serious injury.
D Ground the equipment and the object being sprayed. Refer to Grounding on page 5.
D If there is any static sparking or you feel an electric shock while using this equipment, stop spray-
ing immediately. Do not use the equipment until you identify and correct the problem.
D Provide fresh air ventilation to avoid the buildup of flammable fumes from solvents or the fluid
being sprayed.
D Keep the spray area free of debris, including solvent, rags, and gasoline.
D Electrically disconnect all equipment in the spray area.
D Extinguish all open flames or pilot lights in the spray area.
D Do not smoke in the spray area.
D Do not turn on or off any light switch in the spray area while operating or if fumes are present.
D Do not operate a gasoline engine in the spray area.
TOXIC FLUID HAZARD
Hazardous fluid or toxic fumes can cause serious injury or death if splashed in the eyes or on the skin,
inhaled, or swallowed.
D Know the specific hazards of the fluid you are using.
D Store hazardous fluid in an approved container. Dispose of hazardous fluid according to all local,
state and national guidelines.
D Always wear protective eyewear, gloves, clothing and respirator as recommended by the fluid and
solvent manufacturer.
4 307622J
Installation
Grounding
WARNING
FIRE AND EXPLOSION HAZARD
Before operating the pump, ground the
system as explained below. Also read
the section FIRE AND EXPLOSION
HAZARD on page 4.
Ground all of this equipment.
D Pump: Loosen the grounding lug locknut (W) and
washer (X). Insert one end of a 12 ga (1.5 mm2)
minimum, ground wire (Y) into the slot in lug (Z)
and tighten the locknut securely. See Fig. 1. Order
Part No. 237569 Ground Wire and Clamp. Connect
the clamp end of the ground wire to a true earth
ground.
D Fluid and hydraulic hoses: Use only electrically
conductive hoses.
D Hydraulic power supply: Follow manufacturer’s
recommendations.
D Spray gun or dispensing valve: Obtain grounding
through connection to a properly grounded fluid
hose and pump.
D Object being sprayed: Follow the local code.
D Fluid supply container: Follow the local code.
D All solvent pails used when flushing: Follow the
local code. Use only metal pails, which are conductive. Do not place the pail on a nonconductive
surface, such as paper or cardboard, which interrupts the grounding continuity.
To maintain grounding continuity when flushing or
relieving pressure, always hold a metal part of the gun
firmly to the side of a grounded metal pail, then trigger
the gun.
Z
X
W
Y
0864
Fig. 1
307622J 5
Installation
Typical Installation
hydraulic outlet
7/8-14 UNF-2a
37_ (m) flare
P
C
hydraulic inlet
3/4–16 UNF–2a
R
37_ (m) flare
E
F
H
J
D
B
3/4 npt(f)
fluid intake
G
K
L
Q
N
A
M
03815
KEY
A Fluid Hose to Gun
B Fluid Drain Valve
C Suction Hose
D Hydraulic Return Line
E Hydraulic Supply Line Shutoff
Valve
F Pressure Gauge
G Flow Control Valve
H Pressure Reducing Valve
J Accumulator
K Drain Line
L Hydraulic Supply Line
M Hydraulic Power Supply
N Ground Wire
P Wet cup
Q Check Valve
R Hydraulic Return Line Shutoff
Valve
6 307622J
Installation
NOTE: The Typical Installation shown on page 6 is
only a guide. Contact your Graco distributor for assistance in custom designing your hydraulic system.
NOTE: Mount the pump to suit the type of installation
planned. The pump dimensions and mounting hole
layout are shown on page 15.
CAUTION
The hydraulic supply system must be kept clean at
all times to avoid damage to the motor and hydraulic
power supply. Blow out all hydraulic lines with air and
flush thoroughly with hydraulic oil before connecting
the lines to the motor.
Always plug the hydraulic inlets, outlets, and lines
when disconnecting them for any reason to avoid
introducing dirt and other contaminants into the system.
