INSTRUCTIONS-PARTS

This

manual contains important warnings and information. READ AND KEEP FOR REFERENCE.

INSTRUCTIONS

LIST

308–293

Rev. G

Supersedes E

and PCN G

Model

M-1265, Series B

Optimiser HVLP

100 psi (0.7 MPa, 7 bar) Maximum Working Fluid Pressure 100 psi (0.7 MPa, 7 bar) Maximum Working Air Pressure 65 psi (444 kPa, 4.4 bar) Maximum Compliant Inbound Air Pressure

U.S.

Patent Pending

Spray Gun

GRACO INC. P.O. BOX 1441

COPYRIGHT

Graco

Inc. is registered to I.S. EN ISO 9001

MINNEAPOLIS, MN

1993, GRACO INC.



55440–1441

Table

of Contents

Symbols

Warnings 2. Selection Air

Flow and Atomizing Pressure7. . . . . . . . . . . . . . . . .

Typical Setup 9 Operation 13 Daily Troubleshooting 18 Service 20 Part Parts Accessories 26 Technical Dimensions 28 Warranty 32

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Charts4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Installation8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Gun Care, Flushing, and Cleaning

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Drawing

List

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Data

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . .

14.

24.

25.

28.

WARNING

EQUIPMENT MISUSE HAZARD

INSTRUCTIONS

Equipment serious injury

misuse can cause the equipment to rupture, malfunction or start unexpectedly and result in

Warning Symbol

WARNING

This

symbol alerts you to the possibility of serious

injury or death if you do not follow the instructions.

Caution Symbol

CAUTION

This

symbol alerts you to the possibility of damage to or destruction of equipment if you do not follow the instructions.

This equipment is for professional use only

Read all instruction manuals, tags, and labels before operating the equipment.

Use the equipment only for its intended purpose. If you are uncertain about usage, call your Graco distributor.

Do not alter or modify this equipment. Use only genuine Graco parts and accessories.

Check equipment daily

Use this equipment only in low pressure, air spray systems.

Do not exceed the maximum working pressure of the lowest rated system component. This equip ment has a

Route the hoses away from the traffic areas, sharp edges, moving parts, and hot surfaces. Do not expose Graco hoses to temperatures above 180

D W

ear hearing protection when operating this equipment.

Use fluids or solvents that are compatible with equipment wetted parts. See the Technical Data section of all equipment manuals. Read the fluid and solvent manufacturer’s warnings.

Methylene Chloride with formic or propionic acid is not recommended as a flushing or cleaning solvent with this gun or any other device with nylon or aluminum components as it can damage these parts.

Comply with all applicable local, state and national fire, electrical and other safety regulations.

100 psi (0.7 MPa, 7 bar) maximum working fluid and air pressure

. Repair or replace worn or damaged parts immediately

_F (82_

C) or below –40

_F (–40_C).

308–293

WARNING

PRESSURIZED EQUIPMENT HAZARD

Spray

from the gun, hose leaks or ruptured components can splash fluid in the eyes or on the skin and

cause serious injury



Do not stop or deflect fluid leaks with your hand, body



Follow the stop spraying; clean, check or servicing the equipment; and install or clean fluid nozzles.



Do not point the spray gun at anyone or at any part of the body

 T

ighten all fluid connections before operating the equipment.



Check the hoses, tubes and couplings daily Permanently coupled hoses cannot be repaired; replace the entire hose.

FIRE AND EXPLOSION HAZARD

Poor

air ventilation, open flames, or sparks can cause a hazardous condition and result in fire or

explosion and serious injury



Provide fresh air ventilation to avoid the buildup of flammable fumes from solvent or the fluid being sprayed.



Extinguish all open flames or pilot lights in the spray area.

Pressure Relief Procedure

, glove or rag.

on page 13 when: you are instructed to relieve pressure;

. Replace worn, damaged or loose parts immediately



Electrically disconnect all equipment in the spray area.



Keep the spray area free of debris, including solvent, rags and gasoline.



Do not turn on or of



Do not smoke in the spray area.



Do not operate a gasoline engine in the spray area.

f any light switch in the spray area while operating or if fumes are present.

TOXIC FLUID HAZARD

Hazardous skin, inhaled, or swallowed.



Know the specific hazards of the fluid you are using. Read the fluid manufacturer’s warnings.



Store hazardous fluid in an approved container state and national guidelines.



Dress appropriately for your application. W and respirator

fluids or toxic fumes can cause serious injury or death if splashed in the eyes or on the

. Dispose of hazardous fluid according to all local,

ear the appropriate protective clothing, gloves, eyewear

308–293 3

TERMS:

Selection

Charts

Light Fluid: Medium Fluid: Heavy Fluid:

P/N: NOTE:

See page 6 for additional tips on selecting the needle/nozzle/air cap set best suited to your application.

Up to 18 seconds with No. 2 Zahn cup (20 centipoise) 19 to 28 seconds with No. 2 Zahn cup (20–64 centipoise) Greater than 28 seconds with No. 2 Zahn cup (greater than 64 centipoise) --

2.8 V

olatile Organic Compounds, High-solid Polyurethanes, Heavy W

Part number

CHART 1: GUN ASSEMBLIES, Series B

Standard

With

standard needle/nozzle/air cap kit

Standard Complete Gun Assy

Part No.

236–013 238–233 0.042”

236–014 238–234

Gun Assemblies

Includes:

Standard

Needle/

Nozzle/Air

Cap Kit P/N

Orifice Size

(1.067 mm)

0.055” (1.397 mm)

aterborne Enamels

Material Usage

(See TERMS above)

Light

to Medium Fluids

[5–8

oz./min. (0.15–0.24 l/min.)]

Light to Medium Fluids or Medium Fluid Flow

[6–12 oz./min. (0.18–0.36 l/min.)]

or Low Fluid Flow

236–015 238–235

236–016 238–236

Optional

With

Complete

Gun

Gun Assemblies – available as “Build to Order”

optional needle/nozzle/air cap kit

Includes:

Optional

Assy

Part No.

236–020 238–230 0.020”

236–021 238–231

236–022 238–232

Optional

Needle/

Nozzle/Air

Cap Kit P/N

0.070” (1.778 mm)

0.086” (2.184 mm)

Orifice Size

(0.508 mm)

0.026” (0.660 mm)

0.030” (0.762 mm)

Medium to Heavy Fluids or Medium Fluid Flow

[6–12 oz./min. (0.18–0.36 l/min.)]