Be sure that the hydraulic power supply is equipped
with a suction filter to the hydraulic pump and a system
return line filter of 10 micron size. Carefully follow the
manufacturer’s recommendations on reservoir and
filter cleaning and periodic changes of hydraulic fluid.
The motor has a 3/4–16, 37_ (m) flared tube hydraulic
oil inlet fitting, and a 7/8–14, 37_ (m) flared tube hydraulic oil outlet fitting. Use a minimum 1/2 in. ID
hydraulic supply line and a minimum 5/8 in. ID return
line.
On the hydraulic oil supply line (L), install a shutoff
valve (E) to isolate the system for servicing; a fluid
pressure gauge (F) to monitor hydraulic oil pressure to
the motor and avoid overpressurizing the motor or
displacement pump; a pressure and temperature
compensated flow control valve (G) to prevent the
motor from running too fast; a pressure reducing valve
(H) with a drain line (K) running directly into the hydraulic return line (D); and an accumulator (J) to
reduce the hammering effect caused by the motor
reversing direction.
On the hydraulic return line (D), install a shutoff valve
(R) for isolating the motor for servicing.
WARNING
To reduce the risk of serious injury including skin
injection, your system must include a drain valve
installed near the pump fluid outlet to help relieve
fluid pressure in the displacement pump and hoses
when shutting off the pump.
Install a fluid drain valve (B) and a grounded dispense
hose to the pump’s 1/2 npt fluid outlet, and connect a
suction hose to the 3/4 npt pump fluid intake. See the
Typical Installation.
WARNING
To reduce the risk of component rupture, which can
cause serious injury, including skin injection, be
sure that all accessories and system components
can withstand the pressure and flow created by this
pump.
Ground the pump and system as instructed on
page 5.
307622J 7
Operation
Pressure Relief Procedure
WARNING
SKIN INJECTION HAZARD
Fluid under high pressure can be injected through the skin and cause
serious injury. To reduce the risk of an
injury from injection, splashing fluid, or moving
parts, follow the Pressure Relief Procedure
whenever you:
D Are instructed to relieve the pressure
D Stop spraying/dispensing
D Check or service any of the system equipment
D Install or clean the spray tip/nozzle
1. Lock the gun/valve trigger safety.
2. Turn off the hydraulic supply line valve (E) first,
then the return line valve (R).
3. Unlock the gun/valve trigger safety.
4. Hold a metal part of the gun/valve firmly to a
grounded metal waste container and trigger it to
relieve the fluid pressure.
5. Lock the trigger safety.
6. Open the pump drain valve (required in your
system), having a container ready to catch the
drainage.
7. Leave the drain valve open until you are ready to
spray again.
If you suspect that the spray tip or hose is completely
clogged, or that pressure has not been fully relieved
after following the steps above, very slowly loosen the
hose end coupling and relieve pressure gradually, then
loosen completely. Now clear the tip or hose obstruction.
8 307622J
Operation
CAUTION
When shutting off the hydraulic supply system,
always shut off the supply line shutoff valve (E) first,
and then the return line shutoff valve (R). This is to
prevent overpressurizing the motor or its seals.
When starting the hydraulic system, open the return
line shutoff valve first.
Check the hydraulic fluid level, and add fluid as necessary to fill lines, before each use.
Flush the pump before using it for the first time to
remove the light oil which was left in after factory
testing to protect the pump from corrosion. Be sure the
solvent used is compatible with the fluid to be sprayed
and the wetted parts of the pump (see the Technical
Data on page 14).
To Flush:
Use a compatible solvent when flushing. In a circulating system, circulate the flushing fluid long enough to
thoroughly clean all lines.
WARNING
To operate the pump, turn on the hydraulic power
supply. Open the hydraulic return line shutoff valve (R)
first, and then the supply line shutoff valve (E). Slowly
open the flow control valve. Use the lowest possible
pressure to obtain the desired results. Higher pressures increase tip wear and pump wear.