Heavy Fluids or High Fluid Flow [10–15 oz./min. (0.3–0.45 l/min.)]

Material Usage

(See TERMS above)

Light Fluids or Low Fluid Flow [3–6 oz./min. (0.09–0.18 l/min.)]

Light to Medium Fluids [5–8

oz./min. (0.15–0.24 l/min.)]

or Low Fluid Flow

4 308–293

Selection

Standard

Charts

CHART 1: GUN ASSEMBLIES, Series B (continued)

Optional

With

Optional

Complete

Gun

Part No.

* Maximum

{

See atomizing air pressure chart on page 7.

Non-HVLP Compliant Gun Assemblies

standard needle and nozzle and optional high pressure air cap

Includes:

{ High

Needle

Assy

236–023 238–217 276–293 189–755 0.042”

236–024 238–218 276–294 189–755

Assy.

P/N

Nozzle

P/N

recommended torque to install molded fluid nozzle in the spray gun is 35 in-lbs (4 N

Pressure

Air Cap

P/N

CHART 2: NEEDLE/NOZZLE/AIR CAP KITS

Standard

Needle/

Nozzle/Air

Cap Kit Part No.

Needle/Nozzle/Air Cap Kits

Includes:

{ Needle

Assy.

P/N

Nozzle

P/N

Air Cap

P/N

Orifice Size

(1.067 mm)

0.055” (1.397 mm)

Orifice Size

Material Usage

(See TERMS on page 4)

Light

to Medium Fluids or Low Fluid Flow

[5–8

oz./min. (0.15–0.24 l/min.)]

Light to Medium Fluids or Medium Fluid Flow

[6–12 oz./min. (0.18–0.36 l/min.)]

m).

238–233 238–217 276–293 188–754 0.042” 238–234 238–218 276–294 188–754 238–235 238–219 276–295 188–755

238–236 238–220 276–296 188–756

{

See

page 6 for needle assembly replacement tips.

Optional

Nozzle/Air

* Maximum

{

See page 6 for needle assembly replacement tips.

Needle/Nozzle/Air Cap Kits – available as “Build to Order”

Includes:

Needle/

{ Needle Cap Kit Part No.

235–306 238–703 276–290 188–754 0.020” 235–307 238–703 276–291 188–754 235–308 238–703 276–292 188–754

Assy.

P/N

recommended torque to install molded fluid nozzle in the spray gun is 35 in-lbs (4 N

Nozzle

P/N

Air Cap

P/N

(1.067 mm)

0.055” (1.397 mm)

0.070” (1.778 mm)

0.086” (2.184 mm)

Orifice Size

(0.508 mm)

0.026” (0.660 mm)

0.030” (0.762 mm)

m).

308–293

Selection

Charts

CHART 3: OPTIONAL ORIFICE PURGE SST NEEDLE 

Optional

Stainless

Orifice-Purge

Needle Part No.



Use

Steel

Orifice Size

186–931 0.042” 186–932 186–933 186–934

(1.067 mm)

0.055” (1.397 mm)

0.070” (1.778 mm)

0.086” (2.184 mm)

these needles to purge fluid out of the nozzle orifice to prevent plugging of the tip with fast drying material. A needle shaft assembly (part no. 224–849) must be used with these needles and replaces the standard one-piece needles.

Selecting the Proper Needle/Nozzle/Air Cap Set

The

High V nozzle sets range in size to provide dif rates. Chart 1 shows the recommended combinations based on fluid viscosities and flow rates.

As a general guideline, use the fluid nozzle that will give the required flow with the needle fully triggered at the lowest fluid pressure.

For low flow rates or light viscosity fluid, select the smaller nozzle sizes.

For high flow rates or high viscosity fluid, select the larger nozzle sizes.

Using an air cap size that is smaller than the nozzle/ needle size is not recommended.

NOTE: T fluid pressure gauge may be connected temporarily to the gun fluid inlet to determine the fluid pressure. See Accessories.

olume Low Pressure Spray Gun’

s needle/

ferent fluid flow

o help select the proper needle/nozzle size, a

CHART 4: NEEDLE ASSEMBLY REPLACEMENT TIPS

Needle

Assembly

Part No.

238–217 191–016 238–218 191–017 238–219 191–018 238–703 191–564

Needle T

ip P/N

Selection Problems and Solutions

PROBLEM POSSIBLE

Fluid pressure is high (greater than 10 psi [70 kPa, 0.7 bar]) with gun trig gered

Using a low pres sure setting, the fluid flow making it necessary to restrict needle travel to reduce fluid flow.

Fluid system will not operate at low enough fluid pres sure [below 10 psi (70 kPa, 0.7 bar)]

is too high,

CAUSE

too

Using set with too small orifice

Using set with too large orifice

There’ regulator or air

regulator is not sensitive enough

s no fluid

SOLUTION

Use needle/ nozzle/air cap set with larger orifice

Use needle/ nozzle/air cap set with small er orifice

Add low pres sure fluid regu lator or add more sensitive air regulator on pressure pot

6 308–293

Air

Pressure

Flow and Atomizing Pressure

NOTE:

All tests were completed with the pattern adjustment valve fully open.

Air Flow



Models

 

236–023 & 236–024

All other models

      

#!



    

        

"# 

Atomizing Air Pressure

(inlet pressure versus atomizing pressure)

Models

     



OMIZING PRESSURE (psi)



  

NOMINAL

        

236–013 to 236–016 and

236–020 to 236–028

GUN INLET PRESSURE (psi)

Atomizing Air Pressure

(inlet pressure versus atomizing pressure)

Models



Model Model 236–024













"# 

        

Gun Inlet Pressure

psi (kPa, bar)

20 (140, 1.4) 30 (210, 2.1) 40 (280, 2.8) 50 (345, 3.4) 21 (147, 1.5) 24 (168, 1.6) 60 (410, 4.1) 26 (181, 1.8) 30 (210, 2.1) 70 (480, 4.8) 32 (224, 2.2) 36 (251, 2.5) 80 (550, 5.5) 38 (265, 2.6) 42 (294, 2.9) 90 (620, 6.2) 43 (301, 3.0) 48 (335, 3.3)

100 (700, 7.0) 48 (335, 3.3) 54 (373, 3.7)

236–023 and 236–024

236–023

"# 

Nominal Atomizing Pressure

psi (kPa, bar)

Model 236–023 Model 236–024

6 (41, 0.4) 7 (48, 0.4)

10 (70, 0.7) 12 (84, 0.8)

16 (111, 1.1) 18 (125, 1.2)

Gun

Inlet Pressure

psi (kPa, bar)

15 (104, 1.0) 1.5 (10.5, 0.1) 25 (174, 1.7) 3.0 (21.0, 0.2) 35 (244, 2.4) 4.5 (31.5, 0.3) 45 (312, 3.1) 6.0 (41.0, 0.4) 55 (379, 3.7) 8.5 (58.5, 0.6) 65 (444, 4.4) 75 (514, 5.1) 85 (584, 5.8) 95 (654, 6.5)

Nominal Atomizing Pressure

psi (kPa, bar)

10.0 (70.0, 0.7)

13.0 (91.0, 0.9)

15.5 (107.5, 1.1)

18.0 (125.0, 1.2)

308–293

Typical

Installation

NOTE:

See the

Accessories

section for

accessories recommended to install the system.

KEY

A Model B

C D

E F G H

M-1265 Spray Gun See page 4 for part numbers. Fluid Inlet; 3/8 npsm (R3/8–19) Air Inlet; 1/4 npsm Air Hose

Recommend

Optional

Air Shut-of Air Regulator Air Filter Air Supply Line

5/16” (7.9 mm) ID hose

3/8” (9.5 mm) ID hose

f V

alve

EF G

The M-1265 HVLP Spray Gun

The

Model M-1265 HVLP Spray Gun was designed to

produce the highest quality finish with today’ well as the the Low V fluids of tomorrow

.O.C. (volatile organic compound)

This spray gun can spray most coatings or finishes currently being used for automotive refinish, industrial, aerospace, marine, wood, plastic and architectural applications, while easily operating from any paint delivery system, including cups, pressure pots, or remote pumps for production line operation.

The Model M-1265 HVLP Spray Gun typically utilizes 65 psi (444 kPa, 4.4 bar) inbound air pressure to produce high quality paint finishes at 10 psi (0.07 bar) atomizing air pressure.

The air regulator must have a minimum air flow capacity of 30 scfm at 100 psi (0.7 MPa, 7 bar) air pressure.

NOTE:

If the gun’

s hanging hook is needed, remove the gun trigger and replace the gun plate with the hook, then reinstall the trigger

. See the parts drawing,

page 24.

s fluids as

Ventilate the Spray Booth

WARNING

prevent hazardous concentrations of toxic and/or flammable vapors, spray only in a properly ventilated spray booth. Do not operate the spray gun unless ventilation fans are operating.

Check and follow all of the National, State and Local codes regarding air ex

haust velocity requirements. Check and follow all local safety and fire codes.

02018

308–293

Setup

1. Connect the Air Line

NOTE:

 You



must install an air pressure regulator (F) on the gun air line to control air pressure to the gun. See Fig. 2.

If your regulated air source does not have a filter

install an air filter (G) on the air line to ensure a dry clean air supply to the gun. Dirt and moisture can ruin the appearance of your finished workpiece. See Fig. 2.

Use a 5/16 inch (7.9 mm) I.D. air hose to minimize excessive pressure drop in the hose.

Connect the air hose (D) to the 1/4 npsm gun air inlet (C).

2. Connect the Fluid Hose

NOTE:

 Before



connecting the fluid line, blow it out with air and flush it with solvent. Use solvent which is compatible with the fluid to be sprayed.

Install a fluid regulator (L) on the fluid line to control fluid pressure to the gun. See Fig. 4.

Filter the fluid line of coarse particles and sediment to avoid clogging the fluid nozzle and causing finishing defects.

Connect the fluid hose (J) to the gun fluid inlet (B) 3/8–18 npsm [R 3/8–19] compound thread.

C D

Fig. 1

Connect the other end of the air hose (D) to a reg ulated air supply line (H).

NOTE:

and air shut-of

Fig. 2 shows the filter (G) air regulator (F),

f valve (E) on the air supply line.

02051

Fig. 3

Connect the other end of the fluid hose (J) to a regulated fluid supply line (K).

NOTE:

fluid shut-of

Fig. 4 shows the fluid regulator (L) and

f valve (M) on the fluid supply line (K).

M J

02052

Fig. 2

01990

Fig. 4

308–293 9

02054

Setup

3. Flush the Spray Gun.

Before

running any paint through the spray gun, flush the gun out with a solvent that is compatible with the fluid to be sprayed, using the lowest possible fluid pressure and a grounded metal container

Fig. 5

WARNING

PRESSURIZED EQUIPMENT HAZARD

o reduce the risk of a serious injury whenever you

are instructed to relieve pressure, follow the

sure Relief Procedure

on page 13.

4. Relieve the Pressure.

Pres-

02053

6. Adjust the Spray Pattern

WARNING

COMPONENT

Do not exceed the

7 bar) maximum fluid and air pres

sure

of this gun. Higher pressures can cause parts

to rupture and result in serious injury

Follow these steps to establish the correct fluid flow and air flow:

A. T

urn the fluid adjustment knob (8) counterclockwise until no restriction of the trigger movement is felt, then turn the knob another half turn. When the knob is turned far enough, the trigger should be able to touch the gun handle when the gun is trig gered.

RUPTURE HAZARD

100 psi (0.7 MPa,

open

5. Position the Air Cap

Rotate

the air cap as needed to achieve the desired spray pattern direction. T the pattern air of knob (13a) fully clockwise. Refer to Fig. 12.

Fig.

f by turning the pattern adjustment

o create a round pattern, turn

Vertical Pattern

Horizontal Pattern

02017

Fig. 7

02020

10 308–293

Setup

6. Adjust the Spray Pattern

B. Adjust

the fluid flow using the fluid pressure

(continued)

regulator (L) installed in the gun fluid line. T industrial flow rates will vary with regulator pres sures from 5 to 10 psi (34 to 70 kPa, 0.3 to

0.7 bar).

Fig. 8

C. Hold

the gun parallel to the floor and adjust the fluid pressure to yield a 1 to 6 inch (25.4 to 152.4 mm) straight

fluid stream before the stream falls of

ypical

02059

NOTE:

A larger fluid nozzle at a reduced fluid pressure will maintain the same flow rate, but slow down the fluid stream (velocity). When air is applied, this allows

ization.