In a direct supply system, the pump starts when the
gun or valve is opened, and stalls when it is closed. In
a circulating system, the pump operates continuously
until the hydraulic power supply is turned off.
WARNING
To reduce the risk of overpressurizing the system
which can cause a rupture, fire, or explosion and
result in serious injury, including skin injection,
always follow these precautions:
Never exceed 1000 psi (6.9 MPa, 69 bar), or 3
gpm (11.4 liter/min) hydraulic input to the motor.
Never exceed 1000 psi (6.9 MPa, 69 bar) maximum pump outlet pressure.
To reduce the risk of skin injection, static sparking
and splashing when flushing, be sure the entire
system is grounded, including flushing pails. Hold a
metal part of the gun firmly to the side of a
grounded metal pail, and aimed into it, and use the
lowest possible pressure to flush. See Fig. 2. Then
follow the Pressure Relief Procedure on page 8.
Maintain firm
metal-to-metal
contact between
gun and container.
Fig. 2
S
CAUTION
Never allow the hydraulic oil temperature to exceed
130_F (54_C). The pump seals wear faster and
leaking might occur at higher temperatures.
01136
307622J 9
Maintenance
WARNING
To reduce the risk of serious injury whenever you
are instructed to relieve pressure, always follow the
Pressure Relief Procedure on page 8.
Check the tightness of the packing nut weekly. Always
relieve the pressure before adjusting. The packing
nut should be tight enough to stop leakage, but no
tighter. Overtightening compresses and damages the
packings and results in pump leaking.
Carefully monitor the fluid supply. If the pump empties
the supply container, air is sucked into the pump,
causing it to run too fast and to be damaged. If the
pump runs too fast, shut it off immediately. Fill the
supply container and prime the pump to remove all air,
or flush the pump.
S
Always flush the pump before any fluid dries in it.
Always stop the pump at the bottom of its stroke to
prevent the fluid from drying on the displacement rod
and damaging the throat packings.
Check Valve Adjustment
The fluid piston valve is factory set for low volume
pumping of light viscosity fluids. For heavier fluids or
more volume, increase the ball travel by moving the
pin (S) to a high set of holes. See Fig. 3.
TI18607
Fig. 3
10 307622J
Troubleshooting Chart
1. Relieve the pressure.
WARNING
To reduce the risk of serious injury whenever you
are instructed to relieve pressure, always follow the
Pressure Relief Procedure on page 8.
PROBLEM CAUSE SOLUTION
2. Check all possible causes and problems before
disassembling the pump.
Pump operates, but output low on both
strokes
Pump operates, but output low on down
stroke
Pump operates, but output low on up
stroke
Erratic pump operation Exhausted fluid supply. Refill and reprime, or flush.*
Restricted lines or inadequate hydraulic
supply.
Insufficient hydraulic pressure; closed or
clogged valves, etc.
Exhausted fluid supply. Refill and reprime, or flush.*
Clogged fluid line, valves, etc. Clear.**
Piston check valve needs adjustment. Adjust. See page 10.
Packing nut too tight. Loosen.
Loose packing nut or worn packings. Tighten; replace.
Held open or worn intake valve. Clear; service. See manual 308117.
Held open or worn piston or packings. Clear; service. See manual 308117.
Held open or worn intake valve or piston
packings.
Piston check valve needs adjustment. Adjust. See page 10.
Excessive hydraulic fluid supply volume. Lower.
Air entrained in fluid. Purge all air; change fluid.
Clear lines; increase hydraulic supply.
Open; clean.
Clear; service. See manual 308117.
Pump fails to operate Restricted lines or inadequate hydraulic
supply.
Insufficient hydraulic pressure; closed or
clogged valves, etc.
Exhausted fluid supply. Refill and reprime, or flush.*
Clogged fluid line, valves, etc. Clear.**
Damaged hydraulic motor. Service; see manual 307654.
Dried fluid seizure of displacement rod. Service.*** See manual 308117.