If further fluid flow restriction is needed at the gun,

the air to act on the fluid longer and improve the atom

turn the fluid adjustment knob (8) clockwise to reduce the volume of fluid output by limiting the needle travel.

02017

Fig. 11

(25.4–152.4 mm)

straight fluid stream

Fig. 9

Fluid Velocity of Fluid Nozzles at the Same Flow Rate

0.042 (1.067)

0.055 (1.397)

Size in inches (mm)

Orifice

0.070 (1.778)

0.086 (2.184)

Fig. 10

1–6

in.

0.110 (2.794)

02106

02105

CAUTION

Restricting the trigger and fluid needle travel by continuously spraying with the fluid adjustment knob closed (turned clockwise), will cause accelerated abrasive wear on the fluid needle and wear on the trigger/air valve shaft interface.

For the best results, use the gun fluid regulator to adjust the fluid flow or use a dif nozzle/air cap combination. Refer to page 5.

NOTE:



If the fluid adjustment knob is turned in all the way the gun will emit only air



For continuous spraying,

knob (8) counterclockwise until no restriction of the trigger movement is felt. When the knob is turned far enough, the trigger should be able to touch the gun handle when the gun is triggered. This provides maximum fluid flow and prevents premature wear on the fluid nozzle.

ferent size needle/

turn the fluid adjustment

Continued on the next page.

308–293 1

6. Adjust the Spray Pattern

E. Open

the pattern adjustment valve (13a) by turning

it fully counterclockwise for a full fan pattern.

13a

(continued)

Setup

G. T

est the spray pattern and atomization while hold ing the gun about 6 to 8 inches (150 to 200 mm) from the test piece.

The spray pattern may be too wide with the pattern adjustment knob (13a) turned fully counterclock wise. T until you have the desired pattern size.

urn the pattern adjustment knob clockwise

Open

(wider pattern)

Fig. 12

Using the air pressure regulator (F), set the gun air supply pressure at 50 psi (345 kPa, 3.4 bar) at the gun inlet.

If available, use the fluid manufacturer’s recom mendations to set the air line pressure for a high volume, low pressure, spray gun application.

NOTE:

sure to 10 psi (70 kPa, 0.7 bar) at the air cap for HVLP compliance.

Local laws may limit the maximum pres

(narrower pattern*)



NOTE:

clockwise will produce a round pattern.

Check the atomization quality again. Increase the gun air supply pressure with the air pressure regu lator in 5 psi (34 kPa, 0.3 bar) increments until you obtain the desired atomization.

If after increasing the gun air supply pressure the atomization is still unacceptable, try installing a larger fluid nozzle size to reduce the fluid velocity Refer to Fig. 10. Repeat steps 6-E to 6-I until you obtain the desired atomization.

Turning

the pattern adjustment knob fully

CAUTION

rigger the gun whenever you tighten or remove the nozzle. This keeps the needle seat away from the nozzle seating surface and prevents the seat from being scratched.

When tightening the nozzle, do not exceed 35 in-lbs (4 N

m)

torque. Over-tightening the nozzle can cause the nozzle hex to round, can affect the spray pattern, and

is unnecessary to guarantee a seal.

Fig. 13

12 308–293

01997

Operation

Pressure Relief Procedure

WARNING

PRESSURIZED

The system pressure must be manually relieved to prevent the system from starting or spraying acci dentally. T dental spray from the gun, splashing fluid, or moving parts, follow the

dure

whenever you:



are instructed to relieve the pressure,



stop spraying,



check or service any of the system equipment,



or install or clean the spray nozzle.

1. T

urn of

f the air and fluid supply to the gun.

2. T

rigger the gun into a grounded metal waste

container to relieve air and fluid pressure.

EQUIPMENT HAZARD

o reduce the risk of an injury from acci

Pressure Relief Proce

Applying the Fluid

When

using the HVLP spray gun, instead of a conven tional air spray gun, you may need to use a slightly slower hand movement and make fewer passes with the gun to coat a part. This is due to the reduced spray

velocity produced by lower HVLP air pressures, along with a larger fluid particle size because there is less air to blow of tional air spray spray.

1. T

2. T

f solvents than what is produced by conven

. T

ake care to avoid runs or sags as you

o achieve the best results when applying fluid, keep the gun perpendicular to the surface and maintain a consistent distance of approximately 6 to 8 inches (150 to 200 mm) from the object being sprayed. See Fig. 14.

o obtain an even finish, use smooth, even strokes across the object being sprayed with 50% overlap.

Paint using parallel strokes. This spray gun applies all coatings evenly without cross coating.

Fig. 14

NOTE: T

sure at the air supply gun inlet fitting. See

o eliminate the need to shut of

, install a quick-disconnect at the

Accessories.

WRONG RIGHT

f the air pres

0793

308–293 13

Daily

Gun Care, Flushing, and Cleaning

WARNING

PRESSURIZED

o reduce the risk of a serious injury whenever you

are instructed to relieve pressure, follow the

sure Relief Procedure

EQUIPMENT HAZARD

Pres-

on page 13.

Clean all parts with a non-conductive solvent, com patible with the fluid being sprayed. Conductive solvents can cause the gun to malfunction.

Methylene chloride with formic or propionic acid is not recommended as a flushing or cleaning solvent with this gun as it will damage nylon components.

CAUTION

Solvent left in gun air passages could result in a poor quality paint finish. Do not use any cleaning method which may allow solvent into the gun air passages.

Do not point the gun up while cleaning it.

Do not wipe the gun with a cloth soaked in solvent; ring out the excess.

02056

Do not immerse the gun in solvent.

02057

General System Maintenance

1. Relieve

Clean the fluid and air line filters daily

Check for any fluid leakage from the gun and fluid hoses. T needed.

the pressure.

ighten fittings or replace equipment as

02027

Do not use metal tools to clean the air cap holes as this may scratch them; scratches can distort the spray pattern.

02055

Flush the gun before changing colors and when ever you are done operating the gun.

14 308–293

Daily

Gun Care, Flushing, and Cleaning

WARNING

PRESSURIZED

o reduce the risk of a serious injury whenever you

are instructed to relieve pressure, follow the

sure Relief Procedure

Relieve the pressure.

Disconnect the fluid supply hose (J) from the gun; do not disconnect the air supply hose.

EQUIPMENT HAZARD

on page 13.

Pres-

Point the gun down into a grounded metal con tainer

, and flush the gun with solvent until all traces

of paint are removed from the gun passages.

Fig. 1

Connect the solvent supply hose (N) to the gun.

02052

Fig. 3

5. T

urn of

f the solvent supply

Relieve the pressure. Disconnect the solvent supply.

Disconnect both the solvent (N) and air (D) supply hoses from the gun.

02053

02051

Fig. 2



02052

Fig. 4

308–293 15

Daily

Gun Care, Flushing, and Cleaning

8. Remove

9. T

rigger the gun while you remove the fluid nozzle

(20) from the gun with the gun wrench (35).

12, 19

Fig. 5

the air cap ring (12) and air cap (19).

CAUTION

rigger the gun whenever you tighten or remove the nozzle. This keeps the needle seat away from the nozzle seating surface and prevents the seat from being scratched.

10.

Soak the ring, air cap, and fluid nozzle in solvent.

02060A

12.

With the gun pointed down, clean the front of the gun, using the soft-bristle brush and solvent.

Fig. 7

13.

Scrub the the air cap ring, air cap, and fluid nozzle with the soft-bristle brush. T holes, use a soft implement, such as a toothpick, to avoid damaging critical surfaces. Clean the air cap and fluid nozzle daily cations require more frequent cleaning.

o clean out air cap

, minimum. Some appli

02062A

11.

Dip the end of a soft-bristle brush into a compatible solvent. Do not continuously soak the brush’ bristles with solvent and do not use a wire brush.

Fig. 6

02007

Fig. 8

02011

16 308–293

Daily

Gun Care, Flushing, and Cleaning

14. Trigger (20) with the gun wrench (35).

the gun while you install the fluid nozzle

CAUTION

When tightening the nozzle, do not exceed 35 in-lbs (4 NSm) torque. Over-tightening the nozzle can cause the nozzle hex to round, can af pattern, and is unnecessary to guarantee a seal.

15.

Install the air cap ring (12) and air cap (19).

12, 19

fect the spray

17.

After cleaning the gun, lubricate the following parts with lubricant 111–265 daily:

Fluid adjustment knob threads

D T

rigger pivot pin

NOTE:

Fluid needle shaft; refer to the to remove and reinstall the needle

See Accessories to order lubricant 1

Service

11–265.

Lubricate

section

Fig. 9

16.

Dampen a soft cloth with solvent and wring-out the excess. Point the gun down and wipe of outside of the gun.

Fig. 10

f the

02060A

02063

Fig. 11

Lubricate

02019

308–293 17

Troubleshooting

WARNING

PRESSURIZED EQUIPMENT HAZARD

o reduce the risk of a serious injury

Pressure Relief Procedure

checking or repairing any part of the gun or sys tem.

PROBLEM CAUSE SOLUTION

on page 13 before

, follow the

Fluid flow is fluttering while spraying

Fluid flow fades while spraying high viscosity fluids

No round pattern control

Pattern becomes of on ends

f-set or heavy

Fluid nozzle not tight enough

Fluid filter clogged

Fluid adjustment knob not properly set

4. Baf

Baf damaged

fle (item 1

or damaged

Air hose size is too restricted for higher air flows

Fluid pressure too low fluid flow to reduce when gun is elevated

fle (item 1

Fluid nozzle is over-tightened

Air cap too tight Air cap horn holes plugged

1) installed wrong

, causing

1) installed wrong or

1. T

ighten fluid nozzle; Do not

exceed 35 in-lbs (4 N

Check fluid filter

3. T

urn the fluid adjustment knob out for less feathering or use a larger size nozzle.

Check if baf properly inserted into gun insert hole; see page 24. Replace baf

fle if damaged.

Use larger 3/8 in. (9.5 mm) ID air hose, part no. 185–353. See Accessories.

Raise fluid pressure at source or use a smaller fluid nozzle.

Check if baf inserted into gun insert hole; see page 24. Replace baf

Do not exceed 35 in-lbs (4 N torque on nozzle. Replace nozzle if damaged.

Loosen air cap retaining ring.

Clean air cap horn holes with non-metallic item such as a toothpick.

fle protrusion is

fle protrusion is properly

m) torque.

fle if damaged.

m)

Fluid system will not operate at low enough fluid pressure [below 10 psi (70, kPa, 0.7 bar)]

18 308–293

There’

s no fluid regulator ulator on pressure pot is not sensi tive enough at low pressures

, or air reg-

Add low pressure fluid regulator

add more sensitive air regulator on pressure pot.

, or

Notes

308–293 19

Items Needed for Service

Service

 Gun Wrench – provided



Seal Installation T



Adjustable W



Screw Driver



Lubricant part no. 111–265; see order



Compatible Solvent

NOTE:



Gun Repair Kit 236–007 is available. The kit in cludes the air valve assembly (14), ring packing (22) u-cup seals (32, 33), and packing assembly (39). See page 25 to order



The following procedure covers the replacement of all the parts included in the Gun Repair Kit.



The Optional M-1265 Spray Gun (part no. 236–020 to 236–022, 236–027 and 236–028) have a two piece needle assembly needle shaft assembly and a SST needle tip, instead of the one-piece needle shown in the following instructions. See Chart 2 on page 5 for part numbers.

ool – provided

rench

Accessories

, which includes a SST

WARNING

12, 19

Fig. 1

Remove the fluid adjustment knob (8) and fluid spring (16). See Fig. 5.

Pull the fluid needle (21) out the back of the gun.

Remove the trigger (3).

Remove the fluid adjustment nut (6), spring (15), and air valve (14).

02060A

PRESSURIZED EQUIPMENT HAZARD

o reduce the risk of a serious injury

Pressure Relief Procedure

checking or repairing any part of the gun or sys tem.

on page 13 before

, follow the

Disassembly

Relieve the pressure.

Remove the air cap retaining ring (12) and air cap (19).

3. T

rigger the gun while you remove the fluid nozzle

(20) with the gun wrench (35). See Fig. 1.

CAUTION

rigger the gun whenever you tighten or remove the nozzle. This keeps the needle seat away from the nozzle seating surface and prevents the seat from being scratched.

8. T

o remove the packing adjustment screw (31),

insert a thin-blade screw driver (A) through the

back of the gun and into the packing adjustment screw (31) as shown in Fig. 2. Be careful not to nick or damage parts with the tool.