* Stop the pump immediately if it is running too fast; check fluid supply. If empty, refill and reprime the pump being sure to
eliminate all air from the system, or flush the pump and store it with an oil–based solvent, such as mineral spirits, to prevent
corrosion.
** Relieve the pressure; disconnect fluid line. If pump starts when hydraulic power is restored, line, etc. is clogged.
*** Always stop the pump at the bottom of its stroke, and keep the packing nut/wet–cup 1/3 full of TSL to help prevent dis-
placement rod seizure.
Clear; increase.
Open; clean.
307622J 11
Service
WARNING
To reduce the risk of serious injury whenever you
are instructed to relieve pressure, always follow the
Pressure Relief Procedure on page 8.
Notes:
D Packing Repair Kit 224402 is available. Use all the
parts in the kit for the best results, even if the old
ones still look good.
D Clean all parts as you disassemble the pump and
inspect them for wear or damage. Replace parts as
necessary.
Removing the Displacement Pump (Fig. 4)
1. Flush the pump if possible. Relieve the pressure.
Stop the pump at the bottom of its stroke.
2. Disconnect all hoses from the displacement pump.
1
Torque to 20–30 ft–lb (27–40 NSm)
1
17
T
3. If you remove the pump from its mounting, disconnect the hydraulic hoses first, and plug all hydraulic connections and lines to prevent contamination.
4. Remove the pin (17) from the top of the displacement rod (T).
5. Unscrew and remove the three locknuts (15).
6. Unscrew the displacement rod (T) from the motor
connecting rod.
7. Refer to manual 308117 to service the displacement pump.
8. Reassemble in the reverse order. Torque the tie
rods and locknuts to 20 to 30 ft–lb (27 to 40 NSm).
1
Fig. 4
15
03834
12 307622J
Parts
Model 218077 Viscount I 1000 Pump
Series B Stubby Length
Ref
No. Part No. Description Qty
5 100133 LOCKWASHER 4
6 217222 VISCOUNT I MOTOR
See manual 307654 for parts 1
7 107195 ADAPTER, straight thd; 7/8–14
UNF–2a; 37_ flare(m) 1
8 106470 ELBOW, straight thd,
3/4–16 UNF–2a; 37_ flare 1
9 217221 TUBE, inlet, 1/2 ID 1
10 107197 TEE, run, straight thd; 3/4–16
UNF–2a; 37_ flare(m) 1
11 104029 CLAMP, grounding 1
12 104582 WASHER, tab 1
13 179882 BASE, motor 1
14 166237 ROD, tie; 4–3/4” (120 mm) long 3
15 102021 LOCKNUT, hex; 3/8–16 thd size 3
16 224344 DISPLACEMENT PUMP
See manual 308117 for parts 1
17 100103 PIN, cotter 1
18 106292 NUT, hex, 3/8” 4
19 156082 O–RING 1
1
Torque nuts of tube (9) to
25 to 35 ft–lb (34–47 NSm)
2
Torque to 20–30 ft–lb (27–40 NSm)
7
6
8
1
9
10
11
12
13
14
5
18
17
19
2
15
16
2
03835
307622J 13
Technical Data
Category Data
Maximum Fluid Outlet Pressure 1000 psi (6.9 MPa, 69 bar)
Maximum Hydraulic Input Pressure 1000 psi (6.9 MPa, 69 bar)
Maximum Hydraulic Fluid Volume 3 gpm (11.7 liter/min)
Fluid Delivery Rate at 60 cycles/min 3 gpm (11.7 liter/min)
Maximum Hydraulic Fluid Temperature 130_F (54_C)
Cycles per Gallon (3.8 Liter) 20
Wetted Parts 303 & 304 stainless steel, nitrile rubber, polyethylene,
PTFE
Weight 33 lb (15 kg)
14 307622J
Dimensions
7/8–14 unf–2a
37_ flared(m)
OUTLET ADAPTER
3/4–16 unf–2a
37_ flared(m)
INLET ADAPTER
Mounting Hole
Layout
4–1/4” (108 mm)
DIA. CUTOUT
28.4 in.