A 31

02110

Fig. 2

20 308–293

CAUTION

Service

11.

Clean the parts. Check the fluid needle (21) for damage or excessive wear

. Replace if necessary

Do not use excessive force to push out the packing assembly (39) or the u-cup seal (33) as this may bend the fluid needle (21). Refer to Fig. 3 and 4. If packings are difficult to remove, use a 3/16 in. plastic rod to push them out.

Push the three piece packing assembly (39) out toward the back of the gun, with the threaded end of the fluid needle, as shown in Fig. 3.

Fig. 3

10.

Use the threaded end of the fluid needle (21) to push out the u-cup seal (33) as shown in Fig. 4.

02109A

12.

Check the baf

fle (1

1) for damage. If it is damaged,

carefully pry it off with a screwdriver and replace it.

13.

Lightly lubricate the parts indicated in Fig. 5 with lubricant 1

12 19 20

11–265.

Lightly

lubricate

Lightly lubricate threads

orque to 35–40 in-lbs (3.9–4.5 N

Be sure the baf

the gun insert hole before tightening the nozzle

m)

fle protrusion is properly inserted

Fig. 5

into

02103A

Fig. 4

02022A

308–293 21

Service

Assembly

Insert the fluid needle (21) through the front of the gun as shown in Fig. 6. Install the new packing assembly (39) by placing them on the end of the needle tip. Orientate the packings as shown in Fig. 6.

Washer U-cup;

Fig. 6

down Spreader

lips face



Place the new u-cup seal (33) on the seal installa

4. tion tool (42) with the u-cup lips facing the tool as shown in Fig. 8.

Push the packing (33) into the gun until a definite snap is felt.

U-cup

lips face the tool

Fig. 8

02023

2. Place

the packing adjustment screw (31) over the packing assembly and start the threads into the gun. Then remove the needle.

Insert a thin-blade screw driver (A) through the back of the gun and into the packing adjustment screw (31) as shown in Fig. 7. Be careful not to nick or damage parts with the tool. T

urn the screw with the screw driver (about 3 turns); the packing will still be loose.

A 31

6. Place

the new air valve assembly (14) on the fluid needle (21), against the nut (B). See Fig. 9. This helps align the entrance of the air valve stem into the inside diameter of the u-cup seal (33) without damaging the seal lip.

Install the fluid needle (21) and the air valve assembly (14) into the back of the gun.

Fig. 7

308–293

02110

Fig. 9

02108

8. T

ighten the packing adjustment screw (31) with the gun wrench (35), as shown in Fig. 10, until you can feel a slight drag on the fluid needle. Do not overtighten the screw as this may bind the needle movement.

Fig. 10

Install the trigger (3). T

orque the screw (5) to

10–15 in-lbs (1.1–1.7 Nm). See Fig. 12.

10. Remove

the

u-cup seal (32) from the fluid adjustment nut (6). See Fig. 11. Be careful not to damage the seal

surface or the nut’

s internal threads.

Service

16. Trigger needle does not return after the trigger is released or is slow in returning, loosen the packing adjust ment screw (31) with the gun wrench (35) until the needle returns freely

17. T (20) with the gun wrench (35).

When tightening the nozzle, do not exceed 40 in-lbs (4.5 Nm) torque. Over-tightening the nozzle can

02104A

cause the nozzle hex to round, can af pattern, and is unnecessary to guarantee a seal.

18.

Install the air cap ring (12) and air cap (19).

19.

Make sure the gun fluid packing assembly is sealing properly by spraying solvent at low pres sure before fully pressurizing the gun with the fluid to be sprayed.

the gun to test the needle movement. If the

. See Fig. 10.

rigger the gun while you install the fluid nozzle

CAUTION

fect the spray

11.

Install the new u-cup seal (32) with the seal instal lation tool (42); the u-cup lips must face toward the tool as shown in Fig. 1

1. This will help apply even pressure to the u-cup lips and avoid damaging them.

12.

Push the u-cup seal (32) into the fluid adjustment nut (6) until a definite snap is felt.

13.

Install the new packing ring (22).

lips

tool

face

U-cup

the

22 32

Fig. 11

14. Install

the spring (15) and fluid adjustment nut (6).

orque the nut to 25–35 in-lbs (2.8–4.0 Nm). See

Fig. 12.

15. Install

the spring (16)

and fluid adjustment knob (8).

If the fluid packing leaks, tighten the packing adjustment screw (31) slightly and retest until the packing seals completely

12 19 20

02021

1 2 3 4

5 6

lubricate

Lightly Lightly lubricate threads T

orque to 35–40 in-lbs (3.9–4.5 N

Be sure the baf the gun insert hole before tightening the nozzle

orque to 25–35 in-lb (2.8–4.0 N

orque to 10–15 in-lb (1.1–1.7 N

fle protrusion is properly inserted

m)

into

m) m)

02103A

Fig. 12

308–293 23

Parts

Drawing

13dn

13b

Needle set for optional guns

13cn

Ref

No. 13

Includes items 13a–13d

13a

33*

39*

14*

Needle

for

standard guns

31n

Lightly

1 2 3

lubricate Lightly lubricate threads T

orque to 25–35 in-lbs (2.8–4.0 N

Be sure the baf insert hole before tightening the nozzle

orque to 10–15 in-lbs (1.1–1.7 N

fle protrusion is properly inserted into the gun

Sm)

32*

22*

02025A

U-cup lips face air valve (14)

U-cup lips face spring (16)

Optional gun hook to replace plate (34)

orque to 35–40 in-lb (3.9–4.5 N

orque the screw or any accessory installed in this port to

T 4–6 in-lb (0.35–0.53 N

Sm)

308–293

Part

No. 236–013 to 236–016, Series B

M-1265 Standard HVLP Spray Gun With standard needle, nozzle, and air cap

Includes items 1–42

Part No. 236–020 to 236–028, Series B

M-1265 Optional HVLP Spray Gun With optional needle, nozzle, and air cap

Includes items 1–42

Parts

List

Part No. 236–023 and 236–024, Series B

M-1265 Optional Non-HVLP Compliant Spray Gun With standard needle and nozzle and optional high pressure air cap

Includes items 1–42

Ref No.