(721 mm)
14.7 in.
(373 mm)
13.7 in.
(348 mm)
3/4 NPT
FLUID INLET
Two 5/16” (8 mm) holes on
5” (127mm) dia. bolt circle;
base has 1/2–20 tapped holes
1/2 NPT
FLUID OUTLET
03833
307622J 15
Graco Standard Warranty
Graco warrants all equipment manufactured by Graco and bearing its name to be free from defects in material and workmanship on the
date of sale by an authorized Graco distributor to the original purchaser for use. With the exception of any special, extended, or limited
warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment
determined by Graco to be defective. This warranty applies only when the equipment is installed, operated and maintained in accordance with Graco’s written recommendations.
This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by
faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of non–Graco component parts. Nor shall Graco be liable for malfunction, damage or wear caused by the incompatibility of
Graco equipment with structures, accessories, equipment or materials not supplied by Graco, or the improper design, manufacture,
installation, operation or maintenance of structures, accessories, equipment or materials not supplied by Graco.
This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized Graco distributor for
verification of the claimed defect. If the claimed defect is verified, Graco will repair or replace free of charge any defective parts. The
equipment will be returned to the original purchaser transportation prepaid. If inspection of the equipment does not disclose any defect
in material or workmanship, repairs will be made at a reasonable charge, which charges may include the costs of parts, labor, and
transportation.
THIS WARRANTY IS EXCLUSIVE, AND IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT
NOT LIMITED TO WARRANTY OF MERCHANTABILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE.
Graco’s sole obligation and buyer’s sole remedy for any breach of warranty shall be as set forth above. The buyer agrees that no other
remedy (including, but not limited to, incidental or consequential damages for lost profits, lost sales, injury to person or property, or any
other incidental or consequential loss) shall be available. Any action for breach of warranty must be brought within two (2) years of the
date of sale.
Graco makes no warranty, and disclaims all implied warranties of merchantability and fitness for a particular purpose in connection
with accessories, equipment, materials or components sold but not manufactured by Graco. These items sold, but not manufactured
by Graco (such as electric motors, switches, hose, etc.), are subject to the warranty, if any, of their manufacturer. Graco will provide
purchaser with reasonable assistance in making any claim for breach of these warranties.
In no event will Graco be liable for indirect, incidental, special or consequential damages resulting from Graco supplying equipment
hereunder, or the furnishing, performance, or use of any products or other goods sold hereto, whether due to a breach of contract,
breach of warranty, the negligence of Graco, or otherwise.
FOR GRACO CANADA CUSTOMERS
The parties acknowledge that they have required that the present document, as well as all documents, notices and legal proceedings
entered into, given or instituted pursuant hereto or relating directly or indirectly hereto, be drawn up in English. Les parties reconnaissent avoir convenu que la rédaction du présente document sera en Anglais, ainsi que tous documents, avis et procédures judiciaires
exécutés, donnés ou intentés à la suite de ou en rapport, directement ou indirectement, avec les procedures concernées.
Graco Information
For the latest information about Graco products, visit www.graco.com.
TO PLACE AN ORDER, contact your Graco distributor or call to identify the distributor closest to you:
Phone: 612–623–6921 or Toll Free: 1–800–328–0211 Fax: 612–378–3505
All written and visual data contained in this document reflect the latest product information available at the time of publication.
Graco reserves the right to make changes at any time without notice.
Original instructions. This manual contains English. MM 307622
International Offices: Belgium, China, Japan, Korea
GRACO INC. AND SUBSIDIARIES S P.O. BOX 1441 S MINNEAPOLIS MN 55440–1441 S USA
Copyright 2002, Graco Inc. All Graco manufacturing locations are registered to ISO 9001.
16 307622J
Graco Headquarters: Minneapolis
www.graco.com
Revised 01/2012
Loading...