1 236–004 2 275–852 3 185–761 4 185–746 5 203–953 SCREW

6 188–490 NUT 8 185–745 11 275–851 12 276–278 RET 13 236–006 PA

13a 188–492 S VAL 13b 188–700 S NUT 13cn 187–699 S 13dn 105–456 S RET 14* 236–009 15 111–291 16 110–402

19. –

20. –

21. – 22* 188–694 25 108–382 PLUG 1 31n 188–665 SCREW 32* 110–453

Part No.

Description Qty

GUN BODY HOOK, gun TRIGGER, two-finger PIN, pivot; 10-24 UNC-2B

, lock; No. 10–24 UNC-2A

x 0.375 in.

, fluid adjustment KNOB, fluid adjustment BAFFLE, pattern

AINING RING, air cap

TTERN ADJUSTMENT VALVE

ASSY

.; Includes items 13a–13d

VE, pattern adjustment

, air adjustment

O-RING, split; PTFE

AINING RING AIR VALVE ASSY SPRING, compression SPRING, compression AIR CAP FLUID NOZZLE FLUID NEEDLE RING P

SEAL, u-cup, nut; UHMWPE

ACKING, PTFE

, packing adjustment

r 1

Ref No.

33* 188–493 1 1 1

1 1 1 1 1

34 275–853 PLA

35 188–666

39* 236–008 P

42 276–268 T

Part No.

These parts are included in which may be purchased separately

Keep these spare parts and the Repair Kit on hand

to reduce down time.

See selection charts for your gun model on pages

4 and 6 to order air caps, fluid nozzles, and fluid

needles.

Manual

Description Qty

SEAL, u-cup; UHMWPE

TE, gun

WRENCH, gun

ACKING ASSY u-cup spreader and packing washer

OOL, seal installation

.; includes

, u-cup seal

Repair Kit 236–007

Change

1 1 1

1 1

Summary

1 1

Changed gun parts.

the Selection Charts to reflect the Series B

308–293

Accessories

Cleaning Brush 105–749

For use in cleaning gun

Lubricant 111–265

One 4 oz. (1 lubricant for fluid seals and wear areas.

Fluid T

Allows air and fluid hoses to be more easily strapped together and eases gun movement by the operator

High Pressure Air Cap 189–755

Optimal air cap for use in non-HVLP compliant opera tions. W

Air Pressure V

For use in checking gun atomizing air pressure at various supply air pressures.

actual spraying.

Assemble kit as shown in drawing below tube connector into gun’ side port. Turn on the air to the gun, then trigger the gun and read the resulting air pressure.

NOTE: T pressure must not exceed 10 psi (70 kPa, 0.7 bar).

SST Fluid Pressure Regulator

13 gram) tube sanitary (non-silicone)

ube Kit 236–318

ater-base compatible

erification Kit 224–187

Not to be used for

. Screw

o be “HVLP compliant”, the atomizing air

100 psi (0.7 MPa, 7 bar) Maximum Inlet Pressure 3–30 psi (21–210 kPa, 0.2–2.1 bar)

Regulated Pressure Range

o regulate the fluid pressure to the gun.

1/4 npt(f) inlet and outlet

236–081 Regulator without

pressure gauge

236–449

Regulator with pressure gauge

03405

Air Hose Quick-disconnect

Install between gun air inlet fitting and air hose.

208–536 Coupler, 1/4 npt(f) 169–970

Fluid Hose Assembly 205–142

Nipple,

1/4 npt(m)

300 psi (2.1 MPa, 21 bar) Maximum Working Pressure

Nylon with neoprene cover 3/8 npsm(fbe), 25 ft. (7.6 m) long

Air Filter and Moisture Separator 106–149

, 0.25 in. (2.4 mm) ID,

250 psi (1.7 MPa, 17.4 bar) Maximum

Working Pressure

Removes moisture, oil, and other contami nants from the compressed air supply 1/2 npt(fbe)

Air Pressure Regulator Kit 210–613

300 psi (2.1 MPa, 20 bar) Maximum

Inlet Pressure

0-125 psi (0–0.87 MPa, 0-8.75 bar)

Regulated Pressure Range

o regulate the air pressure to the gun. Includes gauge, air shutof fittings. 1/4 npt(m)

Air Shutoff V

alve 208–390

f valve, and

0135

500 psi (3.4 MPa, 34 bar) Maximum Working Pressure

o shutof

Gun Air Regulator Assy

f air supply line. 1/4 npt(m)

. 235–1

0–100 psi (0–0.7 MPa, 0–7 bar) air

regulator to control air to gun

01727

Air Hose Assembly 210–867

100 psi (0.7 MPa, 7 bar) Maximum Working Pressure

25 ft. (7.625 m) long, 5/16 in. (7.94 mm) ID, 1/4 npsm(f) swivel, buna-n

Air Hose Assembly 185–353

100 psi (0.7 MPa, 7 bar) Maximum Working Pressure

Optional air hose for use when higher air flow is required. 25 ft. (7.625 m) long, 3/8 in. (9.53 mm) ID, 1/4 npsm(f) swivel, buna-n

26 308–293

SST Pressure Cup Kit 235–373 with single air regulator

1 qt. (0.95 liter) capacity steel cup. Includes a pressure relief valve and a single air regulator and gauge.

, 304 stainless

01725

Accessories

SST Pressure Cup Kit 235–374 with double air regulator

1 qt. (0.95 liter) capacity

, 304 stainless steel cup. Includes a pressure relief valve, a 0–100 psi (0–0.7 MPa, 0–7 bar) air regulator for gun atomization, and a 0–15 psi (0–104 kPa, 0–1.0 bar) air regulator for the 1 qt. pressure cup supply air

Gravity Cup Kit 236–038

7.5 oz. (220 cc) capacity

, 430 stainless

steel cup, 3/8 npsm(f) fluid inlet

1 Quart Pressure Cup Kit 224–426

1 qt. (0.95 liter) capacity

, aluminum cup

Some assembly required. Includes:

Part No. 224–419

Description

1 Quart Pressure Cup Assy

(with check valve)

111–324 111–328 187–169 T

Female Connector Male Connector

, 10-32 x 5/32 tube

ubing, 5/32” OD

, 1/8 npt x 5/32 tube

01726

0125

., aluminum

Disposable Polyethylene Cup Liners

Paint and solvent resistant. 40 liners per box.

112–490 112–491

1 Quart Cup Size 2 Quart Cup Size

2 Quart Pressure Cup 214–627

2 qt. (1.94 liter) capacity

, aluminum cup Includes air pressure regulator and gauge, 4 ft. (1.2 m) length air and fluid hose with 1/4 npsm(f) swivel ends, pressure relief valve, and rigid hook handle.

0123

Pressure T

2.5 gal (9.5 liter) capacity

ank 171–226

, aluminum

0122

tank. Includes air pressure regulator and gauge, pressure relief valve, pick

up tube, and rigid hook handle.

1 Quart Remote SST Pressure Cup 235–054

1 qt. (0.95 liter) capacity, 304 stainless steel cup. Includes air pressure regulator and gauge, 4 ft. (1.2 m) length air and fluid hose with 1/4 npsm(f) swivel ends, pressure relief valve, and rigid hook handle.

0166

01962

Husky

Includes Husky 307 Pump, Pail Cover Suction T

307 HVLP Systems

ube and Inlet Filter

, Air Regulators,

, Fluid Regulator

Recirculation Line, and Air and Fluid Hoses

Part No. 224–833

235–659

Description

SST Pail Mount System Carbon Steel Pail Mount System

, Fluid

01526

308–293 27

Accessories

Low Pressure SST Pressure T

For fluid pressures up to 15 psi (104 kPa, 1.0 bar)

gallons

Low

Pressure T

ank Size

(liters)

5 (19) 236–143 236–146 236–149 236–152 10 (38) 236–144 236–147 236–150 236–153 15 (57) 236–145 236–148 236–151 236–154

ank

Low

anks

Pressure T

P/N

03084

ank

Low Pressure T

High Pressure SST Pressure T

For fluid pressures up to100 psi (700 kPa, 7 bar)

ank

with Agitator P/N

High Pressure T with Agitator

High Pressure T

P/N

ank

anks

ank

High Pressure T

with Agitator P/N

ank

03189

Dimensions

6.39

in.

(163 mm)

6.9 in. (175 mm)

02018

Technical

Category Data

Maximum Working Fluid Pressure

Maximum W Pressure

Maximum Compliant Inbound Air Pressure

Fluid and Air Operating T

emperature Range Weight Air Inlet

Fluid Inlet

etted Parts

Noise Data*

Sound psi (444 kPa, 4.4 bar) Sound Power at 65 psi (444 kPa, 4.4 bar):

* All

readings were taken with the gun controls fully open at the assumed operator position. Sound pressure was tested to CAGI–PNUEROP–1969. Sound power was tested to ISO 3744–1981.

orking Air

Pressure at 65

Data

100 psi (0.7 MPa, 7 bar)

65 psi (444 kPa, 4.4 bar)

32

F to 140

60

14.9 oz. (422 g) 1/4–18 npsm (R1/4–19)

compound thread 3/8–18 npsm (R3/8–19)

compound thread 304 and 17–4 PH

Stainless Steel

Db(A)

101 Db(A)

 F (0

C to

28 308–293

Notes

308–293

Notes

30 308–293

Notes

308–293 31

Graco

WARRANTY

Graco

warrants all equipment listed in this manual which is manufactured by Graco and bearing its name to be free from defects in material and workmanship on the date of sale by an authorized Graco distributor to the original purchaser for use. Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defec tive. This warranty applies only when the equipment is installed, operated and maintained in accordance with Graco’ ommendations.

This warranty does not cover caused by faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of non-Graco component parts. Nor shall Graco be liable for malfunction, damage or wear caused by the incompatibility of Graco equipment with structures, accessories, equipment or materials not supplied by Graco, or the im proper design, manufacture, installation, operation or maintenance of structures, accessories, equipment or materials not sup plied by Graco.

This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized Graco distributor for verification of the claimed defect. If the claimed defect is verified, Graco will repair or replace free of charge any defective parts. The equipment will be returned to the original purchaser transportation prepaid. If inspection of the equipment does not disclose any defect in material or workmanship, repairs will be made at a reasonable charge, which charges may include the costs of parts, labor

THIS WARRANTY IS EXCLUSIVE, AND IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTY OF MERCHANTABILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE.

s sole obligation and buyer’s sole remedy for any breach of warranty shall be as set forth above. The buyer agrees that no

Graco’ other

remedy (including, but not limited

, or any other incidental or consequential loss) shall be available. Any action for breach of warranty must be brought within two

erty (2)

years of the date of sale.

GRACO MAKES NO WARRANTY, AND DISCLAIMS ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE IN CONNECTION WITH SOLD BUT NOT MANUFACTURED BY GRACO.

switches, hose, etc.) are subject to the warranty tance in making any claim for breach of these warranties.

arranty and Limitation of Liability

, and Graco shall not be liable for general wear and tear

, and transportation.

s written rec-

, or any malfunction, damage or wear

to, incidental or consequential damages for lost profits, lost sales, injury to person or prop

ACCESSORIES, EQUIPMENT

These items sold, but not manufactured by Graco (such as electric motors,

, if any

, of their manufacturer

. Graco will provide purchaser with reasonable assis

, MA

TERIALS, OR COMPONENTS

For Sales to Canadian Customers:

Except as expressly stated herein, Graco makes no representations, warranties or conditions, express, implied or collateral, con cerning any goods or services sold, and warranty

MERCHANTABLE QUALITY OR FITNESS FOR A PARTICULAR PURPOSE. LIMITATION OF LIABILITY

In no event will Graco be liable for indirect, incidental, special or consequential damages resulting from Graco supplying equip ment hereunder contract, breach of warranty

or condition of any kind, whether arising by operation of law or otherwise, including but not limited to,

, or for the furnishing, performance, or use of any products or other goods sold hereto, whether due to a breach of

, the negligence of Graco, or otherwise.

Graco

PLACE AN ORDER

All

written and visual data contained in this document reflects the latest product information available at the time of publication.

, contact your Graco distributor

Graco reserves the right to make changes at any time without notice.

GRACO SHALL NOT BE LIABLE IN ANY MANNER FOR

Phone Numbers

, or call this number to identify the distributor closest to you:

1–800–367–4023 T

oll Free

any other representation,

WARRANTIES OF

32 308–293

Foreign Offices:

Sales Offices:

Belgium, Canada, England, Korea, France, Germany

GRACO INC. P.O. BOX 1441

PRINTED

IN U.S.A. 308–293 May 1993, Revised February 1997

Minneapolis, Detroit, Los Angeles

MINNEAPOLIS, MN

, Hong Kong, Japan

55440–1441

Graco 02017, 308-293, M-1265 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
